An overlay multicast routing method based on network situational awareness and hierarchical multi-agent reinforcement learning

Miao Ye; Yanye Chen; Yong Wang; Cheng Zhu; Qiuxiang Jiang; Gai Huang; Feng Ding; Miao Ye; Yanye Chen; Yong Wang; Cheng Zhu; Qiuxiang Jiang; Gai Huang; Feng Ding

doi:10.3934/era.2026154

Electronic Research Archive

2026, Volume 34, Issue 5: 3447-3480. doi: 10.3934/era.2026154

Previous Article Next Article

Research article Special Issues

An overlay multicast routing method based on network situational awareness and hierarchical multi-agent reinforcement learning

1.
School of Information and Communication, Guilin University of Electronic Technology, Guilin 541000, China
2.
School of Computer Science and Information Security, Guilin University of Electronic Technology, Guilin 541000, China
3.
Information Center, Guilin Medical University, Guilin 541000, China
4.
School of Optoelectronic Engineering, Guilin University of Electronic Technology, Guilin 541000, China

Received: 27 December 2025 Revised: 23 March 2026 Accepted: 02 April 2026 Published: 22 April 2026

Compared with IP multicast, Overlay Multicast (OM) trees constructed at the application layer offer superior compatibility and flexible deployment advantages in heterogeneous, cross-domain networks. However, OM implementations under traditional network architectures suffer from weak adaptability to highly dynamic traffic due to their lack of awareness of underlying physical resource states. Moreover, reinforcement learning-based approaches fail to decouple the multi-objective tightly coupled nature of OM, resulting in high computational complexity, slow policy convergence, and insufficient stability. To address these challenges, we proposed a MA-DHRL-OM routing method. First, leveraging the centralized topological view provided by Software-Defined Networking (SDN), the method collected link-state information and constructed a traffic-aware feature model to provide multi-dimensional decision support for OM path planning. Second, within a unified framework that integrates multi-agent reinforcement learning and hierarchical reinforcement learning, MA-DHRL-OM solves for the optimal OM tree as follows: The hierarchical learning architecture decomposes the construction of the OM tree into a two-stage subtask framework. By designing tailored decision logic and reward signal feedback mechanisms for upper- and lower-layer agents, it achieved hierarchical decoupling of the high-dimensional OM problem, effectively reducing the action space dimensionality and enhancing policy convergence stability. Moreover, the multi-agent collaboration mechanism enabled each agent to make independent decisions based on its local observations, thereby balancing multi-objective optimization while improving the algorithm's overall scalability and adaptability. Extensive simulation experiments demonstrated that, compared with existing methods, MA-DHRL-OM achieves superior performance in optimizing key metrics such as delay, bandwidth utilization, and packet loss rate while exhibiting more stable convergence behavior and greater flexibility in OM routing decisions.
- overlay multicast,
- software-defined networking,
- hierarchical reinforcement learning,
- multi-agent reinforcement learning,
- multicast routing
Citation: Miao Ye, Yanye Chen, Yong Wang, Cheng Zhu, Qiuxiang Jiang, Gai Huang, Feng Ding. An overlay multicast routing method based on network situational awareness and hierarchical multi-agent reinforcement learning[J]. Electronic Research Archive, 2026, 34(5): 3447-3480. doi: 10.3934/era.2026154

Related Papers:

Abstract

Compared with IP multicast, Overlay Multicast (OM) trees constructed at the application layer offer superior compatibility and flexible deployment advantages in heterogeneous, cross-domain networks. However, OM implementations under traditional network architectures suffer from weak adaptability to highly dynamic traffic due to their lack of awareness of underlying physical resource states. Moreover, reinforcement learning-based approaches fail to decouple the multi-objective tightly coupled nature of OM, resulting in high computational complexity, slow policy convergence, and insufficient stability. To address these challenges, we proposed a MA-DHRL-OM routing method. First, leveraging the centralized topological view provided by Software-Defined Networking (SDN), the method collected link-state information and constructed a traffic-aware feature model to provide multi-dimensional decision support for OM path planning. Second, within a unified framework that integrates multi-agent reinforcement learning and hierarchical reinforcement learning, MA-DHRL-OM solves for the optimal OM tree as follows: The hierarchical learning architecture decomposes the construction of the OM tree into a two-stage subtask framework. By designing tailored decision logic and reward signal feedback mechanisms for upper- and lower-layer agents, it achieved hierarchical decoupling of the high-dimensional OM problem, effectively reducing the action space dimensionality and enhancing policy convergence stability. Moreover, the multi-agent collaboration mechanism enabled each agent to make independent decisions based on its local observations, thereby balancing multi-objective optimization while improving the algorithm's overall scalability and adaptability. Extensive simulation experiments demonstrated that, compared with existing methods, MA-DHRL-OM achieves superior performance in optimizing key metrics such as delay, bandwidth utilization, and packet loss rate while exhibiting more stable convergence behavior and greater flexibility in OM routing decisions.
