1.   Introduction

Zadeh ^[32] inculcated the theory of vagueness and uncertainty into a new class of fuzzy sets. Contributions to the theory of ambiguousness play a significant part in solving many predicament problems involved with impreciseness. Applications of fuzzy sets are extended and disseminated to various fields such as information ^[22], control ^[23], robotics ^[14,15,16], etc.

Chang ^[8] has made a promising contribution to applying fuzzy sets in topological structures. Atanassov ^[6,7] generalized the fuzzy set intuitionistically, and the intuitionistic fuzzy set theory emerged. Coker ^[9] developed the theory on intuitionistic fuzzy set. The fuzzy set theory provides the degree of membership, while the intuitionistic fuzzy set also aggregates the degree of non-membership. B. Cong and V. Kerinovich ^[11] defined the concept of picture fuzzy set, which was deduced from the fuzzy set and intuitionistic fuzzy set. Abdul Razaaq et al. ^[19] defined the rank of picture fuzzy topological space and properties related to continuous functions. Tareq M. Al-Shami et al. ^[1] introduced SR fuzzy set and its relationship with generalizations of fuzzy sets, weighted aggregated operators to facilitate the multiattribute decision makers. An effective approach in decision making problems using aggregation operations for (m, n) fuzzy sets are established by Tareq M. Al-Shami et al. ^[2]. Multi criteria decision making problems under (a, b) fuzzy soft set and (2, 1) fuzzy sets are obtained by aggregated operators defined by Tareq M. Al-Shami et al. ^[3,4]. A new fuzzy ordered weighted averaging (OWA) operator is proposed by Juan-juan Peng et al. ^[17] to solve the aggregation problem associated with many fuzzy numbers. Moreover, various operators are defined with their desirable properties. Chao Tian et al. ^[26] developed the weighted picture fuzzy power Choquet ordered geometric (WPFPCOG) operator and a weighted picture fuzzy power Shapley Choquet ordered geometric (WPFPSCOG) operator based on fuzzy measure to deal with multi criteria decision making problems. Sustainability evaluation index system for water environment treatment public-private-partnership (WET-PPP) projects is constructed by Chao Tian et al. ^[27] to improve the accuracy of decision-making problems and applied effectively to evaluation problems.

Picture fuzzy set has adequate applications in various situations involving many human perspectives in addition to yes, no, refusal, etc. Picture fuzzy set incorporates the degree of neutrality, membership, and non-membership. Manufacturing the components in a fabrication industry by an employee emulates the picture fuzzy set, where the completion of the product by the employee is the degree of membership, the incomplete products contribute the degree of non-membership, and the damaged product is the degree of neutrality.

Statistical data analysis can be effectively implemented by clustering analysis techniques, which are extensively applied in several domains, such as pattern recognition, microbiology analysis, data mining, information retrieval, etc. In an empirical world, the data considered for clustering may be linguistic and uncertain. Abundant clustering algorithms corresponding to various fuzzy environments have been proposed, e.g., intuitionistic clustering algorithm ^[29,30] concerning the correlation coefficient formulas for IFSs, classification of picture fuzzy sets using correlation coefficients ^[21] and Sanchez et al.^[20] created a new method, Fuzzy Granular Gravitational Clustering Algorithm (FGGCA) and also compared FGGCA with other clustering techniques. The correlation coefficient analyzes the association and interdependencies between variables. The correlation coefficient is observed under probability distribution in classical statistics, whereas many real situations are subjective. Correlation coefficients between intuitionistic fuzzy sets are applied to linguistic variables, which overcome the limitations obtained in fuzzy correlation measures. The correlation coefficient between two picture fuzzy sets is the one in which the membership values have different and unique consequences, which helps the decision makers to classify their attributes more effectively. Picture fuzzy clustering ^[25] is one of the computational intelligence methods used in pattern recognition. The enhancement of the traditional and intuitionistic fuzzy sets is picture fuzzy sets. In computational intelligence, a picture fuzzy set provides a better clustering quality than other admissible clustering algorithms involved with different fuzzy sets.

Picture fuzzy set has a robust application in medical diagnosis ^[12]. In the medical diagnosis of a specific disease, some symptoms do not directly affect the particular disorder, and those symptoms have neutral membership. In this way, the picture fuzzy set constitutes a good effect on the medical diagnosis. The topological structures: filters, grills, clusters, etc., have many applications in the field of pattern analysis in the context of camouflaged objects ^[18], their applications of obtaining a C structure compactification ^[28], intuitionistic fuzzy C-ends ^[31] and Q neighbourhoods, infra fuzzy topological spaces, infra fuzzy homeomorphism, infra fuzzy isomorphisms ^[5] triggered us to define the picture fuzzy topological structures like filters, grills, ultrafilter. Picture fuzzy filters have a wide variety of applications in the field of Science and Technology, including pattern recognition, image analysis, digital image processing, and forgery detection. Picture fuzzy filters, picture fuzzy grills, and picture fuzzy ultrafilters may contribute to better analysis of various pattern recognition in the context of camouflaged objects.

Many clustering algorithms are available to classify the data set among picture fuzzy sets, which reflects the significance of the degree of positive, negative and neutral membership. In this paper, the clustering algorithm defined using the correlation coefficient between picture fuzzy sets belonging to the picture fuzzy filter collection enhances the data set's classification method. A straightforward approach based on the picture fuzzy filter is applied to the clustering algorithm, which classifies the data set more effectively in the picture fuzzy topological space domain than the other existing classifications. Classification of picture fuzzy clusters among the picture fuzzy filter collection of any cardinality can be obtained at the fourth stage of the iteration process of the equivalent coefficient matrix involved in the clustering algorithm employed in the paper. An illustration is provided in this paper to experience the ease of classification using a picture fuzzy filter collection. It is compared with some intuitionistic fuzzy set collection and intuitionistic fuzzy filter collection.

The paper is structured as follows: Section 2 deals with the fundamentals of Picture fuzzy sets and the corresponding topological structures. Section 3 explores the fundamental properties of various structures like picture fuzzy filter, grill and ultrafilter. Section 4 deals with an illustration of the application of the clustering algorithm of picture fuzzy sets. For a practical example, the cotton industry is considered. The primary four processes involved in producing yarn are assumed as the attributes. An employee whose performance is based on completion, damage and incomplete of the product plays the role of picture fuzzy sets. A clustering algorithm for picture fuzzy sets is applied to the filter collection to classify the picture fuzzy sets in a filter collection, which helps the industry analyze the employee's performance. The abbreviations and acronyms used in the paper are listed in Table 1.

2.   Preliminaries

2.1.   Picture fuzzy sets and associated topological space

Definition 2.1. ^[10] A picture fuzzy set($PFS$) $D$ on $X$ is of the form of $D$ = $\{(x, \gamma_{D}(x), \nu_{D}(x),$ $\eta_{D}(x))| x\in X\}$. In this form $\gamma_{D}(x)$, $\nu_{D}(x)$, $\eta_{D}(x)$ denote the degree of positive membership, the degree of negative membership, the degree of neutral membership of $x$ in $D$ respectively which satisfying, $\forall x\in X, \gamma_{D}(x)+\nu_{D}(x)+\eta_{D}(x)\leq 1$. The degree of refusal membership of $x$ in $D$ is given by $\rho_{D}(x) = (1-(\gamma_{D}(x)+\nu_{D}(x)+\eta_{D}(x)))$. Such collection of sets is represented as $PFS(X)$.

Definition 2.2. ^[10] Let $D$ and $E$ any two $PFSs$, then

(i) $D\subseteq E$ iff $(y\in X$, $\gamma_{D}(y)\leq \gamma_{E}(y)$ and $\nu_{D}(y)\geq\nu_{E}(y)$ and $\eta_{D}(y)\leq\eta_{E}(y)$);

(ii) $D = E$ iff $(D\subseteq E$ and $E\subseteq D)$;

(iii) $D\cup E$ = $\{(x, \vee(\gamma_{D}(x), \gamma_{E}(x)), \wedge(\nu_{D}(x), \nu_{E}(x)), \wedge(\eta_{D}(x), \eta_{E}(x)))| x\in X\}$;

(iv) $D\cap E$ = $\{(x, \wedge(\gamma_{D}(x), \gamma_{E}(x)), \vee(\nu_{D}(x), \nu_{E}(x)), \wedge(\eta_{D}(x), \eta_{E}(x)))| x\in X\}$;

(v) $CO(D) = \overline{D} = \{(\nu_{D}(x), \gamma_{D}(x), \eta_{D}(x))|x\in X\}$.

Definition 2.3. ^[10] Some Special $PFSs$ are as follows:

(i) A constant picture fuzzy set is the $PFS$ $\widehat{(\vartheta, \varepsilon, \varrho)} = \{(y, \vartheta, \varepsilon, \varrho) |y\in X\}$;

(ii) Picture fuzzy universe set is $1_{X}$ defined as $1_{X} = \widehat{(1, 0, 0)} = \{(y, 1, 0, 0) |y\in X\}$;

(iii) Picture fuzzy empty set is $\phi$ defined as $\phi = 0_{X} = \widehat{(0, 0, 1)} = \{(y, 0, 0, 1) |y\in X\}$.

Definition 2.4. ^[24] A picture fuzzy topology on $X$ is a collection $\sigma$ of $PFS$ satisfying

(1) $\widehat{(\vartheta, \varepsilon, \varrho)}\in\sigma, \widehat{(\vartheta, \varepsilon, \varrho)}\in PFS(X)$;

(2) $G\cap H\in\sigma$ for any $G, H\in\sigma$;

(3) $\cup_{i\in I} H_{i}$ for $\{H_{i}|i\in I\}\subseteq\sigma$.

Then $(X, \sigma)$ is said to be a picture fuzzy topological space ($PFTS$) and the member of $\sigma$ is picture fuzzy open set ($PFOS$) in $X$. The picture fuzzy closed set ($PFCS$) is the complement of it. $\sigma^{c}$ denote the collection of all $PFCSs$.

Definition 2.5. ^[24] For a picture fuzzy topological space $(X, \sigma)$, $int(D)$ and $cl(D)$ denotes the interior and closure operator of a picture fuzzy set $D$ in $(X, \sigma)$ and is defined as follows:

Definition 2.6. ^[10] The image of $D\in PFS(X)$ under the function $f$ from $X$ into $Y$ is defined as follows:

The pre image of $E\in PFS(Y)$ under $f$ is $f^{-1}(E)(a)$ = $(\gamma_{E}(f(a)), \nu_{E}(f(a)), \eta_{E}(f(a)))$.

2.2.   Linear relationship between two IFSs

Let $X = \{x_{1}, x_{2}, \cdots, x_{n}\}$ be a discrete universe of discourse, $D$ and $E$ be a two IFSs on $X$ denoted as $D = \{(x_{i}, \gamma_{D}(x_{i}), \nu_{D}(x_{i}))| x_{i}\in X, i = 1, 2, \cdots, n\}$ and $E = \{(x_{i}, \gamma_{E}(x_{i}), \nu_{E}(x_{i}))|x_{i}\in X, i = 1, 2, \cdots, n\}$ respectively.

Definition 2.7. ^[13] For IFS $D$ = $\{(x_{i}, \gamma_{D}(x_{i}), \nu_{D}(x_{i}))| x_{i}\in X, i = 1, 2, \cdots, n\}$, the informational energy of the set $D$ is defined as

Definition 2.8. ^[13] For $D, E \in IFSs$, the correlation $C_{p_{2}}(D, E)$ is defined by

Definition 2.9. ^[13] The correlation coefficient between any two intuitionistic fuzzy sets $D$ and $E$ is given by,

Proposition 2.1. ^[13] The correlation coefficient between two IFSs $D$ and $E$ defined in Eq (2.3), satisfies:

(1) $K_{IFS_{1}}(D, E) = K_{IFS_{1}}(E, D)$;

(2) $0 \leq K_{IFS_{1}}(D, E) \geq 1$;

(3) $K_{{IFS_1}}(D, E) = 1$ iff $D = E$.

Definition 2.10. ^[13] Let $D_{j}(j = 1, 2, \cdots, m)$ be m IFSs, and $C = (K_{ij})_{m\times m}$ be a correlation matrix, where $K_{ij} = K(D_{i}, D_{j})$ denotes the correlation coefficient of two IFSs $D_{i}$ and $D_{j}$ and satisfies:

(1) $0\leq K_{ij}\leq 1$;

(2) $K_{ii} = 1$;

(3) $K_{ij} = K_{ji}$.

Definition 2.11. ^[30] The correlation matrix of $m$ IFSs is given by $M_{C} = (K_{ij})_{m\times m}$, the composition matrix of a correlation matrix is $M_{C}^{2} = M_{C}\circ M_{C} = (\overline{K}_{ij})_{m\times m}$, where

Definition 2.12. ^[30] Let $M_{C} = (K_{ij})_{m\times m}$ be a correlation matrix, if $M_{C}^{2}\subseteq M_{C},$ i.e.,

Then $M_{C}$ is called an equivalent correlation matrix.

Definition 2.13. ^[30] Let $M_{C} = (K_{ij})_{m\times m}$ be an equivalent correlation matrix. Then we call $(M_{C})_{\lambda} = ({}_{\lambda}K_{ij})_{m \times m}$ the $\lambda$-cutting matrix of $M_{C}$, where

and $\lambda$ is the confidence level with $\lambda \in [0, 1].$

2.3.   Linear relationship between two PFSs

Let $X = \{x_{1}, x_{2}, \cdots, x_{n}\}$ be a discrete universe of discourse, $D$ and $E$ be a two PFSs on $X$ denoted as $D$ = $\{(x_{i}, \gamma_{D}(x_{i}), \nu_{D}(x_{i}),$ $\eta_{D}(x_{i}))|x_{i}\in X, i = 1, 2, \cdots, n\}$ and $E$ = $\{(x_{i}, \gamma_{E}(x_{i}), \nu_{E}(x_{i}),$ $\eta_{E}(x_{i}))| x_{i}\in X$, $i =$ $1, 2, \cdots, n\}$ respectively. Let $u = (u_{1}, u_{2}, \cdots, u_{n})^T$ be the weight vector of $x_{i}(i = 1, 2, \cdots, n)$ with $u_{i} \geq 0$ and $\sum ^{n}_{i = 1} u_{i} = 1$.

Definition 2.14. ^[21] For PFS $D$ = $\{(x_{i}, \gamma_{D}(x_{i}), \nu_{D}(x_{i}),$ $\eta_{D}(x_{i}))| x_{i}\in X, i = 1, 2, \cdots, n\}$, the informational energy of the set $D$ is defined as

Definition 2.15. ^[21] For $D, E \in PFSs$, the correlation $C_{p_{2}}(D, E)$ is defined by

Definition 2.16. ^[21] The correlation coefficient between any two picture fuzzy sets $D$ and $E$ is given by,

$K_{p_{3}}(D, E)$ in Eq (2.9) depends on the following factors:

(1) The amount of information expressed by the degree of positive membership, the degree of neutral membership, the degree of negative membership.

(2) The reliability of the information expressed by refusal membership.

Proposition 2.2. ^[21] Let $u = (u_{1}, u_{2}, \cdots, u_{n})^T$ be the weight vector of $x_{i}(i = 1, 2, \cdots, n)$ with $u_{i} \geq\; 0$ and $\sum ^{n}_{i = 1} u_{i} = 1$ then correlation coefficient between two PFSs $D$ and $E$ defined in Eq (2.9), satisfies:

(1) $K_{p_{3}}(D, E) = K_{p_{3}}(E, D)$;

(2) $0 \leq K_{p_{3}}(D, E) \geq 1$;

(3) $K_{{p_3}}(D, E) = 1$ iff $D = E$.

Definition 2.17. ^[21] Let $D_{j}(j = 1, 2, \cdots, m)$ be m PFSs, and $C = (K_{ij})_{m\times m}$ be a correlation matrix, where $K_{ij} = K(D_{i}, D_{j})$ denotes the correlation coefficient of two PFSs $D_{i}$ and $D_{j}$ and satisfies:

(1) $0\leq K_{ij}\leq 1$;

(2) $K_{ii} = 1$;

(3) $K_{ij} = K_{ji}$.

Definition 2.18. ^[30] The correlation matrix of $m$ PFSs is given by $M_{C} = (K_{ij})_{m\times m}$, the composition matrix of a correlation matrix is $M_{C}^{2} = M_{C}\circ M_{C} = (\overline{K}_{ij})_{m\times m}$, where

Definition 2.19. ^[30] Let $M_{C} = (K_{ij})_{m\times m}$ be a correlation matrix, if $M_{C}^{2}\subseteq M_{C},$ i.e.,

Then $M_{C}$ is called an equivalent correlation matrix.

Definition 2.20. ^[30] Let $M_{C} = (K_{ij})_{m\times m}$ be an equivalent correlation matrix. Then we call $(M_{C})_{\lambda} = ({}_{\lambda}K_{ij})_{m \times m}$ the $\lambda$-cutting matrix of $M_{C}$, where

and $\lambda$ is the confidence level with $\lambda \in [0, 1].$

3.   Picture fuzzy filter

Throughout the paper picture fuzzy topology is observed in the sense of Chang ^[8].

Definition 3.1. Let $(X, \sigma)$ be a $PFTS$. Picture fuzzy filter $\mathfrak{E}\subset\sigma^{c}$ on $X$ is a collection of $PFS(X)$ satisfying

(1) $\mathfrak{E}$ is nonempty and $0_{X}\notin\mathfrak{E}$;

(2) If $D_{1}, D_{2}\in\mathfrak{E}$ then $D_{1}\cap D_{2}\in\mathfrak{E}$;

(3) If $D\subseteq E$ where $D\in\mathfrak{E}$ and $E\in\sigma^{c}$ then $E\in\mathfrak{E}$.

Definition 3.2. If $(X, \sigma)$ is a $PFTS$ and $Y\subseteq X$, the collection $\sigma_{Y} = \{D\cap 1_{Y}:D\in\sigma\}$ is a picture fuzzy topology on $Y$. $(Y, \sigma_{Y})$ is called a picture fuzzy subspace on $X$.

Example 3.1. Let $X = \{k, \ l, \ m\}$ and $\sigma = \{1_{X}, \ 0_{X}, \ H, \ K, \ E = H \cup K, \ D = H \cap K\}$, the membership values of $H$, $K$, $E$ and $D$ are provided in Table 2.

Thus $(X, \ \sigma)$ is a picture fuzzy topological space. Let $Y = \{k, \ l\}$. $\sigma_{Y} = \{D\cap 1_{Y}|D\in\sigma\}$ is a picture fuzzy topology on $Y$.

Definition 3.3. Let $(X, \sigma)$ be a $PFTS$. Picture fuzzy grill $\mathscr{G}\subset\sigma^{c}$ on $X$ is a collection of $PFS(X)$ satisfying

(1) $\mathscr{G}$ is non empty and $0_{X}\notin\mathscr{G}$;

(2) If $D\in\mathscr{G}$ and $D\subseteq E$ then $E\in\mathscr{G}$;

(3) If $D\cup E\in\mathscr{G}$ then $D\in\mathscr{G}$ or $E\in\mathscr{G}$.

Definition 3.4. Picture fuzzy section of $\mathfrak{E}$ is $PFsec(\mathfrak{E}) = \{E\in\sigma^{c}:D\cap E\neq 0_{X}, D\in\mathfrak{E}\}$.

Definition 3.5. $\mathscr{B}\subset\mathfrak{E}$ is a picture fuzzy base for $\mathfrak{E}$ if for every $D\in\mathfrak{E}$ $\exists$ $E\in\mathscr{B}$ with $E\subseteq D$.

Definition 3.6. $\mathscr{H}\subset\sigma^{c}$ is a picture fuzzy subbase for $\mathfrak{E}$ if $\{\cap_{i = 1}^{n}D_{i}|D_{i}\in\mathscr{H}\}$ is a picture fuzzy base for $\mathfrak{E}$.

Proposition 3.1. Let $(X, \sigma)$ be a $PFTS$ and $\mathscr{B}\subset\sigma^{c}$. Then (i) and (ii) are equivalent.

(i) There is only one picture fuzzy filter $\mathfrak{E}$ having $\mathscr{B}$ as a picture fuzzy base;

(ii) (a) $\mathscr{B}$ is non empty and $0_{X}\notin\mathscr{B}$;

(b) If $E_{1}, E_{2}\in\mathscr{B}$ there is $E_{3}\in\mathscr{B}$ with $E_{3}\subseteq E_{1}\cap E_{2}$.

Proof.

(i)$\Rightarrow$(ii). Assume that there is only one picture fuzzy filter $\mathfrak{E}$ having $\mathscr{B}$ as a picture fuzzy base. Since $\mathscr{B}$ is a picture fuzzy base for $\mathfrak{E}$ and $0_{X}\notin\mathfrak{E}$, $0_{X}\notin\mathscr{B}$ and also $\mathscr{B}$ is non empty. Also if $E_{1}, E_{2}\in\mathscr{B}$ such that $E_{1}\subseteq D_{1}$ and $E_{2}\subseteq D_{2}$, for $D_{1}, D_{2}\in\mathfrak{E}$. Since $D_{1}, D_{2}\in\mathfrak{E}$, $D_{1}\cap D_{2} = D_{3}\in\mathfrak{E}$, $E_{1}\cap E_{2}\subseteq D_{1}\cap D_{2} = D_{3}$. Thus $\exists$ $E_{3}\in\mathscr{B}\ni E_{3} = E_{1}\cap E_{2}\subseteq D_{3}$.

(ii)$\Rightarrow$ (i). Suppose that $\mathscr{B}$ is a picture fuzzy base for two different picture fuzzy filters $\mathfrak{E}_{1}$ and $\mathfrak{E}_{2}$. For each $D_{1}\in\mathfrak{E}_{1}$ $\exists$ $E_{1}\in\mathscr{B}$ $\ni$ $E_{1}\subseteq D_{1}$. Similarly for each $D_{2}\in\mathfrak{E}_{2}$ $\exists$ $E_{2}\in\mathscr{B}$ $\ni$ $E_{2}\subseteq A_{2}$. Also if $D_{1}\cap D_{2} = 0_{X}$ then $0_{X}\in\mathscr{B}$ which is impossible. Hence $D_{1}\cap D_{2}\neq 0_{X}$. Therefore $D_{1}\cap D_{2}$ lies in both $\mathfrak{E}_{1}, \mathfrak{E}_{2}$ and thus the picture fuzzy filters are same. □

Proposition 3.2. If there is a picture fuzzy base $\mathscr{B}$ satisfies (a) and (b) of Proposition 3.1, then

is a picture fuzzy filter generated by $\mathscr{B}$.

Proof. Since $\mathscr{B}$ is nonempty implies $\mathfrak{E}$ is nonempty. If $D\in\mathfrak{E}$ then $D\supseteq E$ for some $E\in\mathscr{B}$. By assumption $E\neq 0_{X}$ thus $D\neq 0_{X}$. If $D_{1}$, $D_{2}$ $\in\mathfrak{E}$ there exists $E_{1}, E_{2}\in\mathscr{B}$ with $E_{i}\subseteq D_{i}$ for $i = 1, 2$. Then $D_{1}\cap D_{2}\supseteq E_{1}\cap E_{2}\supseteq E_{3}$ for some $E_{3}\in\mathscr{B}$. Thus $D_{1}\cap D_{2}\in\mathfrak{E}$. This proves that $\mathfrak{E}$ is a picture fuzzy filter on $X$. □

Proposition 3.3. Let $\mathfrak{E}$ be a picture fuzzy filter and $D\in\sigma^{c}$. $\mathfrak{E}\cup \{D\}$ lies in some picture fuzzy filter iff for each $E\in\mathfrak{E}$, $E\cap D\neq 0_{X}$.

Definition 3.7. A picture fuzzy ultrafilter $\mathfrak{E}$ is a maximal picture fuzzy filter among the set of all picture fuzzy filters $\{\mathfrak{E}_{j}\}_{j\in J}$.

Proposition 3.4. Every picture fuzzy filter $\mathfrak{E}$ extends to picture fuzzy ultrafilter $\mathscr{V}$.

Proposition 3.5. For any picture fuzzy filter $\mathfrak{E}$ on $X$, we have the equivalence.

(i) $\mathfrak{E}$ is a picture fuzzy ultrafilter;

(ii) If $D\in\sigma^{c}$ and $\forall$ $E\in\mathfrak{E}$ with $D\cap E\neq 0_{X}$, then $D\in\mathfrak{E}$;

(iii) If $D$ is $PFCS$ and $D$ is not in $\mathfrak{E}$, then there is $E\in\mathfrak{E}$ $\ni$ $D\cap E = 0_{X}$.

Proof.

(i)$\Rightarrow$(ii). Suppose $D$ be a $PFCS$ and $D\cap E\neq 0_{X}$, for all $E\in\mathfrak{E}$. From Proposition $3.3$, $\mathfrak{E}\cup \{D\}$ lies in some picture fuzzy filter $\mathfrak{E}^{*}$. By (i), $\mathfrak{E} = \mathfrak{E}^{*}$.

(ii)$\Rightarrow$ (iii). Let $D$ is $PFCS$ and is not in $\mathfrak{E}$. By (ii), for some $E\in\mathfrak{E}$ we have $D\cap E\neq 0_{X}$.

(iii)$\Rightarrow$ (i). Let $\mathscr{M}$ be a picture fuzzy filter with $\mathfrak{E}\subset\mathscr{M}$ and $\mathfrak{E}\neq\mathscr{M}$. Let $D\in\mathscr{M}$ $\ni$$D\notin\mathfrak{E}$. By (iii), $\exists$ $E\in\mathfrak{E}$ with $D\cap E = 0_{X}$. Since $E, D\in\mathscr{M}$, $E\cap D\in\mathscr{M}$ implies $0_{X}\in\mathscr{M}$, contradicts our assumption. Hence $\mathfrak{E} = \mathscr{M}$ which is a picture fuzzy ultrafilter. □

Proposition 3.6. If $\mathscr{V}_{1}$, $\mathscr{V}_{2}$ the two different picture fuzzy ultrafilters on $X$, then $(\cap_{i}D_{i})\cap(\cap_{j}D_{j}) = 0_{X}$ for all $D_{i}\in\mathscr{V}_{1}$ and $D_{j}\in\mathscr{V}_{2}$.

Proof. Suppose $(\cap_{i}D_{i})\cap(\cap_{j}D_{j})\neq 0_{X}$, for all $D_{i}\in\mathscr{V}_{1}$ and $D_{j}\in\mathscr{V}_{2}$. Then there exists an $x\in X$ for which, $\wedge_{i}(\gamma_{D_{i}}(x))\neq 0$, $\vee_{i}(\nu_{D_{i}}(x))\neq 1$, $\wedge_{i}(\eta_{D_{i}}(x))\neq 0$. Also $\wedge_{j}(\gamma_{D_{j}}(x))\neq 0$, $\vee_{j}(\nu_{D_{j}}(x))\neq 1$, $\wedge_{j}(\eta_{D_{j}}(x))\neq 0$, $\Rightarrow \wedge(\gamma_{D_{i}}(x), \gamma_{D_{j}}(x)) > 0$, $\vee(\nu_{D_{i}}(x), \nu_{D_{j}}(x)) < 1$, $\wedge(\eta_{D_{i}}(x), \eta_{D_{j}}(x)) > 0$, for all $i$, $j$. Which implies $D_{i}\cap D_{j}\neq 0_{X}$. By Proposition 3.5, $D_{i}\in\mathscr{V}_{2}$ and $D_{j}\in\mathscr{V}_{1}$ for all $i$, $j$. Then it leads to contradiction. □

Proposition 3.7. Every picture fuzzy ultrafilter is a picture fuzzy grill.

Proof. Let $D$, $E$ be $PFCS$ with $D\cup E$ lies in picture fuzzy ultrafilter $\mathscr{V}$. Suppose $D, E$ is not in $\mathscr{V}$. Then there exists $D_{1}, E_{1}\in\mathscr{V}$ with $D\cap D_{1} = 0_{X}$ and $E\cap E_{1} = 0_{X}$. Since $\mathscr{V}$ is a picture fuzzy ultrafilter, $(D\cup E)\cap D_{1}\cap E_{1}\in\mathscr{V}$. Now, $[(D\cup E)\cap D_{1}]\cap E_{1}$ = $[(D\cap D_{1})\cup (E\cap E_{1})]\cap E_{1}$ = $[0_{X}\cup (E\cap D_{1})]\cap E_{1}$ = $[0_{X}\cap E_{1}]\cup[(E\cap D_{1})\cap E_{1}]$ = $0_{X}\cup [E\cap E_{1}\cap D_{1}]$ = $0_{X}\cup 0_{X}$ = $0_{X}$. This leads a contradiction. Hence $\mathscr{V}$ is a picture fuzzy grill on $X$. □

Proposition 3.8. If $\mathscr{P}(\mathfrak{E})$ is the collection of picture fuzzy grills containing $\mathfrak{E}$, then we have $\mathfrak{E} = \cap_{\mathscr{G}\in\mathscr{P}(\mathfrak{E})}\mathscr{G}$.

Proof. If $A$ be a $PFCS$ and is not in $\mathfrak{E}$. Now, $\mathscr{L}$ denotes the inductive set consisting of all picture fuzzy filters $\mathscr{G}$ containing $\mathfrak{E}$ and $A\notin\mathscr{G}$. $\mathscr{L}$ posses the maximal filter $\mathscr{V}$. We claim $\mathscr{V}$ is a picture fuzzy grill. Let $B_{1}, B_{2}\in\sigma^{c}$ with $B_{1}\cup B_{2}\in\mathscr{V}$ such that $B_{1}, B_{2}\notin\mathscr{V}$. Consider the family $\mathscr{J}$ = $\{F\in\sigma^{c}| F\cup B_{2}\in\mathscr{V}\}$. Since $B_{1}\in\sigma^{c}$ and $B_{1}\cup B_{2}\in\mathscr{V}$, implies that $B_{1}\in\mathscr{J}$. This implies $\mathscr{J}$ is non empty. Suppose if $0_{X}$ is in $\mathscr{J}$, $B_{2}\in\mathscr{V}$. Contradicts our assumption. Hence $0_{X}\notin\mathscr{J}$. If $F_{1}, F_{2}\in\mathscr{J}$. By definition of $\mathscr{J}$, $F_{1}\cup B_{2}\in\mathscr{V}$ and $F_{2}\cup B_{2}\in\mathscr{V}$. Since $\mathscr{V}$ is a picture fuzzy filter. $[F_{1}\cup B_{2}]\cap[F_{2}\cup B_{2}]$ $\in\mathscr{V}$ $\Rightarrow$ $(F_{1}\cap F_{2})\cup B_{2} \in \mathscr{V}$ $\Rightarrow$ $F_{1}\cap F_{2}\in\mathscr{J}$. If $F\in\mathscr{J}$ and $B\in\sigma^{c}$ such that $F\subseteq B$, $F\cup B_{2}\in\mathscr{V}$, $\mathscr{V}$ is ultrafilter. $B_{1}\cup B_{2}\in\mathscr{V}$, implies that $B\in\mathscr{J}$. Thus $\mathscr{J}$ is a picture fuzzy filter. Since $B_{1}\cup B_{2}\in\mathscr{V}$, $(B_{1}\cup B_{2})\cup B_{2}\in\mathscr{V}$, implies that $B_{1}\cup B_{2}\in\mathscr{J}$. Thus $\mathscr{V}\subset\mathscr{J}$. Since $B_{1}\in\mathscr{J}$ and $B_{1}\notin\mathscr{V}$. Thus $\mathscr{V}\neq\mathscr{J}$. Let $\mathscr{K} = \{C\in\sigma^{c}|A\cup C\in\mathscr{V}\}$. Suppose $0_{X}\in\mathscr{K}$, then by definition of $\mathscr{K}$, $A\in\mathscr{V}$. Contradicts our assumption $\mathscr{V}\in\mathscr{L}$ and $A\notin \mathscr{V}$. Hence $0_{X}\notin\mathscr{K}$. Since $1_{x}\in\mathscr{V}$, implies that $1_{X}\in\mathscr{K}$. $\mathscr{K}$ satisfies the first condition of picture fuzzy filter. If $A^{*}, \ A^{**}\in\mathscr{K}$. By definition of $\mathscr{K}$, the picture fuzzy sets $A^{*}\cup A$ and $A^{**}\cup A$ are in $\mathscr{V}$. Since $\mathscr{V}$ is a picture fuzzy filter, $A^{*}\cup A^{**}\cup A\in\mathscr{V}$. Therefore $A^{*}\cup A^{**}\in\mathscr{K}$. If $A\in\mathscr{K}$ and $A^{*}\in\sigma^{c}$ such that $A^{*}\supseteq A$ then $A^{**}\in\mathscr{K}$. Hence $\mathscr{K}$ is a picture fuzzy filter.

Now, $\mathfrak{E}\subset\mathscr{K}$. $A\notin \mathscr{K}$ for $A\notin \mathscr{V}$. Hence $\mathscr{K}$ also lies in $\mathscr{L}$ and $\mathscr{V}\subset\mathscr{K}$. $\mathscr{V}$ = $\mathscr{K}$ since $\mathscr{V}$ is maximal. If $A\in\mathscr{J}$, then $A\cup B_{2}\in\mathscr{V}$, implies that $B_{2}\in\mathscr{K} = \mathscr{V}$. Contradicts our assumption $B_{2}\notin\mathscr{V}$. Thus $A\notin\mathscr{J}$. $\mathscr{V} = \mathscr{J}$, since $\mathscr{J}\in\mathscr{L}$, $\mathscr{V}\subset\mathscr{J}$. However, $\mathscr{V}\neq\mathscr{J}$. So it is absurd to assume $B_{1}, B_{2}\notin\mathscr{V}$. Thus $B_{1}, B_{2}\in\mathscr{V}$. Therefore $\mathscr{V}$ is a picture fuzzy grill and $A\notin \mathscr{V}$. Hence $\cap_{\mathscr{G}\in\mathscr{P}(\mathfrak{E})}\mathscr{G}\subset\mathfrak{E}$. □

Definition 3.8. A picture fuzzy filter $\mathfrak{E}_{x_{(\vartheta, \varepsilon, \varrho)}}$ generated by picture fuzzy point $x_{(\vartheta, \varepsilon, \varrho)}$, if the non empty collection $\mathfrak{E}_{x_{(\vartheta, \varepsilon, \varrho)}} = \{E\in\sigma^{c}|x_{(\vartheta, \varepsilon, \varrho)}\subseteq E\}$ is a picture fuzzy grill on $X$.

Definition 3.9. Picture fuzzy normal family$(PFNF)$ is a collection of $PFCS$ if given $D_{1}, D_{2}\in\sigma^{c}$ such that $D_{1}\cap D_{2} = 0_{X}$ there exist $E_{1}, E_{2}\in\sigma^{c}$ with $E_{1}\cup E_{2} = 1_{X}$, $D_{1}\cap E_{1} = 0_{X}$ and $D_{2}\cap E_{2} = 0_{X}$.

Proposition 3.9. Let $(X, \sigma)$ be any $PFTS$ and $\sigma^{c}$ be a $PFNF$. Every picture fuzzy grill $\mathscr{G}$ on $X$ lies exactly in one picture fuzzy ultrafilter.

Proof. Assume that $\mathscr{V}_{1}$ and $\mathscr{V}_{2}$ are the picture fuzzy ultrafilters having $\mathscr{G}\subset\mathscr{V}_{1}$, $\mathscr{G}\subset\mathscr{V}_{2}$, $\mathscr{V}_{1}\neq\mathscr{V}_{2}$. Then $\exists$ $D_{1}\in\mathscr{V}_{1}$ and $D_{2}\in\mathscr{V}_{2}$ with $D_{1}\cap D_{2} = 0_{X}$. Since $\sigma^{c}$ is a $PFNF$, there exist $E_{1}, E_{2}\in\sigma^{c}$ with $E_{1}\cup E_{2} = 1_{X}$, $D_{1}\cap E_{1} = 0_{X}$ and $D_{2}\cap E_{2} = 0_{X}$. Since $E_{1}\cup E_{2} = 1_{X}$ and $\mathscr{G}$ is a picture fuzzy grill, $E_{1}\in\mathscr{G}$ or $E_{2}\in\mathscr{G}$. Suppose if $E_{1}\in\mathscr{G}$, then $E_{1}\in\mathscr{V}_{1}$ and $E_{1}\in\mathscr{V}_{2}$. Thus $D_{1}\cap E_{1} = 0_{X}$ with $D_{1}, E_{1}\in\mathscr{V}_{1}$, contradicts our assumption. Similarly, $E_{2}\in\mathscr{G}$, then $E_{2}\in\mathscr{V}_{1}$ and $E_{2}\in\mathscr{V}_{2}$. Thus $D_{2}\cap E_{2} = 0_{X}$ with $D_{2}, E_{2}\in\mathscr{V}_{2}$, contradicts our assumption. Hence $\mathscr{V}_{1} = \mathscr{V}_{2}$. □

Proposition 3.10. If $\sigma^{c}$ be a $PFNF$ and for every picture fuzzy point $x_{(\vartheta, \varepsilon, \varrho)}$ there exists a unique picture fuzzy ultrafilter $\mathscr{V}_{x_{(\vartheta, \varepsilon, \varrho)}}$ which contains $\mathfrak{E}_{x_{(\vartheta, \varepsilon, \varrho)}}$.

Proof. Proof follows from Definition 3.8 and Proposition 3.9. □

Proposition 3.11. For any two picture fuzzy points $x_{(\vartheta, \varepsilon, \varrho)}$, $y_{(\gamma, \delta, \varphi)}$ with $x = y$, we have $\mathscr{V}_{x_{(\vartheta, \varepsilon, \varrho)}} = \mathscr{V}_{y_{(\gamma, \delta, \varphi)}}$.

Proof. Proof is obtained from Proposition 3.6. □

Proposition 3.12. Let $(X, \sigma)$ is a picture fuzzy topological space. Then

(a) $\mathfrak{E}$ is a picture fuzzy filter on $X$ iff $PFsec(\mathfrak{E})$ is picture fuzzy grill on $X$.

(b) $\mathscr{G}$ is a picture fuzzy grill on $X$ iff $PFsec(\mathscr{G})$ is picture fuzzy filter on $X$.

Proof.

(a) Let $\mathfrak{E}$ be a picture fuzzy filter on $X$. First two conditions of $PFsec(\mathfrak{E})$ is true by the nature of $\mathfrak{E}$. Let $D\cup E\in PFsec(\mathfrak{E})$, then for all $C\in\mathfrak{E}$, $C\cap(D\cup E)\in\mathfrak{E}$. By definition of $PFsec(\mathfrak{E})$, $D, E\in PFsec(\mathfrak{E})$. Hence $PFsec(\mathfrak{E})$ is a picture fuzzy grill on $X$. Conversely, $PFsec(\mathfrak{E})$ satisfies first and third condition of picture fuzzy filter. If $D_{1}, D_{2}\in PFsec(\mathfrak{E})$, $D_{1}\cap D_{2}\in PFsec(\mathfrak{E})$. Hence $PFsec(\mathfrak{E})$ is a picture fuzzy filter on $X$.

(b) Let $\mathfrak{E}$ be a picture fuzzy grill on $X$. First and second conditions of picture fuzzy filter is true for $PFsec(\mathfrak{E})$. For the second condition let $D_{1}, D_{2}\in PFsec(\mathfrak{E})$, $(D_{1}\cap C)\neq 0_{X}$ and $(D_{2}\cap C)\neq 0_{X}$, $\forall C\in \mathfrak{E})$. Therefore $D_{1}\cap D_{2}\in PFsec(\mathfrak{E})$. Hence $PFsec(\mathfrak{E})$ is a picture fuzzy filter on $X$. Conversely, $PFsec(\mathfrak{E})$ is a picture fuzzy filter on $X$. First and second conditions of picture fuzzy grill is obvious. For the third condition $D\cup E\in PFsec(\mathfrak{E})$, $C\cap(D\cup E)\neq 0_{X}$. Hence both $D, E$ is in $PFsec(\mathfrak{E})$. Hence $PFsec(\mathfrak{E})$ is a picture fuzzy grill on $X$. □

By the above Proposition, it is easy to analyze that there is a one to one correspondence between the set of all picture fuzzy filters and the set of all picture fuzzy grills.

4.   Implementation of clustering algorithm on PFSs

P. Singh^[21] proposed the clustering algorithm for picture fuzzy set. The proposed algorithm is applied to the picture fuzzy filter collection and the classification of picture fuzzy sets is obtained.

Proposition 4.1. ^[30] The composition matrix $M_{C}^{2}$ is also a correlation matrix.

Proposition 4.2. ^[30] Let $M_{C}$ be a correlation matrix. Then for any non-negative integers $p_{1}$ and $p_{2}$, the composition matrix. $M_{C}^{p_{1}p_{2}}$ derived from $M_{C}^{p_{1}p_{2}} = M_{C}^{p_{1}}\circ M_{C}^{p_{2}}$ is still a correlation matrix.

Proposition 4.3. ^[30] Let $M_{C} = (K_{ij})_{m\times m}$ be a correlation matrix. Then after the finite times of compositions:

$M_{C} \rightarrow M_{C}^{2} \rightarrow M_{C}^{4} \rightarrow \cdots \rightarrow M_{C}^{2^{k}} \rightarrow \cdots,$ there must exist a positive integer k such that $M_{C}^{2^{k}} = M_{C}^{2^{k+1}}$ and $M_{C}^{2^{k}}$ is also an equivalent correlation matrix.

4.1.   Algorithm for PFSs ^[21]

Step 1. Let $\{D_{1}, D_{2}, \cdots, D_{m}\}$ be a set of PFSs in $X = \{x_{1}, x_{2}, \cdots, x_{n}\}.$ Using the formula, correlation coefficient of picture fuzzy set can be calculated and the correlation matrix $M_{C} = (K_{ij})_{m\times m}$, where $K_{ij} = K(D_{i}, D_{j})$ can be constructed.

Step 2. Check whether $M_{C}^{2}\subseteq M_{C},$ where $M_{C}^{2} = M_{C}\circ M_{C} = (\overline{K}_{ij})_{m\times m} = max_{n}\Big\{min\{{K}_{in}, {K}_{nj}\}\Big\} \leq K_{ij}$ $i, j = 1, 2, \cdots, m.$ If it does not hold, construct the equivalent correlation matrix $M_{C}^{2^{k}}$: $M_{C} \rightarrow M_{C}^{2} \rightarrow M_{C}^{4} \rightarrow \cdots \rightarrow M_{C}^{2^{k}} \rightarrow \cdots,$ until $M_{C}^{2^{k}} = M_{C}^{2^{k+1}}$.

Step 3. For confidence level $\lambda$, construct a $\lambda$-cutting matrix $(M_{C})_{\lambda} = ({}_\lambda K_{ij})_{m\times m}$ through Definition 2.13 in order to classify the PFSs $P_{j}(j = 1, 2, \cdots, m)$. If all element of the ith column in $(M_{C})_{\lambda}$ are the same as the corresponding elements of the $j$th column in $(M_{C})_{\lambda}$, then the PFSs $D_{i}$ and $D_{j}$ are of the same type. The classification of picture fuzzy sets can be done by the above principle.

4.2.   Illustration: performance measure of an employee in a cotton industry

Illustration 1. For a practical example, an employee from a subunit of the cotton industry is considered. As the production of yarn depends on four crucial processes blowing, carding, drawing, and roving can be performed by the workers. After completing the above-said stages, the product yarn can be obtained through machines automatically. While doing the first four processes, there are positive, negative, and flaws in an employee's performance. We attempted to define a picture fuzzy topological space on the collection of picture fuzzy sets obtained from employee performance. Later picture fuzzy filter collection is obtained and applied with the clustering algorithm leads to a classification of the employee based on their performance. Each employee is associated with four different attributes denoted by X = {k, l, m, n}, k: Blowing; l: Carding; m: Drawing; n: Roving with weight vector u = (0.4, 0.2, 0.3, 0.1). Based on the expert's information, the evaluation of each employee is expressed in the form of PFSs. Table 3 represents the degree of positive, negative, and neutral membership of each attribute of X given by the experts.

Let $\sigma = \{ 1_{X}, 0_{X}, E_{1}, E_{2}, E_{3}, E_{4}, E_{5}, E_{6}, E_{7}, E_{8}, E_{9}\}$ be the picture fuzzy topology on $X$ where

$\begin{aligned}[t] E_{1} & = \{{(k, 0.7, 0.1, 0.2)}, {(l, 0.9, 0.0, 0.1)}, {(m, 0.8, 0.1, 0.0)}, {(n, 0.7, 0.1, 0.2)}\}, \\ E_{2} & = \{{(k, 0.8, 0.1, 0.1)}, {(l, 0.8, 0.1, 0.1)}, {(m, 0.1, 0.1, 0.7)}, {(n, 0.6, 0.2, 0.1)}\}, \\ E_{3} & = \{{(k, 0.4, 0.2, 0.2)}, {(l, 0.7, 0.1, 0.2)}, {(m, 0.6, 0.1, 0.3)}, {(n, 0.6, 0.3, 0.1)}\}, \\ E_{4} & = E_{1}\cup E_{2}, E_{5} = E_{1}\cup E_{3}, E_{6} = E_{2}\cup E_{3}, E_{7} = E_{1}\cap E_{2}, E_{8} = E_{1}\cap E_{3}, E_{9} = E_{2}\cap E_{3} \end{aligned}$

and ($X, \sigma$) be the PFTS. Then $\sigma^{c} = \{ \overline{1_{X}}, \overline{0_{X}}, \overline{E_{1}}, \overline{E_{2}}, \overline{E_{3}}, \overline{E_{4}}, \overline{E_{5}}, \overline{E_{6}}, \overline{E_{7}}, \overline{E_{8}}, \overline{E_{9}}\}$. Consider the picture fuzzy filter $\mathcal{F}_{1} = \{\overline{0_{x}}, \overline{E_{2}}, \overline{E_{3}}, \overline{E_{6}}, \overline{E_{9}}\}$.

Applying clustering algorithm to picture fuzzy sets from $\mathcal{F}_{1}$.

Step 1. The correlation coefficient of PFSs $\overline E_{j}(j = 2, 3, 6, 9)$ can be computed by using Eq (2.9) and the correlation matrix $M_{C}$ is constructed:

Step 2. Construct equivalent correlation matrices:

Therefore $M_{C}^{8} = M_{C}^{4}$. Hence $M_{C}^{4}$ is equivalent matrix.

Step 3. $\lambda$-cutting matrix $M_{{C}_{\lambda}} = ({\lambda}K_{ij})_{m\times m}$ is computed using the Eq (2.12), based on which, we get all possible classification of the employee $\overline E_{j}(j = 2, 3, 6, 9)$: classification shown in Table 6.

Thus the above illustration leads to classifying an employee from the picture fuzzy filter collection obtained in the third iteration. The number of iterations is more for some collection of picture fuzzy sets. Thus if the collection is a picture fuzzy filter, the classification is obtained at the earliest.

4.3.   Illustration: classification of intuitionistic fuzzy sets from intuitionistic fuzzy filter

Illustration 2. Let $\sigma = \{ 1_{X}, 0_{X}, A_{1}, A_{2}, A_{3}, A_{4}, A_{5}, A_{6}, A_{7}, A_{8}, A_{9}, A_{10}\}$ be the IFT and $(X, \sigma)$ be the IFTs. The membership values of intuitionistic fuzzy sets belongs to $\sigma^{c}$ is given in Table 4. Consider the intuitionistic fuzzy filter $\mathcal{F}_{2} = \{\overline{0_{x}}, \overline{A_{1}}, \overline{A_{6}}, \overline{A_{8}}, \overline{A_{10}}\}$.

Applying clustering algorithm to intuitionistic fuzzy sets from $\mathcal{F}_{2}$.

Step 1. The correlation coefficient of IFSs $\overline A_{j}(j = 1, 6, 8, 10)$ can be computed by using Eq (2.3) and the correlation matrix $M_{C}$ is constructed:

Step 2. Construct equivalent correlation matrices:

Therefore $M_{C}^{8} = M_{C}^{4}$. Hence $M_{C}^{4}$ is equivalent matrix.

Step 3. $\lambda$-cutting matrix $M_{C_{\lambda}} = ({}_{\lambda}K_{ij})_{m\times m}$ is computed using the Eq (2.6), based on which, we get all possible classification of the $\overline A_{j}(j = 1, 6, 8, 10)$: classification is shown in Table 6.

4.4.   Illustration: classification of car data set

Illustration 3.

Now we utilize the algorithm-IFSC to cluster the ten new cars $A_{i}(i = 1, 1, \cdots, 10)$ whose positive and negative membership values are provided in Table 5, which involves the following steps:

Step 1. Utilize to calculate the association coefficients of $A_{i}(i = 1, 1, \cdots, 10)$, and then construct an association matrix:

Step 2. Similarly, ${C}^{2}, {C}^{4}$ has be computed and ${C}^{8}, {C}^{16}$ are as follows:

hence, $C^{8} = C^{16}$, i.e., $C^{8}$ is an equivalent association matrix.

Step 3. Since the confidence level $\lambda$ has a close relationship with the element of the equivalent association matrix $C^{8}$, in the following, we give a detailed sensitivity analysis with respect to the confidence level $\lambda$ and we get all possible classifications of the 10 new cars $A_{i}(i = 1, 2, ..., 10)$: classification is shown in Table 6.

Classification of the above Illustrations are provided in Table 6.

4.5.   Comparative analysis

The clustering algorithm for picture fuzzy sets applied to picture fuzzy filter collection to classify the picture fuzzy sets can accommodate situations in which the inputs are picture fuzzy in nature. As the picture fuzzy set is the generalization of the fuzzy set and intuitionistic fuzzy set and hence the proposed method can be widely used. In Illustration 3, the classification of the intuitionistic fuzzy set is obtained by the $C^{16}$ associative matrix, whereas the classification of the intuitionistic fuzzy set belonging to the intuitionistic fuzzy filter by the clustering technique is obtained at the fourth stage. In Illustration 1, the classification of picture fuzzy sets belonging to picture fuzzy filter collection is obtained at the fourth stage, and the result is more generalized than the intuitionistic fuzzy set.

4.6.   Advantages of proposed method

The correlation coefficient for the intuitionistic fuzzy set has some limitations and cannot reflect the complete information about the nature of the fuzzy set. Picture fuzzy set is an extension of the intuitionistic fuzzy set, which reflects the information about positive, negative, and neutral membership and also the degree of refusal membership. The correlation coefficient between picture fuzzy sets proposed by P. Singh^[21] is applied to the picture fuzzy filter collection to effectively classify picture fuzzy sets from the picture fuzzy topological space. Classification of picture fuzzy set from picture fuzzy filter collection of any cardinality is obtained at the fourth stage of an equivalent correlation coefficient. The classification is compared with other intuitionistic fuzzy set collection to show fewer iterations required to classify the sets.

5.   Conclusions

This paper introduces the notion of picture fuzzy filter, picture fuzzy grill, and picture fuzzy ultrafilter. Properties of the picture fuzzy base and subbase are discussed. Interrelations between picture fuzzy filter, picture fuzzy grill and picture fuzzy ultrafilter are established along with their characterization. Picture fuzzy compact space is studied, and its characterization based on picture fuzzy filter, grill, and ultrafilter has been studied. A clustering algorithm for picture sets in a picture fuzzy filter is implemented with an illustration. Picture fuzzy filter collection reduces the number of iterations required to classify the picture fuzzy sets.

The clustering algorithm based on the correlation coefficient between picture fuzzy sets reflects the significance of positive, negative, and neutral membership. Classification of picture fuzzy sets using the clustering algorithm proposed by P. Singh^[21] is applied to the collection of filters obtained from the picture fuzzy topological space. Thus the paper shows that the decision-making problem in picture fuzzy topological space can be performed in a better way by using the picture fuzzy filter collection. The computational process for the correlation matrix in this work is obtained using MAPLE. The iteration for the equivalent correlation matrix will end at the fourth stage for any cardinality of picture fuzzy filter collection obtained from the picture fuzzy topological space, and the comparison among picture fuzzy filter and Intuitionistic fuzzy filter collection of different cardinalities have been classified at the fourth stage of the equivalent correlation matrix. In the future, the proposed work can be explored more precisely by defining a new clustering algorithm using picture fuzzy topological distance measure and picture fuzzy filter to analyze the classification in the topological structure and compare the accuracy with the other existing clustering algorithms and also pattern recognition problems.
