Abstract

1. Introduction

The design of LED drivers is challenging in many respects ^[1]. For circuits supplied from the ac power line, the harmonic content of the ac input current is a relevant demanding aspect.

Due to the proliferation of LED lamps, the effect of low/medium power LED drivers on the electric power distribution line is a major concern ^[2,3,4]. For this reason, these systems must comply with the class C harmonic emission limits defined by the IEC61000-3-2 or other equivalent regulations. In addition, market requirements put considerable emphasis on the Total Harmonic Distortion (THD) of the ac input current: LED drivers are quite often specified to meet THD targets ^[5,6,7,8,9] that turn out to be more severe than the regulatory requirements of IEC61000-3-2 on the amplitude of the individual harmonics.

Standalone LED drivers (i.e., not embedded into a luminaire) are particularly challenging in this respect: they are often specified for a rated output current over a range of output voltages (a 2:1 range is quite typical) to power different types/lengths of LED strings. These devices must then comply with the IEC61000-3-2 and meet the THD targets even when operated at the specified minimum output voltage, which means at a fraction of their rated maximum power. To make things worse, in many cases light emission must be dimmable and/or drivers are specified to operate over a wide input voltage range (from 90 to 264 Vac). From the driver perspective, these features further extend the input voltage and the power range under consideration for THD targets.

From a different angle, LED drivers are a cost-sensitive application and quite a common way to help meet cost targets is to use the so-called constant-current primary sensing regulation (CC-PSR) technique. This configuration regulates the output dc current required for proper LED driving using only electrical quantities available on the primary side. In this way, the current sensing element, the voltage reference, the error amplifier on the secondary side and the optocoupler that transfers the error signal to the control circuit on the primary side are unnecessary. In addition to reducing the bill of materials and the required board space, this approach brings greater safety and reliability.

The high-power-factor (Hi-PF) flyback converter is perhaps the most popular topology used in low/medium power LED drivers supplied from the ac power line ^{[10,11,12,13,14,15,16,17,18,19,20,21,22,23,24,25]}. It meets the regulatory requirements on the power factor and the ac input current harmonic content, as well as those on safety isolation, with a simple and inexpensive power stage. Additionally, it lends itself to implementing CC-PSR in a relatively simple way and with good performance ^{[15,16,17,18,19,20,21,22]}.

In many cases, Hi-PF flyback converters are operated with a fixed switching frequency and in the discontinuous conduction mode (FF-DCM) ^{[10,11,12,13,14,15,16,17,18]}. As taught in ^[26], this makes the flyback converter an ideal rectifier, theoretically able to provide unity power factor and zero THD.

Hi-PF flyback converters can also be operated in the so-called QR mode, i.e., synchronizing the beginning of switching cycles to transformer demagnetization. QR operation brings a few benefits as compared to FF-DCM: lower conducted EMI emissions, safer operation under short circuit conditions, valley-switching or even true soft-switching (zero-voltage switching, ZVS). However, its standard implementation (that can be found in a large number of commercial products primarily intended for boost PFC converters) provides a sinusoidal envelope of the peaks of the primary current. This cannot achieve a very low THD of the input current, as demonstrated in ^{[19,20,21,22,23,24,25]}. In these papers, various techniques to reduce the THD are reported. Though effective, none of them can theoretically provide unity power factor and zero THD like in a FF-DCM Hi-PF flyback converter.

Relatively recently, a control method has been disclosed ^[27] that is able to provide Hi-PF QR flyback converters, whose basic circuit is shown in Figure 1, with the ability to ideally get a sinusoidal input current (unity power factor and zero THD like FF-DCM ones) and to perform CC-PSR. In this way, the combined benefits of QR operation and CC-PSR can be obtained with minimum penalty in terms of THD. The present work will take this method under consideration.

Figure 1. Principle schematic of an LED driver based on a Hi-PF QR flyback converter.

DownLoad: Full-Size Img PowerPoint

The analysis presented in the existing literature on this topic ^[27,28], however, does not fully explore the causes of distortion of the input current that are inherent in the control method. This will be the main focus of the present work, with the aim of providing some design guidelines to meet the THD design targets with less effort. Therefore, this paper is arranged as follows: in section 2 the method ^[27] is reviewed; section 3 reviews the basic assumptions underlying the method, deals with the causes of distortion of the input current not previously analyzed and provides a few design guidelines to achieve minimum THD of the input current; section 4 will show some experimental results that validate the analysis; section 5 provides the conclusions.

2. Review of the control method

The control method described in ^[27] is essentially the combination of the control scheme described in ^[28] that ideally achieves a sinusoidal input current in a Hi-PF QR flyback converter with secondary-side regulation, and that described in ^[29] that achieves CC-PSR in a traditionally controlled Hi-PF QR flyback converter. Figure 2 shows the principle schematic, Figure 3 its key waveforms.

Figure 2. CC-PSR-controlled Hi-PF QR flyback converter with sinusoidal input current; internal details of the control circuit implementing the method described in ^[27] are shown.

DownLoad: Full-Size Img PowerPoint

Figure 3. Key waveforms of the circuit in Figure 2; switching cycle time scale (left); line cycle time scale (right).

DownLoad: Full-Size Img PowerPoint

Basically, with the first method the peaks of the primary current are enveloped by a properly shaped profile so that the average input current in a switching cycle tracks exactly the profile of the rectified input voltage. With the second method, the amplitude of the peaks is controlled in a way that the average output current on a line cycle time base is kept constant.

Recalling ^[27], the rectified input current to the converter, I_in(θ), with (0 < θ < π), which is found by averaging the primary current over each switching cycle, has the following expression:

${I_{in}}\left( {\rm{ \mathsf{ θ} }} \right) = \frac{1}{2}{\mkern 1mu} {I_{pkp}}\left( \theta \right){\mkern 1mu} \frac{{{T_{ON}}\left( {\rm{ \mathsf{ θ} }} \right)}}{{T\left( {\rm{ \mathsf{ θ} }} \right)}}$

(1)

The peak envelope of the primary current I_pkp(θ) is determined by the programmed current reference Vcs_REF(θ) through the current sensing resistors R_S:

${I_{pkp}}\left( {\rm{ \mathsf{ θ} }} \right) = \frac{{Vc{s_{REF}}\left( {\rm{ \mathsf{ θ} }} \right)}}{{Rs}}$

(2)

Therefore, to achieve a sinusoidal ac input current I_ac(θ), with (0 < θ < 2π), which is the odd counterpart of I_in(θ), Vcs_REF(θ) must be of the following type:

$Vc{s_{REF}}\left( {\rm{ \mathsf{ θ} }} \right) = Vc{s_x}sin {\rm{ \mathsf{ θ} }} \, \frac{{T\left( {\rm{ \mathsf{ θ} }} \right)}}{{{T_{ON}}\left( {\rm{ \mathsf{ θ} }} \right)}}$

(3)

With reference to the control circuit in Figure 2, Vcs_REF(θ) is the output of an analog divider where its input A(θ) can be identified as the output of the shaper circuit (composed by R_t₁, C_t₁, I_ch₁ and switch driven by the timing signal Q) needed to achieve the sinusoidal input current ^[28]; its input B(θ) signal can be considered constant and is generated (through R_T, C_T, I_CH and the transformer demagnetization FW timing signal) in a proper way to achieve output current regulation ^[29].

With the same assumptions as in ^[28], applying charge balance to C_t₁ the resulting A(θ) signal is:

$A\left( {\rm{ \mathsf{ θ} }} \right)\, = {R_{t1}}\, {I_{ch1}}\left( {\rm{ \mathsf{ θ} }} \right)\, \frac{{T\left( {\rm{ \mathsf{ θ} }} \right)}}{{{T_{ON}}\left( {\rm{ \mathsf{ θ} }} \right)}} = {R_{t1}}\, {g_{m1}}\, \, {K_p}\, \, \left( {{\kern 1pt} {V_{PK}}sin {\rm{ \mathsf{ θ} }} } \right)\, \frac{{T\left( {\rm{ \mathsf{ θ} }} \right)}}{{{T_{ON}}\left( {\rm{ \mathsf{ θ} }} \right)}}$

(4)

where g_m₁ is the current-to-voltage gain of the current generator I_ch₁(θ), V_PK the peak of the rectified line voltage V_in(θ) and K_p the divider ratio R_b/(R_a + R_b). Applying charge balance to C_T and denoting with G_M the current-to-voltage gain of the current generator I_CH(θ), it is possible to find:

$B\left( {\rm{ \mathsf{ θ} }} \right) = {G_M}\, {R_T}\, {g_{m1}}\, {R_{t1}}\, {K_p}\, \left( {{V_{PK}}\, sin {\rm{ \mathsf{ θ} }} } \right)\, \frac{{{T_{FW}}\left( {\rm{ \mathsf{ θ} }} \right)}}{{{T_{ON}}\left( {\rm{ \mathsf{ θ} }} \right)}}$

(5)

C_T is assumed to be large enough so that the ac component (at twice the line frequency f_L) of B(θ) is negligible with respect to its dc component B₀:

${B_0} = \overline {B\left( {\rm{ \mathsf{ θ} }} \right)} = \frac{1}{{\rm{ \mathsf{ π} }} }\, {G_M}\, {R_T}\, {g_{m1}}\, {R_{t1}}\, {K_p}\, {V_{PK}}\, \, \int\limits_0^{\rm{ \mathsf{ π} }} {sin {\rm{ \mathsf{ θ} }} \;\frac{{{T_{FW}}\left( {\rm{ \mathsf{ θ} }} \right)}}{{{T_{ON}}\left( {\rm{ \mathsf{ θ} }} \right)}}\;d{\rm{ \mathsf{ θ} }} }$

(6)

Applying the voltage-second balance to the primary winding of the flyback transformer, the on-time T_ON(θ) of the power switch M and the secondary conduction time T_FW(θ) are related by the following relationship:

$\left( {{V_{PK}}\, sin {\rm{ \mathsf{ θ} }} } \right)\, \, {T_{ON}}\left( {\rm{ \mathsf{ θ} }} \right) = \, n\, \, \left( {{V_{out}} + {V_F}} \right)\, \, {T_{FW}}\left( {\rm{ \mathsf{ θ} }} \right) = {V_R}\, {T_{FW}}\left( {\rm{ \mathsf{ θ} }} \right)$

(7)

Considering that K_v = V_PK/V_R, the ratio between the times T_FW (θ) and T_ON (θ) is:

$\frac{{{T_{FW}}\left( {\rm{ \mathsf{ θ} }} \right)}}{{{T_{ON}}\left( {\rm{ \mathsf{ θ} }} \right)}} = \, {K_v}\, sin {\rm{ \mathsf{ θ} }} \,$

(8)

The dc component B₀ of B(θ) is found by combining (8) and (6) and solving the integral:

${B_0} = \, \frac{{{G_M}\, {R_T}\, {g_{m1}}\, {R_{t1}}\, {K_p}\, {V_{PK}}\, {K_v}}}{2}$

(9)

Finally, the current reference Vcs_REF(θ), output of the divider A/B, is:

$Vc{s_{REF}}\left( {\rm{ \mathsf{ θ} }} \right) = {K_D}\, \frac{{A\left( {\rm{ \mathsf{ θ} }} \right)}}{{B\left( {\rm{ \mathsf{ θ} }} \right)}} \approx {K_D}\, \frac{{A\left( {\rm{ \mathsf{ θ} }} \right)}}{{{B_0}}} = \, \frac{{2{K_D}}}{{{G_M}\, {R_T}\, \, {K_v}\, }}\, sin {\rm{ \mathsf{ θ} }} \, \frac{{T\left( {\rm{ \mathsf{ θ} }} \right)}}{{{T_{ON}}\left( {\rm{ \mathsf{ θ} }} \right)}}\,$

(10)

where K_D is the divider gain (dimensionally a voltage).

Equation 10 has the same form as (3), with Vcs_x = 2 K_D/(G_M R_T K_v), thus the control mechanism in Figure 2 shapes the rectified input current I_in(θ) as a rectified sinusoid and, then, the ac input current I_ac(θ) as a sinusoid. It is worth noticing that this result is achieved independently from the duration T_R of the time interval following transformer demagnetization (refer to Figure 3). The only constraint is that the converter does not operate in CCM (Continuous Conduction Mode).

The peak envelope of the secondary current I_pks(θ) can be calculated considering that the secondary current is n = Np/Ns times the primary current I_pkp(θ), found by combining (10) and (2):

$\left\{ {\begin{array}{*{20}{c}} {{I_{pkp}}\left( {\rm{ \mathsf{ θ} }} \right) = \, \frac{1}{{{R_S}}}\, \, \frac{{2{K_D}}}{{{G_M}\, {R_T}\, \, {K_v}\, }}\, sin {\rm{ \mathsf{ θ} }} \, \frac{{T\left( {\rm{ \mathsf{ θ} }} \right)}}{{{T_{ON}}\left( {\rm{ \mathsf{ θ} }} \right)}}} \\ {{I_{pks}}\left( {\rm{ \mathsf{ θ} }} \right) = \, \frac{n}{{{R_S}}}\, \, \frac{{2{K_D}}}{{{G_M}\, {R_T}\, \, {K_v}\, }}\, sin {\rm{ \mathsf{ θ} }} \, \frac{{T\left( {\rm{ \mathsf{ θ} }} \right)}}{{{T_{ON}}\left( {\rm{ \mathsf{ θ} }} \right)}}} \end{array}} \right.\,$

(11)

The average value in a switching cycle of the secondary current is:

${I_o}\left( {\rm{ \mathsf{ θ} }} \right) = \frac{1}{2}\, {I_{pks}}\left( {\rm{ \mathsf{ θ} }} \right)\, \frac{{{T_{FW}}\left( {\rm{ \mathsf{ θ} }} \right)}}{{T\left( {\rm{ \mathsf{ θ} }} \right)}} = \frac{1}{{{R_S}}}\, \frac{{n\, {K_D}}}{{{G_M}\, {R_T}\, \, {K_v}\, }}\, sin {\rm{ \mathsf{ θ} }} \, \frac{{{T_{FW}}\left( {\rm{ \mathsf{ θ} }} \right)}}{{{T_{ON}}\left( {\rm{ \mathsf{ θ} }} \right)}}$

(12)

and the dc output current I_out is the average of I_o(θ) over a line half-cycle:

${I_{out}} = \overline {{I_o}\left( {\rm{ \mathsf{ θ} }} \right)} = \frac{1}{{\, {\rm{ \mathsf{ π} }} }}\, \, \int\limits_0^{\rm{ \mathsf{ π} }} {\, \frac{{n\, {K_D}}}{{{G_M}\, {R_T}\, \, Kv\, {R_S}}}\, sin {\rm{ \mathsf{ θ} }} \, \frac{{{T_{FW}}\left( {\rm{ \mathsf{ θ} }} \right)}}{{{T_{ON}}\left( {\rm{ \mathsf{ θ} }} \right)}}\, d{\rm{ \mathsf{ θ} }} }$

(13)

Finally, combining (13) and (8) and solving the integral the average output current is given by:

${I_{out}} = \frac{{n\, {K_D}}}{{2\, {G_M}\, {R_T}\, {R_S}}}$

(14)

which shows that the regulated dc output current I_out depends solely on external, user-selectable parameters (n, Rs) and on internally fixed parameters (G_M, R_T, K_D). It does not depend on the output voltage V_out, nor on the rms input voltage V_in or the switching frequency f_SW (θ) = 1/T(θ).

Therefore, the control circuit shown in Figure 2, in addition to providing ideally unity power factor and zero harmonic distortion of the ac input current (PF = 1 and THD = 0), performs CC-PSR as well, i.e., it provides a regulated output current using only quantities available on the primary side, without any dedicated circuitry on the secondary side.

It is worth noticing that also the ability to perform CC-PSR is constrained to the converter not operating in CCM.

3. Discussion of the control method

In this section the discussion will be focused on the sinusoidal shaping of the input current operated by the control method analyzed in the previous section. As highlighted in ^[27,28,29], this analysis is based on some fundamental assumptions. Specifically:

1.The converter is operated so that the power switch M is turned on in each cycle after the secondary current reaches zero, therefore in QR-mode (i.e., on the first valley of the ringing that follows secondary current zeroing) or DCM (Discontinuous Conduction Mode).

2.The line voltage is sinusoidal, the input bridge rectifier is ideal, the voltage drop across the power switch M in the ON-state is negligible and there is negligible energy accumulation on the dc side of the bridge, thus the voltage V_in(θ), sensed by the (R_a, R_b) divider and used as a 'template' for the input current shape, is a rectified sinusoid.

3.The transformer's windings are perfectly coupled (no leakage inductance), so that the energy stored in the primary winding is instantaneously transferred to the secondary winding; further, the turn-off transient of the power switch M has negligible duration. As a result, T_FW immediately follows T_ON.

In addition, achieving a sinusoidal shape of I_ac(θ) is based on the following assumptions inherent in (1) and (10) respectively:

4.During the time interval T_R elapsing from the instant when the transformer demagnetizes to the instant when the power switch M is turned on, the transformer current is constantly zero; consequently, the current in the instant when M is turned on is zero too (Zero-current switching at turn-on, ZCS).

5.the ac component (at twice the line frequency f_L) of the control voltage B(θ) is negligible with respect to its dc component B₀, like in any high-PF converter;

Assumption 1 is actually a constraint, already discussed in ^[28]: if not met, the system will not operate as expected. The other assumptions are approximations that simplify the analysis and, as such, may lead to overlooking phenomena that cause distortion of the input current. Assumptions 2, 3 and 4 actually concern the power processing mechanism of the Hi-PF QR flyback converter and their impact on the distortion of the input current will be addressed in another paper.

In this section the focus is on the causes of distortion ascribable to the control method. Some of them (switching frequency voltage ripple across the shaping capacitor C_t1, actual low-frequency shape of the reference generated across C_t1 and propagation delay on the current sense path) have been analyzed in ^[28] already and will not be treated here. The discussion in this section will concentrate on the implications of assumption 5, which is crucial for the selection of the capacitor C_T (a selection criterion is missing so far); additionally, the effects of the input offset voltage of the PWM comparator (see Figure 2) will be investigated with the aim of providing a design criterion to the IC designer.

3.1 Distortion caused by the low frequency ripple of the control voltage B(θ)

The ac component at 2f_L of the control voltage B(θ), though small as compared to its dc component B₀, is a source of distortion inherent in the control method. To evaluate its impact, it is convenient to rewrite (5) taking (8) into account and simplifying the notation:

$B\left( {\rm{ \mathsf{ θ} }} \right) = \Gamma \, {sin ^2}{\rm{ \mathsf{ θ} }} = \frac{\Gamma }{2}\left( {1 - cos 2{\rm{ \mathsf{ θ} }} } \right)$

(15)

It is easy to recognize that Γ/2 = B₀. This equation is the result of averaging over a switching cycle; in other words, it expresses the voltage that would be developed across the resistor R_T if the C_T capacitor (see Figure 2) was just large enough to make the ac component at the switching frequency negligible. However, in order for assumption 5 to be valid, C_T must be much bigger, in order to keep the ac component at 2 f_L low as well.

It is possible to think that B(θ) given by (15) is obtained by an equivalent current generator B(θ)/R_T, whose dc and ac component are both equal to Γ/2R_T = B₀/R_T. As we consider a large capacitor C_T in parallel to R_T, so that its reactance X_T at f = 2 f_L is much smaller than R_T, the dc component B₀/R_T develops the dc voltage B₀ while the ac component B₀/R_T generates an ac voltage in quadrature (lagging) whose peak amplitude B_acpk is equal to B₀ X_T/R_T:

$B\left( {\rm{ \mathsf{ θ} }} \right) = {B_0}\left( {1 - \frac{1}{{4{\rm{ \mathsf{ π} }} \, {f_L}{R_T}{C_T}}}sin 2{\rm{ \mathsf{ θ} }} } \right)$

(16)

Substituting this expression in (10) and taking (2) into account, (1) can be rewritten as:

${I_{in}}\left( {\rm{ \mathsf{ θ} }} \right) = \frac{1}{2}\frac{{Vc{s_x}}}{{Rs}}\frac{{sin {\rm{ \mathsf{ θ} }} }}{{1 - \frac{1}{{4{\rm{ \mathsf{ π} }} \, {f_L}{R_T}{C_T}}}sin 2{\rm{ \mathsf{ θ} }} }}$

(17)

I_ac(θ) is given by (17) too, simply considering θ ∈ (0, 2π).

The diagrams in Figure 4, left to right, show the shape of I_ac(θ) for increasing values of the quantity (4πf_L R_T C_T)^-1 i.e., for increasing amplitude of the low frequency ac component of B(θ) (compared to the dc value B₀). A dotted black sinusoid is shown too for reference.

Figure 4. Shape of I_ac(θ) given by (17) for different values of (4πf_L R_T C_T)^-1.

DownLoad: Full-Size Img PowerPoint

A Fourier analysis of (17) shows that there is an additional small component at the fundamental frequency and that the distortion is nearly all concentrated on the third harmonic; the higher order odd harmonics (even harmonics are zero, being the function hemisymmetrical) become negligible very quickly, as depicted in the left-hand diagram of Figure 5.

Figure 5. Harmonic contents of (17) for different values of (4πf_L R_T C_T)^-1 (left); THD of (17) and its approximation (18) as a function of (4πf_L R_T C_T)^-1 (right).

DownLoad: Full-Size Img PowerPoint

The Fourier series expansion of (17) involves both sines and cosines, so that the odd harmonics are alternately in-phase and in quadrature with the fundamental. In particular, the fundamental leads sin(θ) by few degrees and the third harmonic lags behind the fundamental by 90°.

The THD of the input current resulting from (17) is shown in the right-hand diagram of Figure 5 (red trace) along with its approximate expression (blue trace):

$THD\% = \frac{{50}}{{4{\rm{ \mathsf{ π} }} \, {f_L}{R_T}{C_T}}}$

(18)

which provides a simple and accurate relationship linking the amount of distortion generated by the low-frequency ripple on the control voltage and the capacitor C_T. In fact, the error is < 0.5% for values of (4πf_L R_T C_T)^-1 within 0.2 and < 0.13% for values of (4πf_L R_T C_T)^-1 within 0.1.

The plot on the right-hand side of Figure 5 shows also the 3^rd harmonic (grey trace), visible in the zoomed window only, which is essentially overlapped to the THD plot, reiterating the dominance of the third harmonic: it accounts for 99.5% of THD at (4πf_L R_T C_T)^-1 = 0.2 and for 99.9% of THD at (4πf_L R_T C_T)^-1 = 0.1.

Notice that (18) can be rewritten as:

$THD\% = 50\frac{{{B_{a{c_{pk}}}}}}{{{B_0}}}$

(19)

This is essentially equal to the expression of the third-harmonic distortion that can be found for multiplier-based power factor correction schemes ^[30]. This proves that using an analog divider instead of the multiplier does not bring any significant difference in terms of input current distortion as long as the peak amplitude of the ac component of B(θ), B_acpk, is sufficiently smaller than the dc component B₀. To confirm this statement from a different angle, it is possible to prove that, expanding (17) to Maclaurin series with respect to the variable (4πf_L R_T C_T)^-1, the first order term is exactly the same that is found in case of multiplier-based power factor correction schemes.

In principle, once specified the 3rd harmonic distortion budget allocated to the low-frequency ripple, either (18) or (19) enable the computation of the required C_T value. In section 4 a more practical design rule will be provided; based on that, the required C_T value can be computed with (16).

3.2. Effects of the input offset voltage of the PWM comparator

It is well-known that the input offset voltage of a comparator is the differential input voltage at which its output changes from one logic level to the other. It is most often caused by the mismatch of the transistors (either BJTs or FETs) in the input stage. These transistors should be relatively large to minimize the causes of mismatch but large transistors are slower (and more silicon consuming!) than small transistors. On the other hand, the PWM comparator (see Figure 2) must be fast to minimize the total propagation delay in the current sense path. For this reason, in commercially available control ICs the offset of the PWM comparator is the result of a trade-off.

Usually the offset is in the 10 mV range, a voltage level that in any PFC converter is found on the current sense input when the line voltage is around the zero crossings. It is therefore worth investigating its effect on the shape of the input current.

Input offset voltage is symbolically represented by a voltage source in series with either input terminal of the comparator. In our analysis it is convenient to consider this generator so that it adds up to the Vcs_REF(θ) signal, as shown in Figure 6. Notice that Vo can be either positive or negative. With this representation, the turn-off condition (2) of the power switch M can be rewritten as:

Figure 6. Symbolic representation of PWM comparator's input offset voltage.

DownLoad: Full-Size Img PowerPoint

${I_{pkp}}\left( {\rm{ \mathsf{ θ} }} \right) = \frac{{Vc{s_{REF}}\left( {\rm{ \mathsf{ θ} }} \right) + Vo}}{{Rs}}$

(20)

where Vcs_REF(θ) is still given by (3). This considering, (1) becomes:

${I_{in}}\left( {\rm{ \mathsf{ θ} }} \right) = \frac{1}{{2Rs}}\left[ {Vc{s_x}sin {\rm{ \mathsf{ θ} }} + Vo\frac{{{T_{ON}}\left( {\rm{ \mathsf{ θ} }} \right)}}{{T\left( {\rm{ \mathsf{ θ} }} \right)}}} \right]\, \,$

(21)

The contribution of the input offset voltage, expressed by the term Vo T_ON(θ)/T(θ) in (21), has a twofold effect: on the one hand it offsets (upwards or downwards, depending on the sign of Vo) the input current waveform, like with the traditional control technique, producing crossover distortion; on the other hand, since the actual offset is a function of the instantaneous line voltage (because of the term T_ON(θ)/T(θ)), the shape of the current is affected as well. The amount of distortion caused by the offset Vo depends on the ratio Vo/Vcs_x and a Fourier analysis of (21) shows that the distortion term creates a component at the fundamental frequency and odd harmonics, all in-phase (if Vo > 0) or 180° out of phase (if Vo < 0) with the fundamental component (no cosine term involved, then).

The diagrams of Figures 7 and 8 provide some exemplary quantitative results for the converter specified in Table 1, considering a positive and a negative offset respectively. The calculation method used to obtain these results is clarified in the appendix. The input offset is represented by the parameter ρ = Vo/Vcs_x-max, where Vcs_x-max is the maximum value of Vcs_x = 2 K_D /(G_M R_T K_v), i.e., the one corresponding to the minimum value of K_v, K_v-min = V_PK-min/V_R).

Figure 7. Effect of a positive input offset voltage of the PWM comparator: input current shape (upper) and its harmonic content (lower) for converter specified in Table 1 at 115 Vac (left) and 230 Vac (right).

DownLoad: Full-Size Img PowerPoint

Figure 8. Effect of a negative input offset voltage of the PWM comparator: input current shape (upper) and its harmonic content (lower) for converter specified in Table 1 at 115 Vac (left) and 230 Vac (right).

DownLoad: Full-Size Img PowerPoint

Table 1. Main characteristics of the Hi-PF QR flyback converter used as a reference.

Parameter	Symbol	Value	Unit
Line voltage range	V_acmin-V_acmax	90–264	Vac
Line frequency range	f_l	47–63	Hz
Rated output voltage (14 LED string @ 100% load)	V_out	48	V
Regulated dc output current	I_out	700	mA
Expected full-load efficiency	η	84	%
Transformer primary inductance	L_p	500	μH
Reflected voltage	V_R	120	V
Drain node total capacitance	C_DS	150	pF

| Show Table

DownLoad: CSV

Notice that in LED drivers specified to work in a certain range of output voltages V_out to power different types/lengths of LED strings, V_R is also variable, as stated by (7). Therefore, K_v is minimum at the upper end of the V_out range and maximum at the lower end of the V_out range. Notice also that in a CC-regulated converter a lower V_out (and V_R) means also a lower output (and input) power.

In both Figures 7 and 8, the diagrams on the left-hand side are relevant full load and V_ac = 115 V, those on the right-hand side are relevant to full load and V_ac = 230 V. The upper diagrams show the shape of the ac input current to the converter I_ac(θ) for two different values of ρ:ρ = 0.01 is realistic, ρ = 0.1 is exaggerated but has been considered to show more clearly the distortion caused. Currents are normalized to their peak value. A dotted black sinusoid is shown too for reference. The lower diagrams show the harmonic contents of the current waveforms in the upper diagrams.

Notice in Figure 7 that the shape of I_ac(θ) shows a little crossover distortion, highlighted by the blue circle, i.e., a sort of step change in I_ac(θ) from positive to negative and vice versa at the zero crossings of the instantaneous line voltage V_ac(θ). This is due to the positive offset that keeps the average input current larger than zero even with an extremely small V_in(θ). This distortion is essentially invisible for ρ = 0.01, quite conspicuous for ρ = 0.1 and this is confirmed by the harmonic contents of I_ac(θ) and the resulting values of THD.

In Figure 8, which refers to the case of a negative input offset voltage, the shape of I_ac(θ) shows a different type of crossover distortion, highlighted by the blue circle: a time interval around zero crossings of the instantaneous line voltage V_ac(θ) where I_ac(θ) = 0, although V_ac(θ) ≠ 0.

This type of crossover distortion, often termed dead zone, occurs when the term in brackets in (21) is negative. The physical interpretation of being I_in(θ) < 0 and I_ac(θ) = 0 around zero-crossings is that a negative I_in(θ) actually charges back the input capacitor (C_in in Figure 2) so that V_in(θ) becomes larger than V_ac(θ), the input bridge is reverse-biased and, consequently, I_ac(θ) is zero. Also in this case the distortion is negligible for ρ = 0.01 and conspicuous for ρ = 0.1. The harmonic contents and THD values are only slightly larger than in the case of positive offset, hence one could conclude that, apart from the different shape, a positive offset or a negative offset are essentially equivalent in terms of input current shape degradation.

However, there are very good reasons that make a positive offset preferable to a negative one. There are a number of phenomena related to the power processing mechanism of Hi-PF QR flyback converters, specifically those neglected by the previously mentioned simplifying assumptions 2, 3 and 4, that produce a dead zone in the ac input current I_ac(θ) like a negative offset. An additional negative offset would then exacerbate these phenomena, whereas a positive offset counteracts them and mitigates their effect.

The solutions described in ^[30], where these phenomena are described with reference to boost topology, are based on this concept.

As a conclusion, it is possible to state that as long as input offset voltage Vo is in the range of 1% of the dynamics of the current sense input, its contribution to the THD of the input current is extremely limited (well below 1%). Normally, the dynamics of the current sense input is dictated by considerations about the power dissipation on the sense resistor Rs, and the offset should be designed consequently. Conversely, if for any reasons the PWM comparator can be built with a given maximum Vo, say 10 mV, the dynamics of the current sense input should not be much lower than 1 V.

4. Experimental verifications

A prototype of an LED driver, shown in Figure 9 on the left-hand side and based on the reference Hi-PF QR flyback converter specified in Table 1, has been built and its performance evaluated on the bench. The control method reviewed in section 2 has been implemented in a test chip, shown in Figure 9 on the right-hand side, using STMicroelectronics' BCD6s (0.32 µm) technology.

Figure 9. LED driver prototype (left); control IC layout (right).

DownLoad: Full-Size Img PowerPoint

Figures 10 to 12 summarize the salient results of this evaluation.

Figure 10. Experimental results: THD of the input current vs. V_ac (left) and PF vs. V_ac(right).

DownLoad: Full-Size Img PowerPoint

Figure 11. Experimental results: LED current regulation (CC-PSR accuracy).

DownLoad: Full-Size Img PowerPoint

Figure 12. Experimental waveforms: V_in, V_out, Vcs, I_ac at 115 Vac (left-hand column) and 230 Vac (right-hand column), at full load (upper row) and half load (lower row).

DownLoad: Full-Size Img PowerPoint

Figure 10 shows the values of THD and PF achieved under different loading conditions over the full input voltage range. The THD is around 4% over the input voltage range. At 50% load (same output current, half the output voltage) it is still close to 4% at low line and increases at high line, reaching 7.3% at 230 Vac and remaining below 10% at the upper end of the operating range. The PF is greater than 0.98 over the input voltage range at 100% load; at 50% load, at low line it is nearly equal to that at 100% load, at high line it drops to about 0.97 at 230 Vac.

The plot of Figure 11 shows the output current regulation versus ac line voltage (i.e., the dc current delivered to the LED string), for different LED string voltages. The regulated output current I_out, determined by the CC-PSR mechanism, lies in a band of ±10 mA centered on the target setpoint (700 mA, therefore ±1.4%), over the ac line voltage range and from 50% to 100% load. For a fixed load, the regulation band is approximately half as much. These measurements prove the very good accuracy of the CC-PSR regulation algorithm.

The experimental waveforms in Figure 12 show a shape if I_ac(θ) that is very close to an ideal sinusoid at full load both at 115 Vac and 230 Vac. At half load and 115 Vac the waveform is still very close to a sinusoid, whereas at 230 Vac the distortion, though low, is clearly visible. Notice that at full load and 115 Vac I_ac(θ) shows spikes at the zero crossings. These are due to the low frequency operation of the converter that comes close to the resonance frequency of the EMI filter. However, the harmonic contribution of these spikes are confined in the high frequency region, typically above the 40^th harmonic considered by the regulations on harmonic current emissions (e.g., IEC61000-3-2).

Next, the dependence of the THD of I_ac(θ) on the value of the capacitor C_T was explored.

All the data and waveforms shown in Figures 10 to 12 are taken with C_T = 330 nF. In the control IC it is R_T = 120 kΩ, then (4πf_L R_T C_T)^-1 = 0.04 with f_L = 50 Hz (this line frequency has been used throughout all measurements); the value of C_T was swept in the range from 330 nF down to 22 nF, so that (4πf_L R_T C_T)^-1 changed in the range 0.04 to 0.603, and the value of THD measured at full load and different input voltages. The results are summarized in the plot of Figure 13.

Figure 13. Experimental results: THD of the input current at full load vs. C_T.

DownLoad: Full-Size Img PowerPoint

The results obtained with C_T = 150 nF, corresponding to (4πf_L R_T C_T)^-1 = 0.088, are essentially coincident with those with C_T = 330 nF, except at 90 Vac where the THD is about 1% higher.

With C_T = 100 nF, i.e., (4πf_L R_T C_T)^-1 = 0.133, THD values increase by about 1–1.5% over those with C_T = 150 nF, still remaining well below 10% over the input voltage range. Significant degradation of THD can be observed with C_T values of 47 nF, corresponding to (4πf_L R_T C_T)^-1 = 0.282, and below. The experimental waveforms in Figure 14 refer to this condition.

Figure 14. Experimental waveforms: V_in, V(C_T), Vcs, I_ac at full load, 115 Vac (left-hand column), 230 Vac (right-hand column), with C_T = 330 nF (upper row), C_T = 47 nF (lower row).

DownLoad: Full-Size Img PowerPoint

From these results it is possible to conclude that, as long as (4πf_L R_T C_T)^-1 < 0.1, the THD of I_ac(θ) does not change much with C_T (its tolerance, as well as that of R_T, has little effect, then); additionally, there is no significant benefit in going below (4πf_L R_T C_T)^-1 < 0.05; rather, since this involves larger C_T values and the larger C_T is, the slower is the response of the CC-PSR loop to line and load changes, a design target of (4πf_L R_T C_T)^-1 = 0.1 seems an educated choice.

In other words, considering (16), the system designer should target a peak amplitude of the ac ripple of B(θ), B_acpk, equal to 10% of its dc value B₀, i.e., (4πf_L R_T C_T)^-1 ≤ 0.1. Since it is R_T = 120 kΩ, the value of C_T can be easily derived. Then, THD performance and dynamic performance can be traded off against one another to find the overall optimum operation with a series of bench tests.

5. Conclusions

The control methodology proposed in ^[27] that enables Hi-PF QR flyback converters with peak current mode control to ideally draw a sinusoidal current from the input source while regulating the output current using only quantities available on the primary side of the converter has been reviewed. After explaining the operating principle, the fundamental equations describing its operation have been recalled. A noticeable characteristic of the methodology emerging from this review is its user-friendliness: only two external parts are needed to set up a converter: a capacitor (C_T) to optimize the ac input current shape, and a resistor (Rs) to set the regulated output current.

The subsequent discussion has been concentrated on the effects of some significant nonidealities that in the real-world operation adversely affect the THD of the input current that were not previously analyzed. Specifically, the effects of the low frequency ac ripple on the control voltage of the CC-PSR loop (which the selection of the tuning element C_T depends on) and of the input voltage offset of the PWM comparator have been addressed.

The result of this analysis, corroborated by the experiments carried out on a prototype of an exemplary LED driver based on a control IC that implements the methodology under discussion, can be synthesized in the following two points:

1.The IC designer should target a ratio between the input voltage offset Vo of the PWM comparator and the dynamics of the current sense signal Vcs_x-max not exceeding 1%. In most practical cases the value of Vcs_x-max is dictated by considerations on the power dissipation of the current sensing resistor Rs and the effort directed to keeping Vo within that limit. Ideally, measures should be taken to achieve an always positive Vo because this would mitigate the effects of other nonidealities present in the system.

2.The system designer should target a peak amplitude of the ac ripple in the control voltage B(θ), B_acpk, equal to 10% of its dc value B₀ as a starting point for experimental system optimization. Being the B_acpk/B₀ ratio equal to the quantity (4πf_L R_T C_T)^-1, this is done through a proper selection of the C_T capacitor. This choice typically ensures an acceptable THD level that is also little sensitive to the tolerance of C_T. The optimum value of C_T will be found experimentally trading off the THD performance against the dynamic performance in case of line/load changes.

Of course, in the design of an LED driver, there are additional design guidelines to be taken into consideration to optimize the THD of the input current throughout the operating range. As mentioned in the preliminary discussion of the control method, in addition to the nonidealities in the control there are nonidealities in the power processing mechanism of the Hi-PF QR flyback converter that cause distortion of the input current. The most significant ones are the negative current after demagnetization, the zero-current detection mechanism, the input capacitor after the bridge rectifier.

Their impact can be minimized with proper design choices, but this is the topic of a future work.

Appendixes: Calculation of PWM comparator's input offset voltage impact on THD of I_ac(θ)

Firstly, it is convenient to rewrite (21) as follows:

${I_{in}}\left( {\rm{ \mathsf{ θ} }} \right) = \frac{{Vc{s_x}}}{{2Rs}}\left[ {sin {\rm{ \mathsf{ θ} }} + \frac{{Vo}}{{Vc{s_x}}}\frac{{{T_{ON}}\left( {\rm{ \mathsf{ θ} }} \right)}}{{T\left( {\rm{ \mathsf{ θ} }} \right)}}} \right]\, \,$

(A1)

Introducing the parameter ρ = Vo/Vcs_x-max, and keeping in mind the definitions of Vcs_x, Vcs_x-max given in section 3.2, (A1) can be expressed as:

${I_{in}}\left( {\rm{ \mathsf{ θ} }} \right) = \frac{{Vc{s_x}}}{{2Rs}}\left[ {sin {\rm{ \mathsf{ θ} }} + {\rm{ \mathsf{ ρ} }} \frac{{{K_v}}}{{{K_{v - \min }}}}\frac{{{T_{ON}}\left( {\rm{ \mathsf{ θ} }} \right)}}{{T\left( {\rm{ \mathsf{ θ} }} \right)}}} \right]\, \,$

(A2)

It is now necessary to calculate the ratio T_ON(θ)/T(θ). In ^[28] one can find an approximate expression of T_ON(θ)/T(θ) that neglects the idle time T_R after transformer demagnetization and before the beginning of a new switching cycle (refer to Figure 3). Here we want to provide a more accurate expression that takes T_R into account and that is used to build the plots of Figures 7 and 8.

The basic definition of T(θ), T(θ) = T_ON(θ) + T_FW(θ) + T_R, by virtue of (8) becomes:

$T\left( {\rm{ \mathsf{ θ} }} \right) = {T_{ON}}\left( {\rm{ \mathsf{ θ} }} \right)\left( {1 + {K_v}sin {\rm{ \mathsf{ θ} }} } \right) + {T_R}$

(A3)

As demonstrated in ^[28], the quantity T_ON²(θ)/T(θ) is constant for assigned operating conditions and its value is:

$\frac{{T_{ON}^2\left( {\rm{ \mathsf{ θ} }} \right)}}{{T\left( {\rm{ \mathsf{ θ} }} \right)}} = \frac{{4{L_p}}}{{K_v^2\, V_R^2}}{P_{in}}$

(A4)

By combining (A3) and (A4) it is possible to obtain the following quadratic equation in T_ON(θ):

$T_{ON}^2\left( {\rm{ \mathsf{ θ} }} \right) - \frac{{4{L_p}{P_{in}}}}{{K_v^2\, V_R^2}}\left( {1 + {K_v}sin {\rm{ \mathsf{ θ} }} } \right)T_{ON}^{}\left( {\rm{ \mathsf{ θ} }} \right) - \frac{{4{L_p}{P_{in}}}}{{K_v^2\, V_R^2}}{T_R} = 0$

(A5)

The solution is:

${T_{ON}}\left( {\rm{ \mathsf{ θ} }} \right) = \frac{2}{{{K_v}\, {V_R}}}\left\{ {\frac{{{L_p}{P_{in}}}}{{{V_R}}}\frac{{1 + {K_v}sin {\rm{ \mathsf{ θ} }} }}{{{K_v}}} + \sqrt {{L_p}{P_{in}}\left[ {\frac{{{L_p}{P_{in}}}}{{V_R^2}}{{\left( {\frac{{1 + {K_v}sin {\rm{ \mathsf{ θ} }} }}{{{K_v}}}} \right)}^2} + {T_R}} \right]} } \right\}$

(A6)

Of course, T(θ) is obtained inserting (A6) in (A3), and the ratio T_ON(θ)/T(θ) can be readily computed using Mathcad® or other similar calculation tool. It is possible to recognize that, if in (A6) we set T_R = 0, then we find again the expressions of T_ON(θ) and T(θ) provided in ^[28].

Conflict of interest

The author declares no conflicts of interest in this paper.

References

[1]	Chen B, Ma H, Fang H, et al. (2014) An approach for state of charge estimation of li- ion battery based on thevenin equivalent circuit model. Prognostics and System Health Management Conference (PHM-2014 Hunan) 647–652.
[2]	Ng KS, Moo CS, Chen YP, et al. (2008) State-of-charge estimation for lead-acid batteries based on dynamic open-circuit voltage. Power and Energy Conference, 2008. PECon 2008. IEEE 2nd International 972–976.
[3]	Chang WY (2013) The state of charge estimating methods for battery: A review. ISRN Appl Math 2013.
[4]	Xiong R, Cao J, Yu Q, et al.(2018) Critical review on the battery state of charge estimation methods for electric vehicles. Ieee Access 6: 1832–1843.
[5]	Ren H, Zhao Y, Chen S, et al. (2019) Design and implementation of a battery management system with active charge balance based on the soc and soh online estimation. Energy 166: 908–917. doi: 10.1016/j.energy.2018.10.133
[6]	Gundogdu B, Gladwin D, Foster M, et al. (2018) A forecasting battery state of charge management strategy for frequency response in the uk system. 2018 IEEE International Conference on Industrial Technology (ICIT) 1726–1731.
[7]	Coleman M, Lee CK, Zhu C, et al. (2007) State-of-charge determination from emf voltage estimation: Using impedance, terminal voltage, and current for lead-acid and lithium-ion batteries. IEEE Trans Ind Electron 54: 2550–2557. doi: 10.1109/TIE.2007.899926
[8]	Awadallah MA, Venkatesh B (2016) Accuracy improvement of soc estimation in lithium-ion batteries. J Energy Storage 6: 95–104. doi: 10.1016/j.est.2016.03.003
[9]	Chun CY, Baek J, Seo GS, et al. (2015) Current sensor-less state-of-charge estimation algorithm for lithium-ion batteries utilizing filtered terminal voltage. J Power Sources 273: 255–263. doi: 10.1016/j.jpowsour.2014.08.121
[10]	Larsson F, Andersson P, Blomqvist P, et al. (2014) Characteristics of lithium-ion batteries during fire tests. J Power Sources 271: 414–420. doi: 10.1016/j.jpowsour.2014.08.027
[11]	Zubi G, Dufo-López R, Carvalho M, et al. (2018) The lithium-ion battery: State of the art and future perspectives Renew Sust Energy Rev 89: 292–308.
[12]	He H, Xiong R, Zhang X, et al. (2011) State-of-charge estimation of the lithium-ion battery using an adaptive extended kalman filter based on an improved thevenin model.IEEE Trans Veh Technol 60: 1461–1469. doi: 10.1109/TVT.2011.2132812
[13]	Sarasua AE, Molina MG, Mercado PE (2013) Dynamic modelling of advanced battery energy storage system for grid-tied ac microgrid applications. Energy Storage: Technol Appl.
[14]	Moura SJ, Argomedo FB, Klein R, et al. (2017) Battery state estimation for a single particle model with electrolyte dynamics. IEEE Trans Control Syst Technol 25: 453–468. doi: 10.1109/TCST.2016.2571663
[15]	Moura SJ, Krstic M, Chaturvedi NA (2012) Adaptive pde observer for battery soc/soh estimation. ASME 2012 5th Annual Dynamic Systems and Control Conference joint with the JSME 2012 11th Motion and Vibration Conference 101–110.
[16]	Tsang K, Chan W, Wong Y, et al. (2010) Lithium-ion battery models for computer simulation. 2010 IEEE International Conference on Automation and Logistics 98–102.
[17]	Chen M, Rincon-Mora GA (2006) Accurate electrical battery model capable of predicting runtime and iv performance IEEE Trans Energy Convers 21: 504–511.
[18]	Dey S, Ayalew B, Pisu B (2014) Adaptive observer design for a li-ion cell based on coupled electrochemical-thermal model. ASME 2014 Dynamic Systems and Control Conference V002T23A001–V002T23A001.
[19]	Satadru D, Beshah A, Pierluigi P(2015) Nonlinear robust observers for state-of-charge estimation of lithium-ion cells based on a reduced electrochemical model. IEEE Trans Control Syst Technol 23: 1935–1942.
[20]	Plett GL (2004) Extended kalman filtering for battery management systems of lipb-based hev battery packs: Part 3. state and parameter estimation. J Power sources 134: 277–292. doi: 10.1016/j.jpowsour.2004.02.033
[21]	Zhang L, Peng H, Ning Z, et al. (2017)Comparative research on rc equivalent circuit models for lithium-ion batteries of electric vehicles. Appl Sci 7: 1002.
[22]	Van den Bossche P, Omar N, Al Sakka M, et al. (2014) The challenge of phev battery design and the opportunities of electrothermal modeling. Lithium-Ion Batteries 2014: 249–271.
[23]	Rivera-Barrera JP, Muñoz-Galeano N, Sarmiento-Maldonado HO (2017) Soc estimation for lithium-ion batteries: review and future challenges. Electronics 6: 102. doi: 10.3390/electronics6040102
[24]	Xie B, Liu Y, Ji Y, et al. (2018) Two-stage battery energy storage system (bess) in ac microgrids with balanced state-of-charge and guaranteed small-signal stability. Energies 11: 322. doi: 10.3390/en11020322
[25]	Tang X, Liu B, Gao F (2017) State of charge estimation of lifepo4 battery based on a gain-classifier observer. Energy Procedia 105: 2071–2076. doi: 10.1016/j.egypro.2017.03.585
[26]	Hussein AA (2014) Kalman filters versus neural networks in battery state-of-charge estimation: A comparative study. Int J Mod Nonlinear Theory Appl 3: 199. doi: 10.4236/ijmnta.2014.35022
[27]	Barai A, Widanage WD, Marco J, et al. (2015) A study of the open circuit voltage characterization technique and hysteresis assessment of lithium-ion cells. J Power Sources 295: 99–107. doi: 10.1016/j.jpowsour.2015.06.140
[28]	Xiong R, Yu Q, Wang LY (2017) Open circuit voltage and state of charge online estimation for lithium ion batteries. Energy Procedia 142: 1902–1907. doi: 10.1016/j.egypro.2017.12.388
[29]	Lee S, Kim J, Lee J, et al. (2008) State-of-charge and capacity estimation of lithium- ion battery using a new open-circuit voltage versus state-of-charge. J power sources 185: 1367–1373. doi: 10.1016/j.jpowsour.2008.08.103
[30]	Meng J, Luo G, Ricco M, et al. (2018) Overview of lithium-ion battery modeling methods for state-of-charge estimation in electrical vehicles. Appl Sci 8: 659. doi: 10.3390/app8050659
[31]	Tan Y, Mao J, Tseng K (2011) Modelling of battery temperature effect on electrical characteristics of li-ion battery in hybrid electric vehicle. 2011 IEEE Ninth International Conference on Power Electronics and Drive Systems 637–642.
[32]	Cheng Z, Wang L, Liu J, et al. (2016) Estimation of state of charge of lithium-ion battery based on photovoltaic generation energy storage system. Tehnički vjesnik 23: 695–700.
[33]	Weng C, Sun J, Peng F (2013) An open-circuit-voltage model of lithium-ion batteries for effective incremental capacity analysis. ASME 2013 dynamic systems and controlconference. 2013: V001T05A002–V001T05A002.
[34]	Charkhgard M, Farrokhi M (2010) State-of-charge estimation for lithium-ion batteries using neural networks and ekf. IEEE Trans Ind electron 57: 4178–4187. doi: 10.1109/TIE.2010.2043035
[35]	Ma Y, Zhou X, Li B, et al. (2016) Fractional modeling and soc estimation of lithium-ion battery. IEEE/CAA Journal of Auto Sin 3: 281–287. doi: 10.1109/JAS.2016.7508803
[36]	Ng KS, Moo CS, Chen YP, et al. (2009) Enhanced coulomb counting method for estimating state-of-charge and state-of-health of lithium-ion batteries. Appl energy 86: 1506–1511. doi: 10.1016/j.apenergy.2008.11.021
[37]	Lipu MH, Hannan MA, Hussain A, et al. (2018) State of charge estimation for lithium-ion battery using recurrent narx neural network model based lighting search algorithm. IEEE Access 2018.
[38]	Hansen T, Wang CJ (2005) Support vector based battery state of charge estimator. J Power Sources 141: 351–358. doi: 10.1016/j.jpowsour.2004.09.020
[39]	Chang MH, Huang HP, Chang SW (2013) A new state of charge estimation method for lifepo4 battery packs used in robots. Energies 6: 2007–2030. doi: 10.3390/en6042007
[40]	Tudoroiu RE, Zaheeruddin M, Radu SM, et al. (2018) Real-time implementation of an extended kalman filter and a pi observer for state estimation of rechargeable li-ion batteries in hybrid electric vehicle applications-a case study. Batteries 4: 19. doi: 10.3390/batteries4020019
[41]	Linghu J, Kang L, Liu M, et al. (2018) State of charge estimation for ternary battery in electric vehicles using spherical simplex-radial cubature kalman filter. 2018 International Conference on Power System Technology 1586–1592.
[42]	Wu TH, Moo CS (2017) State-of-charge estimation with state-of-health calibration for lithium-ion batteries. Energies 10: 987. doi: 10.3390/en10070987
[43]	Li Y, Zou C, Berecibar M, et al. (2018) Random forest regression for online capacity estimation of lithium-ion batteries. Appl Energy 23: 197–210.
[44]	Yan Q, Wang Y (2017) Predicting for power battery soc based on neural network. Control Conference (CCC), 2017 36th Chinese 4140–4143.
[45]	He W, Williard N, Chen C, et al. (2014) State of charge estimation for li-ion batteries using neural network modeling and unscented kalman filter-based error cancellation. Int J Electr Power Energy Syst 62: 783–791. doi: 10.1016/j.ijepes.2014.04.059
[46]	Yu Z, Huai R, Xiao L (2015) State-of-charge estimation for lithium-ion batteries using a kalman filter based on local linearization. Energies 8: 7854–7873. doi: 10.3390/en8087854
[47]	Lipu MH, Hussain A, Saad M, et al. (2018) Improved recurrent narx neural network model for state of charge estimation of lithium-ion battery using pso algorithm. 2018 IEEE Symposium on Computer Applications & Industrial Electronics 354–359.
[48]	Lv J, Yuan H, Lv Y (2012) Battery state-of-charge estimation based on fuzzy neural network and improved particle swarm optimization algorithm. 2012 Second International Conference on Instrumentation, Measurement, Computer, Communication and Control 22–27.
[49]	Yu DX, Gao YX(2013) Soc estimation of lithium-ion battery based on kalman filter algorithm. Appl Mech Mater 347: 1852–1855.
[50]	Tingting D, Jun L, Fuquan Z, et al. (2011) Analysis on the influence of measurement error on state of charge estimation of lifepo4 power battery. 2011 International Conference on Materials for Renewable Energy Environment 1: 644–649.
[51]	He Z, Gao M, Wang C, et al. (2013) Adaptive state of charge estimation for li-ion batteries based on an unscented kalman filter with an enhanced battery model. Energies 6: 4134– 4151. doi: 10.3390/en6084134
[52]	Di¸ s¸ ci FN, El-Kahlout Y, Balık¸ cı A (2017) Li-ion battery modeling and soc estimation using extended kalman filter. 2017 10th International Conference on Electrical and Electronics Engineering 166–169.
[53]	Huria T, Ceraolo M, Gazzarri J, et al. (2012) High fidelity electrical model with thermal dependence for characterization and simulation of high power lithium battery cells. 2012 IEEE International Electric Vehicle Conference 1–8.
[54]	Huria T, Ceraolo M, Gazzarri J, et al. (2013) Simplified extended kalman filter observer for soc estimation of commercial power-oriented lfp lithium battery cells. SAE Technical Paper, Tech. Rep., 2013.
[55]	Plett GL (2003) Advances in ekf soc estimation for lipb hev battery packs. Consultant to Compact Power, Inc.
[56]	Lu J, Chen Z, Yang Y, et al. (2018) Online estimation of state of power for lithium-ion batteries in electric vehicles using genetic algorithm. IEEE Access 6: 868–880.
[57]	He W, Williard N, Chen C, et al. (2013) State of charge estimation for electric vehicle batteries using unscented kalman filtering. Microelectron Reliab 53: 840–847. doi: 10.1016/j.microrel.2012.11.010
[58]	Ma Y, Duan P, Sun Y, et al. (2018) Equalization of lithium-ion battery pack based on fuzzy logic control in electric vehicle. IEEE Trans Ind Electron 65: 6762–6771. doi: 10.1109/TIE.2018.2795578
[59]	Gan L, Yang F, Shi Y, et al. (2017) Lithium-ion battery state of function estimation based on fuzzy logic algorithm with associated variables. IOP Conference Series: Earth and Environmental Science 94: 012133. doi: 10.1088/1755-1315/94/1/012133
[60]	Wu T, Wang M, Xiao Q, et al. (2012) The soc estimation of power li-ion battery based on anfis model. Smart Grid Renewable Energy 3: 51. doi: 10.4236/sgre.2012.31007
[61]	Singh P, Reisner D (2002) Fuzzy logic-based state-of-health determination of lead acid batteries. 24th Annual International Telecommunications Energy Conference 2002: 583– 590.
[62]	Singh P, Fennie C, Reisner D (2004) Fuzzy logic modelling of state-of-charge and available capacity of nickel/metal hydride batteries. J Power Sources 136: 322–333. doi: 10.1016/j.jpowsour.2004.03.035
[63]	Salkind AJ, Fennie C, Singh P, et al. (1999) Determination of state-of-charge and state-of- health of batteries by fuzzy logic methodology. J Power sources 80: 293–300. doi: 10.1016/S0378-7753(99)00079-8
[64]	Anton JA, Nieto PG, Viejo CB, et al. (2013) Support vector machines used to estimate the battery state of charge. IEEE Trans. Power Electron 28: 5919–5926. doi: 10.1109/TPEL.2013.2243918
[65]	Guo GF, Shui L, Wu XL, et al. (2014) Soc estimation for li-ion battery using svm based on particle swarm optimization. Adv Mater Res 1051: 1004–1008. doi: 10.4028/www.scientific.net/AMR.1051.1004
[66]	Pattipati B, Sankavaram C, Pattipati K (2011) System identification and estimation framework for pivotal automotive battery management system characteristics. IEEE Trans Syst Man Cybern Part C Appl Rev 41: 869–884. doi: 10.1109/TSMCC.2010.2089979
[67]	de Matos JG, e Silva FS, Ribeiro LAdS (2015) Power control in ac isolated microgrids with renewable energy sources and energy storage systems. IEEE Trans Ind Electron 62: 3490–3498. doi: 10.1109/TED.2015.2439958
[68]	Jun B, Wang YX, Zhao XM (2017) State of charge estimation for electric vehicle batteries based on a particle filter algorithm. DEStech Trans Compu Sci Eng.
[69]	Li B, Peng K, Li G (2018) State-of-charge estimation for lithium-ion battery using the gauss-hermite particle filter technique. J Renewable Sustainable Energy 10: 014105. doi: 10.1063/1.5020028
[70]	Bi J, Gao H, Wang Y, et al. (2017) Estimation of state-of-charge of li-ion batteries in ev using the genetic particle filter. IOP Conference Series: Earth and Environmental Science 81: 012183. doi: 10.1088/1755-1315/81/1/012183
[71]	Xia B, Sun Z, Zhang R, et al. (2017) A cubature particle filter algorithm to estimate the state of the charge of lithium-ion batteries based on a second-order equivalent circuit model. Energies 10: 457. doi: 10.3390/en10040457
[72]	Jiani D, Youyi W, Changyun W (2013) Li-ion battery soc estimation using particle filter based on an equivalent circuit model. 2013 10th IEEE International Conference on Control and Automation (ICCA) 2013: 580–585.
[73]	Xia B, Sun Z, Zhang R, et al. (2017) A comparative study of three improved algorithms based on particle filter algorithms in soc estimation of lithium ion batteries. Energies 10: 1149. doi: 10.3390/en10081149
[74]	Lipu MH, Hannan M, Hussain A, et al. (2018) A review of state of health and remaining useful life estimation methods for lithium-ion battery in electric vehicles: Challenges and recommendations. J Cleaner Prod 2018.
[75]	Deng Y, Hu Y, Cao Y (2014) An improved algorithm of soc testing based on open- circuit voltage-ampere hour method. International Conference on Life System Modeling and Simulation and International Conference on Intelligent Computing for Sustainable Energy and Environment 258–267.
[76]	Murnane M, Ghazel A (2017) A closer look at state of charge (soc) and state of health (soh) estimation techniques for batteries. Available from: http://www. analog. com/media/en/technical-documentation/technicalarticles/A-Closer-Look-at-State- Of-Charge-and-State-Health-Estimation-Techniques-.... pdf.
[77]	Leksono E, Haq IN, Iqbal M, et al. (2013) State of charge (soc) estimation on lifepo4 battery module using coulomb counting methods with modified peukert. 2013 Joint International Conference on Rural Information Communication Technology and Electric- Vehicle Technology (rICT & ICeV-T) 2013.
[78]	Jeong YM, Cho YK, Ahn JH, et al. (2014) Enhanced coulomb counting method with adaptive soc reset time for estimating ocv. 2014 IEEE Energy Conversion Congress and Exposition 1313–1318.
[79]	Wu J, Zhang C, Chen Z (2016) An online method for lithium-ion battery remaining useful life estimation using importance sampling and neural networks. Appl energy 173: 134–140. doi: 10.1016/j.apenergy.2016.04.057
[80]	Liu F, Liu T, Fu Y (2015) An improved soc estimation algorithm based on artificial neural network. 2015 8th International Symposium on Computational Intelligence and Design(ISCID) 2: 152–155.
[81]	Wang L, Savvaris A, Tsourdos A (2018) Online battery pack state of charge estimation via ekf-fuzzy logic joint method. 2018 5th International Conference on Control, Decision and Information Technologies 899–904.
[82]	Zenati A, Desprez P, Razik H, et al. (2012) A methodology to assess the state of health of lithium-ion batteries based on the battery's parameters and a fuzzy logic system. 2012 IEEE International Electric Vehicle Conference (IEVC). 2012: 1–6.
[83]	Khayat N, Karami N (2016) Adaptive techniques used for lifetime estimation of lithium- ion batteries. 2016 Third International Conference on Electrical, Electronics, Computer Engineering and their Applications (EECEA). 2016: 98–103.
[84]	Zhang N, Liu K (2011) The prediction of soc based on multiple dimensioned support vector machine. 2011 Second International Conference on Mechanic Automation and Control Engineering (MACE). 2011: 1786–1788.
[85]	Zhao Q, Qin X, Zhao H, et al. (2018) A novel prediction method based on the support vector regression for the remaining useful life of lithium-ion batteries. Microelectron Reliab 85: 99–108. doi: 10.1016/j.microrel.2018.04.007
[86]	Deng Z, Yang L, Cai Y, et al. (2017) Maximum available capacity and energy estimation based on support vector machine regression for lithium-ion battery. Energy Procedia 107: 68–75. doi: 10.1016/j.egypro.2016.12.131
[87]	Rahul K, Ramprabhakar J, Shankar S (2017) Comparative study on modeling and estimation of state of charge in battery. 2017 International Conference On Smart Technologies For Smart Nation (SmartTechCon). 2017: 1610–1615.
[88]	Xing Y, He W, Pecht M, et al. (2014) State of charge estimation of lithium-ion batteries using the open-circuit voltage at various ambient temperatures. Appl Energy 113: 106–115. doi: 10.1016/j.apenergy.2013.07.008
[89]	Yang D, Liu J, Wang Y, et al. (2014) State-of-charge estimation using a self-adaptive noise extended kalman filter for lithium batteries. 2014 IEEE PES Asia-Pacific Power and Energy Engineering Conference (APPEEC). 2014: 1–5.
[90]	Liu Z, Wang Y, Du J, et al. (2012) Rbf network-aided adaptive unscented kalman filter for lithium-ion battery soc estimation in electric vehicles. 2012 7th IEEE Conference on Industrial Electronics and Applications (ICIEA). 2012: 1673–1677.
[91]	Yang Y, Cui N, Wang C,et al. (2017) Soc estimation of lithium-ion battery based on new adaptive fading extended kalman filter. Chinese Automation Congress (CAC). 2017: 5630– 5634.
[92]	Sangwan V, Kumar R, Rathore AK (2017) State-of-charge estimation for li-ion battery using extended kalman filter (ekf) and central difference kalman filter (cdkf). 2017 IEEE Industry Applications Society Annual Meeting 2017: 1–6.
[93]	Zhang S, Sun H, Lyu C (2018) A method of soc estimation for power li-ion batteries based on equivalent circuit model and extended kalman filter. 2018 13th IEEE Conference on Industrial Electronics and Applications (ICIEA) 2018: 2683–2687.
[94]	Topan PA, Ramadan MN, Fathoni G, et al. (2016) State of charge (soc) and state of health (soh) estimation on lithium polymer battery via kalman filter. International Conference on Science and Technology-Computer (ICST) 2016: 93–96.
[95]	Jiang C, Taylor A, Duan C, et al. (2013) Extended kalman filter based battery state of charge (soc) estimation for electric vehicles. 2013 IEEE Transportation Electrification Conference and Expo (ITEC) 2013: 1–5.
[96]	Farrokhabadi M, König S, Cañizares CA, et al. (2018) Battery energy storage system models for microgrid stability analysis and dynamic simulation. IEEE Trans Power Syst 33: 2301– 2312. doi: 10.1109/TPWRS.2017.2740163
[97]	Thale SS, Wandhare RG, Agarwal V (2015) A novel reconfigurable microgrid architecture with renewable energy sources and storage. IEEE Trans Ind Appl 51: 1805–1816. doi: 10.1109/TIA.2014.2350083
[98]	Weng C, Sun J, Peng H (2014) A unified open-circuit-voltage model of lithium-ion batteries for state-of-charge estimation and state-of-health monitoring. J power Sources 258: 228– 237. doi: 10.1016/j.jpowsour.2014.02.026
[99]	Zhao S, Duncan SR, Howey DA (2017) Observability analysis and state estimation of lithium-ion batteries in the presence of sensor biases. IEEE Trans Control Syst Technol 25: 326–333. doi: 10.1109/TCST.2016.2542115
[100]	Samba A (2015) Battery electrical vehicles-analysis of thermal modelling and thermal management. LUSAC (Laboratoire Universitaire des Sciences Appliquées de Cherbourg), Université de caen Basse Normandie; MOBI (the Mobility, Logistics and Automotive Technology Research Centre), Vrije Universiteit Brussel.
[101]	Tang X, Gao F, Zou C, et al. (2019) Load-responsive model switching estimation for state of charge of lithium-ion batteries. Appl Energy 238: 423–434. doi: 10.1016/j.apenergy.2019.01.057
[102]	Zou C, Manzie C, Neˇ si´ c D, et al. (2016) Multi-time-scale observer design for state-of-charge and state-of-health of a lithium-ion battery. J Power Sources 335: 121–130. doi: 10.1016/j.jpowsour.2016.10.040
[103]	Baghdadi I, Briat O, Eddahech A, et al. (2015) Electro-thermal model of lithium-ion batteries for electrified vehicles applications. 2015 IEEE 24th International Symposium on Industrial Electronics (ISIE). 2015: 1248–1252.
[104]	Pesaran AA (2002) Battery thermal models for hybrid vehicle simulations. J power sources 110: 377–382. doi: 10.1016/S0378-7753(02)00200-8
[105]	Forgez C, Do DV, Friedrich G, et al. (2010) Thermal modeling of a cylindrical lifepo4/graphite lithium-ion battery. J Power Sources 195: 2961–2968. doi: 10.1016/j.jpowsour.2009.10.105
[106]	Gao Z, Chin CS, Woo WL, et al. (2017) Integrated equivalent circuit and thermal model for simulation of temperature-dependent lifepo4 battery in actual embedded application. Energies 10: 85. doi: 10.3390/en10010085
[107]	Peng S, Chen C, Shi H, et al. (2017) State of charge estimation of battery energy storage systems based on adaptive unscented kalman filter with a noise statistics estimator. IEEE Access 5: 202–212.
[108]	Zhou Y, Li X (2015) Overview of lithium-ion battery soc estimation. 2015 IEEE International Conference on Information and Automation 2015: 2454–2459.
[109]	Fayazi A, Arabloo M, Shokrollahi A, et al. (2013) State-of-the-art least square support vector machine application for accurate determination of natural gas viscosity. Ind Eng Chem Res 53: 945–958.
[110]	Xu J, Li S, Cao B (2017) A novel current disturbance estimation method for battery management systems in electric vehicle. Energy Procedia 105: 2837–2842. doi: 10.1016/j.egypro.2017.03.621
[111]	Ciortea F, Rusu C, Nemes M, et al. (2017) Extended kalman filter for state-of-charge estimation in electric vehicles battery packs. Optimization of Electrical and Electronic Equipment (OPTIM) & 2017 Intl Aegean Conference on Electrical Machines and Power Electronics (ACEMP), 2017 International Conference on. 2017: 611–616.

This article has been cited by:

1.	Giuseppe Mauromicale, Santi A. Rizzo, Nunzio Salerno, Giovanni Susinni, Angelo Raciti, Filadelfo Fusillo, Agatino Palermo, Rosario Scollo, 2020, Analysis of the impact of the operating parameters on the variation of the dynamic on-state resistance of GaN power devices, 978-1-7281-4017-9, 101, 10.1109/IESES45645.2020.9210636
2.	Giuseppe Aiello, Mario Cacciato, Francesco Gennaro, Santi Agatino Rizzo, Giuseppe Scarcella, Giacomo Scelba, A Tool for Evaluating the Performance of SiC-Based Bidirectional Battery Chargers for Automotive Applications, 2020, 13, 1996-1073, 6733, 10.3390/en13246733
3.	Claudio Adragna, Giovanni Gritti, Angelo Raciti, Santi Agatino Rizzo, Giovanni Susinni, Analysis of the Input Current Distortion and Guidelines for Designing High Power Factor Quasi-Resonant Flyback LED Drivers, 2020, 13, 1996-1073, 2989, 10.3390/en13112989
4.	Giovanni Susinni, Santi Agatino Rizzo, Francesco Iannuzzo, Two Decades of Condition Monitoring Methods for Power Devices, 2021, 10, 2079-9292, 683, 10.3390/electronics10060683
5.	Salvatore Musumeci, 2021, 10.5772/intechopen.97098

Reader Comments

Your name:*

Email:*
© 2019 the Author(s), licensee AIMS Press. This is an open access article distributed under the terms of the Creative Commons Attribution License (http://creativecommons.org/licenses/by/4.0)
