Unsteady Casson fluid flow over a vertical surface with fractional bioconvection

1.
Department of Mathematics, University of Management and Technology, Lahore 54770, Pakistan
2.
Department of Mathematics, Cankaya University, Etimesgut, Ankara, Turkey
3.
Department of Mathematics, King Abdul Aziz University, Jeddah, Saudi Arabia
4.
Department of Medical Research, China Medical University Hospital, China Medical University, Taichung, Taiwan

Received: 07 October 2021 Revised: 13 January 2022 Accepted: 27 January 2022 Published: 24 February 2022
MSC : 35A22, 76A05

This paper deals with unsteady flow of fractional Casson fluid in the existence of bioconvection. The governing equations are modeled with fractional derivative which is transformed into dimensionless form by using dimensionless variables. The analytical solution is attained by applying Laplace transform technique. Some graphs are made for involved parameters. As a result, it is found that temperature, bioconvection are maximum away from the plate for large time and vice versa and showing dual behavior in their boundary layers respectively. Further recent literature is recovered from the present results and obtained good agreement.

Keywords:

Citation: Muhammad Imran Asjad, Muhammad Haris Butt, Muhammad Armaghan Sadiq, Muhammad Danish Ikram, Fahd Jarad. Unsteady Casson fluid flow over a vertical surface with fractional bioconvection[J]. AIMS Mathematics, 2022, 7(5): 8112-8126. doi: 10.3934/math.2022451

Related Papers:

[1]	Umar Nazir, Abdelaziz Nasr . Utilizing the Box-Behnken method on modeling of ternary-Casson nanofluid with variable density and heat sink across a vertical jet. AIMS Mathematics, 2025, 10(4): 10093-10123. doi: 10.3934/math.2025460
[2]	Taqi A. M. Shatnawi, Nadeem Abbas, Wasfi Shatanawi . Comparative study of Casson hybrid nanofluid models with induced magnetic radiative flow over a vertical permeable exponentially stretching sheet. AIMS Mathematics, 2022, 7(12): 20545-20564. doi: 10.3934/math.20221126
[3]	Muhammad Amin Sadiq Murad, Faraidun Kadir Hamasalh, Hajar F. Ismael . Numerical study of stagnation point flow of Casson-Carreau fluid over a continuous moving sheet. AIMS Mathematics, 2023, 8(3): 7005-7020. doi: 10.3934/math.2023353
[4]	Yasir Khan, Sohaib Abdal, Sajjad Hussain, Imran Siddique . Numerical simulation for thermal enhancement of $H_2O$ + Ethyl Glycol base hybrid nanofluid comprising $GO + (Ag, AA7072, MoS_2)$ nano entities due to a stretched sheet. AIMS Mathematics, 2023, 8(5): 11221-11237. doi: 10.3934/math.2023568
[5]	Ali Raza, Umair Khan, Aurang Zaib, Wajaree Weera, Ahmed M. Galal . A comparative study for fractional simulations of Casson nanofluid flow with sinusoidal and slipping boundary conditions via a fractional approach. AIMS Mathematics, 2022, 7(11): 19954-19974. doi: 10.3934/math.20221092
[6]	Nadeem Abbas, Wasfi Shatanawi, Taqi A. M. Shatnawi . Innovation of prescribe conditions for radiative Casson micropolar hybrid nanofluid flow with inclined MHD over a stretching sheet/cylinder. AIMS Mathematics, 2025, 10(2): 3561-3580. doi: 10.3934/math.2025164
[7]	Sami Ul Haq, Saeed Ullah Jan, Syed Inayat Ali Shah, Ilyas Khan, Jagdev Singh . Heat and mass transfer of fractional second grade fluid with slippage and ramped wall temperature using Caputo-Fabrizio fractional derivative approach. AIMS Mathematics, 2020, 5(4): 3056-3088. doi: 10.3934/math.2020198
[8]	Khalil Ur Rehman, Wasfi Shatanawi, Zeeshan Asghar, Haitham M. S. Bahaidarah . Neural networking analysis for MHD mixed convection Casson flow past a multiple surfaces: A numerical solution. AIMS Mathematics, 2023, 8(7): 15805-15823. doi: 10.3934/math.2023807
[9]	Latifa I. Khayyat, Abdullah A. Abdullah . The onset of Marangoni bio-thermal convection in a layer of fluid containing gyrotactic microorganisms. AIMS Mathematics, 2021, 6(12): 13552-13565. doi: 10.3934/math.2021787
[10]	Aziz Ur Rehman, Muhammad Bilal Riaz, Ilyas Khan, Abdullah Mohamed . Time fractional analysis of Casson fluid with application of novel hybrid fractional derivative operator. AIMS Mathematics, 2023, 8(4): 8185-8209. doi: 10.3934/math.2023414

Abstract

1. Introduction

Fractional calculus is the section of mathematics which deals with the analysis and applications of non-local differentiation and integration ^[1]. In many sections of engineering and science, fractional calculus and the applications of fractional calculus are now regarded as an important platform for accomplished calculations to create new strengths for complex non-local systems ^[2,3,4,5,6]. Butt et al. ^[7] accomplished solutions of semi analytical for the mass and heat transfer of a fractional MHD Jeffery fluid beyond an incalculable oscillating vertical plate by the Caputo Fabrizio fractional operator. Aman et al. ^[8] utilized fractional derivatives to seek the transfer of mass and heat of nanofluids (sodium alginate (SA) carrier fluid with graphene nanoparticles). Ali et al. ^[9] calculated the electrically conducted blended convection stream of summed up Jeffrey nanoliquid in a pivoted liquid cross an endless wavering plate soaked in a permeable medium through Atangana-Baleanu fractional approach. Khan et al. ^[10] used Caputo-Fabrizio fractional operator for the problem of generalized Maxwell fluid heat transfer above an incalculable perpendicular plate. Imran et al. ^[11,12] used Caputo-fractional derivative to analyze the different problems related to fluid flow. Saad et al. ^[13] put forward approximations for model of a fractional cubic isothermal auto-catalytic chemical system by applying Caputo (C), Caputo-Fabrizio (CF) and Atangana-Baleanu fractional derivatives. In (2017), Shiekh et al. ^[14] evaluated the solutions of Jeffrey fluid with Caputo-Fabrizio and Atangana-Baleanu fractional derivative with the benefit of Laplace transform method. Ali et al. ^[15] analyzed the heat transfer of generalized Jeffery nanofluid in a rotating frame. Ahmad et al. ^[16] calculated the outcomes of Caputo and Caputo-Fabrizio for the mass and heat transmission of fractional Jeffrey fluid flow on incalculable perpendicular plate in motion aggressively at different temperature. For further study on fractional operators these references can be consulted ^{[17,18,19,20,21,22,23,24,25,26,27,28,29]}.

In 2020, Baleanu et al. ^[30] suggested new fractional operator Constant Proportional Caputo (CPC) which is the mixture of Caputo derivative and Riemann-Liouville integral. Inspired by it, to contrast the new fractional approach with Caputo-Fabrizio (CF) and Caputo (C) fractional operators is of massive interest. In the existing literature there is no such type of comparison with new Constant Proportional Caputo (CPC). By introducing dimensionless variables, the dominant equations are turned into the position of non-dimensional equations. The classic model of Casson fluid is turned into a fractional model of form $\alpha$ . The current problem is determined by Constant Proportional Caputo (CPC) fractional operator. The exact solutions for concentrations, temperatures and velocity are attained with the technique of Laplace transform. The equivalent ratios of skin, heat friction and mass are also evaluated. We have drawn a contrast approach using MathCad software among the solutions of fractional models of (C) and (CPC) fractional derivatives graphically.

The event of bioconvection is one more extraordinary field which comprises of various natural applications. The convective motion of a matter because of gradient of density at tiny level is named as bioconvection. This flimsiness in thickness inclination happened because of aggregate swimming of microorganisms. This wonder generally happens at the uppermost level of fluid because of which the fluid in that particular district evolves into denser. Flimsiness in stream framework additionally happens because of the isolation in thickness of the lower and upper level of fluid. There are various clinical and organic cycles that require this actual marvel, for example, bio-energizes, chemicals, miniature framework, natural tissues, microbes and bio-innovation etc. The bioconvection measure is ordered into various classifications, for example, gyrotactic microorganism, chemotaxis and geotactic microorganisms. This order depends on the directional developments of different microorganisms. Kuznetsov ^[31,32] explored the bioconvection by utilizing different kinds of nano particles. Mallikarjuna et al. ^[33] examined the consistent bio-convective flow for a nanofluid with gyrotactic microorganism over an upward chamber and changed the displayed issue into dimensionless structure by utilizing dimensionless factors and afterward have tackled resultant conditions in mathematical structure by limited contrast strategy. Uddin et al. ^[34] examined mathematically the numerical model to analysis the effects of speed slip of second request past a flat penetrable plate. Chebyshev strategy utilized in this examination for rough arrangement of issue. The viewer can additionally concentrate about the bioconvection liquid stream with various calculations and flow conditions in references ^{[35,36,37,38,39]}.

Therefore, bioconvection related studies are carried out with classical models for different geometries, like plate sheet, cylinder, regular and irregular surfaces as discussed in the above literature. There is a gap in the existing literature with fractional approach of bioconvection. In 2021, Imran et al. ^[40] published the fractional bioconvection effect for viscous fluid over a vertical geometry (see Figure 1) and discussed the effect of fractional parameter and bioconvection number on the fluid flow with integral transform approach. In their work, the Caputo fractional model was obtained using Fourier and Ficks's Laws for energy and diffusion equation and got good response. In the current work, we extended ^[40] for non-Newtonian fluid with fractional modeling through generalized laws of heat and mass transfer by new fractional operator which is a linear combination of two fractional operators. Analytical solutions are obtained via Laplace transform method and some graphical results for different flow parameters drawn to see physical behavior. Furthermore, it is shown that newly applied fractional operator is stronger in decaying nature than the Caputo one.

Figure 1. Geometry of the problem.

DownLoad: Full-Size Img PowerPoint

2. Mathematical formulation

Consider a turbulent heat flood of a thick liquid by a level area in a $xy$ -coordinate framework arranged at $y = 0$ . First and foremost at $t = 0$ , both dish and fluid are at rest with mention concentration of microorganisms $N_{\infty}$ and reference surface temperature $T_{\infty}$ . Ultimately after a few time $t = 0^{+}$ , dish starts motion at consistent speed and concentration of microorganisms of dish $N_{w}$ expand at surface temperature $T_{w}$ . As length is incalculable, so $y$ and $t$ are the two functions of every physical quantity. First of all we make constitutive fractional model for bioconvection equations and energy balance equations then address them by Laplace transform technique, trailed with velocity field. The momentum equation to a thick liquid having bioconvection expression as ^{[41,42,43,44]}.

$\begin{align} \rho{u}_{t}(y, t) = \mu(1+\frac{1}{\lambda}){u}_{yy}(y, t)+g[\rho\beta_{T}(T-T_{\infty})-\gamma(\rho_{m}-\rho)(N-N_{\infty})]. \end{align}$

(2.1)

The thermal balance equation given by ^{[41,42,43,44]}

$\begin{equation} (\rho C_{p}) T_{t}(y, t) = -q_{y}(y, t). \end{equation}$

(2.2)

The fractional thermal flux equation of heat conduction by applying Fourier's principle became

$\begin{equation} q(y, t) = -k\ {}^{CPC}D_{t}^{\beta}T_{y}(y, t). \end{equation}$

(2.3)

The diffusion balance equation given by ^{[41,42,43,44]}

$\begin{equation} N_{t}(y, t) = -J_{y}(y, t). \end{equation}$

(2.4)

The fractional bioconvection concentration equation given by ^{[41,42,43,44]}

$\begin{equation} J(y, t) = -D_{n}\ {}^{CPC}D_{t}^{\gamma}N_{y}(y, t). \end{equation}$

(2.5)

Based on the conditions,

$\begin{align} u(y, 0) = &0, \quad u(0, t) = u_{0}H(t), \quad u(y, t)\rightarrow0 \ \ as\ \ y\rightarrow \infty, \quad t > 0 \quad y\geq0, \end{align}$

(2.6)

$\begin{align} T(y, 0) = &T_{\infty}, \quad T(0, t) = T_{w}, \quad T(y, t)\rightarrow T_{\infty}\ \ as\ \ y\rightarrow \infty, \quad \quad t > 0, \quad y\geq0, \end{align}$

(2.7)

$\begin{align} N(y, 0) = &N_{\infty}, \quad N(0, t) = N_{w}, \quad N(y, t)\rightarrow N_{\infty}\ \ as\ \ y\rightarrow \infty. \quad t > 0 \quad y\geq0. \end{align}$

(2.8)

Introducing the following dimensionless variables into Eqs (2.1)–(2.5)

$\begin{array}{l} \quad y^{*} = \frac{u_{0}y}{\nu}, \quad u^{*} = \frac{u}{u_{0}}, \quad t^{*} = \frac{tu^{2}_{0}}{\nu}, \quad \theta = \frac{T-T_{\infty}}{T_{w}-T_{\infty}}, \\ N^{*} = \frac{N-N_{\infty}}{N_{w}-N_{\infty}}, \quad \quad\quad q^{*} = \frac{q}{q_{0}}, \quad \quad\quad J^{*} = \frac{J}{J_{0}}. \quad \end{array}$

(2.9)

We have the following dimensionless problem (ignoring *)

$\begin{equation} u_{t}(y, t) = A u_{yy}(y, t)+ {\rm Gr}[\theta(y, t)- {\rm Ra} N(y, t)]. \end{equation}$

(2.10)

The dimensionless thermal balance equation given by

$\begin{equation} \theta_{t}(y, t) = -B \ q_{y}(y, t). \end{equation}$

(2.11)

The dimensionless thermal flux equation of heat conduction by applying Fourier's principle became

$\begin{equation} q(y, t) = -C \ ^{CPC}D_{t}^{\beta}[\theta_{y}(y, t)].\ \ \ \ 0 < \beta\leq 1. \end{equation}$

(2.12)

The dimensionless diffusion balance equation is

$\begin{equation} N_{t}(y, t) = -E J_{y}(y, t). \end{equation}$

(2.13)

The dimensionless bioconvection concentration equation is

$\begin{equation} J(y, t) = -F \ ^{CPC}D_{t}^{\gamma}[N_{y}(y, t)], \ \ \ \ 0 < \gamma\leq 1, \end{equation}$

(2.14)

with dimensionless conditions

$\begin{align} u(y, 0) = 0, \quad u(0, t) = H(t), \quad u(y, t)\rightarrow0 \ \ as\ \ y\rightarrow \infty, \end{align}$

(2.15)

$\begin{align} \theta(y, 0) = 0, \quad \theta(0, t) = 1, \quad \theta(y, t)\rightarrow 0 \ \ as\ \ y\rightarrow \infty, \end{align}$

(2.16)

$\begin{align} N(y, 0) = 0, \quad N(0, t) = 1, \quad N(y, t)\rightarrow0 \ \ as\ \ y\rightarrow \infty. \end{align}$

(2.17)

where

$\begin{eqnarray} {\rm Lb}& = &\frac{\nu}{D_{n}}, \\ A& = &1+\frac{1}{\lambda}, \\ B& = &\frac{q_{0}\nu}{\mu C_{p}u_{0} (T_{w}-T_{\infty})}, \\ C& = &\frac{ku_{0}(T_{w}-T_{\infty})}{q_{0}\nu}, \\ E& = &\frac{J_{0}}{u_{0}(N_{w}-N_{\infty})}, \\ F& = &\frac{D_{n}(N_{w}-N_{\infty})u_{0}}{J_{0}\nu}, \\ {\rm Pr}& = &\frac{\mu C_{p}}{ {\rm k}}, \\ {\rm Gr}& = &\frac{g \nu \beta_{T}(T_{w}-T_{\infty})}{u_{0}^{3}}, \\ {\rm Ra}& = &\frac{\gamma(\rho_{_{m}}-\rho)(N_{w}-N_{\infty})}{\beta_{T}(T_{w}-T_{\infty})\rho}. \end{eqnarray}$

(2.18)

Using Eq (2.12) in Eq (2.11) and Eq (2.14) in Eq (2.13), final forms of dimensionless thermal balance equation and bioconvection concentration equation become respectively,

$\begin{equation} {\theta}_{t} (y, t) = \frac{1}{ {\rm Pr}} ^{CPC}D_{t}^{\beta} {\theta}_{yy} (y, t). \end{equation}$

(2.19)

$\begin{equation} N_{t}(y, t) = \frac{1}{ {\rm Lb}} ^{CPC}D_{t}^{\gamma} N_{yy} (y, t). \end{equation}$

(2.20)

2.1. Heat equation

Taking Laplace transform on Eq (2.19), we have

$\begin{equation} s\bar{\theta} (y, s) = \frac{1}{ {\rm Pr}} \left[\frac{k_{1}(\beta)}{s}+k_{0} (\beta)\right] s^{\beta} \bar{\theta}_{yy} (y, s). \end{equation}$

(2.21)

Also apply Laplace on Eq (2.16)

$\begin{eqnarray} \bar{\theta}(y, 0) = 0, \ \ \ \ \ \ \ \ \ \ \bar{\theta}(0, s) = \frac{1}{s}, \ \ \ \ \ \ \ \bar{\theta}(y, s)\rightarrow0\ \ as\ \ y\rightarrow \infty. \end{eqnarray}$

(2.22)

Using Eq (2.22) in Eq (2.21), the general solution of temperature profile becomes

(2.23)

The Eq (2.23) is in exponential form is very complicated so it is hard to find the inverse formula with this form. Therefore, we used the series form of exponential function and expressed in more suitable form to obtain inverse analytically.

$\begin{align} \bar{\theta}(y, s) = \frac{1}{s}+\sum\limits_{k = 1}^{\infty} \sum\limits_{l = 0}^{\infty} \frac{( {\rm Pr})^{\frac{k}{2}} \left(-y \right)^{k}(-1)^{l} \left[k_{1}(\beta)\right]^{l}\Gamma(\frac{k}{2}+l)}{k! l! \left[k_{0}(\beta)\right]^{\frac{k}{2}+l} \ s^{1-(1-\beta)\frac{k}{2}+l}\Gamma(\frac{k}{2})}. \end{align}$

(2.24)

Taking Laplace inverse on the Eq (2.24), we get

$\begin{align} \theta(y, t) = 1+\sum\limits_{k = 1}^{\infty} \sum\limits_{l = 0}^{\infty} \frac{( {\rm Pr})^{\frac{k}{2}} \left(-y \right)^{k}(-1)^{l} \left[k_{1}(\beta)\right]^{l}t^{-(1-\beta)\frac{k}{2}+l}\Gamma(\frac{k}{2}+l)}{k! l! \left[k_{0}(\beta)\right]^{\frac{k}{2}+l} \ \Gamma(1-(1-\beta)\frac{k}{2}+l)\Gamma(\frac{k}{2})}. \end{align}$

(2.25)

2.2. Bioconvection equation

Taking laplace transform on Eq (2.20), we get

$\begin{equation} s\bar{N} (y, s) = \frac{1}{ {\rm Lb}} \left[\frac{k_{1}(\gamma)}{s}+k_{0} (\gamma)\right] s^{\gamma} \bar{N}_{yy} (y, s). \end{equation}$

(2.26)

Also apply Laplace on Eq (2.17)

$\begin{eqnarray} \bar{N}(y, 0) = 0, \ \ \ \ \ \ \ \bar{N}(0, s) = \frac{1}{s}, \ \ \ \ \ \ \ \ \bar{N}(y, s)\rightarrow0\ \ as\ \ y\rightarrow \infty. \end{eqnarray}$

(2.27)

Using Eq (2.27) in Eq (2.26), the general solution of Bioconvection profile becomes

$\begin{align} \bar{N}(y, s) = \frac{1}{s}\exp\left(-y\sqrt{\frac{ {\rm Lb} \ s^{1-\gamma}}{[\frac{k_{1}(\gamma)}{s}+k_{0}(\gamma)]}}\right). \end{align}$

(2.28)

The Eq (2.28) can be compose in suitable form,

$\begin{align} \bar{N}(y, s) = \frac{1}{s}+\sum\limits_{m = 1}^{\infty} \sum\limits_{n = 0}^{\infty} \frac{( {\rm Lb})^{\frac{m}{2}} \left(-y \right)^{m}(-1)^{n} \left[k_{1}(\gamma)\right]^{n}\Gamma(\frac{m}{2}+n)}{m! n! \left[k_{0}(\gamma)\right]^{\frac{m}{2}+n} \ s^{1-(1-\gamma)\frac{m}{2}+n}\Gamma(\frac{m}{2})}. \end{align}$

(2.29)

Taking Laplace inverse on Eq (2.29), we get

$\begin{align} N(y, t) = 1+\sum\limits_{m = 1}^{\infty} \sum\limits_{n = 0}^{\infty} \frac{( {\rm Lb})^{\frac{m}{2}} \left(-y \right)^{m}(-1)^{n} \left[k_{1}(\gamma)\right]^{n}t^{-(1-\gamma)\frac{m}{2}+n}\Gamma(\frac{m}{2}+n)}{m! n! \left[k_{0}(\gamma)\right]^{\frac{m}{2}+n} \ \Gamma(1-(1-\gamma)\frac{m}{2}+n)\Gamma(\frac{m}{2})}. \end{align}$

(2.30)

2.3. Momentum equation

Taking Laplace transform on Eq (2.10), we have

$\begin{equation} s\bar{u}(y, s) = A\bar u_{yy}(y, s)+ {\rm Gr}[\bar{\theta}(y, s)- {\rm Ra} \bar{N}(y, s)]. \end{equation}$

(2.31)

Also apply Laplace on Eq (2.15)

$\begin{eqnarray} \bar{u}(y, 0) = 0, \ \ \ \ \ \ \ \ \ \bar{u}(0, s) = \frac{1}{s}, \ \ \ \ \ \ \ \ \ \bar{u}(y, s)\rightarrow0\ \ as\ \ y\rightarrow \infty. \end{eqnarray}$

(2.32)

Using Eq (2.32) in Eq (2.31), the general solution of Momentum profile becomes

(2.23)

The Eq (2.33) can be written in suitable form

$\begin{align} \bar{u}(y, s) = &\frac{1}{s}+\frac{1}{s}\sum\limits_{k = 1}^{\infty}\frac{[-y\sqrt{s}]^{k}}{(\sqrt{A})^{k}k!} \\ &-\sum\limits_{k = 0}^{\infty}\sum\limits_{l = 0}^{\infty}\sum\limits_{p = 0}^{\infty}\frac{ {\rm Gr} \ [-y]^{k} \ [ {\rm Pr}]^{p} \ [k_{1}(\beta)]^{p} \ \Gamma(p+1)}{k! \ p!(A)^{1+\frac{k}{2}} s^{p+2-\beta l-\frac{k}{2}} \ [k_{0}(\beta)]^{l} \ \Gamma(p+1-l)}\\ &+\sum\limits_{k = 0}^{\infty}\sum\limits_{l = 0}^{\infty}\sum\limits_{p = 0}^{\infty}\frac{ {\rm Gr} {\rm Ra} \ [-y]^{k} \ [ {\rm Lb}]^{p} \ [k_{1}(\gamma)]^{p} \ \Gamma(p+1)}{k! \ p! (A)^{1+\frac{k}{2}} s^{p+2-\gamma l-\frac{k}{2}} \ [k_{0}(\gamma)]^{l} \ \Gamma(p+1-l)} \\ &+\sum\limits_{k = 0}^{\infty}\sum\limits_{l = 0}^{\infty}\sum\limits_{p = 0}^{\infty}\sum\limits_{m = 0}^{\infty}\frac{ {\rm Gr} \ [-y]^{k}\ [ {\rm Pr}]^{m+\frac{k}{2}} \ [k_{1}(\beta)]^{l+p}}{A k! s^{\beta k-\frac{k}{2}+\beta m +l+p+2} \ [k_{0}(\beta)]^{\frac{k}{2}m+l+p}} \\ &-\sum\limits_{k = 0}^{\infty}\sum\limits_{l = 0}^{\infty}\sum\limits_{p = 0}^{\infty}\sum\limits_{m = 0}^{\infty}\frac{ {\rm Gr} {\rm Ra} \ [-y]^{k} \ [ {\rm Lb}]^{m+\frac{k}{2}} [k_{1}(\gamma)]^{l+p}}{A k! s^{\gamma k-\frac{k}{2}+\gamma m +l+p+2} \ [k_{0}(\gamma)]^{\frac{k}{2}m+l+p}}. \end{align}$

(2.34)

Taking Laplace inverse on Eq (2.34), we get final expression

$\begin{align} {u}(y, t) = &1+\sum\limits_{k = 1}^{\infty}\frac{[-y\sqrt{t}]^{k}}{(A)^{\frac{k}{2}}k!} \quad \\ &- \sum\limits_{k = 0}^{\infty}\sum\limits_{l = 0}^{\infty}\sum\limits_{p = 0}^{\infty}\frac{ {\rm Gr} \ [-y]^{k} \ [ {\rm Pr}]^{p} \ t^{p+1-\beta l\frac{k}{2}} \ [k_{1}(\beta)]^{p} \ \Gamma(p+1)}{k! p! (A)^{1+\frac{k}{2}} [k_{0}(\beta)]^{l} \ \Gamma(p+1-l) \ \Gamma(p+2-\beta l -\frac{k}{2})}\\ &+ \sum\limits_{k = 0}^{\infty}\sum\limits_{l = 0}^{\infty}\sum\limits_{p = 0}^{\infty}\frac{ {\rm Gr} {\rm Ra}\ [-y]^{k} \ [ {\rm Lb}]^{p} t^{p+1-\gamma l\frac{k}{2}} \ [k_{1}(\gamma)]^{p} \ \Gamma(p+1)}{k! p! (A)^{1+\frac{k}{2}} [k_{0}(\gamma)]^{l} \ \Gamma(p+1-l) \ \Gamma(p+2-\gamma l -\frac{k}{2})} \\ &+ \sum\limits_{k = 0}^{\infty}\sum\limits_{l = 0}^{\infty}\sum\limits_{p = 0}^{\infty}\sum\limits_{m = 0}^{\infty}\frac{ {\rm Gr} \ [-y]^{k} \ [ {\rm Pr}]^{m+\frac{k}{2}} \ t^{\beta k-\frac{k}{2}+\beta m +l+p+1} \ [k_{1}(\beta)]^{l+p}}{A k! [k_{0}(\beta)]^{\frac{k}{2}m+l+p} \ \Gamma(\beta k-\frac{k}{2}+pm+l+p+2)} \\ &- \sum\limits_{k = 0}^{\infty}\sum\limits_{l = 0}^{\infty}\sum\limits_{p = 0}^{\infty}\sum\limits_{m = 0}^{\infty}\frac{ {\rm Gr} {\rm Ra} \ [-y]^{k} \ [ {\rm Lb}]^{m+\frac{k}{2}} \ t^{\gamma k-\frac{k}{2}+\gamma m +l+p+1} \ [k_{1}(\gamma)]^{l+p}}{A k! \ [k_{0}(\gamma)]^{\frac{k}{2}m+l+p} \ \Gamma(\gamma k-\frac{k}{2}+pm+l+p+2)}. \end{align}$

(2.35)

3. Graphical results and discussion

and are sketched to see the effect of fractional parameter $\gamma$ for both large and small value of time in bioconvection field. Since the power law fractional operator has been used. As the fractional operator exhibits the memory of the function at the present time. It is found in and that by increasing the values of fractional parameter and taking time t = 2.5, the profile of bioconvection reduces. The concentration near the plate is maximum while decreasing in main stream region and finally asymptotically approaches to zero as $y\rightarrow0$ . This fact also justify the boundary condition as well.

Figure 2. The result of fractional parameter

$\gamma$ on Bioconvection Distribution for large time.

DownLoad: Full-Size Img PowerPoint

Figure 3. The result of fractional parameter

$\gamma$ on Bioconvection Distribution for small time.

DownLoad: Full-Size Img PowerPoint

Impact of fractional parameter $\beta$ on temperature can be seen in Figures 4 and and observed that for small and large values of time. For large time t of different values of fractional parameter, it is observed from that temperature is decreasing function near the plate for great values of $\beta$ . This rapid decay in temperature is due to increase in thermal boundary layer for increasing $\beta$ , while depicts for small time for different fractional parameter and demonstrates that temperature shows the opposite behavior for varying fractional parameter values. Temperature increases away from the plate in the main stream region and finally decay for greater values of y and then asymptotically approaches to zero as y goes to infinity. This is how fractional parameter shows dual behavior for temperature for smaller and larger values of time. The effect of fractional parameters on velocity field is presented in . The fluid velocity rises as we raise the values of fractional parameters. This can be physically deliberated as when fractional parameters are raised, the momentum boundary layer became thickest as a result the velocity profiles increased. When $\lambda\rightarrow \infty$ casson fluid problem model becomes viscous fluid problem. It can be seen in Figure 7. It coincides with Imran et al. ^[40].

Figure 4. The result of fractional parameter

$\beta$ on Temperature Distribution for large time.

DownLoad: Full-Size Img PowerPoint

Figure 5. The result of fractional parameter

$\beta$ on Temperature Distribution for small time.

DownLoad: Full-Size Img PowerPoint

Figure 6. The effect of fractional parameters

$\beta$ and

$\gamma$ on Velocity Distribution.

DownLoad: Full-Size Img PowerPoint

Figure 7. Comparison between our results when (

$\lambda\rightarrow \infty$ ) and Imran et al. ^[40].

DownLoad: Full-Size Img PowerPoint

is designed to see the effect of ${\rm Gr}$ on the velocity field. It is realized that with high values of ${\rm Gr}$ , the velocity faster. Since ${\rm Gr}$ is related to buoyancy forces which rise the natural convection, so the velocity rises in speed. is planned to see the impact of ${\rm Pr}$ on velocity field. Since ${\rm Pr}$ is the dimensionless number that tests the comparative width of a boundary layer of thermal conductivity and momentum. So by increasing values of ${\rm Pr}$ , thermal conductivity is decreased, the viscosity of the fluid is enriched and, lastly, a decay in velocity is detected. It is also noted that the boundary layer width reduces. displays the result of the bioconvection Rayleigh number ${\rm Ra}$ on the velocity field. From figure, It is clear that the fluid velocity declines while rising the values of bioconvection Rayleigh number ${\rm Ra}$ . This is because of that, for higher values of ${\rm Ra}$ , the buoyancy impact from the movement of microorganisms falls.

Figure 8. The effect of

${\rm Gr}$ on Velocity Distribution.

DownLoad: Full-Size Img PowerPoint

Figure 9. The effect of

${\rm Pr}$ on Velocity Distribution.

DownLoad: Full-Size Img PowerPoint

Figure 10. The effect of

${\rm Ra}$ on Velocity Distribution.

DownLoad: Full-Size Img PowerPoint

4. Conclusions

In this work, the unsteady fractional bioconvection for Casson fluid flow for vertical surface has been studied. The governing equations are modeled with fractional derivative and then transformed into dimensionless form by using dimensionless variables. The analytical solution is attained by applying Laplace transform technique. The physical effects of different parameters are explained graphically. Some key points are obtained as follow:

$(1)$ Thermal, diffusion and momentum boundary layers can be controlled with variable values of fractional parameter and time respectively.

$(2)$ Enhancement in temperature, concentration and velocity can be achieved with small values of time.

$(3)$ The presence of bioconvection number ${\rm Ra}$ is responsible for decline of momentum boundary layer.

$(4)$ A good agreement of the present results and the recent literature is obtained for the validation.

Nomenclature

Symbol	Name	Symbol	Name
(C)	Caputo	(CF)	Caputo-Fabrizio
(ABC)	Atangana-Baleanu	(CPC)	Constant proportional Caputo
$\rho$	density of fluid $(kg m^{-3})$	$\mu$	dynamic viscosity $(kg m^{-1}s^{-1})$
$k$	thermal conductivity $(Wm^{-2}K^{-1})$	$g$	gravitational acceleration
$\beta_{T}$	thermal expansion coefficient	u	velocity field $(ms^{-1})$
$C_{p}$	specific heat $(j kg^{-1}K^{-1})$	$D_{n}$	thermal diffusivity
$T$	temperature $(K)$	$T_{\infty}$	ambient temperature $(K)$
$N$	bioconvection	$N_{\infty}$	constant bioconvection
$T_{w}$	temperature at wall $(K)$	$N_{w}$	concentration of microorganisms of dish
$t$	Time (s)	$\beta$ , $\gamma$	Fractional parameters
${\rm Pr}$	Prandtl number (Dimensionless)	${\rm Lb}$	Lewis number (Dimensionless)
${\rm Gr}$	Thermal Grashof number (Dimensionless)	${\rm Ra}$	Rayleigh number (Dimensionless)
$\lambda$	Casson fluid parameter

| Show Table

DownLoad: CSV

Acknowledgments

The authors are greatly appreciative and indebted to the reviewers' comments and suggestions that improved the present form of the manuscript and also the University of Management and Technology, Lahore, Pakistan, for facilitating and supporting the study. The fifth author (Fahd Jarad) was financially supported by Department of Mathematics, Cankaya University, Etimesgut, Ankara, Turkey.

Conflict of interest

This work does not have any conflict of interest.

References

[1]	D. Baleanu, A. Fernandez, On fractional operators and their classifications, Mathematics, 7 (2019), 830. https://doi.org/10.3390/math7090830 doi: 10.3390/math7090830
[2]	M. D. Ikram, M. I. Asjad, A. Akg $\ddot{u}$ l, D. Baleanu, Effects of hybrid nanofluid on novel fractional model of heat transfer flow between two parallel plates, Alex. Eng. J., 60 (2021), 3593–3604, https://doi.org/10.1016/j.aej.2021.01.054 doi: 10.1016/j.aej.2021.01.054
[3]	J. J. Trujillo, E. Scalas, K. Diethelm, D. Baleanu, Fractional calculus: Models and numerical methods, World Scientific, 2016.
[4]	Y. M. Chu, M. D. Ikram, M. I. Asjad, A. Ahmadian, F. Ghaemi, Influence of hybrid nanofluids and heat generation on coupled heat and mass transfer flow of a viscous fluid with novel fractional derivative, J. Therm. Anal. Calorim., 144 (2021), 2057–2077. https://doi.org/10.1007/s10973-021-10692-8 doi: 10.1007/s10973-021-10692-8
[5]	A. Atangana, J. F. Botha, A generalized groundwater flow equation using the concept of variable-order derivative, Bound. Value Probl., 2013 (2013), 53. https://doi.org/10.1186/1687-2770-2013-53 doi: 10.1186/1687-2770-2013-53
[6]	A. Atangana, A. Secer, A note on fractional order derivatives and table of fractional derivatives of some special functions, Abstr. Appl. Anal., 2013 (2013), 279681. https://doi.org/10.1155/2013/279681 doi: 10.1155/2013/279681
[7]	A. R. Butt, M. Abdullah, N. Raza, M. A. Imran, Influence of non-integer order parameter and Hartmann number on the heat and mass transfer flow of a Jeffery fluid over an oscillating vertical plate via Caputo-Fabrizio time fractional derivatives, Eur. Phys. J. Plus, 132 (2017), 414. https://doi.org/10.1140/epjp/i2017-11713-4 doi: 10.1140/epjp/i2017-11713-4
[8]	S. Aman, I. Khan, Z. Ismail, M. Z. Salleh, Applications of fractional derivatives to nanofluids: Exact and numerical solutions, Math. Model. Nat. Phenom., 13 (2018), 1–12. https://doi.org/10.1051/mmnp/2018013 doi: 10.1051/mmnp/2018013
[9]	F. Ali, S. Murtaza, I. Khan, N. A. Sheikh, K. S. Nisar, Atangana-Baleanu fractional model for the flow of Jeffrey nanofluid with diffusion-thermo effects: Applications in engine oil, Adv. Differ. Equ., 2019 (2019), 346. https://doi.org/10.1186/s13662-019-2222-1 doi: 10.1186/s13662-019-2222-1
[10]	Q. Al-Mdallal, K. A. Abro, I. Khan, Analytical solutions of fractional Walter's B fluid with applications, Complexity, 2018 (2018), 8131329. https://doi.org/10.1155/2018/8131329 doi: 10.1155/2018/8131329
[11]	M. A. Imran, I. Khan, M. Ahmad, N. A. Shah, M. Nazar, Heat and mass transport of differential type fluid with non-integer order time-fractional Caputo derivatives, J. Mol. Liq., 229 (2017), 67–75. https://doi.org/10.1016/j.molliq.2016.11.095 doi: 10.1016/j.molliq.2016.11.095
[12]	M. A. Imran, N. A. Shah, I. Khan, M. Aleem, Applications of non-integer Caputo time fractional derivatives to natural convection flow subject to arbitrary velocity and Newtonian heating, Neural. Comput. Appl., 30 (2018), 1589–1599. https://doi.org/10.1007/s00521-016-2741-6 doi: 10.1007/s00521-016-2741-6
[13]	K. M. Saad, Comparing the Caputo, Caputo-Fabrizio and Atangana-Baleanu derivative with fractional order: Fractional cubic isothermal auto-catalytic chemical system, Eur. Phys. J. Plus, 133 (2018), 94. https://doi.org/10.1140/epjp/i2018-11947-6 doi: 10.1140/epjp/i2018-11947-6
[14]	N. A. Sheikh, F. Ali, M. Saqib, I. Khan, S. A. A. Jan, A. S. Alshomrani, et al., Comparison and analysis of the Atangana-Baleanu and Caputo-Fabrizio fractional derivatives for generalized Casson fluid model with heat generation and chemical reaction, Results Phys., 7 (2017), 789–800. https://doi.org/10.1016/j.rinp.2017.01.025 doi: 10.1016/j.rinp.2017.01.025
[15]	F. Ali, S. Murtaza, N. A. Sheikh, I. Khan, Heat transfer analysis of generalized Jeffery nanofluid in a rotating frame: Atangana-Baleanu and Caputo-Fabrizio fractional models, Chaos Solitons Fract., 129 (2019), 1–15. https://doi.org/10.1016/j.chaos.2019.08.013 doi: 10.1016/j.chaos.2019.08.013
[16]	M. Ahmad, M. A. Imran, M. Aleem, I. Khan, A comparative study and analysis of natural convection flow of MHD non-Newtonian fluid in the presence of heat source and first-order chemical reaction, J. Therm. Anal. Calorim., 137 (2019), 1783–1796. https://doi.org/10.1007/s10973-019-08065-3 doi: 10.1007/s10973-019-08065-3
[17]	N. Shahid, A study of heat and mass transfer in a fractional MHD flow over an infinite oscillating plate, SpringerPlus, 4 (2015), 640. https://doi.org/10.1186/s40064-015-1426-4 doi: 10.1186/s40064-015-1426-4
[18]	M. B. Riaz, N. Iftikhar, A comparative study of heat transfer analysis of MHD Maxwell fluid in view of local and nonlocal differential operators, Chaos Solitons Fract., 132 (2020), 109556. https://doi.org/10.1016/j.chaos.2019.109556 doi: 10.1016/j.chaos.2019.109556
[19]	M. Tahir, M. A. Imran, N. Raza, M. Abdullah, M. Aleem, Wall slip and non-integer order derivative effects on the heat transfer flow of Maxwell fluid over an oscillating vertical plate with new definition of fractional Caputo-Fabrizio derivatives, Results Phys., 7 (2017), 1887–1898. https://doi.org/10.1016/j.rinp.2017.06.001 doi: 10.1016/j.rinp.2017.06.001
[20]	M. Saqib, F. Ali, I. Khan, N. A. Sheikh, S. A. A. Jan, Samiulhaq, Exact solutions for free convection flow of generalized Jeffrey fluid: A Caputo-Fabrizio fractional model, Alex. Eng. J., 57 (2018), 1849–1858. https://doi.org/10.1016/j.aej.2017.03.017 doi: 10.1016/j.aej.2017.03.017
[21]	M. A. Imran, F. Miraj, I. Khan, I. Tlili, MHD fractional Jeffrey's fluid flow in the presence of thermo diffusion, thermal radiation effects with first order chemical reaction and uniform heat flux, Results Phys., 10 (2018), 10–17. https://doi.org/10.1016/j.rinp.2018.04.008 doi: 10.1016/j.rinp.2018.04.008
[22]	F. Ali, F. Ali, N. A. Sheikh, I. Khan, K. S. Nisar, Caputo-Fabrizio fractional derivatives modeling of transient MHD Brinkman nanoliquid: Applications in food technology, Chaos Solitons Fract., 131 (2020), 109489. https://doi.org/10.1016/j.chaos.2019.109489 doi: 10.1016/j.chaos.2019.109489
[23]	A. Babakhani, D. Baleanu, Employing of some basic theory for class of fractional differential equations, Adv. Differ. Equ., 2011 (2011), 296353. https://doi.org/10.1155/2011/296353 doi: 10.1155/2011/296353
[24]	M. Herzallah, D. Baleanu, Fractional-order variational calculus with generalized boundary conditions, Adv Differ Equ., 2011 (2011), 357580. https://doi.org/10.1155/2011/357580 doi: 10.1155/2011/357580
[25]	A. Akg $\ddot{u}$ l, A novel method for a fractional derivative with non-local and non-singular kernel, Chaos Solitons Fract., 114 (2018), 478–482. https://doi.org/10.1016/j.chaos.2018.07.032 doi: 10.1016/j.chaos.2018.07.032
[26]	F. Jarad, T. Abdeljawad, A modified Laplace transform for certain generalized fractional operators, Results Nonlinear Anal., 1 (2018), 88-98,
[27]	F. Jarad, T. Abdeljawad, Z. Hammouch, On a class of ordinary differential equations in the frame of Atangana-Baleanu fractional derivative, Chaos Solitons Fract., 117 (2018), 16–20. https://doi.org/10.1016/j.chaos.2018.10.006 doi: 10.1016/j.chaos.2018.10.006
[28]	A. Akg $\ddot{u}$ l, A. Cordero, J. R. Torregrosa, Solutions of fractional gas dynamics equation by a new technique, Math. Methods Appl. Sci., 43 (2020), 1349–1358. https://doi.org/10.1002/mma.5950 doi: 10.1002/mma.5950
[29]	M. D. Ikram, M. A. Imran, A. Ahmadian, M. Ferrara, A new fractional mathematical model of extraction nanofluids using clay nanoparticles for different based fluids, Math. Methods Appl. Sci., 2020. https://doi.org/10.1002/mma.6568 doi: 10.1002/mma.6568
[30]	D. Baleanu, A. Fernandez, A. Akg $\ddot{u}$ l, On a fractional operator combining proportional and classical differintegrals, Mathematics, 8 (2020), 360. https://doi.org/10.3390/math8030360 doi: 10.3390/math8030360
[31]	A. V. Kuznetsov, The onset of nanofluid bioconvection in a suspension containing both nanoparticles and gyrotactic microorganisms, Int. Commun. Heat Mass Tran., 37 (2010), 1421–1425. https://doi.org/10.1016/j.icheatmasstransfer.2010.08.015 doi: 10.1016/j.icheatmasstransfer.2010.08.015
[32]	A. V. Kuznetsov, Nanofluid bioconvection in water-based suspensions containing nanoparticles and oxytactic microorganisms: Oscillatory instability, Nanoscale Res. Lett., 6 (2011), 100. https://doi.org/10.1186/1556-276X-6-100 doi: 10.1186/1556-276X-6-100
[33]	B. Mallikarjuna, A. M. Rashad, A. Chamkha, M. M. M. Abdou, Mixed bioconvection flow of a nanofluid containing gyrotactic microorganisms past a vertical slender cylinder, Front. Heat Mass Tran., 2018.
[34]	M. J. Uddin, Y. Alginahi, O. A. Bég, M. N. Kabir, Numerical solutions for gyrotactic bioconvection in nanofluid-saturated porous media with Stefan blowing and multiple slip effects, Comput. Math. Appl., 72 (2016), 2562–2581. http://dx.doi.org/10.1016/j.camwa.2016.09.018 doi: 10.1016/j.camwa.2016.09.018
[35]	N. A. Amirsom, M. J. Uddin, A. I. M. Ismail, MHD boundary layer bionanoconvective non-Newtonian flow past a needle with Stefan blowing, Heat Transfer, 48 (2019), 727–743. https://doi.org/10.1002/htj.21403 doi: 10.1002/htj.21403
[36]	W. A. Khan, A. M. Rashad, M. M. M. Abdou, I. Tlili, Natural bioconvection flow of a nanofluid containing gyrotactic microorganisms about a truncated cone, Eur. J. Mech., 75 (2019), 133–142. https://doi.org/10.1016/j.euromechflu.2019.01.002 doi: 10.1016/j.euromechflu.2019.01.002
[37]	F. T. Zohra, M. J. Uddin, M. F. Basir, A. I. M. Ismail, Magnetohydrodynamic bio-nano-convective slip flow with Stefan blowing effects over a rotating disc, Proc. Inst. Mech. Eng., Part N, 234 (2020), 83–97. https://doi.org/10.1177/2397791419881580 doi: 10.1177/2397791419881580
[38]	A. M. Alwatban, S. U. Khan, H. Waqas, I. Tlili, Interaction of Wu's slip features in bioconvection of Eyring Powell nanoparticles with activation energy, Processes, 7 (2019), 859. https://doi.org/10.3390/pr7110859 doi: 10.3390/pr7110859
[39]	A. Kumar, V. Sugunamma, N. Sandeep, J. V. R. Reddy, Impact of Brownian motion and thermophoresis on bioconvective flow of nanoliquids past a variable thickness surface with slip effects, Multidiscip. Model. Mater. Struct., 15 (2019), 103–132. https://doi.org/10.1108/MMMS-02-2018-0023 doi: 10.1108/MMMS-02-2018-0023
[40]	M. A. Imran, S. U. Rehman, A. Ahmadian, S. Salahshour, M. Salimi, First solution of fractional bioconvection with power law kernel for a vertical surfacem, Mathematics, 9 (2021), 1366. https://doi.org/10.3390/math9121366 doi: 10.3390/math9121366
[41]	A. Raees, H. Xu, S. J. Liao, Unsteady mixed nano-bioconvection flow in a horizontal channel with its upper plate expanding or contracting, Int. J. Heat Mass Tran., 86 (2015), 174–182. http://dx.doi.org/10.1016/j.ijheatmasstransfer.2015.03.003 doi: 10.1016/j.ijheatmasstransfer.2015.03.003
[42]	Q. Zhao, H. Xu, L. Tao, Unsteady bioconvection squeezing flow in a horizontal channel with chemical reaction and magnetic field effects, Math. Probl. Eng., 2017 (2017), 2541413. https://doi.org/10.1155/2017/2541413 doi: 10.1155/2017/2541413
[43]	N. A. A. Latiff, M. J. Uddin, O. A. Bég, A. I. Ismail, Unsteady forced bioconvection slip flow of a micropolar nanofluid from a stretching/shrinking sheet, Proc. Inst. Mech. Eng., Part N, 230 (2016), 177–187. https://doi.org/10.1177/1740349915613817 doi: 10.1177/1740349915613817
[44]	L. Ali, X. Liu, B. Ali, S. Mujeed, S. Abdal, Finite element simulation of multi-slip effects on unsteady mhd bioconvective micropolar nanofluid flow over a sheet with solutal and thermal convective boundary conditions, Coatings, 9 (2019), 842. https://doi.org/10.3390/coatings9120842 doi: 10.3390/coatings9120842

This article has been cited by:

1.	Muhammad Imran Asjad, Muhammad Danish Ikram, Ali Ahmadian, Soheil Salahshour, Mehdi Salimi, New solutions of generalized MHD viscous fluid flow with thermal memory and bioconvection, 2022, 147, 1388-6150, 14019, 10.1007/s10973-022-11609-9
2.	Mubashir Qayyum, Efaza Ahmad, Sidra Afzal, Tanveer Sajid, Wasim Jamshed, Awad Musa, El Sayed M. Tag El Din, Amjad Iqbal, Fractional analysis of unsteady squeezing flow of Casson fluid via homotopy perturbation method, 2022, 12, 2045-2322, 10.1038/s41598-022-23239-0
3.	Ayesha Riaz, Muhammad Imran Asjad, Musawa Yahya Almusawa, Sayed M. Eldin, Nejla Mahjoub Said, Muhammad Ijaz Khan, New solutions of fractional Maxwell fluid with ternary-hybrid nanoparticles, 2023, 47, 2214157X, 103091, 10.1016/j.csite.2023.103091
4.	Shajar Abbas, Mushtaq Ahmad, Mudassar Nazar, Zubair Ahmad, Muhammad Amjad, Hakim AL Garalleh, Ahmed Zubair Jan, Soret Effect on MHD Casson Fluid over an Accelerated Plate with the Help of Constant Proportional Caputo Fractional Derivative, 2024, 9, 2470-1343, 10220, 10.1021/acsomega.3c07311
5.	Xiao Xin, Rabia Safdar, Wasim Jamshed, Syed M. Hussain, Abdullah Alhushaybari, Aiedh Mrisi Alharthi, Application of constant proportional caputo (CPC) fractional derivative for natural convective casson nanofluid flow on an infinite cylinder, 2024, 1040-7790, 1, 10.1080/10407790.2024.2327497
6.	Saima Rashid, Madeeha Tahir, Muhammad Imran Asjad, Rafia Shafique, M S Alqurashi, S K Elagan, Advanced modelling techniques for magnetohydrodynamic Casson fluid squeezing flow via generalized fractional operators with neural network scheme, 2024, 99, 0031-8949, 125262, 10.1088/1402-4896/ad8d40

Reader Comments

Your name:*

Email:*
© 2022 the Author(s), licensee AIMS Press. This is an open access article distributed under the terms of the Creative Commons Attribution License (http://creativecommons.org/licenses/by/4.0)

通讯作者: 陈斌, bchen63@163.com

1.
沈阳化工大学材料科学与工程学院沈阳 110142

AIMS Mathematics

1.8 3.4

Metrics

Article views(1990) PDF downloads(95) Cited by(6)

Preview PDF

Download XML

Export Citation

Article outline

Show full outline

Figures and Tables

Figures(10)

AIMS Mathematics

Unsteady Casson fluid flow over a vertical surface with fractional bioconvection

Related Papers:

Abstract

1. Introduction

2. Mathematical formulation

2.1. Heat equation

2.2. Bioconvection equation

2.3. Momentum equation

3. Graphical results and discussion

4. Conclusions

Nomenclature

Acknowledgments

Conflict of interest

References

This article has been cited by:

Reader Comments

通讯作者: 陈斌, bchen63@163.com

Metrics

Figures and Tables

Other Articles By Authors

Catalog

AIMS Mathematics

Unsteady Casson fluid flow over a vertical surface with fractional bioconvection

Related Papers:

Abstract

1. Introduction

2. Mathematical formulation

2.1. Heat equation

2.2. Bioconvection equation

2.3. Momentum equation

3. Graphical results and discussion

4. Conclusions

Nomenclature

Acknowledgments

Conflict of interest

References

This article has been cited by:

Reader Comments

通讯作者: 陈斌, bchen63@163.com

Metrics

Figures and Tables

Other Articles By Authors

Related pages

Tools

Export File

Citation

Format

Content

Catalog
