Analytical bounds and finite element modeling of the temperature distribution on a thin plate heated by a localized radiant source

Jose Lages da Silva Neto; Eduardo D. Correa; Rogerio M. S. Gama; Gustavo R. Anjos; Jose Lages da Silva Neto; Eduardo D. Correa; Rogerio M. S. Gama; Gustavo R. Anjos

doi:10.3934/math.20261100

AIMS Mathematics

2026, Volume 11, Issue 8: 27481-27507. doi: 10.3934/math.20261100

Previous Article Next Article

Research article Special Issues

Analytical bounds and finite element modeling of the temperature distribution on a thin plate heated by a localized radiant source

1.
Department of Mechanical Engineering, Universidade do Estado do Rio de Janeiro–UERJ, Rio de Janeiro, RJ 20550-900, Brazil
2.
Department of Mechanical Engineering/Coppe, Universidade Federal do Rio de Janeiro–UFRJ, Rio de Janeiro, RJ 21941-914, Brazil

Received: 25 June 2026 Revised: 15 August 2026 Accepted: 25 August 2026 Published: 31 August 2026
MSC : 35J61, 65N30, 80A20

This work investigates the steady-state temperature field induced on a thin plate by a small high-temperature radiative source placed at a finite distance. A nonlinear source-to-surface model is derived by coupling in-plane heat conduction, a view-factor-based incident radiative flux, and two-sided radiative losses governed by the Stefan–Boltzmann law. The resulting problem is written in weak form and solved with a Newton-linearized finite element formulation. Analytical upper and lower bounds are established for the temperature field, giving admissible limits that are used to assess the numerical results. The implementation is verified with the method of manufactured solutions, for which the relative $ L^2 $ and $ H^1 $ errors decrease monotonically under mesh refinement. An independent uniform-irradiation benchmark is reproduced to roundoff accuracy, and a separate refinement study for the most localized physical source shows changes below $ 0.01\% $ between the production and reference meshes. Simulations show a strong dependence on source height: the peak temperature decreases from about $ 140 $ to about $ 22 $ K as the dimensionless height increases from $ 0.1 $ to $ 10 $, while the computed extrema remain within the analytical bounds. The rigorous derivation of the radiative source term is restricted to the flat reference plate. Corrugated and perforated geometries are included as illustrative tests of the adaptability of the surface finite element implementation, with corrugated cases interpreted only for very low-amplitude surfaces where self-radiative exchange is neglected.
- radiative heat transfer,
- finite element method,
- Newton linearization,
- Stefan–Boltzmann law,
- method of manufactured solutions,
- a priori bounds
Citation: Jose Lages da Silva Neto, Eduardo D. Correa, Rogerio M. S. Gama, Gustavo R. Anjos. Analytical bounds and finite element modeling of the temperature distribution on a thin plate heated by a localized radiant source[J]. AIMS Mathematics, 2026, 11(8): 27481-27507. doi: 10.3934/math.20261100

Related Papers:

Abstract

This work investigates the steady-state temperature field induced on a thin plate by a small high-temperature radiative source placed at a finite distance. A nonlinear source-to-surface model is derived by coupling in-plane heat conduction, a view-factor-based incident radiative flux, and two-sided radiative losses governed by the Stefan–Boltzmann law. The resulting problem is written in weak form and solved with a Newton-linearized finite element formulation. Analytical upper and lower bounds are established for the temperature field, giving admissible limits that are used to assess the numerical results. The implementation is verified with the method of manufactured solutions, for which the relative $ L^2 $ and $ H^1 $ errors decrease monotonically under mesh refinement. An independent uniform-irradiation benchmark is reproduced to roundoff accuracy, and a separate refinement study for the most localized physical source shows changes below $ 0.01\% $ between the production and reference meshes. Simulations show a strong dependence on source height: the peak temperature decreases from about $ 140 $ to about $ 22 $ K as the dimensionless height increases from $ 0.1 $ to $ 10 $, while the computed extrema remain within the analytical bounds. The rigorous derivation of the radiative source term is restricted to the flat reference plate. Corrugated and perforated geometries are included as illustrative tests of the adaptability of the surface finite element implementation, with corrugated cases interpreted only for very low-amplitude surfaces where self-radiative exchange is neglected.

References

[1]	S. Chen, Q. Duan, Tangent stiffness for nonlinear heat transfer and its application to heterogeneous materials, Int. J. Heat Mass Transfer, 181 (2021), 121888. https://doi.org/10.1016/j.ijheatmasstransfer.2021.121888 doi: 10.1016/j.ijheatmasstransfer.2021.121888
[2]	K. H. Wu, C. Y. Wu, Transient two-dimensional radiative and conductive heat transfer in an axisymmetric medium, Heat Mass Transfer, 33 (1998), 327–331. https://doi.org/10.1007/s002310050197 doi: 10.1007/s002310050197
[3]	J. Tencer, J. R. Howell, Coupling radiative heat transfer in participating media with other heat transfer modes, J. Braz. Soc. Mech. Sci. Eng., 38 (2015), 1473–1487. https://doi.org/10.1007/s40430-015-0434-1 doi: 10.1007/s40430-015-0434-1
[4]	M. F. Modest, Radiative Heat Transfer, 3 Eds, New York: Academic Press, 2013.
[5]	R. Siegel, J. R. Howell, Thermal Radiation Heat Transfer, 4 Eds, Abingdon: Taylor & Francis, 2002.
[6]	H. Zhou, G. Qin, S. Jing, Heat transfer for nonlinear boundary conditions involving radiation for constant and temperature related thermal conductivity material using the mwls method, Eng. Anal. Bound. Elem., 128 (2021), 290–297. https://doi.org/10.1016/j.enganabound.2021.04.013 doi: 10.1016/j.enganabound.2021.04.013
[7]	Y. Filipov, I. Faragó, E. Avdzhieva, P. Filipov, A coupled pde–ode model for nonlinear transient heat transfer with convection heating at the boundary, Axioms, 12 (2023), 323. https://doi.org/10.3390/axioms12040323 doi: 10.3390/axioms12040323
[8]	S. Ouchtout, B. Rousseau, Y. Favennec, Finite element framework for modeling conducto-radiative transfers within heterogeneous media at both discrete and continuous scales, Int. J. Heat Mass Transfer, 197 (2022), 123274. https://doi.org/10.1016/j.ijheatmasstransfer.2022.123274 doi: 10.1016/j.ijheatmasstransfer.2022.123274
[9]	M. L. Martins-Costa, R. M. S. Gama, Temperature distribution in porous fins with radiation and temperature-dependent conductivity, Revista Engenharia Térmica, 19 (2020), 45–53.
[10]	M. K. Gupta, K. J. Bumtariya, H. Shukla, P. Patel, Z. Khan, Methods for evaluation of radiation view factor: A review, Mater. Today Proc., 4 (2017), 1236–1243. https://doi.org/10.1016/j.matpr.2017.01.143 doi: 10.1016/j.matpr.2017.01.143
[11]	M. Singh, A discrete-ordinate weak galerkin method for radiative transfer equation, Appl. Numer. Math., 201 (2024), 628–641. https://doi.org/10.1016/j.apnum.2024.02.009 doi: 10.1016/j.apnum.2024.02.009
[12]	D. Kitzmann, J. Bolte, A. B. C. Patzer, Discontinuous galerkin finite element methods for radiative transfer in spherical symmetry, Astron. Astrophys., 595 (2016), A90. https://doi.org/10.1051/0004-6361/201628578 doi: 10.1051/0004-6361/201628578
[13]	Y. Liu, X. Zhang, M. W. Lu, A meshless method based on least-squares approach for steady- and unsteady-state heat conduction problems, Numer. Heat Transfer, Part B, 47 (2005), 257–275. https://doi.org/10.1080/10407790590901648 doi: 10.1080/10407790590901648
[14]	A. S. Hashemi, M. Heydari, G. B. Loghmani, Iterative compact finite difference method for the numerical study of fully wet porous fins with different profile shapes, Appl. Numer. Math., 186 (2023), 358–377. https://doi.org/10.1016/j.apnum.2023.01.021 doi: 10.1016/j.apnum.2023.01.021
[15]	W. Qu, H. He, A spatial–temporal gfdm with an additional condition for transient heat conduction analysis of fgms, Appl. Math. Lett., 110 (2020), 106579. https://doi.org/10.1016/j.aml.2020.106579 doi: 10.1016/j.aml.2020.106579
[16]	X. Zheng, W. Qu, Y. Gu, A time spectral generalized finite difference method for three-dimensional transient heat conduction analysis in functionally graded materials with space–time coefficients, Int. J. Numer. Meth. Eng., 127 (2026), e70259. https://doi.org/10.1002/nme.70259 doi: 10.1002/nme.70259
[17]	L. M. Ruan, W. An, H. P. Tan, H. Qi, Least-squares finite-element method of multidimensional radiative heat transfer in absorbing and scattering media, Numer. Heat Transfer, Part A, 51 (2007), 657–677. https://doi.org/10.1080/10407780600939578 doi: 10.1080/10407780600939578
[18]	D. Büschgens, C. Steimer, H. Pitsch, Radiation modelling of arbitrary two-dimensional surfaces using the surface-to-surface approach extended with a blocking algorithm, Heat Mass Transfer, 58 (2022), 1637–1648. https://doi.org/10.1007/s00231-022-03203-4 doi: 10.1007/s00231-022-03203-4
[19]	V. Kumar, M. D. Alsulami, I. E. Sarris, B. C. Prasannakumara, S. Rana, Backpropagated neural network modeling for the non-fourier thermal analysis of a moving plate, Mathematics, 11 (2023), 438. https://doi.org/10.3390/math11020438 doi: 10.3390/math11020438
[20]	E. D. Correa, J. M. Quirino, R. L. Sobral, J. F. Corrêa, R. M. S. Gama, An analytical and a numerical method for nonlinear convection-radiation problems in porous fins, Adv. Math. Phys., 2022 (2022), 9033324. https://doi.org/10.1155/2022/9033324 doi: 10.1155/2022/9033324
[21]	V. V. Sarmento, M. L. Martins-Costa, R. M. S. da Gama, A model for a set of porous fins on a long rotating cylinder considering thermal radiation and natural convection, Numer. Heat Transfer, Part B, 84 (2023), 234–252. https://doi.org/10.1080/10407790.2023.2200215 doi: 10.1080/10407790.2023.2200215
[22]	S. Kanwal, S. A. A. Shah, A. Bariq, B. Ali, A. E. Ragab, E. A. Az-Zo'bi, Insight into the dynamics of heat and mass transfer in nanofluid flow with linear/nonlinear mixed convection, thermal radiation, and activation energy effects over the rotating disk, Sci. Rep., 13 (2023), 23031. https://doi.org/10.1038/s41598-023-49988-0 doi: 10.1038/s41598-023-49988-0
[23]	B. Ali, H. Sharif, D. Habib, H. A. Ghazwani, I. Saman, H. Yang, Significance of tri-hybrid nanoparticles in thermal management subject to magnetized squeezing flow of a boger-micropolar nanofluid between concentring disks, J. Mol. Liq., 397 (2024), 124141. https://doi.org/10.1016/j.molliq.2024.124141 doi: 10.1016/j.molliq.2024.124141
[24]	M. M. Bhatti, M. Marin, A. Öchsner, R. Ellahi, Parametric analysis of quadratic convection on granular material flow through an inclined heated plane with heat absorption/generation, Continuum Mech. Thermodyn., 37 (2025), 87. https://doi.org/10.1007/s00161-025-01416-6 doi: 10.1007/s00161-025-01416-6
[25]	S. F. Ramadan, M. M. Bhatti, K. S. Mekheimer, A. M. A. S. Moawad, C. M. Khalique, Magneto-bioconvection dynamics of synovial nanofluids: Consequences of porosity, rheology, and heat generation, J. Comput. Appl. Mech., 57 (2026), 122–133. https://doi.org/10.22059/jcamech.2025.406289.1690 doi: 10.22059/jcamech.2025.406289.1690
[26]	B. Vujanovic, A. M. Strauss, Heat transfer with nonlinear boundary conditions via a variational principle, AIAA J., 9 (1971), 327–339. https://doi.org/10.2514/3.6173 doi: 10.2514/3.6173
[27]	M. T. Darvishi, R. S. R. Gorla, F. Khani, B. J. Gireesha, Thermal analysis of natural convection and radiation in a fully wet porous fin, Int. J. Numer. Meth. Heat Fluid Flow, 26 (2016), 2419–2431. https://doi.org/10.1108/HFF-06-2015-0230 doi: 10.1108/HFF-06-2015-0230
[28]	B. K. Jha, G. Samaila, Thermal radiation effect on boundary layer over a flat plate having convective surface boundary condition, SN Appl. Sci., 2 (2020), 381. https://doi.org/10.1007/s42452-020-2167-8 doi: 10.1007/s42452-020-2167-8
[29]	K. Chandan, K. Karthik, K. V. Nagaraja, B. C. Prasannakumara, R. S. Varun Kumar, T. Muhammad, Radiative heat transfer analysis of a concave porous fin under the local thermal non-equilibrium condition, Appl. Math. Mech.-Engl. Ed., 45 (2024), 1613–1632. https://doi.org/10.1007/s10483-024-3143-6 doi: 10.1007/s10483-024-3143-6
[30]	G. Sowmya, M. M. A. Lashin, M. Ijaz Khan, R. S. Varun Kumar, K. C. Jagadeesha, B. C. Prasannakumara, et al., Significance of convection and internal heat generation on the thermal distribution of a porous dovetail fin with radiative heat transfer, Micromachines, 13 (2022), 1336. https://doi.org/10.3390/mi13081336 doi: 10.3390/mi13081336
[31]	M. R. Nigri, J. J. Pedrosa-Filho, R. M. S. Gama, An exact solution for the heat transfer process in infinite cylindrical fins with any temperature-dependent thermal conductivity, Thermal Sci. Eng. Prog., 32 (2022), 101333. https://doi.org/10.1016/j.tsep.2022.101333 doi: 10.1016/j.tsep.2022.101333
[32]	C. J. Permann, D. R. Gaston, D. Andrs, R. W. Carlsen, F. Kong, A. D. Lindsay, et al., Moose: Enabling massively parallel multiphysics simulation, SoftwareX, 11 (2020), 100430. https://doi.org/10.1016/j.softx.2020.100430 doi: 10.1016/j.softx.2020.100430
[33]	G. Dziuk, C. M. Elliott, Finite element methods for surface pdes, Acta Numer., 22 (2013), 289–396. https://doi.org/10.1017/S0962492913000056 doi: 10.1017/S0962492913000056
[34]	M. A. Olshanskii, A. Reusken, Trace finite element methods for pdes on surfaces, In: Geometrically Unfitted Finite Element Methods and Applications, Berlin: Springer, 2017,211–258. https://doi.org/10.1007/978-3-319-71431-8_7
[35]	R. Adams, J. Fournier, Sobolev Spaces, Amsterdam: Elsevier, 2003.
