Hopf bifurcation analysis in delayed predator-prey models with the Crowley-Martin functional response

Shuang Guo; Xing Qiao; Dan Ma; Shuang Guo; Xing Qiao; Dan Ma

doi:10.3934/era.2026245

Electronic Research Archive

2026, Volume 34, Issue 8: 5478-5495. doi: 10.3934/era.2026245

Previous Article Next Article

Research article

Hopf bifurcation analysis in delayed predator-prey models with the Crowley-Martin functional response

School of Mathematical Sciences, Daqing Normal University, Daqing 163712, China

Received: 03 March 2026 Revised: 29 May 2026 Accepted: 08 June 2026 Published: 30 June 2026

A class of delayed predator-prey models with the Crowley-Martin functional response was investigated in this study. First, the conditions for the stability of the coexistence equilibrium were obtained. Second, by applying the normal form method and the center manifold theorem, the conditions for the occurrence of a Hopf bifurcation induced by the time delay were established, and the direction of the Hopf bifurcation was determined. Finally, numerical simulations were conducted to illustrate the theoretical results. The findings provided insights into the effects of time delay on stability and oscillatory behavior in predator-prey interactions, which are significant for understanding population dynamics in ecology.
- predator-prey model,
- delay,
- Hopf bifurcation,
- Crowley-Martin functional response
Citation: Shuang Guo, Xing Qiao, Dan Ma. Hopf bifurcation analysis in delayed predator-prey models with the Crowley-Martin functional response[J]. Electronic Research Archive, 2026, 34(8): 5478-5495. doi: 10.3934/era.2026245

Related Papers:

Abstract

A class of delayed predator-prey models with the Crowley-Martin functional response was investigated in this study. First, the conditions for the stability of the coexistence equilibrium were obtained. Second, by applying the normal form method and the center manifold theorem, the conditions for the occurrence of a Hopf bifurcation induced by the time delay were established, and the direction of the Hopf bifurcation was determined. Finally, numerical simulations were conducted to illustrate the theoretical results. The findings provided insights into the effects of time delay on stability and oscillatory behavior in predator-prey interactions, which are significant for understanding population dynamics in ecology.

References

[1]	P. A. Abrams, The evolution of predator-prey interactions: Theory and evidence, Annu. Rev. Ecol. Evol. Syst., 31 (2000), 79–105. https://doi.org/ 10.1146/annurev.ecolsys.31.1.79 doi: 10.1146/annurev.ecolsys.31.1.79
[2]	M. Chen, Y. Takeuchi, J. Zhang, Dynamic complexity of a modified Leslie-Gower predator-prey system with fear effect, Commun. Nonlinear Sci. Numer. Simul., 119 (2023), 107109. https://doi.org/10.1016/j.cnsns.2023.107109 doi: 10.1016/j.cnsns.2023.107109
[3]	S. Guo, W. Jiang, Hopf-fold bifurcation and fluctuation phenomena in a delayed ratio-dependent Gause-Type predator-prey model, Int. J. Bifurcation Chaos, 23 (2013), 1350153. https://doi.org/10.1142/s0218127413501538 doi: 10.1142/s0218127413501538
[4]	M. Yang, Y. Nie, Bifurcation analysis of a delayed predator-prey model with Holling-Ⅲ functional response, Z. Angew. Math. Phys., 75 (2024), 240. https://doi.org/10.1007/s00033-024-02376-8 doi: 10.1007/s00033-024-02376-8
[5]	X. Chen, Y. Qi, M. Wang, A strongly coupled predator-prey system with non-monotonic functional response, Nonlinear Anal. Theory Methods Appl., 67 (2007), 1966–1979. https://doi.org/10.1016/j.na.2006.08.022 doi: 10.1016/j.na.2006.08.022
[6]	H. Baek, A food chain system with Holling type Ⅳ functional response and impulsive perturbations, Comput Math Appl., 60 (2010), 1152–1163. https://doi.org/10.1016/j.camwa.2010.05.039 doi: 10.1016/j.camwa.2010.05.039
[7]	Y. Qiao, H. Cao, G. Xu, A double time-delay Holling Ⅱ predation model with weak Allee effect and age-structure, Electron. Res. Arch., 32 (2024), 1749–1769. https://doi.org/10.3934/era.2024080 doi: 10.3934/era.2024080
[8]	L. Wang, R. Xu, G. Feng, A stage-structured predator-prey system with time delay, J. Appl. Math. Comput., 33 (2010), 267–281. https://doi.org/10.1007/s12190-009-0286-x doi: 10.1007/s12190-009-0286-x
[9]	H. Shi, S. Ruan, Spatial, temporal and spatiotemporal patterns of diffusive predator-prey models with mutual interference, IMA J. Appl. Math., 80 (2015), 1534–1568. https://doi.org/10.1093/imamat/hxv006 doi: 10.1093/imamat/hxv006
[10]	P. H. Crowley, E. K. Martin, Functional response and interference within and between year classes of a dragonfly population, J. North Am. Benthological Soc., 8 (1989), 211–221. https://doi.org/10.2307/1467324 doi: 10.2307/1467324
[11]	A. P. Maiti, B. Dubey, J. Tushar, A delayed prey-predator model with Crowley-Martin-type functional response including prey refuge, Math. Methods Appl. Sci., 40 (2017), 5792–5809. https://doi.org/10.1002/mma.4429 doi: 10.1002/mma.4429
[12]	D. Wang, Y. Ma, Bifurcation and turing pattern formation in a diffusion modified Leslie-Gower predator-prey model with Crowley-Martin functional response, J. Appl. Math. Phys., 12 (2024), 2190–2211. https://doi.org/10.4236/jamp.2024.126133 doi: 10.4236/jamp.2024.126133
[13]	Y. Guo, S. Sun, Dynamic behavior of a stochastic non-autonomous predator-prey model with Crowley-Martin functional response and impulses, J. Biol. Syst., 30 (2022), 183–223. https://doi.org/10.1142/S0218339022500061 doi: 10.1142/S0218339022500061
[14]	U. Kumar, A. Kanaujiya, Global dynamics of a prey-predator model with component allee effect for predator reproduction and Crowley-Martin-type functional response:the role of strong Allee effect, Eur. Phys. J. Plus, 139 (2024), 878. https://doi.org/10.1140/epjp/s13360-024-05628-8 doi: 10.1140/epjp/s13360-024-05628-8
[15]	M. Yuan, N. Wang, Stability and bifurcation analysis for a predator-prey model with Crowley-Martin functional response, J. Nonlinear Model. Anal., 7 (2025), 1–19. https://doi.org/10.12150/jnma.2025.1 doi: 10.12150/jnma.2025.1
[16]	H. Wang, S. Liu, H. Li, Prey-taxis as a driver of spatial patterns in predator-prey systems: From spots to spirals and chaos, Chaos, 36 (2026), 013114. https://doi.org/10.1063/5.0312345 doi: 10.1063/5.0312345
[17]	M. Liu, H. Wang, W. Jiang, Bifurcations and pattern formation in a predator-prey model with memory-based diffusion, J. Differ. Equations, 350 (2023), 1–40. https://doi.org/10.1016/j.jde.2022.12.010 doi: 10.1016/j.jde.2022.12.010
[18]	M. Wang, N. Liu, Qualitative analysis and traveling wave solutions of a predator-prey model with time delay and stage structure, Electron. Res. Arch., 32 (2024), 2665–2698. https://doi.org/10.3934/era.2024121 doi: 10.3934/era.2024121
[19]	S. Ruan, J. Wei, On the zeros of a third degree exponential polynomial with applications to a delayed model for the control of testosterone secretion, IMA J. Math. Appl. Med. Biol., 18 (2001), 41–52. https://doi.org/10.1093/imammb/18.1.41 doi: 10.1093/imammb/18.1.41
[20]	J. K. Hale, Theory of Functional Differential Equations, $2^{nd}$ edition, Springer, 1977. https://doi.org/10.1007/978-1-4612-9892-2
[21]	Z. Wei, B. Zhu, J. Yang, M. Perc, M. Slavinec, Bifurcation analysis of two disc dynamos with viscous friction and multiple time delays, Appl. Math. Comput., 347 (2019), 265–281. https://doi.org/10.1016/j.amc.2018.10.090 doi: 10.1016/j.amc.2018.10.090
[22]	T. Faria, L. T. Magalhaes, Normal forms for retarded functional differential equations with parameters and applications to Hopf bifurcation, J. Differ. Equations, 122 (1995), 181–200. https://doi.org/10.1006/jdeq.1995.1144 doi: 10.1006/jdeq.1995.1144
