1.   Introduction

Emerging and re-emerging infectious diseases remains a major public health concern. In the last four years, the world witnessed an unprecedented outbreak of coronavirus disease (COVID-19). Since its discovery, COVID-19 has been swiftly spreading from one country to another causing massive deaths and economic devastation world wide. As of 4 June 2023, the cumulative reported number of confirmed cases of COVID-19 reached over 767 million and the cumulative number of dealths reaches over 6.9 million deaths globally [1]. Despite significant progress in the development and introduction of new diagnostics, which has lead to a remarkable decline in deaths and new infections, COVID-19 remains a public health challenge. According to the latest estimates from the world health organization (WHO), from 8 May to 4 June 2023 (28 days), over 1.7 million new cases and over 10,000 deaths occurred globally [1]. Compared to the previous 28 days (10 April to 7 May 2023), this represents a decrease of 38% and 47% in cases and deaths, respectively [1].

In spite of a considerable decline in COVID-19 cases and deaths, it remains imperative for researchers to continuously explore the strength of the novel control methods to eradicate the disease. Mathematical models provide powerful tools for explaining and predicting the COVID-19 trend, and also for quantifying the effectiveness of different novel control strategies either singly or combined. Since its discovery, several mathematical models have been formulated to extensively study various aspects of factors involving COVID-19 transmission and control. Ndaïrou et al. [2] employed a system of integer ordinary differential equations (IODEs) to model the effects of super-spreaders on COVID-19 dynamics in Wuhan, China. Findings from their work showed that super-spreaders play a crucial role on the generation of secondary infections.

Rozenfeld et al. [3] proposed a statistical model to evaluate risk factors associated with COVID-19 infection. Their study showed that the risk of COVID-19 infection is higher among groups already affected by health disparities across age, race, ethnicity, language, income and living conditions. Mushayabasa et al. [4] developed a mathematical model based on IODEs to evaluate the role of governmental action and individual reaction on COVID-19 dynamics in South Africa. Their study demonstrated optimal conditions necessary for the infection to die out as well as persist. In [5], a system of IODEs were utilized to investigate the impacts of vaccination on COVID-19 dynamics. They concluded that vaccination could significantly reduce the generation of new infections. To explore the impact of lockdown of COVID-19 transmission dynamics, Ahmed et al. [6] developed a mathematical model based on the Caputo fractional-order. Khan et al. [7] presented a compartmental model based on Caputo-Fabrizio operator to predict COVID-19 dynamics in the Sultanate of Oman. Ghosh and Martcheva [8] developed an epidemic model based on IODEs to investigate the effects of prosocial awareness on COVID-19 dynamics in Colombia and India. Results from their work showed that prosocial awareness has competitive potential to flatten the COVID-19 prevalence curve.

The aforementioned mathematical models of COVID-19 and those cited therein have certainly produced many useful results and improved the existing knowledge on the disease dynamics. However, despite all these efforts, several challenges remain in the mathematical modeling of COVID-19. In particular, since the advent of several COVID-19 vaccines, a large proportion of the population in different parts of the globe has been reluctant to be inoculated [9]–[11]. This phenomena is known as vaccine hesitancy. WHO defines vaccine hesitancy as the delay in acceptance or refusal of vaccines despite the availability of vaccine services [12]. Vaccine hesitancy limits vaccine efficacy [9].

Emperical studies have shown that the average acceptance rates of the COVID-19 vaccines are relatively low across the world, particularly in the Middle East, Russia, Africa and several European countries [9]. In particular, a study conducted in France in October 2020 revealed that 46% of French citizens are vaccine hesitant. Furthermore, studies conducted in other countries revealed the following statistics with regards to COVID-19 vaccine hesitancy: 36% in Spain and USA, 35% in Italy, 32% in South Africa and 31% in Japan and Germany. Globally, vaccine hesitancy and objection has been estimated to be around 27% [13]. Lack of information about the side effects, especially the long-term effects, time-line of the COVID vaccines production, culture and religion issues, political and conspiracy theory, are some of the reasons that have been associated with vaccine hesitancy [9], [10].

Considering these large percentages of hesitance and objection of COVID-19 vaccines, we thought it is prudent to quantify the public health implications of vaccine hesitancy on COVID-19 dynamics. To this end, we developed a mathematical model of COVID-19 transmission that incorporates vaccination effects and non-pharmaceutical interventions (NPIs). Since vaccination is voluntary and most of the COVID-19 vaccines require two or more doses for one to be completely vaccinated, we assume that individuals can choose to be partially or completely vaccinated. Partially vaccinated individuals are those that do not complete all the required vaccine doses while completely vaccinated are those that complete all the required doses per vaccine.

In this study, we are particularly concerned with quantifying the effects of delaying the first and second COVID-19 vaccine dose on disease dynamics. We are cognisant that the Joint Committee on Vaccination and Immunisation (JCVI) recommends the second dose from 3 to 12 weeks after the first dose [14]. Hence, we will evaluate the implications of taking the second dose after 12 weeks (approximately 84 days). Quantifying the effects of interventions enable policy maker and health experts to evaluate the success of an epidemic response so as to improve and inform ongoing and future interventions.

We therefore proposed a mathematical framework based on the Caputo Fractional derivative, since fractional models can more accurately describe biological and natural phenomena than integer ordinary differential equations [15]–[17]. Although there are several fractional derivatives in literature, we have employed the Caputo derivative due to the following reasons (i) the Caputo derivative for a constant has the same outcome as that of an integer ordinary differential equation, (ii) computations based on the Caputo derivative makes use of local initial conditions, and (iii) the Caputo operator computes an ordinary differential equation, followed by a fractional integral to obtain the desired order of fractional derivative [18]–[20]. To the best of our knowledge, there are no studies in literature that have attempted to quantifying the effects of delaying the second COVID-19 vaccine dose using a fractional model.

The rest of the paper is organized as follows: Section 2 presents the material and methods. We present the novel COVID-19 model and its assumptions. Section 3 presents the results and discussions. In particular, we present both analytical and numerical findings. Finally, concluding remarks and limitations rounds up the paper.

2.   Materials and methods

In this section, we present a fractional model to study the transmission of COVID-19 incoportaing NIPs use and vaccination. The model is based on Fractional Calculus (FC), in particular, the Caputo derivative and the Caputo fractional derivative of order q is defined by equation (2.1) [21]:

with t>0, q∈(0,1].

2.1.   Mathematical model

Let S(t), V(t), E(t), I(t), A(t), H(t) and R(t) denote the number of susceptible, vaccinated, exposed, clinically infected, asymptomatic infectious patients, hospitalized, and recovered human at time t, respectively. Thus the total human population at time t is given by N(t)=S(t)+V(t)+E(t)+I(t)+A(t)+H(t)+R(t). The model is formulated based on the following assumptions:

Based on the above assumptions the transmission dynamics of COVID-19 can be summarized by the following system of equation (Model flow diagram is in Figure 1):

3.   Results and discussions

In this section, we present both analytical and numerical results.

3.1.   Non-negativity and boundedness of model solutions

Since model (2.2) monitors human population, it is essential to demonstrate that all model solutions are bounded and positive for all t ≥ 0. Based on the computations in Supplement A, we obtained the following results.

Theorem 3.1. Model (2.2) has unique and non-negative solutions which turn into region Ω₊ as t→∞, where Ω₊ is defined by:

3.2.   Reproduction numbers

One of the most important threshold quantity of epidemiological models is the reproduction number. It demostrates the disease transmission potential during an outbreak. Generally, the reproduction number is defined as the average number of new infections produced by a typical infected individual during their entire infectious period when introduced into a completely susceptible population [23]. To determine the reproduction number we will make use of the Next-generation matrix (NGM) method [24]. Based on the computations in Supplement B, we obtained the expression of reproduction number of model (2.2) as follows (3.2):

where ℜ_0j, for j = A, I, H denotes the average number of secondary infections generated by one infectious individual from epidemiological class j introduced in population wholly of susceptible (vaccinated and unvaccinated) humans. From (3.2) one can observe the totally susceptible (vaccinated and unvaccinated) human population, Λqμq+κq+κqΛq(κq+μq)(μq+θ2q), contracts the disease following contact with infected individuals in classes A, I and H at rate β^q. Disease transmission is assumed to be reduced by human awareness, (1−ϵ). Susceptible vaccinated individuals have lesser chances of contracting the disease compared to susceptible unvaccinated, modelled by a factor 1−φ. Infected individuals have the probability αq(αq+μq) to survive the exposed state to become infectious. A proportion (1−ω) of infected individuals that survive the exposed state will become infectious for an average duration of 1(μq+γ1q+δ2q). The complementary proportion ω, which survive the exposed state and become clinical patients will be infectious for an average period 1(αq+μq)(μq+dq+γ2q+δ1q). Asymptomatic infectious patients detected at rate δ2q are hospitalized and will be infectious for an average period 1(μq+γ1q+δ2q). Clinically infected patients detected at rate δ1q are hospitalized and their average infectious duration is 1(μq+dq+γ2q+δ1q).

3.3.   Stability of the model steady states

The main focus of this section is to analyze the global behavior of model (2.2) by examining its stability. Global stability analysis enables the researcher to understand the evolution of the disease about the model steady states. Comprehensive analysis in Supplement C shows that the following result holds.

Theorem 3.2. If ℜ₀ < 1 then the disease-free equilibrium (DFE) is globally stable. However, if ℜ₀ > 1 the DFE is unstable and a unique equilibrium exists and is a global attractor.

Theorem 3.2 implies that whenever ℜ₀ < 1 the disease dies out in the community and it persists if ℜ₀ > 1. Hence if novel intervention strategies are capable of reducing ℜ₀ to values less than unity then the disease will become extinct.

3.4.   Estimation of model parameters

In order to determine numerical results of model (2.2), we need to estimate the model parameters. We obtain these parameter values using two approaches: some parameter values are adapted from literature and some other parameter values are estimated by computing the root-mean square error (RMSE) as follows:

where n is the number of observations. We will make use of the COVID-19 data for Wuhan, China presented in [2]. Note that the daily cases correspond to the first term of the equation Dt0qH(t). We will use this term to estimate new daily infections of model (2.2). All model parameter values are presented in Table 1. We assumed the initial population levels as follows: S(0) = 4000, V(0) = 0, E(0) = 10, I(0) = 0, A(0) = 0, H(0) = 6, and R(0) = 0. From model (2) the daily new cases correspond to the term δ2qA+δ1qI which account for the detected cases.

Simulation results in Figure 2 shows (a) the RMSE for different derivative orders (b) model fit versus observed values and (c) plot of residuals. From the illustration in (a), one can observe that the minimum error of estimation for the given data occurs for q=0.345. In (b), we can observe that model estimates are extremely close to the observed data. In (c), one can observe that the residuals show very little or no autocorrelation or partial autocorrelation an evidence that we have a good fit.

3.5.   Global sensitivity analysis

We examined the relationship between individual parameters and ℜ₀ when all model parameters are simultaneously varied. We performed this analysis utilizing the partial rank correlation coefficients (PRCC) approach presented in [27], and the results are presented in Figure 3. The output shows that an increasing recruitment and disease transmission rate will increase disease transmission potential. In contrast, the simulations shows that increasing (i) NPIs use; (ii), vaccination of susceptible individuals (with either first dose or more than one dose) and vaccine efficacy will significantly reduce disease transmission potential. Together, these results suggest that reducing disease transmission rate through awareness campaigns and vaccination will significantly reduce disease transmission potential. In addition, results show that NIPs use has most impact on reducing disease transmission potential. We further investigated the relationship between ℜ₀ and four model parameters which are strongly correlated to it; awareness and disease transmission rate (Figure 4). Overall, these simulations confirm that increasing disease transmission rate will increase disease transmission potential and increasing use of NPIs will reduce disease transmission potential.

A contour plot of ℜ₀ as a function of ϵ (NPIs use)and φ (vaccine efficacy)is presented in Figure 5. The values of other model parameters are based on Table 1. We observe that whenever the efficacy of NPIs and vaccine are atleast 80% all the time, then the disease transmission potential is reduce to values below unity. This implies that the disease will die out in the community as guaranteed by Theorem 3.2.

3.6.   Effects of NPIs and vaccination on disease dynamics

Sensitivity analysis results has shown that high NPIs and vaccine efficacy have the potential to reduce transmission potential. Here, we examine the disease dynamics with varying vaccine and NPIs efficacy (Figure 6). Simulation results (Figure 6) concur with earlier findings that increasing NPIs use coupled with high effective vaccine will lead to disease extinction. In particular, one can observe that when both NPIs use and vaccine efficacy exceeds 75% then the disease dies out in the community. Precisely, when ϵ = φ = 0, then ℜ₀ = 3.96 and when ϵ = φ = 75%, then ℜ₀ = 0.2491. Results presented in Figure 6 also concur with analytical results in Theorem 3.2 that if ℜ₀ < 1 the the disease dies out and the reverse occurs for ℜ₀ > 1.

3.7.   Effects of delaying the first COVID-19 vaccine dose on disease dynamics

To assess the effects of delaying the uptake of the first COVID-19 vaccine dose on disease dynamics, we simulated model (2.2) at different values of κ with θ₂ fixed at 0.01 per day. The results are in Figure 7. Results show that a delay exceeding 10 days (κ = 0.1) may lead to disease persistence and the reverse leads to disease extinction.

3.8.   Effects of delaying the second COVID-19 vaccine dose on disease dynamics

To evaluate the effects of delaying the second COVID-19 vaccine dose on disease dynamics, we simulated model (2.2) at different values of θ₂, (the rate at which individuals received more than a single dose) and the other model parameters are fixed as in Table 1. The results are in Figure 8. Simulation results indicates that an increase in the number of individual who take the optimal vaccine doses will lead to disease extinction. Based on these results one can conclude that, if the delay for the second COVID-19 vaccine is more than 100 days (θ₂ = 0.01) then the disease may persist. Results in Figure 7 and 8 both show that delaying accepting COVID-19 vaccines have public health implications.

3.9.   The role of memory effects on disease dynamics

To investigate the role of memory effects on the evolution COVID-19 over time, we simulated model (2.2) for ℜ₀ < 1 (Figure 9) and ℜ₀ > 1 (Figure 10) at different values of q (the derivative order). In all scenarios, we observed that model solutions will converge to a unique equilibrium point. In particular, if ℜ₀ < 1 model solutions converges to DFE and if ℜ₀ > 1 solution converge to a unique endemic equilibrium. Moreover, we observed that for ℜ₀ > 1 model solutions for different derivative orders exhibit an oscillatory behavior before they eventually converge to their respective endemic points. This phenomena was also obsrved in the following studies [28], [29]. In addition, we observed that due to the fractional-order the rate of decay and growth of solutions differs. In particular, when the memory effects are strong (q < 1), the model solutions converges to their respective equilibrium points earlier than when memory effects are weak (q ≈ 1). This outcome was also noted in the work of Nisar et al. [30].

4.   Conclusion remarks

Mathematical models are invaluable tools that can be used to quantitatively evaluate vaccination programs, improve their design and monitor new vaccine initiatives. Although vaccination is voluntary, the success attained by rolling out vaccines lies on vaccine efficacy and its acceptance by the target population. With the efficacy of COVID-19 vaccines estimated to be in the range of 50–95% efficacy [31], their success essentially depended on their acceptance by the population. Despite being highly effective, COVID-19 roll-out has been characterized by vaccine hesitancy. Globally, vaccine hesitancy and objection has been estimated to be around 27% [13]. Using a fractional model in this paper, we evaluated the vaccine hesitancy on COVID-19 dynamics over time. In particular, we evaluated the effects of delaying the first and second COVID-19 dose on disease dynamics over time. In addition, the model also includes the effects of non-pharmaceutical interventions (NPIs).

We employed a fractional model since model based on fractional calculus are capable of describing real world phenomena more accurately compared to integer ordinary differential equations. In particular, we used the Caputo derivative since its derivative for a constant has the same outcome as that of an integer ordinary differential equation. We computed the reproduction number and carried out sensitivity analysis using the partial rank correlation method to assess its relationship with model parameters. Sensitivity analysis results showed that vaccines with relatively high efficacy are capable of minimizing the spread of the epidemic. We also observed that reducing the delay to accept the first and second vaccine doses significantly reduces the epidemic outcomes. In contrast, we observe that parameters associated with recruitment rate of the population and disease transmission can significantly increase the epidemic whenever they are increased.

We also examined the global stability of the model steady states. By constructing suitable Lyapunov functionals, we demonstrated the both the disease-free and endemic equilibrium are globally asymptotically stable whenever they exist. The aforementioned analytical results are supported by numerical illustrations. To underpin and demonstrate this study, we carried out extensive numerical simulations, in particular, we assessed the effects of NPIs and vaccination on disease dynamics. Results showed that vaccines and NIPs interventions that are 75% effective all the time are capable of stopping the epidemic. We also evaluated the implications of vaccine hesitancy on disease dynamics. Outcomes showed that delaying accepting COVID-19 vaccines have public health implications. In particular, a delay of more than 10 and 100 days for the first and second dose, respectively, leads to disease persistence.

Our study has limitations. First, vaccine hesitancy can be triggered or aided by proliferation of anti-vaccination misinformation through social media [32]. As a future work, it will be interesting to modify the proposed model to incorporate media effects. Second, we did not account for heterogeneity in disease transmission. Risks of acquisition, spread, clinical symptoms and disease severity are heterogeneous, as are access to and uptake of universal strategies of confinement, testing and isolation [33]. Despite all these limitations, our findings might be useful for designing and implementing vaccination programs.

5.   Supplement

5.1.   Supplement A: Existence, uniqueness, positivity and boundedness of model solutions

In this section, we present the existence, uniqueness, positivity and boundedness of the solutions of model (2.2). We commence our discussion by demonstrating existence and uniqueness of solutions. Our approach is based on the fixed-point theory. Let ℬ be a Banach space of real-valued continuous functions defined on an interval ℐ with the associated norm:

where ∥S∥=sup{|S(t)|:t∈ℐ, ∥S∥=sup{|S(t)|:t∈ℐ, ∥V∥=sup{|V(t)|:t∈ℐ, ∥E∥=sup{|E(t)|:t∈ℐ, ∥A∥=sup{|A(t)|:t∈ℐ, ∥I∥=sup{|I(t)|:t∈ℐ, ∥H∥=sup{|H(t)|:t∈ℐ, ∥R∥=sup{|R(t)|:t∈ℐ, and ℬ=ℰ(ℐ)×ℰ(ℐ)×ℰ(ℐ)×ℰ(ℐ)×ℰ(ℐ)×ℰ(ℐ)×ℰ(ℐ), with ℰ(ℐ) denoting the Banach space of real-valued continuous functions on ℐ and the associated sup norm. For convenience system (2.2) can be rewritten in the equivalent form given below

By applying the Caputo fractional integral operator, system (5.2), reduces to the following integral equation of Volterra type with Caputo fractional integral of order 0 < q < 1,

Next we prove that the kernels G_i, i=1,2,3,4,5,6,7 fulfill the Lipschitz condition and contraction under some assumptions. In the following theorem, we have demonstrated for G₁ and one can easily verify for the remainder.

Theorem 5.1. Let us consider the following inequality

The kernel G₁ satisfies the Lipschitz condition as well as contraction if the above inequality is satisfied.

Proof. For S and S₁ we proceed as below.

Since A(t), I(t) and H(t) are bounded functions, i.e, ∥A∥≤k1∥, ∥I∥≤k2 and ∥H∥≤k3, by the property of norm functions, the above inequality (9) can be written as

where η1=β(1−ϵ)(k1+k2+k3)+μ+κ. Hence for G₁ the Lipschitz condition is obtained and if an additionally 0≤β(1−ϵ)(k1+k2+k3)+μ+κ<1, we obtain a contraction. The Lipschitz condition for the other kernels are

Recursively, the expression in (5.3) can be written as

The difference between successive terms of system (5.2) in recursive form is given below:

with the initial conditions S0(t)=S(0), V0(t)=V(0), E0(t)=E, A0(t)=A(0), H0(t)=H(0) and R0(t)=R0. Taking the norm of the first equation of (5.8), we obtain

Applying the Lipschitz condition (5.5) one gets

Thus, we have

Similarly, for the remainder of the equations in system (2.2) we have

From (5.12) one can write

Now, we claim the following result which guaranteed the uniqueness of solution of model (2.2).

Theorem 5.2. The proposed fractional epidemic model (2.2) has a unique solution for t∈[0,T] if the following inequality holds

Proof. Earlier we have shown that the kernels conditions given in Eqs. (5.5) and (5.6) holds. Thus by considering the Eqs. (5.12) and (5.14), and by applying the recursive technique we obtained the succeeding results as below

Therefore, the above mentioned sequences exist and satisfy ∥φ1n(t)∥→0, ∥φ2n(t)∥→0, ∥φ3n(t)∥→0, ∥φ4n(t)∥→0, ∥φ5n(t)∥→0, ∥φ6n(t)∥→0, and ∥φ7n(t)∥→0, as n→∞. Furthermore, from Eq. (5.15) and employing the triangle inequality for any k, we one gets

where Ti=1Γ(q)bqηi<1 by hypothesis. Therefore, S_n, E_n, A_n, I_n, H_n and R_n are regardedas Cauchy sequences in the Banach space B(J). Hence they are uniformly convergent as described in [34].Applying the limit theory on Eq. (5.7) when n → ∞ affirms that the limit of these sequences is the unique solution of system (2.2). Ultimately, the existence of a unique solution for system (2.2) has been achieved.

We now demonstrate the positivity of solutions for all t ≥ 0. To prove positivity and boundedness of solutions, we need the following Generalized Mean Value Theorem in [35] and corollary.

Lemma 5.1. Suppose that f(x)∈C[a,b] and Dt0qf(x)∈C[a,b], for 0 < q ≤ 1, then we have

with a≤ξx, ∀x∈(a,b] and Γ(·) is the gamma function.

Corollary 5.1. Suppose that f(x)∈C[a,b] and Dt0qf(x)∈C(a,b], for 0<q≤1. If Dt0qf(x)≥0, ∀x∈(a,b), then f(x) is non-decreasing for each x∈[a,b]. If Dt0qf(x)≤0, ∀x∈(a,b), then f(x) is non-increasing for each x∈[a,b].

We now prove that the non-negative orthant ℝ+7 is positively invariant region. To do this, we need to show that on each hyperplane bounding the non-negative orthant, the vector field points to ℝ+7. From model (2.2), one gets:

Thus, by Corollary 5.1, the solution of model (2.2) are always positive for t ≥ 0. We now demonstrate that all solutions of model (2.2) are bounded above for all t ≥ 0. To do this, we need the following Lemma 5.2 and Lemma 5.3.

Lemma 5.2. (see [36]). Let q>0, n−1<q<n−𝔑 . Suppose that f(t),f′(t),...,f(n−1)(t) are continuous on [t0,∞) and the exponential order and that Dt0qf(t) is piecewise continuous on [t0,∞). Then

where ℱ(s)=ℒ{f(t)}.

Lemma 5.3. (see [37]). Let ℂ be the complex plane. For any α>0 β>0 , and A∈ℂn×n , we have

for ℛs>∥A∥1α, where ℛs represents the real part of the complex number s, and Eα,β is the Mittag-Leffler function [21].

Since all solutions of model system (2.2) have been shown to be positively invariant and have a lower bound zero (5.18)-(5.24), we now proceed to demonstrate that these solutions are bounded above. By summing all equations of system (2.2) one gets:

Taking the Laplace transform of (5.26) leads to:

Combining like terms and arranging leads to

Applying the inverse Laplace transform leads to

where C=max{Λqμq,N(0)}. Thus, N(t) is bounded from above. This completes the proof of Theorem 3.1.

5.2.   Supplement B: Reproduction number

In order to compute the reproduction number using the next generation matrix (NGM) method [24] we first evaluate the disease-free equilibrium (DFE). Through direct calculations one can easily verify that in the absence of COVID-19 in the community the DFE of model (2.2) is:

We now define the nonnegative matrix ℱ that denotes the generation of new infection terms and the non-singular matrix 𝒱 that denotes the remaining transfer terms are respectively given (at the disease-free equilibrium ℰ⁰) by:

It follows from (5.31), that the NGM K of the model (2.2) is (5.32)

where

The spectral radius of (5.32) gives the reproduction number of model (2.2) is given by Equation (3.2).

5.3.   Supplement C: Stability of the model steady states

To investigate the global stability of the model steady states we will construct appropriate Lyapunov functionals. Since the recovered/removed population does not contribute to the generation of secondary infections one can ignore that last equation of model (2.2) when examining the global stability and consider the following reduced system

Now, to investigate the global stability of the DFE let us consider the Lyapunov functional (5.38):

where

where,

Taking the derivative of L₀(t) along the solutions system (5.37) and making some algebraic simplification lead one gets:

If ℛ0≤1, then ℒ′0(t)≤0. Let M be the largest invariant set in Ω, we can observe that ℒ′0(t)=0 iff either ℛ₀ = 1. Therefore, by the Lyapunov-LaSalle invariance principle [38], the DFE is globally asymptotically stable whenever ℛ₀ ≤ 1. This completes the proof.

To demonstrate the second part of Theorem 3.2, we need Lemma 5.4 in [39]:

Lemma 5.4. Let x(·) be a continuous and differentiable function with x(t)∈ℝ+ . Then, for any time instant t≥b, one has

We now proceed to investigate the global stability of the endemic equilibrium. We define the Lyapunov functional:

with

Applying Lemma 5.4 leads to (5.43):

where

It follows that if xi=1, (for i = 1, 2, 3, 4, 5), that is., S=S*, V=V*, E=E*, A=A*, I=I* and H=H* one gets we have Dt0α𝒲(t)=0. Furthermore, Since the arithmetic mean is greater or equal to the geometric mean, that is;

it implies Dt0q𝒲(t)≤0. Using the LaSalle's invariance principle [38], we conclude that the endemic equilibrium point EE of model (2.2) is globally asymptotically stable if ℛ₀ > 1. This completes the second part of Theorem 3.2.
