Vehicle routing problem with trucks and drones collaboration: a structured literature review

Xiaoteng Han; Jun Shen; Xiaoteng Han; Jun Shen

doi:10.3934/aci.2025020

Applied Computing and Intelligence

2025, Volume 5, Issue 2: 348-358. doi: 10.3934/aci.2025020

Previous Article Next Article

Review

Vehicle routing problem with trucks and drones collaboration: a structured literature review

Xiaoteng Han ,
Jun Shen ^,

School of Computing and IT, University of Wollongong, NSW Australia

Academic Editor: Chih-Cheng Hung

Received: 04 December 2025 Revised: 24 December 2025 Accepted: 24 December 2025 Published: 29 December 2025

Coordinated truck-drone delivery has emerged as an important extension of the vehicle routing problem (VRP), offering new opportunities to improve logistics efficiency, accessibility, and sustainability. In this review, we synthesize the literature on truck-drone routing by examining three interrelated themes: Vehicle routing and synchronization models, stochastic and dynamic operational constraints, and payload-energy management. Early studies primarily formulate truck-drone delivery as variants of heterogeneous or two-echelon VRP using mixed-integer linear programming (MILP) to capture coupled routing decisions, drone endurance limits, and launch-retrieval feasibility, often supplemented by heuristic or metaheuristic strategies to address computational scalability. More recent research extends these formulations to stochastic and dynamic VRP settings by incorporating uncertain customer availability, time windows, vehicle delays, and weather disruptions, reflecting a shift toward adaptive routing under incomplete information. Parallel work on payload configuration and energy management investigates modular loading and battery-swapping mechanisms, demonstrating how load heterogeneity and energy constraints fundamentally reshape feasible routing structures. Extensions to multimodal VRP variants, including electric vehicle-drone systems and van-robot hybrids, further broaden applicability in dense and constrained urban environments. Despite these advances, most models remain grounded in static or weakly stochastic assumptions, with limited support for real-time updates or predictive decision-making. In this review, we identified the integration of data-driven prediction and learning-based optimization within dynamic VRP frameworks as a critical direction for advancing truck-drone delivery toward large-scale operational deployment.
- stochastic,
- vehicle routing problem (VRP),
- urban delivery,
- machine learning
Citation: Xiaoteng Han, Jun Shen. Vehicle routing problem with trucks and drones collaboration: a structured literature review[J]. Applied Computing and Intelligence, 2025, 5(2): 348-358. doi: 10.3934/aci.2025020

Related Papers:

Abstract

Coordinated truck-drone delivery has emerged as an important extension of the vehicle routing problem (VRP), offering new opportunities to improve logistics efficiency, accessibility, and sustainability. In this review, we synthesize the literature on truck-drone routing by examining three interrelated themes: Vehicle routing and synchronization models, stochastic and dynamic operational constraints, and payload-energy management. Early studies primarily formulate truck-drone delivery as variants of heterogeneous or two-echelon VRP using mixed-integer linear programming (MILP) to capture coupled routing decisions, drone endurance limits, and launch-retrieval feasibility, often supplemented by heuristic or metaheuristic strategies to address computational scalability. More recent research extends these formulations to stochastic and dynamic VRP settings by incorporating uncertain customer availability, time windows, vehicle delays, and weather disruptions, reflecting a shift toward adaptive routing under incomplete information. Parallel work on payload configuration and energy management investigates modular loading and battery-swapping mechanisms, demonstrating how load heterogeneity and energy constraints fundamentally reshape feasible routing structures. Extensions to multimodal VRP variants, including electric vehicle-drone systems and van-robot hybrids, further broaden applicability in dense and constrained urban environments. Despite these advances, most models remain grounded in static or weakly stochastic assumptions, with limited support for real-time updates or predictive decision-making. In this review, we identified the integration of data-driven prediction and learning-based optimization within dynamic VRP frameworks as a critical direction for advancing truck-drone delivery toward large-scale operational deployment.

References

[1]	S. Yu, J. Puchinger, S. Sun, Van-based robot hybrid pickup and delivery routing problem, Eur. J. Oper. Res., 298 (2022), 894–914. https://doi.org/10.1016/j.ejor.2021.06.009 doi: 10.1016/j.ejor.2021.06.009
[2]	D. Wang, P. Hu, J. Du, P. Zhou, T. Deng, M. Hu, Routing and scheduling for hybrid truck-drone collaborative parcel delivery with independent and truck-carried drones, IEEE Internet Things, 6 (2019), 10483–10495. https://doi.org/10.1109/JIOT.2019.2939397 doi: 10.1109/JIOT.2019.2939397
[3]	P. Kitjacharoenchai, B. Min, S. Lee, Two echelon vehicle routing problem with drones in last mile delivery, Int. J. Prod. Econ., 225 (2020), 107598. https://doi.org/10.1016/j.ijpe.2019.107598 doi: 10.1016/j.ijpe.2019.107598
[4]	A. Anderluh, P. Nolz, V. Hemmelmayr, T. Crainic, Multi-objective optimization of a two-echelon vehicle routing problem with vehicle synchronization and 'grey zone' customers arising in urban logistics, Eur. J. Oper. Res., 289 (2021), 940–958. https://doi.org/10.1016/j.ejor.2019.07.049 doi: 10.1016/j.ejor.2019.07.049
[5]	S. Lichau, R. Sadykov, J. François, R. Dupas, A branch-cut-and-price approach for the two-echelon vehicle routing problem with drones, Comput. Oper. Res., 173 (2025), 106869. https://doi.org/10.1016/j.cor.2024.106869 doi: 10.1016/j.cor.2024.106869
[6]	A. Morim, G. Campuzano, P. Amorim, M. Mes, E. Lalla-Ruiz, The drone-assisted vehicle routing problem with robot stations, Expert Syst. Appl., 238 (2024), 121741. https://doi.org/10.1016/j.eswa.2023.121741 doi: 10.1016/j.eswa.2023.121741
[7]	Z. Wang, J. Sheu, Vehicle routing problem with drones, Transport. Res. B-Meth., 122 (2019), 350–364. https://doi.org/10.1016/j.trb.2019.03.005 doi: 10.1016/j.trb.2019.03.005
[8]	J. M. Leon-Blanco, P. L. Gonzalez-R, J. L. Andrade-Pineda, D. Canca, M. Calle, A multi-agent approach to the truck multi-drone routing problem, Expert Syst. Appl., 195 (2022), 116604. https://doi.org/10.1016/j.eswa.2022.116604 doi: 10.1016/j.eswa.2022.116604
[9]	M. Moshref-Javadi, S. Lee, M. Winkenbach, Design and evaluation of a multi-trip delivery model with truck and drones, Transport. Res. E-Log., 136 (2020), 101887. https://doi.org/10.1016/j.tre.2020.101887 doi: 10.1016/j.tre.2020.101887
[10]	P. L. Gonzalez-R, D. Canca, J. L. Andrade-Pineda, M. Calle, J. M. Leon-Blanco, Truck-drone team logistics: a heuristic approach to multi-drop route planning, Transport. Res. C-Emer., 114 (2020), 657–680. https://doi.org/10.1016/j.trc.2020.02.030 doi: 10.1016/j.trc.2020.02.030
[11]	A. Karak, K. Abdelghany, The hybrid vehicle-drone routing problem for pick-up and delivery services, Transport. Res. C-Emer., 102 (2019), 427–449. https://doi.org/10.1016/j.trc.2019.03.021 doi: 10.1016/j.trc.2019.03.021
[12]	N. A. Kyriakakis, T. Stamadianos, M. Marinaki, Y. Marinakis, The electric vehicle routing problem with drones: an energy minimization approach for aerial deliveries, Clean. Logist. Suppl. C., 4 (2022), 100041. https://doi.org/10.1016/j.clscn.2022.100041 doi: 10.1016/j.clscn.2022.100041
[13]	S. T. W. Mara, R. Sarker, D. Essam, S. Elsayed, Solving electric vehicle-drone routing problem using memetic algorithm, Swarm Evol. Comput., 79 (2023), 101295. https://doi.org/10.1016/j.swevo.2023.101295 doi: 10.1016/j.swevo.2023.101295
[14]	N. Sluijk, A. M. Florio, J. Kinable, N. Dellaert, T. Van Woensel, A chance-constrained two-echelon vehicle routing problem with stochastic demands, Transport. Sci., 57 (2022), 252–272. https://doi.org/10.1287/trsc.2022.1162 doi: 10.1287/trsc.2022.1162
[15]	J. Euchi, A. Sadok, Hybrid genetic-sweep algorithm to solve the vehicle routing problem with drones, Phys. Commun., 44 (2021), 101236. https://doi.org/10.1016/j.phycom.2020.101236 doi: 10.1016/j.phycom.2020.101236
[16]	Q. Zhou, J. Wu, M. Zhu, Y. Zhou, F. Xiao, Y. Zhang, LLM-QL: a LLM-enhanced Q-learning approach for scheduling multiple parallel drones, IEEE Trans. Knowl. Data Eng., 37 (2025), 5393–5406. https://doi.org/10.1109/TKDE.2025.3579386 doi: 10.1109/TKDE.2025.3579386
[17]	B. Zhou, W. Zeng, H. Yang, Multi-trip UAV-UGV delivery network design with release times, Transport. Res. C-Emer., 181 (2025), 105389. https://doi.org/10.1016/j.trc.2025.105389 doi: 10.1016/j.trc.2025.105389
[18]	E. Teimoury, R. Rashid, The sustainable hybrid truck-drone delivery model with stochastic customer existence, Res. Transp. Econ., 100 (2023), 101325. https://doi.org/10.1016/j.retrec.2023.101325 doi: 10.1016/j.retrec.2023.101325
[19]	H. Y. Jeong, B. D. Song, S. Lee, Truck-drone hybrid delivery routing: payload-energy dependency and no-fly zones, Int. J. Prod. Econ., 214 (2019), 220–233. https://doi.org/10.1016/j.ijpe.2019.01.010 doi: 10.1016/j.ijpe.2019.01.010
[20]	M. A. Masmoudi, S. Mancini, R. Baldacci, Y. H. Kuo, Vehicle routing problems with drones equipped with multi-package payload compartments, Transport. Res. E-Log., 164 (2022), 102757. https://doi.org/10.1016/j.tre.2022.102757 doi: 10.1016/j.tre.2022.102757
