X–factorable transformation–based control of interconnected Lotka–Volterra systems

Lőrinc Márton; Katalin M. Hangos; Lőrinc Márton; Katalin M. Hangos

doi:10.3934/mbe.2026065

Mathematical Biosciences and Engineering

2026, Volume 23, Issue 6: 1774-1798. doi: 10.3934/mbe.2026065

Previous Article Next Article

Research article

X–factorable transformation–based control of interconnected Lotka–Volterra systems

Lőrinc Márton ^{1
,
,},
Katalin M. Hangos ^2,3

1.
Department of Electrical Engineering, Sapientia Hungarian University of Transylvania, Corunca, Romania
2.
Systems and Control Laboratory, HUN-REN Institute for Computer Science and Control, Budapest, Hungary
3.
Department of Electrical Engineering and Information Systems, University of Pannonia, Veszprém, Hungary

Received: 22 December 2025 Revised: 20 April 2026 Accepted: 07 May 2026 Published: 22 May 2026

A dynamic model of interconnected Lotka–Volterra systems has been developed both with static and delayed interconnections. We have shown that the X-transformed model of interconnected Lotka–Volterra systems naturally admits a quasi-polynomial (QP) representation, facilitating systematic analysis and control design. In order to analyze local asymptotic stability around a positive equilibrium, we have shown that the X-factorable transformation preserves local diagonal stability. We propose a decentralized setpoint-tracking controller design based on the transformed model that guarantees population persistence in the subsystems of the network. The proposed controller design is computationally simple and ensures that the controlled system is locally diagonally stable around the prescribed setpoint. Moreover, larger controller gains improve disturbance attenuation, mitigating the effect of the disturbance offset term on control performance.
- network dynamics,
- Lotka-Volterra systems,
- quasi-polynomial systems,
- X-factorable transformation,
- setpoint control
Citation: Lőrinc Márton, Katalin M. Hangos. X–factorable transformation–based control of interconnected Lotka–Volterra systems[J]. Mathematical Biosciences and Engineering, 2026, 23(6): 1774-1798. doi: 10.3934/mbe.2026065

Related Papers:

Abstract

A dynamic model of interconnected Lotka–Volterra systems has been developed both with static and delayed interconnections. We have shown that the X-transformed model of interconnected Lotka–Volterra systems naturally admits a quasi-polynomial (QP) representation, facilitating systematic analysis and control design. In order to analyze local asymptotic stability around a positive equilibrium, we have shown that the X-factorable transformation preserves local diagonal stability. We propose a decentralized setpoint-tracking controller design based on the transformed model that guarantees population persistence in the subsystems of the network. The proposed controller design is computationally simple and ensures that the controlled system is locally diagonally stable around the prescribed setpoint. Moreover, larger controller gains improve disturbance attenuation, mitigating the effect of the disturbance offset term on control performance.

References

[1]	Y. Takeuchi, Global Dynamical Properties of Lotka-Volterra Systems, World Scientific Publishing, Singapore, 1996.
[2]	S. Chen, J. Shi, Z. Shuai, Y. Wu, Global dynamics of a Lotka–Volterra competition patch model, Nonlinearity, 35 (2021), 817. https://doi.org/10.1088/1361-6544/ac3c2e doi: 10.1088/1361-6544/ac3c2e
[3]	M. AlAdwani, S. Saavedra, Is the addition of higher-order interactions in ecological models increasing the understanding of ecological dynamics?, Math. Biosci., 315 (2019), 108222. https://doi.org/10.1016/j.mbs.2019.108222 doi: 10.1016/j.mbs.2019.108222
[4]	E. Bairey, E. D. Kelsic, R. Kishony, High-order species interactions shape ecosystem diversity, Nat. Commun., 7 (2016), 12285. https://doi.org/10.1038/ncomms12285 doi: 10.1038/ncomms12285
[5]	P. Singh, G. Baurah, Higher order interactions and species coexistence, Theor. Ecol., 14 (2021), 71–83. https://doi.org/10.1007/s12080-020-00481-8 doi: 10.1007/s12080-020-00481-8
[6]	S. Cui, Q. Zhao, H. Jardon-Kojakhmetov, M. Cao, Species coexistence and extinction resulting from higher-order Lotka-Volterra two-faction competition, in: Proc. IEEE Conf. Decis. Control, 2023,467–472. https://doi.org/10.1109/CDC49753.2023.10384227
[7]	T. Gibbs, S. A. Levin, J. M. Levine, Coexistence in diverse communities with higher-order interactions, PNAS, 119 (2022), e2205063119. https://doi.org/10.1073/pnas.2205063119 doi: 10.1073/pnas.2205063119
[8]	B. Hernández-Bermejo, V. Fairén, Lotka-Volterra representation of general nonlinear systems, Math. Biosci., 140 (1997), 1–32. https://doi.org/10.1016/S0025-5564(96)00131-9 doi: 10.1016/S0025-5564(96)00131-9
[9]	L. Brenig, A. Goriely, Universal canonical forms for time-continuous dynamical systems, Phys. Rev. A, 40 (1989), 4119. https://doi.org/10.1103/PhysRevA.40.4119 doi: 10.1103/PhysRevA.40.4119
[10]	D. Frezzato, Universal embedding of autonomous dynamical systems into a Lotka-Volterra-like format, Phys. Scr., 99 (2024), 015235. https://doi.org/10.1088/1402-4896/ad1236 doi: 10.1088/1402-4896/ad1236
[11]	Y. Takeuchi, Global stability in generalized Lotka-Volterra diffusion systems, J. Math. Anal. Appl., 116 (1986), 209–221. https://doi.org/10.1016/0022-247X(86)90053-3 doi: 10.1016/0022-247X(86)90053-3
[12]	V. A. Jansen, A. L. Lloyd, Local stability analysis of spatially homogeneous solutions of multi-patch systems, J. Math. Biol., 41 (2000), 232–252. https://doi.org/10.1007/s002850000048 doi: 10.1007/s002850000048
[13]	L. Shen, R. Van, Predator–prey–subsidy population dynamics on stepping-stone domains, J. Theor. Biol., 420 (2017), 241–258. https://doi.org/10.1016/j.jtbi.2017.03.013 doi: 10.1016/j.jtbi.2017.03.013
[14]	G. Stépán, Retarded dynamical systems: stability and characteristic functions, Longman Scientific & Technical, 1989.
[15]	J. M. Cushing, Integrodifferential equations and delay models in population dynamics, vol. 20, Springer Science & Business Media, 2013.
[16]	T. Erneux, Applied delay differential equations, vol. 3, Springer Science & Business Media, 2009.
[17]	F. Chen, On a nonlinear nonautonomous predator–prey model with diffusion and distributed delay, J. Comput. Appl. Math., 180 (2005), 33–49. https://doi.org/10.1016/j.cam.2004.10.001 doi: 10.1016/j.cam.2004.10.001
[18]	J. A. Jacquez, C. P. Simon, Qualitative theory of compartmental systems with lags, Math. Biosci., 180 (2002), 329–362. https://doi.org/10.1016/S0025-5564(02)00131-1 doi: 10.1016/S0025-5564(02)00131-1
[19]	C. Chen, X.-W. Wang, Y.-Y. Liu, Stability of ecological systems: A theoretical review, Phys. Rep., 1088 (2024), 1–41. https://doi.org/10.1016/j.physrep.2024.08.001 doi: 10.1016/j.physrep.2024.08.001
[20]	B. Hernández-Bermejo, Stability conditions and Liapunov functions for quasi-polynomial systems, Appl. Math. Lett., 15 (2002), 25–28. https://doi.org/10.1016/S0893-9659(01)00087-8 doi: 10.1016/S0893-9659(01)00087-8
[21]	N. Motee, B. Bamieh, M. Khammash, Stability analysis of quasi-polynomial dynamical systems with applications to biological network models, Automatica, 48 (2012), 2945–2950. https://doi.org/10.1016/j.automatica.2012.06.094 doi: 10.1016/j.automatica.2012.06.094
[22]	A. Figueiredo, I. Gleria, T. Rocha Filho, Boundedness of solutions and Lyapunov functions in quasi-polynomial systems, Phys. Lett. A, 268 (2000), 335–341. https://doi.org/10.1016/S0375-9601(00)00175-4 doi: 10.1016/S0375-9601(00)00175-4
[23]	A. Magyar, G. Szederkényi, K. M. Hangos, Globally stabilizing feedback control of process systems in generalized Lotka–Volterra form, J. Process Control, 18 (2008), 80–91. https://doi.org/10.1016/j.jprocont.2007.05.003 doi: 10.1016/j.jprocont.2007.05.003
[24]	A. Fradkov, I. Pchelkina, M. Ananyevskiy, A. Tomchin, Control of oscillations by control of invariants in quasi-polynomial nonlinear systems, Nonlinear Dyn., 111 (2023), 13955–13967. https://doi.org/10.1007/s11071-023-08566-9 doi: 10.1007/s11071-023-08566-9
[25]	L. Márton, K. M. Hangos, A. Magyar, Passivity of Lotka–Volterra and quasi-polynomial systems, Nonlinearity, 34 (2021), 1880–1899. https://doi.org/10.1088/1361-6544/abd52b doi: 10.1088/1361-6544/abd52b
[26]	A. Slavik, Lotka-Volterra competition model on graphs, SIAM J. Appl. Dyn. Syst., 19 (2020), 725–762. https://doi.org/10.1137/19M1276285 doi: 10.1137/19M1276285
[27]	J. Liu, X. Chen, D. Muñoz de la Peña, P. D. Christofides, Sequential and iterative architectures for distributed model predictive control of nonlinear process systems, AlChE J., 56 (2010), 2137–2149. https://doi.org/10.1002/aic.12155 doi: 10.1002/aic.12155
[28]	P. D. Christofides, R. Scattolini, D. Muñoz de la Peña, J. Liu, Distributed model predictive control: A tutorial review and future research directions, Comput. Chem. Eng., 51 (2013), 21–41. https://doi.org/10.1016/j.compchemeng.2012.05.011 doi: 10.1016/j.compchemeng.2012.05.011
[29]	S. Chen, Z. Wu, P. D. Christofides, Decentralized machine-learning-based predictive control of nonlinear processes, Chem. Eng. Res. Des., 162 (2020), 45–60. https://doi.org/10.1016/j.cherd.2020.07.019 doi: 10.1016/j.cherd.2020.07.019
[30]	L. Dong, Y. Takeuchi, Impulsive control of multiple Lotka-Volterra systems, Nonlinear Anal. Real World Appl., 14 (2013), 1144–1154. https://doi.org/10.1016/j.nonrwa.2012.09.006 doi: 10.1016/j.nonrwa.2012.09.006
[31]	A. S. Anish, B. D. Baets, S. Rao, Metapopulation models with anti-symmetric Lotka-Volterra systems, J. Biol. Dyn., 18 (2024), 2397404. https://doi.org/10.1080/17513758.2024.2397404 doi: 10.1080/17513758.2024.2397404
[32]	A. Muhammadhaji, A. Halik, H.-L. Li, Dynamics in a ratio-dependent Lotka-Volterra competitive-competitive-cooperative system with feedback controls and delays, Adv. Differ. Equations, 2021 (2021), 230. https://doi.org/10.1186/s13662-021-03364-2 doi: 10.1186/s13662-021-03364-2
[33]	Y. Muroya, Global stability of a delayed nonlinear Lotka-Volterra system with feedback controls and patch structure, Appl. Math. Comput., 239 (2014), 60–73. https://doi.org/10.1016/j.amc.2014.04.036 doi: 10.1016/j.amc.2014.04.036
[34]	T. Khan, H. Chaudhary, Estimation and identifiability of parameters for generalized Lotka-Volterra biological systems using adaptive controlled combination difference anti-synchronization, Differ. Equations Dyn. Syst., 28 (2020), 515–528. https://doi.org/10.1007/s12591-020-00534-8 doi: 10.1007/s12591-020-00534-8
[35]	L. Márton, K. M. Hangos, A. Magyar, Migration-connected networks of Lotka-Volterra and quasi-polynomial systems, Nonlinear Dyn., 113 (2025), 10577–10596. https://doi.org/10.1007/s11071-024-10619-6 doi: 10.1007/s11071-024-10619-6
[36]	N. Samardzija, L. D. Greller, E. Wasserman, Nonlinear chemical kinetic schemes derived from mechanical and electrical dynamical systems, J. Chem. Phys., 90 (1989), 2296–2304. https://doi.org/10.1063/1.455970 doi: 10.1063/1.455970
[37]	K. P. Hadeler, Topics in Mathematical Biology, Springer, 2017.
[38]	G. Szederkényi, A. Magyar, K. M. Hangos, Analysis and Control of Polynomial Dynamic Models with Biological Applications, Academic Press, Cambridge, Massachusetts, 2018.
[39]	T. Plesa, Mapping dynamical systems into chemical reactions, Nonlinear Dyn., 113 (2025), 31149–31173. https://doi.org/10.1007/s11071-025-11622-1 doi: 10.1007/s11071-025-11622-1
[40]	G. Cross, Three types of matrix stability, Linear Algebra Appl., 20 (1978), 253–263. https://doi.org/10.1016/0024-3795(78)90021-6 doi: 10.1016/0024-3795(78)90021-6
[41]	L. Márton, G. Szederkényi, K. M. Hangos, Modeling and control of networked kinetic systems with delayed interconnections, J. Process Control, 130 (2023), 103084. https://doi.org/10.1016/j.jprocont.2023.103084 doi: 10.1016/j.jprocont.2023.103084
