Dynamic strain gradient brittle fracture propagation: comparison with experimental evidence

Valerii Maksimov; Luca Placidi; Francisco James León Trujillo; Chiara De Santis; Anil Misra; Dmitry Timofeev; Francesco Fabbrocino; Emilio Barchiesi; Valerii Maksimov; Luca Placidi; Francisco James León Trujillo; Chiara De Santis; Anil Misra; Dmitry Timofeev; Francesco Fabbrocino; Emilio Barchiesi

doi:10.3934/nhm.2024047

Networks and Heterogeneous Media

2024, Volume 19, Issue 3: 1058-1084. doi: 10.3934/nhm.2024047

Previous Article Next Article

Research article Special Issues

Dynamic strain gradient brittle fracture propagation: comparison with experimental evidence

1.
Faculty of Engineering, International Telematic University Uninettuno, Rome, Italy
2.
International Research Center on Mathematics and Mechanics of Complex Systems (M & MoCS), Università degli Studi dell' Aquila, L' Aquila, Italy
3.
Department of architecture, design and urbanism, Università degli Studi di Sassari, Alghero, Italy
4.
Department of Civil and Environmental Engineering, Florida International University, Miami, FL, USA
5.
Faculty of Engineering, Telematic University Pegaso, Naples, Italy

Received: 15 April 2024 Revised: 25 June 2024 Accepted: 01 July 2024 Published: 30 September 2024

This paper presented a physico-mathematical model for dynamic fracture propagation in brittle materials with a purely continuum mechanics hemi-variational-based strain gradient theory. As for the quasi-static case, the simulation results, obtained by means of finite elements, revealed that strain gradient effects significantly affected the fracture propagation, leading to finite fracture thickness that was independent of the mesh size. It was also observed that nonsymmetric loading rate lead to a deviation from standard mode-Ⅰ crack propagation that cannot be revealed in the quasi-static case. The model results were compared against experimental data from fracture tests on notched specimens taken from the literature. The comparison showed good agreement between the model predictions and the experimental measurements. The presented model and simulation results can be useful in the design and optimization of structural components subjected to dynamic loading conditions.

Keywords:

Citation: Valerii Maksimov, Luca Placidi, Francisco James León Trujillo, Chiara De Santis, Anil Misra, Dmitry Timofeev, Francesco Fabbrocino, Emilio Barchiesi. Dynamic strain gradient brittle fracture propagation: comparison with experimental evidence[J]. Networks and Heterogeneous Media, 2024, 19(3): 1058-1084. doi: 10.3934/nhm.2024047

Related Papers:

[1]	Gilles Pijaudier-Cabot, David Grégoire . A review of non local continuum damage: Modelling of failure?. Networks and Heterogeneous Media, 2014, 9(4): 575-597. doi: 10.3934/nhm.2014.9.575
[2]	Manuel Friedrich, Bernd Schmidt . On a discrete-to-continuum convergence result for a two dimensional brittle material in the small displacement regime. Networks and Heterogeneous Media, 2015, 10(2): 321-342. doi: 10.3934/nhm.2015.10.321
[3]	Marco Cicalese, Antonio DeSimone, Caterina Ida Zeppieri . Discrete-to-continuum limits for strain-alignment-coupled systems: Magnetostrictive solids, ferroelectric crystals and nematic elastomers. Networks and Heterogeneous Media, 2009, 4(4): 667-708. doi: 10.3934/nhm.2009.4.667
[4]	Andrea Braides, Anneliese Defranceschi, Enrico Vitali . Variational evolution of one-dimensional Lennard-Jones systems. Networks and Heterogeneous Media, 2014, 9(2): 217-238. doi: 10.3934/nhm.2014.9.217
[5]	Anya Désilles, Hélène Frankowska . Explicit construction of solutions to the Burgers equation with discontinuous initial-boundary conditions. Networks and Heterogeneous Media, 2013, 8(3): 727-744. doi: 10.3934/nhm.2013.8.727
[6]	Hyeontae Jo, Hwijae Son, Hyung Ju Hwang, Eun Heui Kim . Deep neural network approach to forward-inverse problems. Networks and Heterogeneous Media, 2020, 15(2): 247-259. doi: 10.3934/nhm.2020011
[7]	Antonio DeSimone, Natalie Grunewald, Felix Otto . A new model for contact angle hysteresis. Networks and Heterogeneous Media, 2007, 2(2): 211-225. doi: 10.3934/nhm.2007.2.211
[8]	G. Dal Maso, Antonio DeSimone, M. G. Mora, M. Morini . Globally stable quasistatic evolution in plasticity with softening. Networks and Heterogeneous Media, 2008, 3(3): 567-614. doi: 10.3934/nhm.2008.3.567
[9]	Seung-Yeal Ha, Shi Jin, Jinwook Jung . A local sensitivity analysis for the kinetic Kuramoto equation with random inputs. Networks and Heterogeneous Media, 2019, 14(2): 317-340. doi: 10.3934/nhm.2019013
[10]	Gianni Dal Maso, Francesco Solombrino . Quasistatic evolution for Cam-Clay plasticity: The spatially homogeneous case. Networks and Heterogeneous Media, 2010, 5(1): 97-132. doi: 10.3934/nhm.2010.5.97

Abstract

1. Introduction

Fracture mechanics is a fundamental field of study in mechanical sciences. Over the years, extensive research has focused on studying fracture processes under static loading conditions, providing valuable insights into crack initiation, propagation, and structural failure. However, in many real-world scenarios, materials are subjected to dynamic loading conditions, where cracks can propagate at high speeds and exhibit unique fracture behaviors ^{[7,39,43,45,64,73,77,80]}. Understanding the mechanics of dynamic fracture is hence crucial for enhancing the safety and reliability of structural components and advancing the design of resilient materials. The mechanics underlying dynamic fractures presents many more intricacies than underlying quasi-static fracture ^{[58,59,60,61]}. Experimental studies, however, show its practical relevance^{[6,17,20,23,25,68,79,81]} and also elucidate its loading rate-dependent behavior ^{[18,24,26,27,30,40,44,70,72,78]}. More specifically, the study of dynamic fracture finds application in engineering ^[8,18,54], automotive safety ^[33], medicine ^[69], material science ^[28], and biology ^[74]. Examples of dynamic fracture events include rapid crack propagation in structural components under time-dependent loading due to, e.g., impacts, explosions, or earthquakes ^[24], fragmentation of brittle materials under high-velocity impacts, and crack propagation in geological formations due to seismic activity. The study of dynamic fracture mechanics aims to unravel the underlying mechanisms governing the initiation, propagation, and arrest of cracks under these extreme loading conditions.

This paper presents a physico-mathematical model that addresses dynamic fracture propagation in brittle materials by applying a purely hemi-variational continuum mechanics-based strain gradient theory. This paper is based on experimental analyses conducted in ^[41], which delved into the dependence of the fracture path on the loading rate. In a theoretical paper aimed at predicting mathematically the fracture path and the related branching phenomena, the same authors utilized a microplane model ^[42] in a 3D numerical simulation. In works ^[5,22,55,71], in order to describe the experimental results on dynamic fracture propagation reported in ^[41], different approaches were used like peridynamic, microplane, and phase-field damage modeling. The recent work of Nguyen et al. ^[38] gives a reformulation, in terms of sprain and spress, of a subset of micromorphic theories discussed more than half a century ago by Germain ^[21], Mindlin ^[34], and Eringen ^[16], whose micromechanical foundations for granular systems have been elaborated in a variational approach for finite deformation ^[36], geometrically nonlinear strain gradient models ^[4], and n-th order micromorphic materials ^[37]. Following this granular micromechanical approach and utilizing hemivariational methods, a group of researchers in a series of papers ^{[10,35,47,49,50,52,67]} have clearly established the physical meaning of boundary conditions associated with strain gradient theories ^{[2,3,11,12,13,14,15,62,63,66,76]}. Moreover, they have shown that for heterogeneous systems, strain gradient theories with appropriate elastic and dissipative energies can predict a multitude of phenomena, such as evolution of chirality and size of localization/fracture zone, that are oftentimes ignored or overlooked in classical approaches ^[9,19,29,31]. The strain gradient with the inertia gradient effects approach was used in ^[46,65], the treatment being purely analytical, without application of numerical methods such as the finite element method (FEM). In the papers of Rao et al. ^[56,57], strain gradient effects in the modeling of fracture mechanics have been considered with a two-scale asymptotic analysis. In this study, we employ an isotropic model to investigate the behavior of experiments presented in ^[41]. Our objective is to tune the evolution of damage based on discerning the local strain/stress state, namely, tension/compression. Specifically, we aim at mitigating, avoiding actually, its occurrence in compression. The utilization of an isotropic model accounts for uniformity of the microstructure with respect to directions.

The paper is organized as follows. In Section 2, we introduce the strain-gradient continuum model–elastic and damage components-employed to investigate numerically the propagation of dynamic fracture. In Section 3, we apply the presented model to an experimental case study that is then used for comparison with experimental data and other theoretical approaches available in the literature by solving through the weak form package of the software COMSOL Multiphysics and the weak form of its governing equations. Finally, conclusions are drawn in Section 4.

2. Formulation of the problem

2.1. Preliminary definitions

Let us consider a 2D continuum body $\mathfrak{V}\subset E^{2}$ , where the domain $E^{2}$ is the Euclidean two-dimensional space. The position of every point in the body is established through the utilization of $X$ coordinates in a frame of reference. The set of kinematic descriptors for such a model contains both the displacement field $u = u(X, t)$ and the damage field $\omega = \omega(X, t)$ . The damage state of a material point $X$ is therefore characterized, at time $t$ , by a scalar internal variable $\omega$ , which is assumed to take values within the range [0, 1]. The case $\omega = 0$ corresponds to the undamaged state, while $\omega = 1$ corresponds to complete failure. We assume the material to be not self-healing and, hence, $\omega$ is assumed to be a nondecreasing function of time. If we consider the material as a microstructured one, it becomes significant to allow the deformation energy density to vary based on the second gradient of the displacement. Thus, because of objectivity, the potential energy $U$ is assumed to be a function of the strain tensor $G$ , of its gradient $\nabla G$ , and of the damage $\omega$ , i.e., $U = U(G, \nabla G, \omega)$ . Here, $G = \frac{1}{2}\left(F^{T}F-I\right)$ , where $F = \nabla\chi$ is the deformation gradient tensor, $\chi = X+u$ is the placement function, and $F^{T}$ is the transpose of $F$ . For the small displacement approximation that is dealt with in this work, the strain tensor $G$ is assumed to be equal to $E = Sym(\nabla u)$ , the symmetric part of the displacement gradient.

2.2. The Energy functional

The energy functional $\mathcal{E}(u, \omega)$ depends on the displacement $u$ and the damage $\omega$ and is given as follows ^[53]:

$\begin{equation} \begin{split} \mathcal{E}(u, \omega) & = \int_{\mathfrak{V}}\left[U_e(G, \nabla G, \omega)+U_d(\omega)-b^{ext}\cdot u-m^{ext}:\nabla u \right]dA \\ & -\int_{\partial\mathfrak{V}}[t^{ext}\cdot u+\tau^{ext}\cdot[(\nabla u)n]]ds-\int_{\left[\partial\partial\mathfrak{V}\right]}f^{ext}\cdot u \end{split} \end{equation}$

(2.1)

where $\partial\mathfrak{B}$ are the regular parts of the boundary of $\mathfrak{B}$ , the symbol $[\partial\partial\mathfrak{B}]$ denotes the regular parts of the boundary of $\partial\mathfrak{B}$ , i.e., its wedges, and $n$ is the unit external normal. The symbols (·) and (:) indicate the scalar product between vectors or tensors, respectively. The quantities $b^{ext}$ and $m^{ext}$ are, respectively, the external body force and double force (per unit area), while the quantities $t^{ext}$ and $\tau^{ext}$ are, respectively, the external force and double force (per unit length). Finally, the quantity $f^{ext}$ is the external concentrated force which is applied on the vertices $[\partial\partial\mathfrak{B}]$ .

2.3. Variational principle

In order to get governing equations for this model, we resort to the variational principle thoroughly presented in ^{[32,48,49,51,53,75]}, where the case of one-dimensional bodies was considered. We assume that the descriptors $u(X, t)$ and $\omega(X, t)$ verify the condition

$\begin{equation} \delta\mathcal{E}(u, \omega, \dot{u}, \dot{\omega})\leq\delta\mathcal{E}(u, \omega, \nu, \beta), \qquad\forall\nu, \ \forall\beta\geq0, \end{equation}$

(2.2)

where $\nu$ and $\beta$ are compatible virtual velocities and dots represent derivation with respect to time.

2.4. Reduction from the 3D Mindlin elastic strain gradient energy to the 2D explicit form

A general form of the deformation energy density of an elastic 3D isotropic strain gradient elastic material is provided in ^[34]. In our case, we have

$\begin{equation} U_{e}(G, \nabla G, \omega) = \mathbb{H}(-TrG+\gamma)(U^I_e+U^{II}_e)+\mathbb{H}(TrG-\gamma)\left[(1-r\omega)U^I_e+(1-m\omega)U^{II}_e\right] \end{equation}$

(2.3)

where $\mathbb{H}$ is the Heaviside function, $TrG$ is the trace of $G$ , $r$ affects on the 1st gradient residual inside the fracture, and $m$ affects on microstructure due to damage. Parameters $r$ and $m$ should be as close as possible to the value 1. $\gamma$ is a constitutive parameter representing the threshold of the trace of $G$ controlling the bi-modular behavior of damage, which stipulates that damage evolution occurs only when the trace of the strain tensor $G$ is positive and exceeds a predefined threshold. By implementing this condition, we ensure that damage progression is assessed solely in regions experiencing tensile stresses. The first gradient part $U^I_e$ of the deformation energy density above reads as

$\begin{equation} U^I_{e}(G, \nabla G) = \frac{\lambda}{2}G_{ii}G_{jj}+\mu G_{ij}G_{ij} \end{equation}$

(2.4)

and the strain gradient part $U^{II}_e$ reads as

$\begin{equation} U^{II}_{e}(G, \nabla G, \omega) = 2c_{3}G_{ii, j}G_{jh, h}+\frac{c_{4}}{2}G_{ii, k}G_{ll, k}+2c_{5}G_{ij, i}G_{jm, m}+c_{6}G_{ij, k}G_{ij, k}+2c_{7}G_{ij, k}G_{ki, j} \end{equation}$

(2.5)

where $\lambda$ , $\mu$ , $c_{3}$ , $c_{4}$ , $c_{5}$ , $c_{6}$ , $c_{7}$ $\in\mathbb{R}$ are independent parameters. Our model accounts for an isotropic material, because the key focus is on the examination of damage evolution exclusively under tension while avoiding its manifestation in compression, aimed at capturing the behavior of cementitious materials. The quantities $\lambda$ and $\mu$ in Eq (2.4) are referred to as Lamé parameters and it is a classical result in mechanics that they can be easily related to the Young modulus $Y$ and to the Poisson's ratio $\nu$ . For the 2D case, we have

$\begin{equation} \lambda = \frac{Y\nu}{(1+\nu)(1-2\nu)}, \qquad\mu = \frac{Y}{2(1+\nu)}. \end{equation}$

(2.6)

The coefficients $c_{3}$ – $c_{7}$ can instead be identified in terms of Young modulus and Lamé parameters, and an internal characteristic length–also referred to as the intergranular distance–within the granular micro-mechanics-based framework presented in ^[4] is as follows:

$\begin{equation} \begin{cases} & c_{3} = YL^{2}\frac{\nu}{112(1+\nu)(1-2\nu)} = \frac{L^{2}}{112}\lambda, \\ & c_{4} = YL^{2}\frac{\nu}{112(1+\nu)(1-2\nu)} = \frac{L^{2}}{112}\lambda, \\ & c_{5} = YL^{2}\frac{7-8\nu}{2240(1+\nu)(1-2\nu)} = \frac{L^{2}}{1120}(7\mu+3\lambda), \\ & c_{6} = YL^{2}\frac{7-18\nu}{1120(1+\nu)(1-2\nu)} = \frac{L^{2}}{1120}(7\mu-4\lambda), \\ & c_{7} = YL^{2}\frac{7-8\nu}{2240(1+\nu)(1-2\nu)} = \frac{L^{2}}{1120}(7\mu+3\lambda). \end{cases} \end{equation}$

(2.7)

We now introduce the dissipated energy $U_d$ as

$\begin{equation} U_d(\omega) = \frac{1}{2}k_{\omega}\omega^{2} \end{equation}$

(2.8)

where $k_{\omega}$ represents the resistance to damage. The kinetic energy $U_{k}$ is instead assumed to having the following expression:

$\begin{equation} U_{k} = \frac{1}{2}\rho\big\Vert\frac{\partial u}{\partial t}\big\Vert^2 = \frac{1}{2}\rho \left( \frac{\partial^2 u_1}{\partial t^2}+ \frac{\partial^2 u_2}{\partial t^2}\right). \end{equation}$

(2.9)

where $\rho$ is material density per unit area and $u_{1}$ and $u_{2}$ are the displacement components in the horizontal and vertical directions, respectively. It is easy to prove ^[1] that having a nonzero kinetic energy in the form above is equivalent to have $b^{ext} = -\rho\ddot{u}$ .

3. Numerical results

The weak form package of the commercial software COMSOL Multiphysics has been employed to perform the numerical simulation presented in this section, based on the modeling presented so far.

3.1. Description of the numerical experiments

In the current section, we present numerical simulations to show the capabilities of the presented model to describe initiation and growth of damage localization zones. Following ^[41], we consider a 2D square specimen with a notch (pre-crack). The followig type of numerical experiment is considered: the left edge of the notch (the blue line) is fixed, i.e., cannot move, along the direction $\hat{e_{x}}$ , while the right edge of the notch (the red line) is subjected to an applied velocity in the $\hat{e_{x}}$ direction (from left to right). Such an applied velocity will be also referred to as crack-opening velocity.

Figure 1 illustrates this loading condition. In the original paper ^[41], there are twelve cases of different applied velocities, the loading-rates being in the range from 0.045 m/s to 4.298 m/s. In this section, only four cases of tested velocities are considered for the study, which are Case 1: 0.491 m/s; Case 2: 1.375 m/s; Case 3: 3.268 m/s, and Case 4: 4.298 m/s. In the current study, the applied velocity is assumed to depend upon time–the data of the actual loading history used in the experiments was not reported in the original paper, as follows:

$\begin{equation} v = \begin{cases} \frac{t}{t_{0}}v_{0} & t\leq t_{0}\\ v_{0} & t > t_{0} \end{cases} \end{equation}$

(3.1)

with $t_{0}$ = 100 $\mu s$ and $t$ = 500 $\mu s$ . The prescribed displacement velocity as a function of time for $v_{0}$ = 3.268 m/s is reported in Figure 2.

The constitutive parameters used in the numerical simulations are reported in , where $t_{f}$ is the time horizon of the simulations and $\triangle t$ the time step. It should be noted that since simulations were performed for the 2D case, to take into account the (uniform) thickness of the specimen–25 mm–some constitutive parameters were adapted by multiplying them by this value.

Figure 1. Schematics of analyzed domains and considered boundary conditions.

$Y$	$\nu$	$L$	$\rho$	$k_{\omega}$	$t_{f}$	$\triangle t$	$\gamma$	$r$	$m$
15 $GPa$	0.18	0.01118 $m$	2400 $kg/m^{3}$	5 $J/m^{2}$	500 $\mu s$	0.5 $\mu s$	0.0012	0.99999	0.99999

DOF	N. of elements	Max. element size, $m$	Reaction force, $kN$	Reaction integration over time
656	110	0.1	77.35	17.6204
684	115	0.08	76.87	17.5195
752	128	0.066	77.15	17.5876
796	136	0.04	76.16	17.4080
1108	195	0.026	76.17	17.4330
1614	292	0.02	76.01	17.3816
2768	514	0.0134	75.43	17.2840
3526	661	0.0106	75.52	17.3038
5200	987	0.008	75.32	17.2693
14500	2818	0.004	75.50	17.3041
51046	10060	0.002	75.17	17.2411
186276	36991	0.001	74.80	17.1749

Applied $v_0$ (m/s)	Exp. results ^[41]	Numerical results obtained with various approaches by
Applied $v_0$ (m/s)	Exp. results ^[41]	Ozbolt ^[42]	This paper	Hai ^[22]	Wu's IH-PD ^[71]	Wu's FH-PD ^[71]	Bui ^[5]	Qinami ^[55]
0.491	4.05	4.12	2.88	-	-	-	-	-
1.375	4.64	3.54	3.68	3.75	$\thickapprox$ 4.3	$\thickapprox$ 5.5	$\thickapprox$ 3.3	$\thickapprox$ 4.7
3.268	4.59	4.76	4.99	4.70	$\thickapprox$ 4.6	$\thickapprox$ 6.1	$\thickapprox$ 3.3	$\thickapprox$ 6.1
4.298	5.66	5.15	5.00	-	$\thickapprox$ 5.6	$\thickapprox$ 6.1	-	$\thickapprox$ 6.5

[1]	B. E. Abali, W. H. Müller, F. dell'Isola, Theory and computation of higher gradient elasticity theories based on action principles, Arch. Appl. Mech., 87 (2017), 1495–1510. https://doi.org/10.1007/s00419-017-1266-5 doi: 10.1007/s00419-017-1266-5
[2]	J. J. Alibert, P. Seppecher, F. Dell'Isola, Truss modular beams with deformation energy depending on higher displacement gradients, Math Mech Solids, 8 (2003), 51–73. https://doi.org/10.1177/1081286503008001658 doi: 10.1177/1081286503008001658
[3]	G. Aydin, B. C. Sarar, M. E. Yildizdag, B. E. Abali, Investigating infill density and pattern effects in additive manufacturing by characterizing metamaterials along the strain-gradient theory, Math Mech Solids, 27 (2022), 2002–2016. https://doi.org/10.1177/10812865221100978 doi: 10.1177/10812865221100978
[4]	E. Barchiesi, A. Misra, L. Placidi, E. Turco, Granular micromechanics-based identification of isotropic strain gradient parameters for elastic geometrically nonlinear deformations, Z Angew Math Mech, 101 (2021), e202100059.
[5]	T. Q. Bui, H. Tran, X. Hu, C. T. Wu, Simulation of dynamic brittle and quasi-brittle fracture: a revisited local damage approach, Int J Fracture, 236 (2022), 59–85.
[6]	E. Cadoni, A. Caverzani, M. di Priscoi, Dynamic behaviour of hpfrcc in tension, EPJ Web of Conferences, 26 (2012), 01014. https://doi.org/10.1051/epjconf/20122601014 doi: 10.1051/epjconf/20122601014
[7]	C. H. Chen, E. Bouchbinder, A. Karma, Instability in dynamic fracture and the failure of the classical theory of cracks, Nat. Phys., 13 (2017), 1186–1190. https://doi.org/10.1038/nphys4237 doi: 10.1038/nphys4237
[8]	Y. Cui, X. Zeng, V. B. C. Tan, Z. Zhang, Experimental and numerical studies of niti dynamic fracture behaviors under the impact loading, Int. J. Mech. Sci., 235 (2022), 107724. https://doi.org/10.1016/j.ijmecsci.2022.107724 doi: 10.1016/j.ijmecsci.2022.107724
[9]	H. Darban, R. Luciano, A. Caporale, F. Fabbrocino, Higher modes of buckling in shear deformable nanobeams, Int J Eng Sci, 154 (2020), 103338. https://doi.org/10.1016/j.ijengsci.2020.103338 doi: 10.1016/j.ijengsci.2020.103338
[10]	F. dell'Isola, L. Placidi, Variational principles are a powerful tool also for formulating field theories, In: F. dell'Isola, S. Gavrilyuk, (eds) Variational Models and Methods in Solid and Fluid Mechanics. Vienna: Springer, 535 (2001), 1–15. https://doi.org/10.1007/978-3-7091-0983-0_1
[11]	F. dell'Isola, U. Andreaus, L. Placidi, At the origins and in the vanguard of peridynamics, non-local and higher-gradient continuum mechanics: An underestimated and still topical contribution of gabrio piola, Math Mech Solids, 20 (2015), 887–928. https://doi.org/10.1177/1081286513509811 doi: 10.1177/1081286513509811
[12]	F. dell'Isola, R. Fedele, Irreducible representation of surface distributions and Piola transformation of external loads sustainable by third gradient continua, Comptes Rendus. Mécanique, 351 (2023), 1–30.
[13]	F. dell'Isola, P. Seppecher, A. Madeo, How contact interactions may depend on the shape of cauchy cuts in nth gradient continua: approach "à la d'alembert", Z. Angew. Math. Phys., 63 (2012), 1119–1141. https://doi.org/10.1007/s00033-012-0197-9 doi: 10.1007/s00033-012-0197-9
[14]	V. A. Eremeyev, F. dell'Isola, On weak solutions of the boundary value problem within linear dilatational strain gradient elasticity for polyhedral lipschitz domains, Math Mech Solids, 27 (2022), 433–445. https://doi.org/10.1177/10812865211025576 doi: 10.1177/10812865211025576
[15]	V. A. Eremeyev, S. A. Lurie, Y. O. Solyaev, F. dell'Isola, On the well posedness of static boundary value problem within the linear dilatational strain gradient elasticity, Z. Angew. Math. Phys., 71 (2020), 182. https://doi.org/10.1007/s00033-020-01395-5 doi: 10.1007/s00033-020-01395-5
[16]	A. C. Eringen, Microcontinuum Field Theories I: Foundations and Solids, New York: Springer-Verlang, 1999.
[17]	O. Essersi, M. Tarfaoui, S. Boyd, R. Shenoi, F. Meraghni, Experimental study of dynamic behaviour of aluminum/aluminum and composite/composite double lap joints, Appl Mech Mater, 62 (2011), 155–163. https://doi.org/10.4028/www.scientific.net/AMM.62.155 doi: 10.4028/www.scientific.net/AMM.62.155
[18]	F. Fabbrocino, M. F. Funari, F. Greco, P. Lonetti, R. Luciano, R. Penna, Dynamic crack growth based on moving mesh method, Compos. B. Eng., 174 (2019), 107053. https://doi.org/10.1016/j.compositesb.2019.107053 doi: 10.1016/j.compositesb.2019.107053
[19]	M. F. Funari, S. Spadea, F. Fabbrocino, R. Luciano, A moving interface finite element formulation to predict dynamic edge debonding in frp-strengthened concrete beams in service conditions, Fibers, 8 (2020), 42. https://doi.org/10.3390/fib8060042 doi: 10.3390/fib8060042
[20]	F. Galvez, D. Cendon, N. Garcia, A. Enfedaque, V. Sanchez-Galvez, Dynamic fracture toughness of a high strength armor steel, Eng Fail Anal, 16 (2009), 2567–2575. https://doi.org/10.1016/j.engfailanal.2009.04.020 doi: 10.1016/j.engfailanal.2009.04.020
[21]	P. Germain, The method of virtual power in continuum mechanics. Part 2: Microstructure, SIAM J Appl Math, 25 (1973), 556–575. https://doi.org/10.1137/0125053 doi: 10.1137/0125053
[22]	L. Hai, J. Li, A rate-dependent phase-field framework for the dynamic failure of quasi-brittle materials, Eng. Fract. Mech., 252 (2021), 107847. https://doi.org/10.1016/j.engfracmech.2021.107847 doi: 10.1016/j.engfracmech.2021.107847
[23]	R. H. Cao, R. Yao, T. Hu, C. Wang, K. Li, J. Meng, Failure and mechanical behavior of transversely isotropic rock under compression-shear tests: Laboratory testing and numerical simulation, Eng. Fract. Mech., 241 (2021), 107389. https://doi.org/10.1016/j.engfracmech.2020.107389 doi: 10.1016/j.engfracmech.2020.107389
[24]	X. Huang, A. R. Tabkhi, V. Sadeghian, O. S. Kwon, Impact of loading rate during hybrid simulation on seismic response of steel structures, Earthq Eng Struct Dyn, 51 (2022), 2813–2836. https://doi.org/10.1002/eqe.3703 doi: 10.1002/eqe.3703
[25]	H. H. Jama, G. N. Nurick, M. R. Bambach, R. H. Grzebieta, X. L. Zhao, Steel square hollow sections subjected to transverse blast loads, Thin Wall Struct, 53 (2012), 109–122. https://doi.org/10.1016/j.tws.2012.01.007 doi: 10.1016/j.tws.2012.01.007
[26]	K. Khaled, G. Mohamed, Modelling of the influence of tensile test speed on the fracture load, ASM Sci. J., 12 (2019), 1–12.
[27]	Q. Li, X. Jiang, T. Zeng, S. Xu, Experimental investigation on strain rate effect of high-performance fiber reinforced cementitious composites subject to dynamic direct tensile loading, Cement Concrete Res, 157 (2022), 106825. https://doi.org/10.1016/j.cemconres.2022.106825 doi: 10.1016/j.cemconres.2022.106825
[28]	X. Liu, P. Yu, B. Zheng, E. Oterkus, X. He, C. Lu, Prediction of graphene's mechanical and fracture properties via peridynamics, Int. J. Mech. Sci., 266 (2024), 108914. https://doi.org/10.1016/j.ijmecsci.2023.108914 doi: 10.1016/j.ijmecsci.2023.108914
[29]	R. Luciano, H. Darban, C. Bartolomeo, F. Fabbrocino, D. Scorza, Free flexural vibrations of nanobeams with non-classical boundary conditions using stress-driven nonlocal model, Mech Res Commun, 107 (2020), 103536. https://doi.org/10.1016/j.mechrescom.2020.103536 doi: 10.1016/j.mechrescom.2020.103536
[30]	K. K. Mahato, M. Biswal, D. K. Rathore, R. K. Prusty, K. Dutta, B. C. Ray, Effect of loading rate on tensile properties and failure behavior of glass fibre/epoxy composite, IOP Conference Series: Materials Science and Engineering, 115 (2016), 012017. https://dx.doi.org/10.1088/1757-899X/115/1/012017 doi: 10.1088/1757-899X/115/1/012017
[31]	G. Mancusi, F. Fabbrocino, L. Feo, F. Fraternali, Size effect and dynamic properties of 2d lattice materials, Compos. B. Eng., 112 (2017), 235–242. https://doi.org/10.1016/j.compositesb.2016.12.026 doi: 10.1016/j.compositesb.2016.12.026
[32]	J. Marigo, Modelling of brittle and fatigue damage for elastic material by growth of microvoids, Eng. Fract. Mech., 21 (1985), 861–874. https://doi.org/10.1016/0013-7944(85)90093-1 doi: 10.1016/0013-7944(85)90093-1
[33]	V. Mentl, J. Dzugan, Impact compression and tensile testing by means of a charpy pendulum, in WIT Transactions on The Built Environment, Ashurst: WIT Press, 2008, 55–61.
[34]	R. D. Mindlin, Micro-structure in linear elasticity, Arch Ration Mech Anal, 16 (1964), 51–78. https://doi.org/10.1007/BF00248490 doi: 10.1007/BF00248490
[35]	A. Misra, P. Luca, E. Turco, Variational Methods for Discrete Models of Granular Materials, In: H. Altenbach, A. Öchsner, (eds) Encyclopedia of Continuum Mechanics, Berlin: Springer-Verlag, 2020. https://doi.org/10.1007/978-3-662-55771-6_172
[36]	A. Misra, L. Placidi, F. dell'Isola, E. Barchiesi, Identification of a geometrically nonlinear micromorphic continuum via granular micromechanics, Z. Angew. Math. Phys., 72 (2021), 157. https://doi.org/10.1007/s00033-021-01587-7 doi: 10.1007/s00033-021-01587-7
[37]	N. Nejadsadeghi, A. Misra, Extended granular micromechanics approach: a micromorphic theory of degree n, Math Mech Solids, 25 (2020), 407–429. https://doi.org/10.1177/1081286519879479 doi: 10.1177/1081286519879479
[38]	H. Nguyen, W. Li, Z. P. Bažant, Y. Bazilevs, Isogeometric smooth crack-band model (isCBM) using spress-sprain relations adapted to microplane theory, J Mech Phys Solids, 181 (2023), 105470. https://doi.org/10.1016/j.jmps.2023.105470 doi: 10.1016/j.jmps.2023.105470
[39]	Z. Nowak, Z. L. Kowalewski, T. Szymczak, Low velocity perforation of thick magnesium alloy AM60 plates impacted by rigid conical-nose impactor, Arch. Civ. Mech. Eng., 23 (2022), 5. https://doi.org/10.1007/s43452-022-00525-2 doi: 10.1007/s43452-022-00525-2
[40]	J. Ožbolt, K. K. Rah, D. Meštrović, Influence of loading rate on concrete cone failure, Int J Fract, 139 (2006), 239–252. https://doi.org/10.1007/s10704-006-0041-3 doi: 10.1007/s10704-006-0041-3
