Abstract

1. Introduction

Nonlinear evolution equations (NLEEs) play an important part in the study of nonlinear science, particular in plasma physics, quantum field theory, nonlinear wave propagation and nonlinear optical fibers so that it attracted the attention of a large number of scholars. The extended auxiliary equation technique ^[1], the Bernoulli's equation approach ^[2], the Exp-function technique ^[3], the homotopy analysis technique ^[4], the homotopy perturbation technique ^[5], the improved $tan(\phi/2)$ -expansion technique (^[6,7]), the Hirota's bilinear technique ^{[8,9,10,11,12,13,14,15]}, the He's variational principle ^[16,17], the binary Darboux transformation ^[18], the Lie group analysis ^[19,20], the Bäcklund transformation method ^[21], optimal galerkin-homotopy asymptotic method applied ^[22], and the multiple rogue waves method (^[23,24]) have been proposed to solve NLEEs. By using these approaches, various exact solutions including soliton solution, lump solution, rogue wave solution, periodic solution, interaction solution, rational solution and high-order rational solution were obtained (^[25,26]).

In this paper, we mainly consider the following dynamical model, which can be used to describe some interesting (3+1)-dimensional waves of physics, namely, the generalized Kadomtsev-Petviashvili (gKP) equation ^[27]. That is

$\begin{equation} (\Psi_{t}+6\Psi\Psi_x+\Psi_{xxx})_x +a\Phi_{yy} = 0, \end{equation}$

(1.1)

and also above equation is integrable. Author of ^[28] introduced the modification of KP (mKP) equation ^[29] given

$\begin{equation} 4\Psi_{t}-6\Psi^2\Psi_x+\Psi_{xxx}+6\Psi_x\partial_{x}^{-1}\Psi_y +\Psi_{x}^{-1}\Phi_{yy} = 0. \end{equation}$

(1.2)

The generalized KP (gKP) equation has been researched by some scholars ^[30,31,32] in which is given as

$\begin{equation} (\Psi_{t}+\alpha\Psi_x +\beta\Psi\Psi_x+\gamma\Psi\Psi_{xxt})_x+\Psi_{yy} = 0. \end{equation}$

(1.3)

The another type of gKP equation is given in ^[33] as below

$\begin{equation} \Psi_{xxxy}+3(\Psi_x\Psi_y)_x+\Psi_{tx}+\Psi_{ty}+\Psi_{tz}-\Psi_{zz} = 0. \end{equation}$

(1.4)

We first present the bilinear form for Eq (1.4), by taking the following first-order logarithmic transformation

$\begin{equation} \Psi = 2(\ln f)_{x}, \end{equation}$

(1.5)

then, Eq (1.4) is turned into the bilinear form

$\begin{equation} \left(D_x^3 D_y+D_xD_t+D_yD_t+D_zD_t-D_z^2\right)\mathfrak{f}. \mathfrak{f} = 0, \end{equation}$

(1.6)

in which $D_t, D_x, D_y$ and $D_z$ are Hirota's bilinear frames. Cao ^[34] investigated the generalized B-type KP equation as follows

$\begin{equation} \Psi_{xxxy}+3(\Psi_x\Psi_y)_x-3\Psi_{xz}-\Psi_{ty} = 0. \end{equation}$

(1.7)

Guan et al. ^[35] derived a (3+1)-dimensional gKP equation in below form

$\begin{equation} \Psi_{xxxy}+3(\Psi_x \Psi_{y})_x+\alpha\Psi_{xxxz}+3\alpha(\Psi_x \Psi_{z})_x+\lambda_1\Psi_{xt}+\lambda_2\Phi_{yt}+\lambda_3\Phi_{zt}+ \omega_1\Phi_{xz} +\omega_2\Phi_{yz}+\omega_3\Phi_{zz} = 0, \end{equation}$

(1.8)

and some lump soliton solutions have been constructed using the Hirota bilinear method in ^[36]. Via transformation $\Psi = 2(\ln f)_{x},$ the bilinear form of equation (1.8) reads:

$\begin{equation} \left(D_x^3 D_y+\alpha D_x^3 D_z+\lambda_1D_xD_t+\lambda_2D_yD_t+\lambda_3D_zD_t+\omega_1D_xD_z+ \omega_2D_yD_z+\omega_3D_z^2\right)\mathfrak{f}. \mathfrak{f} = 0. \end{equation}$

(1.9)

Most classical test functions for solving NLPDEs by using the several particular functions can be constructed via Hirota bilinear technique. In other words, Hirota operator covers most of the classical hypothesis function method. For example, the fractional generalized CBS-BK equation ^[37], the generalized Bogoyavlensky-Konopelchenko equation ^[38], the (2+1)-dimensional asymmetrical Nizhnik-Novikov-Veselov equation ^[39], and the (2+1)-dimensional generalized variable-coefficient KP-Burgers-type equation ^[40]. Diverse kinds of studies on solve NLPDEs were perused via mighty authors in which some of them can be stated, for instance, multivariate rogue wave to some PDEs ^[41], interaction lump solutions the gKP equation ^[42], the (1+1)-dimensional coupled integrable dispersionless equations ^[43]. Therefore, we embark on the new research topic of constructing the analytic solutions of nonlinear PDEs by exploring the bilinear method. According to recent studies, we can obtain some of the new exact analytic solutions of nonlinear PDEs by way of constructing their corresponding bilinear differential equations in ^{[44,45,46,47]}. Here, we will study the multiple Exp-function method (MEFM) for determining the multiple soliton solutions (MSSs). The MEFM employed by some of powerful authors for various nonlinear equations have been surveyed in more studies in ^{[31,48,49,50]}. Authors of ^[51] utilized the reduced differential transform method for solving partial differential equations. Also, Yu and Sun ^[52] studied the dimensionally reduced generalized KP equations by help of Hirita bilinear method and obtained of lump solutions.

The outline of our paper is as follows: the multiple Exp-function scheme has been summarized in section 2. In sections 3, the KP equation, will investigate to finding 1-wave, 2-wave, and three-wave solutions. The Sections 4-6 devote to determined the periodic, cross-kink, and solitary wave solutions. Moreover, in Section 7, the modulation instability analysis is investigated. Finally in Section 8, the SIVP technique is considered with four cases for finding the solitary, bright, dark and singular wave solutions. A few of conclusions and outlook will be given in the final section.

2. Multiple Exp-function method

This method was summarized and improved for achieving the analytic solutions of NLPDEs:

Step 1. Assume a nonlinear PDE is given in general frame as follows

$\begin{equation} \mathcal{N}(x, y, t, \Psi , \Psi _{x}, \Psi _{y}, \Psi _{z}, \Psi _{t}, \Psi _{xx}, \Psi _{tt}, ...) = 0. \end{equation}$

(2.1)

Take the novel variables $\xi _{i} = \xi _{i}(x, y, z, t), 1\leq i\leq n$ , by differentiable frames:

$\begin{equation} \xi _{i, x} = \alpha _{i}\xi _{i}, \ \ \xi _{i, y} = \beta _{i}\xi _{i}, \ \ \xi _{i, z} = \gamma _{i}\xi _{i}, \ \ \xi _{i, t} = -\delta _{i}\xi _{i}, \ \ 1\leq i\leq n, \end{equation}$

(2.2)

where $\alpha _{i}, \beta _{i}, \gamma _{i}, 1\leq i\leq n$ , are unfound amounts. It noted that one can get as the following function

$\begin{equation} \xi _{i} = \varpi _{i}e^{\theta _{i}}, \ \ \theta _{i} = \alpha _{i}x+\beta _{i}y+\gamma _{i}z-\delta _{i}t, \ \ 1\leq i\leq n, \end{equation}$

(2.3)

where $\varpi _{i}, 1\leq i\leq n$ , unspecified amounts.

Step 2. Assuming the solution of the Eq (2.1) is function of variables $\xi _{i}, 1\leq i\leq n$ :

$\begin{equation} \Psi = \frac{\Delta (\xi _{1}, \xi _{2}, ..., \xi _{n})}{\Omega (\xi _{1}, \xi _{2}, ..., \xi _{n})}, \ \ \Delta = \sum\limits_{r, s = 1}^{n}\sum\limits_{i, j = 0}^{M}\Delta _{rs, ij}\xi _{r}^{i}\xi _{s}^{j}, \ \ \Omega = \sum\limits_{r, s = 1}^{n}\sum\limits_{i, j = 0}^{N}\Omega _{rs, ij}\xi _{r}^{i}\xi _{s}^{j}, \ \ \end{equation}$

(2.4)

in which $\Delta _{rs, ij}$ and $\Omega _{rs, ij}$ are amounts to be remained. Replacing Eq (2.4) into Eq (2.1) can be achieved the below form as:

$\begin{equation} \Psi = \frac{\Delta (\varpi _{1}e^{\alpha _{1}x+\beta _{1}y+\gamma _{1}z-\delta _{1}t}, ..., \varpi _{n}e^{\alpha _{n}x+\beta _{n}y+\gamma _{n}z-\delta _{n}t})}{\Omega (\varpi _{1}e^{\alpha _{1}x+\beta _{1}y+\gamma _{1}z-\delta _{1}t}, ..., \varpi _{n}e^{\alpha _{n}x+\beta _{n}y+\gamma _{n}z-\delta _{n}t})}, \end{equation}$

(2.5)

and also we have

$\begin{eqnarray} \Delta _{t} & = &\sum\limits_{i = 1}^{n}\Delta _{\xi _{i}}\xi _{i, t}, \ \ \Omega _{t} = \sum\limits_{i = 1}^{n}\Omega _{\xi _{i}}\xi _{i, t}, \ \ \Delta _{x} = \sum\limits_{i = 1}^{n}\Delta _{\xi _{i}}\xi _{i, x}, \ \ \Omega _{x} = \sum\limits_{i = 1}^{n}\Omega _{\xi _{i}}\xi _{i, x}, \ \ \Delta _{y} = \sum\limits_{i = 1}^{n}\Delta _{\xi _{i}}\xi _{i, y}, \ \\ \ \Delta _{z} & = &\sum\limits_{i = 1}^{n}\Delta _{\xi _{i}}\xi _{i, z}, \rm{ \ }\Omega _{y} = \sum\limits_{i = 1}^{n}\Omega _{\xi _{i}}\xi _{i, y}, \ \ \Omega _{z} = \sum\limits_{i = 1}^{n}\Omega _{\xi _{i}}\xi _{i, z}, \ \end{eqnarray}$

(2.6)

$\ \ \ \Psi _{t} = \frac{\Omega \sum\limits_{i = 1}^{n}\Delta _{\xi _{i}}\xi _{i, t}-\Delta \sum\limits_{i = 1}^{n}\Omega _{\xi _{i}}\xi _{i, t}}{\Omega ^{2}}, \ \ \Psi _{x} = \frac{\Omega \sum\limits_{i = 1}^{n}\Delta _{\xi _{i}}\xi _{i, x}-\Delta \sum\limits_{i = 1}^{n}\Omega _{\xi _{i}}\xi _{i, x}}{\Omega ^{2}},$

$\Psi _{y} = \frac{\Omega \sum\limits_{i = 1}^{n}\Delta _{\xi _{i}}\xi _{i, y}-\Delta \sum\limits_{i = 1}^{n}\Omega _{\xi _{i}}\xi _{i, y}}{\Omega ^{2}}, \ \ \Psi _{z} = \frac{ \Omega \sum\limits_{i = 1}^{n}\Delta _{\xi _{i}}\xi _{i, z}-\Delta \sum\limits_{i = 1}^{n}\Omega _{\xi _{i}}\xi _{i, z}}{\Omega ^{2}}.$

3. MSSs for the (3+1) gKP equation

3.1. Option I: 1-wave solution

The one-wave function of the solution will be reduced as below form

$\begin{equation} \Psi = \frac{2\Delta _{1}}{\Omega _{1}}, \ \ \Omega _{1} = 1+\rho _{1}+\rho _{2}\ e^{\alpha _{1}x+\beta _{1}y+\gamma _{1}z-\delta _{1}t}, \ \ \Delta _{1} = \sigma _{1}+\sigma _{2}\ e^{\alpha _{1}x+\beta _{1}y+\gamma _{1}z-\delta _{1}t}, \end{equation}$

(3.1)

in which $\rho _{1}, \rho _{2}, \sigma _{1}$ and $\sigma _{2}$ are unspecified amounts. Substituting (3.1) into Eq (1.8), the below cases will be concluded as:

Case I:

$\begin{equation} \alpha _{1} = \alpha _{1}, \ \ \beta _{1} = \beta _{1}, \ \ \rho _{1} = \rho _{1}, \ \ \rho _{2} = \ \ {\frac{\sigma _{{2}}\left( \rho _{{1}}+1\right) }{\sigma _{{1}}} \ \ } , \ \ \sigma _{1} = \sigma _{1}, \ \ \sigma _{{2}} = \sigma _{2}, \ \ \delta _{{1} } = \delta _{1}, \ \ \gamma _{1} = \gamma _{1}, \ \ \gamma _{2} = \gamma _{2}. \end{equation}$

(3.2)

Case II:

$\begin{equation} \alpha _{1} = \alpha _{1}, \ \ \beta _{1} = - \ \ {\frac{\alpha \, {\alpha _{{1}}} \ \ ^{3}\gamma _{{1}}-\alpha _{{1}}\delta _{{1}}\lambda _{{1}}+\alpha _{{1} }\gamma _{{1}}\omega _{{1}}-\delta _{{1}}\gamma _{{1}}\lambda _{{3}}+{\gamma _{{1}}} ^{2}\omega _{{3}}} \ \ {{\alpha _{{1}}} ^{3}-\delta _{{1}}\lambda _{{2} }+\gamma _{{1}}\omega _{{2}}} }, \ \ \rho _{1} = -1, \ \ \rho _{2} = \rho _{2}, \ \ \end{equation}$

(3.3)

$\sigma _{1} = \sigma _{1}, \ \ \sigma _{{2}} = \sigma _{2}, \ \ \delta _{{1} } = \delta _{1}, \ \ \gamma _{1} = \gamma _{1}, \ \ \gamma _{2} = \gamma _{2}.$

Case III:

$\begin{equation} \alpha _{1} = \ \ {\frac{\gamma _{{1}}\left( \alpha \, \delta _{{1}}\lambda _{{2} }-\alpha \, \gamma _{{1}}\omega _{{2}}-\delta _{{1}}\lambda _{{3}}+\gamma _{{1 }}\omega _{{3}}\right) }{\delta _{{1}}\lambda _{{1}}-\gamma _{{1}}\omega _{{1 }}} }, \ \ \beta _{1} = -\alpha \gamma _{1}, \ \ \rho _{1} = \rho _{1}, \ \ \rho _{2} = \rho _{2}, \ \ \end{equation}$

(3.4)

$\sigma _{1} = \sigma _{1}, \ \ \sigma _{{2}} = \sigma _{2}, \ \ \delta _{{1} } = \delta _{1}, \ \ \ \ \gamma _{1} = \gamma _{1}, \ \ \gamma _{2} = \gamma _{2}.$

Case IV:

$\begin{eqnarray} \alpha _{1} & = &\vartheta , \ \ \beta _{1} = \beta _{1}, \ or\ \ \beta _{1} = -\alpha \gamma _{1}, \ \ \ \rho _{1} = -1, \ \ \rho _{2} = \rho _{2}, \ \ \sigma _{1} = \sigma _{1}, \ \ \\ \sigma _{{2}} & = &\sigma _{2}, \ \delta _{{1}} = \frac{\vartheta ^{3}+\gamma _{1}\omega _{2}}{\lambda _{2}}, \ \ \gamma_1 = \gamma_1, \ \ \gamma_2 = \gamma_2, \ \end{eqnarray}$

(3.5)

in which $\vartheta$ , solves the equation $\lambda_1\vartheta ^4+(\gamma _1\lambda _3-\alpha \gamma _1\lambda_2) {\vartheta }^{3}+(\gamma _1\lambda _1\omega _2-\gamma_1\lambda _2\omega _1) \vartheta -\gamma _1 ^2\omega _3\lambda _2+\gamma_1^2\lambda _3\omega_2 = 0.$

For example, the 1-wave solution for Case III will be considered as

$\begin{equation} \Psi = 2\frac{\sigma _{1}+\sigma _{2}e^{ \ \ {\frac{\gamma _{{1}}\left( \alpha \, \delta _{{1}}\lambda _{{2}}-\alpha \, \gamma _{{1}}\omega _{{2}}-\delta _{{1 }}\lambda _{{3}}+\gamma _{{1}}\omega _{{3}}\right) }{\delta _{{1}}\lambda _{{ 1}}-\gamma _{{1}}\omega _{{1}}} \ \ }x-\alpha \gamma _{1}y+\gamma _{1}z-\delta _{1}t}}{1+\rho _{1}+\rho _{2}e^{ \ \ {\frac{\gamma _{{1}}\left( \alpha \, \delta _{ {1}}\lambda _{{2}}-\alpha \, \gamma _{{1}}\omega _{{2}}-\delta _{{1}}\lambda _{{3}}+\gamma _{{1}}\omega _{{3}}\right) }{\delta _{{1}}\lambda _{{1} }-\gamma _{{1}}\omega _{{1}}} \ \ }\ \ x-\alpha \gamma _{1}y+\gamma _{1}z-\delta _{1}t}}. \end{equation}$

(3.6)

3.2. Option II: 2-wave solutions

The two-wave function of the solution will be reduced as below form

$\begin{equation} \Psi = \frac{2\Delta _{2}}{\Omega _{2}}, \end{equation}$

(3.7)

$\begin{equation} \Omega _{2} = 1+\sigma _{1}e^{\alpha _{1}x+\beta _{1}y+\gamma _{1}z-\delta _{1}t}+\sigma _{2}e^{\alpha _{2}x+\beta _{2}y+\gamma _{2}z-\delta _{2}t}+\sigma _{1}\sigma _{2}\sigma _{12}e^{(\alpha _{1}+\alpha _{2})x+(\beta _{1}+\beta _{2})y+(\gamma _{1}+\gamma _{2})z-(\delta _{1}+\delta _{2})t}, \ \ \end{equation}$

(3.8)

$\Delta _{2} = \rho _{1}e^{\alpha _{1}x+\beta _{1}y+\gamma _{1}z-\delta _{1}t}+\rho _{2}e^{\alpha _{2}x+\beta _{2}y+\gamma _{2}z-\delta _{2}t}+\rho _{1}\rho _{2}\rho _{12}e^{(\alpha _{1}+\alpha _{2})x+(\beta _{1}+\beta _{2})y+(\gamma _{1}+\gamma _{2})z-(\delta _{1}+\delta _{2})t}.$

Substituting (3.7) in terms of (3.8) into Eq (1.8), the below cases will be resulted as:

Case I:

$\begin{eqnarray} \alpha _{1} & = &0, \ \ \alpha _{2} = \alpha _{2}, \ \ \beta _{1} = \beta _{1}, \ \ \beta _{2} = -\alpha \gamma _{2}, \ \ \delta _{{1}} = \ \ {\frac{\gamma _{{1}}\left( \beta _{{1}}\omega _{{2}}+\omega _{{3}}\gamma _{{1}}\right) }{\beta _{{1} }\lambda _{{2}}+\gamma _{{1}}\lambda _{{3}}} }, \ \ \\ \delta _{{2}} & = & \ \ {\frac{\gamma _{{2}}\left( \alpha \, \gamma _{{2}}\omega _{{ \ 2}}-\alpha _{{2}}\omega _{{1}}-\gamma _{{2}}\omega _{{3}}\right) }{\alpha \, \gamma _{{2}}\lambda _{{2}}-\alpha _{{2}}\lambda _{{1}}-\gamma _{{2} }\lambda _{{3}}} }, \gamma _{1} = \gamma _{1}, \ \ \gamma _{2} = \gamma _{2}, \ \ \rho _{1} = 0, \ \ \rho _{2} = \rho _{2}, \end{eqnarray}$

(3.9)

$\ \ \rho _{12} = \rho _{12}, \ \ \sigma _{1} = \sigma _{1}, \ \ \sigma _{2} = \sigma _{2}, \ \ \sigma _{12} = 1.$

Case II:

$\begin{eqnarray} \alpha _{1} & = &\alpha _{1}, \ \ \alpha _{2} = 0, \ \ \beta _{1} = -\alpha \gamma _{1}, \ \ \beta _{2} = \beta _{2}, \ \ \delta _{{1}} = \ \ {\frac{\gamma _{{1}}\left( \alpha \, \gamma _{{1}}\omega _{{\ 2}}-\alpha _{{1}}\omega _{{1}}-\omega _{{3} }\gamma _{{1}}\right) }{\alpha \, \gamma _{{1}}\lambda _{{2}}-\alpha _{{1} }\lambda _{{1}}-\gamma _{{1}}\lambda _{{3}}} }, \\ \ \ \delta _{{2}} & = & \ \ {\frac{\gamma _{{2}}\left( \beta _{{2}}\omega _{{2} }+\gamma _{{2}}\omega _{{3}}\right) }{\beta _{{2}}\lambda _{{2}}+\gamma _{{2} }\lambda _{{3}}} }, \gamma _{1} = \gamma _{1}, \ \ \gamma _{2} = \gamma _{2}, \ \ \rho _{1} = 0, \ \end{eqnarray}$

(3.10)

$\ \rho _{2} = \rho _{2}, \ \ \rho _{12} = \rho _{12}, \ \ \sigma _{1} = \sigma _{1}, \ \ \sigma _{2} = \sigma _{2}, \ \ \sigma _{12} = 1.$

Case III:

$\begin{eqnarray} \alpha _{1} & = &\alpha _{1}, \ \ \alpha _{2} = \alpha _{2}, \ \ \beta _{1} = -\alpha \gamma _{1}, \ \ \beta _{2} = -\alpha \gamma _{2}, \ \ \delta _{{1} } = \ \ {\frac{\gamma _{{1}}\left( \alpha \, \gamma _{{1}}\omega _{{\ 2}}-\alpha _{{ 1}}\omega _{{1}}-\omega _{{3}}\gamma _{{1}}\right) }{\alpha \, \gamma _{{1} }\lambda _{{2}}-\alpha _{{1}}\lambda _{{1}}-\gamma _{{1}}\lambda _{{3}}} }, \ \\ \ \delta _{{2}} & = & \ \ {\frac{\gamma _{{2}}\left( \alpha \, \gamma _{{2}}\omega _{ {\ 2}}-\alpha _{{2}}\omega _{{1}}-\gamma _{{2}}\omega _{{3}}\right) }{\alpha \, \gamma _{{2}}\lambda _{{2}}-\alpha _{{2}}\lambda _{{1}}-\gamma _{{2} }\lambda _{{3}}} }, \gamma _{1} = \gamma _{1}, \ \ \gamma _{2} = \gamma _{2}, \ \ \rho _{1} = 0, \end{eqnarray}$

(3.11)

$\ \ \rho _{2} = \rho _{2}, \ \ \rho _{12} = \rho _{12}, \ \ \sigma _{1} = \sigma _{1}, \ \ \sigma _{2} = \sigma _{2}, \ \ \sigma _{12} = 1.$

Case IV:

$\begin{eqnarray} \alpha _{1} & = &0, \ \ \alpha _{2} = \alpha _{2}, \ \ \beta _{1} = \beta _{1}, \ \ \beta _{2} = -\alpha \gamma _{2}, \ \ \delta _{{1}} = \ \ {\frac{\gamma _{{1}}\left( \beta _{{1}}\omega _{{2}}+\omega _{{3}}\gamma _{{1}}\right) }{\beta _{{1} }\lambda _{{2}}+\gamma _{{1}}\lambda _{{3}}} }, \ \\ \ \delta _{{2}} & = & \ \ {\frac{\gamma _{{2}}\left( \alpha \, \gamma _{{2}}\omega _{ {\ 2}}-\alpha _{{2}}\omega _{{1}}-\gamma _{{2}}\omega _{{3}}\right) }{\alpha \, \gamma _{{2}}\lambda _{{2}}-\alpha _{{2}}\lambda _{{1}}-\gamma _{{2} }\lambda _{{3}}} }, \gamma _{1} = \gamma _{1}, \ \ \gamma _{2} = \gamma _{2}, \ \ \rho _{1} = \rho _{1}, \ \ \rho _{2} = 0, \end{eqnarray}$

(3.12)

$\ \ \rho _{12} = \rho _{12}, \ \ \sigma _{1} = \sigma _{1}, \ \ \sigma _{2} = \sigma _{2}, \ \ \sigma _{12} = 1.$

Case V:

$\begin{eqnarray} \alpha _{1} & = &\alpha _{1}, \ \ \alpha _{2} = \alpha _{2}, \ \ \beta _{1} = -\alpha \gamma _{1}, \ \ \beta _{2} = -\alpha \gamma _{2}, \ \ \delta _{{1} } = \ \ {\frac{\gamma _{{1}}\left( \alpha \, \gamma _{{1}}\omega _{{\ 2}}-\alpha _{{ 1}}\omega _{{1}}-\omega _{{3}}\gamma _{{1}}\right) }{\alpha \, \gamma _{{1} }\lambda _{{2}}-\alpha _{{1}}\lambda _{{1}}-\gamma _{{1}}\lambda _{{3}}} }, \\ \ \ \delta _{{2}} & = & \ \ {\frac{\gamma _{{2}}\left( \alpha \, \gamma _{{2}}\omega _{{\ 2}}-\alpha _{{2}}\omega _{{1}}-\gamma _{{2}}\omega _{{3}}\right) }{ \alpha \, \gamma _{{2}}\lambda _{{2}}-\alpha _{{2}}\lambda _{{1}}-\gamma _{{2} }\lambda _{{3}}} }, \gamma _{1} = \gamma _{1}, \ \ \gamma _{2} = \gamma _{2}, \ \ \rho _{1} = \rho _{1}, \ \ \rho _{2} = 0, \end{eqnarray}$

(3.13)

$\ \ \rho _{12} = \rho _{12}, \ \ \sigma _{1} = \sigma _{1}, \ \ \sigma _{2} = \sigma _{2}, \ \ \sigma _{12} = 1.$

Case VI:

$\begin{eqnarray} \alpha _{1} & = &\alpha _{1}, \ \ \alpha _{2} = \alpha _{2}, \ \ \beta _{1} = -{ \frac{\alpha \, \alpha _{{1}}\gamma _{{2}}} \ \ {\alpha _{{2}}} }, \ \ \beta _{2} = -\alpha \gamma _{2}, \ \ \delta _{{1}} = \ \ {\frac{\alpha _{{1}}\gamma _{{2} }\left( \alpha \, \gamma _{{\ 2}}\omega _{{2}}-\alpha _{{2}}\omega _{{1} }-\gamma _{{2}}\omega _{{3}}\right) }{\alpha _{{2}}\left( \alpha \, \gamma _{{ 2}}\lambda _{{2}}-\alpha _{{2}}\lambda _{{1}}-\gamma _{{2}}\lambda _{{3} }\right) }}, \ \\ \ \delta _{{2}} & = & \ \ {\frac{\gamma _{{2}}\left( \alpha \, \gamma _{{2}}\omega _{ {\ 2}}-\alpha _{{2}}\omega _{{1}}-\gamma _{{2}}\omega _{{3}}\right) }{\alpha \, \gamma _{{2}}\lambda _{{2}}-\alpha _{{2}}\lambda _{{1}}-\gamma _{{2} }\lambda _{{3}}} }, \gamma _{1} = \gamma _{1}, \ \ \gamma _{2} = \gamma _{2}, \ \ \rho _{1} = \rho _{1}, \ \ \rho _{2} = 0, \end{eqnarray}$

(3.14)

$\ \ \rho _{12} = \rho _{12}, \ \ \sigma _{1} = \sigma _{1}, \ \ \sigma _{2} = \sigma _{2}, \ \ \sigma _{12} = \sigma _{12}.$

Case VII:

$\begin{eqnarray} \alpha _{1} & = &\alpha _{1}, \ \ \alpha _{2} = \alpha _{2}, \ \ \beta _{1} = -{ \frac{\alpha \, \alpha _{{1}}\gamma _{{2}}} \ \ {\alpha _{{2}}} }, \ \ \beta _{2} = -\alpha \gamma _{2}, \ \ \delta _{{1}} = \ \ {\frac{\alpha _{{1}}\gamma _{{2} }\left( \alpha \, \gamma _{{\ 2}}\omega _{{2}}-\alpha _{{2}}\omega _{{1} }-\gamma _{{2}}\omega _{{3}}\right) }{\alpha _{{2}}\left( \alpha \, \gamma _{{ 2}}\lambda _{{2}}-\alpha _{{2}}\lambda _{{1}}-\gamma _{{2}}\lambda _{{3} }\right) }}, \\ \ \ \delta _{{2}} & = & \ \ {\frac{\gamma _{{2}}\left( \alpha \, \gamma _{{2}}\omega _{{\ 2}}-\alpha _{{2}}\omega _{{1}}-\gamma _{{2}}\omega _{{3}}\right) }{ \alpha \, \gamma _{{2}}\lambda _{{2}}-\alpha _{{2}}\lambda _{{1}}-\gamma _{{2} }\lambda _{{3}}} }, \gamma _{1} = \ \ {\frac{\alpha _{{1}}\gamma _{{2}}} \ \ {\alpha _{{2} }}} \ \ , \ \ \gamma _{2} = \gamma _{2}, \ \ \rho _{1} = \rho _{1}, \ \ \rho _{2} = \rho _{2}, \end{eqnarray}$

(3.15)

$\ \ \rho _{12} = \rho _{12}, \ \ \sigma _{1} = 0, \ \ \sigma _{2} = \sigma _{2}, \ \ \sigma _{12} = \sigma _{12}.$

Case VIII:

$\begin{eqnarray} \alpha _{1} & = &\frac{1}{2}\alpha _{2}, \ \ \alpha _{2} = \alpha _{2}, \ \ \beta _{1} = -\frac{1}{2}\, \alpha \, \gamma _{{2}}, \ \ \beta _{2} = -\alpha \gamma _{2}, \ \ \delta _{{1}} = \frac{1}{2}\, \ \ {\frac{\gamma _{{2}}\left( \alpha \, \gamma _{{2}}\omega _{{2}}-\alpha _{{2}}\omega _{{1}}-\gamma _{{2}}\omega _{{3}}\right) }{\alpha \, \gamma _{{2}}\lambda _{{2}}-\alpha _{{2}}\lambda _{{ 1}}-\gamma _{{2}}\lambda _{{3}}} }, \ \\ \ \delta _{{2}} & = & \ \ {\frac{\gamma _{{2}}\left( \alpha \, \gamma _{{2}}\omega _{ {\ 2}}-\alpha _{{2}}\omega _{{1}}-\gamma _{{2}}\omega _{{3}}\right) }{\alpha \, \gamma _{{2}}\lambda _{{2}}-\alpha _{{2}}\lambda _{{1}}-\gamma _{{2} }\lambda _{{3}}} }, \gamma _{1} = \frac{1}{2}\gamma _{2}, \ \ \gamma _{2} = \gamma _{2}, \ \ \rho _{1} = \rho _{1}, \ \end{eqnarray}$

(3.16)

$\ \rho _{2} = \rho _{2}, \ \ \rho _{12} = \rho _{12}, \ \ \sigma _{1} = \sigma _{1}, \ \ \sigma _{2} = \sigma _{2}, \ \ \sigma _{12} = 0.$

For instance, the 2-wave solution for Case I will be taken as

$\begin{equation} \Psi _{1} = \left. 2\, \rho _{{2}}{\mathrm{e}^{- \ \ {\frac{t\gamma _{{2}}\left( \alpha \, \gamma _{{\ 2}}\omega _{{2}}-\alpha _{{2}}\omega _{{1}}-\gamma _{{2} }\omega _{{3}}\right) }{\alpha \, \gamma _{{2}}\lambda _{{2}}-\alpha _{{2} }\lambda _{{1}}-\gamma _{{2}}\lambda _{{3}}} \ \ }+x\alpha _{{2}}-y\alpha \, \gamma _{{2}}+z\gamma _{{2}}} \ \ }\right/ \left( 1+\sigma _{{1}}{\mathrm{e}^{-{ \frac{t\gamma _{{1}}\left( \beta _{{1}}\omega _{{2}}+\omega _{{3}}\gamma _{{1 }}\right) }{\beta _{{1}}\lambda _{{2}}+\gamma _{{1}}\lambda _{{3}}} \ \ }+y\beta _{{1}}+z\gamma _{{1}}} \ \ }+\right. \end{equation}$

(3.17)

$\left. \sigma _{{2}}{\mathrm{e}^{- \ \ {\frac{t\gamma _{{2}}\left( \alpha \, \gamma _{{2}}\omega _{{2}}-\alpha _{{2}}\omega _{{1}}-\gamma _{{2}}\omega _{{3}}\right) }{\alpha \, \gamma _{{2}}\lambda _{{2}}-\alpha _{{2}}\lambda _{{ 1}}-\gamma _{{2}}\lambda _{{3}}} \ \ }+x\alpha _{{2}}-y\alpha \, \gamma _{{2} }+z\gamma _{{2}}} \ \ }+\sigma _{{1}}\sigma _{{2}}{\mathrm{e}^{- \ \ {\frac{t\gamma _{{ 1}}\left( \beta _{{1}}\omega _{{2}}+\omega _{{3}}\gamma _{{1}}\right) }{ \beta _{{1}}\lambda _{{2}}+\gamma _{{1}}\lambda _{{3}}} \ \ }- \ \ {\frac{t\gamma _{{2} }\left( \alpha \, \gamma _{{2}}\omega _{{2}}-\alpha _{{2}}\omega _{{1} }-\gamma _{{2}}\omega _{{3}}\right) }{\alpha \, \gamma _{{2}}\lambda _{{2} }-\alpha _{{2}}\lambda _{{1}}-\gamma _{{2}}\lambda _{{3}}} \ \ }+x\alpha _{{2} }+y\beta _{{1}}-y\alpha \, \gamma _{{2}}+z\gamma _{{1}}+z\gamma _{{2}}} } \right) .$

Also, the 2-wave solution for Case III will be considered as

$\begin{equation} \Psi _{2} = \left. 2\, \rho _{{2}}{\mathrm{e}^{- \ \ {\frac{t\gamma _{{2}}\left( \alpha \, \gamma _{{\ 2}}\omega _{{2}}-\alpha _{{2}}\omega _{{1}}-\gamma _{{2} }\omega _{{3}}\right) }{\alpha \, \gamma _{{2}}\lambda _{{2}}-\alpha _{{2} }\lambda _{{1}}-\gamma _{{2}}\lambda _{{3}}} \ \ }+x\alpha _{{2}}-y\alpha \, \gamma _{{2}}+z\gamma _{{2}}} \ \ }\right/ \left( 1+\sigma _{{1}}{\mathrm{e}^{-{ \frac{t\gamma _{{1}}\left( \alpha \, \gamma _{{1}}\omega _{{2}}-\alpha _{{1} }\omega _{{1}}-\omega _{{3}}\gamma _{{1}}\right) }{\alpha \, \gamma _{{1} }\lambda _{{2}}-\alpha _{{1}}\lambda _{{1}}-\gamma _{{1}}\lambda _{{3}}} \ \ } +x\alpha _{{1}}-y\alpha \, \gamma _{{1}}+z\gamma _{{1}}} \ \ }+\right. \end{equation}$

(3.18)

$\left. \sigma _{{2}}{\mathrm{e}^{- \ \ {\frac{t\gamma _{{2}}\left( \alpha \gamma _{{2}}\omega _{{2}}-\alpha _{{2}}\omega _{{1}}-\gamma _{{2}}\omega _{{3} }\right) }{\alpha \gamma _{{2}}\lambda _{{2}}-\alpha _{{2}}\lambda _{{1} }-\gamma _{{2}}\lambda _{{3}}} \ \ }+x\alpha _{{2}}-y\alpha \gamma _{{2}}+z\gamma _{{2}}} \ \ }+\sigma _{{1}}\sigma _{{2}}{\mathrm{e}^{- \ \ {\frac{t\gamma _{{1}}\left( \alpha \gamma _{{1}}\omega _{{2}}-\alpha _{{1}}\omega _{{1}}-\omega _{{3} }\gamma _{{1}}\right) }{\alpha \gamma _{{1}}\lambda _{{2}}-\alpha _{{1} }\lambda _{{1}}-\gamma _{{1}}\lambda _{{3}}} \ \ }- \ \ {\frac{t\gamma _{{2}}\left( \alpha \gamma _{{2}}\omega _{{2}}-\alpha _{{2}}\omega _{{1}}-\gamma _{{2} }\omega _{{3}}\right) }{\alpha \gamma _{{2}}\lambda _{{2}}-\alpha _{{2} }\lambda _{{1}}-\gamma _{{2}}\lambda _{{3}}} \ \ }+x\alpha _{{1}}+x\alpha _{{2} }-y\alpha \gamma _{{1}}-y\alpha \gamma _{{2}}+z\gamma _{{1}}+z\gamma _{{2}}} } \right) .$

And finally, the resulting two-wave solution for Case VIII will be read as

$\begin{equation} \Psi _{3}(x, y, z, t) = 2\left( \rho _{{1}}{\mathrm{e}^{-\frac{1}{2} \ \ {\frac{ t\gamma _{{2}}\left( \alpha \, \gamma _{{2}}\omega _{{2}}-\alpha _{{2}}\omega _{{1}}-\gamma _{{2}}\omega _{{3}}\right) }{\alpha \, \gamma _{{2}}\lambda _{{2 }}-\alpha _{{2}}\lambda _{{1}}-\gamma _{{2}}\lambda _{{3}}} \ \ }+\frac{1}{2} x\alpha _{{2}}-\frac{1}{2}y\alpha \, \gamma _{{2}}+\frac{1}{2}z\gamma _{{2}}} \ \ } +\rho _{{2}}{\mathrm{e}^{- \ \ {\frac{t\gamma _{{2}}\left( \alpha \, \gamma _{{2} }\omega _{{2}}-\alpha _{{2}}\omega _{{1}}-\gamma _{{2}}\omega _{{3}}\right) }{\alpha \, \gamma _{{2}}\lambda _{{2}}-\alpha _{{2}}\lambda _{{1}}-\gamma _{{ 2}}\lambda _{{3}}} \ \ }+x\alpha _{{2}}-y\alpha \, \gamma _{{2}}+z\gamma _{{2}}} \ \ } +\right. \end{equation}$

(3.19)

$\left. \left. \rho _{{1}}\rho _{{2}}\rho _{{12}}{\ \mathrm{e}^{-\frac{3}{2}{ \frac{t\gamma _{{2}}\left( \alpha \, \gamma _{{2}}\omega _{{2}}-\alpha _{{2} }\omega _{{1}}-\gamma _{{2}}\omega _{{3}}\right) }{\alpha \, \gamma _{{2} }\lambda _{{2}}-\alpha _{{2}}\lambda _{{1}}-\gamma _{{2}}\lambda _{{3}}} \ \ }+ \frac{3}{2}x\alpha _{{2}}-\frac{3}{2}y\alpha \, \gamma _{{2}}+\frac{3}{2} z\gamma _{{2}}} \ \ }\right) \right/ \left( 1+\sigma _{{1}}{\mathrm{e}^{-\frac{1}{ 2} \ \ {\frac{t\gamma _{{2}}\left( \alpha \, \gamma _{{2}}\omega _{{2}}-\alpha _{{2 }}\omega _{{1}}-\gamma _{{2}}\omega _{{3}}\right) }{\alpha \, \gamma _{{2} }\lambda _{{2}}-\alpha _{{2}}\lambda _{{1}}-\gamma _{{2}}\lambda _{{3}}} \ \ }+ \frac{1}{2}x\alpha _{{2}}-\frac{1}{2}y\alpha \gamma _{{2}}+\frac{1}{2} z\gamma _{{2}}} \ \ }\right.$

$\left. +\sigma _{{2}}{\mathrm{e}^{- \ \ {\frac{t\gamma _{{2}}\left( \alpha \, \gamma _{{2}}\omega _{{2}}-\alpha _{{2}}\omega _{{1}}-\gamma _{{2}}\omega _{{3}}\right) }{\alpha \, \gamma _{{2}}\lambda _{{2}}-\alpha _{{2}}\lambda _{{ 1}}-\gamma _{{2}}\lambda _{{3}}} \ \ }+x\alpha _{{2}}-y\alpha \, \gamma _{{2} }+z\gamma _{{2}}} \ \ }\right) .$

3.3. Option III: Triple-wave solutions

The triple-wave function of the solution will be reduced as below form

$\begin{equation} \Psi = \frac{\Delta _{3}}{\Omega _{3}}, \end{equation}$

(3.20)

$\begin{equation} \Omega _{3} = 1+\rho _{1}e^{\Lambda _{1}}+\rho _{2}e^{\Lambda _{2}}+\rho _{3}e^{\Lambda _{3}}+\rho _{1}\rho _{2}\rho _{12}e^{\Lambda _{1}+\Lambda _{2}}+\rho _{1}\rho _{3}\rho _{13}e^{\Lambda _{1}+\Lambda _{3}}+\rho _{2}\rho _{3}\rho _{23}e^{\Lambda _{2}+\Lambda _{3}}+\rho _{1}\rho _{2}\rho _{3}\rho _{12}\rho _{13}\rho _{23}e^{\Lambda _{1}+\Lambda _{2}+\Lambda _{3}}, \ \ \end{equation}$

(3.21)

$\Delta _{3} = 2\sigma _{1}e^{\Lambda _{1}}+2\sigma _{2}e^{\Lambda _{2}}+2\sigma _{1}\sigma _{2}\sigma _{12}e^{\Lambda _{1}+\Lambda _{2}}+2\sigma _{1}\sigma _{3}\sigma _{13}e^{\Lambda _{1}+\Lambda _{3}}+2\sigma _{2}\sigma _{3}\sigma _{23}e^{\Lambda _{2}+\Lambda _{3}}+$

$2\sigma _{1}\sigma _{2}\sigma _{3}\sigma _{12}\sigma _{13}\sigma _{23}e^{\Lambda _{1}+\Lambda _{2}+\Lambda _{3}},$

in which $\Lambda _{i} = \alpha _{i}x+\beta _{i}y+\gamma _{i}x-\delta _{i}t, i = 1, 2, 3$ . Inserting (3.20) in terms of (3.21) into Eq (1.8), the below case will be reached:

$\begin{eqnarray} \alpha _{i} & = &\alpha _{i}, \ \ \gamma _{i} = \gamma _{i}, \ \ \sigma _{i} = \sigma _{i}, \ \ \rho _{1} = 0, \ \ \rho _{2} = \rho _{2}, \ \ \rho _{3} = \rho _{3}, \ \ \beta _{{i}} = -\alpha \, \gamma _{{i}}, \ \ \\ \delta _{{i}} & = & \ \ {\frac{\gamma _{{i}}\left( \alpha \, \gamma _{{i}}\omega _{{ \ 2}}-\alpha _{{i}}\omega _{{1}}-\omega _{{3}}\gamma _{{i}}\right) }{\alpha \, \gamma _{{i}}\lambda _{{2}}-\alpha _{{i}}\lambda _{{1}}-\gamma _{{i} }\lambda _{{3}}} }, \ \ i = 1, 2, 3, \ \ \rho _{ij} = \rho _{ij}, \ \ \sigma _{ij} = 1, \ \ i, j = 1, 2, 3, \ i\neq j. \end{eqnarray}$

(3.22)

Then, the solution is

$\begin{equation} \Psi _{1} = \frac{2\sigma _{1}e^{\Lambda _{1}}+2\sigma _{2}e^{\Lambda _{2}}+2\sigma _{1}\sigma _{2}e^{\Lambda _{1}+\Lambda _{2}}+2\sigma _{1}\sigma _{3}e^{\Lambda _{1}+\Lambda _{3}}+2\sigma _{2}\sigma _{3}e^{\Lambda _{2}+\Lambda _{3}}+2\sigma _{1}\sigma _{2}\sigma _{3}e^{\Lambda _{1}+\Lambda _{2}+\Lambda _{3}}} \ \ {1+\rho _{2}e^{\Lambda _{2}}+\rho _{3}e^{\Lambda _{3}}+\rho _{2}\rho _{3}\rho _{23}e^{\Lambda _{2}+\Lambda _{3}}} \ \ , \end{equation}$

(3.23)

in which $\Lambda _{i} = \alpha _{i}x-\alpha \, \gamma _{{i}}y+\gamma _{i}x-{ \frac{\gamma _{{i}}\left(\alpha \, \gamma _{{i}}\omega _{{\ 2}}-\alpha _{{i} }\omega _{{1}}-\omega _{{3}}\gamma _{{i}}\right) }{\alpha \, \gamma _{{i} }\lambda _{{2}}-\alpha _{{i}}\lambda _{{1}}-\gamma _{{i}}\lambda _{{3}}} \ \ } t, i = 1, 2, 3$ and $\Psi = \Psi (x, y, z, t)$ .

4. Novel periodic wave solutions

The triangular periodic waves for Eq (1.8) can be assumed as below:

$\begin{equation} \mathbf{f} = \exp (\tau _{1})+a_{16}\exp (-\tau _{1})+\cosh (\tau _{2})+\cos (\tau _{3})+a_{17}, \ \ \ \tau _{1} = \sum\limits_{i = 1}^{4}a_{i}x_{i}+a_{5}, \ \ \ \tau _{2} = \sum\limits_{i = 6}^{9}a_{i}x_{i-5}+a_{10}, \ \ \ \end{equation}$

(4.1)

$\begin{equation} \tau _{3} = \sum\limits_{i = 11}^{14}a_{i}x_{i-10}+a_{15}, \ \ (x_{1}, x_{2}, x_{3}, x_{4}) = (\mathbf{x}, t) = (x, y, z, t), \ \ \ \Psi (\mathbf{x} , t) = v_{0}+2\ln (\mathbf{f})_{x}, \end{equation}$

(4.2)

in which $a_{i}, i = 1, ..., 17$ are unfound values. Substituting (4.1) and (4.2) into Eq (1.8) the below consequences will be gained:

Case I:

$\begin{eqnarray} \mathbf{f} & = &{\mathrm{e}^{a_{{4}}t+a_{{1}}x- \ \ {\frac{y\left( a_{{3}}a_{{14} }\omega _{{3}}-a_{{4}}a_{{12}}\omega _{{2}}-a_{{4}}a_{{13}}\omega _{{3} }\right) }{a_{{14}}\omega _{{2}}} \ \ }+a_{{3}}z+a_{{5}}} \ \ }+\cosh \left( a_{{9}}t-{ \frac{y\left( a_{{8}}a_{{14}}\omega _{{3}}-a_{{9}}a_{{12}}\omega _{{2}}-a_{{ \ 9}}a_{{13}}\omega _{{3}}\right) }{a_{{14}}\omega _{{2}}} \ \ }+a_{{8}}z+a_{{\ 10 }}\right) \\ &&+\cos \left( ta_{{14}}+ya_{{12}}+za_{{13}}+a_{{15}}\right) . \end{eqnarray}$

(4.3)

Appending (4.3) into (4.1) and (4.2), the soliton-periodic wave solution of Eq (1.8) as below will be achieved:

$\begin{equation} \Psi _{1} = v_{{0}}+\frac{2a_{{1}}{\mathrm{e}^{a_{{4}}t+a_{{1}}x- \ \ {\frac{ y\left( a_{{3}}a_{{14}}\omega _{{3}}-a_{{4}}a_{{12}}\omega _{{2}}-a_{{4}}a_{{ 13}}\omega _{{3}}\right) }{a_{{14}}\omega _{{2}}} \ \ }+a_{{3}}z+a_{{5}}} \ \ }}{ \mathbf{f}}. \end{equation}$

(4.4)

By selecting the suitable values of parameters including

$\begin{eqnarray*} a_{1} & = &1, a_{3} = 1.5, a_{4} = 2, a_{5} = 1.5, a_{8} = 2, a_{9} = 1.5, a_{10} = 1, \\ a_{12} & = &2, a_{13} = 2.5, a_{14} = 1, a_{15} = 3.2, \omega _{2} = 1.5, \omega _{3} = 1.2, \end{eqnarray*}$

the graphical display of soliton-periodic wave solution is offered in Figure 1 such as 3D plot and density plot.

Figure 1. The soliton-periodic solution (4.4) at (f1, f2)

$x = -2, y = -2$ , (f3, f4)

$x = 0, y = 0$ , and (f5, f6)

$x = 2, y = 2$ .

DownLoad: Full-Size Img PowerPoint

Case II:

$\begin{equation} \mathbf{f} = {\mathrm{e}^{a_{{4}}t+a_{{1}}x+ya_{{2}}- \ \ {\frac { \left( {a_{{1}}} \ \ ^{3}a_{{\ 14}}-a_{{4}}a_{{13}}\omega_{{2}} \right) z}{a_{{14}}\omega_{{2}}} \ \ } +a_{ {5}}} \ \ }+\cosh \left( a_{{9}}t+ya_{{7}}+ \ \ {\frac {a_{{9}}a_{{13}}z}{a_{{14 } }}} \ \ +a_{{10}} \right) +\cos \left( ta_{{14}}+ya_{{12}}+za_{{13}}+a_{{\ 15}} \right). \end{equation}$

(4.5)

Plugging (4.5) into (4.1) and (4.2), obtain a soliton-periodic wave solution of Eq (1.8) as below case:

$\begin{equation} \Psi_2 = v_{{0}}+\frac{2a_{{1}}{\mathrm{e}^{a_{{4}}t+a_{{1}}x+ya_{{2}}- \ \ {\frac { \left( {a_{{1}}} ^ {3}a_{{14}}-a_{{4}}a_{{13}}\omega_{{2}} \right) z}{a_{{14} }\omega_{{2} }}} \ \ +a_{{5}}} \ \ } }{\mathbf{f}} . \end{equation}$

(4.6)

Case III:

$\begin{equation} \mathbf{f} = {\mathrm{e}^{a_{{4}}t+a_{{1}}x- \ \ {\frac {y \left( a_{{3}}\omega_{{3} }+a_{{4 }}\lambda_{{3}} \right) }{\omega_{{2}}} \ \ }+a_{{3}}z+a_{{5}}} \ \ }+\cosh \left( a_{{9}}t- \ \ {\frac {y \left( a_{{8}}\omega_{{3}}+a_{{9}}\lambda_{ {3}} \right) }{\omega_{{2}}} \ \ }+a_{{8}}z+a_{{10}} \right) +\cos \left( - \ \ {\frac { a_{ {13}}\omega_{{3}}y}{\omega_{{2}}} \ \ }+za_{{13}}+a_{{15}} \right). \end{equation}$

(4.7)

Incorporating (4.7) into (4.1) and (4.2), the soliton-periodic wave solution of Eq (1.8) will be gained as below:

$\begin{equation} \Psi_3 = v_{{0}}+\frac{2a_{{1}}{\mathrm{e}^{a_{{4}}t+a_{{1}}x- \ \ {\frac {y \left( a_{{3}}\omega_{{3} }+a_{{4}}\lambda_{{3}} \right) }{\omega_{{2}}} \ \ }+a_{{3} }z+a_{{5}}} \ \ } }{\mathbf{f}} . \end{equation}$

(4.8)

Case IV:

$\begin{equation} \mathbf{f} = {\mathrm{e}^{a_{{4}}t- \ \ {\frac {y \left( a_{{3}}a_{{9}}\omega_{{3} }-a_{{4}} a_{{7}}\omega_{{2}}-a_{{4}}a_{{8}}\omega_{{3}} \right) }{a_{{9} }\omega _{{2}}} \ \ }+a_{{3}}z+a_{{5}}} \ \ }+\cosh \left( a_{{9}}t+ya_{{7}}+a_{{8} }z+a_ {{10}} \right) +\cos \left( xa_{{11}}+a_{{15}} \right) . \end{equation}$

(4.9)

Plugging (4.9) into (4.1) and (4.2), the soliton-periodic wave solution of Eq (1.8) will be achieved as below:

$\begin{equation} \Psi_4 = v_{{0}}-\frac{2\sin \left( xa_{{11}}+a_{{15}} \right) a_{{11}} }{ \mathbf{f}}. \end{equation}$

(4.10)

Case V:

$\begin{equation} \mathbf{f} = {\mathrm{e}^{a_{{4}}t+ya_{{2}}+ \ \ {\frac {a_{{4}}a_{{8}}z}{a_{{9}}} \ \ } +a_{{5}} }}+\cosh \left( a_{{9}}t+ya_{{7}}+a_{{8}}z+a_{{10}} \right) +\cos \left( xa_{{11}}- \ \ {\frac { \left( {a_{{11}}} ^{2}\omega_{{3}}+\omega_{{\ 1} }\omega_{{2}} \right) a_{{11}}y}{{\omega_{{2}}} ^{2}}} \ \ + \ \ {\frac {{a_{{\ 11}}} \ \ ^{3}z}{\omega_{{2}}} \ \ }+a_{{15}} \right). \end{equation}$

(4.11)

Incorporating (4.11) into (4.1) and (4.2), we capture a soliton-periodic wave solution of Eq (1.8) as below:

$\begin{equation} \Psi_5 = v_{{0}}-\frac{2\sin \left( xa_{{11}}- \ \ {\frac { \left( {a_{{11}}} \ \ ^{2}\omega_{{3}}+ \omega_{{1}}\omega_{{2}} \right) a_{{11}}y}{{\omega_{{2}}} \ \ ^{2}}} \ \ +{\ \frac {{a_{{11}}} ^{3}z}{\omega_{{2}}} \ \ }+a_{{15}} \right) a_{{11}} }{ \mathbf{f}}. \end{equation}$

(4.12)

Case VI:

$\begin{eqnarray} \mathbf{f} & = &{\mathrm{e}^{a_{{4}}t+ \ \ {\frac{\omega _{{2}}\left( a_{{3}}a_{{9} }-a_{{4}}a_{{8}}\right) x}{a_{{9}}{a_{{11}}} ^{2}}} \ \ -\frac{1}{3}\, \ \ {\frac{ y\left( -2\, \alpha \, a_{{9}}{a_{{11}}} ^{6}\omega _{{2}}+2\, a_{{9}}{a_{{11}}} \ \ ^{6}\omega _{{3}}+3\, \alpha \, {a_{{3}}} ^{2}a_{{9}}{\omega _{{2}}} \ \ ^{3}-3\, \alpha \, a_{{3}}a_{{4}}a_{{8}}{\omega _{{2}}} ^{3}+2\, a_{{9}}{a_{{11}} }^{4}\omega _{{1}}\omega _{{2}}\right) }{{\omega _{{2}}} ^{3}\left( a_{{3}}a_{ {9}}-a_{{4}}a_{{8}}\right) }} \ \ +a_{{3}}z+a_{{5}}} }+ \\ &&\cosh \left( a_{{9}}t-\frac{1}{3} \ \ {\frac{y\Omega }{a_{{4}}{\omega _{{2}}} \ \ ^{3}\left( a_{{3}}a_{{9}}-a_{{4}}a_{{8}}\right) \left( {a_{{9}}} ^{2}{a_{{11}} }^{6}+{\omega _{{2}}} ^{2}\left( a_{{3}}a_{{9}}-a_{{4}}a_{{8}}\right) ^{2}\right) }}+a_{{8}}z+a_{{10}}\right) \\ &&+\cos \left( xa_{{11}}- \ \ {\frac{\alpha {a_{{11}}} ^{3}y}{\omega _{{2}}} \ \ }+{ \frac{{a_{{11}}} ^{3}z}{\omega _{{2}}} \ \ }+a_{{15}}\right) , \end{eqnarray}$

(4.13)

$\begin{eqnarray*} \Omega & = &3\, \alpha \, a_{{4}}a_{{8}}{\omega _{{2}}} ^{5}\left( a_{{3}}a_{{9} }-a_{{4}}a_{{8}}\right) ^{3}+\alpha \, {a_{{9}}} ^{2}{a_{{11}}} ^{6}{\omega _{{2 }}} ^{3}\left( a_{{3}}a_{{9}}+2\, a_{{4}}a_{{8}}\right) \left( a_{{3}}a_{{9} }-a_{{4}}a_{{8}}\right) \\ &&-{a_{{9}}} ^{2}{a_{{11}}} ^{4}{\omega _{{2}}} ^{2}\left( a_{{3}}a_{{9}}-a_{{4} }a_{{8}}\right) ^{2}\left( {a_{{11}}} ^{2}\omega _{{3}}+\omega _{{1}}\omega _{ {2}}\right) -{a_{{9}}} ^{2}{a_{{11}}} ^{12}\left( 3\, {a_{{4}}} ^{2}-{a_{{9}}} \ \ ^{2}\right) \left( \alpha \, \omega _{{2}}-\omega _{{3}}\right) . \end{eqnarray*}$

Appending (4.13) into (4.1) and (4.2), the soliton-periodic wave solution of Eq (1.8) will be obtained as below:

$\begin{eqnarray} \Psi _{5} & = &v_{{0}}+\frac{2}{\mathbf{f}}\left[ \ \ {\frac{\omega _{{2}}\left( a_{{3}}a_{{9}}-a_{{4}}a_{{8}}\right) }{a_{{9}}{a_{{11}}} ^{2}}{\mathrm{e}^{a_{ {4}}t+ \ \ {\frac{\omega _{{2}}\left( a_{{3}}a_{{9}}-a_{{4}}a_{{8}}\right) x}{a_{{ 9}}{a_{{11}}} ^{2}}} \ \ -\frac{1}{3}\, \ \ {\frac{y\left( -2\, \alpha \, a_{{9}}{a_{{11}} }^{6}\omega _{{2}}+2\, a_{{9}}{a_{{11}}} ^{6}\omega _{{3}}+3\, \alpha \, {a_{{3}} }^{2}a_{{9}}{\omega _{{2}}} ^{3}-3\, \alpha \, a_{{3}}a_{{4}}a_{{8}}{\omega _{{2 }}} ^{3}+2\, a_{{9}}{a_{{11}}} ^{4}\omega _{{1}}\omega _{{2}}\right) }{{\omega _{{2}}} ^{3}\left( a_{{3}}a_{{9}}-a_{{4}}a_{{8}}\right) }}+a_{{3}}z+a_{{5}}} \ \ }} \right. \\ &&\left. +\sin \left( -xa_{{11}}+ \ \ {\frac{\alpha \, {a_{{11}}} ^{3}y}{\omega _{{2 }}} \ \ }- \ \ {\frac{{a_{{11}}} ^{3}z}{\omega _{{2}}} \ \ }-a_{{15}}\right) a_{{11}}\right] . \end{eqnarray}$

(4.14)

By selecting suitable values of parameters including

$\begin{eqnarray*} \alpha & = &0.5, a_{3} = 1, a_{4} = 1.5, a_{5} = 2, a_{8} = 2, a_{9} = 1.5, a_{10} = 1, a_{11} = 2, a_{13} = 2.5, a_{14} = 1, \\ a_{15} & = &3.2, \omega _{1} = 1.5, \omega _{2} = 1.2, \omega _{3} = 1.5, \end{eqnarray*}$

the graphical display of soliton-periodic wave solution is offered in Figure 2 such as 3D chart and density chart.

Figure 2. The soliton-periodic solution (4.14) at (f1, f2)

$x = -2, y = -2$ , (f3, f4)

$x = 0, y = 0$ , and (f5, f6)

$x = 2, y = 2$ .

DownLoad: Full-Size Img PowerPoint

Case VII:

$\begin{equation} \mathbf{f} = {\mathrm{e}^{ \ \ {\frac{\Omega \, a_{{9}}t}{{a_{{11}}} ^{3}}} \ \ +a_{{1}}x- \frac{1}{6}\, \ \ {\frac{y\left( -6\, {a_{{1}}} ^{4}{a_{{11}}} ^{5}\omega _{{3}}-3\, { a_{{1}}} ^{4}{a_{{11}}} ^{3}\omega _{{1}}\omega _{{2}}+2\, {a_{{11}}} ^{7}\omega _{{1}}\omega _{{2}}+6\, \Omega \, a_{{1}}a_{{8}}{a_{{11}}} ^{2}\omega _{{2} }\omega _{{3}}+3\, \Omega \, a_{{1}}a_{{8}}\omega _{{1}}{\omega _{{2}}} \ \ ^{2}\right) }{{a_{{11}}} ^{5}{\omega _{{2}}} ^{2}a_{{1}}} \ \ }+ \ \ {\frac{\left( -{a_{{ 1}}} ^{3}{a_{{11}}} ^{3}+\Omega \, a_{{8}}\omega _{{2}}\right) z}{{a_{{11}}} \ \ ^{3}\omega _{{2}}} \ \ }+a_{{5}}} \ \ }+ \end{equation}$

(4.15)

$\cosh \left( a_{{9}}t+ya_{{7}}+a_{{8}}z+a_{{10}}\right) +\cos \left( xa_{{11} }-\frac{1}{2}\, \ \ {\frac{\left( 2\, {a_{{11}}} ^{2}\omega _{{3}}+\omega _{{1} }\omega _{{2}}\right) a_{{11}}y}{{\omega _{{2}}} ^{2}}} \ \ + \ \ {\frac{{a_{{11}}} ^{3}z }{\omega _{{2}}} \ \ }+a_{{15}}\right) ,$

$\Omega = \sqrt{-{a_{{1}}} ^{6}-2\, {a_{{1}}} ^{4}{a_{{11}}} ^{2}+{a_{{11}}} ^{6}}.$

Incorporating (4.15) into (4.1) and (4.2), the soliton-periodic wave solution of Eq (1.8) will be received as below:

$\begin{eqnarray} \Psi _{5} & = &v_{{0}}+\frac{2}{\mathbf{f}}\left[ a_{{1}}{\mathrm{e}^{ \ \ {\frac{ \Omega \, a_{{9}}t}{{a_{{11}}} ^{3}}} \ \ +a_{{1}}x-\frac{1}{6}\, \ \ {\frac{y\left( -6\, {a_{{1}}} ^{4}{a_{{11}}} ^{5}\omega _{{3}}-3\, {a_{{1}}} ^{4}{a_{{11}}} \ \ ^{3}\omega _{{1}}\omega _{{2}}+2\, {a_{{11}}} ^{7}\omega _{{1}}\omega _{{2} }+6\, \Omega \, a_{{1}}a_{{8}}{a_{{11}}} ^{2}\omega _{{2}}\omega _{{3} }+3\, \Omega \, a_{{1}}a_{{8}}\omega _{{1}}{\omega _{{2}}} ^{2}\right) }{{a_{{11 }}} ^{5}{\omega _{{2}}} ^{2}a_{{1}}} \ \ }+ \ \ {\frac{\left( -{a_{{1}}} ^{3}{a_{{11}}} \ \ ^{3}+\Omega \, a_{{8}}\omega _{{2}}\right) z}{{a_{{11}}} ^{3}\omega _{{2}}} \ \ } +a_{{5}}} \ \ }\right. \\ &&\left. -\sin \left( xa_{{11}}-\frac{1}{2}\, \ \ {\frac{\left( 2\, {a_{{11}}} \ \ ^{2}\omega _{{3}}+\omega _{{1}}\omega _{{2}}\right) a_{{11}}y}{{\omega _{{2}} }^{2}}} \ \ + \ \ {\frac{{a_{{11}}} ^{3}z}{\omega _{{2}}} \ \ }+a_{{15}}\right) a_{{11}} \right] . \end{eqnarray}$

(4.16)

By selecting the specific amounts of parameters including

$\begin{eqnarray*} \alpha & = &0.5, a_{1} = 1, a_{4} = a_{9} = \omega _{1} = \omega _{3} = 1.5, , a_{5} = 2, a_{7} = 1.5, a_{8} = 2, \\ a_{10} & = &1, a_{11} = 2, a_{13} = 2.5, a_{14} = 1, a_{15} = 3.2, \omega _{2} = 1.2, \end{eqnarray*}$

the graphical display of soliton-periodic wave solution is offered in Figure 3 such as 3D chart, density chart, and 2D chart and below cases:

$(f3)\ y = 1, 2, 3, \ \ (f6)\ y = 1, 2, 3, \ and\ \ (f9)\ y = -1, -2, -3.$

Figure 3. The soliton-periodic solution (4.16) at (f1, f2)

$z = -2, t = -2$ , (f4, f5)

$z = 0, t = 0$ , and (f7, f8)

$z = 2, t = 2$ .

DownLoad: Full-Size Img PowerPoint

5. Novel cross-kink wave solutions

Three function containing exponential, hyperbolic, and triangular periodic waves for Eq (1.8) can be assumed as the following:

$\begin{equation} \mathbf{f} = \exp(\tau_1)+a_{16}\exp(-\tau_1)+\sinh(\tau_2)+\sin( \tau_3)+a_{17}, \ \ \ \tau_1 = \sum\limits_{i = 1}^{4}a_ix_i+a_5, \ \ \ \tau_2 = \sum\limits_{i = 6}^{9}a_ix_{i-5}+a_{10}, \end{equation}$

(5.1)

$\begin{equation} \tau_3 = \sum\limits_{i = 11}^{14}a_ix_{i-10}+a_{15}, \ \ (x_1, x_2, x_3, x_4) = (\mathbf{x} , t) = (x, y, z, t), \ \ \ \Psi(\mathbf{x}, t) = v_0+2\ln(\mathbf{f})_{x}, \end{equation}$

(5.2)

in which $a_{i}, i = 1, ..., 17$ are unfound values. Substituting (5.2) into Eq (1.8) the below consequences will be gained:

Case I:

$\begin{equation} \mathbf{f} = {\mathrm{e}^{a_{{4}}t+a_{{1}}x- \ \ {\frac{\left( a_{{3}}a_{{14} }\omega _{{3}}-a_{{4}}a_{{12}}\omega _{{2}}-a_{{4}}a_{{13}}\omega _{{3} }\right) y}{a_{{14}}\omega _{{2}}} \ \ }+a_{{3}}z+a_{{5}}} \ \ }+\sinh \left( a_{{9}}t- \ \ {\frac{\left( a_{{8}}a_{{14}}\omega _{{3}}-a_{{9}}a_{{12}}\omega _{{2}}-a_{{9 }}a_{{13}}\omega _{{3}}\right) y}{a_{{14}}\omega _{{2}}} \ \ }+a_{{8}}z+a_{{10} }\right) \end{equation}$

(5.3)

$+\sin \left( ta_{{14}}+ya_{{12}}+za_{{13}}+a_{{15}}\right) .$

Substituting (5.3) into (5.1) and (5.2), the cross-kink solution of Eq (1.8) will be gained as the following:

$\begin{equation} \Psi _{1} = v_{{0}}+\frac{2a_{{1}}{\mathrm{e}^{a_{{4}}t+a_{{1}}x- \ \ {\frac{\left( a_{{3}}a_{{14}}\omega _{{3}}-a_{{4}}a_{{12}}\omega _{{2}}-a_{{4}}a_{{13} }\omega _{{3}}\right) y}{a_{{14}}\omega _{{2}}} \ \ }+a_{{3}}z+a_{{5}}} \ \ }}{\mathbf{ f}}. \end{equation}$

(5.4)

By selecting the suitable values of parameters including

$\begin{eqnarray*} a_{1} & = &1, a_{3} = 3, a_{4} = 2, a_{5} = 1.5, a_{8} = 1.7, a_{9} = 1.5, a_{10} = 1.5, \\ a_{12} & = &2.5, a_{13} = 1.1, a_{14} = 2.1, a_{15} = 3.2, \omega _{2} = 1, \omega _{3} = 1.5, \end{eqnarray*}$

the graphical representation of cross-kink wave solution is offered in Figure 4 such 3D plot and density plot.

Figure 4. The cross-kink wave solution (5.4) at (f1, f2)

$x = 3, y = 2$ , (f3, f4)

$x = 0, y = 2$ , and (f5, f6)

$x = -3, y = 2$ .

DownLoad: Full-Size Img PowerPoint

Case II:

$\begin{equation} \mathbf{f} = {\mathrm{e}^{a_{{4}}t+a_{{1}}x+a_{{2}}y- \ \ {\frac{\left( {a_{{1}}} \ \ ^{3}a_{{14}}-a_{{4}}a_{{13}}\omega _{{2}}\right) z}{a_{{14}}\omega _{{2}}} \ \ } +a_{{5}}} \ \ }+\sinh \left( a_{{9}}t+a_{{7}}y+ \ \ {\frac{a_{{9}}a_{{13}}z}{a_{{14}}} \ \ } +a_{{10}}\right) +\sin \left( ta_{{14}}+ya_{{12}}+za_{{13}}+a_{{15}}\right) . \end{equation}$

(5.5)

Putting (5.5) into (5.1) and (5.2), the cross-kink solution of Eq (1.8) will be received as the following:

$\begin{equation} \Psi _{2} = v_{{0}}+\frac{2a_{{1}}{\mathrm{e}^{a_{{4}}t+a_{{1}}x+a_{{2}}y-{ \frac{\left( {a_{{1}}} ^{3}a_{{14}}-a_{{4}}a_{{13}}\omega _{{2}}\right) z}{a_{ {14}}\omega _{{2}}} \ \ }+a_{{5}}} \ \ }}{\mathbf{f}}. \end{equation}$

(5.6)

By selecting the suitable values of parameters including

the graphical exhibition of cross-kink solution is offered in Figure 5 such as 3D chart and density chart.

Figure 5. The cross-kink wave solution (5.6) at (f1, f2)

$x = 3, y = 2$ , (f3, f4)

$x = 0, y = 2$ , and (f5, f6)

$x = -3, y = 2$ .

DownLoad: Full-Size Img PowerPoint

Case III:

$\begin{equation} \mathbf{f} = {\mathrm{e}^{a_{{4}}t+a_{{1}}x- \ \ {\frac { \left( a_{{3}}\omega_{{3} }+a_{{4} }\lambda_{{3}} \right) y}{\omega_{{2}}} \ \ }+a_{{3}}z+a_{{5}}} \ \ }+\sinh \left( a_{{9}}t- \ \ {\frac { \left( a_{{8}}\omega_{{3}}+a_{{9}}\lambda_{{\ 3}} \right) y}{\omega_{{2}}} \ \ }+a_{{8}}z+a_{{10}} \right) +\sin \left( - \ \ {\frac { a_{{13}}\omega_{{3}}y}{\omega_{{2}}} \ \ }+a_{{13}}z+a_{{15}} \right). \end{equation}$

(5.7)

Plugging (5.7) into (5.1) and (5.2), the cross-kink solution of Eq (1.8) will be obtained as the following:

$\begin{equation} \Psi_3 = v_{{0}}+\frac{2a_{{1}}{\mathrm{e}^{a_{{4}}t+a_{{1}}x- \ \ {\frac { \left( a_{{3}}\omega_{{3}} +a_{{4}}\lambda_{{3}} \right) y}{\omega_{{2}}} \ \ }+a_{{3} }z+a_{{5}}} \ \ } }{\mathbf{f}} . \end{equation}$

(5.8)

Case IV:

$\begin{eqnarray} \mathbf{f} & = &{\mathrm{e}^{- \ \ {\frac{a_{{9}}\left( {a_{{11}}} ^{2}\left( \omega _{{3}}{a_{{1}}} ^{2}-\omega _{{1}}\omega _{{2}}\right) \left( {a_{{1}}} \ \ ^{3}+a_{{3}}\omega _{{2}}\right) -{a_{{1}}} ^{5}\omega _{{1}}\omega _{{2} }\right) t}{{a_{{1}}} ^{2}a_{{7}}{a_{{11}}} ^{2}{\omega _{{2}}} ^{2}}} \ \ +a_{{1}}x- \ \ {\frac{a_{{3}}\left( \omega _{{3}}{a_{{1}}} ^{2}-\omega _{{1}}\omega _{{2} }\right) y}{{a_{{1}}} ^{2}\omega _{{2}}} \ \ }+a_{{3}}z+a_{{5}}} \ \ }+\sin \left( xa_{{ 11}}+a_{{15}}\right) \\ &&+\sinh \left( a_{{9}}t+a_{{7}}y- \ \ {\frac{\left( {a_{{1}}} ^{3}+a_{{3}}\omega _{{2}}\right) {a_{{1}}} ^{2}a_{{7}}{a_{{11}}} ^{2}\omega _{{2}}z}{{a_{{11}}} \ \ ^{2}\left( \omega _{{3}}{a_{{1}}} ^{2}-\omega _{{1}}\omega _{{2}}\right) \left( {a_{{1}}} ^{3}+a_{{3}}\omega _{{2}}\right) -{a_{{1}}} ^{5}\omega _{{1} }\omega _{{2}}} \ \ }+a_{{10}}\right) . \end{eqnarray}$

(5.9)

Inserting (5.9) into (5.1) and (5.2), the cross-kink solution of Eq (1.8) will be gained as the following:

$\begin{equation} \Psi _{4} = v_{{0}}+2\frac{a_{{1}}{\mathrm{e}^{- \ \ {\frac{a_{{9}}\left( {a_{{11}}} \ \ ^{2}\left( \omega _{{3}}{a_{{1}}} ^{2}-\omega _{{1}}\omega _{{2}}\right) \left( {a_{{1}}} ^{3}+a_{{3}}\omega _{{2}}\right) -{a_{{1}}} ^{5}\omega _{{1} }\omega _{{2}}\right) t}{{a_{{1}}} ^{2}a_{{7}}{a_{{11}}} ^{2}{\omega _{{2}}} \ \ ^{2}}} \ \ +a_{{1}}x- \ \ {\frac{a_{{3}}\left( \omega _{{3}}{a_{{1}}} ^{2}-\omega _{{1} }\omega _{{2}}\right) y}{{a_{{1}}} ^{2}\omega _{{2}}} \ \ }+a_{{3}}z+a_{{5}}} \ \ } +\cos \left( xa_{{11}}+a_{{15}}\right) a_{{11}}} \ \ {\mathbf{f}}. \end{equation}$

(5.10)

Case V:

$\begin{equation} \mathbf{f} = {\mathrm{e}^{a_{{4}}t+a_{{2}}y+ \ \ {\frac{a_{{4}}a_{{8}}z}{a_{{9}}} \ \ } +a_{{5}}} \ \ }+\sinh \left( a_{{9}}t+a_{{7}}y+a_{{8}}z+a_{{10}}\right) +\sin \left( xa_{{11}}- \ \ {\frac{a_{{11}}\left( {a_{{11}}} ^{2}\omega _{{3}}+\omega _{{ 1}}\omega _{{2}}\right) y}{{\omega _{{2}}} ^{2}}} \ \ + \ \ {\frac{{a_{{11}}} ^{3}z}{ \omega _{{2}}} \ \ }+a_{{15}}\right) . \end{equation}$

(5.11)

Substituting (5.11) into (5.1) and (5.2), the cross-kink solution of Eq (1.8) will be received as the following:

$\begin{equation} \Psi _{5} = v_{{0}}+\frac{2\cos \left( xa_{{11}}- \ \ {\frac{a_{{11}}\left( {a_{{11} }}^{2}\omega _{{3}}+\omega _{{1}}\omega _{{2}}\right) y}{{\omega _{{2}}} ^{2}} }+ \ \ {\frac{{a_{{11}}} ^{3}z}{\omega _{{2}}} \ \ }+a_{{15}}\right) a_{{11}}} \ \ {\mathbf{f }}. \end{equation}$

(5.12)

By selecting the suitable values of parameters including

the graphical exhibition of cross-kink solution is offered in Figure 6 such as 3D chart and density chart.

Figure 6. The cross-kink wave solution (5.6) at (f1, f2)

$x = 3, y = 2$ , (f3, f4)

$x = 0, y = 2$ , and (f5, f6)

$x = -3, y = 2$ .

DownLoad: Full-Size Img PowerPoint

Case VI:

$\begin{eqnarray} \mathbf{f} & = &{\mathrm{e}^{ \ \ {\frac{\Omega \, a_{{9}}t}{{a_{{11}}} ^{3}}} \ \ +a_{{1} }x-\frac{1}{12} \ \ {\frac{\left( 3\, \Omega \, a_{{1}}a_{{8}}\omega _{{2}}\left( 4\, {a_{{11}}} ^{2}\omega _{{3}}+3\, \omega _{{1}}\omega _{{2}}\right) -12\, {a_{ {1}}} ^{4}{a_{{11}}} ^{5}\omega _{{3}}-{a_{{11}}} ^{3}\omega _{{1}}\omega _{{2} }\left( 9\, {a_{{1}}} ^{4}-2\, {a_{{11}}} ^{2}{a_{{1}}} ^{2}-2\, {a_{{11}}} \ \ ^{4}\right) \right) y}{{a_{{11}}} ^{5}{\omega _{{2}}} ^{2}a_{{1}}} \ \ } + \ \ {\frac{ \left( -{a_{{1}}} ^{3}{a_{{11}}} ^{3}+\Omega \, a_{{8}}\omega _{{2}}\right) z}{ \omega _{{2}}{a_{{11}}} ^{3}}} \ \ +a_{{5}}} \ \ } \\ &&\sinh \left( a_{{9}}t+a_7y+a_{{8}}z+a_{{10}}\right) +\sin \left( xa_{{ 11}} \! - \! \frac{1}{12} \ \ {\frac{a_{11}\left( 12{a_{{11}}} ^{2}\omega _{{3} } \! + \! 7\, \omega _1\omega _2\right) y}{{\omega _{{2}}} ^{2}}} \ \ + \ \ {\frac{a_{11}^3z}\omega _2} \! + \! a_{15}\right), \end{eqnarray}$

(5.13)

$\Omega = \sqrt{-3\, {a_{{1}}} ^{6}-4\, {a_{{1}}} ^{4}{a_{{11}}} ^{2}+{a_{{11}}} ^{6} }.$

Putting (5.13) into (5.1) and (5.2), the cross-kink solution of Eq (1.8) will be concluded as the following:

$\begin{eqnarray} \Psi _{5} & = &v_{{0}}+\frac{2}{\mathbf{f}}\left[ a_{{1}}{\mathrm{e}^{ \ \ {\frac{ \Omega \, a_{{9}}t}{{a_{{11}}} ^{3}}} \ \ +a_{{1}}x-\frac{1}{12} \ \ {\frac{\left( 3\, \Omega \, a_{{1}}a_{{8}}\omega _{{2}}\left( 4\, {a_{{11}}} ^{2}\omega _{{3} }+3\, \omega _{{1}}\omega _{{2}}\right) -12\, {a_{{1}}} ^{4}{a_{{11}}} \ \ ^{5}\omega _{{3}}-{a_{{11}}} ^{3}\omega _{{1}}\omega _{{2}}\left( 9\, {a_{{1}}} \ \ ^{4}-2\, {a_{{11}}} ^{2}{a_{{1}}} ^{2}-2\, {a_{{11}}} ^{4}\right) \right) y}{{a_{{ 11}}} ^{5}{\omega _{{2}}} ^{2}a_{{1}}} \ \ }+ \ \ {\frac{\left( -{a_{{1}}} ^{3}{a_{{11}}} \ \ ^{3}+\Omega \, a_{{8}}\omega _{{2}}\right) z}{\omega _{{2}}{a_{{11}}} ^{3}}} \ \ +a_{{5}}} \ \ }\right. \\ &&+\left. \cos \left( xa_{{11}}-\frac{1}{12} \ \ {\frac{a_{{11}}\left( 12\, {a_{{11} }}^{2}\omega _{{3}}+7\, \omega _{{1}}\omega _{{2}}\right) y}{{\omega _{{2}}} \ \ ^{2}}} \ \ + \ \ {\frac{{a_{{11}}} ^{3}z}{\omega _{{2}}} \ \ }+a_{{15}}\right) a_{{11}} \right] . \end{eqnarray}$

(5.14)

By selecting suitable values of parameters including

$\begin{eqnarray*} \alpha & = &0.5, a_{3} = 1, a_{4} = a_{9} = \omega _{1} = \omega _{3} = 1.5, a_{5} = 2, a_{8} = 2, \\ a_{10} & = &1, a_{11} = 2, a_{13} = 2.5, a_{14} = 1, a_{15} = 3.2, \omega _{2} = 1.2, \end{eqnarray*}$

the graphical representation of cross-kink solution is offered in Figure 7 such as 3D chart and density chart.

Figure 7. The cross-kink wave solution (5.14) at (f1, f2)

$x = -2, y = -2$ , (f3, f4)

$x = 0, y = 0$ , and (f5, f6)

$x = 2, y = 2$ .

DownLoad: Full-Size Img PowerPoint

Case VII:

$\begin{eqnarray} \mathbf{f} & = &{\mathrm{e}^{ \ \ {\frac{\Omega a_{{9}}t}{{a_{{11}}} ^{3}}} \ \ +a_{{1} }x-\frac{1}{6}{\ \frac{y\left( -6{a_{{1}}} ^{4}{a_{{11}}} ^{5}\omega _{{3} }-3\, {a_{{1}}} ^{4}{a_{{11}}} ^{3}\omega _{{1}}\omega _{{2}}+2\, {a_{{11}}} \ \ ^{7}\omega _{{1}}\omega _{{2}}+6\, \Omega a_{{1}}a_{{8}}{a_{{11}}} \ \ ^{2}\omega _{{2}}\omega _{{3}}+3\, \Omega \, a_{{1}}a_{{8}}\omega _{{1}}{\ \omega _{{2}}} ^{2}\right) }{{a_{{11}}} ^{5}{\omega _{{2}}} ^{2}a_{{1}}} \ \ }+{\ \frac{\left( -{a_{{1}}} ^{3}{a_{{11}}} ^{3}+\Omega a_{{8}}\omega _{{2} }\right) z}{{a_{{11}}} ^{3}\omega _{{2}}} \ \ }+a_{{5}}} \ \ }+ \\ &&\cosh \left( a_{{9}}t+ya_{{7}}+a_{{8}}z+a_{{10}}\right) + \cos \left( xa_{{\ 11}}-\frac{1}{2} \ \ {\frac{\left( 2{a_{{11}}} ^{2}\omega _{{3}}+\omega _{{1} }\omega _{{2}}\right) a_{{11}}y}{{\omega _{{2}}} ^{2}}} \ \ + \ \ {\frac{{a_{{11}}} ^{3}z }{\omega _{{2}}} \ \ }+a_{{15}}\right), \end{eqnarray}$

(5.15)

$\Omega = \sqrt{-{a_{{1}}} ^{6}-2\, {a_{{1}}} ^{4}{a_{{11}}} ^{2}+{a_{{11}}} ^{6}}.$

Inserting (5.15) into (5.1) and (5.2), the cross-kink solution of Eq (1.8) will be gained as the following:

(5.16)

By selecting suitable values of parameters including

$\alpha = 0.5, a_1 = 1, a_5 = 1.5, a_8 = 2, a_9 = 0.5, a_{10} = 1.5, a_{15} = 3.2, \omega_1 = 1.5, \omega_2 = 1.2, \omega_3 = 1.5,$

the graphical representation of cross-kink solution is offered in Figure 8 such as 3D chart and density chart.

Figure 8. The lump-periodic solution (5.16) at (f1, f2)

$z = -2$ , (f4, f5)

$z = 0$ , and (f7, f8)

$z = 2$ .

DownLoad: Full-Size Img PowerPoint

6. Novel solitary wave solutions

Three function containing exponential, hyperbolic, and triangular periodic waves for Eq (1.8) can be assumed as the following:

$\begin{equation} \textbf{f} = \exp (\tau _{1})+a_{16}\exp (-\tau _{1})+\tanh (\tau _{2})+\tan (\tau _{3})+a_{17}, \ \ \ \tau _{1} = \sum\limits_{i = 1}^{4}a_{i}x_{i}+a_{5}, \ \ \ \tau _{2} = \sum\limits_{i = 6}^{9}a_{i}x_{i-5}+a_{10}, \ \ \ \end{equation}$

(6.1)

(6.2)

in which $a_{i}, i = 1, ..., 17$ are unfound values. Substituting (6.2) into Eq (1.8) the below consequences will be gained:

Case I:

$\begin{equation} \textbf{f} = {\mathrm{e}^{a_{{4}}t+a_{{1}}x+a_{{2}}y- \ \ {\frac{\left( {a_{{1}}} \ \ ^{3}+a_{{4}}\lambda _{{2}}\right) z}{\omega _{{2}}} \ \ }+a_{{5}}} \ \ }+\tanh \left( ya_{{7}}+a_{{10}}\right) +\tan \left( ya_{{12}}+a_{{15}}\right) +a_{{17}}. \end{equation}$

(6.3)

Substituting (6.3) into (6.1) and (6.2), we can capture a solitary wave solution of Eq (1.8) as the following:

$\begin{equation} \Psi _{1} = v_{{0}}+\frac{2\, a_{{1}}{\mathrm{e}^{a_{{4}}t+a_{{1}}x+a_{{2}}y-{ \frac{\left( {a_{{1}}} ^{3}+a_{{4}}\lambda _{{2}}\right) z}{\omega _{{2}}} \ \ } +a_{{5}}} \ \ }}{\mathbf{f}}. \end{equation}$

(6.4)

Case II:

$\begin{equation} \textbf{f} = {\mathrm{e}^{a_{{1}}x+a_{{2}}y- \ \ {\frac{{a_{{1}}} ^{3}z}{\omega _{{2} }}} \ \ +a_{{5}}} \ \ }+\tanh \left( ya_{{7}}+a_{{10}}\right) +\tan \left( ya_{{12} }+a_{{15}}\right) +a_{{17}}. \end{equation}$

(6.5)

Inserting (6.5) into (6.1) and (6.2), we can capture a solitary wave solution of Eq (1.8) as below:

$\begin{equation} \Psi _{2} = v_{{0}}+\frac{2\, a_{{1}}{\mathrm{e}^{a_{{1}}x+a_{{2}}y- \ \ {\frac{{a_{{ 1}}} ^{3}z}{\omega _{{2}}} \ \ }+a_{{5}}} \ \ }}{\mathbf{f}}. \end{equation}$

(6.6)

Case III:

$\begin{equation} \textbf{f} = {\mathrm{e}^{a_{{4}}t+a_{{1}}x+a_{{2}}y- \ \ {\frac{\left( {a_{{1}}} \ \ ^{3}\omega _{{3}}+a_{{4}}\lambda _{{3}}\omega _{{2}}\right) z}{\omega _{{2} }\omega _{{3}}} \ \ }+a_{{5}}} \ \ }+\tanh \left( ta_{{9}}+ya_{{7}}- \ \ {\frac{za_{{9} }\lambda _{{3}}} \ \ {\omega _{{3}}} \ \ }+a_{{10}}\right) +\tan \left( ya_{{12}}+a_{{ 15}}\right) +a_{{17}}. \end{equation}$

(6.7)

Putting (6.7) into (6.1) and (6.2), the solitary wave solution of Eq (1.8) can be indicated as below:

$\begin{equation} \Psi _{3} = v_{{0}}+\frac{2\, a_{{1}}{\mathrm{e}^{a_{{4}}t+a_{{1}}x+a_{{2}}y-{ \frac{\left( {a_{{1}}} ^{3}\omega _{{3}}+a_{{4}}\lambda _{{3}}\omega _{{2} }\right) z}{\omega _{{2}}\omega _{{3}}} \ \ }+a_{{5}}} \ \ }}{\mathbf{f}}. \end{equation}$

(6.8)

Case IV:

$\begin{equation} \textbf{f} = {\mathrm{e}^{a_{{4}}t+a_{{1}}x+a_{{2}}y+za_{{3}}+a_{{5}}} \ \ }-\tanh \left( \ \ {\frac{ya_{{8}}\omega _{{3}}} \ \ {\omega _{{2}}} \ \ }-za_{{8}}-a_{{10} }\right) -\tan \left( \ \ {\frac{ya_{{13}}\omega _{{3}}} \ \ {\omega _{{2}}} \ \ }-a_{{13} }z-a_{{15}}\right) +a_{{17}}. \end{equation}$

(6.9)

Putting (6.9) into (6.1) and (6.2), the solitary wave of Eq (1.8) can be stated as the following:

$\begin{equation} \Psi _{4} = v_{{0}}+\frac{2\, a_{{1}}{\mathrm{e}^{a_{{4}}t+a_{{1}}x+a_{{2} }y+za_{{3}}+a_{{5}}} \ \ }}{\mathbf{f}}. \end{equation}$

(6.10)

By selecting the suitable values of parameters including

$\begin{eqnarray*} a_{1} & = &1, a_{2} = 1.5, a_{3} = 2, a_{4} = 2, a_{5} = 1.5, a_{8} = 2, a_{9} = 1.5, a_{10} = 1.5, \\ a_{13} & = &2, a_{13} = 1.1, a_{15} = 3.2, a_{17} = 2, \omega _{2} = -1.5, \end{eqnarray*}$

$\omega _{3} = 1.2, \lambda _{2} = 1, \lambda _{3} = 1.5, x = -2, t = 2,$

with the following components

$\begin{eqnarray*} \alpha & = & \ \ {\frac{{a_{{1}}} ^{3}\omega _{{3}}-a_{{1}}\omega _{{1}}\omega _{{2} }-a_{{2}}{\omega _{{2}}} ^{2}-a_{{3}}\omega _{{2}}\omega _{{3}}+a_{{4} }\lambda _{{2}}\omega _{{3}}-a_{{4}}\lambda _{{3}}\omega _{{2}}} \ \ {\omega _{{2} }{a_{{1}}} ^{3}}} \ \ , \ \ \\ \lambda _{{1}} & = &- \ \ {\frac{{a_{{1}}} ^{3}a_{{2}}\omega _{{2}}+{a_{{1}}} ^{3}a_{{ 3}}\omega _{{3}}+a_{{2}}a_{{4}}\lambda _{{2}}\omega _{{2}}+a_{{3}}a_{{4} }\lambda _{{2}}\omega _{{3}}} \ \ {a_{{1}}a_{{4}}\omega _{{2}}} }, \end{eqnarray*}$

the graphical representation of rational solitary solution is offered in Figure 9 such as 3D chart and density chart.

Figure 9. The rational solitary wave solution (6.10) at (f1)

$z = 0$ , (f2)

$z = 1$ , and (f3)

$z = 3$ .

DownLoad: Full-Size Img PowerPoint

Case V:

$\begin{equation} \ f = {\mathrm{e}^{a_{{1}}x- \ \ {\frac{a_{{3}}\omega _{{3}}y}{\omega _{{2}}} \ \ }+za_{{3}}+a_{{5}}} \ \ }-\tanh \left( \ \ {\frac{ya_{{8}}\omega _{{3}}} \ \ {\omega _{{2}} }}-za_{{8}}-a_{{10}}\right) -\tan \left( \ \ {\frac{ya_{{13}}\omega _{{3}}} \ \ { \omega _{{2}}} \ \ }-a_{{13}}z-a_{{15}}\right) +a_{{17}}. \end{equation}$

(6.11)

Incorporating (6.11) into (6.1) and (6.2), the solitary solution of Eq (1.8) will be gained as below:

$\begin{equation} \Psi _{5} = v_{{0}}+\frac{2\, a_{{1}}{\mathrm{e}^{a_{{1}}x- \ \ {\frac{a_{{3}}\omega _{{3}}y}{\omega _{{2}}} \ \ }+za_{{3}}+a_{{5}}} \ \ }}{\mathbf{f}}, \ \ \alpha = \ \ {\frac{{ a_{{1}}} ^{2}\omega _{{3}}-\omega _{{1}}\omega _{{2}}} \ \ {{a_{{1}}} ^{2}\omega _{{ 2}}} \ \ }. \end{equation}$

(6.12)

Case VI:

$\begin{equation} \mathbf{f} = {\mathrm{e}^{a_{{4}}t+a_{{1}}x- \ \ {\frac{\left( a_{{3}}\omega _{{3} }+a_{{4}}\lambda _{{3}}\right) y}{\omega _{{2}}} \ \ }+za_{{3}}+a_{{5}}} \ \ }+\tanh \left( ta_{{9}}- \ \ {\frac{y\left( a_{{8}}\omega _{{3}}+a_{{9}}\lambda _{{3} }\right) }{\omega _{{2}}} \ \ }+za_{{8}}+a_{{10}}\right) -\tan \left( {\ \frac{ ya_{{13}}\omega _{{3}}} \ \ {\omega _{{2}}} \ \ }-a_{{13}}z-a_{{15}}\right) +a_{{17}}. \end{equation}$

(6.13)

Appending (6.13) into (6.1) and (6.2), the solitary solution of Eq (1.8) can be written as the following:

$\begin{equation} \Psi _{6} = v_{{0}}+\frac{2\, a_{{1}}{\mathrm{e}^{a_{{4}}t+a_{{1}}x- \ \ {\frac{ \left( a_{{3}}\omega _{{\ 3}}+a_{{4}}\lambda _{{3}}\right) y}{\omega _{{2}}} \ \ } +za_{{3}}+a_{{5}}} \ \ }}{\mathbf{f}}, \ \ \alpha = \ \ {\frac{{a_{{1}}} ^{2}\omega _{{3} }-\omega _{{1}}\omega _{{2}}} \ \ {{a_{{1}}} ^{2}\omega _{{2}}} \ \ }. \end{equation}$

(6.14)

Case VII:

$\begin{equation} \mathbf{f} = {\mathrm{e}^{a_{{4}}t+a_{{1}}x- \ \ {\frac{a_{{3}}\omega _{{3}}y}{ \omega _{{2}}} \ \ }+za_{{3}}+a_{{5}}} \ \ }+\tanh \left( ta_{{9}}- \ \ {\frac{ya_{{8} }\omega _{{3}}} \ \ {\omega _{{2}}} \ \ }+za_{{8}}+a_{{10}}\right) -\tan \left( \ \ {\frac{ ya_{{13}}\omega _{{3}}} \ \ {\omega _{{2}}} \ \ }-a_{{13}}z-a_{{15}}\right) +a_{{17}}. \end{equation}$

(6.15)

Appending (6.15) into (6.1) and (6.2), the solitary solution of Eq (1.8) will be obtained as below:

$\begin{equation} \Psi _{7} = v_{{0}}+\frac{2\, a_{{1}}{\mathrm{e}^{a_{{4}}t+a_{{1}}x- \ \ {\frac{a_{{3 }}\omega _{{3}}y}{\omega _{{2}}} \ \ }+za_{{3}}+a_{{5}}} \ \ }}{\mathbf{f}}, \ \ \alpha = \ \ {\frac{{a_{{1}}} ^{2}\omega _{{3}}-\omega _{{1}}\omega _{{2}}} \ \ {{a_{{1}}} \ \ ^{2}\omega _{{2}}} }, \ \ \lambda _{{2}} = \ \ {\frac{\lambda _{{3}}\omega _{{2}}} \ \ { \omega _{{3}}} \ \ }. \end{equation}$

(6.16)

By choosing the specific amounts of parameters including

$\begin{eqnarray*} a_{1} & = &1, a_{2} = 1.5, a_{3} = 2, a_{4} = 2, a_{5} = 1.5, a_{8} = 2, a_{9} = 1.3, a_{10} = 1.5, \\ a_{13} & = &2, a_{13} = 2, a_{15} = 3.2, a_{17} = 2, \omega _{2} = -1.5, \\ \omega _{3} & = &1.2, \lambda _{2} = 1, \lambda _{3} = 1.5, x = -2, t = 2, \end{eqnarray*}$

the graphical representation of rational solitary solution is offered in Figure 10 such as 3D chart and density chart.

Figure 10. The rational solitary wave solution (6.16) at (f1)

$z = 0$ , (f2)

$z = 1$ , and (f3)

$z = 3$ .

DownLoad: Full-Size Img PowerPoint

Case VIII:

$\begin{equation} \mathbf{f} = {\mathrm{e}^{a_{{4}}t+a_{{1}}x+a_{{2}}y- \ \ {\frac { \left( {a_{{1}}} \ \ ^{3}a_{{\ 14}}-a_{{4}}a_{{13}}\omega_{{2}} \right) z}{a_{{14}}\omega_{{2}}} \ \ } +a_{ {5}}} \ \ }+\tanh \left( ta_{{9}}+ya_{{7}}+ \ \ {\frac {za_{{9}}a_{{13}}} \ \ {a_{{14 } }}} \ \ +a_{{10}} \right) +\tan \left( ta_{{14}}+ya_{{12}}+a_{{13}}z+a_{{\ 15}} \right) +a_{{17}} . \end{equation}$

(6.17)

Incorporating (6.17) into (6.1) and (6.2), the solitary solution of Eq (1.8) will be received as below:

$\begin{equation} \Psi_8 = v_{{0}}+\frac{2\, a_{{1}}{\mathrm{e}^{a_{{4}}t+a_{{1}}x+a_{{2}}y-{ \frac { \left( {a_{{1} }}^{3}a_{{14}}-a_{{4}}a_{{13}}\omega_{{2}} \right) z}{ a_{{14}}\omega_{ {2}}} \ \ }+a_{{5}}} \ \ } }{\mathbf{f}}, \ \ \alpha = \ \ {\frac {{a_{{1}}} \ \ ^{2}\omega_{{3}}-\omega_{{1}}\omega_{{2}}} \ \ {{a_ {{1}}} ^{2}\omega_{{2}}} }, \ \ \lambda_{{2}} = - \ \ {\frac {a_{{13}}\omega_{{2}}} \ \ {a_{{14}}} }, \ \ \lambda_{{3}} = -{ \frac {a_{{13}}\omega_{{3}}} \ \ {a_{{14}}} \ \ }. \end{equation}$

(6.18)

Case IX:

$\begin{eqnarray} \mathbf{f} & = &{\mathrm{e}^{a_{{4}}t+a_{{1}}x- \ \ {\frac{\left( a_{{3}}a_{{14} }\omega _{{3}}-a_{{4}}a_{{12}}\omega _{{2}}-a_{{4}}a_{{13}}\omega _{{3} }\right) y}{a_{{14}}\omega _{{2}}} \ \ }+a_{{3}}z+a_{{5}}} \ \ } \end{eqnarray}$

(6.19)

$\begin{eqnarray} &&+\tanh \left( ta_{{9}}- \ \ {\frac{y\left( a_{{8}}a_{{14}}\omega _{{3}}-a_{{9}}a_{{12}}\omega _{{2}}-a_{{ \ 9}}a_{{13}}\omega _{{3}}\right) }{a_{{14}}\omega _{{2}}} \ \ }+za_{{8}}+a_{{\ 10 }}\right) \end{eqnarray}$

(6.20)

$\begin{eqnarray} &&+\tan \left( ta_{{14}}+ya_{{12}}+za_{{13}}+a_{{15}}\right) +a_{{17}}. \end{eqnarray}$

(6.21)

Appending (6.21) into (6.1) and (6.2), the solitary solution of Eq (1.8) can be reached as below:

$\begin{equation} \Psi _{9} = v_{{0}}+\frac{2a_{{1}}{\mathrm{e}^{a_{{4}}t+a_{{1}}x- \ \ {\frac{\left( a_{{3}}a_{{14}}\omega _{{3}}-a_{{4}}a_{{12}}\omega _{{2}}-a_{{4}}a_{{13} }\omega _{{3}}\right) y}{a_{{14}}\omega _{{2}}} \ \ }+a_{{3}}z+a_{{5}}} \ \ }}{\mathbf{ f}}, \ \alpha = \ \ {\frac{{a_{{1}}} ^{2}\omega _{{3}}-\omega _{{1}}\omega _{{2}}} \ \ {{ a_{{1}}} ^{2}\omega _{{2}}} }, \ \end{equation}$

(6.22)

$\lambda _{{1}} = - \ \ {\frac{{a_{{1}}} ^{2}\left( a_{{12}}\omega _{{2}}+a_{{\ 13} }\omega _{{3}}\right) }{a_{{14}}\omega _{{2}}} }, \ \lambda _{{3}} = - \ \ {\frac{a_{{ 12}}\omega _{{2}}+a_{{13}}\omega _{{3}}} \ \ {a_{{\ 14}}} \ \ }.$

Case X:

$\begin{equation} \mathbf{f} = {\mathrm{e}^{a_{{4}}t+a_{{1}}x- \ \ {\frac {a_{{3}}\omega_{{3}}y}{ \omega_{{2}} }}+a_{{3}}z+a_{{5}}} \ \ }+\tanh \left( - \ \ {\frac {ya_{{8}}\omega_{{3}} }{ \omega_{{2}}} \ \ }+za_{{8}}+a_{{10}} \right) +\tan \left( ta_{{14}}-{\ \frac { ya_{{13}}\omega_{{3}}} \ \ {\omega_{{2}}} \ \ }+za_{{13}}+a_{{15}} \right) +a_{{17}}. \end{equation}$

(6.23)

Inserting (6.21) into (6.1) and (6.2), the solitary solution of Eq (1.8) will be gained as below form:

$\begin{equation} \Psi_{10} = v_{{0}}+\frac{2\, a_{{1}}{\mathrm{e}^{a_{{4}}t+a_{{1}}x- \ \ {\frac {a_{{ 3}}\omega_{{3}}y}{ \omega_{{2}}} \ \ }+a_{{3}}z+a_{{5}}} \ \ } }{\mathbf{f}}, \ \alpha = { \frac {{a_{{1}}} ^{2}\omega_{{3}}-\omega_{{1}}\omega_{{2}}} \ \ {{a_ {{1}}} \ \ ^{2}\omega_{{2}}} \ \ } , \ \lambda_{{2}} = \ \ {\frac {\lambda_{{3}}\omega_{{2}}} \ \ { \omega_{{3}}} \ \ }. \end{equation}$

(6.24)

By choosing the specific amounts of parameters including

$\begin{eqnarray*} a_{1} & = &1, a_{3} = 1.5, a_{4} = 2, a_{5} = 1.5, a_{7} = 2, a_{8} = 2, a_{9} = 2.1, \\ a_{10} & = &1.5, a_{13} = 2, a_{13} = 2, a_{14} = 2.5, a_{15} = 3.2, \\ a_{17} & = &2, \omega _{2} = -1.5, \omega _{3} = 1.2, \lambda _{3} = 1.5, x = -2, t = 2, \end{eqnarray*}$

the graphical representation of rational solitary solution is offered in Figure 11 such as 3D chart and density chart.

Figure 11. The rational solitary wave solution (6.24) at (f1)

$z = -2$ , (f2)

$z = 0$ , and (f3)

$z = 2$ .

DownLoad: Full-Size Img PowerPoint

Case XI:

$\begin{equation} \mathbf{f} = {\mathrm{e}^{a_{{4}}t+a_{{1}}x+a_{{2}}y- \ \ {\frac{\left( {a_{{1}}} \ \ ^{3}a_{{\ 14}}-a_{{4}}a_{{13}}\omega _{{2}}\right) z}{a_{{14}}\omega _{{2}}} \ \ } +a_{{5}}} \ \ }+\tanh \left( \ \ {\frac{ta_{{14}}a_{{8}}} \ \ {a_{{13}}} \ \ }+ya_{{7}}+za_{{8} }+a_{{10}}\right) +\tan \left( ta_{{14}}+za_{{13}}+a_{{15}}\right) +a_{{17}}. \end{equation}$

(6.25)

Inserting (6.25) into (6.1) and (6.2), the solitary solution of Eq (1.8) can be stated as below case:

$\begin{equation} \Psi _{11} = v_{{0}}+\frac{2a_{{1}}{\mathrm{e}^{a_{{4}}t+a_{{1}}x+a_{{2}}y-{ \frac{\left( {a_{{1}}} ^{3}a_{{14}}-a_{{4}}a_{{13}}\omega _{{2}}\right) z}{a_{ {14}}\omega _{{2}}} \ \ }+a_{{5}}} \ \ }}{\mathbf{f}}, \ \alpha = - \ \ {\frac{{a_{{1}}} \ \ ^{3}a_{{2}}+a_{{1}}a_{{3}}\omega _{{1}}+a_{{2}}a_{{3}}\omega _{{2}}+{a_{{3}}} \ \ ^{2}\omega _{{3}}} \ \ {{a_{{1}}} ^{3}a_{{3}}} }, \end{equation}$

(6.26)

$\begin{eqnarray*} \lambda _{{1}} & = & \ \ {\frac{{a_{{1}}} ^{3}a_{{2}}a_{{12}}a_{{13}}-{a_{{1}}} \ \ ^{3}a_{{3}}{a_{{12}}} ^{2}+a_{{2}}a_{{3}}a_{{12}}a_{{13}}\omega _{{2}}+a_{{2} }a_{{3}}{a_{{13}}} ^{2}\omega _{{3}}+a_{{2}}a_{{3}}a_{{13}}a_{{14}}\lambda _{{ 3}}} \ \ {a_{{3}}a_{{12}}a_{{1}}a_{{14}}} \ \ } \\ &&+\frac{-{a_{{3}}} ^{2}{a_{{12}}} ^{2}\omega _{{2}}-{a_{{3}}} ^{2}a_{{12}}a_{{ 13}}\omega _{{3}}-{a_{{3}}} ^{2}a_{{12}}a_{{14}}\lambda _{{3}}} \ \ {a_{{3}}a_{{12} }a_{{1}}a_{{14}}} \ \ , \end{eqnarray*}$

$\lambda _{{2}} = - \ \ {\frac{a_{{13}}\left( a_{{12}}\omega _{{2}}+a_{{13}}\omega _{ {3}}+a_{{14}}\lambda _{{3}}\right) }{a_{{12}}a_{{14}}} \ \ }.$

Case XII:

$\begin{equation} \mathbf{f} = {\mathrm{e}^{a_{{4}}t+a_{{1}}x- \ \ {\frac{a_{{3}}\omega _{{3}}y}{ \omega _{{2}}} \ \ }+a_{{3}}z+a_{{5}}} \ \ }+\tanh \left( ta_{{9}}+ya_{{7}}- \ \ {\frac{za_{ {7}}\omega _{{2}}} \ \ {\omega _{{3}}} \ \ }+a_{{10}}\right) +\tan \left( ta_{{14}}-{\ \frac{ya_{{13}}\omega _{{3}}} \ \ {\omega _{{2}}} \ \ }+za_{{13}}+a_{{15}}\right) +a_{{ 17}}. \end{equation}$

(6.27)

Inserting (6.27) into (6.1) and (6.2), the solitary solution of Eq (1.8) will be gained as below form:

$\begin{equation} \Psi _{12} = v_{{0}}+\frac{2a_{{1}}{\mathrm{e}^{a_{{4}}t+a_{{1}}x- \ \ {\frac{a_{{3} }\omega _{{3}}y}{\omega _{{2}}} \ \ }+a_{{3}}z+a_{{5}}} \ \ }}{\mathbf{f}}, \ \alpha = -{ \frac{{a_{{1}}} ^{3}a_{{2}}+a_{{1}}a_{{3}}\omega _{{1}}+a_{{2}}a_{{3}}\omega _{{2}}+{a_{{3}}} ^{2}\omega _{{3}}} \ \ {{a_{{1}}} ^{3}a_{{3}}} }, \end{equation}$

(6.28)

$\lambda _{{2}} = - \ \ {\frac{a_{{13}}\left( a_{{12}}\omega _{{2}}+a_{{13}}\omega _{ {3}}+a_{{14}}\lambda _{{3}}\right) }{a_{{12}}a_{{14}}} \ \ }.$

7. Stability analysis of Eq (1.8)

In the current section, we will analyze the continuous modulational instability of the nonlinear generalized KP equation. In addition, the feasibility of the localized waves in the present system is certified by linear stability analysis. First, we search the perturbed solution for the giving Eq (1.8) of the form

$\begin{equation} \Psi(x, y, z, t) = \zeta+\delta\ \Theta, \end{equation}$

(7.1)

where $\Theta = \Theta(x, y, z, t)$ and $\zeta$ is a steady state solution. Inserting (7.1) into Eq (1.8), become

$\begin{equation} \delta\, \ \ {\frac {\partial ^{4}}{\partial {x}^{3}\partial y}}\Theta +\alpha\, \delta\, \ \ {\frac {\partial ^{4}}{\partial {x}^{3} \partial z}}\Theta +3\, {\delta}^{2} \left( \ \ {\frac { \partial ^{2}}{\partial {x}^{2}}} \ \ \Theta \right) {\ \frac {\partial }{\partial y}}\Theta + 3\, {\delta}^{2 } \left( { \frac {\partial }{\partial x}}\Theta \right) \ \ {\frac {\partial ^{2}}{\partial x\partial y}}\Theta +3\, \alpha\, {\delta}^{2} \left( \ \ {\frac {\partial ^{2}}{ \partial {x}^{2}}} \ \ \Theta \right) \ \ {\frac {\partial } {\partial z}}\Theta + \end{equation}$

(7.2)

$3\, \alpha\, {\delta}^{2} \left( \ \ {\frac {\partial }{\partial x}}\Theta \right) {\ \frac {\partial ^{2}}{\partial x\partial z}}\Theta + \lambda_{{1}}\delta\, \ \ {\frac {\partial ^{2}}{\partial t\partial x}}\Theta +\lambda_{{2}}\delta\, { \frac {\partial ^{2}}{ \partial t\partial y}}\Theta + \lambda_{{3}}\delta\, { \ \frac {\partial ^{2}}{\partial t\partial z}}\Theta + \omega_{{1}}\delta\, { \frac {\partial ^{2}}{\partial x\partial z}}\Theta +\omega_{{2}}\delta\, { \frac {\partial ^{2}}{ \partial y\partial z}}\Theta +\omega_{{3}}\delta\, {\ \frac {\partial ^{2}}{\partial {z}^{2}}} \ \ \Theta = 0,$

by linerization Eq (7.2), one gets

$\begin{equation} \delta \ \ {\frac {\partial ^{4}}{\partial {x}^{3}\partial y}}\Theta +\alpha\delta \ \ {\frac {\partial ^{4}}{\partial {x}^{3} \partial z}}\Theta +\lambda_{{1} }\delta \ \ {\frac { \partial ^{2}}{\partial t\partial x}}\Theta + \lambda _{{2} }\delta \ \ {\frac {\partial ^{2}}{\partial t\partial y}}\Theta +\lambda_{{3} }\delta \ \ {\frac {\partial ^{2}}{\partial t \partial z}}\Theta +\omega_{{1} }\delta \ \ {\frac { \partial ^{2}}{\partial x\partial z}}\Theta +\omega_ {{2} }\delta \ \ {\frac {\partial ^{2}}{\partial y\partial z}}\Theta +\omega_{{3} }\delta \ \ {\frac {\partial ^{2}}{\partial {z}^ {2}}} \ \ \Theta = 0. \end{equation}$

(7.3)

Theorem 7.1. Assume that the solution of Eq (7.3) has the following case as

$\begin{equation} \Theta(x, y, z, t) = \rho_1\ e^{i(Mx+Ny+Pz+Bt)}, \end{equation}$

(7.4)

in which $M, N, P$ are the normalized wave numbers, by plugging (7.4) into Eq (7.3), separation the coefficients of $e^{i(Mx+Ny+Pz+Wt)}$ one gets

$\begin{equation} B(M, N, P) = \ \ {\frac {{M}^{3}P\alpha+{M}^{3}N-MP\omega_{{1}}-NP\omega_{{2}}-{P} ^{2} \omega_{{3}}} \ \ {M\lambda_{{1}}+N\lambda_{{2}}+P\lambda_{{3}}} \ \ }. \end{equation}$

(7.5)

Proof. By putting (7.4) into (7.3), becomes

$\begin{equation} \delta\, \ \ {\frac {\partial ^{4}}{\partial {x}^{3}\partial y}}\overline{\Theta} +\alpha\, \delta\, \ \ {\frac {\partial ^{4}}{\partial {x}^{3} \partial z}} \overline{\Theta} +\lambda_{{1}}\delta\, \ \ {\frac { \partial ^{2}}{\partial t\partial x}}\overline{\Theta} + \lambda _{{2}}\delta\, \ \ {\frac {\partial ^{2} }{\partial t\partial y}}\overline{\Phi} +\lambda_{{3}}\delta\, \ \ {\frac { \partial ^{2}}{\partial t \partial z}}\overline{\Theta} +\omega_{{1}}\delta\, \ \ {\frac { \partial ^{2}}{\partial x\partial z}}\overline{\Theta} +\omega_ {{2} }\delta\, \ \ {\frac {\partial ^{2}}{\partial y\partial z}}\overline{\Theta} +\omega_{{3}}\delta\, \ \ {\frac {\partial ^{2}}{\partial {z}^ {2}}} \ \ \overline{ \Theta} \end{equation}$

(7.6)

$= {\mathrm{e}^{i \left( Mx+Ny+Pz+Bt \right) }}\delta\, \rho_{{1}} \left( {M} ^{3}P\alpha+{M}^{3}N-MP\omega_{{1}}-MB\lambda_{{1}}-NP\omega_{{2}}-NB \lambda_{{2}}-{P}^{2}\omega_{{3}}-PB\lambda_{{3}} \right),$

in which $\overline{\Theta} = \Theta(x, y, z, t)$ . By solving and simplifying we can determine the function of $B(M, N, P)$ as the following

$\begin{equation} B(M, N, P) = \ \ {\frac {{M}^{3}P\alpha+{M}^{3}N-MP\omega_{{1}}-NP\omega_{{2}}-{P} ^{2} \omega_{{3}}} \ \ {M\lambda_{{1}}+N\lambda_{{2}}+P\lambda_{{3}}} \ \ }. \end{equation}$

(7.7)

Accordingly, the considered solution was obtained. Thereupon the proof is perfect.

It is easy to notice that modulation stability occurs when $M\lambda_{{1} }+N\lambda_{{2}}+P\lambda_{{3}}\neq0$ . So, the modulation stability achieve spectrum $\Upsilon(B)$ will be as below form:

$\begin{equation} \Upsilon(B) = \ \ {\frac {{M}^{3}P\alpha+{M}^{3}N-MP\omega_{{1}}-NP\omega_{{2}}-{P} ^{2} \omega_{{3}}} \ \ {M\lambda_{{1}}+N\lambda_{{2}}+P\lambda_{{3}}} \ \ }. \end{equation}$

(7.8)

In - can be discovered that while the sign of $B(M, N, P)$ is positive for all quantity of $M$ . Furthermore, in can be observed if the $B(M, N, P)$ is positive or negative for some quantities of $M$ . Finally, in and can be perceived that while the sign of $B(M, N, P)$ is positive for all quantity of $M$ .

Figure 12. The graphic representation

$\Upsilon(B)$ for the wave number

$M$ via considering the diverse quantities

$\lambda_1 = 1, \lambda_2 = 1.5, \lambda_3 = 2, \omega_1 = 2.2, \omega_2 = -2, \omega_3 = 3, \alpha = 0.5$ .

DownLoad: Full-Size Img PowerPoint

Figure 13. The graphic representation

$\Upsilon(B)$ for the wave number

$M$ via considering the diverse quantities

$\lambda_1 = 1, \lambda_2 = 1.5, \lambda_3 = 2, \omega_1 = 2.2, \omega_2 = -2, \omega_3 = 3, \alpha = 0.5$ .

DownLoad: Full-Size Img PowerPoint

Figure 14. The graphic representation

$\Upsilon(B)$ for the wave number

$M$ via considering the diverse quantities

$\lambda_1 = 1, \lambda_2 = 1.5, \lambda_3 = 2, \omega_1 = 2.2, \omega_2 = -2, \omega_3 = 3, \alpha = 0.5$ .

DownLoad: Full-Size Img PowerPoint

8. Usage of SIVP for Eq (1.8)

Via employing the wave alteration $\xi = k(x+ay+bz-ct)$ in Eq (1.8) once can gain to the below ODE as

$\begin{equation} k^2(\alpha b+a)\Psi^{\prime \prime \prime \prime }+6k(\alpha b+a)\Psi^{\prime }\Psi^{\prime \prime }+(ab\omega_{{2}}-ac\lambda_{{2}}+{b} ^{2}\omega_{{3}}-bc\lambda_{{3}}+b \omega_{{1}}-c\lambda_{{1}} )\Psi^{\prime \prime } = 0, \end{equation}$

(8.1)

in which $\Psi = \Psi(\xi)$ and $\Psi^{\prime } = \frac{d\Psi}{d \xi}$ . According to the SIVP ^[16,17] and by multiplying Eq (8.1) with $\Psi^{\prime }$ and integrating once respect to $\xi$ , the following stationary integral will be arises

$\begin{equation} J = \int_{0}^{\infty}\left[A_1\left(\Psi^{\prime }\Psi^{\prime \prime \prime }- \frac{1}{2}(\Psi^{\prime \prime 2}\right)+\frac{1}{3}A_2(\Psi^{\prime 3}+ \frac{1}{2}A_3(\Psi^{\prime 2}\right]d\xi, \end{equation}$

(8.2)

in which

$A_1 = k^2(\alpha b+a), \ \ \ A_2 = 6k(\alpha b+a), \ \ \ A_3 = ab\omega_{{2} }-ac\lambda_{{2}}+{b}^{2}\omega_{{3}}-bc\lambda_{{3}}+b \omega_{{1} }-c\lambda_{{1}}.$

8.1. Case I

We utilize the solitary wave function as the following

$\begin{equation} u(\xi ) = \delta \ sech(\mu \xi ). \end{equation}$

(8.3)

Hence, the stationary integral transforms to

$\begin{eqnarray} J & = &\frac{1}{30}{k}^{2}{\delta }^{2}\mu \, -21\, \alpha \, b{k}^{2}{\mu } ^{2}-21\, a{k}^{2}{\mu }^{2}-8\, \alpha \, b\delta \, k\mu -8\, a\delta \, k\mu +5\, ab\omega _{{2}} \\ &&-5\, ac\lambda _{{2}}+5\, {b}^{2}\omega _{{3}}-5\, bc\lambda _{{\ 3} }+5\, b\omega _{{1}}-5\, c\lambda _{{1}}). \end{eqnarray}$

(8.4)

Based on the SIVP and using derivative $J$ respect to $A$ and $B$ , one get

$\begin{eqnarray} \frac{\partial J}{\partial A} & = &\frac{1}{15}{k}^{2}\delta \, \mu \, -21\, \alpha \, b{k}^{2}{\mu }^{2}-21\, a{k}^{2}{\mu }^{2}-8\, \alpha \, b\delta \, k\mu -8\, a\delta \, k\mu +5\, ab\omega _{{2}}-5\, ac\lambda _{{2}} \\ &&+5\, {b}^{2}\omega _{{3}}-5\, bc\lambda _{{3}}+5\, b\omega _{{1}}-5\, c\lambda _{{1}})+\frac{1}{30}{k}^{2}{\delta }^{2}\mu \, \left( -8\, \alpha \, bk\mu -8\, ak\mu \right) = 0, \end{eqnarray}$

(8.5)

and

$\begin{eqnarray} \frac{\partial J}{\partial B} & = &\frac{1}{30}{k}^{2}{\delta }^{2}-21\, \alpha \, b{k}^{2}{\mu }^{2}-21\, a{\ k}^{2}{\mu }^{2}-8\, \alpha \, b\delta \, k\mu -8\, a\delta \, k\mu +5\, ab\omega _{{2}}-5\, ac\lambda _{{2}}+5\, {b}^{2}\omega _{{3}} \\ &&-5\, bc\lambda _{{3}}+5\, b\omega _{{1}}-5\, c\lambda _{{1}})+\frac{1}{30}{k} ^{2}{\delta }^{2}\mu \, \left( -42\, \alpha \, b{k}^{2}\mu -42\, a{k}^{2}\mu -8\, \alpha \, b\delta \, k-8\, a\delta \, k\right) = 0. \end{eqnarray}$

(8.6)

Solve the Eqs (8.5) and (8.6), become

$\begin{equation} \delta = \pm \frac{21}{2} \ \ {\frac{ab\omega _{{2}}-ac\lambda _{{2}}+{b} ^{2}\omega _{{3}}-bc\lambda _{{3}}+b\omega _{{1}}-c\lambda _{{1}}} \ \ {\sqrt{ -\left( 21\, \alpha \, b+21\, a\right) \left( ab\omega _{{2}}-ac\lambda _{{2}}+{ b}^{2}\omega _{{3}}-bc\lambda _{{3}}+b\omega _{{1}}-c\lambda _{{1}}\right) }} }, \ \ \ \end{equation}$

(8.7)

$\mu = \pm \frac{1}{21} \ \ {\frac{\sqrt{-\left( 21\, \alpha \, b+21\, a\right) \left( ab\omega _{{2}}-ac\lambda _{{2}}+{b}^{2}\omega _{{3}}-bc\lambda _{{3} }+b\omega _{{1}}-c\lambda _{{1}}\right) }}{\left( \alpha \, b+a\right) k}}.$

The condition can be obtained as below

$\begin{equation} \left( \alpha \, b+a\right) \left( ab\omega _{{2}}-ac\lambda _{{2}}+{b} ^{2}\omega _{{3}}-bc\lambda _{{3}}+b\omega _{{1}}-c\lambda _{{1}}\right) < 0. \end{equation}$

(8.8)

Finally, the solitary solution received by utilizing of SIVP can be reached as

$\begin{equation} \Psi (x, y, z, t) = \delta \ \mathrm{sech}\left[ k\mu (x+ay+bz-ct)\right] . \end{equation}$

(8.9)

8.2. Case II

We utilize the bright wave function as the following

$\begin{equation} u(\xi ) = \delta \ \mathrm{sech}^{2}(\mu \xi ). \end{equation}$

(8.10)

Hence, the stationary integral transforms to

$\begin{eqnarray} J & = &- \ \ {\frac{2\, {\delta }^{2}\mu (120\, \alpha \, b{k}^{2}{\mu }^{2}+120\, a{k} ^{2}{\mu }^{2}+35\, \alpha \, b\delta \, k\mu +35\, a\delta \, k\mu -14\, ab\omega _{{2}}} \ \ {105}} \\ &&+\frac{14\, ac\lambda _{{2}}-14\, {b}^{2}\omega _{{3}}+14\, bc\lambda _{{3} }-14\, b\omega _{{1}}+14\, c\lambda _{{1}})}{105}. \end{eqnarray}$

(8.11)

Based on the SIVP and using derivative $J$ respect to $A$ and $B$ , one get

$\begin{eqnarray} \frac{\partial J}{\partial A} & = &- \ \ {\frac{4\, \delta \, \mu (120\, \alpha \, b{k} ^{2}{\mu }^{2}+120\, a{k}^{2}{\mu }^{2}+35\, \alpha \, b\delta \, k\mu +35\, a\delta \, k\mu -14\, ab\omega _{{2}}+14\, ac\lambda _{{2}}} \ \ {105}} \\ &&+\frac{-14\, {b}^{2}\omega _{{3}}+14\, bc\lambda _{{3}}-14\, b\omega _{{1} }+14\, c\lambda _{{1}})-2\, {\delta }^{2}\mu \, \left( 35\, \alpha \, bk\mu +35\, ak\mu \right) }{105} = 0. \end{eqnarray}$

(8.12)

and

$\begin{eqnarray} \frac{\partial J}{\partial B} & = &- \ \ {\frac{2\, {\delta }^{2}(120\, \alpha \, b{k} ^{2}{\mu }^{2}+120\, a{\ k}^{2}{\mu }^{2}+35\, \alpha \, b\delta \, k\mu +35\, a\delta \, k\mu -14\, ab\omega _{{2}}+14\, ac\lambda _{{2}}-14\, {b} ^{2}\omega _{{3}}} \ \ {105}} \\ &&+\frac{+14\, bc\lambda _{{3}}-14\, b\omega _{{1}}+14\, c\lambda _{{1}})-2\, { \delta }^{2}\mu \, \left( 240\, \alpha \, b{k}^{2}\mu +240\, a{k}^{2}\mu +35\, \alpha \, b\delta \, k+35\, a\delta \, k\right) }{105} = 0. \end{eqnarray}$

(8.13)

Solve the Eqs (8.12) and (8.13), become

$\begin{equation} \delta = \pm \frac{48}{5} \ \ {\frac{ab\omega _{{2}}-ac\lambda _{{2}}+{b} ^{2}\omega _{{3}}-bc\lambda _{{3}}+b\omega _{{1}}-c\lambda _{{1}}} \ \ {\sqrt{ -\left( 21\, \alpha \, b+21\, a\right) \left( ab\omega _{{2}}-ac\lambda _{{2}}+{ b}^{2}\omega _{{3}}-bc\lambda _{{3}}+b\omega _{{1}}-c\lambda _{{1}}\right) }} }, \ \ \ \end{equation}$

(8.14)

$\mu = \pm \frac{1}{30} \ \ {\frac{\sqrt{-\left( 21\, \alpha \, b+21\, a\right) \left( ab\omega _{{2}}-ac\lambda _{{2}}+{b}^{2}\omega _{{3}}-bc\lambda _{{3} }+b\omega _{{1}}-c\lambda _{{1}}\right) }}{\left( \alpha \, b+a\right) k}}.$

The condition of definition of the above relations can be expressed as

$\begin{equation} \left( \alpha \, b+a\right) \left( ab\omega _{{2}}-ac\lambda _{{2}}+{b} ^{2}\omega _{{3}}-bc\lambda _{{3}}+b\omega _{{1}}-c\lambda _{{1}}\right) < 0. \end{equation}$

(8.15)

Finally, the solitary solution gained by utilizing of SIVP will be as

$\begin{equation} \Psi (x, y, z, t) = \delta \ \mathrm{sech}^{2}\left[ k\mu (x+ay+bz-ct)\right] . \end{equation}$

(8.16)

8.3. Case III

Assume the dark soliton wave solution be as the below case as

$\begin{equation} u(\xi ) = \delta \ \tanh ^{2}(\mu \xi ). \end{equation}$

(8.17)

Hence, the stationary integral transforms to

$\begin{eqnarray} J & = & \ \ {\frac{2\, {\delta }^{2}\mu (-120\, \alpha \, b{k}^{2}{\mu }^{2}-120\, a{k} ^{2}{\mu }^{2}+35\, \alpha \, b\delta \, k\mu +35\, a\delta \, k\mu +14\, ab\omega _{{2}}} \ \ {105}} \\ &&+\frac{-14\, ac\lambda _{{2}}+14\, {b}^{2}\omega _{{3}}-14\, bc\lambda _{{3} }+14\, b\omega _{{1}}-14\, c\lambda _{{1}})}{105}. \end{eqnarray}$

(8.18)

Based on the SIVP and using derivative $J$ respect to $A$ and $B$ , one get

$\begin{eqnarray} \frac{\partial J}{\partial \delta } & = & \ \ {\frac{4\, \delta \, \mu (-120\, \alpha \, b{k}^{2}{\mu }^{2}-120\, a{k}^{2}{\mu }^{2}+35\, \alpha \, b\delta \, k\mu +35\, a\delta \, k\mu +14\, ab\omega _{{2}}-14\, ac\lambda _{{2}}} \ \ {105}} \\ &&+\frac{+14\, {b}^{2}\omega _{{3}}-14\, bc\lambda _{{3}}+14\, b\omega _{{1} }-14\, c\lambda _{{1}})+2\, {\delta }^{2}\mu \, \left( 35\, \alpha \, bk\mu +35\, ak\mu \right) }{105} = 0, \end{eqnarray}$

(8.19)

and

$\begin{eqnarray} \frac{\partial J}{\partial \mu } & = & \ \ {\frac{2\, {\delta }^{2}(-120\, \alpha \, b{k }^{2}{\mu }^{2}-120\, a{\ k}^{2}{\mu }^{2}+35\, \alpha \, b\delta \, k\mu +35\, a\delta \, k\mu +14\, ab\omega _{{2}}-14\, ac\lambda _{{2}}+}{105}} \\ &&+\frac{14\, {b}^{2}\omega _{{3}}-14\, bc\lambda _{{3}}+14\, b\omega _{{1} }-14\, c\lambda _{{1}})+2\, {\delta }^{2}\mu \, \left( -240\, \alpha \, b{k} ^{2}\mu -240\, a{k}^{2}\mu +35\, \alpha \, b\delta \, k+35\, a\delta \, k\right) }{ 105} = 0. \end{eqnarray}$

(8.20)

Solve the Eqs (8.19) and (8.20), one get

$\begin{equation} \delta = \mp \frac{48}{5} \ \ {\frac{ab\omega _{{2}}-ac\lambda _{{2}}+{b} ^{2}\omega _{{3}}-bc\lambda _{{3}}+b\omega _{{1}}-c\lambda _{{1}}} \ \ {\sqrt{ -\left( 21\, \alpha \, b+21\, a\right) \left( ab\omega _{{2}}-ac\lambda _{{2}}+{ b}^{2}\omega _{{3}}-bc\lambda _{{3}}+b\omega _{{1}}-c\lambda _{{1}}\right) }} }, \ \ \ \end{equation}$

(8.21)

The condition of definition of the above relations can be presented the following form

$\begin{equation} \left( \alpha \, b+a\right) \left( ab\omega _{{2}}-ac\lambda _{{2}}+{b} ^{2}\omega _{{3}}-bc\lambda _{{3}}+b\omega _{{1}}-c\lambda _{{1}}\right) < 0. \end{equation}$

(8.22)

Finally, the dark solution acquired by utilizing of SIVP will be as

$\begin{equation} \Psi (x, y, z, t) = \delta \ \mathrm{tanh}^{2}\left[ k\mu (x+ay+bz-ct)\right] . \end{equation}$

(8.23)

8.4. Case IV

Let the singular soliton wave solution be as the below case as

$\begin{equation} u(\xi ) = \delta \ csch^{2}(\mu \xi ). \end{equation}$

(8.24)

Then, the stationary integral transforms to

$\begin{eqnarray} J & = &- \ \ {\frac{2\, {\delta }^{2}\mu (-120\, \alpha \, b{k}^{2}{\mu }^{2}-120\, a{k }^{2}{\mu }^{2}-70\, \alpha \, b\delta \, k\mu -70\, a\delta \, k\mu +14\, ab\omega _{{2}}} \ \ {105}} \\ &&+\frac{-14\, ac\lambda _{{2}}+14\, {b}^{2}\omega _{{3}}-14\, bc\lambda _{{3} }+14\, b\omega _{{1}}-14\, c\lambda _{{1}})}{105}. \end{eqnarray}$

(8.25)

Based on the SIVP and using derivative $J$ respect to $A$ and $B$ , become

$\begin{eqnarray} \frac{\partial J}{\partial \delta } & = &- \ \ {\frac{4\, \delta \, \mu (-120\, \alpha \, b{k}^{2}{\mu }^{2}-120\, a{k}^{2}{\mu }^{2}-70\, \alpha \, b\delta \, k\mu -70\, a\delta \, k\mu +14\, ab\omega _{{2}}-14\, ac\lambda _{{2} }}{105}} \\ &&+\frac{+14\, {b}^{2}\omega _{{3}}-14\, bc\lambda _{{3}}+14\, b\omega _{{1} }-14\, c\lambda _{{1}})-2\, {\delta }^{2}\mu \, \left( -70\, \alpha \, bk\mu -70\, ak\mu \right) }{105} = 0 \end{eqnarray}$

(8.26)

and

$\begin{eqnarray} \frac{\partial J}{\partial \mu } & = &- \ \ {\frac{2\, {\delta }^{2}(-120\, \alpha \, b{ k}^{2}{\mu }^{2}-120\, a{k}^{2}{\mu }^{2}-70\, \alpha \, b\delta \, k\mu -70\, a\delta \, k\mu +14\, ab\omega _{{2}}-14\, ac\lambda _{{2}}+14\, {b} ^{2}\omega _{{3}}} \ \ {105}} \\ &&+\frac{-14\, bc\lambda _{{3}}+14\, b\omega _{{1}}-14\, c\lambda _{{1}})-2\, { \delta }^{2}\mu \, \left( -240\, \alpha \, b{k}^{2}\mu -240\, a{k}^{2}\mu -70\, \alpha \, b\delta \, k-70\, a\delta \, k\right) }{105} = 0. \end{eqnarray}$

(8.27)

Solve the Eqs (8.26) and (8.27), one get

$\begin{equation} \delta = \pm \frac{24}{5} \ \ {\frac{ab\omega _{{2}}-ac\lambda _{{2}}+{b} ^{2}\omega _{{3}}-bc\lambda _{{3}}+b\omega _{{1}}-c\lambda _{{1}}} \ \ {\sqrt{ -\left( 21\, \alpha \, b+21\, a\right) \left( ab\omega _{{2}}-ac\lambda _{{2}}+{ b}^{2}\omega _{{3}}-bc\lambda _{{3}}+b\omega _{{1}}-c\lambda _{{1}}\right) }} }, \ \ \ \end{equation}$

(8.28)

The condition of definition of the above relations can be presented as the below form as

$\begin{equation} \left( \alpha \, b+a\right) \left( ab\omega _{{2}}-ac\lambda _{{2}}+{b} ^{2}\omega _{{3}}-bc\lambda _{{3}}+b\omega _{{1}}-c\lambda _{{1}}\right) < 0. \end{equation}$

(8.29)

Finally, the singular solution acquired by utilizing of SIVP will be as

$\begin{equation} \Psi (x, y, z, t) = \delta \ \mathrm{csch}^{2}\left[ k\mu (x+ay+bz-ct)\right] . \end{equation}$

(8.30)

9. Conclusion

In this article, the MEFM employed for searching the MSSs for the gKP equation, which contains 1-wave, 2-wave, and 3-wave solutions. The periodic wave, cross-kink, and solitary wave solutions have been obtained. In continuing, the modulation instability applied to discuss the stability of earned solutions. It is quite visible that these novel schemes have plenty of family solutions containing rational exponential, hyperbolic, and periodic functions with selecting particular parameters. Also, the semi-inverse variational principle will be used for the gKP equation. Four major cases containing the solitary, bright, dark and singular wave solutions were studied from four different ansatzes.

By means of symbolic computation, these analytical solutions and corresponding rogue waves are obtained. Via various curve plots, density plot and three-dimensional plots, dynamical characteristics of these rouge waves are exhibited. Because of the strong nonlinear characteristic of Hirota bilinear method, the test function constructed by the Hirota operator, which can be regarded as the test function constructed by considered model. The results are beneficial to the study of the plasma, optics, acoustics, fluid dynamics and fluid mechanics. All computations in this paper have been employed quickly with the help of the Maple 18. Moreover, the method applied in this paper provides an effective tool to obtain exact solutions of nonlinear system and can in common use for other NLEEs.

Acknowledgments

This work is supported by the Education and scientific research project for young and middle-aged teachers of Fujian Province (No. JAT.190666-No.JAT200469)

Conflict of interest

The authors declare that there is no conflict of interests regarding the publication of this paper.

References

[1]	J. Dzielski, A. Kurdila, A benchmark control problem for supercavitating vehicles and an initial investigation of solution, J. Vib. Control, 9 (2003), 791–804. doi: 10.1177/1077546303009007004. doi: 10.1177/1077546303009007004
[2]	I. N. Kirschner, D. C. Kring, A. W. Stokes, N. E. Fine, J. S. Uhlman, Control strategies for supercavitating vehicles, J. J. Vib. Control, 8 (2002), 219–242. doi: 10.1177/107754602023818. doi: 10.1177/107754602023818
[3]	V. N. Semenenko, Artificial supercavitation, physics and calculation, in RTO AVT lecture series on supercavitating flows, Von Karman Institute, Brussels Belgium, 2001. Available from: https://www.researchgate.net/publication/235099692.
[4]	R. E. A. Arndt, Cavitation in vortical flows, Annu. Rev. Fluid Mech., 34 (2003), 143–175. doi: 10.1146/annurev.fluid.34.082301.114957. doi: 10.1146/annurev.fluid.34.082301.114957
[5]	D. E. Sanabria., G. J. Balas, R. E. A. Arndt, Modeling, control, and experimental validation of a high-speed supercavitating vehicle, IEEE J. Oceanic Eng., 40 (2015), 362–373. doi: 10.1109/JOE.2014.2312591. doi: 10.1109/JOE.2014.2312591
[6]	D. E. Sanabria, R. E. A. Arndt, Robust control of a small-scale supercavitating vehicle: From modeling to testing, Ocean Eng., 160 (2018), 412–424. doi: 10.1016/j.oceaneng.2018.04.060. doi: 10.1016/j.oceaneng.2018.04.060
[7]	X. Yuan, T. Xing, Hydrodynamic characteristics of a supercavitating vehicle's aft body, Ocean Eng., 114 (2016), 37–46. doi: 10.1016/j.oceaneng.2016.01.012. doi: 10.1016/j.oceaneng.2016.01.012
[8]	L. Zhang, S. Lin, C. Wang, D. Xie, J. Sun, A new simulation model for hydrodynamic behavior of rigid body in narrow space. Ocean Eng., 182 (2019), 427–441. doi: 10.1016/j.oceaneng.2019.04.046. doi: 10.1016/j.oceaneng.2019.04.046
[9]	X. Zhang, Y. Wei, Y. Han, T. Bai, K. Ma, Design and comparison of LQR and a novel robust backstepping controller for supercavitating vehicles, Trans. Inst. Meas. Control, 39 (2017), 149–162. doi: 10.1177/0142331215607614. doi: 10.1177/0142331215607614
[10]	Y. Shao, M. Mesbahi, G. J. Balas, Planing, switching, and supercavitating flight control, in AIAA Guidance, Navigation, and Control Conference and Exhibit, (2003). doi: 10.2514/6.2003-5724.
[11]	B. Vanek, J. Bokor, G. J. Balas, R. E. A. Arndt, Longitudinal motion control of a high-speed supercavitation vehicle, J. Vib. Control, 13 (2007), 159–184. doi: 10.1177/1077546307070226. doi: 10.1177/1077546307070226
[12]	X. Mao, Q. Wang, Nonlinear control design for a supercavitating vehicle, IEEE Trans. Contrl. Syst. Technol., 17 (2009), 816–832. doi: 10.1109/TCST.2009.2013338. doi: 10.1109/TCST.2009.2013338
[13]	Y. Han, Z. Xu, H. Guo, Robust predictive control of a supercavitating vehicle based on time-delay characteristics and parameter uncertainty, Ocean Eng., 237 (2021), 1–10. doi: 10.1016/j.oceaneng.2021.109627. doi: 10.1016/j.oceaneng.2021.109627
[14]	S. D. Escobar, G. J. Balas, R. E. A. Arndt, Planing avoidance control for supercavitating vehicles, in 2014 American Control Conference, (2014), 4979–4984. doi: 10.1109/ACC.2014.6859485.
[15]	X. Zhang, Y. Han, T. Bai, Y. Wei, K. Ma, H-infinity controller design using LMIs for high-speed underwater vehicles in presence of uncertainties and disturbances, Ocean Eng., 104 (2015), 359–369. doi: 10.1016/j.oceaneng.2015.05.026. doi: 10.1016/j.oceaneng.2015.05.026
[16]	X. Zhao, X. Ye, Sliding mode controller design for supercavitating vehicles, Ocean Eng., 184 (2019), 173–183. doi: 10.1016/j.oceaneng.2019.04.066. doi: 10.1016/j.oceaneng.2019.04.066
[17]	Y. Bai, J. D. Biggs, Z. Zhang, Y. Ding, Adaptive fault-tolerant control for longitudinal motion of supercavitating vehicles. Eur. J. Control, 57 (2021), 263–272. doi: 10.1016/j.ejcon.2020.06.002. doi: 10.1016/j.ejcon.2020.06.002
[18]	B. D. H. Phuc, S. D. Lee, S. S. You, N. S. Rathore, Nonlinear robust control of high-speed supercavitating vehicle in the vertical plane. J. Eng. Marit. Environ., 234 (2019), 510−519. doi: 10.1177/1475090219875861. doi: 10.1177/1475090219875861
[19]	B. Qiang, L. Zhang, Output feedback control design to enlarge the domain of attraction of a supercavitating vehicle subject to actuator saturation, in 32nd Institute of China Electronics Technology Group Corporation, 40 (2018): 3189−3200. doi: 10.1177/0142331217718898.
[20]	T. Akash, S. Pushpendra, L. K. Mohan, H. Jalpa, Fuzzy logic controller and game theory based distributed energy resources allocation, AIMS Energy, 8 (2020), 474−492. doi: 10.3934/energy.2020.3.474. doi: 10.3934/energy.2020.3.474
[21]	I. Katherin, L. W. Bambang, M. Ali, Intelligent distribution network design of sensor and actuator fault tolerant control system on wind turbine benchmark for Region Ⅱ, AIMS Energy, 7 (2019), 111–126. doi: 10.3934/ENERGY.2019.2.111. doi: 10.3934/ENERGY.2019.2.111
[22]	T. S. S Senarathna, K. T. M Udayanga Hemapala, Review of adaptive protection methods for microgrids, AIMS Energy, 7 (2019): 557–578. doi: 10.3934/energy.2019.5.557. doi: 10.3934/energy.2019.5.557
[23]	X. Le, J. Wang, Robust pole assignment for synthesizing feedback control systems using recurrent neural networks, IEEE Trans. Neural. Netw. Learn. Syst, 25 (2014), 383–393. doi: 10.1109/TNNLS.2013.2275732. doi: 10.1109/TNNLS.2013.2275732
[24]	B. Ralph, G. Stephen, Approaches to robust pole assignment, Int. J. Control, 49 (1989), 97–117. doi: 10.1080/00207178908559623. doi: 10.1080/00207178908559623
[25]	J. B. Correction, X. Luo, R. E. A. Arndt, Y. Wu, Numerical simulation of three dimensional cavitation shedding dynamics with special emphasis on cavitation-vortex interaction, Ocean Eng., 87 (2014), 64–77. doi: 10.1016/j.oceaneng.2014.05.005. doi: 10.1016/j.oceaneng.2014.05.005
[26]	X. Long, H. Cheng, B. Ji, R. E. A. Arndt, X. Peng, Large eddy simulation and Euler-Lagrangian coupling investigation of the transient cavitating turbulent flow around a twisted hydrofoil, Int. J. Multiphase Flow, 100 (2018): 41–56. doi: 10.1016/j.ijmultiphaseflow.2017.12.002. doi: 10.1016/j.ijmultiphaseflow.2017.12.002
[27]	A. Karn, R. E. A. Arndt, J. Hong, Gas entrainment behaviors in the formation and collapse of a ventilated supercavity, Exp. Therm. Fluid Sci., 79 (2016), 294–300. doi: 10.1016/j.expthermflusci.2016.08.003. doi: 10.1016/j.expthermflusci.2016.08.003
[28]	W. Zou, H. Liu, L. Xue, Three-dimensional ventilated supercavity on a maneuvering trajectory, Ocean Eng., 122 (2016), 97–104. doi: 10.1016/j.oceaneng.2016.06.023. doi: 10.1016/j.oceaneng.2016.06.023
[29]	S. Shao, Y. Wu, J. Haynes, R. E. A. Arndt, J. Hong, Investigation into the behaviors of ventilated supercavities in unsteady flow, Phys. Fluids, 30 (2018), 236–241. doi: 10.1063/1.5027629. doi: 10.1063/1.5027629
[30]	M. Murayama, Y. Yoshida, Y. Tsujimoto, Unsteady tip leakage vortex cavitation originating from the tip clearance of an oscillating hydrofoil, J. Fluids Eng., 128 (2006), 421–429. doi: 10.1115/1.2173290. doi: 10.1115/1.2173290
[31]	A. Karn, R. E. Arndt, J. Hong, An experimental investigation into supercavity closure mechanisms, J. Fluid Mech., 789 (2016), 259–284. doi:10.1017/jfm.2015.680. doi: 10.1017/jfm.2015.680

This article has been cited by:

1.	Chaudry Masood Khalique, Oke Davies Adeyemo, Kentse Maefo, Symmetry solutions and conservation laws of a new generalized 2D Bogoyavlensky-Konopelchenko equation of plasma physics, 2022, 7, 2473-6988, 9767, 10.3934/math.2022544
2.	K. Hosseini, D. Baleanu, S. Rezapour, S. Salahshour, M. Mirzazadeh, M. Samavat, Multi-complexiton and positive multi-complexiton structures to a generalized B-type Kadomtsev−Petviashvili equation, 2022, 24680133, 10.1016/j.joes.2022.06.020
3.	Abdul-Majid Wazwaz, Naisa S. Alatawi, Wedad Albalawi, S. A. El-Tantawy, Painlevé analysis for a new (3 +1 )-dimensional KP equation: Multiple-soliton and lump solutions, 2022, 140, 0295-5075, 52002, 10.1209/0295-5075/aca49f
4.	Yan Zhu, Chuyu Huang, Junjie Li, Runfa Zhang, Lump solitions, fractal soliton solutions, superposed periodic wave solutions and bright-dark soliton solutions of the generalized (3+1)-dimensional KP equation via BNNM, 2024, 112, 0924-090X, 17345, 10.1007/s11071-024-09911-2
5.	Adisie Fenta Agmas, Fasika Wondimu Gelu, Meselech Chima Fino, A robust, exponentially fitted higher-order numerical method for a two-parameter singularly perturbed boundary value problem, 2025, 10, 2297-4687, 10.3389/fams.2024.1501271

Reader Comments

Your name:*

Email:*
© 2022 the Author(s), licensee AIMS Press. This is an open access article distributed under the terms of the Creative Commons Attribution License (http://creativecommons.org/licenses/by/4.0)
