In supply chain management, cost, quality and price are the three core issues [1]. However, besides seeking to achieve the critical goals of minimum cost, quality service and maximum profit, supply chain managers nowadays are faced with challenges and changes such as supply risk and resilience [2]. A resilient supply chain has a strong predictive ability to meet the demand with the supply even in the course of disruption [3]. Unfortunately, most businesses are often caught short due to the lack of accurate demand forecasting.
Cold chain logistics is a special logistics network that handles perishable produce, including agricultural products, meat, milk and dairy products, pharmaceutical products, etc. [4]. The storage and transportation of perishable assets are sensitive to various operational and environmental factors like temperature and humidity [5]. The global cold chain logistics market is expected to soar from USD 160 billion in 2018 to USD 585.1 billion by 2026, with a compound annual growth rate (CAGR) close to 10% during the period. In 2020, the market size of China's cold chain logistics reached 383.2 billion yuan, a year-on-year increase of 13%, and the total demand for fresh food cold chain logistics exceeded 265 million tons, a year-on-year growth of 13.69%. The statistics from the China Cold-Chain Logistics Association indicate that the market size for cold chain logistics in China will reach RMB 897 billion in 2025, with a CAGR close to 18%, demonstrating the dramatic potential of the market demand [6]. However, the mismanagement of operations within the cold chain network may cause from 20 to 30% of damage to the fresh goods in any given situation [7]. Therefore, in order to reduce the deterioration of fresh goods during transportation, operations like cross-docking [8,9], intermodal freight network application [10] and path optimization [11,12] have been well and widely studied in practice and research. However, due to higher technical requirements, the cold chain logistics is more difficult to manage than a general supply chain, which makes it difficult for replenishment when there is a supply shortage. Consequently, accurate demand forecasting for cold chain logistics and its influential factors analysis will significantly improve operation efficiency and bring information and communication resilience into the cold chain network [13].
The rest of this work is structured as follows. Section 2 reviews literature relevant to this study. Section 3 presents the modelling methods and materials used in this paper. In Section 4, the grey relation model, FGM (1, 1) model and FGM (1, N) model are applied to forecast the demand of agricultural cold chain logistics in Beijing, Tianjin and Hebei. Finally, Section 5 concludes this paper.
Diverse approaches to forecasting the cold chain logistics demand have sparked extensive discussions, and some well-honed techniques are presented below. To predict the cold chain logistics demand for fresh agricultural products, Liu et al. proposed a secondary exponential smoothing model [14]. He et al. used a back-propagation neural network to forecast the size of China's cold chain market, using residents' per capita disposable income and per capita consumption expenditure as exogenous influential factors [15]. Wang et al. developed and tested a multivariate linear regression prediction model to analyze the demand for fruit cold chain logistics. The influential factors tested in the experiment included the disposable income of urban residents, mileage of transportation lines, cold chain circulation rate and retail price index [16]. To construct a demand forecasting model of aquatic cold chain logistics, Xu et al. proposed a gray wolf optimizer-support vector machine [17]. Wang et al. used a metabolic GM (1, 1) model to forecast the demand for the cold chain logistics of agricultural products in China [18]. Lu et al. discovered that the circulation rate of aquatic products in the cold chain, the corrosion rate of aquatic products and the added value of the tertiary industry were the first three factors influencing the Dalian aquatic products cold chain demand by using a grey relation model; they then used a combination of an improved GM (1, 1) model and back propagation (BP) neural network model to predict demand [19].
The above-mentioned research methods for demand forecasting are of practical value and have a certain forecasting accuracy; moreover, they have laid a good foundation for this work to forecast the demand for cold chain logistics. However, there are many factors that affect the demand of cold chain logistics, and there is a nonlinear correlation between each influential factor and the demand of cold chain logistics; what's more, most of the forecasting models need a large amount of sample data to fit the relationship between factors [20]. Using a multiple regression forecasting method has drawbacks that lead to multicollinearity problems while using a time-series forecasting method has the requirement of strict continuity timeline data [21]. The statistical system of cold chain logistics in China is unsound and lacks historical data, which have affected the prediction accuracy of cold chain logistics demand. In other words, when dealing with issues characterized by multicollinearity and insufficient input data, most models appear to fail. Considering the characteristics of cold chain logistics demand forecasting, the multi-variable grey forecasting model GM (1, N) was proposed to address this issue, providing an innovative way to analyze small batches of low-quality uncertain data [22].
A system's characteristic sequence and (N-1) related factor sequences make up GM (1, N). The modeling process fully considers the impact of various influential factors on system change and makes full use of the information contained in the associated series [23]. Although the GM (1, N) model has distinct advantages, it still has some inherent flaws in terms of achieving high predicting accuracy, because it does not reflect the priority of new information [24]. As a result, a new grey system model with fractional order accumulation was proposed; it can effectively reflect the priority of new information [25]. For small sample sizes, practical studies on the novel fractional grey model have demonstrated remarkable prediction performance when compared to the traditional grey model [26,27,28].
Based on the analysis presented above, due to a lack of historical data on cold chain logistics demand, as well as uncertainty and nonlinear linkages in the system, traditional forecasting methods are insufficiently precise and subjective, making them unsuitable for forecasting cold chain logistics demand. While there is a large body of literature on forecasting cold chain logistics demand, fractional grey models with multi-variables for estimating cold chain demand have received little attention; what's more, there are few that focus on various factors influencing regional development. Regional differences in economy and resource distribution have a great impact on the regional development level of agricultural cold chain logistics [29]. Consequently, this paper takes demand forecasting and its influential factors for agricultural cold chain logistics in Beijing-Tianjin-Hebei region as the research objective by using an FGM (1, N) model. This work's contributions are summarized as follows. 1) Grey correlation analysis is used to determine the three main factors influencing cold chain logistics demand for agricultural products in Beijing, Tianjin, and Hebei. 2) An FGM (1, N) model is proposed to forecast agricultural product cold chain logistics demand. 3) The proposed method can accurately forecast the future trend of agricultural cold chain demand logistics in Beijing, Tianjin and Hebei. Furthermore, the prediction results can serve as a policy guide for the integrated and coordinated development of agricultural cold chain logistics in the Beijing-Tianjin-Hebei region.
Through the fitting degree of the curve geometry, grey relation analysis determines whether the correlation between the influential factor series and the characteristic series is close. The greater the degree of curve fitting, the greater the degree of correlation between the sequences, and the greater the importance of the influential factor [30]. The following is a description of the grey relation analysis process.
If Xi is a system influential factor, and its observation data on the kth serial number is xi(k),k=1,2,⋯,n, then Xi={xi(1),xi(2),⋯,xi(n)} is the behavioral sequence of Xi.
Let X0={x0(1),x0(2),⋯,x0(n)} be the system's character behavioral sequence; then the sequences of relevant influencing factors are:
| {X1={x1(1),x1(2),⋯,x1(n)}X2={x2(1),x2(2),⋯,x2(n)}⋮Xm={xm(1),xm(2),⋯,xm(n)}, |
where m is the number of influential factors.
Therefore, the relation degree for a relevant factor sequence and feature sequence can be calculated by using the below formula:
| γ(X0,Xi)=1n∑nk=1γ(x0(k),xi(k)) | (1) |
where,
| γ(x0(k),xi(k))=minimink|x0(k)−xi(k)|+ξmaximaxk|x0(k)−xi(k)||x0(k)−xi(k)|+ξmaximaxk|x0(k)−xi(k)| | (2) |
ξ is the resolution coefficient and ξ∈(0,1) per work [22] according to Deng; if the sequence data are relatively stable, we generally set ξ=0.5 to improve the significance of the difference between correlation coefficients.
The FGM (1, 1) model is used in this study to predict the factors influencing cold chain logistics demand. The modeling procedure is described in detail below [23].
(a) Assume the non-negative sequence X(0)={x(0)(1),x(0)(2),⋯,x(0)(n)}. X(0) represents the annual data series for a cold chain demand influential factor index. The rth-order accumulated generation sequence of the original sequence X(0) is
| X(r)={x(r)(1),x(r)(2),⋯,x(r)(n)} | (3) |
where x(r)(k)=∑ki=1Ck−ik−i+r−1x(0)(k), and Ck−ik−i+r−1=(k−i+r−1)(k−i+r−2)⋯(r+2)(r+1)r(k−i)!.
And C0r−1 = 1. Ck+1k = 0 and x(r)(1)=x(0)(1).
The superscript (r) indicates an rth-order accumulation sequence, while a superscript (0) indicates an original sequence in Eq (3). In this work, the particle swarm algorithm is used to calculate the optimal order r of the prediction model.
(b) The corresponding whitening equation for the newly generated sequence X(r) is as follows:
| dx(r)dt+ax(r)=b | (4) |
where a is the development coefficient and b represents the grey action quantity.
(c) The least squares method is used to compute the values of the parameters a and b.
| [ab]=(BTB)−1BTY | (5) |
where the Y and B matrices are as follows:
| Y=[x(r)(2)−x(r)(1)x(r)(3)−x(r)(2)⋮x(r)(n)−x(r)(n−1)],B=[−Z(r)(2)1−Z(r)(3)1⋮⋮−Z(r)(n)1] |
Where,
| Z(r)(k)=(x(r)(k)+x(r)(k+1))2 | (6) |
(d) The time response formula of the whitening equation is
| x(r)(k)=(x(0)(1)−ba)e−a(k−1)+ba | (7) |
Then the response time series X(r) is obtained as below:
| X(r)={x(r)(1),x(r)(2),⋯,x(r)(n),⋯} | (8) |
The r-order reduction of X(r) is as below:
| X(0)={x(0)(1),x(0)(2),⋯,x(0)(n),⋯} | (9) |
where x(0)(1)=x(0)(1) and x(0)(k)=x(r)(1−r)(k)−x(r)(1−r)(k−1). Therefore, the fitting values for the cold chain demand influential factors index data are {x(0)(1),x(0)(2),⋯,x(0)(n)}, and the predicted values are {x(0)(n+1),x(0)(n+2),⋯}.
An FGM (1, N) model is proposed to predict the cold chain logistics demand while taking into account various influential factors [31].
(a) Assume the system's characteristic data sequence X0={x0(1),x0(2),⋯,x0(n)}, where X0 represents the annual data series for the cold chain demand and the formula below expresses the annual data series for the influential factors:
| {X1={x1(1),x1(2),⋯,x1(n)}X2={x2(1),x2(2),⋯,x2(n)}⋮Xm={xm(1),xm(2),⋯,xm(n)} | (10) |
The sequence after r-order accumulation is X(r)i={x(r)i(1),x(r)i(2),⋯,x(r)i(n)},i=1,2,⋯,m, where
| x(r)i(k)=k∑i=1Ck−ik−i+r−1x(0)i(k),k=1,2,⋯,n |
| Ck−ik−i+r−1=(k−i+r−1)(k−i+r−2)⋯(r+2)(r+1)r(k−i)! |
Let C0r−1 = 1, Ck+1k=0 and x(r)(1)=x(0)(1). Then, x(r)0(k)+az(r)0(k)=∑ni=1bix(r)i(k) is the FGM (1, N) model.
(b) For the newly generated sequence X(r), the corresponding whitening equation can be expressed as:
| dx(r)0dt+ax(r)0(k)=∑ni=1bix(r)i(k) | (11) |
(c) The values of the parameters a and b are calculated by using the least square method:
| [ab]=(BTB)−1BTY |
where the matrices of Y and B are as follows:
| Y=[x(r)0(2)−x(r)0(1)x(r)0(3)−x(r)0(2)⋮x(r)0(n)−x(r)0(n−1)],B=[−z(r)0(2)x(r)1(2)⋯x(r)n(2)−z(r)0(3)x(r)1(3)⋯x(r)n(3)⋮⋮⋱⋮−z(r)0(n)x(r)1(n)⋯x(r)n(n)] |
where, z(r)0(k)=(x(r)0(k)+x(r)0(k+1))2 k=2,3,⋯,n.
(d) The time response formula of the whitening equation is
| x(r)(k)=(x(r)0(1)−1a∑ni=1bix(r)i(k+1))e−a(k−1)1a∑ni=1bix(r)i(k+1) | (12) |
Then the response time series X(r) is obtained as below:
| X(r)0={x(r)0(1),x(r)0(2),⋯,x(r)0(n),⋯} |
The r-order reduction of X(r)0 is as below:
| X(0)={x(0)(1),x(0)(2),⋯,x(0)(n),⋯} | (13) |
where,
| x(0)(1)=x(0)(1),x(0)(k)=x(r)(1−r)(k)−x(r)(1−r)(k−1),k=2,3,⋯,n,⋯ |
Therefore, the fitting values for the cold chain demand logistics index data are
{x(0)(1),x(0)(2),⋯,x(0)(n)}, and the predicted values are {x(0)(n+1),x(0)(n+2),⋯}.
(e) There are various criteria for evaluating the precision of the grey model. For example, the mean absolute percentage error (MAPE), absolute mean error, and mean square error are widely used [32]. In addition, the R2 coefficient of determination is validated for fitting a linear model. In this work, the MAPE and R2 coefficient of determination are used to assess the precision of the models involved. The larger the value of R2, the better the performance of the model. Table 1 displays the MAPE criteria [25].
| MAPE=1nn∑k=1|ˆx(0)(k)−x(0)(k)|x(0)(k)×100% |
| R2=1−SSESST |
| MAPE | Prediction Ability |
| < 10% | Good |
| 10%-20% | Qualified |
| 20%-50% | Barely enough |
| > 50% | Unqualified |
DownLoad:
CSV
where SSE=∑nk=1(x(0)(k)−ˆx(0)(k))2 and SST=∑nk=1(x(0)(k)−¯x(0)(k))2.
Additionally, where x(0)(k) is the actual value at time k, and ˆx(0)(k) is the prediction value at time k.
Five influential factors were preliminarily selected to investigate their impact on the cold chain logistics for agricultural products in Beijing, Tianjin and Hebei; they are the regional GDP, proportion of tertiary industry, fixed assets investment in transport and storage, per capita disposable income indices for urban households, and general price index for farm products; this was done by summarizing existing literature.
The GDP measures a region's level of economic development; it is commonly suitable for estimating logistics efficiency [33]. The larger the total GDP, the higher the level of economic development, and the greater the demand for logistics services such as cargo transportation, warehousing, distribution, and logistics information processing [34]. Therefore, the economy and cold chain logistics benefit from mutual and coordinated growth.
Logistics is a critical component of the tertiary industry. The stabilization of the tertiary industry means continuous requirements for logistics services and the optimization of the economy's structure [35]. The development of the tertiary industry drives the prosperity of the service industry which generates huge potential demand for logistics services [36].
Fixed assets investment in transportation and storage improves infrastructure such as roads, waterways, railways, and cold storage capacity [21]. Cold chain products are mainly distributed in urban areas via road transport; high requirements for time and infrastructure stimulate substantial investment to increase cold chain storage and transportation capacity [37]. As a result, it has a positive impact on cold chain logistics demand.
The consumption level of urban households is represented by per capita disposable income indices. Consumers have higher expectations for food quality and safety as their consumption level rises, and the demand for cold chain services will rise as well [38].
From the standpoint of supply, the general price index for farm products influences the demand for agricultural cold chain logistics. The effective supply of agricultural products ensures that there are enough commodities in the market to meet the needs of consumers, and the reasonable price of agricultural products balances the supply and demand, influencing the demand for agricultural cold chain logistics [39].
The data used for the influential factors in Beijing, Tianjin and Hebei are all from the regional statistics department. Tables 2–4 summarize data from the Statistical Yearbooks of Beijing, Tianjin and Hebei for these five influential factors from 2014 to 2020. The proposed grey model is stable when the sample data size is small in theory, which is a difference between the grey model and the traditional statistical model [40]; therefore, we only use recent data. Because logistics demand is not separately recorded in China's statistical reports, the method described in [39] was employed to calculate cold chain logistics demand for agricultural products; in this method, the number of urban permanent residents is multiplied by the urban per capita consumption of fresh agricultural products. In this paper, the agricultural products include vegetables, fruits, meat, fresh eggs, aquatic products, milk, and dairy products. Table 5 shows the calculation results for the cold chain logistics demand for agricultural products in Beijing, Tianjin, and Hebei from 2014–2020.
| Year | GDP(108 yuan) | Proportion of Tertiary Industry(%) | Fixed Assets Investment in Transport and Storage(108 yuan) | Per Capita Disposable Income Indices for Urban Households | General Price Index for Farm Products |
| 2014 | 22926 | 80.6 | 756.5 | 108.9 | 99.7 |
| 2015 | 24779.1 | 92.6 | 827 | 120.38 | 99.8 |
| 2016 | 27041.2 | 86.9 | 973 | 108.35 | 99.7 |
| 2017 | 29883 | 89.5 | 1327 | 108.96 | 99.6 |
| 2018 | 33106 | 90.2 | 1341.6 | 108.95 | 103.6 |
| 2019 | 35445.1 | 89.6 | 1218.17 | 108.62 | 109.9 |
| 2020 | 36102.6 | 72.6 | 1093.92 | 102.4 | 110.9 |
DownLoad:
CSV
| Year | GDP(108 yuan) | Proportion of Tertiary Industry(%) | Fixed Assets Investment in Transport and Storage(108 yuan) | Per Capita Disposable Income Indices for Urban Households | General Price Index for Farm Products |
| 2014 | 10640.62 | 55.1 | 769.71 | 101.9 | 98.3 |
| 2015 | 10879.51 | 57.2 | 860.77 | 101.7 | 97.8 |
| 2016 | 11477.2 | 60.5 | 787.5 | 102.1 | 102.2 |
| 2017 | 12450.56 | 62 | 670.95 | 102.1 | 101 |
| 2018 | 13362.92 | 62.5 | 621.3 | 102 | 100.2 |
| 2019 | 14055.46 | 63.5 | 784.7 | 102.7 | 103.7 |
| 2020 | 14083.73 | 64.4 | 1079.75 | 102 | 104.5 |
DownLoad:
CSV
| Year | GDP(108 yuan) | Proportion of Tertiary Industry(%) | Fixed Assets Investment in Transport and Storage(108 yuan) | Per Capita Disposable Income Indices for Urban Households | General Price Index for Farm Products |
| 2014 | 29421.2 | 37.30 | 2025.90 | 108.61 | 100.23 |
| 2015 | 29806.1 | 40.19 | 2035.70 | 108.33 | 97.5 |
| 2016 | 31827.9 | 41.71 | 2081.30 | 106.33 | 96.35 |
| 2017 | 36964 | 41.82 | 2116.30 | 108.14 | 96.19 |
| 2018 | 32494.61 | 50.01 | 2581.89 | 107.95 | 104.65 |
| 2019 | 35104.52 | 51.65 | 2646.43 | 117.02 | 101 |
| 2020 | 36206.9 | 51.73 | 3048.69 | 126.38 | 113.67 |
DownLoad:
CSV
| Year | Beijing | Tianjin | Hebei |
| 2014 | 744.79 | 332.35 | 798.44 |
| 2015 | 765.2 | 339.42 | 845.2 |
| 2016 | 793.67 | 353.15 | 980.5 |
| 2017 | 816.34 | 358.02 | 974.4 |
| 2018 | 893.89 | 367.90 | 1094.78 |
| 2019 | 965.4 | 367.68 | 1187.84 |
| 2020 | 1033.95 | 392.82 | 1280.49 |
DownLoad:
CSV
A grey correlation analysis is performed for the agricultural product cold chain logistics demand and five influential factors in Beijing, Tianjin and Hebei, respectively. Table 6 and Figure 1 show the results.
| Influencing Factors | Grey Relation Degree | ||
| Beijing | Tianjin | Hebei | |
| GDP | 0.86 | 0.91 | 0.94 |
| Proportion of Tertiary Industry | 0.92 | 0.96 | 0.87 |
| Fixed Assets Investment in Transport and Storage | 0.65 | 0.79 | 0.90 |
| Per Capita Disposable Income Indices for Urban Households | 0.91 | 0.94 | 0.86 |
| General Price Index for Farm Products | 0.91 | 0.94 | 0.86 |
DownLoad:
CSV
According to Table 6, the first three factors influencing the cold chain logistics demand for agricultural products in Beijing and Tianjin are the proportion of tertiary industry, per capita disposable income indices for urban households and general price index for farm products. In Hebei, the GDP, fixed assets investment in transport and storage, and proportion of tertiary industry are the three major influential factors.
The results in Table 6 also indicate that the five influential factors selected in this study have significant effects on the cold chain logistics for agricultural products in Beijing, Tianjin and Hebei. This further displays that the economy, the supply to demand, the transportation capacity and people's living standards promote the development of cold chain logistics [41]. The ranking of influential factors does vary from region to region. Therefore, it is more relevant to forecast demand based on the influences of local differences.
To predict the main sequence, the prediction results for the relevant influential factors must first be obtained. In this section, the FGM (1, 1) model is used to predict the sequence of influential factors from 2021 to 2025, and the results are summarized in Tables 7–9.
| Year | Proportion of Tertiary Industry (%) | Per Capita Disposable Income Indices for Urban Households | General Price Index for Farm Products | |||
| Fitted Value | Error | Fitted Value | Error | Fitted Value | Error | |
| 2014 | 80.6 | 0.00 | 108.90 | 0.00 | 99.70 | 0.00 |
| 2015 | 89.94 | -2.66 | 115.43 | -4.95 | 98.70 | -1.10 |
| 2016 | 92.20 | 5.30 | 111.95 | 3.60 | 99.94 | 0.24 |
| 2017 | 90.48 | 0.98 | 109.41 | 0.45 | 102.01 | 2.41 |
| 2018 | 86.83 | -3.37 | 107.56 | -1.39 | 104.61 | 1.01 |
| 2019 | 82.31 | -7.29 | 106.13 | -2.49 | 107.61 | -2.29 |
| 2020 | 77.47 | 4.87 | 104.96 | 2.56 | 110.96 | 0.06 |
| MAPE | 4.09% | 1.99% | 0.98% | |||
| R2 | 0.62 | 0.74 | 0.92 | |||
| 2021 | 72.63 | 103.97 | 114.65 | |||
| 2022 | 67.96 | 103.12 | 118.68 | |||
| 2023 | 63.55 | 102.37 | 123.04 | |||
| 2024 | 59.46 | 101.70 | 127.74 | |||
| 2025 | 55.69 | 101.09 | 132.80 | |||
DownLoad:
CSV
| Year | Proportion of Tertiary Industry (%) | Per Capita Disposable Income Indices for Urban Households | General Price Index for Farm Products | |||
| Fitted Value | Error | Fitted Value | Error | Fitted Value | Error | |
| 2014 | 55.10 | 0.00 | 101.90 | 0.00 | 98.30 | 0.00 |
| 2015 | 57.20 | 0.00 | 101.70 | 0.00 | 98.66 | 0.86 |
| 2016 | 60.16 | -0.34 | 101.97 | -0.13 | 99.77 | -2.43 |
| 2017 | 61.96 | -0.04 | 102.16 | 0.06 | 101.00 | 0.00 |
| 2018 | 63.06 | 0.56 | 102.22 | 0.22 | 102.22 | 2.02 |
| 2019 | 63.71 | 0.21 | 102.17 | -0.53 | 103.39 | -0.31 |
| 2020 | 64.04 | -0.36 | 102.07 | 0.07 | 104.48 | -0.02 |
| MAPE | 0.34% | 0.14% | 0.80% | |||
| R2 | 0.99 | 0.62 | 0.73 | |||
| 2021 | 64.13 | 101.92 | 105.49 | |||
| 2022 | 64.05 | 101.75 | 106.42 | |||
| 2023 | 63.83 | 101.57 | 107.27 | |||
| 2024 | 63.51 | 101.39 | 108.06 | |||
| 2025 | 63.09 | 101.21 | 108.77 | |||
DownLoad:
CSV
| Year | GDP (108 yuan) |
Proportion of Tertiary Industry (%) |
Fixed Assets Investment in Transport and Storage (108 yuan) | |||
| Fitted Value | Error | Fitted Value | Error | Fitted Value | Error | |
| 2014 | 29421.20 | 0.00 | 37.30 | 0.00 | 2025.90 | 0.00 |
| 2015 | 30335.69 | 529.59 | 39.85 | -0.34 | 1923.93 | -111.77 |
| 2016 | 31860.05 | 32.15 | 42.48 | 0.77 | 2052.39 | -28.91 |
| 2017 | 33254.37 | -2709.63 | 45.01 | 3.19 | 2246.98 | 130.68 |
| 2018 | 34425.90 | 1931.29 | 47.41 | -2.60 | 2479.50 | -102.39 |
| 2019 | 35378.73 | 274.21 | 49.68 | -1.97 | 2741.73 | 95.30 |
| 2020 | 36138.11 | -68.79 | 51.81 | 0.08 | 3031.17 | -17.52 |
| MAPE | 2.33% | 2.78% | 3.03% | |||
| R2 | 0.76 | 0.91 | 0.95 | |||
| 2021 | 36732.57 | 53.82 | 3347.52 | |||
| 2022 | 37188.87 | 55.70 | 3691.55 | |||
| 2023 | 37530.56 | 57.47 | 4064.68 | |||
| 2024 | 37777.84 | 59.13 | 4468.73 | |||
| 2025 | 37947.74 | 60.69 | 4905.87 | |||
DownLoad:
CSV
According to Tables 7–9, the MAPE values of the simulation results for the first three influential factors for the agricultural products cold chain logistics in Beijing, Tianjin and Hebei are less than 5%. Furthermore, the R2 coefficient of determination values are also relatively high.
According to Table 1, if the MAPE value is less than 10%, the model's prediction accuracy is high, the prediction results are accurate and persuasive. As a result, it is reasonable to predict the influential factors using a FGM (1, 1) model.
In this section, the first three factors influencing the agricultural cold chain demand logistics in the Beijing-Tianjin-Hebei region are identified by grey correlation analysis. As a result, an FGM (1, 3) model with three related factor sequences is used for forecasting agricultural cold chain logistics demand in Beijing, Tianjin and Hebei. Besides, in order to validate the FGM (1, N) model's good performance in terms of forecasting accuracy and efficiency when reflecting the priority of new information, a comparison to the GM (1, N) model [25] is presented. Table 10 displays the comparison of the predicted fitting value and error results for the GM (1, 3) and FGM (1, 3) models.
| Year | Beijing | Tianjin | Hebei | |||
| GM (1, 3) | FGM (1, 3) | GM (1, 3) | FGM (1, 3) | GM (1, 3) | FGM (1, 3) | |
| 2014 | 744.79 | 744.79 | 332.35 | 332.35 | 798.44 | 798.44 |
| 2015 | 660.19 | 752.92 | 271.59 | 314.73 | 785.95 | 838.58 |
| 2016 | 896.37 | 786.22 | 363.92 | 359.78 | 1095.56 | 979.88 |
| 2017 | 840.02 | 836.34 | 361.28 | 365.01 | 1075.16 | 1044.88 |
| 2018 | 885.11 | 891.00 | 362.44 | 364.86 | 1172.99 | 1205.44 |
| 2019 | 985.07 | 948.01 | 373.93 | 375.67 | 1194.78 | 1246.31 |
| 2020 | 1030.47 | 1029.53 | 384.24 | 382.47 | 1303.27 | 1335.58 |
| MAPE | 4.7% | 1.26% | 4.19% | 2.79% | 5.51% | 4.57% |
| R2 | 0.777 | 0.988 | 0.545 | 0.762 | 0.904 | 0.972 |
DownLoad:
CSV
According to Table 10, the MAPE values of cold chain logistics demand for agricultural products in Beijing, Tianjin, and Hebei from 2021–2025, as predicted by the FGM (1, 3) model, are 1.26, 2.79 and 4.57%, respectively, and the R2 values are 0.988, 0.762 and 0.972, respectively, which are very close to 1. In comparison to the results in Table 1, the MAPE and R2 values for the two models meet the requirements, but the MAPE of FGM (1, 3) is much lower than that of GM (1, 3), and R2 is closer to 1. What's more, the growth rate of FGM (1, 3) is extremely consistent with the actual situation. In other words, the comparison indicates that the FGM (1, 3) model predicts future values better than the GM (1, 3) model. As a result, the FGM (1, 3) model is used to forecast the agricultural cold chain demand logistics in the Beijing-Tianjin-Hebei region from 2021 to 2025; the results are summarized in Table 11, and the corresponding trend chart is shown in Figure 2.
| Year | Beijing | Tianjin | Hebei |
| 2021 | 1108.98 | 383.33 | 1418.48 |
| 2022 | 1195.60 | 385.14 | 1509.67 |
| 2023 | 1288.25 | 386.15 | 1606.23 |
| 2024 | 1386.23 | 386.58 | 1708.47 |
| 2025 | 1488.85 | 386.37 | 1816.88 |
DownLoad:
CSV
According to the forecasting results, agricultural cold chain demand in Beijing-Tianjin-Hebei region could exceed 36 million tons in 2025, up from 18.75 million tons in 2014. As shown in Figure 2, the growth trends of demand for cold chain logistics for agricultural products in Beijing, Tianjin, and Hebei from 2011 to 2025 differ due to differences in economic, industrial, and population conditions. Among them, the cold chain logistics demand for agricultural products in Beijing and Hebei has been steadily increasing since 2017, and this high growth rate is expected to continue during the forecast period of 2021 to 2025. Although the demand in Tianjin fluctuated slightly between 2014 and 2020, the demand is predicted to remain flat and stable during the forecast period from 2021 to 2025, with a growth rate of nearly 0.
In general, Beijing and Tianjin have high consumption levels and a large floating population, which ensures a demand for fresh agricultural products [36]. At the same time, people's understanding of the health benefits of eating fresh agricultural products has gradually increased, fueling demand for cold chain logistics [42]. In the Beijing-Tianjin-Hebei region, Hebei is the primary producer of fresh agricultural products. At the same time, the general price index for farm products will continue to rise (Tables 7 and 8), which is also very consistent with China's current strategy of vigorously developing agricultural economy and Rural Revitalization [27]. Therefore, all of these factors will lead to a high claim for cold chain logistics in the Beijng-Tianjin-Hebei region. Furthermore, increasing the fixed assets investment in transport and storage in Hebei Province (Table 9) will promote a convenient transportation system, resulting in a more prosperous logistics industry in the Beijing-Tianjin-Hebei region [14]. As a result, government assistance in the construction of logistics networks in Hebei, such as roads and railways, will help to promote the integrated development of the cold chain logistics industry in the Beijing-Tianjin-Hebei region.
This paper analyzes the demand forecast and its influential factors based on the use of a grey model. A cold chain logistics demand forecast case study for agricultural products in Beijing, Tianjin and Hebei was conducted taking into account regional differences. The following conclusions can be made based on the above research. 1) There are many factors influencing the demand for cold chain logistics, but the main influential factors vary slightly from region to region. Identification of the main influential factors for each region can better respond to the needs of cold chain logistics. 2) The FGM (1, 3) model was successfully implemented to forecast based on the use of various input data demonstrating better performance than the GM (1, 3) model. 3) From 2021 to 2025, the agricultural cold chain logistics demand in Beijing and Hebei will continue to rise, while it will remain stable in Tianjin. According to the prediction results, Beijing, Tianjin and Hebei could take targeted measures based on their specific developing trends and influential factors.
The economic development of the different regions differs, and this inconsistency contributes to the cold chain logistics industry's low efficiency. Cold chain logistics, no matter how many regions are involved, should be seen as a unified system. Hence, a cold chain network, as so many other forms of logistics networks, should form a systematic and dynamic approach to achieve its objectives of meeting the demand with supply efficiently. Given the major factors influencing agricultural product cold chain logistics in Beijing, Tianjin, and Hebei, fully utilizing the comparative advantages of various regions and constructing an efficient agricultural product cold chain logistics system will contribute to the integrated development of the agricultural product cold chain logistics industry in Beijing, Tianjin and Hebei.
The limitations and future research direction of this work are listed as follows. First, though the fractional order accumulation model shows higher accuracy and stability of prediction in the application, there are not enough other cases to test the forecasting model; furthermore, it is suggested to adopt other intelligent optimization algorithms to search for more optimal values for the fractional order, which will improve forecast accuracy. Second, there was no assessment of influencing factors on cold chain logistics as comprehensively as possible, a certain criterion for systematic assessment of cold chain influencing factors is to set to select independent variables. Last but not least, one of the most crucial works is to build a simulation model by using a technique such as a system dynamics approach or discrete-event dynamic system, incorporating it into the forecast model. The incorporation with such techniques will not only provide a graphical visualization of a supply chain network and an analysis of system behavior, but it will also improve the management and prediction of how the disruption in a supply chain is propagated, which will improve the performance in terms of cost, quality and time, and thus the resilience of a supply chain network system [43,44].
This paper was supported by a Research Project on Human Resources and Social Security in Hebei Province grant (JRSHZ-2022-02079), and a Social Science Grand Research of Hebei Education Department (ZD202105). The authors also gratefully acknowledge the helpful comments and suggestions of the reviewers, which have improved the presentation.
The research data used to support the findings of this study are included within the article, the data used are shown in Tables 2–5.
The authors declare no conflicts of interest.
| [1] | I. T. Jolliffe, J. Cadima, in Principal component analysis: a review and recent developments, Philosophical transactions of the Royal Society A: Mathematical, Physical and Engineering Sciences, 374 (2016), 20150202. https://doi.org/10.1098/rsta.2015.0202 |
| [2] | R. O. Duda, P. E. Hart, Pattern Classification, John Wiley & Sons, 2006. |
| [3] | A. Gersho, R. M. Gray, Vector Quantization and Signal Compression, Springer Science & Business Media, 2012. |
| [4] | D. Seung, L. Lee, Algorithms for non-negative matrix factorization, Adv. Neural Inf. Process. Syst., 13 (2001), 556–562. |
| [5] |
D. Li, S. Zhang, X. Ma, Dynamic module detection in temporal attributed networks of cancers, IEEE/ACM Trans. Comput. Biol. Bioinf., 19 (2021), 2219–2230. https://doi.org/10.1109/TCBB.2021.3069441 doi: 10.1109/TCBB.2021.3069441
|
| [6] |
Z. Zhao, Z. Ke, Z. Gou, H. Guo, K. Jiang, R. Zhang, The trade-off between topology and content in community detection: An adaptive encoder–decoder-based nmf approach, Expert Syst. Appl., 209 (2022), 118230. https://doi.org/10.1016/j.eswa.2022.118230 doi: 10.1016/j.eswa.2022.118230
|
| [7] |
N. Yu, M. J. Wu, J. X. Liu, C. H. Zheng, Y. Xu, Correntropy-based hypergraph regularized nmf for clustering and feature selection on multi-cancer integrated data, IEEE Trans. Cybern., 51 (2020), 3952–3963. https://doi.org/10.1109/TCYB.2020.3000799 doi: 10.1109/TCYB.2020.3000799
|
| [8] | N. Yu, Y. L. Gao, J. X. Liu, J. Wang, J. Shang, Hypergraph regularized nmf by l 2, 1-norm for clustering and com-abnormal expression genes selection, in 2018 IEEE International Conference on Bioinformatics and Biomedicine (BIBM), (2018), 578–582. |
| [9] |
M. Venkatasubramanian, K. Chetal, D. J. Schnell, G. Atluri, N. Salomonis, Resolving single-cell heterogeneity from hundreds of thousands of cells through sequential hybrid clustering and nmf, Bioinformatics, 36 (2020), 3773–3780. https://doi.org/10.1093/bioinformatics/btaa201 doi: 10.1093/bioinformatics/btaa201
|
| [10] |
W. Wu, X. Ma, Network-based structural learning nonnegative matrix factorization algorithm for clustering of scrna-seq data, IEEE/ACM Trans. Comput. Biol. Bioinf., 20 (2022), 566–575. https://doi.org/10.1038/s41579-022-00790-1 doi: 10.1038/s41579-022-00790-1
|
| [11] | R. Egger, J. Yu, A topic modeling comparison between lda, nmf, top2vec, and bertopic to demystify twitter posts, Front. Soc., 7 (2022). |
| [12] |
H. Che, J. Wang, Nonnegative matrix factorization algorithm based on a discrete-time projection neural network, Neural Networks, 103 (2018), 63–71. https://doi.org/10.1016/j.neunet.2018.03.003 doi: 10.1016/j.neunet.2018.03.003
|
| [13] | H. Che, J. Wang, A. Cichocki, Bicriteria sparse nonnegative matrix factorization via two-timescale duplex neurodynamic optimization, IEEE Trans. Neural Networks Learn. Syst., 2021 (2021). |
| [14] |
H. Che, J. Wang, A two-timescale duplex neurodynamic approach to mixed-integer optimization, IEEE Trans. Neural Networks Learn. Syst., 32 (2020), 36–48. https://doi.org/10.1109/TNNLS.2020.2973760 doi: 10.1109/TNNLS.2020.2973760
|
| [15] | X. Ma, W. Zhao, W. Wu, Layer-specific modules detection in cancer multi-layer networks, IEEE/ACM Trans. Comput. Biol. Bioinf., 2022 (2022). |
| [16] | S. Wang, A. Huang, Penalized nonnegative matrix tri-factorization for co-clustering, Expert Syst. Appl., 78 (2017), 64–73. |
| [17] |
F. Shang, L. Jiao, F. Wang, Graph dual regularization non-negative matrix factorization for co-clustering, Pattern Recognit., 45 (2012), 2237–2250. https://doi.org/10.1016/j.patcog.2011.12.015 doi: 10.1016/j.patcog.2011.12.015
|
| [18] | C. Ding, T. Li, W. Peng, H. Park, Orthogonal nonnegative matrix t-factorizations for clustering, in Proceedings of the 12th ACM SIGKDD International Conference on Knowledge Discovery and Data Mining, (2006), 126–135. |
| [19] | J. Li, H. Che, X. Liu, Circuit design and analysis of smoothed l0 norm approximation for sparse signal reconstruction, Circuits Syst. Signal Process., (2022), 1–25. |
| [20] |
X. Ju, H. Che, C. Li, X. He, Solving mixed variational inequalities via a proximal neurodynamic network with applications, Neural Process. Lett., 54 (2022), 207–226. https://doi.org/10.1007/s11063-021-10628-1 doi: 10.1007/s11063-021-10628-1
|
| [21] |
H. Che, J. Wang, A collaborative neurodynamic approach to global and combinatorial optimization, Neural Networks, 114 (2019), 15–27. https://doi.org/10.1016/j.neunet.2019.02.002 doi: 10.1016/j.neunet.2019.02.002
|
| [22] |
X. Ju, H. Che, C. Li, X. He, G. Feng, Exponential convergence of a proximal projection neural network for mixed variational inequalities and applications, Neurocomputing, 454 (2021), 54–64. https://doi.org/10.1016/j.neucom.2021.04.059 doi: 10.1016/j.neucom.2021.04.059
|
| [23] |
C. Dai, H. Che, M.-F. Leung, A neurodynamic optimization approach for l 1 minimization with application to compressed image reconstruction, Int. J. Artif. Intell. Tools, 30 (2021), 2140007. https://doi.org/10.1142/S0218213021400078 doi: 10.1142/S0218213021400078
|
| [24] |
H. Che, J. Wang, A. Cichocki, Sparse signal reconstruction via collaborative neurodynamic optimization, Neural Networks, 154 (2022), 255–269. https://doi.org/10.1016/j.neunet.2022.07.018 doi: 10.1016/j.neunet.2022.07.018
|
| [25] | H. Che, J. Wang, A. Cichocki, Neurodynamics-based iteratively reweighted convex optimization for sparse signal reconstruction, in 2022 12th International Conference on Information Science and Technology (ICIST), IEEE, (2022), 45–51. |
| [26] |
Y. Wang, J. Wang, H. Che, Two-timescale neurodynamic approaches to supervised feature selection based on alternative problem formulations, Neural Networks, 142 (2021), 180–191. https://doi.org/10.1016/j.neunet.2021.04.038 doi: 10.1016/j.neunet.2021.04.038
|
| [27] | X. Ju, C. Li, H. Che, X. He, G. Feng, A proximal neurodynamic network with fixed-time convergence for equilibrium problems and its applications, IEEE Trans. Neural Networks Learn. Syst., 2022 (2022). |
| [28] |
F. Shang, L. Jiao, J. Shi, J. Chai, Robust positive semidefinite l-isomap ensemble, Pattern Recognit. Lett., 32 (2011), 640–649. https://doi.org/10.1016/j.patrec.2010.12.005 doi: 10.1016/j.patrec.2010.12.005
|
| [29] | M. Belkin, P. Niyogi, V. Sindhwani, Manifold regularization: A geometric framework for learning from labeled and unlabeled examples., J. Mach. Learn. Res., 7 (2006). |
| [30] | K. Chen, H. Che, X. Li, M. F. Leung, Graph non-negative matrix factorization with alternative smoothed l0 regularizations, Neural Comput. Appl., 2022 (2022), 1–15. |
| [31] | X. Yang, H. Che, M. F. Leung, C. Liu, Adaptive graph nonnegative matrix factorization with the self-paced regularization, Appl. Intell., 2022 (2022), 1–18. |
| [32] |
Z. Huang, Y. Wang, X. Ma, Clustering of cancer attributed networks by dynamically and jointly factorizing multi-layer graphs, IEEE/ACM Trans. Comput. Biol. Bioinf., 19 (2021), 2737–2748. https://doi.org/10.1137/19M1301746 doi: 10.1137/19M1301746
|
| [33] |
J. B. Tenenbaum, V. d. Silva, J. C. Langford, A global geometric framework for nonlinear dimensionality reduction, Science, 290 (2000), 2319–2323. https://doi.org/10.1126/science.290.5500.2319 doi: 10.1126/science.290.5500.2319
|
| [34] | M. Belkin, P. Niyogi, Laplacian eigenmaps and spectral techniques for embedding and clustering, Adv. Neural Inf. Process. Syst., 14 (2001). |
| [35] | D. Cai, X. He, J. Han, T. S. Huang, Graph regularized nonnegative matrix factorization for data representation, IEEE Trans. Pattern Anal. Mach. Intell., 33 (2010), 1548–1560. |
| [36] | D. Zhou, J. Huang, B. Schölkopf, Learning with hypergraphs: Clustering, classification, and embedding, Adv. Neural Inf. Process. Syst., 19 (2006). |
| [37] | J. Yu, D. Tao, M. Wang, Adaptive hypergraph learning and its application in image classification, IEEE Trans. Image Process., 21 (2012), 3262–3272. |
| [38] |
P. Zhou, X. Wang, L. Du, X. Li, Clustering ensemble via structured hypergraph learning, Inf. Fusion, 78 (2022), 171–179. https://doi.org/10.1016/j.inffus.2021.09.003 doi: 10.1016/j.inffus.2021.09.003
|
| [39] | L. Xia, C. Huang, Y. Xu, J. Zhao, D. Yin, J. Huang, Hypergraph contrastive collaborative filtering, in Proceedings of the 45th International ACM SIGIR Conference on Research and Development in Information Retrieval, (2022), 70–79. |
| [40] | Y. Feng, H. You, Z. Zhang, R. Ji, Y. Gao, Hypergraph neural networks, in Proceedings of the AAAI Conference on Artificial Intelligence, 33 (2019), 3558–3565. https://doi.org/10.1609/aaai.v33i01.33013558 |
| [41] | J. Jiang, Y. Wei, Y. Feng, J. Cao, Y. Gao, Dynamic hypergraph neural networks, in International Joint Conference on Artificial Intelligence, (2019), 2635–2641. |
| [42] | X. Liao, Y. Xu, H. Ling, Hypergraph neural networks for hypergraph matching, in Proceedings of the IEEE/CVF International Conference on Computer Vision, (2021), 1266–1275. |
| [43] |
K. Zeng, J. Yu, C. Li, J. You, T. Jin, Image clustering by hyper-graph regularized non-negative matrix factorization, Neurocomputing, 138 (2014), 209–217. https://doi.org/10.1016/j.neucom.2014.01.043 doi: 10.1016/j.neucom.2014.01.043
|
| [44] | L. Du, X. Li, Y. D. Shen, Robust nonnegative matrix factorization via half-quadratic minimization, in 2012 IEEE 12th International Conference on Data Mining, (2012), 201–210. |
| [45] | D. Kong, C. Ding, H. Huang, Robust nonnegative matrix factorization using l21-norm, in Proceedings of the 20th ACM International Conference on Information and Knowledge Management, (2011), 673–682. https://doi.org/10.3917/ag.682.0673 |
| [46] | H. Gao, F. Nie, W. Cai, H. Huang, Robust capped norm nonnegative matrix factorization: Capped norm nmf, in Proceedings of the 24th ACM International on Conference on Information and Knowledge Management, 2015 2015,871–880. |
| [47] |
Z. Li, J. Tang, X. He, Robust structured nonnegative matrix factorization for image representation, IEEE Trans. Neural Networks Learn. Syst., 29 (2017), 1947–1960. https://doi.org/10.1109/TNNLS.2017.2691725 doi: 10.1109/TNNLS.2017.2691725
|
| [48] | N. Guan, T. Liu, Y. Zhang, D. Tao, L. S. Davis, Truncated cauchy non-negative matrix factorization, IEEE Trans. Pattern Anal. Mach. Intell., 41 (2017), 246–259. |
| [49] | N. Guan, D. Tao, Z. Luo, J. Shawe-Taylor, Mahnmf: Manhattan non-negative matrix factorization, Statics, 1050 (2012), 14. |
| [50] |
S. Peng, W. Ser, B. Chen, Z. Lin, Robust orthogonal nonnegative matrix tri-factorization for data representation, Knowl. Based Syst., 201 (2020), 106054. https://doi.org/10.1016/j.knosys.2020.106054 doi: 10.1016/j.knosys.2020.106054
|
| [51] |
C. Y. Wang, N. Yu, M. J. Wu, Y. L. Gao, J. X. Liu, J. Wang, Dual hyper-graph regularized supervised nmf for selecting differentially expressed genes and tumor classification, IEEE/ACM Trans. Comput. Biol. Bioinf., 18 (2020), 2375–2383. https://doi.org/10.1109/TCBB.2020.2975173 doi: 10.1109/TCBB.2020.2975173
|
| [52] | L. Lovász, M. D. Plummer, Matching theory, American Mathematical Society, 2009. https://doi.org/10.1090/chel/367 |
| [53] |
X. Gao, X. Ma, W. Zhang, J. Huang, H. Li, Y. Li, J. Cui, Multi-view clustering with self-representation and structural constraint, IEEE Trans. Big Data, 8 (2021), 882–893. https://doi.org/10.1109/TBDATA.2021.3128906 doi: 10.1109/TBDATA.2021.3128906
|
| [54] | C. Liu, W. Cao, S. Wu, W. Shen, D. Jiang, Z. Yu, H.-S. Wong, Supervised graph clustering for cancer subtyping based on survival analysis and integration of multi-omic tumor data, IEEE/ACM Trans. Comput. Biol. Bioinf., 19 (2020), 1193–1202. |
| [55] | C. Liu, S. Wu, R. Li, D. Jiang, H. S. Wong, Self-supervised graph completion for incomplete multi-view clustering, IEEE Trans. Knowl. Data Eng., 2023 (2023), forthcoming. |
| [56] | C. Liu, R. Li, S. Wu, H. Che, D. Jiang, Z. Yu, H.-S. Wong, Self-guided partial graph propagation for incomplete multiview clustering, IEEE Trans. Neural Networks Learn. Syst., 2023 (2023). |
| [57] | C. Li, H. Che, M. F. Leung, C. Liu, Z. Yan, Robust multi-view non-negative matrix factorization with adaptive graph and diversity constraints, Inf. Sci., 2023 (2023). |
| [58] | B. Pan, C. Li, H. Che, Nonconvex low-rank tensor approximation with graph and consistent regularizations for multi-view subspace learning, Neural Networks, 161 (2023), 638–658. |
| [59] | S. Wang, Z. Chen, S. Du, Z. Lin, Learning deep sparse regularizers with applications to multi-view clustering and semi-supervised classification, IEEE Trans. Pattern Anal. Mach. Intell., 44 (2021), 5042–5055. |
| [60] |
S. Du, Z. Liu, Z. Chen, W. Yang, S. Wang, Differentiable bi-sparse multi-view co-clustering, IEEE Trans. Signal Process., 69 (2021), 4623–4636. https://doi.org/10.1109/TSP.2021.3101979 doi: 10.1109/TSP.2021.3101979
|
| [61] |
S. Wang, X. Lin, Z. Fang, S. Du, G. Xiao, Contrastive consensus graph learning for multi-view clustering, IEEE/CAA J. Autom. Sin., 9 (2022), 2027–2030. https://doi.org/10.1109/JAS.2022.105959 doi: 10.1109/JAS.2022.105959
|
| [62] | Z. Fang, S. Du, X. Lin, J. Yang, S. Wang, Y. Shi, Dbo-net: Differentiable bi-level optimization network for multi-view clustering, Inf. Sci., 2023 (2023). |
| 1. | Justin Eilertsen, Santiago Schnell, Sebastian Walcher, On the anti-quasi-steady-state conditions of enzyme kinetics, 2022, 350, 00255564, 108870, 10.1016/j.mbs.2022.108870 | |
| 2. | Lambertus A. Peletier, Johan Gabrielsson, Impact of enzyme turnover on the dynamics of the Michaelis–Menten model, 2022, 346, 00255564, 108795, 10.1016/j.mbs.2022.108795 | |
| 3. | Justin Eilertsen, Kashvi Srivastava, Santiago Schnell, Stochastic enzyme kinetics and the quasi-steady-state reductions: Application of the slow scale linear noise approximation à la Fenichel, 2022, 85, 0303-6812, 10.1007/s00285-022-01768-6 | |
| 4. | Justin Eilertsen, Malgorzata Anna Tyczynska, Santiago Schnell, Hunting ε: The Origin and Validity of Quasi-Steady-State Reductions in Enzyme Kinetics, 2021, 20, 1536-0040, 2450, 10.1137/20M135073X | |
| 5. | Marc R. Roussel, Moisés Santillán, Biochemical Problems, Mathematical Solutions, 2022, 7, 2473-6988, 5662, 10.3934/math.2022313 | |
| 6. | Justin Eilertsen, Santiago Schnell, On the Validity of the Stochastic Quasi-Steady-State Approximation in Open Enzyme Catalyzed Reactions: Timescale Separation or Singular Perturbation?, 2022, 84, 0092-8240, 10.1007/s11538-021-00966-5 | |
| 7. | Justin Eilertsen, Santiago Schnell, Sebastian Walcher, Rigorous estimates for the quasi-steady state approximation of the Michaelis–Menten reaction mechanism at low enzyme concentrations, 2024, 78, 14681218, 104088, 10.1016/j.nonrwa.2024.104088 | |
| 8. | P. F. Zhuk, S. O. Karakhim, Two different types of kinetics, where the initial rate increases faster or slower than the reactant concentration, can coexist on bell-shaped kinetic dependencies, 2023, 61, 0259-9791, 1758, 10.1007/s10910-023-01491-7 | |
| 9. | Roktaek Lim, Thomas L. P. Martin, Junghun Chae, Woo Joong Kim, Cheol-Min Ghim, Pan-Jun Kim, Pedro Mendes, Generalized Michaelis–Menten rate law with time-varying molecular concentrations, 2023, 19, 1553-7358, e1011711, 10.1371/journal.pcbi.1011711 | |
| 10. | Daniel R. Reynolds, 2024, 9780323917469, 31, 10.1016/B978-0-32-391746-9.00010-9 | |
| 11. | Justin Eilertsen, Santiago Schnell, Sebastian Walcher, Natural Parameter Conditions for Singular Perturbations of Chemical and Biochemical Reaction Networks, 2023, 85, 0092-8240, 10.1007/s11538-023-01150-7 |
Figures(8) / Tables(7)
Jiyang Yu, Baicheng Pan, Shanshan Yu, Man-Fai Leung. Robust capped norm dual hyper-graph regularized non-negative matrix tri-factorization[J]. Mathematical Biosciences and Engineering, 2023, 20(7): 12486-12509. doi: 10.3934/mbe.2023556
| MAPE | Prediction Ability |
| < 10% | Good |
| 10%-20% | Qualified |
| 20%-50% | Barely enough |
| > 50% | Unqualified |
DownLoad:
CSV
| Year | GDP(108 yuan) | Proportion of Tertiary Industry(%) | Fixed Assets Investment in Transport and Storage(108 yuan) | Per Capita Disposable Income Indices for Urban Households | General Price Index for Farm Products |
| 2014 | 22926 | 80.6 | 756.5 | 108.9 | 99.7 |
| 2015 | 24779.1 | 92.6 | 827 | 120.38 | 99.8 |
| 2016 | 27041.2 | 86.9 | 973 | 108.35 | 99.7 |
| 2017 | 29883 | 89.5 | 1327 | 108.96 | 99.6 |
| 2018 | 33106 | 90.2 | 1341.6 | 108.95 | 103.6 |
| 2019 | 35445.1 | 89.6 | 1218.17 | 108.62 | 109.9 |
| 2020 | 36102.6 | 72.6 | 1093.92 | 102.4 | 110.9 |
DownLoad:
CSV
| Year | GDP(108 yuan) | Proportion of Tertiary Industry(%) | Fixed Assets Investment in Transport and Storage(108 yuan) | Per Capita Disposable Income Indices for Urban Households | General Price Index for Farm Products |
| 2014 | 10640.62 | 55.1 | 769.71 | 101.9 | 98.3 |
| 2015 | 10879.51 | 57.2 | 860.77 | 101.7 | 97.8 |
| 2016 | 11477.2 | 60.5 | 787.5 | 102.1 | 102.2 |
| 2017 | 12450.56 | 62 | 670.95 | 102.1 | 101 |
| 2018 | 13362.92 | 62.5 | 621.3 | 102 | 100.2 |
| 2019 | 14055.46 | 63.5 | 784.7 | 102.7 | 103.7 |
| 2020 | 14083.73 | 64.4 | 1079.75 | 102 | 104.5 |
DownLoad:
CSV
| Year | GDP(108 yuan) | Proportion of Tertiary Industry(%) | Fixed Assets Investment in Transport and Storage(108 yuan) | Per Capita Disposable Income Indices for Urban Households | General Price Index for Farm Products |
| 2014 | 29421.2 | 37.30 | 2025.90 | 108.61 | 100.23 |
| 2015 | 29806.1 | 40.19 | 2035.70 | 108.33 | 97.5 |
| 2016 | 31827.9 | 41.71 | 2081.30 | 106.33 | 96.35 |
| 2017 | 36964 | 41.82 | 2116.30 | 108.14 | 96.19 |
| 2018 | 32494.61 | 50.01 | 2581.89 | 107.95 | 104.65 |
| 2019 | 35104.52 | 51.65 | 2646.43 | 117.02 | 101 |
| 2020 | 36206.9 | 51.73 | 3048.69 | 126.38 | 113.67 |
DownLoad:
CSV
| Year | Beijing | Tianjin | Hebei |
| 2014 | 744.79 | 332.35 | 798.44 |
| 2015 | 765.2 | 339.42 | 845.2 |
| 2016 | 793.67 | 353.15 | 980.5 |
| 2017 | 816.34 | 358.02 | 974.4 |
| 2018 | 893.89 | 367.90 | 1094.78 |
| 2019 | 965.4 | 367.68 | 1187.84 |
| 2020 | 1033.95 | 392.82 | 1280.49 |
DownLoad:
CSV
| Influencing Factors | Grey Relation Degree | ||
| Beijing | Tianjin | Hebei | |
| GDP | 0.86 | 0.91 | 0.94 |
| Proportion of Tertiary Industry | 0.92 | 0.96 | 0.87 |
| Fixed Assets Investment in Transport and Storage | 0.65 | 0.79 | 0.90 |
| Per Capita Disposable Income Indices for Urban Households | 0.91 | 0.94 | 0.86 |
| General Price Index for Farm Products | 0.91 | 0.94 | 0.86 |
DownLoad:
CSV
| Year | Proportion of Tertiary Industry (%) | Per Capita Disposable Income Indices for Urban Households | General Price Index for Farm Products | |||
| Fitted Value | Error | Fitted Value | Error | Fitted Value | Error | |
| 2014 | 80.6 | 0.00 | 108.90 | 0.00 | 99.70 | 0.00 |
| 2015 | 89.94 | -2.66 | 115.43 | -4.95 | 98.70 | -1.10 |
| 2016 | 92.20 | 5.30 | 111.95 | 3.60 | 99.94 | 0.24 |
| 2017 | 90.48 | 0.98 | 109.41 | 0.45 | 102.01 | 2.41 |
| 2018 | 86.83 | -3.37 | 107.56 | -1.39 | 104.61 | 1.01 |
| 2019 | 82.31 | -7.29 | 106.13 | -2.49 | 107.61 | -2.29 |
| 2020 | 77.47 | 4.87 | 104.96 | 2.56 | 110.96 | 0.06 |
| MAPE | 4.09% | 1.99% | 0.98% | |||
| R2 | 0.62 | 0.74 | 0.92 | |||
| 2021 | 72.63 | 103.97 | 114.65 | |||
| 2022 | 67.96 | 103.12 | 118.68 | |||
| 2023 | 63.55 | 102.37 | 123.04 | |||
| 2024 | 59.46 | 101.70 | 127.74 | |||
| 2025 | 55.69 | 101.09 | 132.80 | |||
DownLoad:
CSV
| Year | Proportion of Tertiary Industry (%) | Per Capita Disposable Income Indices for Urban Households | General Price Index for Farm Products | |||
| Fitted Value | Error | Fitted Value | Error | Fitted Value | Error | |
| 2014 | 55.10 | 0.00 | 101.90 | 0.00 | 98.30 | 0.00 |
| 2015 | 57.20 | 0.00 | 101.70 | 0.00 | 98.66 | 0.86 |
| 2016 | 60.16 | -0.34 | 101.97 | -0.13 | 99.77 | -2.43 |
| 2017 | 61.96 | -0.04 | 102.16 | 0.06 | 101.00 | 0.00 |
| 2018 | 63.06 | 0.56 | 102.22 | 0.22 | 102.22 | 2.02 |
| 2019 | 63.71 | 0.21 | 102.17 | -0.53 | 103.39 | -0.31 |
| 2020 | 64.04 | -0.36 | 102.07 | 0.07 | 104.48 | -0.02 |
| MAPE | 0.34% | 0.14% | 0.80% | |||
| R2 | 0.99 | 0.62 | 0.73 | |||
| 2021 | 64.13 | 101.92 | 105.49 | |||
| 2022 | 64.05 | 101.75 | 106.42 | |||
| 2023 | 63.83 | 101.57 | 107.27 | |||
| 2024 | 63.51 | 101.39 | 108.06 | |||
| 2025 | 63.09 | 101.21 | 108.77 | |||
DownLoad:
CSV
| Year | GDP (108 yuan) |
Proportion of Tertiary Industry (%) |
Fixed Assets Investment in Transport and Storage (108 yuan) | |||
| Fitted Value | Error | Fitted Value | Error | Fitted Value | Error | |
| 2014 | 29421.20 | 0.00 | 37.30 | 0.00 | 2025.90 | 0.00 |
| 2015 | 30335.69 | 529.59 | 39.85 | -0.34 | 1923.93 | -111.77 |
| 2016 | 31860.05 | 32.15 | 42.48 | 0.77 | 2052.39 | -28.91 |
| 2017 | 33254.37 | -2709.63 | 45.01 | 3.19 | 2246.98 | 130.68 |
| 2018 | 34425.90 | 1931.29 | 47.41 | -2.60 | 2479.50 | -102.39 |
| 2019 | 35378.73 | 274.21 | 49.68 | -1.97 | 2741.73 | 95.30 |
| 2020 | 36138.11 | -68.79 | 51.81 | 0.08 | 3031.17 | -17.52 |
| MAPE | 2.33% | 2.78% | 3.03% | |||
| R2 | 0.76 | 0.91 | 0.95 | |||
| 2021 | 36732.57 | 53.82 | 3347.52 | |||
| 2022 | 37188.87 | 55.70 | 3691.55 | |||
| 2023 | 37530.56 | 57.47 | 4064.68 | |||
| 2024 | 37777.84 | 59.13 | 4468.73 | |||
| 2025 | 37947.74 | 60.69 | 4905.87 | |||
DownLoad:
CSV
| Year | Beijing | Tianjin | Hebei | |||
| GM (1, 3) | FGM (1, 3) | GM (1, 3) | FGM (1, 3) | GM (1, 3) | FGM (1, 3) | |
| 2014 | 744.79 | 744.79 | 332.35 | 332.35 | 798.44 | 798.44 |
| 2015 | 660.19 | 752.92 | 271.59 | 314.73 | 785.95 | 838.58 |
| 2016 | 896.37 | 786.22 | 363.92 | 359.78 | 1095.56 | 979.88 |
| 2017 | 840.02 | 836.34 | 361.28 | 365.01 | 1075.16 | 1044.88 |
| 2018 | 885.11 | 891.00 | 362.44 | 364.86 | 1172.99 | 1205.44 |
| 2019 | 985.07 | 948.01 | 373.93 | 375.67 | 1194.78 | 1246.31 |
| 2020 | 1030.47 | 1029.53 | 384.24 | 382.47 | 1303.27 | 1335.58 |
| MAPE | 4.7% | 1.26% | 4.19% | 2.79% | 5.51% | 4.57% |
| R2 | 0.777 | 0.988 | 0.545 | 0.762 | 0.904 | 0.972 |
DownLoad:
CSV
| Year | Beijing | Tianjin | Hebei |
| 2021 | 1108.98 | 383.33 | 1418.48 |
| 2022 | 1195.60 | 385.14 | 1509.67 |
| 2023 | 1288.25 | 386.15 | 1606.23 |
| 2024 | 1386.23 | 386.58 | 1708.47 |
| 2025 | 1488.85 | 386.37 | 1816.88 |
DownLoad:
CSV
| MAPE | Prediction Ability |
| < 10% | Good |
| 10%-20% | Qualified |
| 20%-50% | Barely enough |
| > 50% | Unqualified |
| Year | GDP(108 yuan) | Proportion of Tertiary Industry(%) | Fixed Assets Investment in Transport and Storage(108 yuan) | Per Capita Disposable Income Indices for Urban Households | General Price Index for Farm Products |
| 2014 | 22926 | 80.6 | 756.5 | 108.9 | 99.7 |
| 2015 | 24779.1 | 92.6 | 827 | 120.38 | 99.8 |
| 2016 | 27041.2 | 86.9 | 973 | 108.35 | 99.7 |
| 2017 | 29883 | 89.5 | 1327 | 108.96 | 99.6 |
| 2018 | 33106 | 90.2 | 1341.6 | 108.95 | 103.6 |
| 2019 | 35445.1 | 89.6 | 1218.17 | 108.62 | 109.9 |
| 2020 | 36102.6 | 72.6 | 1093.92 | 102.4 | 110.9 |
| Year | GDP(108 yuan) | Proportion of Tertiary Industry(%) | Fixed Assets Investment in Transport and Storage(108 yuan) | Per Capita Disposable Income Indices for Urban Households | General Price Index for Farm Products |
| 2014 | 10640.62 | 55.1 | 769.71 | 101.9 | 98.3 |
| 2015 | 10879.51 | 57.2 | 860.77 | 101.7 | 97.8 |
| 2016 | 11477.2 | 60.5 | 787.5 | 102.1 | 102.2 |
| 2017 | 12450.56 | 62 | 670.95 | 102.1 | 101 |
| 2018 | 13362.92 | 62.5 | 621.3 | 102 | 100.2 |
| 2019 | 14055.46 | 63.5 | 784.7 | 102.7 | 103.7 |
| 2020 | 14083.73 | 64.4 | 1079.75 | 102 | 104.5 |
| Year | GDP(108 yuan) | Proportion of Tertiary Industry(%) | Fixed Assets Investment in Transport and Storage(108 yuan) | Per Capita Disposable Income Indices for Urban Households | General Price Index for Farm Products |
| 2014 | 29421.2 | 37.30 | 2025.90 | 108.61 | 100.23 |
| 2015 | 29806.1 | 40.19 | 2035.70 | 108.33 | 97.5 |
| 2016 | 31827.9 | 41.71 | 2081.30 | 106.33 | 96.35 |
| 2017 | 36964 | 41.82 | 2116.30 | 108.14 | 96.19 |
| 2018 | 32494.61 | 50.01 | 2581.89 | 107.95 | 104.65 |
| 2019 | 35104.52 | 51.65 | 2646.43 | 117.02 | 101 |
| 2020 | 36206.9 | 51.73 | 3048.69 | 126.38 | 113.67 |
| Year | Beijing | Tianjin | Hebei |
| 2014 | 744.79 | 332.35 | 798.44 |
| 2015 | 765.2 | 339.42 | 845.2 |
| 2016 | 793.67 | 353.15 | 980.5 |
| 2017 | 816.34 | 358.02 | 974.4 |
| 2018 | 893.89 | 367.90 | 1094.78 |
| 2019 | 965.4 | 367.68 | 1187.84 |
| 2020 | 1033.95 | 392.82 | 1280.49 |
| Influencing Factors | Grey Relation Degree | ||
| Beijing | Tianjin | Hebei | |
| GDP | 0.86 | 0.91 | 0.94 |
| Proportion of Tertiary Industry | 0.92 | 0.96 | 0.87 |
| Fixed Assets Investment in Transport and Storage | 0.65 | 0.79 | 0.90 |
| Per Capita Disposable Income Indices for Urban Households | 0.91 | 0.94 | 0.86 |
| General Price Index for Farm Products | 0.91 | 0.94 | 0.86 |
| Year | Proportion of Tertiary Industry (%) | Per Capita Disposable Income Indices for Urban Households | General Price Index for Farm Products | |||
| Fitted Value | Error | Fitted Value | Error | Fitted Value | Error | |
| 2014 | 80.6 | 0.00 | 108.90 | 0.00 | 99.70 | 0.00 |
| 2015 | 89.94 | -2.66 | 115.43 | -4.95 | 98.70 | -1.10 |
| 2016 | 92.20 | 5.30 | 111.95 | 3.60 | 99.94 | 0.24 |
| 2017 | 90.48 | 0.98 | 109.41 | 0.45 | 102.01 | 2.41 |
| 2018 | 86.83 | -3.37 | 107.56 | -1.39 | 104.61 | 1.01 |
| 2019 | 82.31 | -7.29 | 106.13 | -2.49 | 107.61 | -2.29 |
| 2020 | 77.47 | 4.87 | 104.96 | 2.56 | 110.96 | 0.06 |
| MAPE | 4.09% | 1.99% | 0.98% | |||
| R2 | 0.62 | 0.74 | 0.92 | |||
| 2021 | 72.63 | 103.97 | 114.65 | |||
| 2022 | 67.96 | 103.12 | 118.68 | |||
| 2023 | 63.55 | 102.37 | 123.04 | |||
| 2024 | 59.46 | 101.70 | 127.74 | |||
| 2025 | 55.69 | 101.09 | 132.80 | |||
| Year | Proportion of Tertiary Industry (%) | Per Capita Disposable Income Indices for Urban Households | General Price Index for Farm Products | |||
| Fitted Value | Error | Fitted Value | Error | Fitted Value | Error | |
| 2014 | 55.10 | 0.00 | 101.90 | 0.00 | 98.30 | 0.00 |
| 2015 | 57.20 | 0.00 | 101.70 | 0.00 | 98.66 | 0.86 |
| 2016 | 60.16 | -0.34 | 101.97 | -0.13 | 99.77 | -2.43 |
| 2017 | 61.96 | -0.04 | 102.16 | 0.06 | 101.00 | 0.00 |
| 2018 | 63.06 | 0.56 | 102.22 | 0.22 | 102.22 | 2.02 |
| 2019 | 63.71 | 0.21 | 102.17 | -0.53 | 103.39 | -0.31 |
| 2020 | 64.04 | -0.36 | 102.07 | 0.07 | 104.48 | -0.02 |
| MAPE | 0.34% | 0.14% | 0.80% | |||
| R2 | 0.99 | 0.62 | 0.73 | |||
| 2021 | 64.13 | 101.92 | 105.49 | |||
| 2022 | 64.05 | 101.75 | 106.42 | |||
| 2023 | 63.83 | 101.57 | 107.27 | |||
| 2024 | 63.51 | 101.39 | 108.06 | |||
| 2025 | 63.09 | 101.21 | 108.77 | |||
| Year | GDP (108 yuan) |
Proportion of Tertiary Industry (%) |
Fixed Assets Investment in Transport and Storage (108 yuan) | |||
| Fitted Value | Error | Fitted Value | Error | Fitted Value | Error | |
| 2014 | 29421.20 | 0.00 | 37.30 | 0.00 | 2025.90 | 0.00 |
| 2015 | 30335.69 | 529.59 | 39.85 | -0.34 | 1923.93 | -111.77 |
| 2016 | 31860.05 | 32.15 | 42.48 | 0.77 | 2052.39 | -28.91 |
| 2017 | 33254.37 | -2709.63 | 45.01 | 3.19 | 2246.98 | 130.68 |
| 2018 | 34425.90 | 1931.29 | 47.41 | -2.60 | 2479.50 | -102.39 |
| 2019 | 35378.73 | 274.21 | 49.68 | -1.97 | 2741.73 | 95.30 |
| 2020 | 36138.11 | -68.79 | 51.81 | 0.08 | 3031.17 | -17.52 |
| MAPE | 2.33% | 2.78% | 3.03% | |||
| R2 | 0.76 | 0.91 | 0.95 | |||
| 2021 | 36732.57 | 53.82 | 3347.52 | |||
| 2022 | 37188.87 | 55.70 | 3691.55 | |||
| 2023 | 37530.56 | 57.47 | 4064.68 | |||
| 2024 | 37777.84 | 59.13 | 4468.73 | |||
| 2025 | 37947.74 | 60.69 | 4905.87 | |||
| Year | Beijing | Tianjin | Hebei | |||
| GM (1, 3) | FGM (1, 3) | GM (1, 3) | FGM (1, 3) | GM (1, 3) | FGM (1, 3) | |
| 2014 | 744.79 | 744.79 | 332.35 | 332.35 | 798.44 | 798.44 |
| 2015 | 660.19 | 752.92 | 271.59 | 314.73 | 785.95 | 838.58 |
| 2016 | 896.37 | 786.22 | 363.92 | 359.78 | 1095.56 | 979.88 |
| 2017 | 840.02 | 836.34 | 361.28 | 365.01 | 1075.16 | 1044.88 |
| 2018 | 885.11 | 891.00 | 362.44 | 364.86 | 1172.99 | 1205.44 |
| 2019 | 985.07 | 948.01 | 373.93 | 375.67 | 1194.78 | 1246.31 |
| 2020 | 1030.47 | 1029.53 | 384.24 | 382.47 | 1303.27 | 1335.58 |
| MAPE | 4.7% | 1.26% | 4.19% | 2.79% | 5.51% | 4.57% |
| R2 | 0.777 | 0.988 | 0.545 | 0.762 | 0.904 | 0.972 |
| Year | Beijing | Tianjin | Hebei |
| 2021 | 1108.98 | 383.33 | 1418.48 |
| 2022 | 1195.60 | 385.14 | 1509.67 |
| 2023 | 1288.25 | 386.15 | 1606.23 |
| 2024 | 1386.23 | 386.58 | 1708.47 |
| 2025 | 1488.85 | 386.37 | 1816.88 |
