1.   Introduction

A semiring is an algebra with two associative binary operations $+, \cdot$, in which $+$ is commutative and $\cdot$ distributive over $+$ from the left and right. Such an algebra is a common generalization of both rings and distributive lattices. It has broad applications in information science and theoretical computer science (see ^[5,6]). In this paper, we shall investigate some small-order semirings which will play a crucial role in subsequent follows.

The semiring A with addition and multiplication table (see ^[12])

The semiring B with addition and multiplication table (see ^[4])

Eight 2-element semirings with addition and multiplication table (see ^[2])

For any semiring $S$, we denote by $S^{0}$ the semiring obtained from $S$ by adding an extra element $0$ and where $a = 0+a = a+0, 0 = 0a = a0$ for every $a\in S$. For any semiring $S$, $S^{\ast}$ will denote the (multiplicative) left-right dual of $S$. In 2005, Pastijn et al. ^[4,9,10] studied the semiring variety generated by $B^{0}$ and $(B^{0})^{\ast}$ (Denoted by ${\bf{Sr}}(2, 1)$). They showed that the lattice of subvarieties of this variety is distributive and contains 78 varieties precisely. Moreover, each of these is finitely based. In 2016, Ren et al. ^[12,13] studied the variety generated by $B^{0}, (B^{0})^{\ast}$ and $A^{0}$ (Denoted by ${\bf{Sr}}(3, 1)$). They showed that the lattice of subvarieties of this variety is distributive and contains 179 varieties precisely. Moreover, each of these is finitely based. From ^[4,10], we have ${\bf{HSP}}(L_{2}, R_{2}, M_{2}, D_{2})\subsetneqq{\bf{HSP}}(B^{0}, (B^{0})^{\ast}).$ So

In 2016, Shao and Ren ^[15] studied the variety ${\bf{HSP}}(L_{2}, R_{2}, M_{2}, D_{2}, Z_2, W_2)$ (Denoted by ${\bf{S}}_6$). They showed that the lattice of subvarieties of this variety is distributive and contains 64 varieties precisely. Moreover, each of these is finitely based. Recently, Ren and Zeng ^[14] studied the variety generated by $B^{0}, (B^{0})^{\ast}, N_{2}, T_{2}$. They proved that the lattice of subvarieties of this variety is a distributive lattice of order 312 and that each of its subvarieties is finitely based. In ^[16], Wang, Wang and Li studied the variety generated by $B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2}$. They proved that the lattice of subvarieties of this variety is a distributive lattice of order 716 and that each of its subvarieties is finitely based. It is easy to check

So semiring variety ${\bf{HSP}}{(B^{0}, (B^{0})^{\ast}, A^0, N_{2}, T_{2})}$ is a proper subvariety of the semiring variety ${\bf{HSP}}(B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2}, Z_2, W_2)$. The main purpose of this paper is to study the variety ${\bf{HSP}}(B^{0}, (B^{0})^{\ast},$ $A^{0}, N_{2}, T_{2}, Z_2, W_2)$. We show that the lattice of subvarieties of this variety is a distributive lattice of order 2327. Moreover, we show this variety is hereditarily finitely based.

2.   Preliminaries

By a variety we mean a class of algebras of the same type that is closed under subalgebras, homomorphic images and direct products (see ^[11]). Let ${\bf{W}}$ be a variety, let $\cal{L}({\bf{W}})$ denote the lattice of subvarieties of ${\bf{W}}$ and let ${\rm{Id}}_{\bf W}(X)$ denote the set of all identities defining ${\bf{W}}$. If ${\bf{W}}$ can be defined by finitely many identities, then we say that $\bf W$ is finitely based (see ^[14]). In other words, $\bf W$ is said to be finitely based if there exists a finite subset $\Sigma$ of ${\rm{Id}}_{\bf W}(X)$ such that for any $p\approx q\in {\rm{Id}}_{\bf W}(X)$, $p\approx q$ can be derived from $\Sigma$, i.e., $\Sigma\vdash p\approx q$. Otherwise, we say that ${\bf W}$ is nonfinitely based. Recall that ${\bf{W}}$ is said to be hereditarily finitely based if all members of ${\cal L}({\bf{W}})$ are finitely based. If a variety ${\bf{W}}$ is finitely based and ${\cal L}({\bf{W}})$ is a finite lattice, then ${\bf{W}}$ is hereditarily finitely based (see ^[14]).

A semiring is called an additively idempotent semiring (ai-semiring for short) if its additive reduct is a semilattice, i.e., a commutative idempotent semigroup. It is also called a semilattice-ordered semigroup (see ^[3,8,12]). The variety of all semirings (resp. all ai-semirings) is denoted by ${\bf{SR}}$ (resp. AI). Let $X$ denote a fixed countably infinite set of variables and $X^{+}$ the free semigroup on $X$ (see ^[8]). A semiring identity (SR-identity for short) is an expression of the form $u\approx v$, where $u$ and $v$ are terms with $u = u_1+\cdots +u_k$, $v = v_1+\cdots+v_\ell$, where $u_i, v_j\in X^+$. Let $\underline{k}$ denote the set $\{1, 2, \ldots, k\}$ for a positive integer $k$, $\Sigma$ be a set of identities which include the identities determining AI (Each identity in $\Sigma$ is called an AI-identity) and $u\approx v$ be an AI-identity. It is easy to check that the ai-semiring variety defined by $u\approx v$ coincides with the ai-semiring variety defined by the identities $u\approx u+v_{j}, v\approx v+u_i, i\in \underline{k}, j\in \underline{\ell}$. Thus, in order to show that $u\approx v$ is derivable from $\Sigma$, we only need to show that $u\approx u+v_{j}, v\approx v+u_i, i\in \underline{k}, j\in \underline{\ell}$ can be derived from $\Sigma$ (see ^[9]).

To solve the word problem for the variety ${\bf{HSP}}(B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2}, Z_2, W_2)$, the following notions and notations are needed. Let $q$ be an element of $X^+$. Then

● the head of $q$, denoted by $h(q)$, is the first variable occurring in $q$;

● the tail of $q$, denoted by $t(q)$, is the last variable occurring in $q$;

● the content of $q$, denoted by $c(q)$, is the set of variables occurring in $q$;

● the length of $q$, denoted by $|q|$, is the number of variables occurring in $q$ counting multiplicities;

● the initial part of $q$, denoted by $i(q)$, is the word obtained from $q$ by retaining only the first occurrence of each variable;

● the final part of $q$, denoted by $f(q)$, is the word obtained from $q$ by retaining only the last occurrence of each variable;

● $r(q)$ denotes set $\{x\in X\, |\, \mbox{the number of occurrences of $x$ in $q$ is odd}\}$.

By [13,Lemma 1.2], ${\bf{Sr}}(3, 1)$ satisfies the identity $p\approx q$ if and only if $(i(p), f(p), r(p)) = (i(q), f(q),$ $r(q))$. This result will be used later without any further notice. The basis for each one of $N_2, T_2, Z_2, W_2$ can be found from ^[2] (See Table 1).

By [15,Lemma 1.1] and the Table 1, we have

Lemma 2.1. Let $u\approx v$ be a nontrivial ${\bf{SR}}$-identity, where $u = u_1+u_2+\cdots+u_m$, $v = v_1+v_2+\cdots+v_n$, $u_i, v_j\in X^+$, $i\in\underline{m}, j\in\underline{n}$. Then

$\textrm{(i)}$ $N_2\models u\approx v\; {if\; and\; only\; if}\; \{u_{i}\in u\, |\, |u_{i}| = 1\} = \{v_{i}\in v\, |\, |v_{i}| = 1\}$;

$\textrm{(ii)}$ $T_2\models u\approx v\; {if\; and\; only\; if}\; \{u_{i}\in u\, |\, |u_{i}|\geq 2\}\neq\phi, \, \{v_{i}\in v\, |\, |v_{i}|\geq 2\}\neq\phi$;

$\textrm{(iii)}$ $Z_2\models u\approx v\; {if\; and\; only\; if}\; (\forall x\in X)\, u\neq x, \, v\neq x$;

$\textrm{(iv)}$ $W_2\models u\approx v\; {if\; and\; only\; if}\; m = n = 1, c(u_{1}) = c(v_{1})\; {or}\; m, n\geq2$.

Suppose that $u = u_1+\cdots+u_m, u_i\in X^+, i\in \underline{m}$. Let $1$ be a symbol which is not in $X$ and $Y$ an arbitrary subset of $\bigcup^{i = m}_{i = 1}c(u_1)$. For any $u_i$ in $u$, if $c(u_i)\subseteq Y$, put $h_Y(u_i) = 1$. Otherwise, we shall denote by $h_Y(u_i)$ the first variable occurring in the word obtained from $u_i$ by deleting all variables in $Y$. The set $\{h_{Y}(u_i)|u_i\in u\}$ is written $H_Y(u)$. Dually, we have the notations $t_{Y}(u_i)$ and $T_{Y}(u_i)$. In particular, if $Y = \emptyset$, then $h_{Y}(u_i) = h(u_i)$ and $t_{Y}(u_i) = t(u_i)$. Moreover, if $c(u_i)\cap Y\neq\emptyset$ for every $u_i$ in $u$, then we write $D_Y(u) = \emptyset$. Otherwise, $D_Y(u)$ is the sum of all terms $u_i$ in $u$ such that $c(u_i)\cap Y = \emptyset$. By [13,Lemma 2.3 and 2.11] and [4,Lemma 2.4 and its dual,Lemma 2.5 and 2.6], we have

Lemma 2.2. Let $u\approx u+q$ be an AI-identity, where $u = u_{1}+\cdots+u_{m}, u_{i}, q\in X^{+}, i\in \underline{m}$. If $u\approx u+q$ holds in ${\bf{Sr}}(3, 1)$, then

$\textrm{(i)}$ for every $Z\subseteq \bigcup^{i = m}_{i = 1}c(u_i)\backslash c(q)$, there exists $p_1$ in $X^+$ with $r(p_1) = r(q)$ and $c(q)\subseteq c(p_1)\subseteq \bigcup^{i = k}_{i = 1}c(u_i)$ such that $D_Z(u)\approx D_Z(u)+p_1$ holds in ${\bf{Sr}}(3, 1)$, where $D_Z(u) = u_1+\cdots +u_k$.

$\textrm{(ii)}$ for every $Y\subseteq Z = \bigcup^{i = m}_{i = 1}c(u_i)\backslash c(q)$, $H_Y(D_Z(u)) = H_Y(D_Z(u)+p_1)$ and $T_Y(D_Z(u)) = T_Y(D_Z(u)+p_1)$.

Throughout this paper, $u\overset{(3.1), (3.2), \cdots}\approx v$ denotes the identity $u\approx v$ can be derived from the identities $(3.1), (3.2), \cdots$ and the identities determining ${\bf{SR}}$. For other notations and terminology used in this paper, the reader is referred to ^{[1,4,7,13,15]}.

3.   Equational basis of ${\bf{HSP}}(B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2}, Z_2, W_2)$

In this section, we shall show that the variety ${\bf{HSP}}(B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2}, Z_2, W_2)$ is finitely based. Indeed, we have

Theorem 3.1. The semiring variety ${\bf{HSP}}(B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2}, Z_2, W_2)$ is determined by (3.1)–(3.12),

Proof. From ^[13] and Lemma 2.1, we know that both ${\bf{Sr}}{(3, 1)}$ and ${\bf{HSP}}(N_2, T_2, Z_{2}, W_{2})$ satisfy identities (3.1)–(3.12) and so does ${\bf{HSP}}(B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2}, Z_2, W_2)$.

Next, we shall show that every identity that holds in ${\bf{HSP}}(B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2}, Z_2, W_2)$ can be derived from (3.1)–(3.12) and the identities determining $\textbf{SR}$. Let $u\approx v$ be such an identity, where $u = u_1+u_2+\cdots+u_m$, $v = v_1+v_2+\cdots+v_n$, $u_i, v_j\in X^+$, $1\leq i\leq m, 1\leq j\leq n.$ By Lemma 2.1 (ⅳ), we only need to consider the following two cases:

Case 1. $m = n = 1$ and $c(u_{1}) = c(v_{1})$. From ${\bf{Sr}}(3, 1), T_2, Z_2\models u_{1}\approx v_{1},$ it follows that $(i(u_{1}), f(u_{1}), r(u_{1})) = (i(v_{1}), f(v_{1}), r(v_{1}))$, $|u_{1}|\geq 2$ and $|v_{1}|\geq2$. Hence $u_{1}\overset{(3.1)\sim(3.6)}\approx v_{1}$.

Case 2. $m, n\geq2.$ It is easy to verify that $u\approx v$ and the identity $(3.12)$ imply the identities $u\approx u+v_j,$ $v\approx v+u_i$ for all $i, j$ such that $1\leq i\leq m, 1\leq j\leq n.$ Conversely, the latter $m+n$ identities imply $u\approx u+v\approx v$. Thus, to show that $u\approx v$ is derivable from (3.1)–(3.12) and the identities determining $\textbf{SR}$, we need only show that the simpler identities $u\approx u+v_j,$ $v\approx v+u_i$ for all $i, j$ such that $1\leq i\leq m, 1\leq j\leq n.$ Hence we need to consider the following two cases:

Case 2.1. $u\approx u+q,$ where $|q| = 1$. Since $N_2\models u\approx u+q,$ there exists $u_s = q$. Thus $u+q\approx u'+u_s+q\approx u'+u_s+u_s\overset{(3.12)}\approx u'+u_s\approx u.$

Case 2.2. $u\approx u+q,$ where $|q|\geq 2$. Since $u\approx u+q$ holds in $T_{2}$, it follows from Lemma 2.1 (ⅱ) that there exists $u_{i}$ in $u$ such that $u_{i} > 1$. Put $Z = (\bigcup_{i = 1}^{i = m}c(u_{i}))\backslash c(q)$. Assume that $D_{Z}(u) = u_{1}+\cdots+u_{k}$. Then $\bigcup_{i = 1}^{i = k}c(u_{i}) = c(q)$. By Lemma 2.2 (ⅰ), there exists $p_1\in X^+$ such that $r(p_1) = r(q)$ and $c(q)\subseteq c(p_1)\subseteq \bigcup_{i = 1}^{i = k}c(u_{i})$. Moreover,

Write $p = p^{3}_{1}u^{2}_{1}u^{2}_{2}\cdots u^{2}_{k}$. Thus $c(p) = c(q)$, $r(p) = r(q)$ and we have derived the identity

Due to $|p| > 1$, it follows that (3.4) implies the identity

Suppose that $i(q) = x_{1}x_{2}\cdots x_{\ell}$. We shall show by induction on $j$ that for every $1\leq j\leq\ell$, $u\approx u+x^{2}_{1}x^{2}_{2}\cdots x^{2}_{\ell}p$ is derivable from (3.1)–(3.11) and the identities defining SR.

From Lemma 2.1 (ⅱ), there exists $u_{i_{1}}$ in $D_Z(u)$ with $c(u_{i_{1}})\subseteq c(q)$ such that $h(u_{i_{1}}) = h(q) = x_1$. Furthermore,

Therefore

Assume that for some $1 < j\leq\ell$,

is derivable from (3.1–3.12) and the identities defining SR. By Lemma 2.1 (ⅱ), there exists $u_i$ in $D_Z(u)$ with $c(u_i)\subseteq c(q)$ such that $u_{i} = u_{i_{1}}x_{j}u_{i_{2}}$ and $c(u_{i_{1}})\subseteq\{x_1, x_2, \ldots, x_{j-1}\}.$ It follows that

Consequently

Moreover, we have

Hence $u\approx u+x^{2}_1x^{2}_2\cdots x^{2}_{j-1}x^{2}_{j}p$. Using induction we have

Dually,

Thus

It follows that $u\approx u+q$.

4.   The lattice ${\cal L}({\bf{HSP}}(B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2}, Z_2, W_2))$

In this section we characterize the lattice ${\cal L}({\bf{HSP}}(B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2}, Z_2, W_2))$. Throughout this section, $t(x_1, \ldots, x_n)$ denotes the term $t$ which contains no other variables than $x_1, \ldots, x_n$ (but not necessarily all of them). Let $S \in{\bf{HSP}}(B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2}, Z_2, W_2)$ and let $E^{+}(S)$ denote the set $\{a\in S\, |\, a+a = a\}$, where any element of $E^{+}(S)$ is said to be an additive idempotent of $(S, +)$. Notice that ${\bf{HSP}}(B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2}, Z_2, W_2)$ satisfies the identities

By (4.1) and (4.2), it is easy to verify that $E^{+}(S) = \{a+a\, |\, a\in S\}$ forms a subsemiring of $S$. To characterize the lattice ${\cal L}({\bf{HSP}}(B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2}, Z_2, W_2))$, we need to consider the following mapping

It is easy to prove that $\varphi({\bf{W}}) = \{E^{+}(S)\, |\, S\in {\bf{W}}\}$ for each member ${\bf{W}}$ of ${\cal L}({\bf{HSP}}(B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2},$ $Z_2, W_2))$. If ${\bf{W}}$ is the subvariety of ${\bf{HSP}}(B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2})$ determined by the identities

then ${\widehat{\bf{W}}}$ denotes the subvariety of ${\bf{HSP}}(B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2}, Z_2, W_2)$ determined by the identities

Lemma 4.1. ^[16] The ai-semiring variety ${\bf{HSP}}(B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2})$ is determined by the identities (3.1)–(3.11) and ${\cal L}({\bf{HSP}}(B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2}))$ is a distributive lattice of order 716.

Lemma 4.2. Let ${\bf{W}}$ be a member of ${\cal L}({\bf{HSP}}(B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2}))$. Then, ${\widehat{\bf{W}}} = {\bf{W}}\vee{\bf{HSP}}(Z_2, W_2).$

Proof. Since ${\bf{W}}$ satisfies the identities (4.4), it follows that ${\bf{W}}$ is a subvariety of ${\widehat{\bf{W}}}$. Both $Z_2$ and $W_2$ are members of ${\widehat{\bf{W}}}$ and so ${\bf{W}}\vee{\bf{HSP}}(Z_2, W_2)\subseteq{\widehat{\bf{W}}}$. To show the converse inclusion, it suffices to show that every identity that is satisfied by ${\bf{W}}\vee{\bf{HSP}}(Z_2, W_2)$ can be derived by the identities holding in ${\bf{HSP}}(B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2}, Z_2, W_2)$ and

if ${\bf{W}}$ is the subvariety of ${\cal L}({\bf{HSP}}(B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2}))$ determined by $u_i(x_{i_1}, \ldots, x_{i_{n}})\approx v_i(x_{i_1}, \ldots, x_{i_{n}}),$ $i\in \underline{k}$. Let $u\approx v$ be such an identity, where $u = u_{1}+u_{2}+\cdots+u_{m}, v = v_{1}+v_{2}+\cdots+v_{n}, u_{i}, v_{j}\in X^{+}, 1\leq i\leq m, 1\leq j\leq n$. By Lemma 2.1 (8), we only need to consider the following two cases.

Case 1. $m, n\geq 2$. By identity (3.12), ${\bf{HSP}}(B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2}, Z_2, W_2)$ satisfies the identities

Since $u\approx v$ holds in ${\bf{HSP}}(B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2})$, we have that it is derivable from the collection $\Sigma$ of $u_i\approx v_i, i\in \underline{k}$ and the identities determining ${\bf{HSP}}(B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2})$. From [1,Exercise Ⅱ.14.11], it follows that there exist $t_1, t_2, \ldots, t_\ell\in P_{f}(X^+)$ such that

● $t_1 = u, t_\ell = v$;

● For any $i = 1, 2, \ldots, \ell-1$, there exist $p_i, q_i, r_i\in P_{f}(X^+)$ (where $p_i$, $q_i$ and $r_i$ may be empty words), a semiring substitution $\varphi_{i}$ and an identity $u'_{i}\approx v'_{i}\in \Sigma$ such that

Let $\Sigma'$ denote the set $\{u+u\approx v+v\, |\, u\approx v\in \Sigma\}$. For any $i = 1, 2, \ldots, \ell-1$, we shall show that $t_{i}+t_i\approx t_{i+1}+t_{i+1}$ is derivable from $\Sigma'$ and the identities holding in ${\bf{HSP}}(B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2}, Z_2, W_2)$. Indeed, we have

Further,

This implies the identity

We now have

Case 2. $m = n = 1$ and $c(u) = c(v)$. Since $Z_2\models u_{1}\approx v_{1}$, $u_{1}\neq x, v_{1}\neq x$, for every $x\in X$. Since $u_{1}\approx v_{1}$ holds in ${\bf{HSP}}(B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2})$, we have that it is derivable from the collection $\Sigma$ of $u_i\approx v_i, i\in \underline{k}$ and the identities defining ${\bf{HSP}}(B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2})$. From [1,Exercise Ⅱ.14.11], it follows that there exist $t_1, t_2, \ldots, t_\ell\in P_{f}(X^+)$ such that

● $t_1 = u_1, t_\ell = v_1$;

● For any $i = 1, 2, \ldots, \ell-1$, there exist $p_i, q_i\in P_{f}(X^+)$ (where $p_i$ and $q_i$ may be empty words), a semiring substitution $\varphi_{i}$ and an identity $u'_{i}\approx v'_{i}\in \Sigma$ (where $u'_{i}$ and $v'_{i}$ are words) such that

By Lemma 4.1, we have that $u_{1}\approx v_{1}$ can be derived from (3.1)–(3.6), so, by Theorem 3.1, it can be derived from monomial identities holding in ${\bf{HSP}}(B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2}, Z_2, W_2)$. This completes the proof.

Lemma 4.3. The following equality holds

There are $716$ intervals in ${\cal L}({\bf{HSP}}(B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2}, Z_2, W_2))$, and each interval is a congruence class of the kernel of the complete epimorphism $\varphi$ in $\textrm{(4.3)}$.

Proof. Firstly, we shall show that equality (4.9) holds. It is easy to see that

So it suffices to show that

for each member ${\bf{W}}$ of ${\cal L}({\bf{HSP}}(B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2}))$. If ${\bf{W}}_1$ is a member of $[{\bf{W}}, \widehat{{\bf{W}}}]$, then it is routine to verify that ${\bf{W}}\subseteq \{E^+(S)\, |\, S\in {\bf{W}}_1\}\subseteq {\bf{W}}$. This implies that $\{E^+(S)\, |\, S\in {\bf{W}}_1\} = {\bf{W}}$ and so $\varphi({\bf{W}}_1) = {\bf{W}}$. Hence, ${\bf{W}}_1$ is a member of $\varphi^{-1}({\bf{W}})$ and so $[{\bf{W}}, \widehat{{\bf{W}}}]\subseteq \varphi^{-1}({\bf{W}})$. Conversely, if ${\bf{W}}_1$ is a member of $\varphi^{-1}({\bf{W}})$, then ${\bf{W}} = \varphi({\bf{W}}_1) = \{E^+(S)\, |\, S\in {\bf{W}}_1\}$ and so $\varphi^{-1}({\bf{W}})\subseteq[{\bf{W}}, \widehat{{\bf{W}}}]$. This shows that (4.9) holds.

From Lemma 4.1, we know that ${\cal L}({\bf{HSP}}(B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2}))$ is a lattice of order $716$. So there are $716$ intervals in ${\cal L}({\bf{HSP}}(B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2}, Z_2, W_2))$. Next, we show that $\varphi$ a complete epimorphism. On one hand, it is easy to see that $\varphi$ is a complete $\wedge$-epimorphism. On the other hand, let $({\bf{W}}_i)_{i\in I}$ be a family of members of ${\cal L}({\bf{HSP}}(B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2}, Z_2,$ $W_2))$. Then, by (4.3), we have that $\varphi({\bf{W}}_i)\subseteq {\bf{W}}_i\subseteq \widehat{\varphi({\bf{W}}_i)}$ for each $i\in I$. Further,

This implies that $\varphi(\underset{i\in I}\bigvee{\bf{W}}_i) = \underset{i\in I}\bigvee\varphi({\bf{W}}_i).$ Thus, $\varphi$ is a complete $\vee$-homomorphism and so $\varphi$ is a complete $\vee$-epimorphism. By (4.10), we deduce that each interval in (4.3) is a congruence class of the kernel of the complete epimorphism $\varphi$.

In order to characterize the lattice ${\cal L}({\bf{HSP}}(B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2}, Z_2, W_2))$, by Lemma 4.3, we only need to describe the interval $[{\bf{W}}, {\widehat{\bf{W}}}]$ for each member ${\bf{W}}$ of ${\cal L}({\bf{HSP}}(B^{0},$ $(B^{0})^{\ast}, A^{0}, N_{2}, T_{2}))$. Next, we have

Lemma 4.4. Let ${\bf{W}}$ be a member of ${\cal L}({\bf{HSP}}(B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2}))$. Then, ${\bf{W}}\vee{\bf{HSP}}(Z_2)$ is the subvariety of $\widehat{{\bf{W}}}$ determined by the identity

Proof. It is easy to see that both, ${\bf{W}}$ and ${\bf{HSP}}(Z_2)$ satisfy the identity (4.11) and so does ${\bf{W}}\vee{\bf{HSP}}(Z_2)$. In the following we prove that every identity that is satisfied by ${\bf{W}}\vee{\bf{HSP}}(Z_2)$ is derivable from (4.11) and the identities holding in $\widehat{{\bf{W}}}$. Let $u\approx v$ be such an identity, where $u = u_{1}+u_{2}+\cdots+u_{m}, v = v_{1}+v_{2}+\cdots+v_{n}, u_{i}, v_{j}\in X^{+}, 1\leq i\leq m, 1\leq j\leq n$. We only need to consider the following cases.

Case 1. $m = n = 1$. Since $Z_2$ satisfies $u_{1}\approx v_{1}$, it follows that $|u_{1}|\neq 1$ and $|v_{1}|\neq1$. By Lemma 4.2, $\widehat{{\bf{W}}}$ satisfies the identity $u_1^3+u_1^3\approx v_1^3+v_1^3$. Hence $u_1\overset{(3.4)}\approx u_1^3\overset{(4.11)}\approx u_1^3+u_1^3\approx v_1^3+v_1^3\overset{(4.11)}\approx v_1^3\overset{(3.4)}\approx v_1$.

Case 2. $m = 1$, $n\geq 2$. Since $Z_2$ satisfies $u_{1}\approx v$, it follows that $|u_{1}|\neq 1$. By Lemma 4.2, $\widehat{{\bf{W}}}$ satisfies the identity $u_1^3+u_1^3\approx v+v$. Hence $u_1\overset{(3.4)}\approx u^3_1\overset{(4.11)}\approx u^3_1+u^3_1\approx v+v\overset{(3.11)}\approx v$.

Case 3. $m\geq 2$, $n = 1$. Similar to Case 2.

Case 4. $m, n\geq 2$. By Lemma 4.2, $\widehat{{\bf{W}}}$ satisfies the identity $u+u\approx v+v$. Hence $u\overset{(3.11)}\approx u+u\approx v+v\overset{(3.11)}\approx v$.

Lemma 4.5. Let ${\bf{W}}$ be a member of ${\cal L}({\bf{Sr}}(3, 1))$. Then ${\bf{W}}\vee{\bf{HSP}}(W_2)$ is the subvariety of $\widehat{{\bf{W}}}$ determined by the identities

Proof. It is easy to see that both, ${\bf{W}}$ and ${\bf{HSP}}(W_2)$ satisfy the identity (4.12) and so does ${\bf{W}}\vee{\bf{HSP}}(W_2)$. So it suffices to show that every identity that is satisfied by ${\bf{W}}\vee{\bf{HSP}}(W_2)$ is derivable from (4.12) and the identities holding in $\widehat{{\bf{W}}}$. Let $u\approx v$ be such an identity, where $u = u_{1}+u_{2}+\cdots+u_{m}, v = v_{1}+v_{2}+\cdots+v_{n}, u_{i}, v_{j}\in X^{+}, 1\leq i\leq m, 1\leq j\leq n$. By Lemma 4.2, $\widehat{{\bf{W}}}$ satisfies the identity $u^{3}\approx v^{3}$. Hence, $u\overset{(4.12)}\approx u^{3}\approx v^{3}\overset{(4.12)}\approx v$.

Lemma 4.6. Let ${\bf{W}}$ be a member of ${\cal L}({\bf{HSP}}(B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2}))$. Then the interval $[{\bf{W}}, \widehat{{\bf{W}}}]$ of ${\cal L}({\bf{HSP}}(B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2}, Z_2, W_2))$ is given in Figure 1.

Proof. Suppose that ${\bf{W}}_1$ is a member of $[{\bf{W}}, \widehat{{\bf{W}}}]$ such that ${\bf{W}}_1\neq \widehat{{\bf{W}}}$ and ${\bf{W}}_1\neq {\bf{W}}$. Then, there exists a nontrivial identity $u\approx v$ holding in ${\bf{W}}_1$ such that it is not satisfied by $\widehat{{\bf{W}}}$. Also, we have that ${\bf{W}}_1$ does not satisfy the identity $x+x\approx x$. By Lemma 4.2, we only need to consider the following two cases.

Case 1. ${\bf{HSP}}(Z_2)\models u\approx v, {\bf{HSP}}(W_2) \not\models u\approx v$. Then, $u\approx v$ satisfies one of the following three cases:

● $m = n = 1$, $c(u_1)\neq c(v_1)$, $|u_1|\neq1$ and $|v_1|\neq1$;

● $m = 1, n > 1$ and $|u_1|\neq1$;

● $m > 1, n = 1$ and $|v_1|\neq1$.

It is easy to see that, in each of the above cases, $u\approx v$ can imply the identity $x^3\approx x^3+x^3$. By Lemma 4.4, we have that ${\bf{W}}_1$ is a subvariety of ${\bf{W}}\vee {\bf{HSP}}(Z_2)$. On the other hand, since ${\bf{W}}_{1}\models x^3\approx x^3+x^3$ and ${\bf{W}}_{1}\not\models x+x\approx x$, it follows that $Z_2$ is a member of ${\bf{W}}_1$ and so ${\bf{W}}\vee {\bf{HSP}}(Z_2)$ is a subvariety of ${\bf{W}}_1$. Thus, ${\bf{W}}_1 = {\bf{W}}\vee {\bf{HSP}}(Z_2)$.

Case 2. ${\bf{HSP}}(Z_2)\not\models u\approx v, {\bf{HSP}}(W_2) \models u\approx v$. Then, $u\approx v$ satisfies one of the following two cases:

● $m = n = 1$, $c(u_1) = c(v_1)$ and $|u_1| = 1$;

● $m = n = 1$, $c(u_1) = c(v_1)$ and $|v_1| = 1$.

If $N_2, T_2\not\in{\bf{W}}$, then, in each of the above cases, $u\approx v$ can imply the identity $x\approx x^3$. By Lemma 4.5, ${\bf{W}}_1$ is a subvariety of ${\bf{W}}\vee {\bf{HSP}}(W_2)$. On the other hand, since ${\bf{W}}_{1}\models x\approx x^3$ and ${\bf{W}}_{1}\not\models x\approx x+x$, it follows that $W_2$ is a member of ${\bf{W}}_1$ and so ${\bf{W}}\vee {\bf{HSP}}(W_2)$ is a subvariety of ${\bf{W}}_1$. Thus, ${\bf{W}}_1 = {\bf{W}}\vee {\bf{HSP}}(W_2)$.

If $N_2\in{\bf{W}}$, then, by Lemma 2.1 (ⅰ), $|u_1| = |v_1| = 1$, a contradiction. Thus, ${\bf{V}}_1 = \widehat{{\bf{V}}}$.

If $T_2\in{\bf{W}}$, then, by Lemma 2.1 (ⅱ), $|u_1|\geq2, |v_1|\geq2$, a contradiction. Thus, ${\bf{V}}_1 = \widehat{{\bf{V}}}$.

By Lemma 4.3 and 4.6, we can show that the lattice ${\cal L}({\bf{HSP}}(B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2}, Z_2,$ $W_2))$ of subvarieties of the variety ${\bf{HSP}}(B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2}, Z_2, W_2)$ contains 2327 elements. In fact, we have

Theorem 4.7. ${\cal L}({\bf{HSP}}(B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2}, Z_2, W_2))$ is a distributive lattice of order $\textrm{2327}$.

Proof. We recall from ^[16] that ${\bf{Sr}}(3, 1)\vee T_2$ [${\bf{Sr}}(3, 1)\vee N_2$] contains 358 subvarieties since ${\bf{Sr}}(3, 1)$ contains 179 subvarieties. By Lemma 4.3 and 4.6, we can show that ${\cal L}({\bf{HSP}}(B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2}, Z_2,$ $W_2))$ has exactly 2327 (where $2327 = 179\times4+358\times3\times2-179\times3$) elements. Suppose that ${\bf{W}}_1, {\bf{W}}_2$ and ${\bf{W}}_3$ are members of ${\cal L}({\bf{HSP}}(B^{0}, (B^{0})^{\ast}, A^{0},$ $N_{2}, T_{2}, Z_2, W_2))$ such that ${\bf{W}}_1\vee {\bf{W}}_2 = {\bf{W}}_1\vee {\bf{W}}_3$ and ${\bf{W}}_1\wedge {\bf{W}}_2 = {\bf{W}}_1\wedge{\bf{W}}_3$. Then, by Lemma 4.3

and

Since ${\cal L}({\bf{HSP}}(B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2})$ is distributive, it follows that $\varphi({\bf{W}}_2) = \varphi({\bf{W}}_3)$. Write ${\bf{W}}$ for $\varphi({\bf{W}}_2)$. Then both ${\bf{W}}_{2}, {\bf{W}}_{3}$ are members of $[{\bf{W}}, \widehat{{\bf{W}}}]$. Suppose that ${\bf{W}}_2\neq{\bf{W}}_3$. Then, by Lemma 4.6, ${\bf{W}}_1\vee {\bf{W}}_2 = {\bf{W}}_1\vee {\bf{W}}_3$ and ${\bf{W}}_1\wedge {\bf{W}}_2 = {\bf{W}}_1\wedge{\bf{W}}_3$ can not hold at the same time. This implies that ${\bf{W}}_2 = {\bf{W}}_3$.

By Theorem 4.1, 4.7 and [14,Corollary 1.2], we now immediately deduce

Corollary 4.8. ${\bf{HSP}}(B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2}, Z_2, W_2)$ is hereditarily finitely based.

5.   Conclusions

This article considers a semiring variety generated by $B^{0}, (B^{0})^{\ast}, A^{0}, N_{2}, T_{2}, Z_2, W_2$. The finite basis problem for semirings is an interesting developing topic, with plenty of evidence of a high level of complexity along the lines of the more well-developed area of semigroup varieties. This article is primarily a contribution toward the property of being hereditarily finite based, meaning that all subvarieties are finitely based. This property is of course useful because it guarantees the finite basis property of a large number of examples.
