Observer-based boundary stabilization of a reaction–diffusion equation under random measurement deception: a dynamic event-triggered design

Lianglin Xiong; Xueqing Chen; Haiyang Zhang; Tao Wu; Lianglin Xiong; Xueqing Chen; Haiyang Zhang; Tao Wu

doi:10.3934/math.20261117

AIMS Mathematics

2026, Volume 11, Issue 9: 27969-28008. doi: 10.3934/math.20261117

Previous Article Next Article

Research article Special Issues

Observer-based boundary stabilization of a reaction–diffusion equation under random measurement deception: a dynamic event-triggered design

1.
School of Mathematics and Computer Science, Yunnan Minzu University, Kunming 650504, Yunnan, China
2.
Yunnan Open University, Kunming 650504, Yunnan, China
3.
School of Mathematics and Statistics, Yunnan University, Kunming 650504, Yunnan, China

Received: 10 April 2026 Revised: 21 August 2026 Accepted: 25 August 2026 Published: 02 September 2026
MSC : 35K57, 93C20, 93D15

This work considers dynamic event-triggered boundary output feedback control for a one-dimensional reaction–diffusion equation when the boundary measurement may be randomly falsified. The compromised measurement channel is described by a Bernoulli switching model together with a Lipschitz nonlinear deception mapping. To alleviate the control update and actuation burden in networked implementation, a dynamic triggering law equipped with an auxiliary internal state is introduced so that the triggering threshold is adjusted online according to the closed-loop evolution. It is further shown that the triggering instants admit a uniform positive separation, thereby excluding Zeno accumulation. Based on this triggering framework, a backstepping boundary observer and its corresponding boundary feedback law are constructed. A composite Lyapunov analysis is then carried out to establish sufficient conditions for a global mean-square exponential estimate of the plant and observer states with respect to the augmented initial energy despite the coexistence of random deception and event-triggered updating. Numerical simulations, including Monte Carlo tests under independent attack realizations, are finally provided to illustrate the theoretical results. The results show that the proposed scheme stabilizes the originally unstable reaction–diffusion system, maintains effective state estimation under intermittent deceptive measurements, guarantees a positive interevent time, and substantially reduces unnecessary boundary control updates while preserving the desired closed-loop convergence behavior.
- reaction–diffusion equation,
- boundary observer,
- event-triggered boundary control,
- deceptive measurement attacks,
- global mean-square exponential stability
Citation: Lianglin Xiong, Xueqing Chen, Haiyang Zhang, Tao Wu. Observer-based boundary stabilization of a reaction–diffusion equation under random measurement deception: a dynamic event-triggered design[J]. AIMS Mathematics, 2026, 11(9): 27969-28008. doi: 10.3934/math.20261117

Related Papers:

Abstract

This work considers dynamic event-triggered boundary output feedback control for a one-dimensional reaction–diffusion equation when the boundary measurement may be randomly falsified. The compromised measurement channel is described by a Bernoulli switching model together with a Lipschitz nonlinear deception mapping. To alleviate the control update and actuation burden in networked implementation, a dynamic triggering law equipped with an auxiliary internal state is introduced so that the triggering threshold is adjusted online according to the closed-loop evolution. It is further shown that the triggering instants admit a uniform positive separation, thereby excluding Zeno accumulation. Based on this triggering framework, a backstepping boundary observer and its corresponding boundary feedback law are constructed. A composite Lyapunov analysis is then carried out to establish sufficient conditions for a global mean-square exponential estimate of the plant and observer states with respect to the augmented initial energy despite the coexistence of random deception and event-triggered updating. Numerical simulations, including Monte Carlo tests under independent attack realizations, are finally provided to illustrate the theoretical results. The results show that the proposed scheme stabilizes the originally unstable reaction–diffusion system, maintains effective state estimation under intermittent deceptive measurements, guarantees a positive interevent time, and substantially reduces unnecessary boundary control updates while preserving the desired closed-loop convergence behavior.

References

[1]	A. Smyshlyaev, M. Krstic, Backstepping observers for a class of parabolic PDEs, Syst. Control Lett., 54 (2005), 613–625. http://doi.org/10.1016/j.sysconle.2004.11.001 doi: 10.1016/j.sysconle.2004.11.001
[2]	G. A. de Andrade, R. Vazquez, D. J. Pagano, Backstepping-based estimation of thermoacoustic oscillations in a Rijke tube with experimental validation, IEEE Trans. Automat. Contr., 65 (2020), 5336–5343. http://doi.org/10.1109/TAC.2020.2970152 doi: 10.1109/TAC.2020.2970152
[3]	H. Anfinsen, O. M. Aamo, Stabilization of a linear hyperbolic PDE with actuator and sensor dynamics, Automatica, 95 (2018), 104–111. http://doi.org/10.1016/j.automatica.2018.05.019 doi: 10.1016/j.automatica.2018.05.019
[4]	M. Krstic, A. Smyshlyaev, Boundary control of PDEs: a course on backstepping designs, Philadelphia, PA: Society for Industrial and Applied Mathematics, 2008. http://doi.org/10.1137/1.9780898718607
[5]	G. Weiss, Admissibility of unbounded control operators, SIAM J. Control Optim., 27 (1989), 527–545. http://doi.org/10.1137/0327028 doi: 10.1137/0327028
[6]	H. Lhachemi, C. Prieur, Finite-dimensional observer-based boundary stabilization of reaction-diffusion equations with either a Dirichlet or Neumann boundary measurement, Automatica, 135 (2022), 109955. http://doi.org/10.1016/j.automatica.2021.109955 doi: 10.1016/j.automatica.2021.109955
[7]	J. Li, Y. Ding, New mechanism for spatial heterogeneity pattern revealed by nonlocal competition and host-taxis in a 2D pine wilt disease model, J. Math. Biol., 92 (2026), 19. http://doi.org/10.1007/s00285-025-02336-4 doi: 10.1007/s00285-025-02336-4
[8]	Y. Ding, P. Yu, Equivalence of MTS and CMR methods on the normal form of Turing-Hopf bifurcation in delayed reaction–diffusion equations, Chaos Soliton. Fract., 202 (2026), 117485. http://doi.org/10.1016/j.chaos.2025.117485 doi: 10.1016/j.chaos.2025.117485
[9]	R. Vazquez, M. Krstic, Explicit boundary control of reaction-diffusion PDEs on arbitrary-dimensional balls, In: 2015 European control conference (ECC), Linz, Austria, 2015,879–884. http://doi.org/10.1109/ECC.2015.7330653
[10]	T. Hashimoto, M. Krstic, Stabilization of reaction diffusion equations with state delay using boundary control input, IEEE Trans. Automat. Contr., 61 (2016), 4041–4047. http://doi.org/10.1109/TAC.2016.2539001 doi: 10.1109/TAC.2016.2539001
[11]	C. Peng, F. Li, A survey on recent advances in event-triggered communication and control, Inform. Sciences, 457–458 (2018), 113–125. http://doi.org/10.1016/j.ins.2018.04.055 doi: 10.1016/j.ins.2018.04.055
[12]	X.-M. Zhang, Q.-L. Han, B.-L. Zhang, An overview and deep investigation on sampled-data-based event-triggered control and filtering for networked systems, IEEE Trans. Ind. Inform., 13 (2017), 4–16. http://doi.org/10.1109/TII.2016.2607150 doi: 10.1109/TII.2016.2607150
[13]	I. Karafyllis, M. Krstic, Sampled-data boundary feedback control of 1-D parabolic PDEs, Automatica, 87 (2018), 226–237. http://doi.org/10.1016/j.automatica.2017.10.006 doi: 10.1016/j.automatica.2017.10.006
[14]	P. Tabuada, Event-triggered real-time scheduling of stabilizing control tasks, IEEE Trans. Automat. Contr., 52 (2007), 1680–1685. http://doi.org/10.1109/TAC.2007.904277 doi: 10.1109/TAC.2007.904277
[15]	W. P. M. H. Heemels, M. C. F. Donkers, A. R. Teel, Periodic event-triggered control for linear systems, IEEE Trans. Automat. Contr., 58 (2013), 847–861. http://doi.org/10.1109/TAC.2012.2220443 doi: 10.1109/TAC.2012.2220443
[16]	A. Girard, Dynamic triggering mechanisms for event-triggered control, IEEE Trans. Automat. Contr., 60 (2015), 1992–1997. http://doi.org/10.1109/TAC.2014.2366855 doi: 10.1109/TAC.2014.2366855
[17]	M. Abdelrahim, R. Postoyan, J. Daafouz, D. Nešić, Robust event-triggered output feedback controllers for nonlinear systems, Automatica, 75 (2017), 96–108. http://doi.org/10.1016/j.automatica.2016.09.044 doi: 10.1016/j.automatica.2016.09.044
[18]	N. Espitia, A. Girard, N. Marchand, C. Prieur, Event-based control of linear hyperbolic systems of conservation laws, Automatica, 70 (2016), 275–287. http://doi.org/10.1016/j.automatica.2016.04.009 doi: 10.1016/j.automatica.2016.04.009
[19]	A. Selivanov, E. Fridman, Distributed event-triggered control of diffusion semilinear PDEs, Automatica, 68 (2016), 344–351. http://doi.org/10.1016/j.automatica.2016.02.006 doi: 10.1016/j.automatica.2016.02.006
[20]	M. Wakaiki, H. Sano, Event-triggered control of infinite-dimensional systems, SIAM J. Control Optim., 58 (2020), 605–635. http://doi.org/10.1137/18M1179717 doi: 10.1137/18M1179717
[21]	B. Rathnayake, M. Diagne, Global exponential stability of event-triggered control of a parabolic PDE with switching dynamic triggering designs, IMA J. Math. Control Inform., 42 (2025), dnaf042. http://doi.org/10.1093/imamci/dnaf042 doi: 10.1093/imamci/dnaf042
[22]	D. Ding, Q.-L. Han, Y. Xiang, X. Ge, X.-M. Zhang, A survey on security control and attack detection for industrial cyber-physical systems, Neurocomputing, 275 (2018), 1674–1683. http://doi.org/10.1016/j.neucom.2017.10.009 doi: 10.1016/j.neucom.2017.10.009
[23]	A. Teixeira, I. Shames, H. Sandberg, K. H. Johansson, A secure control framework for resource-limited adversaries, Automatica, 51 (2015), 135–148. http://doi.org/10.1016/j.automatica.2014.10.067 doi: 10.1016/j.automatica.2014.10.067
[24]	S.-R. Jia, W.-J. Lin, Adaptive event-triggered reachable set control for Markov jump cyber-physical systems with time-varying delays, AIMS Math., 9 (2024), 25127–25144. http://doi.org/10.3934/math.20241225 doi: 10.3934/math.20241225
[25]	D. Zhao, Z. Wang, G. Wei, Q.-L. Han, A dynamic event-triggered approach to observer-based PID security control subject to deception attacks, Automatica, 120 (2020), 109128. http://doi.org/10.1016/j.automatica.2020.109128 doi: 10.1016/j.automatica.2020.109128
[26]	Y. Deng, Z. Meng, H. Lu, Adaptive event-triggered state estimation for complex networks with nonlinearities against hybrid attacks, AIMS Math., 7 (2022), 2858–2877. http://doi.org/10.3934/math.2022158 doi: 10.3934/math.2022158
[27]	H. Fawzi, P. Tabuada, S. Diggavi, Secure estimation and control for cyber-physical systems under adversarial attacks, IEEE Trans. Automat. Contr., 59 (2014), 1454–1467. http://doi.org/10.1109/TAC.2014.2303233 doi: 10.1109/TAC.2014.2303233
[28]	N. Shukla, N. Keerthana, R. Sakthivel, V. T. Elayabharath, J. Dabas, Observer-reliant event-triggered security control design for stochastic third-order PDE systems with multiple attacks, Eur. J. Control, 82 (2025), 101186. http://doi.org/10.1016/j.ejcon.2025.101186 doi: 10.1016/j.ejcon.2025.101186
[29]	B. Rathnayake, M. Diagne, N. Espitia, I. Karafyllis, Observer-based event-triggered boundary control of a class of reaction-diffusion PDEs, IEEE Trans. Automat. Contr., 67 (2022), 2905–2917. http://doi.org/10.1109/TAC.2021.3094648 doi: 10.1109/TAC.2021.3094648
[30]	F. Koudohode, N. Espitia, M. Krstic, Event-triggered boundary control of an unstable reaction diffusion PDE with input delay, Syst. Control Lett., 186 (2024), 105775. http://doi.org/10.1016/j.sysconle.2024.105775 doi: 10.1016/j.sysconle.2024.105775
[31]	H. Yuan, J. Wang, J. Zeng, W. Lan, Output-feedback event-triggered boundary control of reaction-diffusion PDEs with delayed actuator, Automatica, 176 (2025), 112266. http://doi.org/10.1016/j.automatica.2025.112266 doi: 10.1016/j.automatica.2025.112266
[32]	N. Espitia, J. Auriol, Event-triggered gain scheduling of $2\times 2$ linear hyperbolic PDEs with time and space varying coupling coefficients, Automatica, 179 (2025), 112455. http://doi.org/10.1016/j.automatica.2025.112455 doi: 10.1016/j.automatica.2025.112455
[33]	Y. Xiao, X. Xu, B. Luo, C. Yang, W. Gui, Adaptive event-triggered tracking control for strict-feedback nonlinear ODE cascaded $n+1$ coupled hyperbolic PDE systems, ISA Trans., 164 (2025), 24–33. http://doi.org/10.1016/j.isatra.2025.05.019 doi: 10.1016/j.isatra.2025.05.019
[34]	Z. Chen, J. Tan, Y. He, Z. Cao, Decentralized observer-based event-triggered control for an interconnected fractional-order system with stochastic cyber-attacks, AIMS Math., 9 (2024), 1861–1876. http://doi.org/10.3934/math.2024091 doi: 10.3934/math.2024091
[35]	S. Touhami, A. Chaira, D. F. M. Torres, Harmonic and trace inequalities in Lipschitz domains, In: Frontiers in functional equations and analytic inequalities, Cham: Springer, 2019,599–611. http://doi.org/10.1007/978-3-030-28950-8_30
[36]	J. M. Steele, The Cauchy-Schwarz master class: an introduction to the Art of mathematical inequalities, Cambridge: Cambridge University Press, 2004.
[37]	E. D. Sontag, Y. Wang, New characterizations of input-to-state stability, IEEE Trans. Automat. Contr., 41 (1996), 1283–1294. http://doi.org/10.1109/9.536498 doi: 10.1109/9.536498
[38]	I. Karafyllis, M. Krstic, Input-to-state stability for PDEs, Cham: Springer, 2019. http://doi.org/10.1007/978-3-319-91011-6
[39]	V. V. Kravchenko, Direct and inverse Sturm-Liouville problems: a method of solution, Cham: Birkhäuser, 2020. http://doi.org/10.1007/978-3-030-47849-0
