Output formation containment of time-delayed heterogeneous singular multi-agent systems with stochastic impulsive effects

Mhamed Benaissa; Esmail H. A. Al-Sabri; Maryam Iqbal; Walid Abdelfattah; Ghada A. Alsawah; Azmat Ullah Khan Niazi; Mhamed Benaissa; Esmail H. A. Al-Sabri; Maryam Iqbal; Walid Abdelfattah; Ghada A. Alsawah; Azmat Ullah Khan Niazi

doi:10.3934/math.2026482

AIMS Mathematics

2026, Volume 11, Issue 4: 11706-11730. doi: 10.3934/math.2026482

Previous Article Next Article

Research article

Output formation containment of time-delayed heterogeneous singular multi-agent systems with stochastic impulsive effects

1.
Department of Chemical Engineering, University of Ha'il, Saudi Arabia
2.
Department of Mathematics, faculty of science, King Khalid University, Abha, Saudi Arabia
3.
Department of Mathematics and Computer, faculty of science, Ibb University, Yemen
4.
Department of Mathematics and Statistics, the University of Lahore, Sargodha Pakistan
5.
Humanities and Social Research Center, Northern Border University, Arar, Saudi Arabia
6.
Department of Industrial and Systems Engineering, College of Engineering, Princess Nourah bint Abdulrahman University, P.O. Box 84428, Riyadh 11671, Saudi Arabia

Received: 15 February 2026 Revised: 05 April 2026 Accepted: 21 April 2026 Published: 28 April 2026
MSC : 26A33, 34K37

This paper investigates the containment of output formation for heterogeneous singular multi-agent systems (MASs) subject to time delays and stochastic impulsive disturbances. The considered agents exhibit diverse dynamics, including descriptor-type tracking and algebraic systems, reflecting heterogeneity in state-space representations. Communication constraints are modeled via bounded state and input delays, while environmental uncertainties are captured through stochastic noise and impulsive effects occurring at arbitrary time instants. A distributed control protocol is proposed to achieve output formation containment, ensuring asymptotic convergence of follower outputs to a convex combination of leader outputs. The approach effectively addresses system singularities and uncertainties by employing a Lyapunov–Krasovskii functional combined with stochastic stability analysis. Sufficient conditions for mean-square admissibility and asymptotic convergence are derived. Numerical simulations validate the effectiveness and robustness of the proposed control strategy under varying delays and impulsive conditions.
- heterogeneous singular multi-agent systems,
- stochastic impulsive disturbances,
- formation containment,
- time delay
Citation: Mhamed Benaissa, Esmail H. A. Al-Sabri, Maryam Iqbal, Walid Abdelfattah, Ghada A. Alsawah, Azmat Ullah Khan Niazi. Output formation containment of time-delayed heterogeneous singular multi-agent systems with stochastic impulsive effects[J]. AIMS Mathematics, 2026, 11(4): 11706-11730. doi: 10.3934/math.2026482

Related Papers:

Abstract

This paper investigates the containment of output formation for heterogeneous singular multi-agent systems (MASs) subject to time delays and stochastic impulsive disturbances. The considered agents exhibit diverse dynamics, including descriptor-type tracking and algebraic systems, reflecting heterogeneity in state-space representations. Communication constraints are modeled via bounded state and input delays, while environmental uncertainties are captured through stochastic noise and impulsive effects occurring at arbitrary time instants. A distributed control protocol is proposed to achieve output formation containment, ensuring asymptotic convergence of follower outputs to a convex combination of leader outputs. The approach effectively addresses system singularities and uncertainties by employing a Lyapunov–Krasovskii functional combined with stochastic stability analysis. Sufficient conditions for mean-square admissibility and asymptotic convergence are derived. Numerical simulations validate the effectiveness and robustness of the proposed control strategy under varying delays and impulsive conditions.

References

[1]	W. Chen, J. Hu, Z. Wu, S. Ma, A survey on fault detection for networked systems under communication constraints, Syst. Sci. Control Eng., 13 (2025), 2460434. https://doi.org/10.1080/21642583.2025.2460434 doi: 10.1080/21642583.2025.2460434
[2]	C. Y. Wang, Z. Y. Zuo, Z. Q. Qi, Z. T. Ding, Predictor-based extended-state-observer design for consensus of MASs with delays and disturbances, IEEE T. Cybernetics, 49 (2019), 1259. https://doi.org/10.1109/TCYB.2018.2799798 doi: 10.1109/TCYB.2018.2799798
[3]	G. Bao, L. Ma, X. Yi, Recent advances on cooperative control of heterogeneous multi-agent systems subject to constraints: A survey, Syst. Sci. Control Eng., 10 (2022), 539–551. https://doi.org/10.1080/21642583.2022.2074169 doi: 10.1080/21642583.2022.2074169
[4]	S. Behjat, M. R. Salehizadeh, G. Lorenzini, Modeling time-delay in consensus control: A review, Int. J. Res. Tech. Electr. Ind., 3 (2024), 287–298. https://doi.org/10.48308/ijrtei.2024.234427.1037 doi: 10.48308/ijrtei.2024.234427.1037
[5]	J. Zhang, M. Lyu, T. Shen, L. Liu, Y. Bo, Sliding mode control for a class of nonlinear multi-agent systems with time delay and uncertainties, IEEE T. Ind. Electron., 65 (2017), 865–875. https://doi.org/10.1109/TIE.2017.2701777 doi: 10.1109/TIE.2017.2701777
[6]	C. Li, Y. Liu, M. Gao, L. Sheng, Fault-tolerant formation consensus control for time-varying multi-agent systems with stochastic communication protocol, Int. J. Netw. Dyn. Intell., 2024. https://doi.org/10.53941/ijndi.2024.100004
[7]	A. Khan, A. U. K. Niazi, S. Rehman, S. Ahmed, Hostile-based bipartite containment control of nonlinear fractional multi-agent systems with input delays: A signed graph approach under disturbance and switching networks, AIMS Math., 9 (2024), 12678–12699. https://doi.org/10.3934/math.2024620 doi: 10.3934/math.2024620
[8]	Z. H. Zhu, B. Hu, Z. H. Guan, D. X. Zhang, T. Li, Observer-based bipartite containment control for singular multi-agent systems over signed digraphs, IEEE T. Circuits-I, 68 (2020), 444–457. https://doi.org/10.1109/TCSI.2020.3026323 doi: 10.1109/TCSI.2020.3026323
[9]	Y. Wang, M. Rajabinezhad, Y. Zhang, S. Zuo, Cyber-physical defense for heterogeneous multi-agent systems against exponentially unbounded attacks on signed digraphs, arXiv preprint, 2025.
[10]	L. Zhang, Y. Li, J. Lou, J. Lu, Bipartite asynchronous impulsive tracking consensus for multi-agent systems, Front. Inform. Tech. El., 23 (2022), 1522–1532. https://doi.org/10.1631/FITEE.2100122 doi: 10.1631/FITEE.2100122
[11]	Z. Yan, Z. Pan, G. Hu, J. Cheng, W. Qi, Annular finite-time $H_2/H_\infty$ control for mean-field jump-diffusion systems, IEEE T. Cybernetics, 55 (2025), 5358–5371. https://doi.org/10.1109/TCYB.2025.3597588 doi: 10.1109/TCYB.2025.3597588
[12]	Z. Yan, Z. Pan, G. Hu, H. Yan, Finite-time annular domain guaranteed cost control for uncertain mean-field stochastic systems with Wiener and Poisson noises, IEEE T. Syst. Man Cy.-S., 55 (2025), 7981–7993. https://doi.org/10.1109/TSMC.2025.3598993 doi: 10.1109/TSMC.2025.3598993
[13]	H. Zheng, J. Lu, S. Zhen, X. Liu, Y. Chen, Hybrid nominal-robust control strategy with error-bounding constraints for enhanced hub motor performance, Control Eng. Pract., 168 (2026), 106672. https://doi.org/10.1016/j.conengprac.2025.106672 doi: 10.1016/j.conengprac.2025.106672
[14]	Z. Li, J. Jin, D. Zhang, C. Chen, Design and realization of pulse-controlled multi-memristor Hopfield neural networks and their applications in information encryption, Multimedia Syst., 31 (2025), 427. https://doi.org/10.1007/s00530-025-02012-z doi: 10.1007/s00530-025-02012-z
[15]	N. Cheng, W. Wang, H. Zeng, X. Liu, X. Zhang, Novel exponential-weighted integral inequality for exponential stability analysis of time-varying delay systems, Appl. Math. Lett., 172 (2026), 109730. https://doi.org/10.1016/j.aml.2025.109730 doi: 10.1016/j.aml.2025.109730
[16]	C. Li, W. Wang, H. Zeng, X. Zhang, Novel stability and stabilization criteria for T-S fuzzy systems with time-varying delay based on fuzzy line integral, Commun. Nonlinear Sci., 156 (2026), 109663. https://doi.org/10.1016/j.cnsns.2026.109663 doi: 10.1016/j.cnsns.2026.109663
[17]	F. Zhu, P. Li, Adaptive fuzzy consensus tracking control of multi-agent systems with predefined time, AIMS Math., 10 (2025), 5307–5331. https://doi.org/10.3934/math.2025245 doi: 10.3934/math.2025245
[18]	M. Nasir, Z. Ahmed, N. Ali, M. A. Saeed, $H_\infty $ performance tracking and group consensus of delayed multi-agent systems under attack, J. Vib. Control, 30 (2024), 1721–1736. https://doi.org/10.1177/10775463231170032 doi: 10.1177/10775463231170032
[19]	H. Yang, S. Li, L. Yang, Z. Ding, Leader-following consensus of fractional-order uncertain multi-agent systems with time delays, Neural Process. Lett., 54 (2022), 4829–4849. https://doi.org/10.1007/s11063-022-10837-2 doi: 10.1007/s11063-022-10837-2
[20]	T. Hu, Z. He, X. Zhang, S. Zhong, Leader-following consensus of fractional-order multi-agent systems based on event-triggered control, Nonlinear Dynam., 99 (2020), 2219–2232. https://doi.org/10.1007/s11071-019-05390-y doi: 10.1007/s11071-019-05390-y
[21]	J. Liu, G. Jiang, C. Chu, Y. Li, Z. Wang, S. Hu, A formal model for multiagent Q-learning on graphs, Sci. China Inform. Sci., 68 (2025), 192206. https://doi.org/10.1007/s11432-024-4289-6 doi: 10.1007/s11432-024-4289-6
[22]	X. Liu, L. Zhao, J. Jin, A noise-tolerant fuzzy-type zeroing neural network for robust synchronization of chaotic systems, Concurr. Comp.-Pract. E., 36 (2024), e8218. https://doi.org/10.1002/cpe.8218 doi: 10.1002/cpe.8218
[23]	J. Xiong, X. Wang, C. Li, Recurrent neural network based sliding mode control for an uncertain tilting quadrotor UAV, Int. J. Robust Nonlin., 35 (2025), 8030–8046. https://doi.org/10.1002/rnc.70108 doi: 10.1002/rnc.70108
[24]	Q. Lu, X. Wu, J. She, F. Guo, L. Yu, Disturbance rejection for systems with uncertainties based on fixed-time equivalent-input-disturbance approach, IEEE-CAA J. Automatic., 11 (2024), 2384–2395. https://doi.org/10.1109/JAS.2024.124650 doi: 10.1109/JAS.2024.124650
[25]	H. Tian, Z. Wang, Z. Cao, B. Sun, Field and delay effects on synchronization in a multilayer memristive neuronal network with a hub, Chaos Soliton. Fract., 201 (2025), 117292. https://doi.org/10.1016/j.chaos.2025.117292 doi: 10.1016/j.chaos.2025.117292
[26]	W. Yuan, J. Chen, S. Chen, D. Feng, Z. Hu, P. Li, et al., Transformer in reinforcement learning for decision-making: A survey, Front. Inform. Tech. El., 25 (2024), 763–790. https://doi.org/10.1631/FITEE.2300548 doi: 10.1631/FITEE.2300548
[27]	Y. Kang, L. Yao, H. Wang, Fault isolation and fault-tolerant control for Takagi-Sugeno fuzzy time-varying delay stochastic distribution systems, IEEE T. Fuzzy Syst., 30 (2022), 1185–1195. https://doi.org/10.1109/TFUZZ.2021.3053320 doi: 10.1109/TFUZZ.2021.3053320
[28]	J. Zhang, X. Zhao, G. Zheng, F. Zhu, T. N. Dinh, On distributed prescribed-time unknown input observers, IEEE T. Automat. Contr., 70 (2025), 4743–4750. https://doi.org/10.1109/TAC.2025.3536856 doi: 10.1109/TAC.2025.3536856
[29]	J. Zhang, Y. Song, G. Zheng, Prescribed-time observer for descriptor systems with unknown input, Automatica, 172 (2025), 111999. https://doi.org/10.1016/j.automatica.2024.111999 doi: 10.1016/j.automatica.2024.111999
[30]	X. Yang, X. Zhang, J. Cao, H. Liu, Observer-based adaptive fuzzy fractional backstepping consensus control of uncertain multiagent systems via event-triggered scheme, IEEE T. Fuzzy Syst., 32 (2024), 3953–3967. https://doi.org/10.1109/TFUZZ.2024.3386312 doi: 10.1109/TFUZZ.2024.3386312
[31]	J. Kandasamy, R. Ramachandran, V. Veerasamy, A. X. R. Irudayaraj, Distributed leader-follower based adaptive consensus control for networked microgrids, Appl. Energ., 353 (2024), 122083. https://doi.org/10.1016/j.apenergy.2023.122083 doi: 10.1016/j.apenergy.2023.122083
[32]	X. Pu, Z. Cheng, Couple-group consensus of heterogeneous fractional multi-agent systems with pinning and self-adaptive controller, In: 2022 34th Chinese Control and Decision Conference (CCDC), IEEE, 2022, 3357–3362. https://doi.org/10.1109/CCDC55256.2022.10034347
[33]	R. Almeida, E. Girejko, S. Hristova, A. B. Malinowska, Leader-following consensus for fractional multi-agent systems, Adv. Differ. Equ., 2019 (2019), 1–15. https://doi.org/10.1186/s13662-019-2235-9 doi: 10.1186/s13662-019-2235-9
[34]	B. Ramakrishnan, F. Parastesh, S. Jafari, K. Rajagopal, G. Stamov, I. Stamova, Synchronization in a multiplex network of nonidentical fractional-order neurons, Fractal Fract., 6 (2022), 169. https://doi.org/10.3390/fractalfract6030169 doi: 10.3390/fractalfract6030169
[35]	M. Abdelrahim, A. Abdessameud, E. H. Abed, M. Abu-Khalaf, B. Acikmese, E. M. Adam, et al., 2019 index IEEE transactions on automatic control Vol. 64, IEEE T. Automat. Contr., 64 (2019), 5273–5349. https://doi.org/10.1109/TAC.2020.2967132 doi: 10.1109/TAC.2020.2967132
[36]	W. Zhang, B. Gong, X. Wang, H. Li, Leader-following consensus of stochastic delayed multiagent systems with input saturation under self-triggered impulsive control, Sci. China Tech. Sci., 68 (2025), 1420404. https://doi.org/10.1007/s11431-024-2715-5 doi: 10.1007/s11431-024-2715-5
[37]	Z. Guo, L. Cao, C. Zuo, Y. Pan, Dynamic event-triggered adaptive tracking control for multi-agent systems with power exponential function using fuzzy disturbance observer, Int. J. Fuzzy Syst., 25 (2023), 2900–2917. https://doi.org/10.1007/s40815-023-01540-y doi: 10.1007/s40815-023-01540-y
[38]	M. Parsa, M. Danesh, Robust containment control of uncertain multi-agent systems with time-delay and heterogeneous Lipschitz nonlinearity, IEEE T. Syst. Man Cyb.-Sy., 51 (2019), 2312–2321. https://doi.org/10.1109/TSMC.2019.2912268 doi: 10.1109/TSMC.2019.2912268
[39]	Y. Ye, H. Su, Leader-following consensus of nonlinear fractional-order multi-agent systems over directed networks, Nonlinear Dynam., 96 (2019), 1391–1403. https://doi.org/10.1007/s11071-019-04861-6 doi: 10.1007/s11071-019-04861-6
[40]	P. Xiao, Z. Gu, Adaptive event-triggered consensus of fractional-order nonlinear multi-agent systems, IEEE Access, 10 (2021), 213–220. https://doi.org/10.1109/ACCESS.2021.3136892 doi: 10.1109/ACCESS.2021.3136892
[41]	H. Guo, M. Chen, Y. Shen, M. Lungu, Distributed event-triggered collision avoidance formation control for QUAVs with disturbances based on virtual tubes, IEEE T. Indu. Electron., 72 (2024), 1892–1903. https://doi.org/10.1109/TIE.2024.3417975 doi: 10.1109/TIE.2024.3417975
[42]	T. Shi, L. Chen, G. He, W. Song, Distributed composite learning dynamic event-triggered control for nonlinear multi-agent power systems, IEEE T. Circuits-I, 72 (2025), 2274–2287. https://doi.org/10.1109/TCSI.2025.3539299 doi: 10.1109/TCSI.2025.3539299
[43]	S. Miao, H. Su, Consensus of different-order switched multi-agent systems on matrix-weighted networks, Appl. Math. Comput., 508 (2026), 129610. https://doi.org/10.1016/j.amc.2025.129610 doi: 10.1016/j.amc.2025.129610
[44]	X. Xu, B. Li, Semi-global stabilization of parabolic PDE-ODE systems with input saturation, Automatica, 171 (2025), 111931. https://doi.org/10.1016/j.automatica.2024.111931 doi: 10.1016/j.automatica.2024.111931
[45]	X. Xu, B. Li, PDE-based observation and predictor-based control for linear systems with distributed infinite input and output delays, Automatica, 170 (2024), 111845. https://doi.org/10.1016/j.automatica.2024.111845 doi: 10.1016/j.automatica.2024.111845
[46]	Y. Wang, W. Kong, J. Li, H. Sun, X. Li, Q. Wei, A decoupling model for fatigue life assessment of double wellhead system with subsea suction anchor, Ocean Eng., 311 (2024), 118896. https://doi.org/10.1016/j.oceaneng.2024.118896 doi: 10.1016/j.oceaneng.2024.118896
[47]	Z. Zhou, Y. Wang, X. Liu, Z. Li, M. Wu, G. Zhou, Hybrid of neural network and physics-based estimator for vehicle longitudinal dynamics modeling using limited driving data, IEEE T. Intell. Transp., 26 (2025), 16735–16746. https://doi.org/10.1109/TITS.2025.3585346 doi: 10.1109/TITS.2025.3585346
[48]	J. Chen, M. Li, M. Marcantoni, B. Jayawardhana, Y. Wang, Range-only distributed safety-critical formation control based on contracting bearing estimators and control barrier functions, IEEE Internet Things, 12 (2025), 40968–40979. https://doi.org/10.1109/JIOT.2025.3590774 doi: 10.1109/JIOT.2025.3590774
[49]	J. Wang, H. Wang, J. Song, X. Chen, J. Guo, K. Li, et al., Knowledge-guided self-learning control strategy for mixed vehicle platoons with delays, Nature Commun., 16 (2025), 7705. https://doi.org/10.1038/s41467-025-62597-x doi: 10.1038/s41467-025-62597-x
[50]	B. Wang, J. Sun, B. Peng, X. Cui, L. Cheng, X. Zheng, Optimal event-triggered neural learning tracking control for pneumatic muscle antagonistic joint with asymmetric constraints, IEEE T. Ind. Electron., 72 (2025), 14677–14687. https://doi.org/10.1109/TIE.2025.3585055 doi: 10.1109/TIE.2025.3585055
