A key conditional quotient filter for nonlinear, non-Gaussian, and non-Markovian systems

Yue Zeng; Yuelin Zhao; Feng Wu; Li Zhu; Yue Zeng; Yuelin Zhao; Feng Wu; Li Zhu

doi:10.3934/math.2026366

AIMS Mathematics

2026, Volume 11, Issue 4: 8879-8902. doi: 10.3934/math.2026366

Previous Article Next Article

Research article

A key conditional quotient filter for nonlinear, non-Gaussian, and non-Markovian systems

Dalian University of Technology, Dalian 116024, China

Received: 23 January 2026 Revised: 19 March 2026 Accepted: 24 March 2026 Published: 01 April 2026
MSC : 93E10

In this paper, we propose a novel efficient key conditional quotient filter (KCQF) for the estimation of state in the nonlinear system, which can be either Gaussian or non-Gaussian, and either Markovian or non-Markovian. The core idea of the proposed KCQF is that only the key measurement conditions, rather than all measurement conditions, should be used to estimate the state. Based on key measurement conditions, the quotient-form analytical integral expressions for the conditional probability density function, mean, and variance of state were derived using the principle of probability conservation, and were calculated using the Monte Carlo method, which thereby constructed the KCQF. Three numerical examples were given to demonstrate the superior estimation accuracy of KCQF, compared to ten filters. The experimental results demonstrated that the KCQF algorithm not only accurately addresses nonlinear problems with high precision but also directly handles navigation issues under time-varying noise conditions.
- estimation,
- filtering,
- nonlinear systems,
- stochastic systems,
- key conditional quotient
Citation: Yue Zeng, Yuelin Zhao, Feng Wu, Li Zhu. A key conditional quotient filter for nonlinear, non-Gaussian, and non-Markovian systems[J]. AIMS Mathematics, 2026, 11(4): 8879-8902. doi: 10.3934/math.2026366

Related Papers:

Abstract

In this paper, we propose a novel efficient key conditional quotient filter (KCQF) for the estimation of state in the nonlinear system, which can be either Gaussian or non-Gaussian, and either Markovian or non-Markovian. The core idea of the proposed KCQF is that only the key measurement conditions, rather than all measurement conditions, should be used to estimate the state. Based on key measurement conditions, the quotient-form analytical integral expressions for the conditional probability density function, mean, and variance of state were derived using the principle of probability conservation, and were calculated using the Monte Carlo method, which thereby constructed the KCQF. Three numerical examples were given to demonstrate the superior estimation accuracy of KCQF, compared to ten filters. The experimental results demonstrated that the KCQF algorithm not only accurately addresses nonlinear problems with high precision but also directly handles navigation issues under time-varying noise conditions.

References

[1]	H. Ye, W. Wu, Y. Zhang, K. Li, S. Wu, Receiving filter design for the distant sidelobe suppression of RMWFPA radar, IEEE T. Aero. Elec. Sys., 61 (2025), 13333–13347. https://doi.org/10.1109/TAES.2025.3578060 doi: 10.1109/TAES.2025.3578060
[2]	M. J. Lindenfeld, Mismatched filters for incoherent pulse compression in laser radar, IEEE T. Aero. Elec. Sys., 57 (2021), 1252–1260. https://doi.org/10.1109/TAES.2020.3038256 doi: 10.1109/TAES.2020.3038256
[3]	H. Liu, X. Sun, J. Yang, M. Xu, S. Bai, Skewed unscented Kalman filter using Gaussian sum, IEEE T. Aero. Elec. Sys., 61 (2025), 3917–3935. https://doi.org/10.1109/TAES.2024.3501237 doi: 10.1109/TAES.2024.3501237
[4]	T. Badar, S. Särkkä, Z. Zhao, A. Visala, Rao–blackwellized particle filter using noise adaptive Kalman filter for fully mixing state-space models, IEEE T. Aero. Elec. Sys., 60 (2024), 6972–6982. https://doi.org/10.1109/TAES.2024.3409644 doi: 10.1109/TAES.2024.3409644
[5]	L. Guo, S. Hu, J. Zhou, X. R. Li, Recursive nonlinear filtering via Gaussian approximation with minimized kullback–leibler divergence, IEEE T. Aero. Elec. Sys., 60 (2024), 965–979. https://doi.org/10.1109/TAES.2023.3330952 doi: 10.1109/TAES.2023.3330952
[6]	L. Zhu, Y. Zhao, F. Wu, A key condition quotient method for heat conduction conditional uncertainty propagation, Int. Commun. Heat Mass, 171 (2026), 110207. https://doi.org/10.1016/j.icheatmasstransfer.2025.110207 doi: 10.1016/j.icheatmasstransfer.2025.110207
[7]	S. Wei, S. Chen, X. Dong, Z. Peng, W. Zhang, Parametric identification of time-varying systems from free vibration using intrinsic chirp component decomposition, Acta Mech. Sin., 36 (2020), 188–205. https://doi.org/10.1007/s10409-019-00905-7 doi: 10.1007/s10409-019-00905-7
[8]	Y. Zhao, F. Wu, Key conditional quotient of random finite element model under measurement conditions, Comput. Method. Appl. M., 440 (2025), 117943. https://doi.org/10.1016/j.cma.2025.117943 doi: 10.1016/j.cma.2025.117943
[9]	R. E. Kalman, A new approach to linear filtering and prediction problems, J. Basic Eng., 82 (1960), 35–45. https://doi.org/10.1115/1.3662552 doi: 10.1115/1.3662552
[10]	X. Song, M. Zhang, W. X. Zheng, Z. Liu, Maximum correntropy kalman filter for linear discrete-time systems with intermittent observations and non-gaussian noise, IEEE T. Circuits-II, 71 (2024), 3246–3250. https://doi.org/10.1109/TCSII.2024.3357588 doi: 10.1109/TCSII.2024.3357588
[11]	A. H. Jazwinski, Introduction to filtering theory, In: Stochastic processes and filtering theory, Academic Press, (1970), 142–161. https://doi.org/10.1016/S0076-5392(09)60374-X
[12]	L. D. Avendano-Valencia, L. E. Avendano, J. M. Ferrero, G. Castellanos-Dominguez, Improvement of an extended Kalman filter power line interference suppressor for ECG signals, In: 2007 Computers in Cardiology, 2007,553–556. http://doi.org/10.1109/CIC.2007.4745545
[13]	G. Battistelli, L. Chisci, Stability of consensus extended Kalman filter for distributed state estimation, Automatica, 68 (2016), 169–178. https://doi.org/10.1016/j.automatica.2016.01.071 doi: 10.1016/j.automatica.2016.01.071
[14]	H. Hajimolahoseini, M. R. Taban, H. R. Abutalebi, Improvement of extended Kalman filter frequency tracker for nonstationary harmonic signals, In: 2008 international symposium on telecommunications, 2008,592–597. https://doi.org/10.1109/ISTEL.2008.4651370
[15]	S. J. Julier, J. K. Uhlmann, New extension of the Kalman filter to nonlinear systems, In: Proceedings Volume 3068, Signal Processing, Sensor Fusion, and Target Recognition VI, 1997. https://doi.org/10.1117/12.280797
[16]	A. Meyer Sjøberg, O. Egeland, Lie algebraic unscented Kalman filter for pose estimation, IEEE T. Automat. Contr, 67 (2022), 4300–4307. https://doi.org/10.1109/TAC.2021.3121247 doi: 10.1109/TAC.2021.3121247
[17]	S. J. Julier, The scaled unscented transformation, In: Proceedings of the 2002 American Control Conference (IEEE Cat. No. CH37301), 6 (2002), 4555–4559. https://doi.org/10.1109/ACC.2002.1025369
[18]	M. R. Morelande, B. Ristic, Reduced sigma point filtering for partially linear models, In: 2006 IEEE International Conference on Acoustics Speech and Signal Processing Proceedings, 2006. https://doi.org10.1109/ICASSP.2006.1660584
[19]	I. Arasaratnam, S. Haykin, Cubature Kalman filters, IEEE T. Automat. Contr., 54 (2009), 1254–1269. https://doi.org/10.1109/TAC.2009.2019800 doi: 10.1109/TAC.2009.2019800
[20]	N. J. Gordon, D. J. Salmond, A. F. Smith, Novel approach to nonlinear/non-Gaussian Bayesian state estimation, In: IEE Proceedings F (Radar and Signal Processing), 140 (1993), 107–113. https://doi.org/10.1049/ip-f-2.1993.0015
[21]	D. Huang, F. Wu, Y. Zhao, J. Yan, H. Zhang, Application of high-credible statistical results calculation scheme based on least squares Quasi-Monte Carlo method in multimodal stochastic problems, Comput. Method. Appl. M., 418 (2024), 116576, https://doi.org/10.1016/j.cma.2023.116576 doi: 10.1016/j.cma.2023.116576
[22]	F. Wu, Y. Zhao, K. Zhao, W. Zhong, A multi-body dynamical evolution model for generating the point set with best uniformity, Swarm Evol. Comput., 73 (2022), 101121, https://doi.org/10.1016/j.swevo.2022.101121 doi: 10.1016/j.swevo.2022.101121
[23]	R. Van Der Merwe, A. Doucet, N. De Freitas, E. Wan, The unscented particle filter, In: NIPS'00: Proceedings of the 14th International Conference on Neural Information Processing Systems, 13 (2000), 563–569.
[24]	F. Wang, J. Zhang, B. Lin, X. Li, Two stage particle filter for nonlinear Bayesian estimation, IEEE Access, 6 (2018), 13803–13809. https://doi.org/10.1109/ACCESS.2018.2808922 doi: 10.1109/ACCESS.2018.2808922
[25]	W. Wei, S. Gao, Y. Zhong, C. Gu, G. Hu, Adaptive square-root unscented particle filtering algorithm for dynamic navigation, Sensors, 18 (2018), 2337. https://doi.org/10.3390/s18072337 doi: 10.3390/s18072337
[26]	M. Bolic, P. M. Djuric, S. Hong, New resampling algorithms for particle filters, In: 2003 IEEE International Conference on Acoustics, Speech, and Signal Processing, 2003. Proceedings.(ICASSP'03)., 2003. https://doi.org/10.1109/ICASSP.2003.1202435
[27]	A. Daniyan, Y. Gong, S. Lambotharan, An improved resampling approach for particle filters in tracking, In: 2017 22nd International Conference on Digital Signal Processing (DSP), 2017. https://doi.org/10.1109/ICDSP.2017.8096095
[28]	T. Z. Lv, C. X. Zhao, H. F. Zhang, An improved fastslam algorithm based on revised genetic resampling and SR-UPF, Int. J. Autom. Comput., 15 (2018), 325–334. https://doi.org/10.1007/s11633-016-1050-y doi: 10.1007/s11633-016-1050-y
[29]	D. Lin, X. Chen, Y. Zheng, Z. Guo, Q. Zhang, S. Wang, Quaternion information filters with inaccurate measurement noise covariance: A variational Bayesian method, IEEE T. Signal Proces., 73 (2025), 1367–1378. https://doi.org/10.1109/TSP.2025.3549023 doi: 10.1109/TSP.2025.3549023
[30]	D. M. Titterington, B. Wang, Convergence properties of a general algorithm for calculating variational Bayesian estimates for a normal mixture model, Bayesian Anal., 1 (2006), 625–650. https://doi.org/10.1214/06-BA121. doi: 10.1214/06-BA121
[31]	B. Yang, H. Wang, Z. Shi, Variational Bayesian and generalized maximum-likelihood based adaptive robust nonlinear filtering framework, Signal Process., 215 (2024), 109271. https://doi.org/10.1016/j.sigpro.2023.109271 doi: 10.1016/j.sigpro.2023.109271
[32]	B. Chen, X. Liu, H. Zhao, J. C. Principe, Maximum correntropy Kalman filter, Automatica, 76 (2017), 70–77. https://doi.org/10.1016/j.automatica.2016.10.004 doi: 10.1016/j.automatica.2016.10.004
[33]	S. Peng, P. Cai, D. Lin, Y. Zheng, S. Wang, Cauchy–Gaussian maximum mixture correntropy Kalman filter with component-by-component construction, Signal Process., 234 (2025), 110008. https://doi.org/10.1016/j.sigpro.2025.110008 doi: 10.1016/j.sigpro.2025.110008
[34]	W. Yu, D. Lin, Y. Zheng, S. Wang, Extended $\text{H}\infty$ filtering in RKHS for nonlinear systems with uncertainty, IEEE T. Circuits-II, 72 (2025), 429–433. https://doi.org/10.1109/TCSII.2024.3522913 doi: 10.1109/TCSII.2024.3522913
[35]	C. H. Tseng, S. F. Lin, D. J. Jwo, Robust Huber-based cubature Kalman filter for gps navigation processing, J. Navigation, 70 (2017), 527–546. https://doi.org/10.1017/S0373463316000692 doi: 10.1017/S0373463316000692
[36]	G. Tan, T. Wang, A new result on $\text{H}\infty$ filtering criterion based on improved techniques, Circuits Syst. Signal Process, 45 (2026), 977–994. https://doi.org/10.1007/s00034-025-03305-4 doi: 10.1007/s00034-025-03305-4
[37]	J. Li, J. B. Chen, Probability density evolution method for dynamic response analysis of structures with uncertain parameters, Comput. Mech., 34 (2004), 400–409. https://doi.org/10.1007/s00466-004-0583-8 doi: 10.1007/s00466-004-0583-8
[38]	A. Rényi, Probability theory, Dover Publications, 2007.
[39]	D. Raihan, S. Chakravorty, Particle Gaussian mixture filters-I, Automatica, 98 (2018), 331–340. https://doi.org/10.1016/j.automatica.2018.07.023 doi: 10.1016/j.automatica.2018.07.023
[40]	M. Sun, M. E. Davies, I. K. Proudler, J. R. Hopgood, Adaptive Kernel Kalman filter, IEEE T. Signal Process., 71 (2023), 713–726. https://doi.org/10.1109/TSP.2023.3250829 doi: 10.1109/TSP.2023.3250829
[41]	J. S. Liu, R. Chen, Sequential Monte Carlo methods for dynamic systems, J. Am. Stat. Assoc., 93 (1998), 1032–1044. https://doi.org/10.1080/01621459.1998.10473765 doi: 10.1080/01621459.1998.10473765
[42]	G. Kitagawa, Monte Carlo filter and smoother for non-Gaussian nonlinear state space models, J. Comput. Graph. Stat, 5 (1996), 1–25. https://doi.org/10.1080/10618600.1996.10474692 doi: 10.1080/10618600.1996.10474692
[43]	F. WU, Y. ZHAO, Y. YANG, N. ZHOU, A new discrepancy for sample generation in stochastic response analyses of aerospace problems with uncertain parameters, Chinese J. Aeronaut., 37 (2024), 192–211. https://doi.org/10.1016/j.cja.2024.09.044 doi: 10.1016/j.cja.2024.09.044
[44]	C. Hide, T. Moore, M. Smith, Adaptive Kalman filtering algorithms for integrating GPS and low cost INS, Tn: Plans 2004. Position location and navigation symposium (ieee cat. no. 04ch37556), 2004. https://doi.org/10.1109/PLANS.2004.1308998
[45]	M. J. Yu, INS/GPS integration system using adaptive filter for estimating measurement noise variance, IEEE T. Aero. Elec. Sys., 48 (2012), 1786–1792. https://doi.org/10.1109/TAES.2012.6178100 doi: 10.1109/TAES.2012.6178100
[46]	Y. Huang, Y. Zhang, Z. Wu, N. Li, J. Chambers, A novel adaptive Kalman filter with inaccurate process and measurement noise covariance matrices, IEEE T. Automat. Contr., 63 (2018), 594–601. https://doi.org/10.1109/TAC.2017.2730480 doi: 10.1109/TAC.2017.2730480
[47]	C. Pan, J. Gao, Z. Li, N. Qian, F. Li, Multiple fading factors-based strong tracking variational Bayesian adaptive Kalman filter, Measurement, 176 (2021), 109139. https://doi.org/10.1016/j.measurement.2021.109139 doi: 10.1016/j.measurement.2021.109139
[48]	T. Ardeshiri, E. Özkan, U. Orguner, F. Gustafsson, Approximate Bayesian smoothing with unknown process and measurement noise covariances, IEEE Signal Proc. Let., 22 (2015), 2450–2454. https://doi.org/10.1109/LSP.2015.2490543 doi: 10.1109/LSP.2015.2490543
[49]	F. M. Tan, J. J. Zhao, Strong tracking based variational bayesian adaptive kalman filtering algorithm, Electron. Opt. Control, 27 (2020), 12–16. In Chinese. https://doi.org/10.3969/j.issn.1671-637X.2020.01.003 doi: 10.3969/j.issn.1671-637X.2020.01.003
[50]	F. Guo, D. Schlipf, P. W. Cheng, Evaluation of lidar-assisted wind turbine control under various turbulence characteristics, Wind Energy Sci., 8 (2023), 149–171. https://doi.org/10.5194/wes-8-149-2023 doi: 10.5194/wes-8-149-2023
[51]	F. Wu, L. Zhu, Y. Zhao, C. Ai, X. Wang, F. Cai, et al., Wave spectrum fitting with multiple parameters based on optimization algorithms and its application, Ocean Eng., 312 (2024), 119073. https://doi.org/10.1016/j.oceaneng.2024.119073 doi: 10.1016/j.oceaneng.2024.119073
[52]	Y. Yang, F. Wu, X. Wei, W. Hu, C. Li, S. Liang, Time-variant uncertainty modeling with limited samples: Interval process model dimension reduction construction method, Eng. Struct., 350 (2026), 121932. https://doi.org/10.1016/j.engstruct.2025.121932 doi: 10.1016/j.engstruct.2025.121932
[53]	F. Wu, Y. Zhao, W. Hu, An interval analysis method based on pdf for unconditional/conditional uncertain structural responses, Appl. Math. Model., 152 (2026), 116577. https://doi.org/10.1016/j.apm.2025.116577 doi: 10.1016/j.apm.2025.116577
