An unconditionally stable maximum-principle-preserving numerical method for a normalized time-fractional diffusion equation

Xinpei Wu; Ke Zhang; Juho Ma; Junseok Kim; Xinpei Wu; Ke Zhang; Juho Ma; Junseok Kim

doi:10.3934/math.2026922

AIMS Mathematics

2026, Volume 11, Issue 7: 22897-22919. doi: 10.3934/math.2026922

Previous Article Next Article

Research article

An unconditionally stable maximum-principle-preserving numerical method for a normalized time-fractional diffusion equation

1.
Department of Mathematics, Korea University, Seoul 02841, Republic of Korea
2.
School of Mathematics and Statistics, Heze University, Heze 274015, China
3.
College of Mathematics and System Sciences, Xinjiang University, Urumqi 830046, China

Received: 19 May 2026 Revised: 30 June 2026 Accepted: 16 July 2026 Published: 28 July 2026
MSC : 35R11, 39A14, 80M20

In this paper, we present the mathematical and numerical analysis of a numerical method for a normalized time-fractional diffusion equation. The method is unconditionally stable and preserves the maximum principle. The normalized derivative was defined using a weighting function. The integral of this function is always equal to one for all fractional orders and times. This property makes it possible to compare the diffusion behavior under different fractional orders in a fair way. We considered a recently proposed finite difference scheme with an implicit time discretization for the equation. The resulting algebraic system has a tridiagonal matrix. The Thomas algorithm was applied to solve the system efficiently. We proved that the numerical scheme is unconditionally stable, satisfies the maximum principle, and converges correctly. The convergence order is $ O(\Delta t^{2-\alpha}) $ in time and $ O(h^2) $ in space. Several numerical examples were also presented. The results agree with the theoretical analysis and further validate the influence of different fractional orders on the diffusion behavior.
- unconditionally stable numerical scheme,
- normalized time-fractional derivative,
- convergence analysis
Citation: Xinpei Wu, Ke Zhang, Juho Ma, Junseok Kim. An unconditionally stable maximum-principle-preserving numerical method for a normalized time-fractional diffusion equation[J]. AIMS Mathematics, 2026, 11(7): 22897-22919. doi: 10.3934/math.2026922

Related Papers:

Abstract

In this paper, we present the mathematical and numerical analysis of a numerical method for a normalized time-fractional diffusion equation. The method is unconditionally stable and preserves the maximum principle. The normalized derivative was defined using a weighting function. The integral of this function is always equal to one for all fractional orders and times. This property makes it possible to compare the diffusion behavior under different fractional orders in a fair way. We considered a recently proposed finite difference scheme with an implicit time discretization for the equation. The resulting algebraic system has a tridiagonal matrix. The Thomas algorithm was applied to solve the system efficiently. We proved that the numerical scheme is unconditionally stable, satisfies the maximum principle, and converges correctly. The convergence order is $ O(\Delta t^{2-\alpha}) $ in time and $ O(h^2) $ in space. Several numerical examples were also presented. The results agree with the theoretical analysis and further validate the influence of different fractional orders on the diffusion behavior.

References

[1]	F. Effenberger, S. Aerdker, L. Merten, H. Fichtner, Superdiffusion of energetic particles at shocks: a fractional diffusion and Lévy flight model of spatial transport, Astron. Astrophys., 686 (2024), A219. https://doi.org/10.1051/0004-6361/202449334 doi: 10.1051/0004-6361/202449334
[2]	R. Shah, M. Amjad, M. Younis, M. Öztürk, A. Büyükkaya, Analytical and numerical study of nonlinear variable-order time fractional reaction-diffusion coupled equations arising in biological and chemical processes, Fractal Fract., 10 (2026), 151. https://doi.org/10.3390/fractalfract10030151 doi: 10.3390/fractalfract10030151
[3]	X. Zheng, J. Cheng, H. Wang, Uniqueness of determining the variable fractional order in variable-order time-fractional diffusion equations, Inverse Probl., 35 (2019), 125002. https://doi.org/10.1088/1361-6420/ab3aa3 doi: 10.1088/1361-6420/ab3aa3
[4]	J. Hong, B. Jin, Y. Kian, Identification of a spatially-dependent variable order in one-dimensional subdiffusion, SIAM J. Math. Anal., 57 (2025), 1315–1341. https://doi.org/10.1137/24M1673371 doi: 10.1137/24M1673371
[5]	C. Lee, J. Kim, A normalized variable-order time-fractional diffusion equation, Phys. A, 680 (2025), 131052. https://doi.org/10.1016/j.physa.2025.131052 doi: 10.1016/j.physa.2025.131052
[6]	J. Kim, A normalized Caputo-Fabrizio fractional diffusion equation, AIMS Math., 10 (2025), 6195–6208. https://doi.org/10.3934/math.2025282 doi: 10.3934/math.2025282
[7]	S. Bera, M. Sen, S. Nath, Efficient numerical simulation of variable-order fractional diffusion processes with a memory kernel, J. Comput. Sci., 92 (2025), 102705. https://doi.org/10.1016/j.jocs.2025.102705 doi: 10.1016/j.jocs.2025.102705
[8]	J. Cheng, Q. Xia, J. Kim, Y. Li, Decoupled, efficient and structure-preserving numerical scheme for the non-isothermal phase field sintering model, Comput. Math. Appl., 196 (2025), 49–63. https://doi.org/10.1016/j.camwa.2025.07.007 doi: 10.1016/j.camwa.2025.07.007
[9]	Y. Li, Z. Lv, Q. Xia, On the unconditionally stable phase field model of ternary components system considering mass conservation and liquid-solid phase transition, J. Comput. Phys., 543 (2025), 114404. https://doi.org/10.1016/j.jcp.2025.114404 doi: 10.1016/j.jcp.2025.114404
[10]	F. Zhu, K. Sun, G. Zhang, J. Yang, Diffuse-interface modeling and energy-stable numerical framework for the heat transfer-coupled two-phase fluids in contact with solids, J. Comput. Phys., 524 (2025), 113699. https://doi.org/10.1016/j.jcp.2024.113699 doi: 10.1016/j.jcp.2024.113699
[11]	J. Yang, J. Kim, On a two-phase incompressible diffuse interface fluid model with curvature-dependent mobility, J. Comput. Phys., 525 (2025), 113764. https://doi.org/10.1016/j.jcp.2025.113764 doi: 10.1016/j.jcp.2025.113764
[12]	A. Kanwal, S. Boulaaras, R. Shafqat, B. Taufeeq, M. ur Rahman, Explicit scheme for solving variable-order time-fractional initial boundary value problems, Sci. Rep., 14 (2024), 5396. https://doi.org/10.1038/s41598-024-55943-4 doi: 10.1038/s41598-024-55943-4
[13]	J. Jia, C. Jiang, Y. Li, M. Liu, W. Qiu, Variable-order fractional wave equation: analysis, numerical approximation, and fast algorithm, Commun. Nonlinear Sci. Numer. Simul., 158 (2026), 109786. https://doi.org/10.1016/j.cnsns.2026.109786 doi: 10.1016/j.cnsns.2026.109786
[14]	C. Lee, Y. Nam, M. Bang, S. Ham, J. Kim, Numerical investigation of the dynamics for a normalized time-fractional diffusion equation, AIMS Math., 9 (2024), 26671–26687. https://doi.org/10.3934/math.20241297 doi: 10.3934/math.20241297
[15]	M. Jornet, J. J. Nieto, Power-series solution of the L-fractional logistic equation, Appl. Math. Lett., 154 (2024), 109085. https://doi.org/10.1016/j.aml.2024.109085 doi: 10.1016/j.aml.2024.109085
[16]	J. Kim, Maximum principle preserving unconditionally stable method for the Allen–Cahn equation with a high-order potential, Electron. Res. Arch., 33 (2025), 433–446. https://doi.org/10.3934/era.2025021 doi: 10.3934/era.2025021
[17]	Y. Lin, C. Xu, Finite difference/spectral approximations for the time-fractional diffusion equation, J. Comput. Phys., 225 (2007), 1533–1552. https://doi.org/10.1016/j.jcp.2007.02.001 doi: 10.1016/j.jcp.2007.02.001
[18]	W. Zhao, D. Guo, J. Li, Q. Zhao, Cubic spline rule to compute hypersingular integral on a circle, Electron. Res. Arch., 34 (2026), 3008–3023. https://doi.org/10.3934/era.2026136 doi: 10.3934/era.2026136
[19]	J. W. Thomas, Numerical partial differential equations: finite difference methods, Springer, 1995. https://doi.org/10.1007/978-1-4899-7278-1
[20]	S. Kwak, Practical implementation of boundary conditions in the Thomas algorithm, J. Korean Soc. Ind. Appl. Math., 29 (2025), 171–183. https://doi.org/10.12941/jksiam.2025.29.171 doi: 10.12941/jksiam.2025.29.171
[21]	Z. Z. Sun, G. Gao, Fractional differential equations: finite difference methods, Boston De Gruyter, 2020. https://doi.org/10.1515/9783110616064
[22]	S. Su, J. Yang, Maximum principle-preserving, unconditionally energy-stable, and convergent method with second-order accuracy for the phase-field model of image inpainting, Comput. Math. Appl., 183 (2025), 32–45. https://doi.org/10.1016/j.camwa.2025.01.032 doi: 10.1016/j.camwa.2025.01.032
[23]	M. Stynes, E. O'Riordan, J. L. Gracia, Error analysis of a finite difference method on graded meshes for a time-fractional diffusion equation, SIAM J. Numer. Anal., 55 (2017), 1057–1079. https://doi.org/10.1137/16M1082329 doi: 10.1137/16M1082329
