Study on synergistic effect of multiple physical fields on hot mix asphalt during compaction process

Huanan Yu; Yutang Gao; Guoping Qian; Chao Zhang; Changyun Shi; Jinguo Ge; Wan Dai; Huanan Yu; Yutang Gao; Guoping Qian; Chao Zhang; Changyun Shi; Jinguo Ge; Wan Dai

doi:10.3934/mbe.2024229

Mathematical Biosciences and Engineering

2024, Volume 21, Issue 4: 5181-5206. doi: 10.3934/mbe.2024229

Previous Article Next Article

Research article Special Issues

Study on synergistic effect of multiple physical fields on hot mix asphalt during compaction process

1.
National Engineering Research Center of Highway Maintenance Technology, School of Traffic and Transportation Engineering, Changsha University of Science & Technology, Changsha 410114, China
2.
Xiangjiang Laboratory, Changsha 410205, China

Academic Editor: Hui Yao

Received: 09 January 2024 Revised: 26 February 2024 Accepted: 27 February 2024 Published: 06 March 2024

The multiple physical fields of hot mix asphalt (HMA) during the compaction process have a significant impact on the durability of asphalt pavement, and this research aimed to evaluate the synergistic effect of the HMA field compaction of multi-physical field evolution during the compaction process. First, the temperature field, structural layer thickness variation, and structural layer density variation were monitored during field compaction. Second, the evolution properties of compaction thickness were obtained under the synergistic influence of multi-physical fields by temperature field and compaction thickness. Finally, the evolution properties of compaction density were obtained under the synergistic influence of multi-physical fields based on the temperature field and structural layer density. The results showed that the field compaction process could be characterized by three stages under the synergistic impact of multi-physical fields. The cooling of the temperature field presents two-stage characteristics. There were cubic polynomial evolution properties for the temperature field versus time and the density versus temperature field. There was an exponential relationship between the thickness of the compacted layer and the number of mills. The aggregate particles showed different motion characteristics in the horizontal and vertical directions and vertical directions. The vertical displacement was larger than the horizontal displacement under the synergistic influence of multi-physical fields during the three stages of compaction. The migration and reorganization of aggregate particles affected the evolution of the multi-physics fields of the compaction process under the action of different compaction modes.

Keywords:

Citation: Huanan Yu, Yutang Gao, Guoping Qian, Chao Zhang, Changyun Shi, Jinguo Ge, Wan Dai. Study on synergistic effect of multiple physical fields on hot mix asphalt during compaction process[J]. Mathematical Biosciences and Engineering, 2024, 21(4): 5181-5206. doi: 10.3934/mbe.2024229

Related Papers:

[1]	Qian Lin, Yan Zhu . Unicyclic graphs with extremal exponential Randić index. Mathematical Modelling and Control, 2021, 1(3): 164-171. doi: 10.3934/mmc.2021015
[2]	Zhen Lin . On the sum of powers of the $A_{\alpha}$ -eigenvalues of graphs. Mathematical Modelling and Control, 2022, 2(2): 55-64. doi: 10.3934/mmc.2022007
[3]	Iman Malmir . Novel closed-loop controllers for fractional nonlinear quadratic systems. Mathematical Modelling and Control, 2023, 3(4): 345-354. doi: 10.3934/mmc.2023028
[4]	Zhibo Cheng, Pedro J. Torres . Periodic solutions of the $L_p$ -Minkowski problem with indefinite weight. Mathematical Modelling and Control, 2022, 2(1): 7-12. doi: 10.3934/mmc.2022002
[5]	Mrutyunjaya Sahoo, Dhabaleswar Mohapatra, S. Chakraverty . Wave solution for time fractional geophysical KdV equation in uncertain environment. Mathematical Modelling and Control, 2025, 5(1): 61-72. doi: 10.3934/mmc.2025005
[6]	Vladimir Stojanovic . Fault-tolerant control of a hydraulic servo actuator via adaptive dynamic programming. Mathematical Modelling and Control, 2023, 3(3): 181-191. doi: 10.3934/mmc.2023016
[7]	Jiaquan Huang, Zhen Jia, Peng Zuo . Improved collaborative filtering personalized recommendation algorithm based on k-means clustering and weighted similarity on the reduced item space. Mathematical Modelling and Control, 2023, 3(1): 39-49. doi: 10.3934/mmc.2023004
[8]	Qian Wang, Xue Han . Comparing the number of ideals in quadratic number fields. Mathematical Modelling and Control, 2022, 2(4): 268-271. doi: 10.3934/mmc.2022025
[9]	Yongming Li, Shou Ma, Kunting Yu, Xingli Guo . Vehicle kinematic and dynamic modeling for three-axles heavy duty vehicle. Mathematical Modelling and Control, 2022, 2(4): 176-184. doi: 10.3934/mmc.2022018
[10]	Yanchao He, Yuzhen Bai . Finite-time stability and applications of positive switched linear delayed impulsive systems. Mathematical Modelling and Control, 2024, 4(2): 178-194. doi: 10.3934/mmc.2024016

Abstract

1. Introduction

In theoretical chemistry, the topological index of a graph, also called molecular structure descriptor, is a real number related to a structural graph of a molecule, and is often used to predict the physico-chemical properties and biological activities of molecules. A large number of molecular structure descriptors have been conceived and several of them have found applications in quantitative structure-activity and structure-property relationships (QSAR/QSPR) studies. In particular, degree-based topological indices and distance-based topological indices are the most important molecular structure descriptors that play an important role in QSAR/QSPR.

Throughout in this paper, $G$ is a simple connected undirected graph with the vertex set $V(G)$ and edge set $E(G)$ . For $u, v \in V(G)$ , $d_v$ is the degree of vertex $v$ in $G$ and $d(u, v)$ is the distance between vertices $u$ and $v$ in $G$ . As a molecular descriptor, the Wiener index, introduced by Wiener ^[1] in 1947, is considered as one of the most used topological indexes with high correlation with many physical and chemical indices of molecular compounds. The Wiener index equals the sum of distances between all pairs of vertices of a graph $G$ , that is,

$W(G) = \sum\limits_{\{u, v \}\subseteq V(G)}d(u, v).$

In 1989, the Schultz index ^[2] of a chemical graph $G$ was put forward as a topological index of alkanes. It is defined as

$S(G) = \sum\limits_{\{u, v \}\subseteq V(G)}(d_u+d_v)d(u, v).$

The proposal of this index has opened up the research on the degree-distance-type index. Plavšić et al. ^[3] showed that the Wiener index and the Schultz index are highly intercorrelated topological indices. For arbitrary catacondensed benzenoid graphs, Dobrynin ^[4] proved that the Schultz index has the same discriminating power with the Wiener index. So, it is both significant and interesting to study the Schultz index for some given class of graphs (or network), no matter whether they are molecular graphs or not.

In 1994, Gutman ^[5] proposed the Schultz index of the second kind, often called the Gutman index, and defined it as

$Gut(G) = \sum\limits_{\{u, v \}\subseteq V(G)}d_ud_vd(u, v).$

Bounds of this index have been extensively studied using mathematical methods; see ^[6]. Moreover, for a tree $T$ on $n$ vertices, the Gutman index and Wiener index are closely related by

$Gut(T) = 4W(T)-(n-1)(2n-1).$

In 2021, from a geometric perspective (degree radius), Gutman ^[7] introduced a novel degree-based topological index called the Sombor index, which is defined as

$SO(G) = \sum\limits_{uv\in E(G)}\sqrt{d^2_u+d^2_v}.$

Note that the Sombor index is the sum of Euclidean distances of the degrees of the two vertices of each edge in the graph. This index is widely studied in mathematics and chemistry; see ^[8].

Inspired by the above research, we propose a new topological index called the Sombor-Wiener (SW) index, and define it as

$SW(G) = \sum\limits_{\{u, v\}\subseteq V(G)}\sqrt{d^2_u+d^2_v}d(u, v).$

The new index can be regarded as the sum of the product of degree radius and distance between any two vertices in the graph, which is a novel version of the distance-based topological index.

Naturally, we define a general topological index $DWW(G)$ of a graph $G$ contributed by the degree weights of all vertices as

$DWW(G) = \sum\limits_{\{u, v\}\subseteq V(G)}f(d_u, d_v)d(u, v),$

where $f(d_u, d_v)$ is a real function of $d_u$ and $d_v$ with

$f(d_u, d_v)\geq 0\; \; \text{and}\; \; f(d_u, d_v) = f(d_v, d_u).$

Clearly, the general topological index, called the degree-weighted Wiener index, is the generalization of the Schultz index, the Gutman index, and the SW index.

In this paper, we study the basic properties of the SW index, and the linear regression analysis of the SW index, with respect to acentric factor of octane isomers. In addition, we give the calculation formula of degree-weighted Wiener index for generalized Bethe trees. Our results generalize some known formulae on the Schultz index and Gutman index.

2. Basic properties of the SW index

Theorem 2.1. Let $G$ be a connected graph with $n$ vertices.

(i) If $G = P_n$ , then

$SW(G) = (n-1)\left(\frac{\sqrt{2}(n^2-5n+9)}{3}+\sqrt{5}(n-2)\right).$

(ii) If $G$ is $r$ -regular, then

$SW(G) = \sqrt{2}rW(G).$

Moreover, if $G = K_n$ , then

$SW(G) = \frac{\sqrt{2}n(n-1)^2}{2}.$

If $G = C_n$ , then

$SW(G) =\left\{ \begin{array}{l}\frac{\sqrt{2}n^3}{4} , \qquad \qquad \mathit{\text{if n is even;}}\\ \frac{\sqrt{2}n(n^2-1)}{4}, \ \quad \mathit{\text{if n is odd.}} \end{array} \right.$

(iii) If $G = K_{n_1, \, n_2}$ , then

$SW(G) = n_1n_2\left[\sqrt{n_1^2+n_2^2}+\sqrt{2}(n_1+n_2)-2\sqrt{2}\right].$

In particular, if $G = K_{1, \, n-1}$ , then

$SW(G) = (n-1)(\sqrt{n^2-2n+2}+\sqrt{2}n-2\sqrt{2}).$

Proof. (i) If $G = P_n$ , then

$\begin{align*} SW(G) = & \sum\limits_{\{u, v\}\subseteq V(G)}\sqrt{d^2_u+d^2_v}d(u, v)\\ = & \sqrt{5}(1+2+\cdots+n-2)+\sqrt{2}(n-1)\\ & +2\sqrt{2}(1+2+\cdots+n-3)\\ & +\sqrt{5}(n-2)+\cdots+2\sqrt{2}+2\sqrt{5}+\sqrt{5}\\ = & \frac{\sqrt{5}(n-1)(n-2)}{2}+\sqrt{2}(n-1)\\ & +2\sqrt{2}\left(1+3+\cdots+\frac{(n-3)(n-2)}{2}\right)\\ & +\sqrt{5}(1+2+\cdots+n-2)\\ = & \sqrt{2}(n-1)+\sqrt{5}(n-1)(n-2)\\ & +\frac{2\sqrt{2}(n-1)(n-2)(n-3)}{6}\\ = & (n-1)\left(\frac{\sqrt{2}(n^2-5n+9)}{3}+\sqrt{5}(n-2)\right). \end{align*}$

(ii) If $G$ is $r$ -regular, then

$SW(G) = \sum\limits_{\{u, v\}\subseteq V(G)}\sqrt{r^2+r^2}d(u, v) = \sqrt{2}rW(G).$

In particular, if $G = K_n$ , then

$\begin{align*} SW(G) & = \sqrt{2}(n-1)W(G)\\& = \sqrt{2}(n-1)\frac{n(n-1)}{2}\\ & = \frac{\sqrt{2}n(n-1)^2}{2}. \end{align*}$

If $G$ is a cycle $C_n$ , from ^[9], we have

$SW(G) = \left\{ \begin{array}{l}\frac{\sqrt{2}n^3}{4} , \qquad \qquad \text{if } ~~n ~~\text{ is even;}\\ \frac{\sqrt{2}n(n^2-1)}{4}, \ \quad \text{if } ~~n ~~ \text{is odd.} \end{array} \right.$

(iii) If $G = K_{n_1, \, n_2}$ , then

$\begin{align*} SW(G) = & \sum\limits_{\{u, v\}\subseteq V(G)}\sqrt{d^2_u+d^2_v}d(u, v)\\ = & n_1n_2\sqrt{n_1^2+n_2^2}+2\binom{n_1}{2}\sqrt{n_2^2+n_2^2}\\ & +2\binom{n_2}{2}\sqrt{n_1^2+n_1^2}\\ = & n_1n_2\left[\sqrt{n_1^2+n_2^2}+\sqrt{2}(n_1+n_2)-2\sqrt{2}\right]. \end{align*}$

Let $n_1 = 1$ and $n_2 = n-1$ , then

$SW(K_{1, \, n-1}) = (n-1)(\sqrt{n^2-2n+2}+\sqrt{2}n-2\sqrt{2}).$

This completes the proof. □

Theorem 2.2. Let $G$ be a connected graph with the maximum degree $\Delta$ and the minimum degree $\delta$ , then

$\sqrt{2}\delta W(G)\leq SW(G)\leq \sqrt{2}\Delta W(G)$

with equality if, and only if, $G$ is regular.

Proof. By definition of $SW(G)$ , we have the proof. □

Corollary 2.3. Let $G$ be a connected graph with $n$ vertices, then

$\sqrt{2} W(G)\leq SW(G)\leq \sqrt{2}(n-1) W(G).$

Theorem 2.4. Let $G$ be a connected graph with the minimum degree $\delta$ , then

$\begin{align} \frac{1}{\sqrt{2}}S(G)\leq SW(G) \leq S(G)-(2-\sqrt{2})\delta W(G) \end{align}$

(2.1)

with equality (left and right) if, and only if, $G$ is regular.

Proof. First, we prove the left-hand side of (2.1). By Cauchy-Schwarz's inequality, we have

$\begin{align*} SW(G) & = \sum\limits_{\{u, v\}\subseteq V(G)}\sqrt{d^2_u+d^2_v}d(u, v)\\ & \geq \sum\limits_{\{u, v\}\subseteq V(G)}\frac{1}{\sqrt{2}}(d_u+d_v)d(u, v)\\ & = \frac{1}{\sqrt{2}}S(G) \end{align*}$

with equality if, and only if, $d_u = d_v$ for $u, v\in V(G)$ , that is, $G$ is regular.

Second, we prove the righthand side of (2.1). For any $u, v \in V(G)$ ( $d_u\geq d_v$ ), we have

$\sqrt{d^2_u+d^2_v}\leq d_u+(\sqrt{2}-1)d_v$

with equality if, and only if, $d_u = d_v$ . Thus,

$\begin{align*} \begin{aligned} SW(G) & = \sum\limits_{\{u, v\}\subseteq V(G)}\sqrt{d^2_u+d^2_v}d(u, v)\\ & \leq \sum\limits_{\{u, v\}\subseteq V(G)} [d_u+(\sqrt{2}-1)d_v]d(u, v)\\ & \leq \sum\limits_{\{u, v\}\subseteq V(G)} (d_u+d_v)d(u, v)-\sum\limits_{\{u, v\}\subseteq V(G)} (2-\sqrt{2})\delta d(u, v)\\ & \leq S(G)-(2-\sqrt{2})\delta W(G)\end{aligned} \end{align*}$

with equality if, and only if, $G$ is regular.

This completes the proof. □

Theorem 2.5. Let $G$ be a connected graph with the maximum degree $\Delta$ and the minimum degree $\delta$ , then

$\frac{\sqrt{2}}{\Delta}Gut(G)\leq SW(G) \leq \frac{\sqrt{2}}{\delta}Gut(G)$

with equality (left and right) if, and only if, $G$ is regular.

Proof. Note that

$\sqrt{d^2_u+d^2_v} = d_ud_v\sqrt{\frac{1}{d_u^2}+\frac{1}{d_v^2}},$

then we have

$\begin{align*} SW(G) & = \sum\limits_{\{u, v\}\subseteq V(G)}\sqrt{d^2_u+d^2_v}d(u, v)\\ & \leq \sum\limits_{\{u, v\}\subseteq V(G)} d_ud_v\sqrt{\frac{1}{\delta^2}+\frac{1}{\delta^2}}d(u, v)\\ & = \frac{\sqrt{2}}{\delta}\sum\limits_{\{u, v\}\subseteq V(G)} d_ud_vd(u, v)\\ & = \frac{\sqrt{2}}{\delta}Gut(G) \end{align*}$

and

$\begin{align*} SW(G) & = \sum\limits_{\{u, v\}\subseteq V(G)}\sqrt{d^2_u+d^2_v}d(u, v)\\ & \geq \sum\limits_{\{u, v\}\subseteq V(G)} d_ud_v\sqrt{\frac{1}{\Delta^2}+\frac{1}{\Delta^2}}d(u, v)\\ & = \frac{\sqrt{2}}{\Delta}\sum\limits_{\{u, v\}\subseteq V(G)} d_ud_vd(u, v)\\ & = \frac{\sqrt{2}}{\Delta}Gut(G). \end{align*}$

This completes the proof. □

3. Degree-weighted Wiener index of generalized Bethe trees

The generalized Bethe tree is an important graph structure that has wide applications in many fields. The investigation on topological indices of generalized Bethe trees and dendrimer trees frequently appeared in various journals. A Bethe tree $B_{k, d}$ is a rooted tree at $k$ levels whose root is on level $1$ and has degree equal to $d$ , the vertices of levels from $2$ to $k-1$ have degrees equal to $d+1$ , and the vertices on the level $k$ have degree equal to $1$ ; see ^[10]. In 2007, Rojo ^[11] generalized the notion of a Bethe tree as follows: A generalized Bethe tree $B_{k}$ is a rooted tree whose vertices at the same level have equal degrees. Moreover, a regular dendrimer tree $T_{k, d}$ is a generalized Bethe tree of $k+1$ levels with each non-pendent vertex having degree $d$ .

Theorem 3.1. Let $B_{k+1}$ be a generalized Bethe tree of $k+1$ levels. If $d_1$ denotes the degree of rooted vertex and $d_i+1$ denotes the degree of vertices on the $i$ -th level of $B_{k+1}$ for $i < 1\leq k$ , then

$DWW(B_{k+1}) = \sum\limits_{l = 1}^{k+1}A_l,$

where $n_j$ is the number of vertices on the $j$ -th level of $B_{k+1}$ , and

$n_1 = 1\; \; \mathit{\text{and}}\; \; n_{j+1} = d_1d_2\cdots d_j$

for $1\leq j\leq k$ , and

$\begin{align*} \begin{aligned} A_1 = & \sum\limits_{j = 2}^{k}n_j(j-1)f(d_1, d_j+1 )+kn_{k+1}f(d_1, 1), \\ A_l = & \Big[2\binom{d_{l-1}}{2}+4\binom{d_{l-1}}{1}\binom{d_{l-1}d_{l-2}-d_{l-1}}{1}+\cdots\\ & +2(l-1)\binom{d_{l-1}\cdots d_{2}}{1}\binom{n_l-d_{l-1}\cdots d_{2}}{1}\Big]f(d_l+1, d_l+1)\\ & +\sum\limits_{j = l+1}^{k}n_j(j-l)f(d_l+1, d_j+1)\\&+(k-l+1)n_{k+1}f(d_l+1, 1)\\ & +(d_{l-1}-1)\Big[\sum\limits_{j = l+1}^{k}n_j(j-l+2)f(d_l+1, d_j+1)\\ & +(k-l+3)n_{k+1}f(d_l+1, 1)\Big]\\ & +(d_{l-1}d_{l-2}-d_{l-1})\Big[\sum\limits_{j = l+1}^{k}n_j(j-l+4)f(d_l+1, d_j+1)\\ & +(k-l+5)n_{k+1}f(d_l+1, 1)\Big]+\cdots\\ & +(n_l-d_{l-1}\cdots d_2)\Big[\sum\limits_{j = l+1}^{k}n_j(j+l-2)f(d_l+1, d_j+1)\\ & +(k+l-1)n_{k+1}f(d_l+1, 1)\Big], \\ A_{k+1} = & f(1, 1)\Big[2\binom{d_{k}}{2}+4\binom{d_{k}}{1}\binom{d_{k}d_{k-1}-d_{k}}{1}+\cdots\\ & +2k\binom{d_{k}\cdots d_{2}}{1}\binom{n_{k+1}-d_{k}\cdots d_{2}}{1}\Big].\end{aligned} \end{align*}$

Proof. Let $A_i$ be the value of degree-weighted Wiener index of vertices on the $i$ -th level of $B_{k+1}$ , then

$DWW(B_{k+1}) = \sum\limits_{i = 1}^{k+1}A_i.$

By definition of $B_{k+1}$ , we have

$\begin{align*} A_1 = & n_2f(d_1, d_2+1)+2n_3f(d_1, d_3+1)+\cdots\\ & +(k-1)n_kf(d_1, d_k+1)+kn_{k+1}f(d_1, 1)\\ = & \sum\limits_{j = 2}^{k}n_j(j-1)f(d_1, d_j+1)+kn_{k+1}f(d_1, 1), \\ A_2 = & 2 \binom{d_1}{2}f(d_2+1, d_2+1)+n_2\Big[d_2f(d_2+1, d_3+1)\\ & +2d_2d_3f(d_2+1, d_4+1) + \cdots\\ &+ d_2d_3\cdots d_{k-1}(k-2)f(d_2+1, d_k+1)\\ & +d_2d_3\cdots d_{k}(k-1)f(d_2+1, 1)\\ & +(n_2-1)(3d_2f(d_2+1, d_3+1)\\ & +4d_2d_3f(d_2+1, d_4+1)+\cdots\\ & +d_2d_3\cdots d_{k-1}kf(d_2+1, d_k+1)\\ &+d_2d_3\cdots d_{k}(k+1)f(d_2+1, 1))\Big]\\ = & d_1(d_1-1)f(d_2+1, d_2+1)\\ & +n_2\Big[n_3/d_1f(d_2+1, d_3+1) \\ & +2n_4/d_1f(d_2+1, d_4+1) + \cdots\\ &+ n_k/d_1(k-2)f(d_2+1, d_k+1)\\ & +n_{k+1}/d_1(k-1)f(d_2+1, 1)\\ & +(n_2-1)(3n_3/d_1f(d_2+1, d_3+1)\\ & +4n_4/d_1f(d_2+1, d_4+1)+\cdots\\ & +kn_k/d_1f(d_2+1, d_k+1)\\ & +n_{k+1}/d_1(k+1)f(d_2+1, 1))\Big]\\ = & d_1(d_1-1)f(d_2+1, d_2+1)\\ &+ n_2/d_1\Big[\sum\limits_{j = 3}^{k}(j-2)n_jf(d_2+1, d_j+1)\\ & +(k-1)n_{k+1}f(d_2+1, 1)\\ & +(n_2-1)(\sum\limits_{j = 3}^{k}jn_jf(d_2+1, d_j+1)\\ & +(k+1)n_{k+1}f(d_2+1, 1))\Big]\\ = &d_1(d_1-1)f(d_2+1, d_2+1)\\ & + \sum\limits_{j = 3}^{k}(j-2)n_jf(d_2+1, d_j+1)\\ & +(k-1)n_{k+1}f(d_2+1, 1)\\ & +(n_2-1)\Big[\sum\limits_{j = 3}^{k}jn_jf(d_2+1, d_j+1)\\ & +(k+1)n_{k+1}f(d_2+1, 1)\Big], \\ A_3 = & \Big[2\binom{d_2}{2}+4\binom{d_2}{1}\binom{n_3-d_2}{1}\Big]f(d_3+1, d_3+1)\\ & +n_3\Big[d_3f(d_3+1, d_4+1)\\ & +2d_3d_4f(d_3+1, d_5+1)+\cdots\\ & +(k-3)d_3d_4\cdots d_{k-1}f(d_3+1, d_{k}+1)\\ & +(k-2)d_3d_4\cdots d_k f(d_3+1, 1)\\ & +(d_2-1)(3d_3f(d_3+1, d_4+1)\\ & +4d_3d_4 f(d_3+1, d_5+1)+\cdots\\ & +(k-1)d_3d_4\cdots d_{k-1}f(d_3+1, d_{k}+1)\\ & +kd_3d_4\cdots d_k f(d_3+1, 1))\\ & +(n_3-d_2)(5d_3f(d_3+1, d_4+1)\\ & +6d_3d_4f(d_3+1, d_5+1)+\cdots\\ & +(k+1)d_3d_4\cdots d_{k-1}f(d_3+1, d_{k}+1)\\ & +(k+2)d_3d_4\cdots d_k f(d_3+1, 1))\Big]\\ = & \Big[2\binom{d_2}{2}+4\binom{d_2}{1}\binom{n_3-d_2}{1}\Big])f(d_3+1, d_3+1)\\ & +\sum\limits_{j = 4}^{k}n_j(j-3)f(d_3+1, d_j+1)\\ & +(k-2)n_{k+1}f(d_3+1, 1)\\ & +(d_2-1)\Big[\sum\limits_{j = 4}^{k}n_j(j-1)f(d_3+1, d_j+1)\\ & +kn_{k+1}f(d_3+1, 1)\Big]\\&+(n_3-d_2)\Big[\sum\limits_{j = 4}^{k}n_j(j+1)f(d_3+1, d_j+1)\\ & +n_{k+1}(k+2)f(d_3+1, 1)\Big]. \end{align*}$

By calculating similarly to the above, for any $2\leq l \leq k$ , we have

$\begin{align*} A_l = & \Big[2\binom{d_{l-1}}{2}+4\binom{d_{l-1}}{1}\binom{d_{l-1}d_{l-2}-d_{l-1}}{1}+\cdots\\ & +2(l-1)\binom{d_{l-1}\cdots d_{2}}{1}\binom{n_l-d_{l-1}\cdots d_{2}}{1}\Big]f(d_l+1, d_l+1)\\ & +\sum\limits_{j = l+1}^{k}n_j(j-l)f(d_l+1, d_j+1)\\&+(k-l+1)n_{k+1}f(d_l+1, 1)\\ & +(d_{l-1}-1)\Big[\sum\limits_{j = l+1}^{k}n_j(j-l+2)f(d_l+1, d_j+1)\\ & +(k-l+3)n_{k+1}f(d_l+1, 1)\Big]\\ & +(d_{l-1}d_{l-2}-d_{l-1})\Big[\sum\limits_{j = l+1}^{k}n_j(j-l+4)f(d_l+1, d_j+1)\\ & +(k-l+5)n_{k+1}f(d_l+1, 1)\Big]+\cdots\\ & +(n_l-d_{l-1}\cdots d_2)\Big[\sum\limits_{j = l+1}^{k}n_j(j+l-2)f(d_l+1, d_j+1)\\ & +(k+l-1)n_{k+1}f(d_l+1, 1)\Big]. \end{align*}$

In particular, we have

$\begin{align*} A_{k+1} = & f(1, 1)\Big[2\binom{d_{k}}{2}+4\binom{d_{k}}{1}\binom{d_{k}d_{k-1}-d_{k}}{1}+\cdots\\ & +2k\binom{d_{k}\cdots d_{2}}{1}\binom{n_{k+1}-d_{k}\cdots d_{2}}{1}\Big]. \end{align*}$

This completes the proof. □

Corollary 3.2. The degree-weighted Wiener index of a Bethe tree $B_{k, d}$ is

$DWW(B_{k, d}) = \sum\limits_{l = 1}^{k}A_l,$

where

$\begin{align*} A_1 = & \sum\limits_{j = 2}^{k-1}d(d+1)^{j-2}(j-1)f(d, d+1)+(k-1)d(d+1)^{k-2}f(d, 1), \\ A_l = & \Big[2\binom{d+1}{2}+4\binom{d+1}{1}\binom{(d+1)^2-(d+1)}{1}+\cdots\\ & +2(l-1)\binom{d^{l-2}}{1}\binom{n_l-d^{l-2}}{1}\Big]f(d+1, d+1)\\ & +\sum\limits_{j = l+1}^{k-1}n_j(j-l)f(d+1, d+1)+(k-l)n_{k}f(d+1, 1)\\ & +(d_{l-1}-1)\Big[\sum\limits_{j = l+1}^{k-1}f(d+1, d+1)n_j(j-l+2)\\ & +(k-l+2)n_{k}f(d+1, 1)\Big]\\ & +(d_{l-1}d_{l-2}-d_{l-1})\Big[\sum\limits_{j = l+1}^{k-1}n_j(j-l+4)f(d+1, d+1)\\ & +(k-l+4)n_{k}f(d+1, 1)\Big] +\cdots\\ & +(n_l-d_{l-1}\cdots d_2)\Big[\sum\limits_{j = l+1}^{k-1}n_j(j+l-2)f(d+1, d+1)\\ & +(k+l-2)n_{k}f(d+1, 1)\Big], \\ A_{k} = & f(1, 1)\Big[2\binom{d}{2}+4\binom{d}{1}\binom{d(d-1)}{1}+\cdots\\ & +2(k-1)\binom{d^{k-2}}{1}\binom{(d-1)d^{k-2}}{1}\Big]. \end{align*}$

Corollary 3.3. The degree-weighted Wiener index of a regular dendrimer tree $T_{k, d}$ is

$DWW(T_{k, d}) = \sum\limits_{l = 1}^{k+1}A_l,$

where

$\begin{align*} A_1 = & \sum\limits_{j = 2}^{k}n_j(j-1)f(d, d)+kd(d-1)^{k-1}f(d, 1), \\ A_l = & \Big[2\binom{d-1}{2}+4\binom{d-1}{1}\binom{(d-1)(d-2)}{1}+\cdots\\ & +2(l-1)\binom{(d-1)^{l-2}}{1}\binom{n_l-(d-1)^{l-2}}{1}\Big]f(d, d)\\ & +\sum\limits_{j = l+1}^{k}n_j(j-l)f(d, d)+(k-l+1)n_{k+1}f(d, 1)\\ & +(d-2)\Big[\sum\limits_{j = l+1}^{k}n_j(j-l+2)f(d, d)\\ & +(k-l+3)n_{k+1}f(d, 1)\Big]\\ & +(d-1)(d-2)\Big[\sum\limits_{j = l+1}^{k}n_j(j-l+4)f(d, d)\\ & +(k-l+5)n_{k+1}f(d, 1)\Big] +\cdots\\ & +(n_l-(d-1)^{l-2})\Big[\sum\limits_{j = l+1}^{k}n_j(j+l-2)f(d, d)\\ & +(k+l-1)n_{k+1}f(d, 1)\Big], \\ A_{k+1} = & f(1, 1)\Big[2\binom{d-1}{2}+4\binom{d-1}{1}\binom{(d-1)(d-2)}{1}+\cdots\\ & +2k\binom{(d-1)^{k-1}}{1}\binom{(d-1)^{k}}{1}\Big]. \end{align*}$

4. Applications of SW indices to the acentric factor of octane isomers

In this section, the chemical applicability of the SW index is investigated. The acentric factor (AcenFac) is a measure of the non-sphericity of molecules. We consider the correlation between acentric factors of octane isomers and the respective SW indices. The experimental values of acentric factors of octane isomers were taken from http://www.moleculardescriptors.eu/dataset/dataset.htm.

Using the data from Table 1, we find the correlation of AcenFac with the value of SW index for octane isomers; see Figure 1. The following equations give the regression models for the SW index:

$AcenFac = 0.00198\times SW+0.008141.$

Table 1. Experimental values of AcenFac and SW index for octane isomers.

Molecule	AcenFac	SW
Octane	0.397898	202.8093
2-methyl-heptane	0.377916	191.2453
3-methyl-heptane	0.371002	182.2057
4-methyl-heptane	0.371504	179.1925
3-ethyl-hexane	0.362472	170.5225
2, 2-dimethyl-hexane	0.339426	170.4970
2, 3-dimethyl-hexane	0.348247	166.8181
2, 4-dimethyl-hexane	0.344223	169.9447
2, 5-dimethyl-hexane	0.35683	179.0977
3, 3-dimethyl-hexane	0.322596	158.2653
3, 4-dimethyl-hexane	0.340345	160.7917
2-methyl-3-ethyl-pentane	0.332433	157.9633
3-methyl-3-ethyl-pentane	0.306899	149.3210
2, 2, 3-trimethyl-pentane	0.300816	148.2544
2, 2, 4-trimethyl-pentane	0.30537	157.5862
2, 3, 3-trimethyl-pentane	0.293177	145.1517
2, 3, 4-trimethyl-pentane	0.317422	153.9314
2, 2, 3, 3-tetramethylbutane	0.255294	135.0271

| Show Table

DownLoad: CSV

Figure 1. Scatter plot between acentric factor of Octane isomers and their SW index.

DownLoad: Full-Size Img PowerPoint

Thus, the SW index can also help to predict the properties of octane isomers.

5. Conclusions

In this paper, we propose the SW index, and establish some mathematical relations between the Harary-Sombor index and other classic topological indices. Morover, we obtain the calculation formula of degree-weighted Wiener index for generalized Bethe trees. In addition, some numerical results are discussed. We calculate the SW index of octane isomers. The regression models show that the AcenFac and SW index of octane isomers are highly correlated.

In 1993, Klein and Randić ^[12] introduced the notion of resistance distance. Naturally, from the perspective of distance, we similarly propose the degree-weighted resistance-distance index of a graph $G$ and define it as

$DWR(G) = \sum\limits_{\{u, v \}\subseteq V(G)}f(d_u, d_v)r(u, v),$

where $r(u, v)$ is the resistance distance between $u$ and $v$ . It would be interesting to explore chemical and mathematical properties and possible predictive potential of this index.

Use of AI tools declaration

The authors declare they have not used Artificial Intelligence (AI) tools in the creation of this article.

Acknowledgments

The authors are thankful to the anonymous referees for their helpful comments that improved the quality of the manuscript. This work was funded by the National Natural Science Foundation of China under Grant No. 12261074.

Conflict of interest

The authors declare no conflicts of interest to this work.

References

[1]	R. N. Linden, J. P. Mahoney, N. C. Jackson, Effect of compaction on asphalt concrete performance, Transp. Res. Rec., 1217 (1989), 20–28. https://onlinepubs.trb.org/Onlinepubs/trr/1989/1217/1217-003.pdf
[2]	X. Zhao, D. Niu, P. Zhang, Y. Niu, H. Xia, P. Liu, Macro-meso multiscale analysis of asphalt concrete in different laboratory compaction methods and field compaction, Constr. Build. Mater., 361 (2022), 129607. https://doi.org/10.1016/j.conbuildmat.2022.129607 doi: 10.1016/j.conbuildmat.2022.129607
[3]	H. Zhang, H. Ding, A. Rahman, Effect of asphalt mortar viscoelasticity on microstructural fracture behavior of asphalt mixture based on cohesive zone model, J. Mater. Civ. Eng., 34 (2022), 04022122. https://doi.org/10.1061/(ASCE)MT.1943-5533.0004277 doi: 10.1061/(ASCE)MT.1943-5533.0004277
[4]	H. Wang, C. Wang, Z. You, X. Yang, Z. Huang, Characterising the asphalt concrete fracture performance from X-ray CT Imaging and finite element modelling, Int. J. Pavement Eng., 19 (2018), 307–318. https://doi.org/10.1080/10298436.2017.1347440 doi: 10.1080/10298436.2017.1347440
[5]	P. Liu, H. Xu, D. Wang, C. Wang, C. Schulze, M. Oeser, Comparison of mechanical responses of asphalt mixtures manufactured by different compaction methods, Constr Build Mater., 162 (2018), 765–780. https://doi.org/10.1016/j.conbuildmat.2017.12.082 doi: 10.1016/j.conbuildmat.2017.12.082
[6]	W. Liu, Y. Gao, X. Huang, L. Li, Investigation of motion of coarse aggregates in asphalt mixture based on virtual simulation of compaction test, Int. J. Pavement Eng., 21 (2018), 1–13. https://10.1080/10298436.2018.1447109 doi: 10.1080/10298436.2018.1447109
[7]	W. Liu, X. Gong, Y. Gao, L. Li, Evaluation, Microscopic characteristics of field Compaction of asphalt mixture using discrete element method, J. Test. Eval., 47 (2019), 20180633. https://10.1520/JTE20180633 doi: 10.1520/JTE20180633
[8]	X. Yang, Z. You, C. Jin, H. Wang, Aggregate representation for mesostructure of stone based materials using a sphere growth model based on realistic aggregate shapes, Mater. Struct., 49 (2016), 2493–2508. https://10.1617/s11527-015-0662-y doi: 10.1617/s11527-015-0662-y
[9]	Q. Liu, J. Hu, P. Liu, J. Wu, M. Oeser, Uncertainty analysis of in-situ pavement compaction considering microstructural characteristics of asphalt mixtures, Constr. Build. Mater., 279 (2021), 122514. https://10.1016/j.conbuildmat.2021.122514 doi: 10.1016/j.conbuildmat.2021.122514
[10]	C. Zhang, H. Yu, X. Zhu, D. Yao, X. Peng, X. Fan, Unified characterization of rubber asphalt mixture strength under different stress loading paths, J. Mater. Civ. Eng., 36 (2024), 04023498. https://doi.org/10.1061/JMCEE7.MTENG-16145 doi: 10.1061/JMCEE7.MTENG-16145
[11]	T. Huang, Z. Wang, H. Dong, H. Qin, H. Liu, Z. Cao, Time-temperature-stress equivalent characteristics and nonlinear viscoelastic model of asphalt mixture under triaxial compressive stress state, J. Mater. Civ. Eng., 36 (2024), 04023543. https://doi.org/10.1061/JMCEE7.MTENG-16679 doi: 10.1061/JMCEE7.MTENG-16679
[12]	H.Y. Ahmed, Methodology for determining most suitable compaction temperatures for hot mix asphalt, J. Eng. Sci., (2007), 1235–1253. https://10.21608/jesaun.2007.114551 doi: 10.21608/jesaun.2007.114551
[13]	D. Jin, K. A. Boateng, S. Chen, K. Xin, Z. You, Comparison of rubber asphalt with polymer asphalt under long-term aging conditions in Michigan, Sustainability, 14 (2022). https://doi.org/10.3390/su141710987 doi: 10.3390/su141710987
[14]	Y. Gao, X. Huang, W. Yu, The compaction characteristics of hot mixed asphalt mixtures, J. Wuhan Univ. Technol.-Mater. Sci. Ed., 29 (2014), 956–959. https://10.1007/s11595-014-1027-z doi: 10.1007/s11595-014-1027-z
[15]	P. Liu, C. Wang, W. Lu, M. Moharekpour, M. Oeser, D. Wang, Development of an FEM-DEM model to investigate preliminary compaction of asphalt pavements, Buildings, 12 (2022), 932. https://doi.org/10.3390/buildings12070932 doi: 10.3390/buildings12070932
[16]	S. Komaragiri, A. Gigliotti, A. Bhasin, Feasibility of using a physics engine to virtually compact asphalt mixtures in a gyratory compactor, Constr. Build. Mater., 308 (2021), 124977. https://doi.org/10.1016/j.conbuildmat.2021.124977 doi: 10.1016/j.conbuildmat.2021.124977
[17]	S. Komaragiri, A. Gigliotti, A. Bhasin, Calibration and extended validation of a virtual asphalt mixture compaction model using bullet physics engine, Constr. Build. Mater., 311 (2021), 125257. https://doi.org/10.1016/j.conbuildmat.2021.125257 doi: 10.1016/j.conbuildmat.2021.125257
[18]	X. Wang, S. Shen, H. Huang, Meso-scale kinematic responses of asphalt mixture in both field and laboratory compaction, Transp. Res. Rec., 2675 (2021), 1631–1642. https://doi.org/10.1177/03611981211009222 doi: 10.1177/03611981211009222
[19]	X. Wang, H. Huang, E. Tutumluer, J. S. Tingle, S. Shen, Monitoring particle movement under compaction using smartrock sensor: a case study of granular base layer compaction, Transp. Geotech., 34 (2022), 100764. https://doi.org/10.1016/j.trgeo.2022.100764 doi: 10.1016/j.trgeo.2022.100764
[20]	D. Zhang, Z. Cheng, D. Geng, S. Xie, T. Wang, Experimental and numerical analysis on mesoscale mechanical behavior of coarse aggregates in the asphalt mixture during gyratory compaction, Processes, 10 (2021), 47. https://doi.org/10.3390/pr10010047 doi: 10.3390/pr10010047
[21]	Z. Liu, L. Sun, J. Li, L. Liu, Effect of key design parameters on high temperature performance of asphalt mixtures, Constr. Build. Mater., 348 (2022), 128651. https://doi.org/10.1016/j.conbuildmat.2022.128651 doi: 10.1016/j.conbuildmat.2022.128651
[22]	H. C. Dan, D. Yang, L. H. Zhao, S. P. Wang, Z. Zhang, Meso-scale study on compaction characteristics of asphalt mixtures in Superpave gyratory compaction using SmartRock sensors, Constr. Build. Mater., 262 (2020), 120874. https://doi.org/10.1016/j.conbuildmat.2020.120874 doi: 10.1016/j.conbuildmat.2020.120874
[23]	C. Shi, G. Qian, C. Hu, H. Yu, X. Gong, C. Zhang, et al., Experimental study of aggregate skeleton shear properties for asphalt mixture under different compaction stages, Constr. Build. Mater., 404 (2023), 133123. https://doi.org/10.1016/j.conbuildmat.2023.133123 doi: 10.1016/j.conbuildmat.2023.133123
[24]	H. C. Dan, D. Yang, X. Liu, A. P. Peng, Z. Zhang, Experimental investigation on dynamic response of asphalt pavement using SmartRock sensor under vibrating compaction loading, Constr. Build. Mater., 247 (2020) 118592. https://10.1016/j.conbuildmat.2020.118592 doi: 10.1016/j.conbuildmat.2020.118592
[25]	D. Jin, L. Yin, L. Malburg, Z. You, Laboratory evaluation and field demonstration of cold in-place recycling asphalt mixture in Michigan low-volume road, Case Stud. Constr. Mater., 20 (2024), e02923. https://doi.org/10.1016/j.cscm.2024.e02923 doi: 10.1016/j.cscm.2024.e02923
[26]	A. Sha, X. Ren, J. Li, W. Jiang, M. Jia, Densification behavior of asphalt mixture and its relation with particle dynamic responses during gyratory compaction, Constr. Build. Mater., 377 (2023), 131138. https://doi.org/10.1016/j.conbuildmat.2023.131138 doi: 10.1016/j.conbuildmat.2023.131138
[27]	X. Wang, S. Shen, H. Huang, Z. Zhang, Towards smart compaction: Particle movement characteristics from laboratory to the field, Constr. Build. Mater., 218 (2019), 323–332. https://10.1016/j.conbuildmat.2019.05.122 doi: 10.1016/j.conbuildmat.2019.05.122
[28]	Z. Cheng, D. Zhang, S. Xie, P. A. Polaczyk, T. Wang, SmartRock-based research on gyratory locking point for stone mastic asphalt mixture, Buildings, 12 (2022), 97. https://doi.org/10.3390/buildings12020097 doi: 10.3390/buildings12020097
[29]	X. Zhao, D. Niu, Y. Niu, B. Hu, X. Chen, P. Liu, Effect of compaction parameter on aggregate particle migration and compaction mechanism using 2D image analysis, Constr. Build. Mater., 382 (2023), 131298. https://doi.org/10.1016/j.conbuildmat.2023.131298 doi: 10.1016/j.conbuildmat.2023.131298
[30]	X. Cai, K. Wu, W. Huang, Study on the optimal compaction effort of asphalt mixture based on the distribution of contact points of coarse aggregates, Road Mater. Pavement Des., 22 (2021), 1594–1615. https://doi.org/10.1080/14680629.2019.1710238 doi: 10.1080/14680629.2019.1710238
[31]	D. Jin, D. Ge, J. Wang, L. Malburg, Z. You, Reconstruction of asphalt pavements with crumb rubber modified asphalt mixture in cold region: Material characterization, construction, and performance, Materials, 16 (2023). https://doi.org/10.3390/ma16051874 doi: 10.3390/ma16051874
[32]	H. Yu, C. Zhang, G. Qian, J. Ge, X. Zhu, D. Yao, et al., Characterization and evaluation of coarse aggregate wearing morphology on mechanical properties of asphalt mixture, Constr. Build. Mater., 388 (2023), 131299. https://doi.org/10.1016/j.conbuildmat.2023.131299 doi: 10.1016/j.conbuildmat.2023.131299
[33]	D. Jin, T. K. Meyer, S. Chen, K. A. Boateng, J. M. Pearce, Z. You, Evaluation of lab performance of stamp sand and acrylonitrile styrene acrylate waste composites without asphalt as road surface materials, Constr. Build. Mater., 338 (2022), 127569. https://doi.org/10.1016/j.conbuildmat.2022.127569 doi: 10.1016/j.conbuildmat.2022.127569
[34]	C. Y. Ribas, L. P. Thives, Evaluation of effect of compaction method on the macrostructure of asphalt mixtures through digital image processing under Brazilian conditions, Constr. Build. Mater., 228 (2019), 116821. https://doi.org/10.1016/j.conbuildmat.2019.116821 doi: 10.1016/j.conbuildmat.2019.116821
[35]	C. Wang, M. Moharekpour, Q. Liu, Z. Zhang, P. Liu, M. Oeser, Investigation on asphalt-screed interaction during pre-compaction: Improving paving effect via numerical simulation, Constr. Build. Mater., 289 (2021), 123164. https://doi.org/10.1016/j.conbuildmat.2021.123164 doi: 10.1016/j.conbuildmat.2021.123164
[36]	Y. Li, Y. Yao, X. Shi, L. Zhang, G. Li, S. Pei, Study on vacuum compaction of asphalt mixture and its compaction performance, in IOP Conference Series: Earth and Environmental Science, 455 (2020), 012091. https://10.1088/1755-1315/455/1/012091
[37]	M. Hu, W. Jia, Z. Liu, J. Zhang, Y. Yao, Z. Shen, Experimental study on the characteristics of air voids of asphalt mixture under vacuum compaction, in IOP Conference Series: Earth and Environmental Science, 719 (2021), 032069. https://10.1088/1755-1315/719/3/032069
[38]	D. Jin, K. A. Boateng, D. Ge, T. Che, L. Yin, W. Harrall, et al., A case study of the comparison between rubberized and polymer modified asphalt on heavy traffic pavement in wet and freeze environment, Case Stud. Constr. Mater., 18 (2023), e01847. https://doi.org/10.1016/j.cscm.2023.e01847 doi: 10.1016/j.cscm.2023.e01847
[39]	G. Qian, Z. He, H. Yu, X. Gong, J. Sun, Research on the affecting factors and characteristic of asphalt mixture temperature field during compaction, Constr. Build. Mater., 257 (2020), 119509. https://doi.org/10.1016/j.conbuildmat.2020.119509 doi: 10.1016/j.conbuildmat.2020.119509
[40]	L. Chu, B. Zhu, T. Fwa, Prediction of temperature cooling trend of asphalt mixtures, in IOP Conference Series: Materials Science and Engineering, (2021), 012030. https://doi.org/10.1088/1757-899X/1075/1/012030
[41]	S. Maruyama, S. Moriya, Newton's Law of Cooling: Follow up and exploration, Int. J. Heat Mass Transf., 164 (2021), 120544. https://doi.org/10.1016/j.ijheatmasstransfer.2020.120544 doi: 10.1016/j.ijheatmasstransfer.2020.120544
[42]	H. Lodewikus, Compaction of Asphalt Road Pavements: Using Finite Elements and Critical State Theory, Ph.D thesis, University of Twente, Enschede, 2004.
[43]	X. Qiu, J. Xu, W. Xu, S. Xiao, F. Wang, J. Yuan, Characterization of fatigue damage mechanism of asphalt mixtures with acoustic emission, Constr. Build. Mater., 240 (2020), 117961. https://doi.org/10.1016/j.conbuildmat.2019.117961 doi: 10.1016/j.conbuildmat.2019.117961
[44]	Z. Cheng, X. Jia, H. Jiang, W. Hu, B. Huang, Quantification of impact compaction locking point for asphalt mixture, Constr. Build. Mater., 302 (2021), 124410. https://doi.org/10.1016/j.conbuildmat.2021.124410 doi: 10.1016/j.conbuildmat.2021.124410
[45]	X. Zhu, G. Qian, H. Yu, D. Yao, C. Shi, C. Zhang, Evaluation of coarse aggregate movement and contact unbalanced force during asphalt mixture compaction process based on discrete element method, Constr. Build. Mater., 328 (2022), 127004. https://doi.org/10.1016/j.conbuildmat.2022.127004 doi: 10.1016/j.conbuildmat.2022.127004
[46]	Y. Li, W. Jiang, J. Shan, P. Li, R. Lu, B. Lou, Characteristics of void distribution and aggregate degradation of asphalt mixture specimens compacted using field and laboratory methods, Constr. Build. Mater., 270 (2021), 121488. https://doi.org/10.1016/j.conbuildmat.2020.121488 doi: 10.1016/j.conbuildmat.2020.121488

This article has been cited by:

1.	Hafiz Muhammad Fraz, Kashif Ali, Muhammad Faisal Nadeem, Entropy measures of silicon nanotubes using degree based topological indices, 2025, 100, 0031-8949, 015202, 10.1088/1402-4896/ad94b4
2.	Pranavi Jaina, K. Anil Kumar, J. Vijayasekhar, Application of Zagreb Index Models in Predicting the Physicochemical Properties of Unsaturated Fatty Acids, 2025, 41, 22315039, 201, 10.13005/ojc/410124

Reader Comments

Your name:*

Email:*
© 2024 the Author(s), licensee AIMS Press. This is an open access article distributed under the terms of the Creative Commons Attribution License (http://creativecommons.org/licenses/by/4.0)
