Dynamics of a diffusive and delayed HIV infection model with impaired immunity and latent cell-to-cell transmission

Hui Miao; Hui Miao

doi:10.3934/math.2026774

AIMS Mathematics

2026, Volume 11, Issue 6: 19011-19030. doi: 10.3934/math.2026774

Previous Article Next Article

Research article

Dynamics of a diffusive and delayed HIV infection model with impaired immunity and latent cell-to-cell transmission

Hui Miao ^,

School of Applied Mathematics, Shanxi University of Finance and Economics, Taiyuan 030006, China

Received: 06 May 2026 Revised: 16 June 2026 Accepted: 24 June 2026 Published: 29 June 2026
MSC : 34D40, 35K57, 92D30

Viral concentrations in plasma can be suppressed by antiviral drugs, yet reactivation of latently infected cells is the main obstacle to total human immunodeficiency virus (HIV) elimination. In this paper, to characterize the within-host dynamics of HIV with impaired immunity, we formulated and analyzed a general HIV infection model involving diffusion and three delays. Uninfected CD4$ ^+ $T cells were at risk of infection when they came into contact with three viral transmission routes, namely virus-to-cell infection, latent cell-to-cell transmission, and cell-to-cell transmission, all characterized by general incidence functions. Viral infection reproduction number was calculated, and the global properties were demonstrated. Numerical simulations were carried out to illustrate the corresponding theoretical results.
- viral infection model,
- latent cell-to-cell transmission,
- diffusion,
- general incidence function,
- global stability
Citation: Hui Miao. Dynamics of a diffusive and delayed HIV infection model with impaired immunity and latent cell-to-cell transmission[J]. AIMS Mathematics, 2026, 11(6): 19011-19030. doi: 10.3934/math.2026774

Related Papers:

Abstract

Viral concentrations in plasma can be suppressed by antiviral drugs, yet reactivation of latently infected cells is the main obstacle to total human immunodeficiency virus (HIV) elimination. In this paper, to characterize the within-host dynamics of HIV with impaired immunity, we formulated and analyzed a general HIV infection model involving diffusion and three delays. Uninfected CD4$ ^+ $T cells were at risk of infection when they came into contact with three viral transmission routes, namely virus-to-cell infection, latent cell-to-cell transmission, and cell-to-cell transmission, all characterized by general incidence functions. Viral infection reproduction number was calculated, and the global properties were demonstrated. Numerical simulations were carried out to illustrate the corresponding theoretical results.

References

[1]	M. A. Nowak, S. Bonhoeffer, G. M. Shaw, R. M. May, Anti-viral drug treatment: Dynamics of resistance in free virus and infected cell populations, J. Theor. Biol., 184 (1997), 203–217. http://doi.org/10.1006/jtbi.1996.0307 doi: 10.1006/jtbi.1996.0307
[2]	A. S. Perelson, P. W. Nelson, Mathematical analysis of HIV-1 dynamics in vivo, SIAM Review, 41 (1999), 3–44. http://doi.org/10.1137/S0036144598335107 doi: 10.1137/S0036144598335107
[3]	T. Guo, Z. P. Qiu, The effects of CTL immune response on HIV infection model with potent therapy, latently infected cells and cell-to-cell viral transmission, Math. Biosci. Eng., 16 (2019), 6822–6841. http://doi.org/10.3934/mbe.2019341 doi: 10.3934/mbe.2019341
[4]	H. Yan, Y. Y. Xiao, Q. Yan, X. N. Liu, Dynamics of an HIV-1 virus model with both virus-to-cell and cell-to-cell transmissions, general incidence rate, intracellular delay, and CTL immune responses, Math. Method. Appl. Sci., 42 (2019), 6385–6406. http://doi.org/10.1002/mma.5747 doi: 10.1002/mma.5747
[5]	K. A. Pawelek, S. Q. Liu, F. Pahlevani, L. B. Rong, A model of HIV-1 infection with two time delays: mathematical analysis and comparison with patient data, Math. Biosci., 235 (2012), 98–109. http://doi.org/10.1016/j.mbs.2011.11.002 doi: 10.1016/j.mbs.2011.11.002
[6]	H. Miao, R. Liu, M. Y. Jiao, Global dynamics of a delayed latent virus model with both virus-to-cell and cell-to-cell transmissions and humoral immunity, J. Inequal. Appl., 2021 (2021), 156. http://doi.org/10.1186/s13660-021-02691-y doi: 10.1186/s13660-021-02691-y
[7]	Z. X. Hu, J. J. Zhang, H. Wang, W. B. Ma, F. C. Liao, Dynamics analysis of a delayed viral infection model with logistic growth and immune impairment, Appl. Math. Model., 38 (2014), 524–534. http://doi.org/10.1016/j.apm.2013.06.041 doi: 10.1016/j.apm.2013.06.041
[8]	H. Miao, X. Abdurahman, Z. D. Teng, L. Zhang, Dynamical analysis of a delayed reaction-diffusion virus infection model with logistic growth and humoral immune impairment, Chaos Solition. Fract., 110 (2018), 280–291. http://doi.org/10.1016/j.chaos.2018.03.006 doi: 10.1016/j.chaos.2018.03.006
[9]	J. Z. Lin, R. Xu, X. H. Tian, Threshold dynamics of an HIV-1 model with both viral and cellular infections, cell-mediated and humoral immune responses, Math. Biosci. Eng., 16 (2019), 292–319. http://doi.org/10.3934/mbe.2019015 doi: 10.3934/mbe.2019015
[10]	A. M. Elaiw, N. H. AlShamrani, Global stability of a delayed adaptive immunity viral infection with two routes of infection and multi-stages of infected cells, Commun. Nonlinear Sci., 86 (2020), 105259. http://doi.org/10.1016/j.cnsns.2020.105259 doi: 10.1016/j.cnsns.2020.105259
[11]	A. Boukhouima, E. M. Lotfi, M. Mahrouf, N. Yousfi, T. Kuniya, A general fractional-order viral infection model with cell-to-cell transmission and adaptive immunity, Progr. Fract. Differ. Appl., 9 (2023), 41–63. http://doi.org/10.18576/pfda/090103 doi: 10.18576/pfda/090103
[12]	R. R. Regoes, D. Wodarz, M. A. Nowak, Virus dynamics: the effect of target cell limitation and immune responses on virus evolution, J. Theor. Biol., 191 (1998), 451–462. http://doi.org/10.1006/jtbi.1997.0617 doi: 10.1006/jtbi.1997.0617
[13]	S. Iwami, S. Nakaoka, Y. Takeuchi, Y. Miura, T. Miura, Immune impairment thresholds in HIV infection, Immunol. Lett., 123 (2009), 149–154. http://doi.org/10.1016/j.imlet.2009.03.007 doi: 10.1016/j.imlet.2009.03.007
[14]	A. M. Elaiw, S. F. Alshehaiween, A. D. Hobiny, Impact of B-cell impairment on virus dynamics with time delay and two modes of transmission, Chaos Solition. Fract., 130 (2020), 109455. http://doi.org/10.1016/j.chaos.2019.109455 doi: 10.1016/j.chaos.2019.109455
[15]	T. W. Chun, L. Stuyver, S. B. Mizell, L. A. Ehler, J. A. M. Mican, M. Baseler, et al., Presence of an inducible HIV-1 latent reservoir during highly active antiretroviral therapy, Proc. Natl. Acad. Sci. U.S.A., 94 (1997), 13193–13197. http://doi.org/10.1073/pnas.94.24.13193 doi: 10.1073/pnas.94.24.13193
[16]	J. K. Wong, M. Hezareh, H. F. Gunthard, D. V. Havlir, C. C. Ignacio, C. A. Spina, et al., Recovery of replication-competent HIV despite prolonged suppression of plasma viremia, Science, 278 (1997), 1291–1295. http://doi.org/10.1126/science.278.5341.1291 doi: 10.1126/science.278.5341.1291
[17]	R. Xu, Z. E. Ma, An HBV model with diffusion and time delay, J. Theor. Biol., 257 (2009), 499–509. http://doi.org/ 10.1016/j.jtbi.2009.01.001 doi: 10.1016/j.jtbi.2009.01.001
[18]	K. F. Wang, W. D. Wang, Propagation of HBV with spatial dependence, Math. Biosci., 210 (2007), 78–95. http://doi.org/10.1016/j.mbs.2007.05.004 doi: 10.1016/j.mbs.2007.05.004
[19]	H. Yang, J. J. Wei, Dynamics of spatially heterogeneous viral model with time delay, Commun. Pur. Appl. Anal., 19 (2020), 85–102. http://doi.org/10.3934/cpaa.2020005 doi: 10.3934/cpaa.2020005
[20]	A. M. Elaiw, A. D. Al. AlAgha, Analysis of a delayed and diffusive oncolytic M1 virotherapy model with immune response, Nonlinear Anal.-Real, 55 (2020), 103116. http://doi.org/10.1016/j.nonrwa.2020.103116 doi: 10.1016/j.nonrwa.2020.103116
[21]	C. C. McCluskey, Y. Yang, Global stability of a diffusive virus dynamics model with general incidence function and time delay, Nonlinear Anal.-Real, 25 (2015), 64–78. http://doi.org/10.1016/j.nonrwa.2015.03.002 doi: 10.1016/j.nonrwa.2015.03.002
[22]	K. Hattaf, N. Yousfi, A generalized HBV model with diffusion and two delays, Comput. Math. Appl., 69 (2015), 31–40. http://doi.org/10.1016/j.camwa.2014.11.010 doi: 10.1016/j.camwa.2014.11.010
[23]	S. Zhang, P. Wu, S. Q. Liu, Spatiotemporal evolution of a pine wilt disease model integrating infectious disease transmission and predator-prey interactions, J. Math. Biol., 92 (2026), 83. http://doi.org/10.1007/s00285-026-02406-1 doi: 10.1007/s00285-026-02406-1
[24]	P. Wu, S. Zhang, X. N. Wang, H. Wang, Spatiotemporal cholera dynamics with antibiotic resistance and vaccination via demographic-epidemic data in Zimbabwe, J. Math. Biol., 92 (2026), 42. http://doi.org/10.1007/s00285-026-02360-y doi: 10.1007/s00285-026-02360-y
[25]	P. Wu, C. Fang, Spatiotemporal dynamics of syphilis in Xinjiang via a demographic geographic data-validated reaction diffusion model, J. Math. Phys., 66 (2025), 062704. http://doi.org/10.1063/5.0273893 doi: 10.1063/5.0273893
[26]	H. Miao, X. M. Feng, Dynamics of a diffusive HTLV and HIV coinfection model with macrophages, latent cells and two delays, J. Biol. Dynam., 20 (2026), 2607155. http://doi.org/10.1080/17513758.2025.2607155 doi: 10.1080/17513758.2025.2607155
[27]	H. Q. Sun, J. L. Wang, Dynamics of a diffusive virus model with general incidence function, cell-to-cell transmission and time delay, Comput. Math. Appl., 77 (2019), 284–301. http://doi.org/10.1016/j.camwa.2018.09.032 doi: 10.1016/j.camwa.2018.09.032
[28]	C. C. Travis, G. F. Webb, Existence and stability for partial functional differential equations, Trans. Amer. Math. Soc., 200 (1974), 395–418. http://doi.org/10.2307/1997265 doi: 10.2307/1997265
[29]	W. E. Fitzgibbon, Semilinear functional differential equations in Banach space, J. Differ. Equations, 29 (1978), 1–14. http://doi.org/10.1016/0022-0396(78)90037-2 doi: 10.1016/0022-0396(78)90037-2
[30]	H. L. Smith, R. H. Martin, Reaction-diffusion systems with time delays: monotonicity, invariance, comparison and convergence, J. Reine. Angew. Math., 413 (1991), 1–35. http://doi.org/10.1515/crll.1991.413.1 doi: 10.1515/crll.1991.413.1
[31]	J. H. Wu, Theory and applications of partial functional differential equations, New York: Springer, 1996. http://doi.org/10.1007/978-1-4612-4050-1
[32]	M. H. Protter, H. F. Weinberger, Maximum principles in differential equations, Englewood Cliffs: Springer, 1967. https://doi.org/10.1007/978-1-4612-5282-5
[33]	D. Henry, Geometric theory of semilinear parabolic equations: lecture notes in mathematics, New York: Springer, 1993. https://doi.org/10.1007/BFb0089647
[34]	P. van den Driessche, J. Watmough, Reproduction numbers and sub-threshold endemic equilibria for compartmental models of disease transmission, Math. Biosci., 180 (2002), 29–48. http://doi.org/10.1016/S0025-5564(02)00108-6 doi: 10.1016/S0025-5564(02)00108-6
[35]	J. K. Hale, S. M. V. Lunel, Introduction to functional differential equations, New York: Springer, 1993. http://doi.org/10.1007/978-1-4612-4342-7
[36]	Y. Wang, Y. C. Zhou, F. Brauer, J. M. Heffernan, Viral dynamics model with CTL immune response incorporating antiretroviral therapy, J. Math. Biol., 67 (2013), 901–934. http://doi.org/10.1007/s00285-012-0580-3 doi: 10.1007/s00285-012-0580-3
[37]	N. H. AlShamrani, R. H. Halawania, A. M. Elaiw, Analysis of general HIV-1 infection models with weakened adaptive immunity and three transmission modalities, Alex. Eng. J., 106 (2024), 101–146. http://doi.org/10.1016/j.aej.2024.06.033 doi: 10.1016/j.aej.2024.06.033
[38]	R. E. Mickens, Nonstandard finite difference models of differential equations, Singapore: World Scientific, 1993. http://doi.org/10.1142/2081
[39]	R. E. Mickens, Dynamics consistency: a fundamental principle for constructing nonstandard finite difference schemes for differential equations, J. Differ. Equ. Appl., 11 (2005), 645–653. http://doi.org/10.1080/10236190412331334527 doi: 10.1080/10236190412331334527
[40]	O. Nave, Modification of semi-analytical method applied system of ODE, Modern Applied Science, 14 (2020), 75–81. http://doi.org/10.5539/mas.v14n6p75 doi: 10.5539/mas.v14n6p75
