1.   Introduction

Let $V$ be an $\ell$-dimensional vector space over a field $\mathbb {K}$ of characteristic 0. An arrangement of hyperplanes ${\cal A}$ is a finite collection of codimension one affine subspaces in $V$. An arrangement ${\cal A}$ is called central if every hyperplane $H \in {\cal A}$ goes through the origin.

Let $V^*$ be the dual space of $V$, and $S = S(V^*)$ be the symmetric algebra over $V^*$. A $\mathbb{K}$-linear map $\theta :S \to S$ is called a derivation if for $f, g \in S$,

Let ${\rm{De}}{{\rm{r}}_\mathbb{K}}\left(S \right)$ be the $S$-module of derivations. When ${\cal A}$ is central, for each $H\in {\cal A}$, choose $\alpha_H\in V^{*}$ with $\ker(\alpha_H) = H$. Define an $S$-submodule of ${\rm{De}}{{\rm{r}}_\mathbb{K}}\left(S \right)$, called the module of ${\cal A}$-derivations by

The arrangement ${\cal A}$ is called free if ${\cal D}\left({\cal A} \right)$ is a free $S$-module. Then, ${\cal D}\left({\cal A}\right)$ has a basis comprising of $\ell$ homogeneous elements. For an affine arrangement $\mathcal A$ in $V$, $\bf{c}\mathcal A$ denotes the cone over $\mathcal A$ ^[7], which is a central arrangement in an $(\ell + 1)$-dimensional vector space by adding the new coordinate $z$.

Let $E = {\mathbb{R}}^\ell$ be an $\ell$-dimensional Euclidean space with a coordinate system ${x_1}, \ldots, {x_\ell }$, and let $\Phi$ be a crystallographic irreducible root system in the dual space $E^*$. Let ${\Phi }^+$ be a positive system of $\Phi$. For $\alpha \in {\Phi }^+$ and $k \in \mathbb{Z}$, define an affine hyperplane ${H_{\alpha, k}}$ by

The ${\rm{Shi}}$ arrangement ${\rm{Shi}}\left(\ell \right)$ was introduced by Shi in the study of the Kazhdan-Lusztig representation theory of the affine Weyl groups in ^[9] by

when the root system is of type ${A}_{\ell-1}$.

For $m\in \mathbb{Z}_{\geq 0}$, the extended Shi arrangement $\mathrm{Shi}^{k}$ of the type $\Phi$ is an affine arrangement defined by

There are a lot of researches on the freeness of the cones over the extended Shi arrangements ^[1,3,4]. The first breakthrough was the proof of the freeness of multi-Coxeter arrangements with constant multiplicities by Terao in ^[13]. Combining it with algebro-geometric method, Yoshinaga proved the freeness of the extended Shi arrangements in ^[15]. Nevertheless, there has been limited progress in constructing their bases, and a universal method for determining these bases remains elusive. For types ${A}_{\ell-1}$, $B_\ell$, $C_\ell$, and $D_\ell$, explicit bases for the cones over the Shi arrangements were constructed in ^[6,10,11]. Notably, a basis for the extended Shi arrangements of type $A_2$ was established in ^[2]. Recently, Suyama and Yoshinaga constructed explicit bases for the extended Shi arrangements of type ${A_{\ell-1}}$ using discrete integrals in ^[12]. Feigin et al. presented integral expressions for specific bases of certain multiarrangements in ^[5]. In these studies, Suyama and Terao first constructed a basis for the derivation module of the cone over the Shi arrangement, as detailed in ^[11], with Bernoulli polynomials playing a central role in their approach. The following definitions are pertinent to this result.

For $\left({k_1, k_2} \right) \in {\left({{\mathbb{Z}_{ \ge 0}}} \right)^2}$, the homogenization polynomial of degree $k_1+k_2+1$ is defined by

where ${B_k}\left(x \right)$ denotes the $k$-th Bernoulli polynomial and ${B_k}\left(0 \right) = {B_k}$ denotes the $k$-th Bernoulli number. Using this polynomial, the basis for ${\cal D}\left({\rm{{\bf{c}}Shi}\left(\ell \right) } \right)$ was constructed as follows.

Theorem 1.1. [11, Theorem 3.5] The arrangement ${\rm{{\bf{c}}Shi}\left(\ell \right) }$ is free with the exponents $\left({0, 1, {\ell^{\ell - 1}}} \right)$. The homogeneous derivations

form a basis for ${\cal D}\left({\rm{{\bf{c}}Shi}\left(\ell \right) } \right)$, where $1 \le j \le \ell - 1$ and ${\partial _i}\left({1 \le i \le \ell} \right)$, ${\partial _z}$ denote $\frac{\partial }{{\partial {x_i}}}$, $\frac{\partial }{{\partial z}}$ respectively. $I_{\left[{u, v} \right]}^k$ represents the elementary symmetric function in the variables $\left\{ {{x_u}, {x_{u + 1}}, \ldots, {x_v}} \right\}$ of degree $k$ for $1 \le u \le v \le \ell$.

The above conclusion was reached by using Saito's criterion, which is a crucial theorem for determining the basis of a free arrangement.

Theorem 1.2. [8, Saito's criterion] Let ${\cal A}$ be a central arrangement, and $Q\left({\cal A} \right)$ be the defining polynomial of ${\cal A}$. Given ${\theta _1}, \ldots, {\theta _\ell } \in {\cal D}\left({\cal A} \right)$, the following two conditions are equivalent:

$\left(1 \right)\; {\rm{detM}}\left({{\theta _1}, \ldots, {\theta _\ell }} \right)\doteq Q\left({\cal A} \right),$

$\left(2 \right)\; {\theta _1}, \ldots, {\theta _\ell }$ form a basis for ${\cal D}\left({\cal A} \right)$ over $S$,

where ${\rm{M}}\left({{\theta _1}, \ldots, {\theta _\ell }} \right) = {\Big({{\theta _j}\left({{x_i}} \right)} \Big)_{\ell \times \ell }}$ denotes the coefficient matrix, and $A\doteq B$ means that $A = cB$, $c \in \mathbb{K}\setminus\{0\}$.

This theorem provides a useful tool for determining when a set of derivations forms a basis for the module of derivations associated with a central arrangement.

Let ${\alpha _\ell} = {\left({1, \ldots, 1} \right)^T}$ and ${\beta _\ell } = {\left({{x_1}, \ldots, {x_\ell }} \right)^T}$ be the $\ell \times 1$ column vectors, and define $\psi _{i, j}^{(\ell)} : = \psi _j^{(\ell)}\left({{x_i}} \right)$ for $1 \le i \le \ell$, $1 \le j \le \ell - 1$. Suyuma and Terao in ^[11] proved the equality

which yields

A graph $G = \left(V, E \right)$ is defined as an ordered pair, where the set ${V} = \left\{ 1, 2, \ldots, \ell \right\}$ represents the vertex set, and ${E}$ is a collection of two-element subsets of ${V}$. If $\left\{ i, j \right\} \in {E}$ for some $i, j \in {V}$, then $\left\{ i, j \right\}$ is referred to as an edge. Writing $\left\{ i, j \right\} \in G$ implies $\left\{ i, j \right\} \in {E}$. Let ${U} \subseteq {V}$, and define ${E}\left({U} \right) = \left\{ \{i, j\} \mid i, j \in {U}, \{i, j\} \in{E} \right\}$. We say ${U}$ induces a subgraph $G_{{U}} = \left({U}, {E}\left({U} \right) \right)$. Specifically, we use the symbol $K_{{U}}$ for the induced subgraph of the complete graph $K_{\ell}$. For $i < j$, the interval notation $\left[i, j \right]$ represents $\left\{ i, i + 1, \ldots, j \right\}$.

For a graph $G$ on the vertex set $\left\{ {1, 2, \ldots, \ell} \right\}$, the arrangement ${\rm{Shi}}\left(G \right)$ was defined in ^[14] by

Then, ${\rm Shi}\left(G \right)$ is an arrangement between the Linial arrangement

and the Shi arrangement ${\rm{Shi}}\left(\ell \right)$. Write $\mathcal{A}\left(G \right) : = \mathbf{c}{\rm Shi}\left(G \right)$. It was classified to be free according to the following theorem.

Theorem 1.3. [14, Theorem 3] The arrangement ${\cal A}\left({G} \right)$ is free if and only if $G$ consists of all edges of three complete induced subgraphs ${G_{\left[{1, s} \right]}}, {G_{\left[{t, \ell} \right]}}, {G_{\left[{2, \ell - 1} \right]}}$, where $1 \le s \le \ell$, $t \le s + 1.$ The free arrangement ${\cal A}\left({G} \right)$ has exponents $\left({0, 1, {{\left({\ell - 1} \right)}^{\ell + t- s - 2}}, {\ell^{{s-t + 1}}}} \right)$ for $s < \ell$ and $t > 1$, and $\left({0, 1, {\ell^{\ell - 1}}} \right)$ for $s = \ell$ or $t = 1$.

For $s, t\in \mathbb{Z}^{+}$, we may define the arrangement

By Theorem 1.3, for $1 \le s \le \ell$ and $t \le s+1$, the arrangement ${\cal A}\left[{s, t} \right]$ is free with exponents $\left({0, 1, {{\left({\ell - 1} \right)}^{\ell + t - s - 2}}, {\ell^{{s-t+ 1}}}} \right)$ for $s < \ell$ and $t > 1$, and $\left({0, 1, {\ell^{\ell - 1}}} \right)$ for $s = \ell$ or $t = 1$.

For $0 \le q \le \ell-2$, we write ${\cal A}\left[{q} \right]: = {\cal A}\left[{\ell - 1, \ell - q} \right]$, then ${\cal A}\left[{q} \right]$ is free with exponents $\left({0, 1, {{\left({\ell - 1} \right)}^{\ell - q - 1}}, {\ell ^q}} \right)$.

2.   Main results

In this section, based on the conclusions of Suyama and Terao, we provide an explicit construction of the basis for ${\cal D}\left({{\cal A}\left[q \right]} \right)$, ${0 \le q \le \ell-2}$. First, we shall establish a basis for ${\cal D}\left({{\cal A}\left[0 \right]} \right)$, which is the ingredient of the basis for ${\cal D}\left({{\cal A}\left[q \right]} \right)$.

Theorem 2.1. For $1 \le j \le \ell - 2$, define homogeneous derivations

where

Then, the derivations $\eta _1, \eta _2, \varphi _1^{\left(0 \right)}, \ldots, \varphi _{\ell - 1}^{\left(0 \right)}$ form a basis for ${\cal D}\left({{\cal A}\left[0 \right]} \right)$.

Proof. Write ${\varphi^{\left(0 \right)} _{i, j}}: = \varphi _j^{\left(0 \right)}\left({{x_i}} \right), 1 \le i \le \ell, 1 \le j \le \ell - 1$, and from the definitions of $\varphi_j^{(0)}$ and ${\psi _j^{(\ell)}}$, we can get

for $1 \le i \le \ell-1$, $1 \le j \le \ell-2$. Consequently, for $1 \le m < n \le \ell-1$, it follows that ${\varphi _j^{\left(0 \right)}} \left({{x_m} - {x_n}} \right)$ is divisible by ${{x_m} - {x_n}}$, and ${\varphi _j^{\left(0 \right)}}\left({{x_m} - {x_n} - z} \right)$ is divisible by ${{x_m} - {x_n} - z}.$ For $1 \le m \le \ell-1$, let the congruence notation $\mathop \equiv \limits^{\left({m, k} \right)}$ in the subsequent calculation denote modulo the ideal $\left({{x_m} - {x_\ell} - kz} \right).$ We derive

which implies that ${\varphi _j^{\left(0 \right)}\left({{x_m} - {x_\ell} - z} \right)}$ is divisible by ${{x_m} - {x_\ell} - z}.$ Thus, $\varphi _j^{\left(0 \right)} \in {\cal D}\left({{\cal A}\left[0 \right]} \right)$ for $1 \le j \le \ell-2$. Therefore, we have $\eta _1, \eta _2, \varphi _1^{\left(0 \right)}, \ldots, \varphi _{\ell-1}^{\left(0 \right)}\in {\cal D}\left({{\cal A}\left[0 \right]} \right)$. Additionally, we obtain

According to the equalities (1.1) and (2.1), we have

Hence, we obtain

By applying Theorem 1.2, we conclude that the derivations $\eta _1, \eta _2, \varphi _1^{\left(0 \right)}, \ldots, \varphi _{\ell-1}^{\left(0 \right)}$ form a basis for ${\cal D}\left({{\cal A}\left[0 \right]} \right)$. □

Definition 2.1. For $1 \le q \le \ell - 2$, $1 \le j \le \ell - 1$, define the homogeneous derivations

To prove the derivations $\eta _1, \eta _2, \varphi _1^{\left(q \right)}, \ldots, \varphi _{\ell - 1}^{\left(q \right)}$ form a basis for ${\cal D}\left({{\cal A}\left[q \right]} \right)$, first we prove all such derivations belong to the module ${\cal D}\left({{\cal A}\left[q \right]} \right).$

Theorem 2.2. For $1 \le m \le \ell - 1$, $1 \le j \le \ell - 2$, we have

Proof. We have the following congruence relation of polynomials modulo the ideal $\left({{x_m} - {x_\ell} } \right).$

We complete the proof. □

Remark 2.1 In equality (2.2), we observe that $\prod\limits_{s = j + 2}^{\ell - 1} {\left({{x_s} - {x_m }} \right)} = 0$ for $j+2 \le m \le \ell-1$. This implies that $\varphi _j^{\left(0 \right)}\left({{x_m} - {x_\ell}} \right)$ is divisible by ${{x_m} - {x_\ell}}$ for $1 \le j \le \ell-3$ and $j+2 \le m \le \ell-1$.

According to Remark 2.1, for $1 \le j \le \ell-q-2$, we have $\varphi_{j}^{(0)}\left(x_{m}-x_{\ell}\right)$ is divisible by $x_{m}-x_{\ell}$ for $\ell-q \leq m \leq \ell-1$, which implies that $\varphi _j^{\left(q \right)} = \varphi _j^{\left(0 \right)} \in {\cal D}\left({{\cal A}\left[q \right]} \right)$. Therefore, to prove the derivations belong to the module ${\cal D}\left({{\cal A}\left[q \right]} \right)$, it suffices to prove $\varphi _j^{\left(q \right)} \in {\cal D}\left({{\cal A}\left[q \right]} \right)$ for $\ell-q-1 \le j \le \ell-1$.

For the sake of convenience in the proof, let us introduce the notations for $f, g, h\in \mathbb{Z}^{+}$,

If $g > h$, we agree that ${\rm{A}}_f^{\left[{g, h} \right]} = {\rm{B}}_f^{\left[{g, h} \right]} = 1$.

Lemma 2.1. For any $u, v, w \in \mathbb {Z}^+$ that satisfy $4 \leq \ell-j+1 \leq u \leq \ell-2$, $3 \leq v \leq \ell-2$, and $3 \leq w \leq \ell-2$, we have the following three equalities:

Proof. We will only prove equality (2.5) by induction on $w$. The proofs of equalities (2.3) and (2.4) are similar. For $w = 3$,

and the equality holds. Assume that for $w = k\le \ell-3$, the equality holds. Then, we replace ${x_{\ell-k-1}}$ with ${x_{\ell-k-2}}$, and multiply both sides of the equality by $({x_{\ell-k-1}} - {x_{\ell-k-2}} - z)$ to get

We have completed the induction. □

Lemma 2.2. The derivation $\varphi _j^{\left(q \right)}$ belongs to the module ${\cal D}\left({{\cal A}\left[q \right]} \right)$ for ${2 \le q \le \ell-2}$ and $\ell-q-1 \le j \le \ell-3$.

Proof. For $2 \le q \le \ell-2$ and $j = \ell-q-1$, it is evident from Remark 2.1 that

For $3 \le q \le \ell-2$ and $\ell-q \le j \le \ell-3$, we will establish this by induction on $q$. From Theorem 2.2, for $\ell-q \le m \le \ell-1$, we have

(1) For $q = 3$, we get

If $m = \ell-3, \ell-2, \ell-1$, then we have $\varphi _{\ell - 3}^{(3)}\left({{x_m} - {x_\ell }} \right)\mathop \equiv \limits^{\left({m, 0} \right)} 0$, which indicates that $\varphi _{\ell - 3}^{(3)}\left({{x_m} - {x_\ell }} \right)$ is divisible by ${{x_m} - {x_\ell }}$ for $m = \ell-3, \ell-2, \ell-1$. Therefore, $\varphi _j^{\left({3} \right)} \in {\cal D}\left({{\cal A}\left[{3} \right]} \right)$.

(2) For $q = k\; {\le \ell-3 }$, assume that $\varphi _j^{\left(k \right)} \in {\cal D}\left({{\cal A}\left[k \right]} \right)$, which implies that $\varphi _j^{\left(k \right)}\left({{x_m} - {x_\ell}} \right)$ is divisible by ${x_m} - {x_\ell}$ for $\ell-k \le m \le \ell-1$.

For $q = k + 1$, we observe that

According to the induction hypothesis and Remark 2.1, it is sufficient to prove that ${\varphi _j^{(k+1)}\left({{x_{\ell-k - 1}} - {x_\ell}} \right)}$ is divisible by ${{x_{\ell-k - 1}} - {x_\ell}}$. By using the equality (2.3), we obtain

Therefore, ${\varphi _j^{\left({k+ 1} \right)}\left({{x_{\ell-k - 1}} - {x_\ell}} \right)}$ is divisible by ${{x_{\ell-k - 1}} - {x_\ell}}$, and it follows that $\varphi _j^{\left({k+ 1} \right)} \in {\cal D}\left({{\cal A}\left[{k+1} \right]} \right)$. Consequently, we can conclude that for any $3 \le q \le \ell-2$ and $\ell-q \le j \le \ell-3$, $\varphi _j^{\left(q \right)} \in {\cal D}\left({{\cal A}\left[q \right]} \right)$. □

Lemma 2.3. The derivation $\varphi _{\ell-2}^{\left(q \right)}$ belongs to the module ${\cal D}\left({{\cal A}\left[q \right]} \right)$ for ${1 \le q \le \ell-2}$.

Proof. From Theorem 2.2, we can get the following equality for $\ell-q \le m \le \ell-1$,

(1) For $q = 1, 2$, this conclusion is straightforward to verify.

(2) For $q = k\; {\le \ell-3 }$, assume that $\varphi _{\ell-2}^{\left({k} \right)} \in {\cal D}\left({{\cal A}\left[{k} \right]} \right)$, which implies that $\varphi _{\ell-2}^{\left({k} \right)}\left({{x_m} - {x_\ell}} \right)$ is divisible by ${{x_m} - {x_\ell}}$ for $\ell-k\le m \le \ell-1$.

For $q = k + 1$, we have

By using the equality (2.4), we have

Therefore, ${\varphi _{\ell-2}^{\left({k+1} \right)}\left({{x_{\ell-k-1}} - {x_\ell}} \right)}$ is divisible by ${{x_{\ell-k-1}} - {x_\ell}}$. According to the induction hypothesis and Remark 2.1, we have $\varphi _{\ell-2}^{\left({k+1} \right)} \in {\cal D}\left({{\cal A}\left[{k+1} \right]} \right)$. Hence, we may conclude that for any $1 \le q \le \ell-2$, $\varphi _{\ell-2}^{\left(q \right)} \in {\cal D}\left({{\cal A}\left[q \right]} \right)$. □

Lemma 2.4. The derivation $\varphi _{\ell - 1}^{\left({q} \right)}$ belongs to the module ${\cal D}\left({{\cal A}\left[{ q} \right]} \right)$ for $1 \le q \le \ell - 2$.

Proof. First, from Theorem 2.2, for $\ell-q \le m \le \ell-1$, we can get

(1) For $q = 1, 2$, it is obvious that $\varphi _{\ell-1}^{\left(q \right)} \in {\cal D}\left({{\cal A}\left[q \right]} \right)$.

(2) For $q = k\; {\le \ell-3 }$, assume that $\varphi _{\ell-1}^{\left({k} \right)} \in {\cal D}\left({{\cal A}\left[{k} \right]} \right)$, which implies that $\varphi _{\ell-1}^{\left({k} \right)}\left({{x_m} - {x_\ell}} \right)$ is divisible by ${{x_m} - {x_\ell}}$ for $\ell-k\le m \le \ell-1$.

For $q = k + 1$, we can see

By using the equality (2.5), we have

Therefore, ${\varphi _{\ell-1}^{\left({k+1} \right)}\left({{x_{\ell-k- 1}} - {x_{\ell}}} \right)}$ is divisible by ${{x_{\ell-k- 1}} - {x_{\ell}}}$. According to the induction hypothesis and Remark 2.1, we have $\varphi _{\ell-1}^{\left({k+1} \right)} \in {\cal D}\left({{\cal A}\left[{k+1} \right]} \right)$. Hence, we may conclude that for any $1 \le q \le \ell-2$, $\varphi _{\ell-1}^{\left(q \right)} \in {\cal D}\left({{\cal A}\left[q \right]} \right)$. □

From the above proof, we finally conclude that $\varphi _1^{\left(q \right)}, \ldots, \varphi _{\ell - 1}^{\left(q \right)}$ belong to the module ${\cal D}\left({{\cal A}\left[{ q} \right]} \right)$.

Theorem 2.3. For $1 \le q \le \ell-2$, the derivations $\eta _1, \eta _2, \varphi _1^{\left(q \right)}, \ldots, \varphi _{\ell - 1}^{\left(q \right)}$ form a basis for ${\cal D}\left({{\cal A}\left[q \right]} \right)$.

Proof. According to Lemmas 2.2–2.4, it suffices to prove that

Let

and

be the $(q+1) \times 1$ column vectors, and define a matrix

Write ${\widetilde M_{{(q + 1)} \times {(q + 1)}}}{\rm{ : = }}\left({{M_{\left({q + 1} \right) \times \left({q - 1} \right)}}, {\gamma _1}, {\gamma _2}} \right)$, then

Thus, we obtain the following equality

Hence,

We complete the proof. □
