1.   Introduction

We consider the following hypersingular integral equation on a circle:

Equation (1.1), considered the natural integral equation for harmonic problems, aligns with the form derived by Yu ^[28,29]. While natural integral equations themselves hold limited direct significance for solving boundary value problems (BVPs), they become instrumental in unbounded domain BVPs ^[8]. By introducing artificial boundaries such as circles or ellipses and applying corresponding natural integral equations on these boundaries, domain decomposition methods and coupled algorithms can be effectively constructed ^[29].

Integrals of this kind possess several definitions and we present our definition as follows:

and

The equivalent of (1.2) and (1.3) can be similarly obtained in ^[32].

The composite middle rectangle rule remains applicable when the singular point coincides with the midpoint of each subinterval, leading to a superconvergence phenomenon. This allows us to derive the error expansion of the error functional. We leverage these asymptotic expansion results to develop an algorithmic scheme for solving hypersingular integral equations.

The hypersigular integral defined on the integral

has been paid much attention recently.

Hypersingular integrals frequently arise in boundary element methods and various physical problems, including fracture mechanics, elasticity, acoustics, and electromagnetic scattering ^[31]. Numerous methods have been devised to handle these integrals, such as Gaussian quadrature ^[9,10], Newton-Cotes rules ^{[3,12,16,17,19,25,26,27,28]}, transformation methods ^[5,7,11], and others ^{[2,4,11,24,30]}. These studies rigorously analyze trapezoidal-type quadrature formulas for weakly singular, singular (Cauchy principal value), and hypersingular integrals, providing full asymptotic expansions for error analysis ^{[33,34,35,36,37]}. Reference ^[38] explored product integration using a variant of the generalized Euler-Maclaurin summation formula, while ^[39] applied this formula to study the convergence of weakly singular Fredholm and Volterra integral equations. Hypersingular integral equations in potential theory was studied in ^[40], and modal analysis of a submerged elastic disk was studied by ^[43]. Superconvergence results for the hypersingular integral equation was presented in ^[41]. Singular integral operators ^[45], finite-part integrals of highly oscillatory functions ^[42], and hypersingular integrals ^[44] have been paid much attention in recent years.

The extrapolation method^[13,21,22] is based on the error function as

where $T(0) = a_0$ and $a_j$ are constants independent of $h$. In ^[14], a generalized trapezoidal rule for numerical computation of hypersingular integrals on intervals was introduced, with asymptotic error expansion proven. In ^[15], the composite trapezoidal rule for Hadamard finite-part integrals with the hypersingular kernel $1/\sin^2(x-s)$ was discussed, obtaining the main part of the asymptotic error expansion. In ^[18], two extrapolation algorithms were presented for hypersingular integrals on intervals, proving their convergence rates, which match those of classical middle rectangle rule approximations. In ^[20], an extrapolation algorithm for supersingular integrals was introduced.

Before presenting our main results, we first let

where $\tau\in[-1, 1]$ and

Set $J : = (-\infty)\bigcup(-1, 1)\bigcup(1, \infty)$, $W : C(J)\rightarrow C(-1, 1)$ and let

be the linear operator.

Compared with Gaussian quadrature and Newton-Cotes rules, the extrapolation method is more effective. In the following, the asymptotic error expansion of the middle rectangle rule for Hadamard finite-part integrals on a circle is given, based on the asymptotic error expansion, and an algorithm to solve the hypersingular integrals equation is presented. The asymptotic error expansion is

where $a_i(\tau)$ are functions independent of $h$ defined as

This paper provides the asymptotic error expansion of the middle rectangle rule for Hadamard finite-part integrals on circles. Based on this expansion, an algorithm for solving hypersingular integral equations is proposed. To avoid computing $a_i(\tau)$, an extrapolation algorithm is suggested for a given $\tau$. A series of $s_j$ values approximate the singular point $s$ with mesh refinement. Using extrapolation techniques, we achieve higher-order accuracy and obtain a posteriori error estimates. Additionally, a collocation scheme is constructed to solve hypersingular integral equations via extrapolation methods, with proven convergence rates.

2.   Main results

Let $c = t_0 < t_1 < \cdots < t_{n-1} < t_{n} = c+2\pi$ be a uniform partition of the interval $[c, c+2\pi]$ with mesh size $h = 2\pi/n$ and set

We define $f_C(t)$, the constant interpolation for $f(t)$, as

and a linear transformation

from the reference element $[-1, 1]$ to the subinterval $[t_{i}, t_{i+1}]$.

Replacing $f(t)$ in (1.1) with $f_{C}(t)$ produces the composite rectangle rule:

where $\omega_i(s)$ denotes the Cotes coefficients given by

and $E_{n}(f, s)$ is the error functional.

Let

and

We also define

and

If $F_{i}(\tau)$ is replaced by the Legendre polynomial, it is known that $\phi_{i, i+1}$ defines the Legendre function of the second kind ^[1]. Let

and

Define $K_s(t)$ as

Theorem 2.1. Assume $f(t) \in C^{\infty}[c, c+2\pi]$. For the middle rectangle rule $I_n(f; s)$ defined in (2.5) and $a_i(\tau)$ defined in (1.9), we have

where $s = t_{m-1}+(1+\tau)h/2, \ \ m = 1, 2, \cdots, n$.

Then the error function can be written as

From the error functional, we know that it is not convergence when the first term is $a_{0}(\tau)$. By the first part of $a_{0}(\tau) = 0$, we have the convergence rate $O(h)$ which is called the superconvergence phenomenon.

3.   Proof of Theorem 2.1

Define

where

By (2.4), we have

where

and $F_{i}(\tau)$ is defined as in(2.9).

Lemma 3.1. Let $K_s(t)$ be defined as in (2.13). For $t \in (t_{j-1}, t_{j})$, by linear transformation (2.6), we have

where

and $c_{j}$ is defined as in (3.5).

Proof. By the identity in ^[1],

and then we get

and

Then

which completes the proof.

Lemma 3.2. (See [18, Lemma 3.2]) Let $P_{n}(t), n = 0, 1, \cdots$, be the Legendre function ^[1] defined as

For the polynomial $t^n, n = 0, 1, \cdots$, it can be expanded by the Legendre function as

where $(a)_{n} = (a)(a+1)\cdots(a+n-1)$.

Lemma 3.3. Let $\phi_{i, i+1}(t)$ and $\phi_{ii}(t)$ be defined as in (2.10) and (2.11), respectively. Then

and

where

and

Proof. For $i = 2i_{1}$,

leads to

where $\omega_{2j-1}$ is defined as in (3.15) and $P_{j}(\tau)$ are Legendre polynomials. The first part of (3.13) follows immediately from the definition of $\phi_{i, i+1}(\tau)$. Since

then we have

with $a_{j} = -(4j+1)\sum_{k = 1}^{j}\omega_{2k-1}$, which leads to the first part of (3.14) by using the recurrence relation ^[1].

which completed the proof.

Lemma 3.4. Assume $s \in (t_{m-1}, t_{m})$, for some $m$, $c_{j}$ defined as in (3.5). Then, we have

Proof. By the equation of (1.2),

The second identity can be obtained similarly.

Lemma 3.5. Under the assumption of Lemma 3.4, then we have

Proof. We have:

The second part of this Lemma 3.4 can be obtained similarly.

Lemma 3.6. For $k > i+1$, it holds that

Proof. The proof of (3.23) can be obtained similarly to Lemma 3.4 or Lemma 3.5.

Lemma 3.7. Suppose $f(t) \in C^{\infty}[c, c+2\pi]$. If $s\neq t_j$, for any $j = 1, 2, \cdots, n$, then it holds that

Proof. By taking the Taylor expansion for $f(t_{j-1/2})$, we have

and thus,

and

Combining (3.25) and (3.26) leads to (3.24).

Define

3.1.   Proof of Theorem 2.1

Proof.

By (3.27) of $\mathcal{H}_j(t)$, we have

Putting (3.28) and (3.29) together yields

where

The proof is complete.

For $i = 1$,

where

has been used. When $\tau = 0$, we get $a_{0}(\tau) = 0$ ^[6]. This is not the same as the case with a singular point located on the interval. The reason is that on the circle each subinterval is equal so we just consider the case of $s$ located at the middle of the interval.

At last, we suggest the modified composite middle rectangle rule, denoting by $\tilde{I}_{n}(f, s)$, defined by

4.   Extrapolation algorithm

Following asymptotic expansion,

For the given $s$ and positive integer $n_0$, we have

First, we partition $[c, c+2\pi]$ into $n_0$ equal subintervals to get a mesh denoted by $\Pi_1$ with mesh size $h_1 = 2\pi/n_0$. Then $\Pi_1$ is refined to get mesh $\Pi_2$ with mesh size $h_2 = h_1/2$. In this way, a series of meshes $\{\Pi_j\}(j = 1, 2, \cdots)$ is obtained in which $\Pi_j$ is refined from $\Pi_{j-1}$ with mesh size denoted by $h_j$. The extrapolation scheme is presented in Table 1.

Define

and

The extrapolation algorithm takes the form of:

Theorem 4.1. Under the same condition of Theorem 2.1, for a given $\tau$ and (4.2), we have

and

Proof. By Eq (4.1), we get

and

Putting (4.5)–(4.7) together, we have

where

where $b_i(s, \tau)$ is a constant for a given $\tau$. By (4.8), we also have

By (4.8) and (4.10), with $h_j = 2h_{j+1}$, we have

which implies

and

The accuracy $O(h^{3})$ can be obtained after performing the extrapolation process.

In order to directly use the error expansion of (4.1), we presented the following the new partition as $c = t_{00} < t_{01} < \cdots < t_{0, n-1} < t_{0n} = c+2\pi$ with $t_{0i} = t_{i}+\frac{h}{2}, i = 0, 1, \cdots, n-1$ and

Then we have the approximate formula:

and get

and then we find the following theorem similarly as with Theorem 2.1.

Theorem 4.2. Assume $f(t) \in C^{\infty}[c, c+2\pi]$. For the rectangle rule $\tilde{I}_n(f; s)$ defined in (4.15) and $a_{2i+1}(\tau)$ defined in (1.9), independent of $h$ and $s$, such that

where $s = t_{m-1}+(1+\tau)h/2, \ \ m = 1, 2, \cdots, n$.

Similarly as extrapolation scheme $T(h_j)$, new extrapolation scheme is presented in Table 2.

Theorem 4.3. Under the asymptotic expansion of Theorem 4.2, we have

and the posteriori asymptotic error estimate is given by

The proof of Theorem 4.3 can be similarly obtained as with Theorem 4.1, so we omitted it here.

5.   Extrapolation scheme for the hypersingular integral equation

Consider

with

As in ^[29], under the compatibility condition (5.2), there exists a unique solution up to an additive constant for (5.1). With periodical condition

there is a unique solution of (5.1).

Applying $\tilde{I}_{n}(f, s)$ to approximate the hypersingular integral in (5.1) and using $\hat{t}_k = t_{k-1}+h/2(k = 1, 2, \cdots, n)$ of each subinterval to be a collocation point, we get

denoted by

where

and $f_k = f(\hat{t}_k)(k = 1, 2, \cdots, n)$. Obviously, $\mathcal{A}_n$ is a circulant matrix and also a symmetric Toeplitz matrix. Since,

we see that $\mathcal{A}_n$ is singular.

The regularizing factor $\gamma_{0n}$ (see Reference ^[23]) in (5.4) is introduced, which leads to

where $\gamma_{0n}$ has the form

System (5.8) is denoted as

where

and $e_n = (\underbrace{1, 1, \cdots, 1}_{n})$.

Linear system (5.8) can be rewritten as

where $f_1 = f_{n+1}$ has been used. Let $v_m = -(f_{m+1}-f_m)/h$, and we get

The following lemma has been proved in ^[23].

Lemma 5.1. ([23, Theorem 6.2.1, §6.2, Chapter 6]) For Eq (5.13), its solution is

Lemma 5.2. ([6, Lemma 4.2]) Let $\mathcal{B}_{n+1} = (b_{ik})_{(n+1)\times (n+1)}$ be the inverse matrix of $\mathcal{A}_{n+1}$, defined in (5.10). Then,

(1) $\mathcal{B}_{n+1}$ is expressed as

where

(2) $\mathcal{B}_n$ is a Toeplitz and also circulant matrix.

(3) for $i = 1, 2, \cdots, n$, we have

5.1.   Advantage of circulant matrices

Circulant matrices have unique advantages in matrix operations, such as matrix multiplication. It can greatly save the calculation time and improve the calculation efficiency. The circular matrix only needs to store the elements of the first row (or the first column) to completely determine the entire matrix, because the remaining row (or column) elements are obtained from the cyclic shift of the first row (or column) elements. Circulant matrices have many good mathematical properties, such as the fact that their eigenvalues and eigenvectors can be calculated analytically, which makes it easier to analyze and deal with circulant matrices than general matrices in solving linear equations and eigenvalue problems.

We present the main theorem of this section.

Theorem 5.1. The solution of linear system (5.8) or (5.10)is

Proof. Let ${\bf F}_{n+1}^e = (0, f(\hat{t}_1), f(\hat{t}_2), \cdots, f(\hat{t}_n))^T$ be the exact vector. Then, from (5.10), we get

which implies

where $\{b_{ik}\}$ are the entries of $\mathcal{B}_{n+1}$ and $\tilde{E}_{n}(f, s)$ is defined in (4.15).

For the first part of $\frac1{2\pi} \sum_{m = 1}^n g(\hat{t}_m) h$ of the rectangle rule to compute the definite integral $\frac1{2\pi} \int_{0}^{2\pi} g(t) dt$.

Then we have

By (5.24) and (5.20), we obtain

and

Then we have

where (5.19) and (5.20) has been used.

6.   Numerical example

Example 6.1. We consider (1.1) with density function $f(t) = 1+2\cos(t)+ 2\cos(2t), c = -\pi, c+2\pi = \pi$.

Numerical results are presented in Table 3 for $s = t_{[n/4]}+(1+\tau)h/2$. The right half of Table 3 shows that the accuracy of $\tilde{I}_{n}(s, f)$ is always $O(h^2)$. However, from the left half, the accuracy is $O(h^2)$ if $s$ is located at the superconvergence point $(\tau = 0)$, and if $\tau\ne 0$, the middle rectangle rule is divergent.

Example 6.2. We still consider $f (t) = 1+2\cos(t)+ 2\cos(2t), c = -\pi, c+2\pi = \pi$. For $s = -\pi/2$, and $g(s) = 5.026548245744136e+001$, we use $s = t_{[n/4]}+(\tau+1) h/2$ with $\tau = 0$ to compute $s = -\pi/2$.

For $s = 0$ and $g(s) = -7.539822368615504e+01$, we also use $s = t_{[n/2]}+(\tau+1) h/2$ with $\tau = 0$ to compute $s = 0$.

In Tables 4 and 6, we present the error of the middle rectangle rule as $h^2$, $h^{4}$, $h^{6}$, and $h^{8}$, respectively. In Tables 5 and 7, the convergence rates $h^2$, $h^{4}$, and $h^{6}$ also agree with the theoretic analysis of Theorem 4.2.

In Tables 8 and 10, we present the error of the middle rectangle rule as $h$, $h^{2}$, $h^{3}$, and $h^{4}$, respectively. In Tables 9 and 11, the convergence rates $h$, $h^{2}$, and $h^{3}$ also agree with the theoretic analysis of Theorem 2.1.

Example 6.3. In this example, we will not only test our method on a hypersingular integral, but also solve a hypersingular integral equation $g(s) = -2\cos(2s)- 2\sin(2s), c = -\pi, c+2\pi = \pi$, while the analysis solution is $f(t) = \cos(2t)+ \sin(2t)$. The good numerical results indicate that our quadrature is efficient and accurate, which matches the theoretical analysis.

In Table 12, we list the numerical results at $s = 1.45122657606971$. Numerical results show that the convergence rate of the hypersingular integral equation has the order $O(h^2)$. With extrapolation methods, the order can reach $O(h^4)$, $O(h^6)$, and $O(h^8)$ in Table12.

7.   Conclusions

The article mainly focuses on a class of hypersingular integral equations in the boundary element method. A solution centered on the extrapolation algorithm is proposed, which is based on the asymptotic expansion of the error of the composite rectangle rule. By leveraging the asymptotic characteristics of the error of the composite rectangle rule, an extrapolation algorithm is constructed, providing a new approach to solving hypersingular integral equations. The algorithm is verified through in-depth theoretical and numerical examples. It is confirmed that the main part of the error function of the composite rectangle rule has an asymptotic expansion. Numerical experiments show that special functions significantly affect the convergence rate of the algorithm. This discovery has important guiding significance for subsequent algorithm optimization and improvement of computational efficiency. The adoption of this algorithm has two prominent advantages. First, it can obtain high-precision calculation results, meeting the precision requirements of practical applications; second, it is convenient for deriving a posteriori error estimates.
