A decision-level fusion hybrid deep learning framework for high-precision automated optical inspection of VCSEL semiconductor devices

Kyu-Jeong Choi; Jin-Taek Seong; Kyu-Jeong Choi; Jin-Taek Seong

doi:10.3934/math.2026594

AIMS Mathematics

2026, Volume 11, Issue 5: 14487-14521. doi: 10.3934/math.2026594

Previous Article Next Article

Research article Special Issues

A decision-level fusion hybrid deep learning framework for high-precision automated optical inspection of VCSEL semiconductor devices

Kyu-Jeong Choi ^1,2,
Jin-Taek Seong ^{1
,
,}

1.
Graduate School of Data Science, Chonnam National University, Gwangju 61186, Republic of Korea
2.
Opticis Company Ltd., Seongnam-si 13354, Republic of Korea

Received: 20 March 2026 Revised: 14 April 2026 Accepted: 24 April 2026 Published: 22 May 2026
MSC : 68T07, 68T45

This paper presents a hybrid deep learning framework for the automated optical inspection (AOI) of vertical cavity surface-emitting laser (VCSEL) semiconductor devices. Manual inspection is limited by subjective inconsistency and operator fatigue, while high-end commercial AOI systems impose substantial costs that are often impractical for small and medium sized manufacturers. The proposed system adopts a decision-level fusion architecture in which defect-specific binary classifiers are aggregated through an OR-gate. This design prioritizes recall so that any defect flagged by at least one sub-classifier triggers rejection, reducing the risk of defect escape. An industrial dataset of 22, 410 images with severe class imbalance (e.g., crack defects comprising less than 0.4% of all labels) was used for training, with targeted augmentation applied to minority classes. Five fold cross-validation yielded an overall accuracy of 98.7% and an F1-score of 93.5%. Deployment on an active production line reduced per-unit inspection time from 17.7 s to 1.5 s (an 89% reduction) and recorded a secondary defect escape rate of 0.00%.
- automated optical inspection,
- vertical cavity surface-emitting laser,
- decision-level fusion,
- hybrid deep learning,
- surface defect detection
Citation: Kyu-Jeong Choi, Jin-Taek Seong. A decision-level fusion hybrid deep learning framework for high-precision automated optical inspection of VCSEL semiconductor devices[J]. AIMS Mathematics, 2026, 11(5): 14487-14521. doi: 10.3934/math.2026594

Related Papers:

Abstract

This paper presents a hybrid deep learning framework for the automated optical inspection (AOI) of vertical cavity surface-emitting laser (VCSEL) semiconductor devices. Manual inspection is limited by subjective inconsistency and operator fatigue, while high-end commercial AOI systems impose substantial costs that are often impractical for small and medium sized manufacturers. The proposed system adopts a decision-level fusion architecture in which defect-specific binary classifiers are aggregated through an OR-gate. This design prioritizes recall so that any defect flagged by at least one sub-classifier triggers rejection, reducing the risk of defect escape. An industrial dataset of 22, 410 images with severe class imbalance (e.g., crack defects comprising less than 0.4% of all labels) was used for training, with targeted augmentation applied to minority classes. Five fold cross-validation yielded an overall accuracy of 98.7% and an F1-score of 93.5%. Deployment on an active production line reduced per-unit inspection time from 17.7 s to 1.5 s (an 89% reduction) and recorded a secondary defect escape rate of 0.00%.
