A block diagonal preconditioner with two preconditioning matrices for saddle point problems

Hong-Yu Wu; Hong-Yu Wu

doi:10.3934/era.2026327

Electronic Research Archive

2026, Volume 34, Issue 10: 7583-7600. doi: 10.3934/era.2026327

Previous Article Next Article

Research article

A block diagonal preconditioner with two preconditioning matrices for saddle point problems

Hong-Yu Wu ^{1,2
,
,}

1.
School of Mathematics and Statistics, Hunan First Normal University, Changsha 410205, China
2.
Hunan Provincial University Key Laboratory for Big Data Analysis and Application, Hunan First Normal University, Changsha 410205, China

Received: 18 April 2026 Revised: 11 August 2026 Accepted: 17 August 2026 Published: 03 September 2026

This paper introduced a block diagonal preconditioner that incorporated two distinct preconditioned matrices for solving saddle point problems. Then we established some convergence conditions for the resulting iterative method under appropriate conditions. Moreover, a spectral property of the preconditioned matrix was also provided. Numerical experiments demonstrated that the proposed preconditioner exhibited superior performance compared with several recently developed preconditioners.
- block diagonal preconditioner,
- saddle point problem,
- convergence,
- iterative method
Citation: Hong-Yu Wu. A block diagonal preconditioner with two preconditioning matrices for saddle point problems[J]. Electronic Research Archive, 2026, 34(10): 7583-7600. doi: 10.3934/era.2026327

Related Papers:

Abstract

This paper introduced a block diagonal preconditioner that incorporated two distinct preconditioned matrices for solving saddle point problems. Then we established some convergence conditions for the resulting iterative method under appropriate conditions. Moreover, a spectral property of the preconditioned matrix was also provided. Numerical experiments demonstrated that the proposed preconditioner exhibited superior performance compared with several recently developed preconditioners.

References

[1]	Z. Bai, Structured preconditioners for nonsingular matrices of block two-by-two structures, Math. Comp., 75 (2006), 791–815. https://doi.org/10.1090/S0025-5718-05-01801-6 doi: 10.1090/S0025-5718-05-01801-6
[2]	Z. Bai, J. Pan, Matrix Analysis and Computations, Society for Industrial and Applied Mathematics, 2021. https://doi.org/10.1137/1.9781611976632
[3]	M. Benzi, G. H. Golub, J. Liesen, Numerical solution of saddle point problems, Acta Numer., 14 (2005), 1–137. https://doi.org/10.1017/S0962492904000212 doi: 10.1017/S0962492904000212
[4]	Z. Bai, A two-step matrix splitting iteration paradigm based on one single splitting for solving systems of linear equations, Numer. Linear Algebra Appl., 31 (2024), 2510. https://doi.org/10.1002/nla.2510 doi: 10.1002/nla.2510
[5]	Z. Bai, G. H. Golub, M. K. Ng, Hermitian and skew-Hermitian splitting methods for non-Hermitian positive definite linear systems, SIAM J. Matrix Anal. Appl., 24 (2003), 603–626. https://doi.org/10.1137/S0895479801395458 doi: 10.1137/S0895479801395458
[6]	C. Li, S. Wu, A single-step HSS method for non-Hermitian positive definite linear systems, Appl. Math. Lett., 44 (2015), 26–29. https://doi.org/10.1016/j.aml.2014.12.013 doi: 10.1016/j.aml.2014.12.013
[7]	X. Wang, X. Xiao, Q. Zheng, A single-step iteration method for non-Hermitian positive definite linear systems, J. Comput. Appl. Math., 346 (2019), 471–482. https://doi.org/10.1016/j.cam.2018.07.021 doi: 10.1016/j.cam.2018.07.021
[8]	M. Benzi, A. J. Wathen, Some preconditioning techniques for saddle point problems, in Model Order Reduction: Theory, Research Aspects and Applications, 13 (2008), 195–211. https://doi.org/10.1007/978-3-540-78841-6_10
[9]	F. P. A. Beik, M. Benzi, S. A. Chaparpordi, On block diagonal and block triangular iterative schemes and preconditioners for stabilized saddle point problems, J. Comput. Appl. Math., 326 (2017), 15–30. https://doi.org/10.1016/j.cam.2017.05.009 doi: 10.1016/j.cam.2017.05.009
[10]	B. S. Southworth, A. A. Sivas, S. Rhebergen, On fixed-point, Krylov, and $2\times2$ block preconditioners for nonsymmetric problems, SIAM J. Matrix Anal. Appl., 41 (2020), 871–900. https://doi.org/10.1137/19M1298317 doi: 10.1137/19M1298317
[11]	E. de Sturler, J. Liesen, Block-diagonal and constraint preconditioners for nonsymmetric indefinite linear systems. Part Ⅰ: Theory, SIAM J. Sci. Comput., 26 (2005), 1598–1619. https://doi.org/10.1137/S1064827502411006 doi: 10.1137/S1064827502411006
[12]	S. H. A. Chaparpordi, F. P. A. Beik, D. K. Salkuyeh, Block triangular preconditioners for stabilized saddle point problems with nonsymmetric (1, 1)-block, Comput. Math. Appl., 76 (2018), 1544–1553. https://doi.org/10.1016/j.camwa.2018.07.006 doi: 10.1016/j.camwa.2018.07.006
[13]	A. Klawonn, G. Starke, Block triangular preconditioners for nonsymmetric saddle point problems: field-of-values analysis, Numer. Math., 81 (1999), 577–594. https://doi.org/10.1007/s002110050405 doi: 10.1007/s002110050405
[14]	X. Xiao, C. Wang, A block upper trangular preconditioner with two parameters for saddle-point problems, Comput. Math. Appl., 160 (2024), 15–29. https://doi.org/10.1016/j.camwa.2024.02.015 doi: 10.1016/j.camwa.2024.02.015
[15]	Z. Bai, M. K. Ng, Z. Wang, Constraint preconditioners for symmetric indefinite matrices, SIAM J. Matrix Anal. Appl., 31 (2009), 410–433. https://doi.org/10.1137/080720243 doi: 10.1137/080720243
[16]	C. Keller, N. I. M. Gould, A. J. Wathen, Constraint preconditioning for indefinite linear systems, SIAM J. Matrix Anal. Appl., 21 (2000), 1300–1317. https://doi.org/10.1137/S0895479899351805 doi: 10.1137/S0895479899351805
[17]	H. Wu, A general class of constraint preconditioners for generalized saddle point linear systems, Appl. Math. Comput., 489 (2025), 129148. https://doi.org/10.1016/j.amc.2024.129148 doi: 10.1016/j.amc.2024.129148
[18]	X. Shao, H. Meng, A new generalized variant of the deteriorated PSS preconditioner for nonsymmetric saddle point problems, Comput. Math. Appl., 118 (2022), 208–213. https://doi.org/10.1016/j.camwa.2022.05.030 doi: 10.1016/j.camwa.2022.05.030
[19]	N. Wang, J. Li, A class of preconditioners based on symmetric-triangular decomposition and matrix splitting for generalized saddle point problems, IMA J. Numer. Anal., 43 (2023), 2998–3025. https://doi.org/10.1093/imanum/drac061 doi: 10.1093/imanum/drac061
[20]	H. Wang, N. Zhang, On the NESS iteration method for singular saddle point problems, J. Comput. Appl. Math., 476 (2026), 117082. https://doi.org/10.1016/j.cam.2025.117082 doi: 10.1016/j.cam.2025.117082
[21]	M. Benzi, G. H. Golub, A preconditioner for generalized saddle point problems, SIAM J. Matrix Anal. Appl., 26 (2004), 20–41. https://doi.org/10.1137/S0895479802417106 doi: 10.1137/S0895479802417106
[22]	Y. Cao, L. Yao, M. Jiang, Q. Niu, A relaxed HSS preconditioner for saddle point problems from meshfree discretization, J. Comput. Math., 31 (2013), 398–421. https://doi.org/10.4208/jcm.1304-m4209 doi: 10.4208/jcm.1304-m4209
[23]	D. K. Salkuyeh, M. Masoudi, A new relaxed HSS preconditioner for saddle point problems, Numer. Algor., 74 (2017), 781–795. https://doi.org/10.1007/s11075-016-0171-2 doi: 10.1007/s11075-016-0171-2
[24]	Z. Bai, M. Benzi, Regularized HSS iteration methods for saddle-point linear systems, BIT Numer. Math., 57 (2017), 287–311. https://doi.org/10.1007/s10543-016-0636-7 doi: 10.1007/s10543-016-0636-7
[25]	Q. Liu, An alternating LHSS preconditioner for saddle point problems, Comput. Appl. Math., 31 (2012), 339–352. https://doi.org/10.1590/S1807-03022012000200007 doi: 10.1590/S1807-03022012000200007
[26]	C. Li, S. Wu, The SHSS preconditioner for saddle point problems, J. Appl. Anal. Comput., 13 (2023), 3221–3230. https://doi.org/10.11948/20220552 doi: 10.11948/20220552
[27]	D. M. Young, Iterative Solution of Large Linear Systems, Academic Press, 1971. https://doi.org/10.1016/C2013-0-11733-3
[28]	Q. Zheng, L. Lu, Extended shift-splitting preconditioners for saddle point problems, J. Comput. Appl. Math., 313 (2017), 70–81. https://doi.org/10.1016/j.cam.2016.09.008 doi: 10.1016/j.cam.2016.09.008
[29]	D. K. Salkuyeh, M. Rahimian, A modification of the generalized shift-splitting method for singular saddle point problems, Comput. Math. Appl., 74 (2017), 2940–2949. https://doi.org/10.1016/j.camwa.2017.07.029 doi: 10.1016/j.camwa.2017.07.029
[30]	H. C. Elman, A. Ramage, D. J. Silvester, Algorithm 866: IFISS, a Matlab toolbox for modelling incompressible flow, ACM Trans. Math. Software, 33 (2007), 14. https://doi.org/10.1145/1236463.1236469 doi: 10.1145/1236463.1236469
[31]	H. C. Elman, D. J. Silvester, A. J. Wathen, Finite Elements and Fast Iterative Solvers: with Applications in Incompressible Fluid Dynamics, Oxford University Press, 2005. https://doi.org/10.1093/oso/9780198528678.001.0001
