A detailed chemical kinetic model for pyrolysis of the lignin model compound chroman

James Bland; Gabriel da Silva; James Bland; Gabriel da Silva

doi:10.3934/environsci.2013.1.12

AIMS Environmental Science

2014, Volume 1, Issue 1: 12-25. doi: 10.3934/environsci.2013.1.12

Previous Article Next Article

Research article

A detailed chemical kinetic model for pyrolysis of the lignin model compound chroman

James Bland ^1,2,
Gabriel da Silva ^{1
,
,}

1.
Department of Chemical and Biomolecular Engineering, The University of Melbourne, Victoria 3010, Australia;
2.
Department of Economics, Purdue University, West Lafayette, Indiana 47907, USA

Received: 11 November 2013 Accepted: 19 December 2013 Published: 19 December 2013

The pyrolysis of woody biomass, including the lignin component, is emerging as a potential technology for the production of renewable fuels and commodity chemicals. Here we describe the construction and implementation of an elementary chemical kinetic model for pyrolysis of the lignin model compound chroman and its reaction intermediate ortho-quinone methide (o-QM). The model is developed using both experimental and theoretical data, and represents a hybrid approach to kinetic modeling that has the potential to provide molecular level insight into reaction pathways and intermediates while accurately describing reaction rates and product formation. The kinetic model developed here can replicate all known aspects of chroman pyrolysis, and provides new information on elementary reaction steps. Chroman pyrolysis is found to proceed via an initial retro-Diels–Alder reaction to form o-QM + ethene (C₂H₄), followed by dissociation of o-QM to the C₆H₆ isomers benzene and fulvene (+ CO). At temperatures of around 1000–1200 K and above fulvene rapidly isomerizes to benzene, where an activation energy of around 270 kJ mol^-1 is required to reproduce experimental observations. A new G3SX level energy surface for the isomerization of fulvene to benzene supports this result. Our modeling also suggests that thermal decomposition of fulvene may be important at around 950 K and above. This study demonstrates that theoretical protocols can provide a significant contribution to the development of kinetic models for biomass pyrolysis by elucidating reaction mechanisms, intermediates, and products, and also by supplying realistic rate coefficients and thermochemical properties.
- Biomass,
- lignin,
- pyrolysis,
- kinetics,
- ab initio,
- transition state theory
Citation: James Bland, Gabriel da Silva. A detailed chemical kinetic model for pyrolysis of the lignin model compound chroman[J]. AIMS Environmental Science, 2014, 1(1): 12-25. doi: 10.3934/environsci.2013.1.12

Related Papers:

Abstract

The pyrolysis of woody biomass, including the lignin component, is emerging as a potential technology for the production of renewable fuels and commodity chemicals. Here we describe the construction and implementation of an elementary chemical kinetic model for pyrolysis of the lignin model compound chroman and its reaction intermediate ortho-quinone methide (o-QM). The model is developed using both experimental and theoretical data, and represents a hybrid approach to kinetic modeling that has the potential to provide molecular level insight into reaction pathways and intermediates while accurately describing reaction rates and product formation. The kinetic model developed here can replicate all known aspects of chroman pyrolysis, and provides new information on elementary reaction steps. Chroman pyrolysis is found to proceed via an initial retro-Diels–Alder reaction to form o-QM + ethene (C₂H₄), followed by dissociation of o-QM to the C₆H₆ isomers benzene and fulvene (+ CO). At temperatures of around 1000–1200 K and above fulvene rapidly isomerizes to benzene, where an activation energy of around 270 kJ mol^-1 is required to reproduce experimental observations. A new G3SX level energy surface for the isomerization of fulvene to benzene supports this result. Our modeling also suggests that thermal decomposition of fulvene may be important at around 950 K and above. This study demonstrates that theoretical protocols can provide a significant contribution to the development of kinetic models for biomass pyrolysis by elucidating reaction mechanisms, intermediates, and products, and also by supplying realistic rate coefficients and thermochemical properties.

References

[1]	Hou Z, Bennett CA, Klein MT, et al. (2010) Approaches and software tools for modeling lignin pyrolysis. Energy Fuels 24: 58-67. doi: 10.1021/ef900488k
[2]	Klein MT, Virk PS (2008) Modeling of lignin thermolysis. Energy Fuels 22: 2175-2182. doi: 10.1021/ef800285f
[3]	Britt PF, Kidder MK, Buchanan AC (2007) Oxygen substituent effects in the pyrolysis of phenethyl phenyl ethers. Energy Fuels 21: 3102-3108. doi: 10.1021/ef700354y
[4]	Beste A, Buchanan AC (2009) Computational study of bond dissociation enthalpies for lignin model compounds. Substituent effects in phenethyl phenyl ethers. J Org Chem 74: 2837-2841.
[5]	Beste A, Buchanan AC (2011) Kinetic analysis of the phenyl-shift reaction in b-O-4 lignin model compounds: A computational study. J Org Chem 76: 2195-2203. doi: 10.1021/jo2000385
[6]	Dorrestijn E, Pugin R, Nogales VC, et al. (1997) Thermal decomposition of chroman. Reactivity of o-quinone methide. J Org Chem 62: 4804-4810.
[7]	Bao JP, Zhu CS, Ma AL (2009) The relationship between methylated chromans and maturity of organic matter in the source rocks from Jianghan hypersaline basin. Sci China Ser D – Earth Sci 52: 34-41. doi: 10.1007/s11430-009-5018-4
[8]	Paul GC, Gajewski JJ (1993) o-Benzoquinone methide: An intermediate in the gas-phase pyrolysis of chroman. J Org Chem 58: 5060-5062. doi: 10.1021/jo00071a013
[9]	Dorrestijn E, Mulder P (1998) The automation of a reactor flow system with online GC analysis. J Anal App Pyrolysis 44: 167-179. doi: 10.1016/S0165-2370(97)00084-3
[10]	da Silva G, Bozzelli JW (2007) Quantum chemical study of the thermal decomposition of o-quinone methide (6-methylene-2,4-cyclohexadien-1-one). J Phys Chem A 111: 7987-7994.
[11]	Dorrestijn E, Mulder P (1999) The radical-induced decomposition of 2-methoxyphenol. J Chem Soc, Perkin Trans 2: 777-780.
[12]	Britt PF, Buchanan AC, Cooney MJ, et al. (2000) Flash vacuum pyrolysis of methoxy-substituted lignin model compounds. J Org Chem 65: 1376-1389. doi: 10.1021/jo991479k
[13]	da Silva G, Chen CC, Bozzelli JW (2007) Toluene combustion: Reaction paths, thermochemical properties, and kinetic analysis for the methylphenyl radical + O₂ reaction. J Phys Chem A 111: 8663-8676.
[14]	Prendergast MB, Cooper PA, Kirk BB, et al. (2013) Hydroxyl radical formation in the gas phase oxidation of distonic 2-methylphenyl radical cations. Phys Chem Chem Phys 15: 20577-20584. doi: 10.1039/c3cp53690d
[15]	da Silva G, Bozzelli JW (2009) Benzoxyl radical decomposition kinetics: Formation of benzaldehyde + H, phenyl + CH₂O, and benzene + HCO. J Phys Chem A 113: 6979-6986. doi: 10.1021/jp902458d
[16]	da Silva G, Bozzelli JW (2009) Kinetic modeling of the benzyl + HO₂ reaction. Proc Comb Inst 32: 287-294. doi: 10.1016/j.proci.2008.05.040
[17]	da Silva G, Hamdan MR, Bozzelli JW (2009) Oxidation of the benzyl radical: Mechanism, thermochemistry, and kinetics for the reactions of benzyl hydroperoxide. J Chem Theory Comput 5: 3185-3194. doi: 10.1021/ct900352f
[18]	da Silva G, Bozzelli JW (2010) On the reactivity of methylbenzenes. Comb Flame 157: 2175-2183. doi: 10.1016/j.combustflame.2010.06.001
[19]	Wentrup C, Muller P (1973) One-step synthesis of fulvene and fulvenallene: Thermolysis of alpha-coumaranone, phthalide, and benzocyclopropene. Tetrahedron Lett 14: 2915-2918. doi: 10.1016/S0040-4039(01)96281-1
[20]	Hosoya T, Kawamoto H, Saka S (2009) Role of methoxyl group in char formation from lignin-related compounds. J Anal Appl Pyrolysis 84: 79-83. doi: 10.1016/j.jaap.2008.10.024
[21]	Curtiss LA, Redfern PC, Raghavachari K, et al. (2001) Gaussian-3X (G3X) theory: Use of improved geometries, zero-point energies, and Hartree-Fock basis sets. J Chem Phys 114: 108-117. doi: 10.1063/1.1321305
[22]	Zheng J, Zhao Y, Truhlar DG (2009) The DBH24/08 database and its use to assess electornic structure model chemistries for chemical reaction barrier heights. J Chem Theory Comput 5: 808-821. doi: 10.1021/ct800568m
[23]	da Silva G (2013) G3X-K theory: A composite theoretical method for thermochemical kinetics. Chem. Phys Lett chem Phys let 558: 109-113.
[24]	Frisch MJ, et al., Gaussian 03, Revision D.01, Gaussian, Inc., Wallingford CT, 2004.
[25]	da Silva G, Moore EE, Bozzelli JW (2009) Decomposition of methylbenzyl radicals in the pyrolysis and oxidation of xylenes. J Phys Chem A 113: 10264-10278. doi: 10.1021/jp905722t
[26]	Mokrushin V, Bedanov V, Tsang W, et al. (2006) ChemRate, Version 1.5.2, National Institute of Standards and Testing, Gaithersburg, MD.
[27]	da Silva G, Dlugogorski BZ, Kennedy EM (2007) Elementary reaction step model of the N-nitrosation of ammonia. Int J Chem Kinet 39: 645-656. doi: 10.1002/kin.20280
[28]	da Silva G, Kennedy EM, Dlugogorski BZ (2007) Nucleophilic reactivity of aniline derivatives towards the nitroso group. J Phys Org Chem 20: 167-179. doi: 10.1002/poc.1142
[29]	Schraa, GJ, Arends IWCE, Mulder P (1994) Thermal decomposition of 2,3-dihydro-1,4-benzodioxin and 1,2-dimethoxybenzene. J Chem Soc Perkin Trans 2: 189-197.
[30]	Gaynor BJ, Gilbert RG, King KD, Harman PJ (1981) Kinetic study of the thermal isomerization of fulvene. Aust J Chem 34: 449-452. doi: 10.1071/CH9810449
[31]	Melius CF, Miller JA, Evleth EM (1992) Unimolecular reaction mechanisms involving C₃H₄, C₄H₄, and C₆H₆ hydrocarbon species. Symp (Int) Comb 24: 621-628. doi: 10.1016/S0082-0784(06)80076-7
[32]	Miller JA, Klippenstein SJ (2003) The recombination of propargyl radicals and other reactions on a C₆H₆ potential. J Phys Chem A 107: 7783-7799.
[33]	Soorkia S, Trevitt AJ, Selby TM, et al. (2010) Reaction of the C₂H radical with 1-butyne (C₄H₆): Low-temperature kinetics and isomer-specific product detection. J Phys Chem A 114: 3340-3354. doi: 10.1021/jp911132r
