A hierarchical decoupling framework and hybrid adaptive genetic algorithm for multimachine dual-arm PCB placement scheduling

Chang Kou; Mingze Sun; Ting Song; Jihong Shen; Chang Kou; Mingze Sun; Ting Song; Jihong Shen

doi:10.3934/nhm.2026047

Networks and Heterogeneous Media

2026, Volume 21, Issue 4: 1172-1196. doi: 10.3934/nhm.2026047

Previous Article Next Article

Research article Special Issues

A hierarchical decoupling framework and hybrid adaptive genetic algorithm for multimachine dual-arm PCB placement scheduling

1.
Dalian Rijia Co., Ltd., Dalian 116600, China
2.
College of Mathematical Sciences, Harbin Engineering University, Harbin 150000, China

Received: 18 March 2026 Revised: 05 May 2026 Accepted: 05 June 2026 Published: 10 June 2026

Printed circuit boards (PCBs) are an indispensable part of electronic products. As the consumer electronics market continues to expand, the PCB assembly rate has become a key factor limiting production line efficiency. PCB placement scheduling is a highly complex, multivariable combinatorial optimization problem characterized by nonlinearity and high coupling. From a system perspective, this scheduling problem is modeled as a complex network optimization, wherein the intricate coupling of resources, time, and processes parallels the node interdependencies and information propagation mechanisms inherent in complex system architectures. Given its nondeterministic polynomial-time (NP)-hard nature and the dynamic constraints of the production environment, this study develops a rigorous mathematical model based on motion trajectory analysis and proposes a three-stage hierarchical decoupling framework. This decomposition transforms the high-dimensional network complexity into manageable subtasks while preserving essential variable interdependencies. To solve this complex network optimization, the framework integrates a hybrid adaptive genetic algorithm (HAGA) implemented through a three-level strategy.Initially, an improved adaptive genetic algorithm (IAGA) handles global load balancing; subsequently, an improved spectral clustering algorithm groups components to minimize tool-changing overhead; finally, a hybrid genetic algorithm and ant colony optimization (GA-ACO) optimizes synchronized intramachine paths. Unlike partial-stage methods, this holistic approach ensures synergistic optimization from global network equilibrium to local machine precision. Numerical experiments using real-world data from Dalian Rijia Co., Ltd. demonstrate that HAGA achieves at least a 10% reduction in the production cycle. This research proves that the hierarchical strategy effectively balances computational efficiency with global optimization performance.
Citation: Chang Kou, Mingze Sun, Ting Song, Jihong Shen. A hierarchical decoupling framework and hybrid adaptive genetic algorithm for multimachine dual-arm PCB placement scheduling[J]. Networks and Heterogeneous Media, 2026, 21(4): 1172-1196. doi: 10.3934/nhm.2026047

Related Papers:

Abstract

Printed circuit boards (PCBs) are an indispensable part of electronic products. As the consumer electronics market continues to expand, the PCB assembly rate has become a key factor limiting production line efficiency. PCB placement scheduling is a highly complex, multivariable combinatorial optimization problem characterized by nonlinearity and high coupling. From a system perspective, this scheduling problem is modeled as a complex network optimization, wherein the intricate coupling of resources, time, and processes parallels the node interdependencies and information propagation mechanisms inherent in complex system architectures. Given its nondeterministic polynomial-time (NP)-hard nature and the dynamic constraints of the production environment, this study develops a rigorous mathematical model based on motion trajectory analysis and proposes a three-stage hierarchical decoupling framework. This decomposition transforms the high-dimensional network complexity into manageable subtasks while preserving essential variable interdependencies. To solve this complex network optimization, the framework integrates a hybrid adaptive genetic algorithm (HAGA) implemented through a three-level strategy.Initially, an improved adaptive genetic algorithm (IAGA) handles global load balancing; subsequently, an improved spectral clustering algorithm groups components to minimize tool-changing overhead; finally, a hybrid genetic algorithm and ant colony optimization (GA-ACO) optimizes synchronized intramachine paths. Unlike partial-stage methods, this holistic approach ensures synergistic optimization from global network equilibrium to local machine precision. Numerical experiments using real-world data from Dalian Rijia Co., Ltd. demonstrate that HAGA achieves at least a 10% reduction in the production cycle. This research proves that the hierarchical strategy effectively balances computational efficiency with global optimization performance.
