Computation of edge metric dimension of zero divisor graph of matrices

Sahil Sharma; Omaima Al Shanqiti; Vijay Kumar Bhat; Sahil Sharma; Omaima Al Shanqiti; Vijay Kumar Bhat

doi:10.3934/math.2026526

AIMS Mathematics

2026, Volume 11, Issue 5: 12780-12794. doi: 10.3934/math.2026526

Previous Article Next Article

Research article Topical Sections

Computation of edge metric dimension of zero divisor graph of matrices

1.
School of Mathematics, Shri Mata Vaishno Devi University, Jammu and Kashmir, Katra 182320, India
2.
Department of Mathematics, Umm Al-Qura University, Makkah, Saudi Arabia

Received: 10 February 2026 Revised: 07 April 2026 Accepted: 28 April 2026 Published: 08 May 2026
MSC : 05C12, 05C76, 05C90

This paper investigated the resolving parameters of the zero-divisor graph (ZDG) associated with the non-commutative ring of $ 3 \times 3 $ upper triangular matrices over the field $ \mathbb{Z}_2 $. The structural complexity of non-commutative matrix rings, especially the difference between left and right zero-divisors, poses special difficulties for graph-theoretic characterization, although the metric dimensions of ZDGs for commutative rings have been well known. For this particular graph structure $ G = ZDG[M_3(\mathbb{Z}_2)] $, we specifically calculated the metric dimension ($ \text{dim}_v(G) $) and the edge metric dimension ($ \text{edim}_e(G) $). We determined the minimal resolving sets and proved that $ \text{dim}_v(G) = [11] $ and $ \text{edim}_e(G) = [13] $ by combining combinatorial proofs with structural decomposition into equivalence classes. A basic framework for calculating the metric dimensions of generalized $ n \times n $ matrix rings over finite fields is provided by these findings.
- metric dimension,
- ZDG,
- edge metric dimension,
- upper triangular matrix,
- resolving set
Citation: Sahil Sharma, Omaima Al Shanqiti, Vijay Kumar Bhat. Computation of edge metric dimension of zero divisor graph of matrices[J]. AIMS Mathematics, 2026, 11(5): 12780-12794. doi: 10.3934/math.2026526

Related Papers:

Abstract

This paper investigated the resolving parameters of the zero-divisor graph (ZDG) associated with the non-commutative ring of $ 3 \times 3 $ upper triangular matrices over the field $ \mathbb{Z}_2 $. The structural complexity of non-commutative matrix rings, especially the difference between left and right zero-divisors, poses special difficulties for graph-theoretic characterization, although the metric dimensions of ZDGs for commutative rings have been well known. For this particular graph structure $ G = ZDG[M_3(\mathbb{Z}_2)] $, we specifically calculated the metric dimension ($ \text{dim}_v(G) $) and the edge metric dimension ($ \text{edim}_e(G) $). We determined the minimal resolving sets and proved that $ \text{dim}_v(G) = [11] $ and $ \text{edim}_e(G) = [13] $ by combining combinatorial proofs with structural decomposition into equivalence classes. A basic framework for calculating the metric dimensions of generalized $ n \times n $ matrix rings over finite fields is provided by these findings.

References

[1]	Z. Beerliova, F. Eberhard, T. Erlebach, A. Hall, M. Hoffman, M. Mihal'ak, et al., Network discovery and verification, IEEE J. Sel. Areas Commun., 24 (2006), 2168–2181. https://doi.org/10.1109/JSAC.2006.884015 doi: 10.1109/JSAC.2006.884015
[2]	L. M. Blumenthal, Theory and applications of distance geometry, Clarendon Press, 1953.
[3]	J. A. Bondy, U. S. Murty, Graph theory, Springer, 2008.
[4]	P. J. Slater, Leaves of trees, Proceedings of the 6th Southeastern Conference on Combinatorics, Graph Theory, and Computing, 1975,549–559.
[5]	F. Harary, R. A. Melter, On the metric dimension of a graph, Ars Combin., 2 (1976), 191–195.
[6]	R. A. Melter, I. Tomescu, Metric bases in digital geometry, Comput. Graphics Image Process., 25 (1984), 113–121. https://doi.org/10.1016/0734-189X(84)90051-3 doi: 10.1016/0734-189X(84)90051-3
[7]	S. Khuller, B. Raghavachari, A. Rosenfeld, Landmarks in graphs, Discrete Appl. Math., 70 (1996), 217–229.
[8]	A. Sebö, E. Tannier, On metric generators of graphs, Math. Oper. Res., 29 (2004), 383–393. https://doi.org/10.1287/moor.1030.0070 doi: 10.1287/moor.1030.0070
[9]	I. Tomescu, M. Imran, Metric dimension and $R$-sets of a connected graph, Graphs Combin., 27 (2011), 585–591. https://doi.org/10.1007/s00373-010-0988-8 doi: 10.1007/s00373-010-0988-8
[10]	G. Chartrand, L. Eroh, M. A. Johnson, O. R. Oellermann, Resolvability in graphs and the metric dimension of a graph, Discrete Appl. Math., 105 (2000), 99–113. https://doi.org/10.1016/S0166-218X(00)00198-0 doi: 10.1016/S0166-218X(00)00198-0
[11]	S. K. Sharma, V. K. Bhat, Metric dimension of heptagonal circular ladder, Discrete Math. Algorithms Appl., 13 (2021), 2050095. https://doi.org/10.1142/S1793830920500950 doi: 10.1142/S1793830920500950
[12]	I. Javaid, M. T. Rahim, K. Ali, Families of regular graphs with constant metric dimension, Utilitas Math., 75 (2008), 21–34.
[13]	C. Hernando, M. Mora, I. M. Pelayo, C. Seara, J. Cáceres, M. L. Puertas, On the metric dimension of some families of graphs, Electron. Notes Discrete Math., 22 (2005), 129–133. https://doi.org/10.1016/j.endm.2005.06.023 doi: 10.1016/j.endm.2005.06.023
[14]	P. S. Buczkowski, G. Chartrand, C. Poisson, P. Zhang, On $k$-dimensional graphs and their bases, Period. Math. Hung., 46 (2003), 9–15. https://doi.org/10.1023/A:1025745406160 doi: 10.1023/A:1025745406160
[15]	I. Tomescu, I. Javaid, On the metric dimension of the Jahangir graph, Bull. Math. Soc. Sci. Math. Roum., 50 (2007), 371–376.
[16]	I. Beck, Coloring of commutative rings, J. Algebra, 116 (1988), 208–226. https://doi.org/10.1016/0021-8693(88)90202-5 doi: 10.1016/0021-8693(88)90202-5
[17]	D. F. Anderson, P. S. Livingston, The zero-divisor graph of a commutative ring, J. Algebra, 217 (1999), 434–447. https://doi.org/10.1006/jabr.1998.7840 doi: 10.1006/jabr.1998.7840
[18]	P. Singh, V. K. Bhat, Zero-divisor graphs of finite commutative rings: a survey, Surv. Math. Appl., 15 (2020), 371–397.
[19]	P. Singh, V. K. Bhat, Adjacency matrix and Wiener index of zero divisor graph $\Gamma(\mathbb{Z}_n)$, J. Appl. Math. Comput., 66 (2021), 717–732. https://doi.org/10.1007/s12190-020-01460-2 doi: 10.1007/s12190-020-01460-2
[20]	P. Singh, V. K. Bhat, Graph invariants of the line graph of zero-divisor graph of $\mathbb{Z}_n$, J. Appl. Math. Comput., 68 (2022), 1271–1287. https://doi.org/10.1007/s12190-021-01567-0 doi: 10.1007/s12190-021-01567-0
[21]	S. P. Redmond, The zero-divisor graph of a non-commutative ring, Int. J. Commut. Rings, 1 (2002), 203–211.
[22]	F. R. DeMeyer, T. McKenzie, K. Schneider, The zero-divisor graph of a commutative semigroup, J. Algebra, 247 (2002), 215–220. https://doi.org/10.1007/s002330010128 doi: 10.1007/s002330010128
[23]	M. Behboodi, Zero-divisor graphs for modules over commutative rings, J. Commut. Algebra, 4 (2012), 175–197. https://doi.org/10.1216/JCA-2012-4-2-175 doi: 10.1216/JCA-2012-4-2-175
[24]	S. Sharma, V. K. Bhat, Fault-tolerant metric dimension of zero-divisor graphs of commutative rings, AKCE Int. J. Graphs Combin., 19 (2022), 24–30. https://doi.org/10.1080/09728600.2021.2009746 doi: 10.1080/09728600.2021.2009746
[25]	L. A. Hanna, M. M. Alkandari, V. K. Bhat, Fault-tolerant metric dimension and applications: Zero-divisor graph of upper triangular matrices, Mathematics, 13 (2025), 3678. https://doi.org/10.3390/math13223678 doi: 10.3390/math13223678
