A fully decoupled scheme for the simplified Ericksen–Leslie system with variable density

Jiaoyan Hou; Zhaowei Wang; Danxia Wang; Jiaoyan Hou; Zhaowei Wang; Danxia Wang

doi:10.3934/math.20261236

AIMS Mathematics

2026, Volume 11, Issue 9: 31294-31328. doi: 10.3934/math.20261236

Previous Article Next Article

Research article Special Issues

A fully decoupled scheme for the simplified Ericksen–Leslie system with variable density

1.
Shanxi College of Technology, Shuozhou, 036000, Shanxi, China
2.
School of Mathematics, Taiyuan University of Technology, Taiyuan, 030024, Shanxi, China

Received: 10 May 2026 Revised: 12 September 2026 Accepted: 15 September 2026 Published: 23 September 2026
MSC : 35Q35, 65M60

In this work, we develop a fully decoupled sphere-constraint-preserving scheme for the simplified Ericksen–Leslie system with variable density. To begin, the original system is reformulated so that the constraint condition $ |{{\mathbf b}}| = 1 $ can be maintained in the discrete numerical scheme. Next, by employing the Gauge–Uzawa method together with the scalar auxiliary variable (SAV) approach, we construct a first-order time discretization scheme that is fully decoupled and unconditionally energy stable. Combining this with the finite element method (FEM) yields a first-order fully discrete scheme along with its implementation details. A rigorous error analysis is carried out for the temporal semi-discretization. Subsequently, the convergence of the proposed numerical method is established through a rigorous error analysis. Finally, several numerical experiments are carried out to demonstrate the effectiveness of the scheme.
- Ericksen–Leslie,
- variable density,
- Gauge–Uzawa method,
- SAV method
Citation: Jiaoyan Hou, Zhaowei Wang, Danxia Wang. A fully decoupled scheme for the simplified Ericksen–Leslie system with variable density[J]. AIMS Mathematics, 2026, 11(9): 31294-31328. doi: 10.3934/math.20261236

Related Papers:

Abstract

In this work, we develop a fully decoupled sphere-constraint-preserving scheme for the simplified Ericksen–Leslie system with variable density. To begin, the original system is reformulated so that the constraint condition $ |{{\mathbf b}}| = 1 $ can be maintained in the discrete numerical scheme. Next, by employing the Gauge–Uzawa method together with the scalar auxiliary variable (SAV) approach, we construct a first-order time discretization scheme that is fully decoupled and unconditionally energy stable. Combining this with the finite element method (FEM) yields a first-order fully discrete scheme along with its implementation details. A rigorous error analysis is carried out for the temporal semi-discretization. Subsequently, the convergence of the proposed numerical method is established through a rigorous error analysis. Finally, several numerical experiments are carried out to demonstrate the effectiveness of the scheme.

References

[1]	J. Fan, Y. Zhou, Uniform local well-posedness for an Ericksen–Leslie's density-dependent parabolic–hyperbolic liquid crystals model, Appl. Math. Lett., 74 (2017), 79–84. https://doi.org/10.1016/j.aml.2017.04.012 doi: 10.1016/j.aml.2017.04.012
[2]	J. L. Ericksen, Conservation laws for liquid crystals, Trans. Soc. Rheol., 5 (1961), 23–34. https://doi.org/10.1122/1.548883 doi: 10.1122/1.548883
[3]	J. L. Guermond, A. J. Salgado, Error analysis of a fractional time-stepping technique for incompressible flows with variable density, SIAM J. Numer. Anal., 49 (2011), 917–944. https://doi.org/10.1137/090768758 doi: 10.1137/090768758
[4]	F. M. Leslie, Theory of flow phenomena in liquid crystals, Adv. Liq. Cryst., 4 (1979), 1–81. https://doi.org/10.1016/B978-0-12-025004-2.50008-9 doi: 10.1016/B978-0-12-025004-2.50008-9
[5]	F. M. Leslie, Some constitutive equations for liquid crystals, Arch. Ration. Mech. Anal., 28 (1968), 265–283. https://doi.org/10.1007/BF00251810 doi: 10.1007/BF00251810
[6]	F. H. Lin, Nonlinear theory of defects in nematic liquid crystals; phase transition and flow phenomena, Commun. Pure Appl. Math., 42 (1989), 789–814. https://doi.org/10.1002/cpa.3160420605 doi: 10.1002/cpa.3160420605
[7]	C. Liu, N. J. Walkington, Approximation of liquid crystal flows, SIAM J. Numer. Anal., 37 (2000), 725–741. https://doi.org/10.1137/S0036142997327282 doi: 10.1137/S0036142997327282
[8]	P. Lin, C. Liu, H. Zhang, An energy law preserving C0 finite element scheme for simulating the kinematic effects in liquid crystal dynamics, J. Comput. Phys., 227 (2007), 1411–1427. https://doi.org/10.1016/j.jcp.2007.09.008 doi: 10.1016/j.jcp.2007.09.008
[9]	J. Zhao, X. Yang, J. Li, Q. Wang, Energy stable numerical schemes for a hydrodynamic model of nematic liquid crystals, SIAM J. Sci. Comput., 38 (2016), A3264–A3290. https://doi.org/10.1137/15M1024093 doi: 10.1137/15M1024093
[10]	X. Bao, R. Chen, H. Zhang, Constraint-preserving energy-stable scheme for the 2D simplified Ericksen–Leslie system, J. Comput. Math., 39 (2021), 1–21. https://doi.org/10.4208/jcm.1906-m2018-0144 doi: 10.4208/jcm.1906-m2018-0144
[11]	R. C. Cabrales, F. Guillén-González, J. V. Gutiérrez-Santacreu, A time-splitting finite-element stable approximation for the Ericksen–Leslie equations, SIAM J. Sci. Comput., 37 (2015), B261–B282. https://doi.org/10.1137/140960979 doi: 10.1137/140960979
[12]	F. M. Guillén-González, J. V. Gutiérrez-Santacreu, A linear mixed finite element scheme for a nematic Ericksen–Leslie liquid crystal model, ESAIM: Math. Model. Numer. Anal., 47 (2013), 1433–1464. https://doi.org/10.1051/m2an/2013076 doi: 10.1051/m2an/2013076
[13]	X. Zhang, D. Wang, J. Zhang, H. Jia, Fully decoupled linear BDF2 scheme for the penalty incompressible Ericksen–Leslie equations, Math. Comput. Simul., 212 (2023), 249–266. https://doi.org/10.1016/j.matcom.2023.05.001 doi: 10.1016/j.matcom.2023.05.001
[14]	F. De Anna, C. Liu, Non-isothermal general Ericksen–Leslie system: Derivation, analysis and thermodynamic consistency, Arch. Ration. Mech. Anal., 231 (2019), 637–717. https://doi.org/10.1007/s00205-018-1287-4 doi: 10.1007/s00205-018-1287-4
[15]	S. Badia, F. Guillén-González, J. V. Gutiérrez-Santacreu, An overview on numerical analyses of nematic liquid crystal flows, Arch. Comput. Methods Eng., 18 (2011), 285–313. https://doi.org/10.1007/s11831-011-9061-x doi: 10.1007/s11831-011-9061-x
[16]	H. Wu, X. Xu, C. Liu, On the general Ericksen–Leslie system: Parodi's relation, well-posedness and stability, Arch. Ration. Mech. Anal., 208 (2013), 59–107. https://doi.org/10.1007/s00205-012-0588-2 doi: 10.1007/s00205-012-0588-2
[17]	D. Wang, F. Liu, H. Jia, J. Zhang, Error estimates of a sphere-constraint-preserving numerical scheme for Ericksen–Leslie system with variable density, Discrete Contin. Dyn. Syst. B, 28 (2023), 5814–5838. https://doi.org/10.3934/dcdsb.2023065 doi: 10.3934/dcdsb.2023065
[18]	H. Chen, J. Mao, J. Shen, Error estimate of gauge–Uzawa methods for incompressible flows with variable density, J. Comput. Appl. Math., 364 (2020), 112321. https://doi.org/10.1016/j.cam.2019.06.037 doi: 10.1016/j.cam.2019.06.037
[19]	J. Shen, J. Xu, J. Yang, The scalar auxiliary variable (SAV) approach for gradient flows, J. Comput. Phys., 353 (2018), 407–416. https://doi.org/10.1016/j.jcp.2017.10.028 doi: 10.1016/j.jcp.2017.10.028
[20]	X. Li, W. Wang, J. Shen, Stability and error analysis of IMEX SAV schemes for the magneto-hydrodynamic equations, SIAM J. Numer. Anal., 60 (2022), 1026–1054. https://doi.org/10.1137/21M1430376 doi: 10.1137/21M1430376
[21]	A. J. Chorin, Numerical solution of the Navier–Stokes equations, Math. Comp., 22 (1968), 745–762. https://doi.org/10.1090/S0025-5718-1968-0242392-2 doi: 10.1090/S0025-5718-1968-0242392-2
[22]	R. Temam, Sur l'approximation de la solution des équations de Navier–Stokes par la méthode des pas fractionnaires, Arch. Ration. Mech. Anal., 33 (1969), 377–385. https://doi.org/10.1007/BF00247710 doi: 10.1007/BF00247710
[23]	J. L. Guermond, A. Salgado, A splitting method for incompressible flows with variable density based on a pressure Poisson equation, J. Comput. Phys., 228 (2009), 2834–2846. https://doi.org/10.1016/j.jcp.2008.12.028 doi: 10.1016/j.jcp.2008.12.028
[24]	R. H. Nochetto, J. H. Pyo, The gauge–Uzawa FEM. Part Ⅰ: The Navier–Stokes equations, SIAM J. Numer. Anal., 43 (2005), 1043–1068. https://doi.org/10.1137/040609756 doi: 10.1137/040609756
[25]	R. H. Nochetto, J. H. Pyo, The gauge–Uzawa FEM Part Ⅱ: The Boussinesq equations, Math. Models Methods Appl. Sci., 16 (2008), 1599–1626. https://doi.org/10.1142/S0218202506001561 doi: 10.1142/S0218202506001561
[26]	J. H. Pyo, J. Shen, Gauge Uzawa methods for incompressible flows with variable density, Proc. Korean Soc. Ind. Appl. Math., 1 (2006), 75–78.
[27]	J. H. Pyo, The Gauge–Uzawa and Related Projection FEMs for the Evolution Navier–Stokes Equations, University of Maryland, College Park, 2002.
[28]	J. Shen, J. H. Pyo, Normal mode analysis of second-order projection methods for incompressible flows, Discrete Contin. Dyn. Syst., 5 (2005), 817–840. https://doi.org/10.3934/dcds.2005.5.817 doi: 10.3934/dcds.2005.5.817
[29]	J. Shen, On error estimates of projection methods for Navier–Stokes equations: First-order schemes, SIAM J. Numer. Anal., 29 (1992), 57–77. https://doi.org/10.1137/0729004 doi: 10.1137/0729004
[30]	E. Weinan, J. G. Liu, Gauge method for viscous incompressible flows, Commun. Math. Sci., 1 (2003), 317–332. https://doi.org/10.4310/CMS.2003.v1.n2.a6 doi: 10.4310/CMS.2003.v1.n2.a6
[31]	Z. Wang, D. Wang, H. Jia, C. Zhang, First-order, unconditionally stable, fully decoupled methods for the penalty Ericksen–Leslie system with variable density, Adv. Appl. Math. Mech., 18 (2026), 666–699. https://doi.org/10.4208/aamm.OA-2024-0065 doi: 10.4208/aamm.OA-2024-0065
[32]	J. Shen, L. Xue, Q. Zhang, Structure-preserving SAV-RK$s$ spectral methods for nonlinear Hamiltonian system, Commun. Comput. Phys., 39 (2026), 661–695. https://doi.org/10.4208/cicp.OA-2025-0108 doi: 10.4208/cicp.OA-2025-0108
[33]	H. Zhan, T. Wang, G. Hu, An unconditionally energy-stable and orthonormality-preserving scheme for the Kohn–Sham gradient flow based model based on a tetrahedral spectral element method, Commun. Comput. Phys., 37 (2025), 921–941. https://doi.org/10.4208/cicp.OA-2024-0053 doi: 10.4208/cicp.OA-2024-0053
[34]	Z. Zhang, S. Li, J. Lowengrub, S. M. Wise, An efficient constant-coefficient Multiple SAV scheme for computing vesicle growth and shrinkage, Commun. Comput. Phys., (2026). https://doi.org/10.4208/cicp.OA-2026-0008 doi: 10.4208/cicp.OA-2026-0008
[35]	H. Zhu, L. Yang, R. Zhang, Y. Jia, A coupled numerical method for time-fractional convection-diffusion equations based on compressed Legendre polynomials, AIMS Math., 11 (2026), 19488–19515. https://doi.org/10.3934/math.2026792 doi: 10.3934/math.2026792
[36]	J. F. Gerbeau, C. Le Bris, T. Lelièvre, Mathematical Methods for the Magnetohydrodynamics of Liquid Metals, Clarendon Press, 2006.
[37]	Y. He, Unconditional convergence of the Euler semi-implicit scheme for the three-dimensional incompressible MHD equations, IMA J. Numer. Anal., 35 (2015), 767–801. https://doi.org/10.1093/imanum/dru015 doi: 10.1093/imanum/dru015
[38]	A. Figalli, Y. R. Y. Zhang, Sharp gradient stability for the Sobolev inequality, Duke Math. J., 171 (2022), 2407–2459. https://doi.org/10.1215/00127094-2022-0051 doi: 10.1215/00127094-2022-0051
[39]	Z. L. Wang, On the expanded Maxwell's equations for moving charged media system–General theory, mathematical solutions and applications in TENG, Mater. Today, 52 (2022), 348–363. https://doi.org/10.1016/j.mattod.2021.10.027 doi: 10.1016/j.mattod.2021.10.027
[40]	R. Temam, Navier–Stokes Equations and Nonlinear Functional Analysis, SIAM, 1995.
[41]	Z. Cai, M. S. de Queiroz, D. M. Dawson, A sufficiently smooth projection operator, IEEE Trans. Autom. Control, 51 (2006), 135–139. https://doi.org/10.1109/TAC.2005.861704 doi: 10.1109/TAC.2005.861704
[42]	Z. Si, Q. Wang, Y. Wang, A modified characteristic projection FEM for the Kelvin–Voigt viscoelastic fluid equations, Comput. Math. Appl., 109 (2022), 44–57. https://doi.org/10.1016/j.camwa.2022.01.025 doi: 10.1016/j.camwa.2022.01.025
[43]	F. Hecht, New development in FreeFem++, J. Numer. Math., 20 (2012), 251–266. https://doi.org/10.1515/jnum-2012-0013 doi: 10.1515/jnum-2012-0013
