Bogdanov-Takens bifurcation of a two species chemical reaction system and its stability using parameter identification

Xue Zhang; Jinzhao Wang; Feng Li; Hongwei Li; Muhammad Marwan; Xue Zhang; Jinzhao Wang; Feng Li; Hongwei Li; Muhammad Marwan

doi:10.3934/nhm.2026016

Networks and Heterogeneous Media

2026, Volume 21, Issue 2: 349-367. doi: 10.3934/nhm.2026016

Previous Article Next Article

Research article Special Issues

Bogdanov-Takens bifurcation of a two species chemical reaction system and its stability using parameter identification

School of Mathematics and Statistics, Linyi University, Linyi 276005, Shandong, China

Received: 26 November 2025 Revised: 05 March 2026 Accepted: 06 March 2026 Published: 19 March 2026

In this paper, we mathematically analyzed a chemical reaction-based dynamical model to investigate codimension-two and codimension-three Bogdanov–Takens (BT) bifurcations and their impact on system dynamics. Generalized eigenvectors were first computed using normalization techniques to derive unfolding parameters for codim-two BT bifurcation. A codim-three BT bifurcation case was then obtained, with its unfolding parameters determined with the aid of the seven-step method. A control technique based on anonymous parameters and updated law was used to control oscillations in our considered dynamical system. Analytical results were validated through numerical simulations, highlighting the role of autocatalytic reactions $ 2 D_1 \xrightarrow{\alpha_4} D_2 $ and $ 2 D_1+D_2 \xrightarrow{\alpha_5} 3 D_1 $ in system behavior. These bifurcations generated oscillations, bi-stability, and excitability, behaviors essential for understanding and controlling complex chemical and biological systems.
- chemical reaction system,
- codim-two BT bifurcation,
- codim-three BT bifurcation,
- normalization,
- stability,
- updated law
Citation: Xue Zhang, Jinzhao Wang, Feng Li, Hongwei Li, Muhammad Marwan. Bogdanov-Takens bifurcation of a two species chemical reaction system and its stability using parameter identification[J]. Networks and Heterogeneous Media, 2026, 21(2): 349-367. doi: 10.3934/nhm.2026016

Related Papers:

Abstract

In this paper, we mathematically analyzed a chemical reaction-based dynamical model to investigate codimension-two and codimension-three Bogdanov–Takens (BT) bifurcations and their impact on system dynamics. Generalized eigenvectors were first computed using normalization techniques to derive unfolding parameters for codim-two BT bifurcation. A codim-three BT bifurcation case was then obtained, with its unfolding parameters determined with the aid of the seven-step method. A control technique based on anonymous parameters and updated law was used to control oscillations in our considered dynamical system. Analytical results were validated through numerical simulations, highlighting the role of autocatalytic reactions $ 2 D_1 \xrightarrow{\alpha_4} D_2 $ and $ 2 D_1+D_2 \xrightarrow{\alpha_5} 3 D_1 $ in system behavior. These bifurcations generated oscillations, bi-stability, and excitability, behaviors essential for understanding and controlling complex chemical and biological systems.

References

[1]	Q. Din, T. Donchev, D. Kolev, Stability, bifurcation analysis and chaos control in chlorine dioxide–iodine–malonic acid reaction, MATCH Commun. Math. Comput. Chem., 79 (2018), 577–606. Available from: https://match.pmf.kg.ac.rs/electronic_versions/Match79/n3/match79n3_577-606.pdf.
[2]	M. Chen, X. Z. Li, Stability analysis and turing pattern of an enzyme-catalyzed reaction model, MATCH Commun. Math. Comput. Chem., 94 (2025), 195–206. https://doi.org/10.46793/match.94-1.195C doi: 10.46793/match.94-1.195C
[3]	M. A. Khan, Q. Din, Codimension-one and codimension-two bifurcations of a fractional-order cubic autocatalator chemical reaction system, MATCH Commun. Math. Comput. Chem., 91 (2024), 415–452. https://doi.org/10.46793/match.91-2.415K doi: 10.46793/match.91-2.415K
[4]	H. Nabila, H. Tayebb, Nonlinear dynamics of fractional-order chaotic chemical reactor system based on the adomian decomposition method and its control via adaptive sliding mode control, MATCH Commun. Math. Comput. Chem., 94 (2025), 355–378. https://doi.org/10.46793/match.94-2.355N doi: 10.46793/match.94-2.355N
[5]	M. A. Khan, M. S. Khan, Q. Din, Codimension-one and codimension-two bifurcations of a modified Brusselator model, Int. J. Dyn. Control, 13 (2025), 154. https://doi.org/10.1007/s40435-025-01652-3 doi: 10.1007/s40435-025-01652-3
[6]	Y. Huang, X. S. Yang, Chaoticity of some chemical attractors: A computer assisted proof, J. Math. Chem., 38 (2005), 107–117. https://doi.org/10.1007/s10910-005-4537-2 doi: 10.1007/s10910-005-4537-2
[7]	C. Xu, Y. Wu, Bifurcation and control of chaos in a chemical system, Appl. Math. Model., 39 (2015), 2295–2310. https://doi.org/10.1016/j.apm.2014.10.030 doi: 10.1016/j.apm.2014.10.030
[8]	R. Wu, L. Yang, Bogdanov-Takens bifurcation of an enzyme-catalyzed reaction model, Nonlinear Dyn., 112 (2024), 14363–14377. https://doi.org/10.1007/s11071-024-09868-2 doi: 10.1007/s11071-024-09868-2
[9]	M. Izadi, H. Ahmad, H. M. Srivastava, Numerical computations of time-dependent auto-catalytic glycolysis chemical reaction-diffusion system, MATCH Commun. Math. Comput. Chem., 93 (2025), 69–97. https://doi.org/10.46793/match.93-1.069I doi: 10.46793/match.93-1.069I
[10]	Z. M. Alaof, K. K. Ali, M. S. Mehanna, A. H. Abdel-Aty, M. A. Shaalan, Applications of the Belousov–Zhabotinsky reaction–diffusion system: Analytical and numerical approaches, Open Phys., 23 (2025), 20250129. https://doi.org/10.1515/phys-2025-0129 doi: 10.1515/phys-2025-0129
[11]	C. Zhou, F. Xie, Z. Li, Complex bursting patterns and fast-slow analysis in a smallest chemical reaction system with two slow parametric excitations, Chaos Soliton Fractals, 137 (2020), 109859. https://doi.org/10.1016/j.chaos.2020.109859 doi: 10.1016/j.chaos.2020.109859
[12]	J. H. Merkin, A. F. Taylor, Reduction waves in the two-variable Oregonator model for the BZ reaction, Physica D, 241 (2012), 1336–1343. https://doi.org/10.1016/j.physd.2012.04.007 doi: 10.1016/j.physd.2012.04.007
[13]	Q. Din, U. Saeed, Stability, discretization, and bifurcation analysis for a chemical reaction system, MATCH Commun. Math. Comput. Chem, 90 (2023), 151–174. https://doi.org/10.46793/match.90-1.151D doi: 10.46793/match.90-1.151D
[14]	D. Erle, Nonoscillation in closed reversible chemical systems, J. Math. Chem., 27 (2000), 293–302. https://doi.org/10.1023/A:1018871722219 doi: 10.1023/A:1018871722219
[15]	S. Azimi, C. Panchal, A. Mizera, I. Petre, Multi-stability, limit cycles, and period-doubling bifurcation with reaction systems, Int. J. Found. Comput. Sci., 28 (2017), 1007–1020. https://doi.org/10.1142/S0129054117500368 doi: 10.1142/S0129054117500368
[16]	B. Fercec, I. Nagy, V. G. Romanovski, G. Szederkényi, J. Tóth, Limit cycles in a two-species reaction, J. Nonlinear Model. Anal., 1 (2019), 283–300. https://doi.org/10.12150/jnma.2019.283 doi: 10.12150/jnma.2019.283
[17]	I. Nagy, V. G. Romanovski, J. Tóth, Two nested limit cycles in two-species reactions, Mathematics, 8 (2020), 1658. https://doi.org/10.3390/math8101658 doi: 10.3390/math8101658
[18]	M. Banaji, B. Boros, The smallest bimolecular mass action reaction networks admitting Andronov–Hopf bifurcation, Nonlinearity, 36 (2023), 1398. https://doi.org/10.1088/1361-6544/acb0a8 doi: 10.1088/1361-6544/acb0a8
[19]	M. Ch-Chaoui, K. Mokni, A discrete evolutionary Beverton–Holt population model, Int. J. Dyn. Control, 11 (2023), 1060–1075. https://doi.org/10.1007/s40435-022-01035-y doi: 10.1007/s40435-022-01035-y
[20]	H. Mouhsine, H. Ben Ali, K. Mokni, M. Ch-Chaoui, Dynamics unveiled: Investigating bifurcations and the strong Allee effect in a discrete-time prey-predator system, Int. J. Dyn. Control, 13 (2025), 324. https://doi.org/10.1007/s40435-025-01834-z doi: 10.1007/s40435-025-01834-z
[21]	M. Marwan, N. Wang, F. Li, Practical computation of higher codimension Bogdanov-Takens bifurcations in energy supply-demand system, Math. Comput. Simul., 238 (2025), 255–268. https://doi.org/10.1016/j.matcom.2025.05.004 doi: 10.1016/j.matcom.2025.05.004
[22]	M. Marwan, M. Han, M. Osman, Hidden covers (wings) in the fractals of chaotic systems using advanced Julia function, Fractals, 31 (2023), 2350125. https://doi.org/10.1142/S0218348X23501256 doi: 10.1142/S0218348X23501256
[23]	Y. Xu, Y. Yang, F. Meng, S. Ruan, Degenerate codimension-2 cusp of limit cycles in a Holling-Tanner model with harvesting and anti-predator behavior, Nonlinear Anal. Real World Appl., 76 (2024), 103995. https://doi.org/10.1016/j.nonrwa.2023.103995 doi: 10.1016/j.nonrwa.2023.103995
[24]	X. Gao, Y. Jin, M. Marwan, F. Li, Y. Wei, Impact of Hopf and bautin bifurcations on an autocatalytic chemical reaction system, MATCH Commun. Math. Comput. Chem., 94 (2025), 863–889. https://doi.org/10.46793/match94-3.09225 doi: 10.46793/match94-3.09225
[25]	Y. A. Kuznetsov, Practical computation of normal forms on center manifolds at degenerate Bogdanov-Takens bifurcations, Int. J. Bifurcation Chaos, 15 (2005), 3535–3546. https://doi.org/10.1142/S0218127405014209 doi: 10.1142/S0218127405014209
[26]	F. A. Carrillo, F. Verduzco, J. Delgado, Analysis of the Takens-Bogdanov bifurcation on m-parameterized vector fields, Int. J. Bifurcation Chaos, 20 (2010), 995–1005. https://doi.org/10.1142/S0218127410026277 doi: 10.1142/S0218127410026277
[27]	X. Liu, S. Liu, Codimension-two bifurcation analysis in two-dimensional Hindmarsh-Rose model, Nonlinear Dyn., 67 (2012), 847–857. https://doi.org/10.1007/s11071-011-0030-6 doi: 10.1007/s11071-011-0030-6
[28]	G. Peng, Y. Jiang, Practical computation of normal forms of the Bogdanov-Takens bifurcation, Nonlinear Dyn., 66 (2011), 99–132. https://doi.org/10.1007/s11071-010-9914-0 doi: 10.1007/s11071-010-9914-0
[29]	C. Li, J. Li, Z. Ma, Codimension 3 B-T bifurcations in an epidemic model with a nonlinear incidence, Discrete Contin. Dyn. Syst. Ser. B, 20 (2015), 1107–1116. https://doi.org/10.3934/dcdsb.2015.20.1107 doi: 10.3934/dcdsb.2015.20.1107
[30]	B. Zeng, P. Yu, M. Han, An efficient solution procedure for solving higher-codimension Hopf and Bogdanov-Takens bifurcations, Commun. Nonlinear Sci. Numer. Simul., 138 (2024), 108241. https://doi.org/10.1016/j.cnsns.2024.108241 doi: 10.1016/j.cnsns.2024.108241
[31]	F. Takens, Forced oscillations and bifurcations, in Global analysis of dynamical systems, Institute of Physics (IOP) Publishing, (2001), 1–61. Available from: https://zbmath.org/1702959.
[32]	R. I. Bogdanov, Bifurcation of the limit cycle of a family of plane vector fields, Sel. Math. Sov., 1 (1981), 373–387. Available from: https://istina.msu.ru/publications/article/2336810/.
[33]	Z. Liu, P. Magal, D. Xiao, Bogdanov-Takens bifurcation in a predator-prey model, Z. Angew. Math. Phys., 67 (2016), 137. https://doi.org/10.1007/s00033-016-0724-1 doi: 10.1007/s00033-016-0724-1
[34]	M. Lu, C. Xiang, J. Huang, Bogdanov-Takens bifurcation in a SIRS epidemic model with a generalized non-monotone incidence rate, Discrete Contin. Dyn. Syst. Ser. S, 13 (2020), 3125–3138. https://doi.org/10.3934/dcdss.2020115 doi: 10.3934/dcdss.2020115
[35]	S. Wang, H. Yu, Equilibria and Bogdanov-Takens bifurcation analysis in the Bazykin's predator-prey system, Discrete Dyn. Nat. Soc., 2022 (2022), 4844228. https://doi.org/10.1155/2022/4844228 doi: 10.1155/2022/4844228
[36]	I. Al-Darabsah, S. A. Campbell, M-current induced Bogdanov-Takens bifurcation and switching of neuron excitability class, J. Math. Neurosci., 11 (2021), 1–26. https://doi.org/10.1186/s13408-021-00103-5 doi: 10.1186/s13408-021-00103-5
[37]	F. Li, M. Marwan, K. Karawanich, On the bifurcations in a quadrotor unmanned aerial vehicle dynamical system using normal form theory, Nonlinear Dyn., 113 (2025), 6405–6425. https://doi.org/10.1007/s11071-024-10483-4 doi: 10.1007/s11071-024-10483-4
[38]	M. Marwan, M. Z. Abidin, On the analytical approach of codimension-three degenerate Bogdanov-Takens (B-T) bifurcation in satellite dynamical system, J. Nonlinear Model. Anal., 5 (2023), 667–681. https://doi.org/10.12150/jnma.2023.667 doi: 10.12150/jnma.2023.667
[39]	L. Fortuna, M. Frasca, A. Buscarino, Optimal and Robust Control: Advanced Topics with MATLAB®, CRC Press, 2021. https://doi.org/10.1201/9781003196921
[40]	F. Lin, G. Xue, B. Qin, S. Li, H. Liu, Event-triggered finite-time fuzzy control approach for fractional-order nonlinear chaotic systems with input delay, Chaos Solitons Fractals, 175 (2023), 114036. https://doi.org/10.1016/j.chaos.2023.114036 doi: 10.1016/j.chaos.2023.114036
[41]	X. Li, S. Lu, Z. Yu, S. Wu, F. Yang, Hybrid control strategy and optimal control for rumor spreading, Chaos Solitons Fractals, 195 (2025), 116180. https://doi.org/10.1016/j.chaos.2025.116180 doi: 10.1016/j.chaos.2025.116180
[42]	J. Iqbal, S. Ahmad, M. Marwan, A. Rafiq, Control analysis of virotherapy chaotic system, J. Biol. Dyn., 16 (2022), 585–595. https://doi.org/10.1080/17513758.2022.2104391 doi: 10.1080/17513758.2022.2104391
[43]	M. Marwan, S. Ahmad, M. Aqeel, M. Sabir, Control analysis of Rucklidge chaotic system, J. Dyn. Syst. Meas. Control, 141 (2019), 041010. https://doi.org/10.1115/1.4042030 doi: 10.1115/1.4042030
[44]	M. Ch-Chaoui, K. Mokni, A multi-parameter bifurcation analysis of a prey–predator model incorporating the prey Allee effect and predator-induced fear, Nonlinear Dyn., 113 (2025), 18879–18911. https://doi.org/10.1007/s11071-025-11063-w doi: 10.1007/s11071-025-11063-w
