Abstract

1. Introduction

In numerous engineering and scientific domains, nonlinear fractional partial differential equations (NFDEs) have gained significant importance in the description and modelling of intricate processes. The memory and inherited characteristics of the system being modelled can be precisely captured via NFPDEs. These equations are particularly helpful for explaining anomalous diffusion phenomena and have a wide range of applications in disciplines like chemistry, physics, engineering, finance, biology, and economics ^{[1,2,3,4,5,6]}. As a result, in many application domains, the exploration of NFPDEs is crucial to comprehending and forecasting the behavior of complex systems. Nonetheless, there are special difficulties in resolving and interpreting fractional derivatives due to their non-locality and non-linearity. The solution and analysis of these equations may require the development of new methods and tools, as traditional analytical and numerical approaches might not be directly relevant. Notwithstanding these difficulties, research on NFPDEs has produced significant advances in a number of scientific and engineering domains ^[7,8,9]. Research opportunities have increased and our understanding of complicated processes has improved as a result of the development of new analytical and numerical techniques for solving and analyzing NFPDEs ^[10,11,12]. Exact solutions to nonlinear fractional problems can currently be obtained by a variety of effective methods, such as the generalized projective Riccati equation approach ^[13], sine-Gordon expansion method ^[14], generalized Riccati method and the auxiliary ordinary differential equation method ^[15], Lie symmetry approach ^[16], first integral method ^[17], modified Kudryashov method ^[18], extended exp ${(-\phi(\xi))}$ -expansion method ^[19], modified auxiliary equation method ^[20], unified method ^[21], $(\frac{G'}{G})$ -expansion methods ^[22,23,24], Khater methods ^[25,26], Poincaré-Lighthill-Kuo method ^[27], Riccati-Bernoulli Sub-ODE ^[28], exp-function method ^[29], fractional Sin-Gordon method ^[30], sub-equation method ^[31], tanh-method ^[32], extended direct algebraic method ^{[33,34,35,36]}, Sardar sub-equation method ^[37], exponential rational function method ^[38], and so on ^{[39,40,41,42,43,44]}.

Kundu et al. ^[45] introduced the Kundu-Mukherjee-Naskar equation (KMNE) for the first time in $2014$ and found optical soliton solutions for it. The KMNE has been the subject of extensive research recently. Its wave events are crucial for accurately modelling propagation pulses in high-speed data transfer in communication systems, optical fibers and the ocean currents of rogue waves ^[46,47,48]. One common application for optical fibers is the transmission of light between their two ends. Their long-distance and faster data transmission rate compared to wires makes them commonly employed in optical fiber communications. The goal of the current study is to construct and analyze optical soliton solutions for the gFKMNE, a fractional generalization of KMNE, which exhibits the following dimensionless display ^[49]:

$\begin{equation} i D^{\delta}_{t}z+a D^{\beta}_{y}(D^{\alpha}_{x} z)+i b z(z D^{\alpha}_{x} z^{*}-z^{*} D^{\alpha}_{x}) = 0, \end{equation}$

(1.1)

wherein $0 < \alpha, \beta, \delta \leq1$ , $z = z(t, x, y)$ is the quantity that represents a complex wave envelope, $z^{*}$ is the complex conjugate of $z$ . Furthermore, the dispersion term and the nonlinearity term are indicated by the two parameters $a$ , $b$ respectively. The wave's temporal history is represented by the first term in Eq (1), which is succeeded by the dispersion term $a D^{\beta}_{y}(D^{\alpha}_{x} z)$ . Ultimately, the coefficient of $b$ that is changed from the standard Kerr law nonlinearity represents the nonlinear portion. In optical fibers and communication systems, the pulse propagation is described by this equation. The fractional derivatives $D^{\alpha}_{x}(\circ)$ , $D^{\beta}_{y}(\circ)$ , and $D^{\delta}_{t}(\circ)$ are the generalized conformable fractional derivatives (gCFDs) of order $\alpha$ , $\beta$ , and $\delta$ respectively.

In many applications, such as irrigation and river flows, tidal waves, weather research and tsunami prediction, Eq (1.1) is used. Due to such significance, many researchers have developed an interest in examining Eq (1.1). For instance, Eq (1.1) was solved with new exact solutions by Günerhan et al. ^[50] through the use of an enhanced direct algebraic approach. Using the csch-approach, extended tanh-coth method, and extended rational sinh-cosh method, Rizvi et al. ^[51] were able to get the singular soliton, dark soliton, combination dark-singular soliton, and other hyperbolic solutions for Eq (1.1). Talarposhti et al. ^[52] derived optical soliton solutions for the KMNE using the exp-function approach. Onder et al. ^[53] used the novel Kudryashov techniques along with the Sardar sub-equation to introduce optical soliton solutions for the KMNE. Zafar et al. ^[54] found new soliton solutions for the KMNE by employing the exp-function approach and the extended Jacobi's elliptic expansion function. Kumar et al. ^[55] used the new auxiliary equation approach with the generalized Kudryashov method to find dark, bright, periodic U-shaped, and singular soliton solutions for Eq (1.1). Furthermore, this equation was investigated by other authors through the use of new precise solution techniques such the semi-inverse approach ^[56], the extended trial function method ^[57], the sine-Gordon and sinh-Gordon expansion methods ^[58], the Hamiltonian-based algorithm ^[59], Laplace-Adomian decomposition method ^[60], and other methods ^{[61,62,63,64,65]}.

Inspired by current research, we seek to address gFKMNE expressed in (1.1) through two enhanced implementations of the $(\frac{G'}{G})$ -expansion technique: the extended $(\frac{G'}{G})$ -expansion method and the generalized $(r+\frac{G'}{G})$ -expansion method, which are based on the reduction of NFPDEs to integer-order NODEs produced by the model's wave transformation. The strategic techniques further transform the resultant NODEs into an algebraic system of nonlinear equations by assuming a series-form solution. These equations may then be solved using the Maple tool to produce dark soliton lattices for gFKMNE. The important solitons in these dark soliton lattices are organized regularly in an optical medium. Dark soliton formations are collections of dark solitaires arranged regularly inside a medium. They are frequently shaped like wave channels or optical fibers. Similar to the lattice of a crystal, these solitons are restricted to areas of decreased optical intensity within a larger field that retain their structure and amplitude while moving. Not only can dark soliton lattices be used to precisely control and manipulate optical waves, but they can also be used to process information and communications networks, provide insight into nonlinear optics phenomena, provide platforms for basic research on the behavior of wave propagation, and have potential applications in signal processing, optical communication, and sensing. Thus, dark soliton lattices offer a stimulating new topic for nonlinear optics research that will enable both basic and applied investigations ^[66,67,68].

The format of the present article is as follows: Section 1 provides an introduction. The operational mechanism for the $(\frac{G'}{G})$ -expansion methods and the description of gCFD are detailed in Section 2. We build many additional sets of optical soliton solutions for Eq (1.1) in Section 3. A few illustrations and a graphical representations of dark soliton lattices are presented and discussed in Section 4. Our study excursion comes to an end with the provided conclusion in Section 5.

2. Materials and methodology

In this section, the basic definition of used fractional derivative gCFD and the operational procedure of the proposed methods are presented.

2.1. The definition of gCFD

Explicit soliton solutions to nonlinear FPDEs can be obtained by taking use of the advantages that gCFDs have over conventional fractional derivative operators. Notably, alternate formulations of fractional derivatives do not provide the optical soliton solutions of Eq (1.1) because they violate the chain rule ^[69,70]. Consequently, gCFDs were added to Eq (1.1). ^[71] defined this derivative operator of order $\wp$ as follows:

$\begin{equation} ^{gCFD} D^\wp_\varphi z(\varphi) = \lim\limits_{\varpi \to 0} \frac{z( (\frac{\Gamma(n)}{\Gamma(n-\wp+1)})\varpi \varphi^{1-\wp}+\varphi)-z(\varphi)}{\varpi}, \quad \wp \in (0,1] \quad n \geq -1, \quad n \in R. \end{equation}$

(2.1)

We utilize the following characteristics of this derivative in this study:

$\begin{equation} ^{gCFD} D^\wp_\varphi \varphi^\gamma = \frac{\gamma \Gamma(n)}{\Gamma(n-\wp+1)} \varphi^{\gamma-\wp}, \quad \forall \gamma \in R, \end{equation}$

(2.2)

$\begin{equation} ^{gCFD} D^\wp_\varphi(\gamma_1\rho(\varphi)\pm \gamma_2\eta(\varphi)) = \gamma_1 {^{gCFD} D^\wp_\varphi(\rho(\varphi))}\pm \gamma_2 {^{gCFD} D^\wp_\varphi(\eta(\varphi))}, \end{equation}$

(2.3)

$\begin{equation} ^{gCFD} D^\wp_\varphi \omega[\zeta(\varphi)] = \omega'_\zeta(\zeta(\varphi)) {^{gCFD} D^\wp_\varphi \zeta(\varphi)} , \end{equation}$

(2.4)

where $\rho(\varphi)$ , $\eta(\varphi)$ , $\omega(\varphi)$ , and $\zeta(\varphi)$ are arbitrary differentiable functions, whereas $\gamma$ , $\gamma_1$ and $\gamma_2$ signify constants.

2.2. The working methodology of $(\frac{G'}{G})$ -expansion method

In this phase of our study, we discuss the processes of the $(\frac{G'}{G})$ -expansion approach, with a focus on solving the given general NFPDE:

$\begin{equation} R(z, D^{ \delta}_{t} z, D^{ \alpha}_{x_1}z, D^{ \beta}_{x_1} z,z D^{ \alpha}_{x_1} z, \ldots) = 0, \quad 0 < \alpha, \beta , \delta \leq1, \end{equation}$

(2.5)

where $z = z(t, x_1, x_2, x_3, \ldots, x_j)$ .

Equation (2.5) is solved using the following strategy:

(ⅰ). Starting with a variable transformation of the framework $z(t, x_1, x_2, x_3, \dots, x_j) = Z(\varphi)$ , where $\varphi$ can be stated in a number of ways. Equation (2.5) progresses via this transformation, resulting in the NODE that follows:

$\begin{equation} Q(Z,Z'Z,Z',\dots) = 0, \end{equation}$

(2.6)

where $Z' = \frac{d Z}{d\varphi}$ . On rare occasions, the NODE may become vulnerable to the homogeneous balancing principle due to the integration of Eq (2.6).

(ⅱ). Next, based on the method's version, we assume the following series-form solution for (2.6):

Version 1. For the extended $(\frac{G'}{G})$ -expansion method, we assume the following $(\frac{G'}{G})$ solution:

$\begin{equation} Z(\varphi) = \sum\limits_{l = -\rho}^{\rho}\tau_l(\frac{G'(\varphi)}{G(\varphi)})^l, \end{equation}$

(2.7)

Version 2. For the generalized $(r+\frac{G'}{G})$ -expansion method, we assume the following $(\frac{G'}{G})$ solution:

$\begin{equation} Z(\varphi) = \sum\limits_{l = -\rho}^{\rho}\tau_l(r+\frac{G'(\varphi)}{G(\varphi)})^l, \quad r \in R, \end{equation}$

(2.8)

where it is subsequently necessary to compute the values of $\tau_l's (l = -\rho... \rho)$ . The balance number $\rho$ , a positive integer in Eqs (2.7) and (2.8), can be found by homogeneously balancing the nonlinear terms and the derivative with the highest order terms in Eq (2.6). Greater accuracy can be achieved in determining the balance number $\rho$ by applying the following mathematical formulas:

$\begin{equation} D(\frac{d^p Z}{d\varphi^p}) = \rho+p, \ \ \text{and} \ \ D(Z^q (\frac{d^p Z}{d\varphi^p})^s) = \rho q+p(s+\rho), \end{equation}$

(2.9)

where $D$ expresses the degree of $Z(\varphi)$ , whereas $p, q$ , and $s$ are positive integers.

Moreover, the function $G(\varphi)$ in Eq (2.8) satisfies the subsequent second-order linear ODE:

$\begin{equation} G''(\varphi)+\lambda G'(\varphi)+\mu G(\varphi) = 0, \end{equation}$

(2.10)

where $\lambda, \mu$ are constants.

Moreover, with Eq (2.10)'s general solution, we have:

$\begin{equation} \bigg(\frac{G'(\varphi)}{G(\varphi)}\bigg) = \left\{ \begin{array}{ll} \frac{1}{2}\,{\frac {\sqrt {\kappa} \left( \nu_{{1}}\sinh \left( \frac{1}{2}\,\sqrt { \kappa}\varphi \right) +\nu_{{2}}\cosh \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) \right) }{\nu_{{1}}\cosh \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) +\nu_{{2}}\sinh \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) }}-\frac{1}{2} \,\lambda, & \kappa < 0, \\ \frac{1}{2}\,{\frac {\sqrt {-\kappa} \left( -\nu_{{1}}\sin \left( \frac{1}{2}\,\sqrt {- \kappa}\varphi \right) +\nu_{{2}}\cos \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) \right) }{\nu_{{1}}\cos \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) +\nu_{{2}}\sin \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) }}-\frac{1}{2} \,\lambda, & \kappa > 0, \\ {\frac {\nu_{{2}}}{\nu_{{1}}+\nu_{{2}}\varphi}}, & \kappa = 0,\\ \end{array} \right. \end{equation}$

(2.11)

where $\kappa = \lambda^2-4\mu$ , while $\nu_1$ and $\nu_2$ in (2.11) are arbitrary constants.

(ⅲ). Next, we insert Eqs (2.8) or (2.7) into Eq (2.6) or into the Equation that we acquired from the integration of Eq (2.6), and we gather all the terms that have an analogous power of $(\frac{G'(\varphi)}{G(\varphi)})$ .

(ⅳ). The derived polynomial $(\frac{G'(\varphi)}{G(\varphi)})^i$ has all of its coefficients equal to zero, resulting in a collection of nonlinear algebraic equations in $\tau_l (l = -\rho..., \rho)$ , $\lambda$ , $\mu$ , and other necessary parameters.

(ⅴ). The unresolved parameters are discovered by using the Maple tool to solve the resulting system.

(ⅵ). To generate sets of soliton solutions for Eq (2.5), the values predicted from step 5 are subsequently substituted in Eqs (2.7) or (2.8), depending on the version.

3. Establishing optical soliton solutions for gFKMNE

We use the suggested methods in this section to build families of optical soliton solutions for (1.1). Using the subsequent wave modification as a component of the procedure, we can (1.1):

$\begin{equation} \begin{split} &z(x,y,t) = e^{i \xi} Z(\varphi),\quad \xi = \xi(t,x,y), \quad \varphi = \varphi(t,x,y), \\ & \varphi = {\frac {p_{{1}}\Gamma \left( n-\alpha+1 \right) {x}^{\alpha}}{\alpha \,\Gamma \left( n \right) }}+{\frac {p_{{2}}\Gamma \left( n-\beta+1 \right) {y}^{\beta}}{\beta\,\Gamma \left( n \right) }}-{\frac {\varrho\, \Gamma \left( n-\delta+1 \right) {t}^{\delta}}{\delta\,\Gamma \left( n \right) }}, \\ & \xi = -{\frac {q_{{1}}\Gamma \left( n-\alpha+1 \right) {x}^{\alpha}}{\alpha \,\Gamma \left( n \right) }}-{\frac {q_{{2}}\Gamma \left( n-\beta+1 \right) {y}^{\beta}}{\beta\,\Gamma \left( n \right) }}+{\frac { \omega\,\Gamma \left( n-\delta+1 \right) {t}^{\delta}}{\delta\, \Gamma \left( n \right) }}+\theta_{{0}}, \\ \end{split} \end{equation}$

(3.1)

where $Z(\varphi)$ symbolizes the amplitude part, $q_1$ and $q_2$ indicate wave numbers in the $x-$ and $y-$ directions, respectively, $\omega$ represents the frequency of the wave and $\theta_0$ is a constant, the parameters $p_1$ and $p_2$ indicate inverse width along the $x$ and $y$ directions, respectively, and $\varrho$ is used for the velocity, delivering the afterwards NODE from the real part of (1.1):

$\begin{equation} \begin{split} - a p_1 p_2 Z''-(\omega+a q_1 q_2) Z -2 b q_1 Z^3 = 0, \end{split} \end{equation}$

(3.2)

with the constraint from the imaginary part:

$\begin{equation} \varrho = -a \left( q_{{1}}p_{{2}}+q_{{2}}p_{{1}} \right). \end{equation}$

(3.3)

It is established that $\rho = 1$ when a homogeneous balancing condition between $Z''$ and $Z^3$ (given in (3.2)) has been created.

3.1. Implementation of the extended $(\frac{G'}{G})$ -expansion method

First, we wish to address (3.2) with the help of the extended $(\frac{G'}{G})$ -expansion method. Equation (2.7) yields the following closed form solution for (3.2) when $\rho = 1$ is substituted in it:

$\begin{equation} U(\varphi) = \sum\limits_{l = -1}^{1}\tau_l \bigg(\frac{G'(\varphi)}{G(\varphi)}\bigg)^l. \end{equation}$

(3.4)

By including (3.4) in (3.2) and bringing together terms with a comparable power of $\bigg(\frac{G'(\varphi)}{G(\varphi)}\bigg)$ , we get an expression based on the terms $\bigg(\frac{G'(\varphi)}{G(\varphi)}\bigg)$ . By setting the coefficients to zero, this formula can be converted into a set of algebraic nonlinear equations. The system can be solved using Maple in the following three cases of solutions:

Case 1.1.

$\begin{equation} \begin{split} &\tau_{{0}} = \frac{1}{2}\,{\frac {\tau_{{-1}}\lambda}{\mu}},\tau_{{1}} = 0,\tau_{ {-1}} = \tau_{{-1}},p_{{1}} = p_{{1}},p_{{2}} = p_{{2}},q_{{1}} = {\frac {ap_{ {1}}p_{{2}}{\mu}^{2}}{b{\tau_{{-1}}}^{2}}},\\ &q_{{2}} = q_{{2}},\omega = -\frac{1}{2} \,{\frac {ap_{{1}}p_{{2}} \left( -4\,\mu\,b{\tau_{{-1}}}^{2}+2\,a{\mu} ^{2}q_{{2}}+{\lambda}^{2}b{\tau_{{-1}}}^{2} \right) }{b{\tau_{{-1}}}^{ 2}}}. \end{split} \end{equation}$

(3.5)

Case 1.2.

$\begin{equation} \begin{split} &\tau_{{0}} = \frac{1}{2}\,\tau_{{1}}\lambda,\tau_{{1}} = \tau_{{1}},\tau_{{-1}} = 0 ,p_{{1}} = p_{{1}},p_{{2}} = p_{{2}},q_{{1}} = {\frac {ap_{{1}}p_{{2}}}{b{ \tau_{{1}}}^{2}}},\\ &q_{{2}} = q_{{2}},\omega = -\frac{1}{2}\,{\frac {ap_{{1}}p_{{2}} \left( -4\,\mu\,b{\tau_{{1}}}^{2}+2\,aq_{{2}}+{\lambda}^{2}b{\tau_{{1 }}}^{2} \right) }{b{\tau_{{1}}}^{2}}}. \end{split} \end{equation}$

(3.6)

Case 1.3.

$\begin{equation} \begin{split} \tau_{{0}} = \tau_{{0}},\tau_{{1}} = \tau_{{1}},\tau_{{-1}} = \tau_{{-1}},p _{{1}} = 0,p_{{2}} = p_{{2}},q_{{1}} = 0,q_{{2}} = q_{{2}},\omega = 0. \end{split} \end{equation}$

(3.7)

Considering case 1.1 and utilizing Eq (3.1), (3.4) and the corresponding general solution of (2.10), we construct the subsequent plethora of optical soliton solutions for (1.1):

Family 1.1.1. When $\tau > 0$ ,

(ⅰ) When $\nu_1\neq0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{1,1,1}(t,x,y) = & e^{i \xi}\bigg( \tau_{{-1}} \left( \frac{1}{2}\,{\frac {\sqrt {\kappa} \left( \nu_{{1}}\sinh \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) +\nu_{{2}}\cosh \left( \frac{1}{2} \,\sqrt {\kappa}\varphi \right) \right) }{\nu_{{1}}\cosh \left( \frac{1}{2} \,\sqrt {\kappa}\varphi \right) +\nu_{{2}}\sinh \left( \frac{1}{2}\,\sqrt { \kappa}\varphi \right) }}-\frac{1}{2}\,\lambda \right) ^{-1}+\frac{1}{2}\,{\frac { \tau_{{-1}}\lambda}{\mu}} \bigg). \end{split} \end{equation}$

(3.8)

(ⅱ) When $\nu_1 = 0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{1,1,2}(t,x,y) = & e^{i \xi}\bigg( {\frac {\tau_{{-1}}}{\frac{1}{2}\,\sqrt {\kappa}\coth \left( \frac{1}{2}\,\sqrt { \kappa}\varphi \right) -\frac{1}{2}\,\lambda}}+\frac{1}{2}\,{\frac {\tau_{{-1}} \lambda}{\mu}} \bigg). \end{split} \end{equation}$

(3.9)

(ⅲ) When $\nu_1\neq0$ , $\nu_2 = 0$

$\begin{equation} \begin{split} u_{1,1,3}(t,x,y) = & e^{i \xi}\bigg( {\frac {\tau_{{-1}}}{\frac{1}{2}\,\sqrt {\kappa}\tanh \left( \frac{1}{2}\,\sqrt { \kappa}\varphi \right) -\frac{1}{2}\,\lambda}}+\frac{1}{2}\,{\frac {\tau_{{-1}} \lambda}{\mu}} \bigg). \end{split} \end{equation}$

(3.10)

Family 1.1.2. When $\tau < 0$ ,

(ⅰ) When $\nu_1\neq0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{1,1,4}(t,x,y) = & e^{i \xi}\bigg( \tau_{{-1}} \left( \frac{1}{2}\,{\frac {\sqrt {-\kappa} \left( -\nu_{{1}}\sin \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) +\nu_{{2}}\cos \left( \frac{1}{2} \,\sqrt {-\kappa}\varphi \right) \right) }{\nu_{{1}}\cos \left( \frac{1}{2} \,\sqrt {-\kappa}\varphi \right) +\nu_{{2}}\sin \left( \frac{1}{2}\,\sqrt {- \kappa}\varphi \right) }}-\frac{1}{2}\,\lambda \right) ^{-1}+\frac{1}{2}\,{\frac { \tau_{{-1}}\lambda}{\mu}} \bigg). \end{split} \end{equation}$

(3.11)

(ⅱ) When $\nu_1 = 0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{1,1,5}(t,x,y) = & e^{i \xi}\bigg( {\frac {\tau_{{-1}}}{\frac{1}{2}\,\sqrt {-\kappa}\cot \left( \frac{1}{2}\,\sqrt {- \kappa}\varphi \right) -\frac{1}{2}\,\lambda}}+\frac{1}{2}\,{\frac {\tau_{{-1}} \lambda}{\mu}} \bigg). \end{split} \end{equation}$

(3.12)

(ⅲ) When $\nu_1\neq0$ , $\nu_2 = 0$

$\begin{equation} \begin{split} u_{1,1,6}(t,x,y) = & e^{i \xi}\bigg( {\frac {\tau_{{-1}}}{-\frac{1}{2}\,\sqrt {-\kappa}\tan \left( \frac{1}{2}\,\sqrt {- \kappa}\varphi \right) -\frac{1}{2}\,\lambda}}+\frac{1}{2}\,{\frac {\tau_{{-1}} \lambda}{\mu}} \bigg). \end{split} \end{equation}$

(3.13)

Family 1.1.3. When $\tau = 0$ ,

(ⅰ) When $\nu_1\neq0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{1,1,7}(t,x,y) = & e^{i \xi}\bigg({\frac {\tau_{{-1}} \left( \nu_{{1}}+\nu_{{2}}\varphi \right) }{\nu_{ {2}}}}+\frac{1}{2}\,{\frac {\tau_{{-1}}\lambda}{\mu}} \bigg). \end{split} \end{equation}$

(3.14)

(ⅱ) When $\nu_1 = 0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{1,1,8}(t,x,y) = & e^{i \xi}\bigg( {\frac {\tau_{{-1}}}{{\varphi }^{-1}-\frac{1}{2}\,\lambda}}+\frac{1}{2}\,{\frac {\tau_ {{-1}}\lambda}{\mu}} \bigg). \end{split} \end{equation}$

(3.15)

(ⅲ) When $\nu_1\neq0$ , $\nu_2 = 0$

$\begin{equation} \begin{split} u_{1,1,9}(t,x,y) = & e^{i \xi}\bigg( -2\,{\frac {\tau_{{-1}}}{\lambda}}+\frac{1}{2}\,{\frac {\tau_{{-1}}\lambda}{ \mu}} \bigg), \end{split} \end{equation}$

(3.16)

where $\varphi = {\frac {p_{{1}}\Gamma \left(n-\alpha+1 \right) {x}^{\alpha}}{\alpha \, \Gamma \left(n \right) }}+{\frac {p_{{2}}\Gamma \left(n-\beta+1 \right) {y}^{\beta}}{\beta\, \Gamma \left(n \right) }}-{\frac {\varrho\, \Gamma \left(n-\delta+1 \right) {t}^{\delta}}{\delta\, \Gamma \left(n \right) }}$ $\xi = -{\frac {q_{{1}}\Gamma \left(n-\alpha+1 \right) {x}^{\alpha}}{\alpha \, \Gamma \left(n \right) }}-{\frac {q_{{2}}\Gamma \left(n-\beta+1 \right) {y}^{\beta}}{\beta\, \Gamma \left(n \right) }}+{\frac { \omega\, \Gamma \left(n-\delta+1 \right) {t}^{\delta}}{\delta\, \Gamma \left(n \right) }}+\theta_{{0}}$ for $q_1$ and $\omega$ defined in Eq (3.5).

Considering case 1.2 and utilizing Eq (3.1), (3.4) and the corresponding general solution of (2.10), we construct the subsequent plethora of optical soliton solutions for (1.1):

Family 1.2.1. When $\tau > 0$ ,

(ⅰ) When $\nu_1\neq0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{1,2,1}(t,x,y) = & e^{i \xi}\bigg( \frac{1}{2}\,\tau_{{1}}\lambda+\tau_{{1}} \left( \frac{1}{2}\,{\frac {\sqrt {\kappa} \left( \nu_{{1}}\sinh \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) +\nu _{{2}}\cosh \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) \right) }{\nu_ {{1}}\cosh \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) +\nu_{{2}}\sinh \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) }}-\frac{1}{2}\,\lambda \right) \bigg). \end{split} \end{equation}$

(3.17)

(ⅱ) When $\nu_1 = 0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{1,2,2}(t,x,y) = & e^{i \xi}\bigg( \frac{1}{2}\,\tau_{{1}}\lambda+\tau_{{1}} \left( \frac{1}{2}\,\sqrt {\kappa}\coth \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) -\frac{1}{2}\,\lambda \right) \bigg). \end{split} \end{equation}$

(3.18)

(ⅲ) When $\nu_1\neq0$ , $\nu_2 = 0$

$\begin{equation} \begin{split} u_{1,2,3}(t,x,y) = & e^{i \xi}\bigg( \frac{1}{2}\,\tau_{{1}}\lambda+\tau_{{1}} \left( \frac{1}{2}\,\sqrt {\kappa}\tanh \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) -\frac{1}{2}\,\lambda \right) \bigg). \end{split} \end{equation}$

(3.19)

Family 1.2.2. When $\tau < 0$ ,

(ⅰ) When $\nu_1\neq0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{1,2,4}(t,x,y) = & e^{i \xi}\bigg( \frac{1}{2}\,\tau_{{1}}\lambda+\tau_{{1}} \left( \frac{1}{2}\,{\frac {\sqrt {-\kappa} \left( -\nu_{{1}}\sin \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) + \nu_{{2}}\cos \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) \right) }{ \nu_{{1}}\cos \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) +\nu_{{2}} \sin \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) }}-\frac{1}{2}\,\lambda \right) \bigg). \end{split} \end{equation}$

(3.20)

(ⅱ) When $\nu_1 = 0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{1,2,5}(t,x,y) = & e^{i \xi}\bigg( \frac{1}{2}\,\tau_{{1}}\lambda+\tau_{{1}} \left( \frac{1}{2}\,\sqrt {-\kappa}\cot \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) -\frac{1}{2}\,\lambda \right) \bigg). \end{split} \end{equation}$

(3.21)

(ⅲ) When $\nu_1\neq0$ , $\nu_2 = 0$

$\begin{equation} \begin{split} u_{1,2,6}(t,x,y) = & e^{i \xi}\bigg( \frac{1}{2}\,\tau_{{1}}\lambda+\tau_{{1}} \left( -\frac{1}{2}\,\sqrt {-\kappa}\tan \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) -\frac{1}{2}\,\lambda \right) \bigg). \end{split} \end{equation}$

(3.22)

Family 1.2.3. When $\tau = 0$ ,

(ⅰ) When $\nu_1\neq0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{1,2,7}(t,x,y) = & e^{i \xi}\bigg( \frac{1}{2}\,\tau_{{1}}\lambda+{\frac {\tau_{{1}}\nu_{{2}}}{\nu_{{1}}+\nu_{{2} }\varphi }} \bigg). \end{split} \end{equation}$

(3.23)

(ⅱ) When $\nu_1 = 0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{1,2,8}(t,x,y) = & e^{i \xi}\bigg( \frac{1}{2}\,\tau_{{1}}\lambda+\tau_{{1}} \left( {\varphi }^{-1}-\frac{1}{2}\,\lambda \right) \bigg), \end{split} \end{equation}$

(3.24)

Considering case 1.3 and utilizing Eq (3.1), (3.4) and the corresponding general solution of (2.10), we construct the subsequent plethora of optical soliton solutions for (1.1)

Family 1.3.1. When $\tau > 0$ ,

(ⅰ) When $\nu_1\neq0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{1,3,1}(t,x,y) = & e^{i \xi}\bigg( \tau_{{-1}} \left( \frac{1}{2}\,{\frac {\sqrt {\kappa} \left( \nu_{{1}}\sinh \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) +\nu_{{2}}\cosh \left( \frac{1}{2} \,\sqrt {\kappa}\varphi \right) \right) }{\nu_{{1}}\cosh \left( \frac{1}{2} \,\sqrt {\kappa}\varphi \right) +\nu_{{2}}\sinh \left( \frac{1}{2}\,\sqrt { \kappa}\varphi \right) }}-\frac{1}{2}\,\lambda \right) ^{-1}\\ &+\tau_{{0}}+\tau_ {{1}} \left( \frac{1}{2}\,{\frac {\sqrt {\kappa} \left( \nu_{{1}}\sinh \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) +\nu_{{2}}\cosh \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) \right) }{\nu_{{1}}\cosh \left( \frac{1}{2}\,\sqrt { \kappa}\varphi \right) +\nu_{{2}}\sinh \left( \frac{1}{2}\,\sqrt {\kappa} \varphi \right) }}-\frac{1}{2}\,\lambda \right) \bigg). \end{split} \end{equation}$

(3.25)

(ⅱ) When $\nu_1 = 0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{1,3,2}(t,x,y) = & e^{i \xi}\bigg( {\frac {\tau_{{-1}}}{\frac{1}{2}\,\sqrt {\kappa}\coth \left( \frac{1}{2}\,\sqrt { \kappa}\varphi \right) -\frac{1}{2}\,\lambda}}+\tau_{{0}}+\tau_{{1}} \left( \frac{1}{2} \sqrt {\kappa}\coth \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) -\frac{1}{2}\lambda \right) \bigg). \end{split} \end{equation}$

(3.26)

(ⅲ) When $\nu_1\neq0$ , $\nu_2 = 0$

$\begin{equation} \begin{split} u_{1,3,3}(t,x,y) = & e^{i \xi}\bigg( {\frac {\tau_{{-1}}}{\frac{1}{2}\,\sqrt {\kappa}\tanh \left( \frac{1}{2}\,\sqrt { \kappa}\varphi \right) -\frac{1}{2}\,\lambda}}+\tau_{{0}}+\tau_{{1}} \left( \frac{1}{2} \sqrt {\kappa}\tanh \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) -\frac{1}{2} \lambda \right) \bigg). \end{split} \end{equation}$

(3.27)

Family 1.3.2. When $\tau < 0$ ,

(ⅰ) When $\nu_1\neq0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{1,3,4}(t,x,y) = & e^{i \xi}\bigg( \tau_{{-1}} \left( \frac{1}{2}\,{\frac {\sqrt {-\kappa} \left( -\nu_{{1}}\sin \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) +\nu_{{2}}\cos \left( \frac{1}{2} \,\sqrt {-\kappa}\varphi \right) \right) }{\nu_{{1}}\cos \left( \frac{1}{2} \,\sqrt {-\kappa}\varphi \right) +\nu_{{2}}\sin \left( \frac{1}{2}\,\sqrt {- \kappa}\varphi \right) }}-\frac{1}{2}\,\lambda \right) ^{-1}\\ &+\tau_{{0}}+\tau_ {{1}} \left( \frac{1}{2}\,{\frac {\sqrt {-\kappa} \left( -\nu_{{1}}\sin \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) +\nu_{{2}}\cos \left( \frac{1}{2} \,\sqrt {-\kappa}\varphi \right) \right) }{\nu_{{1}}\cos \left( \frac{1}{2} \,\sqrt {-\kappa}\varphi \right) +\nu_{{2}}\sin \left( \frac{1}{2}\,\sqrt {- \kappa}\varphi \right) }}-\frac{1}{2}\,\lambda \right) \bigg). \end{split} \end{equation}$

(3.28)

(ⅱ) When $\nu_1 = 0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{1,3,5}(t,x,y) = & e^{i \xi}\bigg( {\frac {\tau_{{-1}}}{\frac{1}{2}\,\sqrt {-\kappa}\cot \left( \frac{1}{2}\,\sqrt {- \kappa}\varphi \right) -\frac{1}{2}\,\lambda}}+\tau_{{0}}+\tau_{{1}} \left( \frac{1}{2} \sqrt {-\kappa}\cot \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) -\frac{1}{2}\lambda \right) \bigg). \end{split} \end{equation}$

(3.29)

(ⅲ) When $\nu_1\neq0$ , $\nu_2 = 0$

$\begin{equation} \begin{split} u_{1,3,6}(t,x,y) = & e^{i \xi}\bigg( {\frac {\tau_{{-1}}}{-\frac{1}{2}\,\sqrt {-\kappa}\tan \left( \frac{1}{2}\,\sqrt {- \kappa}\varphi \right) -\frac{1}{2}\,\lambda}}+\tau_{{0}}+\tau_{{1}} \left( - \frac{1}{2}\,\sqrt {-\kappa}\tan \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) - \frac{1}{2}\,\lambda \right) \bigg). \end{split} \end{equation}$

(3.30)

Family 1.3.3. When $\tau = 0$ ,

(ⅰ) When $\nu_1\neq0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{1,3,7}(t,x,y) = & e^{i \xi}\bigg( {\frac {\tau_{{-1}} \left( \nu_{{1}}+\nu_{{2}}\varphi \right) }{\nu_{ {2}}}}+\tau_{{0}}+{\frac {\tau_{{1}}\nu_{{2}}}{\nu_{{1}}+\nu_{{2}} \varphi }} \bigg). \end{split} \end{equation}$

(3.31)

(ⅱ) When $\nu_1 = 0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{1,3,8}(t,x,y) = & e^{i \xi}\bigg( {\frac {\tau_{{-1}}}{{\varphi }^{-1}-\frac{1}{2}\,\lambda}}+\tau_{{0}}+\tau_{{ 1}} \left( {\varphi }^{-1}-\frac{1}{2}\,\lambda \right) \bigg). \end{split} \end{equation}$

(3.32)

(ⅲ) When $\nu_1\neq0$ , $\nu_2 = 0$

$\begin{equation} \begin{split} u_{1,3,9}(t,x,y) = & e^{i \xi}\bigg( -2\,{\frac {\tau_{{-1}}}{\lambda}}+\tau_{{0}}-\frac{1}{2}\,\tau_{{1}}\lambda \bigg), \end{split} \end{equation}$

(3.33)

where $\varphi = {\frac {p_{{2}}\Gamma \left(n-\beta+1 \right) {y}^{\beta}}{\beta\, \Gamma \left(n \right) }}-{\frac {\varrho\, \Gamma \left(n-\delta+1 \right) {t}^{\delta}}{\delta\, \Gamma \left(n \right) }} \xi = -{\frac {q_{{2}}\Gamma \left(n-\beta+1 \right) {y}^{\beta}}{\beta\, \Gamma \left(n \right) }}+\theta_{{0}}$ .

3.2. Implementation of the generalized $(r+\frac{G'}{G})$ -expansion method

Now, we wish to address (3.2) with the help of the generalized $(r+\frac{G'}{G})$ -expansion method. Equation (2.8) yields the following closed-form solution for (3.2) when $\rho = 1$ is substituted in it:

$\begin{equation} U(\varphi) = \sum\limits_{l = -1}^{1}\tau_l \bigg(r+\frac{G'(\varphi)}{G(\varphi)}\bigg)^l. \end{equation}$

(3.34)

We obtain an expression based on the terms $\bigg(r+\frac{G'(\varphi)}{G(\varphi)}\bigg)$ by including (3.34) in (3.2) and combining terms with similar powers of $\bigg(r+\frac{G'(\varphi)}{G(\varphi)}\bigg)$ . By setting the coefficients to zero, this formula can be converted into a set of algebraic nonlinear equations. Following Maple's solution to this system, the following six cases of solutions are generated:

Case 2.1.

$\begin{equation} \begin{split} \tau_{{0}} = \tau_{{0}},\tau_{{1}} = 0,\tau_{{-1}} = -\tau_{{0}}\sqrt { \kappa},p_{{1}} = p_{{1}},p_{{2}} = p_{{2}},q_{{1}} = 0,q_{{2}} = q_{{2}}, \omega = \kappa\,ap_{{1}}p_{{2}},r = \frac{1}{2}\,\lambda+\frac{1}{2}\,\sqrt {\kappa}. \end{split} \end{equation}$

(3.35)

Case 2.2.

$\begin{equation} \begin{split} &\tau_{{0}} = \tau_{{0}},\tau_{{1}} = 0,\tau_{{-1}} = -2\,{\frac {\tau_{{0}} \left( {r}^{2}-\lambda\,r+\mu \right) }{2\,r-\lambda}},p_{{1}} = p_{{1} },q_{{1}} = \frac{1}{4}\,{\frac { \left( 4\,{r}^{2}-4\,\lambda\, r+{\lambda}^{2} \right) ap_{{1}}p_{{2}}}{{\tau_{{0}}}^{2}b}},\\ &q_{{2}} = q _{{2}},\omega = -\frac{1}{4}\,{\frac { \left( 4\,aq_{{2}}{r}^{2}-4\,aq_{{2}} \lambda\,r-8\,{\tau_{{0}}}^{2}b\mu+2\,{\tau_{{0}}}^{2}b{\lambda}^{2}+a q_{{2}}{\lambda}^{2} \right) ap_{{1}}p_{{2}}}{{\tau_{{0}}}^{2}b}},p_{{2}} = p_{{2}},r = r. \end{split} \end{equation}$

(3.36)

Case 2.3.

$\begin{equation} \begin{split} &\tau_{{0}} = \frac{1}{2}\,\tau_{{1}}\lambda-\tau_{{1}}r,\tau_{{1}} = \tau_{{1}}, \tau_{{-1}} = 0,p_{{1}} = p_{{1}},p_{{2}} = p_{{2}},q_{{1}} = {\frac {ap_{{1}} p_{{2}}}{b{\tau_{{1}}}^{2}}},\\ &q_{{2}} = q_{{2}},\omega = -\frac{1}{2}\,{\frac {ap_{ {1}}p_{{2}} \left( {\lambda}^{2}b{\tau_{{1}}}^{2}+2\,aq_{{2}}-4\,\mu\, b{\tau_{{1}}}^{2} \right) }{b{\tau_{{1}}}^{2}}},r = r. \end{split} \end{equation}$

(3.37)

Case 2.4.

$\begin{equation} \begin{split} &\tau_{{0}} = 0,\tau_{{1}} = \tau_{{1}},\tau_{{-1}} = -\mu\,\tau_{{1}}+\frac{1}{4}\, \tau_{{1}}{\lambda}^{2},p_{{1}} = p_{{1}},p_{{2}} = p_{{2}},q_{{1}} = { \frac {ap_{{1}}p_{{2}}}{b{\tau_{{1}}}^{2}}},\\ &q_{{2}} = q_{{2}},\omega = -{ \frac {ap_{{1}}p_{{2}} \left( -8\,\mu\,b{\tau_{{1}}}^{2}+2\,{\lambda}^ {2}b{\tau_{{1}}}^{2}+aq_{{2}} \right) }{b{\tau_{{1}}}^{2}}},r = \frac{1}{2}\, \lambda. \end{split} \end{equation}$

(3.38)

Case 2.5.

$\begin{equation} \begin{split} &\tau_{{0}} = \tau_{{0}},\tau_{{1}} = 0,\tau_{{-1}} = -2\,\tau_{{0}} \left( \frac{1}{2}\,\lambda+\frac{1}{2}\,\sqrt {-\kappa} \right) +\lambda\,\tau_{{0}},p_{{1}} = p_{{1}},p_{{2}} = p_{{2}},q_{{1}} = -\frac{1}{4}\,{\frac {\kappa\,ap_{{1}}p_{{2}} }{{\tau_{{0}}}^{2}b}},\\ &q_{{2}} = q_{{2}},\omega = -\frac{1}{4}\,{\frac { \left( -8 \,{\tau_{{0}}}^{2}b\mu+2\,{\tau_{{0}}}^{2}b{\lambda}^{2}+4\,aq_{{2}} \mu-aq_{{2}}{\lambda}^{2} \right) ap_{{1}}p_{{2}}}{{\tau_{{0}}}^{2}b}} ,r = \frac{1}{2}\,\lambda+\frac{1}{2}\,\sqrt {-\kappa}. \end{split} \end{equation}$

(3.39)

Case 2.6.

$\begin{equation} \begin{split} &\tau_{{0}} = 0,\tau_{{1}} = \tau_{{1}},\tau_{{-1}} = \mu\,\tau_{{1}}-\frac{1}{4}\, \tau_{{1}}{\lambda}^{2},p_{{1}} = p_{{1}},p_{{2}} = p_{{2}},q_{{1}} = { \frac {ap_{{1}}p_{{2}}}{b{\tau_{{1}}}^{2}}},\\ &q_{{2}} = q_{{2}},\omega = -{ \frac {ap_{{1}}p_{{2}} \left( 4\,\mu\,b{\tau_{{1}}}^{2}-{\lambda}^{2}b {\tau_{{1}}}^{2}+aq_{{2}} \right) }{b{\tau_{{1}}}^{2}}},r = \frac{1}{2}\,\lambda. \end{split} \end{equation}$

(3.40)

Considering case 2.1 and utilizing Eq (3.1), (3.34) and the corresponding general solution of Eq (2.10), we construct the subsequent plethora of optical soliton solutions for (1.1):

Family 2.1.1. When $\tau > 0$ ,

(ⅰ) When $\nu_1\neq0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{2,1,1}(t,x,y) = & e^{i \xi}\bigg( -\tau_{{0}}\sqrt {\kappa} \left( \frac{1}{2}\,\sqrt {\kappa}+\frac{1}{2}\,{\frac { \sqrt {\kappa} \left( \nu_{{1}}\sinh \left( \frac{1}{2}\,\sqrt {\kappa} \varphi \right) +\nu_{{2}}\cosh \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) \right) }{\nu_{{1}}\cosh \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) +\nu_{{2}}\sinh \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) }} \right) ^{-1}+\tau_{{0}} \bigg). \end{split} \end{equation}$

(3.41)

(ⅱ) When $\nu_1 = 0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{2,1,2}(t,x,y) = & e^{i \xi}\bigg( -{\frac {\tau_{{0}}\sqrt {\kappa}}{\frac{1}{2}\,\sqrt {\kappa}+\frac{1}{2}\,\sqrt { \kappa}\coth \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) }}+\tau_{{0}} \bigg). \end{split} \end{equation}$

(3.42)

(ⅲ) When $\nu_1\neq0$ , $\nu_2 = 0$

$\begin{equation} \begin{split} u_{2,1,3}(t,x,y) = & e^{i \xi}\bigg( -{\frac {\tau_{{0}}\sqrt {\kappa}}{\frac{1}{2}\,\sqrt {\kappa}+\frac{1}{2}\,\sqrt { \kappa}\tanh \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) }}+\tau_{{0}} \bigg). \end{split} \end{equation}$

(3.43)

Family 2.1.2. When $\tau < 0$ ,

(ⅰ) When $\nu_1\neq0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{2,1,4}(t,x,y) = & e^{i \xi}\bigg( -\tau_{{0}}\sqrt {\kappa} \left( \frac{1}{2}\,\sqrt {\kappa}+\frac{1}{2}\,{\frac { \sqrt {-\kappa} \left( -\nu_{{1}}\sin \left( \frac{1}{2}\,\sqrt {-\kappa} \varphi \right) +\nu_{{2}}\cos \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) \right) }{\nu_{{1}}\cos \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) +\nu_{{2}}\sin \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) }} \right) ^{-1}+\tau_{{0}} \bigg). \end{split} \end{equation}$

(3.44)

(ⅱ) When $\nu_1 = 0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{2,1,5}(t,x,y) = & e^{i \xi}\bigg( -{\frac {\tau_{{0}}\sqrt {\kappa}}{\frac{1}{2}\,\sqrt {\kappa}+\frac{1}{2}\,\sqrt {- \kappa}\cot \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) }}+\tau_{{0}} \bigg). \end{split} \end{equation}$

(3.45)

(ⅲ) When $\nu_1\neq0$ , $\nu_2 = 0$

$\begin{equation} \begin{split} u_{2,1,6}(t,x,y) = & e^{i \xi}\bigg( -{\frac {\tau_{{0}}\sqrt {\kappa}}{\frac{1}{2}\,\sqrt {\kappa}-\frac{1}{2}\,\sqrt {- \kappa}\tan \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) }}+\tau_{{0}} \bigg). \end{split} \end{equation}$

(3.46)

Family 2.1.3. When $\tau = 0$ ,

(ⅰ) When $\nu_1\neq0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{2,1,7}(t,x,y) = & e^{i \xi}\bigg( -\tau_{{0}}\sqrt {\kappa} \left( \frac{1}{2}\,\lambda+\frac{1}{2}\,\sqrt {\kappa}+{ \frac {\nu_{{2}}}{\nu_{{1}}+\nu_{{2}}\varphi }} \right) ^{-1}+\tau_{{0 }} \bigg). \end{split} \end{equation}$

(3.47)

(ⅱ) When $\nu_1 = 0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{2,1,8}(t,x,y) = & e^{i \xi}\bigg( -{\frac {\tau_{{0}}\sqrt {\kappa}}{\frac{1}{2}\,\sqrt {\kappa}+{\varphi }^{-1} }}+\tau_{{0}} \bigg). \end{split} \end{equation}$

(3.48)

(ⅲ) When $\nu_1\neq0$ , $\nu_2 = 0$

$\begin{equation} \begin{split} u_{2,1,9}(t,x,y) = & -\tau_{{0}} e^{i \xi}, \end{split} \end{equation}$

(3.49)

Considering case 2.2 and utilizing Eq (3.1), (3.34) and the corresponding general solution of Eq (2.10), we construct the subsequent plethora of optical soliton solutions for (1.1):

Family 2.2.1. When $\tau > 0$ ,

(ⅰ) When $\nu_1\neq0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{2,2,1}(t,x,y) = & e^{i \xi}\bigg( \frac{ -2\,\tau_{{0}} ( {r}^{2}-\lambda\,r+\mu ) }{( 2\,r- \lambda ) \left( r+\frac{1}{2}\,{\frac {\sqrt {\kappa} \left( \nu_ {{1}}\sinh \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) +\nu_{{2}}\cosh \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) \right) }{\nu_{{1}}\cosh \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) +\nu_{{2}}\sinh \left( \frac{1}{2} \,\sqrt {\kappa}\varphi \right) }}-\frac{1}{2}\,\lambda \right) }+\tau_{{0 }} \bigg). \end{split} \end{equation}$

(3.50)

(ⅱ) When $\nu_1 = 0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{2,2,2}(t,x,y) = & e^{i \xi}\bigg( -2\,{\frac {\tau_{{0}} \left( {r}^{2}-\lambda\,r+\mu \right) }{ \left( 2\,r-\lambda \right) \left( r+\frac{1}{2}\,\sqrt {\kappa}\coth \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) -\frac{1}{2}\,\lambda \right) }}+ \tau_{{0}} \bigg). \end{split} \end{equation}$

(3.51)

(ⅲ) When $\nu_1\neq0$ , $\nu_2 = 0$

$\begin{equation} \begin{split} u_{2,2,3}(t,x,y) = & e^{i \xi}\bigg( -2\,{\frac {\tau_{{0}} \left( {r}^{2}-\lambda\,r+\mu \right) }{ \left( 2\,r-\lambda \right) \left( r+\frac{1}{2}\,\sqrt {\kappa}\tanh \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) -\frac{1}{2}\,\lambda \right) }}+ \tau_{{0}} \bigg). \end{split} \end{equation}$

(3.52)

Family 2.2.2. When $\tau < 0$ ,

(ⅰ) When $\nu_1\neq0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{2,2,4}(t,x,y) = & e^{i \xi}\bigg( \frac{ -2\,\tau_{{0}} ( {r}^{2}-\lambda\,r+\mu ) }{ ( 2\,r- \lambda ) \left( r+\frac{1}{2}\,{\frac {\sqrt {-\kappa} \left( - \nu_{{1}}\sin \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) +\nu_{{2}} \cos \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) \right) }{\nu_{{1}} \cos \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) +\nu_{{2}}\sin \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) }}-\frac{1}{2}\,\lambda \right) }+\tau_{{0}} \bigg). \end{split} \end{equation}$

(3.53)

(ⅱ) When $\nu_1 = 0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{2,2,5}(t,x,y) = & e^{i \xi}\bigg( -2\,{\frac {\tau_{{0}} \left( {r}^{2}-\lambda\,r+\mu \right) }{ \left( 2\,r-\lambda \right) \left( r+\frac{1}{2}\,\sqrt {-\kappa}\cot \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) -\frac{1}{2}\,\lambda \right) }}+ \tau_{{0}} \bigg). \end{split} \end{equation}$

(3.54)

(ⅲ) When $\nu_1\neq0$ , $\nu_2 = 0$

$\begin{equation} \begin{split} u_{2,2,6}(t,x,y) = & e^{i \xi}\bigg( -2\,{\frac {\tau_{{0}} \left( {r}^{2}-\lambda\,r+\mu \right) }{ \left( 2\,r-\lambda \right) \left( r-\frac{1}{2}\,\sqrt {-\kappa}\tan \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) -\frac{1}{2}\,\lambda \right) }}+ \tau_{{0}} \bigg). \end{split} \end{equation}$

(3.55)

Family 2.2.3. When $\tau = 0$ ,

(ⅰ) When $\nu_1\neq0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{2,2,7}(t,x,y) = & e^{i \xi}\bigg( -2\,\tau_{{0}} \left( {r}^{2}-\lambda\,r+\mu \right) \left( 2\,r- \lambda \right) ^{-1} \left( r+{\frac {\nu_{{2}}}{\nu_{{1}}+\nu_{{2}} \varphi }} \right) ^{-1}+\tau_{{0}} \bigg). \end{split} \end{equation}$

(3.56)

(ⅱ) When $\nu_1 = 0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{2,2,8}(t,x,y) = & e^{i \xi}\bigg( -2\,{\frac {\tau_{{0}} \left( {r}^{2}-\lambda\,r+\mu \right) }{ \left( 2\,r-\lambda \right) \left( r+{\varphi }^{-1}-\frac{1}{2}\,\lambda \right) }}+\tau_{{0}} \bigg). \end{split} \end{equation}$

(3.57)

(ⅲ) When $\nu_1\neq0$ , $\nu_2 = 0$

$\begin{equation} \begin{split} u_{2,2,9}(t,x,y) = & e^{i \xi}\bigg( -2\,{\frac {\tau_{{0}} \left( {r}^{2}-\lambda\,r+\mu \right) }{ \left( 2\,r-\lambda \right) \left( r-\frac{1}{2}\,\lambda \right) }}+\tau_{{0 }} \bigg), \end{split} \end{equation}$

(3.58)

Considering case 2.3 and utilizing Eq (3.1), (3.34) and the corresponding general solution of Eq (2.10), we construct the subsequent plethora of optical soliton solutions for (1.1):

Family 2.3.1. When $\tau > 0$ ,

(ⅰ) When $\nu_1\neq0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{2,3,1}(t,x,y) = & e^{i \xi}\bigg( \frac{1}{2}\,\tau_{{1}}\lambda-\tau_{{1}}r+\tau_{{1}} \left( r+\frac{1}{2}\,{\frac { \sqrt {\kappa} \left( \nu_{{1}}\sinh \left( \frac{1}{2}\,\sqrt {\kappa} \varphi \right) +\nu_{{2}}\cosh \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) \right) }{\nu_{{1}}\cosh \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) +\nu_{{2}}\sinh \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) }} -\frac{1}{2}\,\lambda \right) \bigg). \end{split} \end{equation}$

(3.59)

(ⅱ) When $\nu_1 = 0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{2,3,2}(t,x,y) = & e^{i \xi}\bigg( \frac{1}{2}\,\tau_{{1}}\lambda-\tau_{{1}}r+\tau_{{1}} \left( r+\frac{1}{2}\,\sqrt { \kappa}\coth \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) -\frac{1}{2}\,\lambda \right) \bigg). \end{split} \end{equation}$

(3.60)

(ⅲ) When $\nu_1\neq0$ , $\nu_2 = 0$

$\begin{equation} \begin{split} u_{2,3,3}(t,x,y) = & e^{i \xi}\bigg( \frac{1}{2}\,\tau_{{1}}\lambda-\tau_{{1}}r+\tau_{{1}} \left( r+\frac{1}{2}\,\sqrt { \kappa}\tanh \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) -\frac{1}{2}\,\lambda \right) \bigg). \end{split} \end{equation}$

(3.61)

Family 2.3.2. When $\tau < 0$ ,

(ⅰ) When $\nu_1\neq0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{2,3,4}(t,x,y) = & e^{i \xi}\bigg( \frac{1}{2}\,\tau_{{1}}\lambda-\tau_{{1}}r+\tau_{{1}} \left( r+\frac{1}{2}\,{\frac { \sqrt {-\kappa} \left( -\nu_{{1}}\sin \left( \frac{1}{2}\,\sqrt {-\kappa} \varphi \right) +\nu_{{2}}\cos \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) \right) }{\nu_{{1}}\cos \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) +\nu_{{2}}\sin \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) }} -\frac{1}{2}\,\lambda \right) \bigg). \end{split} \end{equation}$

(3.62)

(ⅱ) When $\nu_1 = 0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{2,3,5}(t,x,y) = & e^{i \xi}\bigg( \frac{1}{2}\,\tau_{{1}}\lambda-\tau_{{1}}r+\tau_{{1}} \left( r+\frac{1}{2}\,\sqrt {- \kappa}\cot \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) -\frac{1}{2}\,\lambda \right) \bigg). \end{split} \end{equation}$

(3.63)

(ⅲ) When $\nu_1\neq0$ , $\nu_2 = 0$

$\begin{equation} \begin{split} u_{2,3,6}(t,x,y) = & e^{i \xi}\bigg( \frac{1}{2}\,\tau_{{1}}\lambda-\tau_{{1}}r+\tau_{{1}} \left( r-\frac{1}{2}\,\sqrt {- \kappa}\tan \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) -\frac{1}{2}\,\lambda \right) \bigg). \end{split} \end{equation}$

(3.64)

Family 2.3.3. When $\tau = 0$ ,

(ⅰ) When $\nu_1\neq0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{2,3,7}(t,x,y) = & e^{i \xi}\bigg( \frac{1}{2}\,\tau_{{1}}\lambda-\tau_{{1}}r+\tau_{{1}} \left( r+{\frac {\nu_{{2 }}}{\nu_{{1}}+\nu_{{2}}\varphi }} \right) \bigg). \end{split} \end{equation}$

(3.65)

(ⅱ) When $\nu_1 = 0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{2,3,8}(t,x,y) = & e^{i \xi}\bigg( \frac{1}{2}\,\tau_{{1}}\lambda-\tau_{{1}}r+\tau_{{1}} \left( r+{\varphi }^{-1} -\frac{1}{2}\,\lambda \right) \bigg). \end{split} \end{equation}$

(3.66)

(ⅲ) When $\nu_1\neq0$ , $\nu_2 = 0$

$\begin{equation} \begin{split} u_{2,3,9}(t,x,y) = & e^{i \xi}\bigg( \frac{1}{2}\,\tau_{{1}}\lambda-\tau_{{1}}r+\tau_{{1}} \left( r-\frac{1}{2}\,\lambda \right) \bigg), \end{split} \end{equation}$

(3.67)

Considering case 2.4 and utilizing Eq (3.1), (3.34) and the corresponding general solution of Eq (2.10), we construct the subsequent plethora of optical soliton solutions for (1.1):

Family 2.4.1. When $\tau > 0$ ,

(ⅰ) When $\nu_1\neq0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{2,4,1}(t,x,y) = & e^{i \xi}\bigg( 2\,{\frac { \left( -\mu\,\tau_{{1}}+\frac{1}{4}\,\tau_{{1}}{\lambda}^{2} \right) \left( \nu_{{1}}\cosh \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) +\nu_{{2}}\sinh \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) \right) }{\sqrt {\kappa} \left( \nu_{{1}}\sinh \left( \frac{1}{2}\,\sqrt { \kappa}\varphi \right) +\nu_{{2}}\cosh \left( \frac{1}{2}\,\sqrt {\kappa} \varphi \right) \right) }}\\ &+\frac{1}{2}\,{\frac {\tau_{{1}}\sqrt {\kappa} \left( \nu_{{1}}\sinh \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) +\nu _{{2}}\cosh \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) \right) }{\nu_ {{1}}\cosh \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) +\nu_{{2}}\sinh \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) }} \bigg). \end{split} \end{equation}$

(3.68)

(ⅱ) When $\nu_1 = 0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{2,4,2}(t,x,y) = & e^{i \xi}\bigg( 2\,{\frac {-\mu\,\tau_{{1}}+\frac{1}{4}\,\tau_{{1}}{\lambda}^{2}}{\sqrt { \kappa}\coth \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) }}+\frac{1}{2}\,\tau_{ {1}}\sqrt {\kappa}\coth \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) \bigg). \end{split} \end{equation}$

(3.69)

(ⅲ) When $\nu_1\neq0$ , $\nu_2 = 0$

$\begin{equation} \begin{split} u_{2,4,3}(t,x,y) = & e^{i \xi}\bigg( 2\,{\frac {-\mu\,\tau_{{1}}+\frac{1}{4}\,\tau_{{1}}{\lambda}^{2}}{\sqrt { \kappa}\tanh \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) }}+\frac{1}{2}\,\tau_{ {1}}\sqrt {\kappa}\tanh \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) \bigg). \end{split} \end{equation}$

(3.70)

Family 2.4.2. When $\tau < 0$ ,

(ⅰ) When $\nu_1\neq0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{2,4,4}(t,x,y) = & e^{i \xi}\bigg( 2\,{\frac { \left( -\mu\,\tau_{{1}}+\frac{1}{4}\,\tau_{{1}}{\lambda}^{2} \right) \left( \nu_{{1}}\cos \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) +\nu_{{2}}\sin \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) \right) }{\sqrt {-\kappa} \left( -\nu_{{1}}\sin \left( \frac{1}{2}\,\sqrt {- \kappa}\varphi \right) +\nu_{{2}}\cos \left( \frac{1}{2}\,\sqrt {-\kappa} \varphi \right) \right) }}\\ &+\frac{1}{2}\,{\frac {\tau_{{1}}\sqrt {-\kappa} \left( -\nu_{{1}}\sin \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) + \nu_{{2}}\cos \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) \right) }{ \nu_{{1}}\cos \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) +\nu_{{2}} \sin \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) }} \bigg). \end{split} \end{equation}$

(3.71)

(ⅱ) When $\nu_1 = 0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{2,4,5}(t,x,y) = & e^{i \xi}\bigg( 2\,{\frac {-\mu\,\tau_{{1}}+\frac{1}{4}\,\tau_{{1}}{\lambda}^{2}}{\sqrt {- \kappa}\cot \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) }}+\frac{1}{2}\,\tau_{ {1}}\sqrt {-\kappa}\cot \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) \bigg). \end{split} \end{equation}$

(3.72)

(ⅲ) When $\nu_1\neq0$ , $\nu_2 = 0$

$\begin{equation} \begin{split} u_{2,4,6}(t,x,y) = & e^{i \xi}\bigg( -2\,{\frac {-\mu\,\tau_{{1}}+\frac{1}{4}\,\tau_{{1}}{\lambda}^{2}}{\sqrt {- \kappa}\tan \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) }}-\frac{1}{2}\,\tau_{ {1}}\sqrt {-\kappa}\tan \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) \bigg). \end{split} \end{equation}$

(3.73)

Family 2.4.3. When $\tau = 0$ ,

(ⅰ) When $\nu_1\neq0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{2,4,7}(t,x,y) = & e^{i \xi}\bigg( \left( -\mu\,\tau_{{1}}+\frac{1}{4}\,\tau_{{1}}{\lambda}^{2} \right) \left( \frac{1}{2}\,\lambda+{\frac {\nu_{{2}}}{\nu_{{1}}+\nu_{{2}}\varphi }} \right) ^{-1}+\tau_{{1}} \left( \frac{1}{2}\,\lambda+{\frac {\nu_{{2}}}{\nu_{{1}}+\nu_ {{2}}\varphi }} \right) \bigg). \end{split} \end{equation}$

(3.74)

(ⅱ) When $\nu_1 = 0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{2,4,8}(t,x,y) = & e^{i \xi}\bigg( \left( -\mu\,\tau_{{1}}+\frac{1}{4}\,\tau_{{1}}{\lambda}^{2} \right) \varphi +{\frac {\tau_{{1}}}{\varphi }} \bigg), \end{split} \end{equation}$

(3.75)

Considering case 2.5 and utilizing Eq (3.1), (3.34) and the corresponding general solution of Eq (2.10), we construct the subsequent plethora of optical soliton solutions for (1.1):

Family 2.5.1. When $\tau > 0$ ,

(ⅰ) When $\nu_1\neq0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{2,5,1}(t,x,y) = & e^{i \xi}\bigg( \frac{ \left( -2\,\tau_{{0}} \left( \frac{1}{2}\,\lambda+\frac{1}{2}\,\sqrt {-\kappa} \right) +\lambda\,\tau_{{0}} \right) }{ \left( \frac{1}{2}\,\sqrt {-\kappa}+\frac{1}{2} \,{\frac {\sqrt {\kappa} \left( \nu_{{1}}\sinh \left( \frac{1}{2}\,\sqrt { \kappa}\varphi \right) +\nu_{{2}}\cosh \left( \frac{1}{2}\,\sqrt {\kappa} \varphi \right) \right) }{\nu_{{1}}\cosh \left( \frac{1}{2}\,\sqrt {\kappa} \varphi \right) +\nu_{{2}}\sinh \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) }} \right) }+\tau_{{0}} \bigg). \end{split} \end{equation}$

(3.76)

(ⅱ) When $\nu_1 = 0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{2,5,2}(t,x,y) = & e^{i \xi}\bigg( {\frac {-2\,\tau_{{0}} \left( \frac{1}{2}\,\lambda+\frac{1}{2}\,\sqrt {-\kappa} \right) +\lambda\,\tau_{{0}}}{\frac{1}{2}\,\sqrt {-\kappa}+\frac{1}{2}\,\sqrt {\kappa }\coth \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) }}+\tau_{{0}} \bigg). \end{split} \end{equation}$

(3.77)

(ⅲ) When $\nu_1\neq0$ , $\nu_2 = 0$

$\begin{equation} \begin{split} u_{2,5,3}(t,x,y) = & e^{i \xi}\bigg( {\frac {-2\,\tau_{{0}} \left( \frac{1}{2}\,\lambda+\frac{1}{2}\,\sqrt {-\kappa} \right) +\lambda\,\tau_{{0}}}{\frac{1}{2}\,\sqrt {-\kappa}+\frac{1}{2}\,\sqrt {\kappa }\tanh \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) }}+\tau_{{0}} \bigg). \end{split} \end{equation}$

(3.78)

Family 2.5.2. When $\tau < 0$ ,

(ⅰ) When $\nu_1\neq0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{2,5,4}(t,x,y) = & e^{i \xi}\bigg( \frac{ \left( -2\,\tau_{{0}} \left( \frac{1}{2}\,\lambda+\frac{1}{2}\,\sqrt {-\kappa} \right) +\lambda\,\tau_{{0}} \right) }{ \left( \frac{1}{2}\,\sqrt {-\kappa}+\frac{1}{2} \,{\frac {\sqrt {-\kappa} \left( -\nu_{{1}}\sin \left( \frac{1}{2}\,\sqrt {- \kappa}\varphi \right) +\nu_{{2}}\cos \left( \frac{1}{2}\,\sqrt {-\kappa} \varphi \right) \right) }{\nu_{{1}}\cos \left( \frac{1}{2}\,\sqrt {-\kappa} \varphi \right) +\nu_{{2}}\sin \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) }} \right) }+\tau_{{0}} \bigg). \end{split} \end{equation}$

(3.79)

(ⅱ) When $\nu_1 = 0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{2,5,5}(t,x,y) = & e^{i \xi}\bigg( {\frac {-2\,\tau_{{0}} \left( \frac{1}{2}\,\lambda+\frac{1}{2}\,\sqrt {-\kappa} \right) +\lambda\,\tau_{{0}}}{\frac{1}{2}\,\sqrt {-\kappa}+\frac{1}{2}\,\sqrt {- \kappa}\cot \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) }}+\tau_{{0}} \bigg). \end{split} \end{equation}$

(3.80)

(ⅲ) When $\nu_1\neq0$ , $\nu_2 = 0$

$\begin{equation} \begin{split} u_{2,5,6}(t,x,y) = & e^{i \xi}\bigg( {\frac {-2\,\tau_{{0}} \left( \frac{1}{2}\,\lambda+\frac{1}{2}\,\sqrt {-\kappa} \right) +\lambda\,\tau_{{0}}}{\frac{1}{2}\,\sqrt {-\kappa}-\frac{1}{2}\,\sqrt {- \kappa}\tan \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) }}+\tau_{{0}} \bigg). \end{split} \end{equation}$

(3.81)

Family 2.5.3. When $\tau = 0$ ,

(ⅰ) When $\nu_1\neq0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{2,5,7}(t,x,y) = & e^{i \xi}\bigg( \left( -2\,\tau_{{0}} \left( \frac{1}{2}\,\lambda+\frac{1}{2}\,\sqrt {-\kappa} \right) +\lambda\,\tau_{{0}} \right) \left( \frac{1}{2}\,\lambda+\frac{1}{2}\,\sqrt {-\kappa}+{\frac {\nu_{{2}}}{\nu_{{1}}+\nu_{{2}}\varphi }} \right) ^{- 1}+\tau_{{0}} \bigg). \end{split} \end{equation}$

(3.82)

(ⅱ) When $\nu_1 = 0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{2,5,8}(t,x,y) = & e^{i \xi}\bigg( {\frac {-2\,\tau_{{0}} \left( \frac{1}{2}\,\lambda+\frac{1}{2}\,\sqrt {-\kappa} \right) +\lambda\,\tau_{{0}}}{\frac{1}{2}\,\sqrt {-\kappa}+{\varphi }^{-1}}}+ \tau_{{0}} \bigg). \end{split} \end{equation}$

(3.83)

(ⅲ) When $\nu_1\neq0$ , $\nu_2 = 0$

$\begin{equation} \begin{split} u_{2,5,9}(t,x,y) = & e^{i \xi}\bigg( 2\,{\frac {-2\,\tau_{{0}} \left( \frac{1}{2}\,\lambda+\frac{1}{2}\,\sqrt {-\kappa} \right) +\lambda\,\tau_{{0}}}{\sqrt {-\kappa}}}+\tau_{{0}} \bigg), \end{split} \end{equation}$

(3.84)

Considering case 2.6 and utilizing Eq (3.1), (3.34) and the corresponding general solution of Eq (2.10), we construct the subsequent plethora of optical soliton solutions for (1.1):

Family 2.6.1. When $\tau > 0$ ,

(ⅰ) When $\nu_1\neq0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{2,6,1}(t,x,y) = & e^{i \xi}\bigg( 2\,{\frac { \left( \mu\,\tau_{{1}}-\frac{1}{4}\,\tau_{{1}}{\lambda}^{2} \right) \left( \nu_{{1}}\cosh \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) +\nu_{{2}}\sinh \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) \right) }{\sqrt {\kappa} \left( \nu_{{1}}\sinh \left( \frac{1}{2}\,\sqrt { \kappa}\varphi \right) +\nu_{{2}}\cosh \left( \frac{1}{2}\,\sqrt {\kappa} \varphi \right) \right) }}\\ &+\frac{1}{2}\,{\frac {\tau_{{1}}\sqrt {\kappa} \left( \nu_{{1}}\sinh \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) +\nu _{{2}}\cosh \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) \right) }{\nu_ {{1}}\cosh \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) +\nu_{{2}}\sinh \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) }} \bigg). \end{split} \end{equation}$

(3.85)

(ⅱ) When $\nu_1 = 0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{2,6,2}(t,x,y) = & e^{i \xi}\bigg( 2\,{\frac {\mu\,\tau_{{1}}-\frac{1}{4}\,\tau_{{1}}{\lambda}^{2}}{\sqrt {\kappa }\coth \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) }}+\frac{1}{2}\,\tau_{{1}} \sqrt {\kappa}\coth \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) \bigg). \end{split} \end{equation}$

(3.86)

(ⅲ) When $\nu_1\neq0$ , $\nu_2 = 0$

$\begin{equation} \begin{split} u_{2,6,3}(t,x,y) = & e^{i \xi}\bigg( 2\,{\frac {\mu\,\tau_{{1}}-\frac{1}{4}\,\tau_{{1}}{\lambda}^{2}}{\sqrt {\kappa }\tanh \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) }}+\frac{1}{2}\,\tau_{{1}} \sqrt {\kappa}\tanh \left( \frac{1}{2}\,\sqrt {\kappa}\varphi \right) \bigg). \end{split} \end{equation}$

(3.87)

Family 2.6.2. When $\tau < 0$ ,

(ⅰ) When $\nu_1\neq0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{2,6,4}(t,x,y) = & e^{i \xi}\bigg( 2\,{\frac { \left( \mu\,\tau_{{1}}-\frac{1}{4}\,\tau_{{1}}{\lambda}^{2} \right) \left( \nu_{{1}}\cos \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) +\nu_{{2}}\sin \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) \right) }{\sqrt {-\kappa} \left( -\nu_{{1}}\sin \left( \frac{1}{2}\,\sqrt {- \kappa}\varphi \right) +\nu_{{2}}\cos \left( \frac{1}{2}\,\sqrt {-\kappa} \varphi \right) \right) }}\\ &+\frac{1}{2}\,{\frac {\tau_{{1}}\sqrt {-\kappa} \left( -\nu_{{1}}\sin \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) + \nu_{{2}}\cos \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) \right) }{ \nu_{{1}}\cos \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) +\nu_{{2}} \sin \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) }} \bigg). \end{split} \end{equation}$

(3.88)

(ⅱ) When $\nu_1 = 0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{2,6,5}(t,x,y) = & e^{i \xi}\bigg( 2\,{\frac {\mu\,\tau_{{1}}-\frac{1}{4}\,\tau_{{1}}{\lambda}^{2}}{\sqrt {- \kappa}\cot \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) }}+\frac{1}{2}\,\tau_{ {1}}\sqrt {-\kappa}\cot \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) \bigg). \end{split} \end{equation}$

(3.89)

(ⅲ) When $\nu_1\neq0$ , $\nu_2 = 0$

$\begin{equation} \begin{split} u_{2,6,6}(t,x,y) = & e^{i \xi}\bigg( -2\,{\frac {\mu\,\tau_{{1}}-\frac{1}{4}\,\tau_{{1}}{\lambda}^{2}}{\sqrt {- \kappa}\tan \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) }}-\frac{1}{2}\,\tau_{ {1}}\sqrt {-\kappa}\tan \left( \frac{1}{2}\,\sqrt {-\kappa}\varphi \right) \bigg). \end{split} \end{equation}$

(3.90)

Family 2.6.3. When $\tau = 0$ ,

(ⅰ) When $\nu_1\neq0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{2,6,7}(t,x,y) = & e^{i \xi}\bigg( \left( \mu\,\tau_{{1}}-\frac{1}{4}\,\tau_{{1}}{\lambda}^{2} \right) \left( \frac{1}{2}\lambda+{\frac {\nu_{{2}}}{\nu_{{1}}+\nu_{{2}}\varphi }} \right) ^ {-1}+\tau_{{1}} \left( \frac{1}{2}\,\lambda+{\frac {\nu_{{2}}}{\nu_{{1}}+\nu_{ {2}}\varphi }} \right) \bigg). \end{split} \end{equation}$

(3.91)

(ⅱ) When $\nu_1 = 0$ , $\nu_2\neq0$

$\begin{equation} \begin{split} u_{2,6,8}(t,x,y) = & e^{i \xi}\bigg( \left( \mu\,\tau_{{1}}-\frac{1}{4}\,\tau_{{1}}{\lambda}^{2} \right) \varphi + {\frac {\tau_{{1}}}{\varphi }} \bigg), \end{split} \end{equation}$

(3.92)

4. Discussion and graphs

We present graphic representations of several wave patterns observed in the (2+1)-dimensional gFKMNE under study in this section. In contour and 3D visuals, we found and visualized wave patterns using the extended $(\frac{G'}{G})$ -expansion method and generalized $(r+\frac{G'}{G})$ -expansion method. The depictions show that the created soliton solutions, often referred to as dark soliton lattices, are cyclically structured in optical media. Dark soliton formations are collections of dark solitaires arranged regularly inside a medium. They are frequently shaped like wave channels or optical fibers. Similar to the lattice of a crystal, these solitons are restricted to areas of decreased optical intensity within a larger field that retain their structure and amplitude while moving. Not only can dark soliton lattices be used to precisely control and manipulate optical waves, but also to process information and communications networks, provide insight into nonlinear optics phenomena, provide platforms for basic research on the behavior of wave propagation, and have potential applications in signal processing, optical communication, and sensing. Thus, dark soliton lattices offer a stimulating new topic for nonlinear optics research that will enable both basic and applied investigations.

Figure 1. The 3D and contour visuals of the periodic soliton solution

$u_{1,1,2}$ articulated in (3.9) are graphed for

$\lambda = 4,\mu = 3,n = 2,\alpha = 1,\beta = 1$ ,

$\delta = 1,\tau_{{-1}} = 5,p_{{1}} = 2 ,p_{{2}} = 1$ ,

$q_{{2}} = 5,a = 10,b = 3,\theta_{{0}} = 0,t = 0$ .

DownLoad: Full-Size Img PowerPoint

Figure 2. The 3D and contour visuals of the periodic soliton solution

$u_{1,1,6}$ articulated in (3.13) are graphed for

$\lambda = 1,\mu = 2,n = 2,\alpha = 1$ ,

$\beta = 1,\delta = 0.9,\tau_{{-1}} = 10,p_{{1 }} = 3,p_{{2}} = 4$ ,

$q_{{2}} = 1,a = 2,b = 4,\theta_{{0}} = 1,t = 10$ .

DownLoad: Full-Size Img PowerPoint

Figure 3. The 3D and contour visuals of the periodic soliton solution

$u_{1,1,8}$ articulated in (3.15) are graphed for

$\lambda = 4,\mu = 4,n = 2,\alpha = 0.7,\beta = 0.8,\delta = 0.9$ ,

$\tau_{{-1}} = 5, p_{{1}} = 1,p_{{2}} = 2$ ,

$q_{{2}} = 3,a = 5,b = 1,\theta_{{0}} = 2,t = 20$ .

DownLoad: Full-Size Img PowerPoint

Figure 4. The 3D and contour visuals of the periodic soliton solution

$u_{1,2,3}$ articulated in (3.19) are graphed for

$\lambda = 4,\mu = 1,n = 3,\alpha = 0.3,\beta = 0.5$ ,

$\delta = 0.2,\tau_{{1}} = 6,p _{{1}} = 3,p_{{2}} = 1$ ,

$q_{{2}} = 7,a = 10,b = 10,\theta_{{0}} = 1,t = 50$ .

DownLoad: Full-Size Img PowerPoint

Figure 5. The 3D and contour visuals of the periodic soliton solution

$u_{2,2,3}$ articulated in (3.52) are graphed for

$\lambda = 3,\mu = 1,n = 1,\alpha = 1,\beta = 1$ ,

$\delta = 1,\tau_{{0}} = 6,p_{{1}} = 10 ,p_{{2}} = 5$ ,

$q_{{2}} = 6,a = 2,b = 2,\theta_{{0}} = 0,t = 100,r = 1$ .

DownLoad: Full-Size Img PowerPoint

Figure 6. The 3D and contour visuals of the periodic soliton solution

$u_{2,2,8}$ articulated in (3.57) are graphed for

$\lambda = 6,\mu = 9,n = 2,\alpha = 1,\beta = 1,\delta = 0.5$ ,

$\tau_{{0}} = 1,p_{{1}} = 20,p_{{2}} = 1,q_{{2}} = 8$ ,

$a = 1,b = 4,\theta_{{0}} = 100,t = 30,r = 10$ .

DownLoad: Full-Size Img PowerPoint

Figure 7. The 3D and contour visuals of the periodic soliton solution

$u_{2,4,2}$ articulated in (3.69) are graphed for

$\lambda = 5,\mu = 0,n = 1,\alpha = 1,\beta = 0.9$ ,

$\delta = 0.5,\tau_{{1}} = 1,p_{{ 1}} = 5,p_{{2}} = 3$ ,

$q_{{2}} = 1,a = 2,b = 5,\theta_{{0}} = 0,t = 50$ .

DownLoad: Full-Size Img PowerPoint

Figure 8. The 3D and contour visuals of the periodic soliton solution

$u_{2,4,6}$ articulated in (3.73) are graphed for

$\lambda = 0,\mu = 1,n = 2,\alpha = 1,\beta = 1$ ,

$\delta = 1,\tau_{{1}} = 15,p_{{1}} = 2 ,p_{{2}} = 7$ ,

$q_{{2}} = 3,a = 5,b = 10,\theta_{{0}} = 1,t = 100$ .

DownLoad: Full-Size Img PowerPoint

5. Conclusions

In summary, this study derived optical soliton solutions for the (2+1)-dimensional gFKMNE, a nonlinear model that explains pulse transmission in communication structures and optical fibers. The two improved versions of the $(\frac{G'}{G})$ -expansion method were the extended $(\frac{G'}{G})$ -expansion method and the generalized $(r+\frac{G'}{G})$ -expansion method. These techniques relied on the model's wave translation into integer-order NODEs. By assuming a series-form solution, the strategic techniques further turned the resulting NODEs into a system of nonlinear algebraic equations. Using the Maple program, these equations were solved to produce the gFKMNE's optical soliton solutions. In comparison with the extended $(\frac{G'}{G})$ -expansion method, it was observed that the generalized $(r+\frac{G'}{G})$ -expansion method produced more families of optical soliton solutions. Furthermore, all of the results obtained by the extended $(\frac{G'}{G})$ -expansion method could be obtained from the results of the generalized $(r+\frac{G'}{G})$ -expansion method with $r = 0$ . As a result, the generalized $(r+\frac{G'}{G})$ -expansion method was found to be more effective and superior. Furthermore, using 3D and contour visuals, it was demonstrated that the generated soliton solutions are periodically structured in optical media, which are called dark soliton lattices. Such dark soliton lattices have applications in optical communications, optical signal processing, and nonlinear optics, among other areas. Moreover, the effectiveness and dependability of the methods used in this study show how widely relevant they are to nonlinear issues in a range of scientific fields. The soliton dynamics and their implications for the models studied have been greatly improved by the $(\frac{G'}{G})$ -expansion approaches; however, it is important to recognize that this technique has limitations, especially when the highest derivative is not uniformly balanced with the nonlinear term. Notwithstanding this shortcoming, the paper highlights the amount of unaddressed concerns regarding nonlinear behavior and soliton dynamics and provides fresh avenues for future research in the area.

References

[1]	Ren X, Li J, He F, et al. (2023) Impact of climate policy uncertainty on traditional energy and green markets: Evidence from time-varying granger tests. Renew Sust Energ Rev 173: 113058. https://doi.org/10.1016/j.rser.2022.113058 doi: 10.1016/j.rser.2022.113058
[2]	Abdel-Fattah A, Hamdan S, Ayadi O, et al. (2022) Energy efficiency and thermal insulation code violations for residential buildings in Jordan and the role of social advocacy campaigns. Energ Sustain Dev 71: 419–432. https://doi.org/10.1016/j.esd.2022.10.013 doi: 10.1016/j.esd.2022.10.013
[3]	Qadourah J A (2022) Energy and economic potential for photovoltaic systems installed on the rooftop of apartment buildings in Jordan. Results Eng 16: 100642. https://doi.org/10.1016/j.rineng.2022.100642 doi: 10.1016/j.rineng.2022.100642
[4]	Abu Qadourah J, AL-Falahat A M, Alrwashdeh S S (2022) Alrwashdeh, Assessment of solar photovoltaics potential installation into multi-family building's envelope in Amman, Jordan. Cogent Eng 9 https://doi.org/10.1080/23311916.2022.2082059 doi: 10.1080/23311916.2022.2082059
[5]	Alrwashdeh S S (2019) Investigation of Wind Energy Production at Different Sites in Jordan Using the Site Effectiveness Method. Energ Eng J Assoc Energ Eng 116: 47–59. https://doi.org/10.1080/01998595.2019.12043338 doi: 10.1080/01998595.2019.12043338
[6]	Alrwashdeh S S, Alsaraireh F M (2018) Wind energy production assessment at different sites in Jordan using probability distribution functions. ARPN J Eng Appl Sci 13: 8163–8172.
[7]	Juaidi A, Abdallah R, Ayadi O, et al. (2022) Chapter 7 - Wind energy in Jordan and Palestine: current status and future perspectives, in Renewable Energy Production and Distribution, M. Jeguirim, Editor. Academic Press. 229–269. https://doi.org/10.1016/B978-0-323-91892-3.00006-6
[8]	Abu-Rumman G, Khdair A I, Khdair S I (2020) Current status and future investment potential in renewable energy in Jordan: An overview. Heliyon 6: e03346. https://doi.org/10.1016/j.heliyon.2020.e03346 doi: 10.1016/j.heliyon.2020.e03346
[9]	Al Afif R, Ayed Y, Maaitah O N (2023) Feasibility and optimal sizing analysis of hybrid renewable energy systems: A case study of Al-Karak, Jordan. Renew Energy https://doi.org/10.1016/j.renene.2022.12.109 doi: 10.1016/j.renene.2022.12.109
[10]	Alawin A A, Rahmeh T A, Jaber J O, et al. (2016) Renewable energy education in engineering schools in Jordan: Existing courses and level of awareness of senior students. Renew Sust Energ Rev 65: 308–318. https://doi.org/10.1016/j.rser.2016.07.003 doi: 10.1016/j.rser.2016.07.003
[11]	Alawneh R, Ghazali F, Ali H, et al. (2019) A Novel framework for integrating United Nations Sustainable Development Goals into sustainable non-residential building assessment and management in Jordan. Sustain Cities Soc 49: 101612. https://doi.org/10.1016/j.scs.2019.101612 doi: 10.1016/j.scs.2019.101612
[12]	Albatayneh A, Hindiyeh M, AlAmawi R (2022) Potential of renewable energy in water-energy-food nexus in Jordan. Energ Nexus 7: 100140. https://doi.org/10.1016/j.nexus.2022.100140 doi: 10.1016/j.nexus.2022.100140
[13]	Qadourah J A, Alrwashdeh S (2022) ECONOMIC FEASIBILITY OF HEATING SOURCE CONVERSION OF THE SWIMMING POOLS. J Appl Eng Sci 20: 230–238. https://doi.org/10.5937/jaes0-34474 doi: 10.5937/jaes0-34474
[14]	Al-Falahat A M, Kardjilov N, Khanh T V, et al. (2019) Energy-selective neutron imaging by exploiting wavelength gradients of double crystal monochromators—Simulations and experiments. Nuclear Instruments and Methods in Physics Research, Section A: Accelerators, Spectrometers, Detectors and Associated Equipment 943. https://doi.org/10.1016/j.nima.2019.162477
[15]	Ala'a M, Qadourah J A, Alrwashdeh S S, et al. (2022) Energy performance and economics assessments of a photovoltaic-heat pump system. Results Eng 13. https://doi.org/10.1016/j.rineng.2021.100324 doi: 10.1016/j.rineng.2021.100324
[16]	Ali H, Hashlamun R (2019) Envelope retrofitting strategies for public school buildings in Jordan. J Buiild Eng 25: 100819. https://doi.org/10.1016/j.jobe.2019.100819 doi: 10.1016/j.jobe.2019.100819
[17]	Alkhalidi A, Alqarra K, Abdelkareem M A, et al. (2022) Renewable energy curtailment practices in Jordan and proposed solutions. Int J Thermofluids 16: 100196. https://doi.org/10.1016/j.ijft.2022.100196 doi: 10.1016/j.ijft.2022.100196
[18]	Almomani E, Hammad E A, AlQutob R, et al. (2022) Capacity Building for Health Technology Assessment in Jordan: Institutionalization and Its Use in Pricing and Reimbursement Decisions. Value Health Reg Iss 32: 47–53. https://doi.org/10.1016/j.vhri.2022.07.006 doi: 10.1016/j.vhri.2022.07.006
[19]	Alrwashdeh S S (2017) Determining the optimum tilt solar angle of a PV applications at different sites in Jordan. J Eng Appl Sci 12: 9295–9303.
[20]	Alrwashdeh S S (2018)Predicting of energy production of solar tower based on the study of the cosine efficiency and the field layout of heliostats. Int J Mech Eng Technol 9: 250–257.
[21]	Alrwashdeh S S (2018) Investigation of the energy output from PV racks based on using different tracking systems in Amman-Jordan. Int J Mech Eng Technol 9: 687–694.
[22]	Alrwashdeh S S (2018) Comparison among solar panel arrays production with a different operating temperatures in Amman-Jordan. Int J Mech Eng Technol 9: 420–429.
[23]	Bartmiński P, Siłuch M (2022) Mapping the albedo of the active surface at different stages of the growing season using data from various sources. Remote Sens Appl Soc Environ 28: 100818. https://doi.org/10.1016/j.rsase.2022.100818 doi: 10.1016/j.rsase.2022.100818
[24]	Cierniewski J, Ceglarek J (2023) Influence of arable land location incorporating its roughness on blue-sky albedo variation. J Quantit Spectrosc Radiat Transf 296: 108440. https://doi.org/10.1016/j.jqsrt.2022.108440 doi: 10.1016/j.jqsrt.2022.108440
[25]	Du J, Zhou H, Jacinthe P A, et al. (2023) Retrieval of lake water surface albedo from Sentinel-2 remote sensing imagery. J Hydrol 617: 128904. https://doi.org/10.1016/j.jhydrol.2022.128904 doi: 10.1016/j.jhydrol.2022.128904
[26]	Lin X, Wu S, Chen B, et al. (2022) Estimating 10-m land surface albedo from Sentinel-2 satellite observations using a direct estimation approach with Google Earth Engine. ISPRS J Photogramm Remote Sens 194: 1–20. https://doi.org/10.1016/j.isprsjprs.2022.09.016 doi: 10.1016/j.isprsjprs.2022.09.016
[27]	Xiao Y, Ke C Q, Shen X, et al. (2023) What drives the decrease of glacier surface albedo in High Mountain Asia in the past two decades? Sci Total Environ 863: 160945. https://doi.org/10.1016/j.scitotenv.2022.160945 doi: 10.1016/j.scitotenv.2022.160945
[28]	Alrwashdeh S S (2018) Energy production evaluation from a linear fresnel reflectors arrays with different array orientation. Inter J Engin Res Technol 11: 1811–1819.
[29]	Alrwashdeh S S (2018) Assessment of the energy production from PV racks based on using different solar canopy form factors in Amman-Jordan. Inter J Engin Res Technol 11: 1595–1603.
[30]	Alrwashdeh S.S (2018) The effect of solar tower height on its energy output at Ma'an-Jordan. AIMS Energ. 6: 959–966. https://doi.org/10.3934/energy.2018.6.959 doi: 10.3934/energy.2018.6.959
[31]	Alrwashdeh S S (2018) Assessment of photovoltaic energy production at different locations in Jordan. Int J Renew Energ Res 8: 797–804.
[32]	Alrwashdeh S S (2019) An energy production evaluation from PV arrays with different inter-row distances. Int J Mech Prod Eng Res Develop 9: 1–10.
[33]	Alrwashdeh S S (2019) Energy production assessment of solar tower based on the study of the mirror shadowing and blocking effects. Univers J Mech Eng 7: 71–76. ttps://doi.org/10.13189/ujme.2019.070205 doi: 10.13189/ujme.2019.070205
[34]	Jin Y, Liu K, Xiong L, et al. (2022) A non-traditional variant nonlinear energy sink for vibration suppression and energy harvesting. Mech Syst Signal Process 181: 109479. https://doi.org/10.1016/j.ymssp.2022.109479 doi: 10.1016/j.ymssp.2022.109479
[35]	Kiwan S, Al-Gharibeh E (2020) Jordan toward a 100% renewable electricity system. Ren Energ 147: 423–436. https://doi.org/10.1016/j.renene.2019.09.004 doi: 10.1016/j.renene.2019.09.004
[36]	Ma'bdeh S N, Ali H H, Rabab'ah I O (2022) Sustainable assessment of using green roofs in hot-arid areas – Residential buildings in Jordan. J Buiild Eng 45: 103559. https://doi.org/10.1016/j.jobe.2021.103559 doi: 10.1016/j.jobe.2021.103559
[37]	Alrwashdeh S S (2021) Investigation of the energy output from PV panels based on using different orientation systems in Amman-Jordan. Case Stud Therm Eng 28. https://doi.org/10.1016/j.csite.2021.101580 doi: 10.1016/j.csite.2021.101580
[38]	Alrwashdeh S S (2021) Investigation of the energy output from PV panels based on using different orientation systems in Amman-Jordancorlowast. Case Stud Therm Eng 28: 101580. https://doi.org/10.1016/j.csite.2021.101580 doi: 10.1016/j.csite.2021.101580
[39]	Alrwashdeh S S (2022) INVESTIGATION OF THE ENERGY OUTPUT OF PARABOLIC TROUGH RACKS BASED ON USING DIFFERENT RHOMBOID LAYOUT. ARPN J J Eng Appl Sci 17: 578–586.
[40]	Alrwashdeh S S, Ammari H (2019) Life cycle cost analysis of two different refrigeration systems powered by solar energy. Case Stud Therm Eng 16. https://doi.org/10.1016/j.csite.2019.100559 doi: 10.1016/j.csite.2019.100559
[41]	Alrwashdeh S S, Ammari H, Jweihan Y S, et al. (2022) Refurbishment of Existing Building toward a Surplus Energy Building in Jordan. Open Const Build Technol J 16 https://doi.org/10.2174/18748368-v16-e2208150 doi: 10.2174/18748368-v16-e2208150
[42]	Alrwashdeh S S, Qadourah J A, Al-Falahat A M (2022) Investigation of the Effect of Roof Color on the Energy Use of a Selected House in Amman, Jordan. Front Mech Eng 8. https://doi.org/10.3389/fmech.2022.897170 doi: 10.3389/fmech.2022.897170
[43]	Alsarayreh A A, Al-Obaidi M A, Alrwashdeh S S, et al. (2022) Enhancement of energy saving of reverse osmosis system via incorporating a photovoltaic system, in Computer Aided Chemical Engineering. 697–702. https://doi.org/10.1016/B978-0-323-95879-0.50117-X
[44]	Altarawneh O R, Alsarayreh A A, Ala'a M, et al (2022) Energy and exergy analyses for a combined cycle power plant in Jordan. Case Stud Therm Eng 31. https://doi.org/10.1016/j.csite.2022.101852 doi: 10.1016/j.csite.2022.101852
[45]	Pastor R, Tobarra L, Robles-Gómez A, et al. (2020) Renewable energy remote online laboratories in Jordan universities: Tools for training students in Jordan. Renew Energ 149: 749–759. https://doi.org/10.1016/j.renene.2019.12.100 doi: 10.1016/j.renene.2019.12.100
[46]	Chenoweth J, Al-Masri R A (2021) The impact of adopting a water-energy nexus approach in Jordan on transboundary management. Environ Sci Policy 118: 49–55. https://doi.org/10.1016/j.envsci.2021.01.006 doi: 10.1016/j.envsci.2021.01.006
[47]	Murtadha T K, dil Hussein A A, Alalwany A A H, et al. (2022)Improving the cooling performance of photovoltaic panels by using two passes circulation of titanium dioxide nanofluid. Case Stud Therm Eng. 36. https://doi.org/10.1016/j.csite.2022.102191 doi: 10.1016/j.csite.2022.102191
[48]	Schuetze B, Hussein H (2023) The geopolitical economy of an undermined energy transition: The case of Jordan. Energ Policy 180: 113655. https://doi.org/10.1016/j.enpol.2023.113655 doi: 10.1016/j.enpol.2023.113655
[49]	Alrwashdeh S S (2022) Energy sources assessment in Jordan. Results Eng 13. https://doi.org/10.1016/j.rineng.2021.100329 doi: 10.1016/j.rineng.2021.100329

Reader Comments

Your name:*

Email:*
© 2023 the Author(s), licensee AIMS Press. This is an open access article distributed under the terms of the Creative Commons Attribution License (http://creativecommons.org/licenses/by/4.0)
