The food seeking behavior of slime mold: a macroscopic approach

1 Department of Mathematics, University of Mannheim, Mannheim 68159, Germany
2 School of Mathematical and Statistical Sciences, Arizona State University, Tempe AZ 85257-1804, USA

Special Issues: Stochastic Modeling and Statistical Inference in Biology

Starting from a particle model we derive a macroscopic aggregation-diffusion equation for the evolution of slime mold under the assumption of propagation of chaos in the large particle limit. We analyze properties of the macroscopic model in the stationary case and study the behavior of the slime mold between food sources. The efficient numerical simulation of the aggregation-diffusion equation allows for a detailed analysis of the interplay between the different regimes drift, interaction and diffusion.
  Article Metrics

Keywords interacting particle system; aggregation-diffusion equation; numerical simulations; agent based model; stochastic differential equation

Citation: Simone Göttlich, Stephan Knapp, Dylan Weber. The food seeking behavior of slime mold: a macroscopic approach. Mathematical Biosciences and Engineering, 2020, 17(6): 6631-6658. doi: 10.3934/mbe.2020345


  • 1. T. Nakagaki, Smart behavior of true slime mold in a labyrinth, Res. Microbiol., 152 (2001), 767-770.
  • 2. T. Nakagaki, R. Kobayashi, Y. Nishiura, T.Ueda, Obtaining multiple separate food sources: behavioural intelligence in the Physarum plasmodium, Proc. R. Soc. London, Ser. B, 271 (2004), 2305-2310.
  • 3. A. Adamatzky, From reaction-diffusion to Physarum computing, Nat. Comput., 8 (2009), 431- 447.
  • 4. A. Adamatzky, Developing proximity graphs by P. polycephalum: Does the plasmodium follow the toussaint hierarchy?, Parallel Process. Lett., 19 (2009), 105-127.
  • 5. W. Baumgarten, T. Ueda, M. J. B. Hauser, Plasmodial vein networks of the slime mold Physarum polycephalum form regular graphs, Phys. Rev. E, 82 (2010), 046113.
  • 6. T. Latty, M. Beekman, Speed-accuracy trade-offs during foraging decisions in the acellular slime mould Physarum polycephalum, Proc. R. Soc. B, 278 (2011), 539-545.
  • 7. V. Bonifaci, K. Mehlhorn, G. Varma, Physarum can compute shortest paths, J. Theor. Biol., 309 (2012), 121-133.
  • 8. A. Adamatzky, Slime mold solves maze in one pass, assisted by gradient of chemo-attractants, IEEE Trans. NanoBioscience, 11 (2012), 131-134.
  • 9. C. Oettmeier, K. Brix, H. G. Döbereiner, Physarum polycephalum-a new take on a classic model system, J. Phys. D, 50 (2017), 413001.
  • 10. A. Tero, R. Kobayashi, T. Nakagaki, Physarum solver: A biologically inspired method of roadnetwork navigation, Phys. A, 363 (2006), 115-119.
  • 11. J. Jones, In Approximating the Behaviours of Physarum polycephalum for the Construction and Minimisation of Synthetic Transport Networks, International Conference on Unconventional Computation, Berlin, 2009, Springer, Berlin, 2009, 191-208.
  • 12. J. Jones, Characteristics of pattern formation and evolution in approximations of Physarum transport Networks, Artif. Life, 16 (2010), 127-153.
  • 13. J. Jones, Influences on the formation and evolution of Physarum polycephalum inspired emergent transport networks, Nat. Comput., 10 (2011), 1345-1369.
  • 14. A. Adamatzky, P. P. B. de Oliveira, Brazilian highways from slime mold's point of view, Kybernetes, 40 (2011), 1373-1394.
  • 15. J. N. Burchett, O. Elek, N. Tejos, J. X. Prochaska, T. M. Tripp, R. Bordoloi, et al., Revealing the dark threads of the cosmic web, Astrophys. J. Lett., 891 (2020), L35.
  • 16. Y. P. Gunji, T. Shirakawa, T. Niizato, T. Haruna, Minimal model of a cell connecting amoebic motion and adaptive transport networks, J. Theor. Biol., 253 (2008), 659-667.
  • 17. M. A. I. Tsompanas, G. Ch Sirakoulis, Modeling and hardware implementation of an amoeba-like cellular automaton, Bioinspiration Biomimetics, 7 (2012), 036013.
  • 18. Y. X. Liu, Z. L. Zhang, C. Gao, Y. H. Wu, Q. Tao, In A Physarum network evolution model based on IBTM, Advances in swarm intelligence, lecture notes in Computer Science, Berlin, 2013, Y. Tan, Y. H. Shi, H. W. Mo, Eds, Springer, Berlin, 2013, 19-26.
  • 19. Y. H. Wu, Z. L. Zhang, Y. Deng, H. Zhou, T. Qian, A new model to imitate the foraging behavior of Physarum polycephalum on a nutrient-poor substrate, Neurocomputing, 148 (2015), 63-69.
  • 20. Y. X. Liu, C. Gao, Z. L. Zhang, Y. H. Wu, M. X. Liang, L. Tao, et al., A new multi-agent system to simulate the foraging behaviors of Physarum, Nat. Comput., 16 (2017), 15-29.
  • 21. A. Tero, R. Kobayashi, T. Nakagaki, A mathematical model for adaptive transport network in path finding by true slime mold, J. Theor. Biol., 244 (2007), 553-564.
  • 22. A. Tero, K. Yumiki, R. Kobayashi, T. Saigusa, T. Nakagaki, Flow-network adaptation in Physarum amoebae, Theory Biosci., 127 (2008), 89-94.
  • 23. R. Borsche, S. Göttlich, A. Klar, P. Schillen, The scalar keller-segel model on networks, Math. Models Methods Appl. Sci., 24 (2014), 221-247.
  • 24. G. Bretti, R. Natalini, Numerical approximation of nonhomogeneous boundary conditions on networks for a hyperbolic system of chemotaxis modeling the Physarum dynamics, J. Comput. Methods Sci. Eng., 18 (2018), 85-115.
  • 25. J. A. Carrillo, K. Craig, F. S. Patacchini, A blob method for diffusion, Calculus Var. Partial Differ. Equations, 58 (2019), 53.
  • 26. L. Chen, S. Göttlich, Q. Yin, Mean Field Limit and Propagation of Chaos for a Pedestrian Flow Model, J. Stat. Phys., 166 (2017), 211-229.
  • 27. L. Chen, S. Göttlich, S. Knapp, Modeling of a diffusion with aggregation: rigorous derivation and numerical simulation, ESAIM: Math. Modell. Numer. Anal., 52 (2018), 567-593
  • 28. B. Øksendal, Stochastic Differential Equations, 2nd edition, Springer, Berlin, 2003.
  • 29. T. Nakagaki, H. Yamada, Á. Tóth, Maze-solving by an amoeboid organism, Nature, 407 (2000), 470.
  • 30. T. Nakagaki, H. Yamada, Á. Tóth, Path finding by tube morphogenesis in an amoeboid organism, Biophys. Chem., 92 (2001), 47-52.
  • 31. L. C. Evans, Partial Differential Equations, 2nd edition, American Mathematical Society, Rhode Island, 2010.
