One of the major parameters influencing Photovoltaic (PV) panel's efficiency is temperature. The main problem identified in this study is that high surface temperatures cause PV panels to operate less efficiently and shortens their lifetime. Consequently, a cooling system is needed that diminishes panel temperature and enriches its efficiency. The main objective of the proposed research is to investigate the efficacy of an active cooling system that uses a copper-tube thermal collector integrated with a radiator-style heat exchanger to improve the performance of the PV panel. The city of Kalaburagi in the Indian state of Karnataka was chosen for the experimental testing because of its hot temperature. Our findings showed that the proposed active rear surface cooling system successfully reduced surface temperature by 16 ℃ on average. Cooled and uncooled PV panels had 23.35% and 21.75% average electrical efficiency, respectively. Cooling increased efficiency by 1.6%. The PV system's average thermal efficiency with cooling was 59.6%, and the combined total efficiency reached 82.95%. Thus, our findings presented in this research demonstrate how effective the suggested active back surface cooling was in relation to Kalaburagi city's climate. The research also showed that a closed-loop water circulation system improves PV module performance.
Citation: Md Moyeed Abrar, Sangamesh G. Sakri. Performance evaluation of a PV panel incorporating active cooling technique for efficiency enhancement in hot climatic conditions of Kalaburagi city[J]. AIMS Energy, 2025, 13(6): 1560-1582. doi: 10.3934/energy.2025058
One of the major parameters influencing Photovoltaic (PV) panel's efficiency is temperature. The main problem identified in this study is that high surface temperatures cause PV panels to operate less efficiently and shortens their lifetime. Consequently, a cooling system is needed that diminishes panel temperature and enriches its efficiency. The main objective of the proposed research is to investigate the efficacy of an active cooling system that uses a copper-tube thermal collector integrated with a radiator-style heat exchanger to improve the performance of the PV panel. The city of Kalaburagi in the Indian state of Karnataka was chosen for the experimental testing because of its hot temperature. Our findings showed that the proposed active rear surface cooling system successfully reduced surface temperature by 16 ℃ on average. Cooled and uncooled PV panels had 23.35% and 21.75% average electrical efficiency, respectively. Cooling increased efficiency by 1.6%. The PV system's average thermal efficiency with cooling was 59.6%, and the combined total efficiency reached 82.95%. Thus, our findings presented in this research demonstrate how effective the suggested active back surface cooling was in relation to Kalaburagi city's climate. The research also showed that a closed-loop water circulation system improves PV module performance.
| [1] |
Pourasl HH, Reza VR, Barenji B, et al. (2023) Solar energy status in the world: A comprehensive review. Energy Rep 10: 3474–3493. https://doi.org/10.1016/j.egyr.2023.10.022 doi: 10.1016/j.egyr.2023.10.022
|
| [2] |
Maka AOM, Alabid JM (2022) Solar energy technology and its roles in sustainable development. Clean Energy 6: 476–483. https://doi.org/10.1093/ce/zkac023 doi: 10.1093/ce/zkac023
|
| [3] |
Sarang SA, Raza MA, Panhwar M, et al. (2024) Maximizing solar power generation through conventional and digital MPPT techniques: a comparative analysis. Sci Rep 14: 1–18. https://doi.org/10.1038/s41598-024-59776-z doi: 10.1038/s41598-024-59776-z
|
| [4] |
Lazaroiu AC, Osman MG, Strejoiu CV, et al. (2023) A Comprehensive overview of photovoltaic technologies and their efficiency for climate neutrality. Sustainability 15: 16297. https://doi.org/10.3390/su152316297 doi: 10.3390/su152316297
|
| [5] |
Farahmand MZ, Nazari ME, Shamlou S, et al. (2021) The Simultaneous impacts of seasonal weather and solar conditions on PV panels electrical characteristics. Energies 14: 845. https://doi. org/https://doi.org/10.3390/e14040845 doi: 10.3390/e14040845
|
| [6] |
Shaker LM, Al-Amiery AA, Hanoon MM, et al. (2024) Examining the influence of thermal effects on solar cells: a comprehensive review. Sustain Energy Res 11: 100–108. https://doi.org/10.1186/s40807-024-00100-8. doi: 10.1186/s40807-024-00100-8
|
| [7] |
Libra M, Mr´azek D, Tyukhov I, et al. (2023) Reduced real lifetime of PV panels—E conomic consequences. Sol Energy 259: 229–234. https://doi.org/10.1016/j.solener.2023.04.063 doi: 10.1016/j.solener.2023.04.063
|
| [8] |
Kabré A, Bonkoungou D, Koalaga Z (2024) Analysis of the effect of temperature and relative humidity on the reliability of a photovoltaic module. Adv Mater Phys Chem 14: 165–177. https://doi.org/10.4236/ampc.2024.148013 doi: 10.4236/ampc.2024.148013
|
| [9] |
Sajjad U, Amer M, Ali HM, et al. (2019) Cost effective cooling of photovoltaic modules to improve efficiency. Case Stud Therm Eng 14: 100420. https://doi.org/10.1016/j.csite.2019.100420 doi: 10.1016/j.csite.2019.100420
|
| [10] |
Rasool IN, Abdullah RS (2023) Experimental study of PV panel performance using backside water cooling chamber. Int J Energy Prod Manag 8: 89–95. https://doi.org/10.18280/ijepm.080205 doi: 10.18280/ijepm.080205
|
| [11] |
Murtadha TK, Hussein AA (2022) Optimization the performance of photovoltaic panels using aluminum-oxide nanofluid as cooling fluid at different concentrations and one-pass flow system. Results Eng 15: 100541. https://doi.org/10.1016/j.rineng.2022.100541 doi: 10.1016/j.rineng.2022.100541
|
| [12] |
Sornek K, Goryl W (2022) Development and tests of the water cooling system dedicated. Energies 15: 65884. https://doi.org/10.3390/en15165884 doi: 10.3390/en15165884
|
| [13] | Nasir U, Rehman SU, Waqas A, et al. (2020) Improving photovoltaic module efficiency using back side water-cooling technique. 020 IEEE 23rd International Multitopic Conference (INMIC), Pakistan, 1–6. https://doi.org/10.1109/INMIC50486.2020.9318093 |
| [14] |
Ismael OR, Selimli S (2025) Energy and exergy analysis of PV modules: sustainable improvements through fin structure and spray cooling. Sol Energy Mater Sol Cells 283: 113458. https://doi.org/10.1016/j.solmat.2025 doi: 10.1016/j.solmat.2025
|
| [15] |
Ali AA, Tubena HL, Oudah ZA, et al. (2025) Enhancing photovoltaic performance and efficiency by innovative cooling system of sawdust: experimental investigation. Environ Prog Sustain Energy, e14640. https://doi.org/10.1002/ep.14640 doi: 10.1002/ep.14640
|
| [16] |
Jasim OM, Selimli S, Dumrul H, et al. (2022) Closed-loop aluminium oxide nanofluid cooled photovoltaic thermal collector energy and exergy analysis, an experimental study. J Energy Storage 50: 104654. https://doi.org/10.1016/j.est.2022.104654 doi: 10.1016/j.est.2022.104654
|
| [17] |
Khelifa A, Touafek K, Moussa HB (2015) Approach for the modelling of hybrid photovoltaic-thermal solar collector. IET Renew Power Gener 9: 207–217. https://doi.org/10.1049/iet-rpg.2014.0076 doi: 10.1049/iet-rpg.2014.0076
|
| [18] | Bahaidarah HMS, Baloch AAB, Gandhidasan P (2014) Modeling and comparative analysis of jet impingement cooling and conventional channel cooling for photovoltaic strings. 2014 IEEE 40th Photovoltaic Specialist Conference (PVSC), USA, 748–753. https://doi.org/10.1109/PVSC.2014.6925028. |
| [19] |
Rajasekaran B, Kumaresan G, Arulprakasajothi M, et al. (2024) Improving the performance of heat sinks through the integration of fins and the utilization of graphene-mixed latent heat energy storage. Therm Sci Eng Prog 50: 102525. https://doi.org/10.1016/j.tsep.2024.102525 doi: 10.1016/j.tsep.2024.102525
|
| [20] | Colţ G (2016) Performance evaluation of a PV panel by rear surface water active cooling. 2016 International Conference on Applied and Theoretical Electricity (ICATE), Romania, 1–5. https://doi.org/10.1109/ICATE.2016.7754634 |
| [21] |
Shalaby SM, Elfakharany MK, Moharram BM, et al. (2021) Experimental study on the performance of PV with water cooling. Energy Rep 7: 957–961. https://doi.org/10.1016/j.egyr.2021.11.155 doi: 10.1016/j.egyr.2021.11.155
|
| [22] |
Chin CS, Gao Z, Han M, et al. (2020) Enhancing performance of photovoltaic panel by cold plate design with guided channels. IET Renew Power Gener 14: 1606–1617. https://doi.org/10.1049/iet-rpg.2019.1042 doi: 10.1049/iet-rpg.2019.1042
|
| [23] |
Bahaidarah H, Subhan A, Gandhidasan P, et al. (2013) Performance evaluation of a PV (photovoltaic) module by back surface water cooling for hot climatic conditions. Energy 59: 445–453. https://doi.org/10.1016/j.energy.2013.07.050 doi: 10.1016/j.energy.2013.07.050
|
| [24] |
Attia H, Hossin K, Al Hazza M (2023) Experimental investigation of photovoltaic systems for performance improvement using water cooling. Clean Energy 7: 721–733. https://doi.org/10.1093/ce/zkad034 doi: 10.1093/ce/zkad034
|
| [25] |
Sohani A, Shahverdian MH, Sayyaadi H (2021) Energy and exergy analyses on seasonal comparative evaluation of water flow cooling for improving the performance of monocrystalline PV module in hot-arid climate. Sustainability 13: 6084. https://doi.org/10.3390/su13116084 doi: 10.3390/su13116084
|
| [26] |
Schiro F, Benato A, Stoppato A (2017) Improving photovoltaics efficiency by water cooling: modelling and experimental approach. Energy 137: 798–810. https://doi.org/10.1016/j.energy.2017.04.164 doi: 10.1016/j.energy.2017.04.164
|
| [27] |
Harmailil IO, Sultan SM, Tso CP, Fudholi A, et al. (2024) The state of the art of photovoltaic module cooling techniques and performance assessment methods. Symmetry 16: 412. https://doi.org/10.3390/sym16040412 doi: 10.3390/sym16040412
|
| [28] |
Sharaf M, Yousef MS, Huzayyin AS (2022) Review of cooling techniques used to enhance the efficiency of photovoltaic power systems. Environ Sci Pollut Res 29: 26131–26159. https://doi.org/10.1007/s11356-022-18719-9 doi: 10.1007/s11356-022-18719-9
|
| [29] |
Akrouch MA, Chahine K, Faraj J, et al. (2023) Advancements in cooling techniques for enhanced efficiency of solar photovoltaic panels: A detailed comprehensive review and innovative classification. Energy Built Environ 6: 248–276. https://doi.org/10.1016/j.enbenv.2023.11.002 doi: 10.1016/j.enbenv.2023.11.002
|
| [30] |
Dwivedi P, Sudhakar K, Soni A, et al. (2020) Advanced cooling techniques of P. V. modules: a state of art. Case Stud Therm Eng 21: 100674. https://doi.org/10.1016/j.csite.2020.100674 doi: 10.1016/j.csite.2020.100674
|
| [31] |
Hosseinzadeh M, Sardarabadi M, Passandideh-Fard M (2018) Energy and exergy analysis of nanofluid based photovoltaic thermal system integrated with phase change material. Energy 147: 636–647. https://doi.org/10.1016/j.energy.2018.01.073 doi: 10.1016/j.energy.2018.01.073
|
| [32] |
Alktranee M, Péter B (2023) Energy and exergy analysis for photovoltaic modules cooled by evaporative cooling techniques. Energy Rep 9: 122–132. https://doi.org/10.1016/j.egyr.2022.11.177 doi: 10.1016/j.egyr.2022.11.177
|
| [33] |
Park SR, Pandey AK, Tyagi VV, et al. (2014) Energy and exergy analysis of typical renewable energy systems. Renew Sustain Energy Rev 30: 105–123. https://doi.org/10.1016/j.rser.2013.09.011 doi: 10.1016/j.rser.2013.09.011
|
| [34] |
Saldana M, Gallegos S, Gálvez E, et al. (2024) The Reynolds number: a journey from its origin to modern applications. Fluids 9: 299. https://doi.org/10.3390/fluids9120299 doi: 10.3390/fluids9120299
|
| [35] |
Gurka R, Nafi AS, Weihs D (2022) On an adaptation of the Reynolds number, applicable to body-caudal-fin aquatic locomotion. Front Mar Sci 9: 914214. https://doi.org/10.3389/fmars.2022.914214 doi: 10.3389/fmars.2022.914214
|
| [36] |
Dawood TA, Barwari RRI, Akroot A (2023) Solar energy and factors affecting the efficiency and performance of panels in Erbil/Kurdistan. Int J Heat Technol 41: 304–312. https://doi.org/10.18280/ijht.410203 doi: 10.18280/ijht.410203
|
Figures(11) / Tables(4)
Md Moyeed Abrar, Sangamesh G. Sakri. Performance evaluation of a PV panel incorporating active cooling technique for efficiency enhancement in hot climatic conditions of Kalaburagi city[J]. AIMS Energy, 2025, 13(6): 1560-1582. doi: 10.3934/energy.2025058
