Modeling and optimization of the tribological properties of an epoxy resin reinforced with nano graphene oxide nano Al₂O₃/MoS₂ particles by RSM

Olfat Ahmed Mahmood

Collage of Sciences, Diyala University, Diyala, Iraq

Received: 18 September 2025 Revised: 26 October 2025 Accepted: 31 October 2025 Published: 25 November 2025

The tribological properties of epoxy resin, a thermosetting polymer, were enhanced through the incorporation of nano- and micro-scale fillers. A hybrid composite was developed by dispersing nano-alumina and micro-molybdenum disulfide (MoS₂) within an epoxy matrix pre-modified with nano-graphene oxide. Specimen preparation was conducted via a laboratory ball mill, and a response surface methodology was utilized to optimize filler weight fractions. Evaluation via pin-on-disc testing (ASTM G99) under dry sliding conditions verified the improvement in tribological characteristics. The optimal formulation, containing 0.5 wt% graphene oxide, 3.92 wt% nano-alumina, and 3.99 wt% MoS₂, yielded a minimal coefficient of friction (0.12) and a low wear rate (2.3 × 10⁻⁶ mm³/N·m). Furthermore, this composite retained commendable mechanical properties, with a tensile strength of 75.4 MPa and a modulus of elasticity of 3.1 GPa.
- nano epoxy,
- nano graphene,
- coefficient of friction,
- wear rate,
- surface response method
Citation: Olfat Ahmed Mahmood. Modeling and optimization of the tribological properties of an epoxy resin reinforced with nano graphene oxide nano Al2O3/MoS2 particles by RSM[J]. AIMS Materials Science, 2025, 12(6): 1107-1125. doi: 10.3934/matersci.2025052

Related Papers:

Abstract

The tribological properties of epoxy resin, a thermosetting polymer, were enhanced through the incorporation of nano- and micro-scale fillers. A hybrid composite was developed by dispersing nano-alumina and micro-molybdenum disulfide (MoS₂) within an epoxy matrix pre-modified with nano-graphene oxide. Specimen preparation was conducted via a laboratory ball mill, and a response surface methodology was utilized to optimize filler weight fractions. Evaluation via pin-on-disc testing (ASTM G99) under dry sliding conditions verified the improvement in tribological characteristics. The optimal formulation, containing 0.5 wt% graphene oxide, 3.92 wt% nano-alumina, and 3.99 wt% MoS₂, yielded a minimal coefficient of friction (0.12) and a low wear rate (2.3 × 10⁻⁶ mm³/N·m). Furthermore, this composite retained commendable mechanical properties, with a tensile strength of 75.4 MPa and a modulus of elasticity of 3.1 GPa.

References

[1]	Menezes PL, Rohatgi PK, Omrani E (2018) Self-Lubricating Composites, Heidelberg: Springer Berlin. https://doi.org/10.1007/978-3-662-64243-6
[2]	Friedrich K, Schlarb AK (2008) Tribology of Polymeric Nanocomposites: Friction and Wear of Bulk Materials and Coatings, Oxford: Butterworth-Heinemann. https://doi.org/10.1016/C2011-0-09093-2
[3]	Ratna D, Chakraborty BC (2024) Chapter 1. Introduction to composite materials, In: Ratna D, Chakraborty BC, Polymer Matrix Composite Materials: Structural and Functional Applications, Berlin, Boston: De Gruyter, 1–72. https://doi.org/10.1515/9783110781571-001
[4]	Hutchings I, Shipway P (2017) Tribology: Friction and Wear of Engineering Materials, Oxford: Butterworth-Heinemann. https://www.sciencedirect.com/book/9780081009109/tribology
[5]	Omrani E, Rohatgi PK, Menezes PL (2019) Tribology and Applications of Self-Lubricating Materials, Boca Raton: CRC Press. https://doi.org/10.1201/9781315154077
[6]	Delogu F, Gorrasi G, Sorrentino A (2017) Fabrication of polymer nanocomposites via ball milling: Present status and future perspectives. Prog Mater Sci 86: 75–126. https://doi.org/10.1016/j.pmatsci.2017.01.003 doi: 10.1016/j.pmatsci.2017.01.003
[7]	Davim JP (2013) Tribology of Nanocomposites, Heidelberg: Springer Berlin. https://doi.org/10.1007/978-3-642-33882-3
[8]	Kurahatti RV, Surendranathan AO, Kumar AVR, et al. (2014) Dry sliding wear behaviour of epoxyreinforced with nanoZrO₂ particles. Procedia Mater Sci 5: 274–280. https://doi.org/10.1016/j.mspro.2014.07.267 doi: 10.1016/j.mspro.2014.07.267
[9]	Monteserín C, Blanco M, Aranzabe E, et al. (2017) Effects of graphene oxide and chemically-reduced graphene oxide on the dynamic mechanical properties of epoxy amine composites. Polymers 9: 449. https://doi.org/10.3390/polym9090449 doi: 10.3390/polym9090449
[10]	Wang Q, Xue Q, Liu H, et al. (1996) The effect of particle size of nanometer ZrO₂ on the tribological behaviour of PEEK. Wear 198: 216–219. https://doi.org/10.1016/0043-1648(96)07201-8 doi: 10.1016/0043-1648(96)07201-8
[11]	Chang L, Zhang Z (2006) Tribological properties of epoxy nanocomposites: Part Ⅱ. A combinative effect of short carbon fibre with nano-TiO₂. Wear 260: 869–878. https://doi.org/10.1016/j.wear.2005.04.002 doi: 10.1016/j.wear.2005.04.002
[12]	Shi G, Zhang MQ, Rong MZ, et al. (2003) Friction and wear of low nanometer Si₃N₄ filled epoxy composites. Wear 254: 784–796. https://doi.org/10.1016/S0043-1648(03)00190-X doi: 10.1016/S0043-1648(03)00190-X
[13]	Chen B, Ni BJ, Fu MX, et al. (2019) Effect of molybdenum disulfide exfoliation conditions on the mechanical properties of epoxy nanocomposites. Chin J Polym Sci 37: 687–692. https://doi.org/10.1007/s10118-019-2239-7 doi: 10.1007/s10118-019-2239-7
[14]	Tang LC, Wan YJ, Yan D, et al. (2013) The effect of graphene dispersion on the mechanical properties of graphene/epoxy composites. Carbon 60: 16–27. https://doi.org/10.1016/j.carbon.2013.03.050 doi: 10.1016/j.carbon.2013.03.050
[15]	El-Ghazaly A, Anis G, Salem HG (2017) Effect of graphene addition on the mechanical and tribological behavior of nanostructured AA2124 self-lubricating metal matrix composite. Compos Part A Appl Sci Manuf 95: 325–336. https://doi.org/10.1016/j.compositesa.2017.02.006 doi: 10.1016/j.compositesa.2017.02.006
[16]	ASTM International (2017) Standard test method for wear testing with a pin-on-disk apparatus. ASTM G99-17.
[17]	Berman D, Erdemir A, Sumant AV (2014) Graphene: A new emerging lubricant. Mater Today 17: 31–42. https://doi.org/10.1016/j.mattod.2013.12.003 doi: 10.1016/j.mattod.2013.12.003
[18]	Stachowiak GW, Batchelor AW (1993) Engineering Tribology, Boston: Butterworth-Heinemann. https://doi.org/10.1016/C2011-0-07515-4
